Summit SWC1840BCSSADALHD Specs

SWC1840BCSSADA

31.38" x 17.75" x 23.5" (H x W x D)

18" wide ADA compliant wine cellar for built-in or
freestanding use with stainless steel cabinet, digital
controls, and LED lighting

Highlights:

Commercially listed to NSF-7 standards
32" height allows installation under lower ADA compliant

counters
Less than 18" wide for a perfect fit

Product Features:

ADA compliant 32" height allows installation under lower ADA compliant counters
Built-in capable Make the best use of space by installing your appliance under the counter
Commercially approved ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
34 bottle capacity Versatile interior can store up to 34 standard 750ml Bordeaux style or wider Burgundy style

bottles
Stainless steel wrapped cabinet Stainless steel cabinet offers lasting durability and professional style
Professional towel bar handle Curved stainless steel handle provides an easy grip with professional style
Factory installed lock Keyed lock for a secure interior
Automatic defrost Reduced maintenance with auto defrost system
Digital thermostat Electronic controls for precise temperature management.

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

SWC1840BCSSADA Specifications:

Overview

Height of Cabinet 31.38" (80 cm)
Width 17.75" (45 cm)
Depth 23.5" (60 cm)
Capacity 3.3 cu.ft. (93 L)
Bottles 34 bottles
Defrost Type Automatic
Door Glass
Cabinet Stainless Steel
US Electrical Safety CSA
Amps 1.25
Voltage/Frequency 115 V AC/60 Hz
Weight 103.0 lbs. (47 kg)
Shipping Weight 123.0 lbs. (56 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Wine Cellar

Number of Zones 1
Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Shelf Type Wood
Shelf Qty 5
Thermostat Type Digital
Interior Light Yes
Fan Type Interior and Exterior
Refrigerant Type R600a
Refrigerant Amount 1.06 oz.
High Side PSI 150.0
Low Side PSI 50.0
Level Legs 4
Temperature Range 41º to 68ºF
