Summit SCM1800M2 User Manual

DUAL MAGNETRON COMMERCIAL

MICROWAVE OVEN

Model: SCM1800M2

User's manual

Please read these instructions carefully before installing and operating the oven.

In the space below, record the SERIAL NO. found on the nameplate of your oven and retain this information for future reference.

SERIAL NO. ________________________ Please save sales receipt for warranty.

FELIX STORCH, INC. Summit Appliance Division 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com

PPRREECCAAUUTTIIOONNSS TTOO AAVVOOIIDD PPOOSSSSIIBBLLEE EEXXPPOOSSUURREE

TTOO EEXXCCEESSSSIIVVEE MMIICCRROOWWAAVVEE EENNEERRGGYY

Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the:

a. Door (bent), b. Hinges and latches (broken or loosened), c. Door seals and sealing surfaces.

The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

TTAABBLLEE OOFF CCOONNTTEENNTTSS

PRECAUTIONS / MICROWAVE ENERGY .........................................................................1

IMPORTANT SAFETY INSTRUCTIONS .............................................................................2

INSTALLATION GUIDE .......................................................................................................4

GROUNDING INSTRUCTIONS ..........................................................................................6

UTENSILS GUIDE ...............................................................................................................7

COOKING TECHNIQUES ...................................................................................................8

SPECIFICATIONS ...............................................................................................................9

LOCATION OF PARTS ......................................................................................................10

CONTROL PANEL .............................................................................................................13

OPERATION INSTRUCTIONS ..........................................................................................14

MICROWAVE COOKING ..........................................................................................14

SA VE A MUL TI-STAGE COOKING SETTING TO A NUMBER KEY ....................... 114

HOW TO USE THE X2 PAD ......................................................................................15

MULTI-STAGE COOKING .........................................................................................16

COUNT OF OPERATIONS .......................................................................................16

SWITCH ....................................................................................................................17

ADJUST THE COOKING TIME .................................................................................17

CHILD-PROOF LOCK ...............................................................................................17

RETURN TO FACTORY SETTING ...........................................................................17

CARE AND CLEANING .....................................................................................................18

LIMITED WARRANTY ....................................................................................................... 19

IIMMPPOORRTTAANNTT SSAAFFEETTYY IINNSSTTRRUUCCTTIIOONNSS

When using electrical appliances, basic safety precautions should be followed. WARNING - To reduce the risk of burns, electric shock, fire, and injury to persons or exposure to

excessive microwave energy:

1. Read all instructions before using the appliance.

2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY" on page 1.

3. This appliance must be grounded. Connect only to properly grounded outlet. See "GROUNDING INSTRUCTIONS” on page 6.

4. Install or locate this appliance only in accordance with the provided installation instructions.

5. Some products such as whole eggs and sealed containers  for example, closed glass jars  can explode and should not be heated in this oven.

6. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, c ook, or dry food. It is not designed for industrial or laboratory use.

7. As with any appliance, close supervision is necessary when used by children.

8. To reduce the risk of fire in the oven cavity: a. Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible

materials are placed inside the oven to facilitate cooking. b. Remove wire twist-ties from paper or plastic bags before placing bag in oven. c. If materials inside the oven shoul d ignite, k eep oven door clos ed, turn oven off, and disconnect

the power cord or shut off power at the fuse or circuit breaker panel. d. Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or

food in the cavity when not in use.

9. Liquids such as water, coffee, or tea can be overheated beyond the boiling point without appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN V ERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to persons: a. Do not overheat the liquid. b. Stir the liquid both before and halfway through heating it. c. Do not use straight-sided containers with narrow necks. d. After heating, allow the container to stand in the microwave oven for a short time before

removing the container.

e. Use extreme care when inserting a spoon or other utensil into the container.

10. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in a microwave oven.

11. Pierce foods with heavy skins such as potatoes, whole squash, apples and chestnuts before cooking.

12. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be checked before serving in order to avoid burns.

13. Cooking utensils may become hot because of heat transferred from the heated food. Potholders

may be needed to handle the utensil.

14. Do not cover or block any openings on the appliance.

15. Do not store or use this appliance outdoors. Do not use this product near water, for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.

16. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it has been damaged or dropped.

17. Do not immerse cord or plug in water. Keep cord away from heated surfaces. Do not let cord hang over edge of table or counter.

18. Use only thermometers that are specifically designed for use in microwave ovens.

19. Do not operate any heating or cooking appliance beneath this microwave oven.

20.This appliance should be serviced only by qualified service personnel. Contact nearest authorized service facility for examination, repair, or adjustment.

21. When cleaning surfaces of door and oven that come together on closing the door, use only mild, nonabrasive soaps or detergents applied with a sponge or soft cloth.

22.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

SAVE THESE INSTRUCTIONS

○

IINNSSTTAALLLLAATTIIOONN GGUUIIDDEE

1. Make sure that all packing materials are removed, both inside and out of the oven.

2. Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches, and dents inside the cavity or on the door. If there is any damage, do not operate the oven but contact qualified service personnel.

3. This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.

4. Do not place the oven where heat, moisture or high humidity are generated, or near combustible materials.

5. For correct operation, the oven must have sufficient airflow. Allow 20cm of space above the oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on the appliance. Do not remove feet on which oven stands.

6. Make sure that the power supply cord is undamaged and does not run under the ov en or over any hot or sharp surface.

7. The socket must be readily accessible so that it can be easily unplugged in an emergency.

To replace the oven lamp

1 ○2 ○3

○

IINNSSTTAALLLLAATTIIOONN GGUUIIDDEE

Follow these steps to replace the oven lamp: (lamp type：

1. Unplug the oven and carefully loosen the screw of the lamp cover with a Phillips-head screwdriver.

2. Remove the lamp cover.

3. Gently turn the bulb in a counter-clockwise direction to take it out.

4. Insert the new bulb and turn it in a clockwise direction until it is firmly seated.

5. Re-install the lamp cover, screwing it into place. If you have a problem, please contact our Service Department at 1-800-932-4267 for help in replacing

the lamp.

E14A/T170 Power Supply： 230v~ 240v / 25w)
