Summit FF63BBIIF Specification Sheet

FF63BBIIF

33.25" x 23.63" x 23" (H x W x D)

Built-in undercounter auto defrost all-refrigerator for
residential use with a customizable door front to accept
overlay panels and black cabinet finish

Highlights:

Flexible design allows built-in or freestanding use in 24"
spaces

Customizable door front accepts full overlay panels for a
seamless look that can blend into cabinetry

Automatic defrost ensures minimum user maintenance

Product Features:

Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinets
Slim undercounter dimensions Ideal 24" footprint offers full 5.5 cu.ft. storage capacity in a slim fit
Panel-ready door Integrated stainless steel door frame allows you to mount full overlay panels over the door to

create a custom look that can blend into cabinetry with no exposed frame (panel size: 23

5/16" W x 28 1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Automatic defrost Reduced maintenance with auto defrost system
Adjustable glass shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for

a simple clean-up
Door shelves Store tall bottles and condiments right on the door for convenient access
Wine shelf Removable scalloped wine shelf is included to store champagne and wine bottles
Fruit and vegetable crisper Get the longest life and best taste out of produce by storing greens in a convenient slide

drawer
Interior light Automatically illuminates when you open the door

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

FF63BBIIF Specifications:

Overview

Height of Cabinet 33.25" (84 cm)
Width 23.63" (60 cm)
Depth 23.0" (58 cm)
Depth with door at 90° 45.38" (115 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door Panel-Ready
Cabinet Black
US Electrical Safety UL
Canadian Electrical

Safety
Sanitation ETL-S
Amps 1.3
Voltage/Frequency 115 V AC/60 Hz
Weight 100.0 lbs. (45 kg)
Shipping Weight 110.0 lbs. (50 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator Features

Door Swing RHD
Reversible Factory Reversible
Crisper Qty 1
Crisper Finish Opaque
Crisper Cover Glass
Shelf Type Glass
Shelf Qty 3
Full Door Shelf Qty 3
Adjustable Shelves Yes
Wine Bottle Shelves Yes
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R134a
Refrigerant Amount 1.7oz.
High Side PSI 285.0
Low Side PSI 70.0
Level Legs Qty 4
Interior Light Yes

Dimensions

ULC

Interior Height 26.25" (67 cm)
Interior Width 21.0" (53 cm)
Interior Depth 18.0" (46 cm)
Compressor Step Height 5.5" (14 cm)
Compressor Step Width 21.0" (53 cm)
Compressor Step Depth 6.0" (15 cm)
