Summit FF63BBIDTPUBADA Instruction Manual

FF63BBIDTPUBADA

32.25" x 23.63" x 23" (H x W x D)

Built-in undercounter ADA compliant craft beer Pub Cellar
in black with digital thermostat and deluxe interior

Highlights:

Perfect for storing or aging craft beer for long-term use
Digital thermostat lets you manage the temperature from

41º to 65ºF to best accommodate beer
Flexible design allows built-in or freestanding use in 24"

spaces

Product Features:

ADA compliant 32" height to fit under lower ADA compliant counters
Slim undercounter dimensions Ideal 24" footprint offers full 5.5 cu.ft. storage capacity in a slim fit
Built-in capable Make the best use of space by installing your appliance under the counter and flush with

other cabinets
Automatic defrost Reduced maintenance with auto defrost system
Designed for craft beer storage Wide range temperature control lets you manage the interior between 41º and 65ºF for

optimum storage of all types of beer
Digital thermostat Exterior thermostat located in kickplate lets you manage the temperature without opening the

door
Adjustable glass shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for

a simple clean-up
Door shelves Store tall bottles and condiments right on the door for convenient access
Scalloped bottle shelf Removable scalloped shelf is included to hold larger bottles in a horizontal configuration

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2008 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

FF63BBIDTPUBADA Specifications:

Overview

Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.25" (82 cm)
Width 23.63" (60 cm)
Depth 23.0" (58 cm)
Depth with Handle 24.63" (63 cm)
Depth with door at 90° 45.38" (115 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door Black
Cabinet Black
US Electrical Safety UL
Canadian Electrical

Safety
Energy Usage/Year 307.0kWh/year
Amps 1.0
Shipping Weight 104.0 lbs. (47 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Wine Cellar

Number of Zones 1
Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Shelf Type Glass and

Shelf Qty 3
Thermostat Type Digital
Interior Light Yes
Fan Type Exterior
Refrigerant Type R134a
Refrigerant Amount 1.7 oz.
High Side PSI 285.0
Low Side PSI 70.0
Interior Height 1 26.25" (67 cm)
Interior Width 1 21.0" (53 cm)
Interior Depth 1 18.0" (46 cm)
Compressor Step

Height
Compressor Step Width 21.0" (53 cm)

ULC

Scalloped

5.5" (14 cm)

Compressor Step Depth 6.0" (15 cm)
Level Legs 4
Temperature Range 41º to 65ºF
