Summit SCR610BLX, SCR610BLXPNR, SCR610BLXCSS User Manual

COMMERCIAL

WINE CELLARS

X-Series Wine Cellars

SCR610BLX/CSS

SCR611GLOSX

SCR1401X/LH/CSS

CH Series Champagne Cellars

SCR610CH/CSS SCR611GLOSCH SCR1156CH/CSS

SCR1401/LH/CH/CSS

Owner’s Manual

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

Felix Storch, Inc. Summit Appliance Division ISO 9001:2015 registered

770 Garrison Avenue Bronx, NY 10474 www.summitappliance.com

Write Model and Serial No. (on lower left corner of inside cabinet) here:

________________________________________________

TABLE OF CONTENTS

Appliance Safety

Important Safeguards

3-4

Location of Parts

5-6

Installation Instructions

7-9

Before Using Your Appliance

Installation of Your Appliance

Electrical Connection

7-8

Extension Cord

Reversing the Door Swing of Your Appliance

8-9

Installing the Stainless Steel Handle

Operating Your Appliance

9-12

SCR1401* Series

9-11

SCR1156*, SCR610*, & SCR611GLOS* Series

Door Lock

Defrosting

Shelving

Care and Maintenance

Cleaning Your Wine Cellar

Power Failure

Vacations

Moving Your Appliance

Energy-Saving Tips

Troubleshooting

14-15

Limited Warranty

APPLIANCE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the Safety Alert Symbol and either the words "DANGER" or "WARNING".

DANGER means that failure to heed this safety statement may result in severe personal injury or death.

WARNING means that failure to heed this safety statement may result in extensive product damage, serious personal injury, or death.

All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury, and let you know what can happen if the instructions are not followed.

IMPORTANT SAFEGUARDS

Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precautions, including the following:

Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do

not use an extension cord. Replace all panels before operating. It is recommended that a separate circuit serving only your appliance be provided. Use receptacles

that cannot be turned off by a switch or pull chain. Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or

explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of

this or any other appliance. The fumes can create a fire hazard or explosion. Before proceeding with cleaning and maintenance operations, make sure the power line of the unit is

disconnected. Do not connect or disconnect the electric plug when your hands are wet. Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in

electrical shock or death. Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in

this manual. All other servicing should be referred to a qualified technician. This appliance is CFC- and HFC-free and contains a small quantity of Isobutane (R600a) which is

environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the

greenhouse effect. Care must be taken during transportation and setting up of the appliance that no

parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.

In the event of any damage:

- Avoid open flames and anything that creates a spark,

- Disconnect from the electrical power line,

- Air the room in which the appliance is located for several minutes and

- Contact the Service Department for advice.

The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a

leakage, if the appliance is in a small room, there is the danger of combustible gases building up. For every ounce of coolant at least 325 cubic feet of room space is required. The amount of coolant in the appliance is stated on the data plate inside the appliance. It is hazardous for anyone other than an Authorized Service Person to carry out servicing or repairs to this appliance.

Take serious care when handling, moving, and using the appliance to avoid either damaging the

refrigerant tubing or increasing the risk of a leak.

Replacing component parts and servicing shall be done by factory authorized service personnel so as

to minimize the risk of possible ignition due to incorrect parts or improper service.

FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL

Use two or more people to move and install appliance. Failure to do so can result in back or other

injury. To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.

Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This unit

must be installed in an area protected from the elements, such as wind, rain, water spray or drips. The appliance should not be located next to ovens, grills or other sources of high heat. The appliance must be installed with all electrical, water and drain connections in accordance with

state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in

accordance with the National Electrical Code and local codes and ordinances, is required. Do not kink or pinch the power supply cord of the appliance. The size of the fuse (or circuit breaker) should be 15 amperes. It is important that the appliance be leveled in order to work properly. You may need to make several

adjustments to level it. All installations must be in accordance with local plumbing code requirements. Make certain that the pipes are not pinched, kinked or damaged during installation. Check for leaks after connection. Never allow children to operate, play with or crawl inside the appliance. Although the unit has been tested at the factory, due to long-term transit and storage, the first batch

of cubes must be discarded. Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage

or discolor the interior. Use this appliance only for its intended purpose as described in this Owner’s Manual. Keep fingers out of the “pinch point” areas. Clearances between the doors and between the doors

and cabinet are necessarily small. Be careful closing doors when children are in the area.

Risk of child entrapment!

Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are

still dangerous, even if they will “just sit in the garage a few days”.

Before discarding your old refrigerator:

Take off the doors Leave the shelves in place so that children may not easily climb inside.

- SAVE THESE INSTRUCTIONS -

LOCATION OF PARTS

X-SERIES WINE CELLARS

Model shown: SCR1401X

Type equation here.

1. Digital control panel* (located in front kickplate on SCR610/11)

2. Power button

3. Light switch (upper panel & front grille on SCR1401; front grille on all others)

4. Digital display and controls

5. Door handle

6. Ventilation grille

7. Security lock

8. Adjustable leveling legs

X-series cellars feature fixed

diamond shelving racks designed to

store bottles horizontally as shown

on the right
