Page 1
VLT74
33.25" x 37.5" x 22.25" (H x W x D)
-35ºC laboratory 6.7 cu.ft. chest freezer with stainless steel
corner guards, NIST calibrated thermometer with alarm,
and lock
Highlights:
Designed to operate at -35ºC for select laboratory,
pharmacy, industrial, and other institutional storage needs
Includes an external NIST calibrated readout of the current
and high/low temperature with an audible alarm
Manual defrost operation and static cooling system
Product Features:
Low temperature chest freezer Operates at -35ºC for use in laboratories, research facilities, and other settings with lower
temperature cold storage needs
NIST calibrated temperature display Alarm includes continuous NIST calibrated display of the current interior and high/low
temperature, and can be switched from Celsius to Fahrenheit at the touch of a button
High/low temperature alarm Audible alarm sounds if the interior temperature rises or falls out of set range
Certificate of calibration 2-year certificate included for your records
Buffered temperature probe Thermometer probe is encased in a glycol-filled bottle and stored in a fixed box on the center
shelf. This is the ideal way to produce temperature readings closest to stored contents, as
recommended by the CDC and VFC's guidelines
Factory-installed lock Added security with a locking lid (2 keys included)
Manual defrost operation Static cooling system with a front drain for easier defrosting as needed
Digital controls Externally located digital thermostat allows you to adjust the temperature as needed without
opening the lid
Counterbalanced hinges The lid will remain open once lifted for easier loading
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 [email protected] www.summitappliance.com
Page 2
VLT74 Specifications:
Overview
Height of Cabinet 33.25" (84 cm)
Width 37.5" (95 cm)
Depth 22.25" (57 cm)
Depth with Handle 24.0" (61 cm)
Capacity 6.7 cu.ft. (190 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Shipping Weight 86.0 lbs. (39 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101086408
Freezer
Door Swing Lift-Up
Interior Height 26.0" (66 cm)
Interior Width 32.0" (81 cm)
Interior Depth 15.0" (38 cm)
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 1.76 oz.
High Side PSI 300.0
Low Side PSI 130.0
Compressor Step Height 8.75" (22 cm)
Compressor Step Width 7.75" (20 cm)
Compressor Step Depth 15.0" (38 cm)
