Page 1
ALR15BIF
31.5" x 14.75" x 23.75" (H x W x D)
15" wide ADA compliant all-refrigerator for built-in or
freestanding use, with digital controls, LED light, lock,
panel-ready door, and black cabinet
Highlights:
32" height allows installation under lower ADA compliant
counters
Integrated door frame accepts overlay panels for a
customized look
Just under 15" wide for an easy fit, with a flush back design
to save space
Product Features:
ADA Compliant Sized just under 32" high to fit under lower ADA compliant counters
Built-in capable Make the best use of space by installing your appliance under the counter
Panel-ready door Integrated stainless steel door frame accepts full overlay panels for a custom look; panel size
should be 27 3/8" H x 14 11/16" W at 3/4" thickness
Digital thermostat Electronic controls for precise temperature management.
Digital display Temperature readout can be shown in Celsius or Fahrenheit
LED lighting Gentle illumination with an on/off switch
Frost-free operation No-frost operation ensures reduced maintenance
Adjustable glass shelves Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup
Door storage Two racks offer the perfect storage solution for tall bottles and condiments
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 [email protected] www.summitappliance.com
Page 2
ALR15BIF Specifications:
Overview
Height of Cabinet 31.5" (80 cm)
Width 14.75" (37 cm)
Depth 23.75" (60 cm)
Capacity 2.2 cu.ft. (62 L)
Defrost Type Frost-Free
Door Panel-Ready
Cabinet Black
US Electrical Safety ETL
Canadian Electrical
Safety
Sanitation ETL-S
Energy Usage/Year 240.0kWh/year
Amps 1.0
Voltage/Frequency 115 V AC/60 Hz
Weight 60.0 lbs. (27 kg)
Shipping Weight 65.0 lbs. (29 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Sabbath Mode Yes
Door Swing RHD
Reversible Factory Reversible
Shelf Type Glass
Shelf Qty 3
Full Door Shelf Qty 2
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior and
Refrigerant Type R600a
Refrigerant Amount 0.78oz.
High Side PSI 270.0
Low Side PSI 105.0
Level Legs Qty 4
Interior Light Yes
Temperature Range 36°F to 43°F
Dimensions
Interior Height 24.63" (63 cm)
Interior Width 12.0" (30 cm)
ETL-C
Exterior
Interior Depth 17.63" (45 cm)
Compressor Step Height 3.13" (8 cm)
Compressor Step Width 12.0" (30 cm)
Compressor Step Depth 5.25" (13 cm)
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 [email protected] www.summitappliance.com
