Summit Appliance TDCM1429 Specifications

CK36ELGLASS

40" x 36.13" x 23.63" (H x W x D)

36 inch wide all-in-one kitchenette in black with a 2-burner
115V smooth-top cooktop, 2-door refrigerator-freezer, sink,
and storage cabinet

Highlights:

Complete all-in-one convenience with a refrigerator­freezer, cooktop, sink, and storage compartment in just 36"

Black and stainless steel exterior finish brings a modern
look to your kitchen space

ENERGY STAR certified 2-door refrigerator-freezer
included

Product Features:

Complete one-piece kitchenette All-in-one kitchen is built with virtually everything you need for meal preparation
2-door refrigerator-freezer included CP34BSS is packaged inside the kitchenette. This 3.2 cu.ft. ENERGY STAR certified

refrigerator includes adjustable glass shelves, door storage, and a freezer compartment
Sink and faucet Stainless steel sink with ready-to-use faucet included
2-burner smooth-top cooktop Includes a 5 3/4" 600W front element and 7" 900W rear element in a smooth black finish for

easier cleanup and safer cooking
115V operation with pre-installed cords Both the cooktop (12 amps) and refrigerator (1.1 amps) include 3-pronged cords for easy

setup
Push-to-turn knobs Cooktop knobs require a small amount of force to turn the elements on, helping to prevent

accidents
Indicator lights Operating indicators light up to show which burner is in use
Black and stainless steel exterior finish Modern design with a jet black powder-coated metal cabinet, stainless steel surface, and

stainless steel refrigerator doors
One piece stainless steel countertop Easy-to-clean surface with a professional look

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [email protected] www.summitappliance.com

CK36ELGLASS Specifications:

Overview

Height of Cabinet 40.0" (102 cm)
Width 36.13" (92 cm)
Depth 23.63" (60 cm)
Depth with Handle 24.63" (63 cm)
Depth with door at 90° 41.88" (106 cm)
Capacity 3.2 cu.ft. (91 L)
Defrost Type Cycle
Door Black/SS
Cabinet Black
US Electrical Safety ETL
Canadian Electrical

Safety
Amps 13.1
Voltage/Frequency 115 V AC/60 Hz
Weight 116.0 lbs. (53 kg)
Shipping Weight 121.0 lbs. (55 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101033709

Kitchenette

Refrigerator Included CP34BSS
Refrigerator Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Shelf Type Glass
Shelf Qty 1
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Full Door Shelves 2
Can Storage Yes
Thermostat Type Dial
Interior Light Yes
Refrigerant Type R600a
Refrigerant Amount 1.16 oz.
High Side PSI 250.0
Low Side PSI 88.0
Cooking Type Smooth-Top

ETL-C

Cooktop

Number of Burners 2
Cooktop Controls Dial
Interior Height 1 18.5" (47 cm)
Interior Width 1 15.75" (40 cm)
Interior Depth 1 15.0" (38 cm)
Interior Height 2 7.5" (19 cm)
Interior Width 2 14.0" (36 cm)
Interior Depth 2 14.0" (36 cm)
Sink Height 7.25" (18 cm)
Sink Width 12.0" (30 cm)
Sink Depth 12.0" (30 cm)
