Summit SCR1841BLHD Specifications

SCR1841B

34.25" x 17.75" x 23.5" (H x W x D)

18" wide commercial glass door refrigerator designed for
the display and refrigeration of beverages or sealed food,
built-in or freestanding capable with digital controls, lock,
and LED light

Highlights:

Less than 18" wide for a perfect fit
Flexible design allows built-in or freestanding use under

counters
Commercially listed to NSF-7 standards and meets UL-471

Product Features:

Built-in capable Make the best use of space by installing your appliance under the counter
Commercially approved ETL-S listed to ANSI-NSF Standard 7 for use in commercial establishments
Fully finished black cabinet Allows the unit to be used freestanding
Stainless steel trimmed triple pane tempered

glass door
Factory installed lock Keyed security on the door
Digital thermostat Electronic controls for precise temperature management.
Digital display Temperature readout can be shown in Celsius or Fahrenheit
LED lighting Gentle illumination with an on/off switch
Automatic defrost Reduced maintenance with the convenience of auto defrost

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

Provides a full display of stored contents with a heat-safe double tempered design

SCR1841B Specifications:

Overview

Height of Cabinet 34.25" (87 cm)
Width 17.75" (45 cm)
Depth 23.5" (60 cm)
Depth with Handle 25.25" (64 cm)
Depth with door at 90° 39.75" (101 cm)
Capacity 2.7 cu.ft. (76 L)
Defrost Type Automatic
Door Glass
Cabinet Black
US Electrical Safety ETL
Canadian Electrical

Safety
Sanitation ETL-S
Energy Usage/Year 284.0kWh/year
Amps 1.25
Voltage/Frequency 115 V AC/60 Hz
Weight 95.0 lbs. (43 kg)
Shipping Weight 98.0 lbs. (44 kg)
Estimated Time to Ship Next day shipping
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator Features

Door Swing RHD
Reversible Yes
Shelf Type Chrome
Shelf Qty 4
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior and

Refrigerant Type R600a
Refrigerant Amount 1.06oz.
High Side PSI 150.0
Low Side PSI 50.0
Level Legs Qty 2
Interior Light Yes
Temperature Range 34º to 64ºF

Dimensions

Interior Height 21.5" (55 cm)

ETL-C

Exterior

Interior Width 12.75" (32 cm)
Interior Depth 16.75" (43 cm)
Compressor Step Height 4.75" (12 cm)
Compressor Step Width 12.75" (32 cm)
Compressor Step Depth 4.5" (11 cm)
