Summit FF511LBIMED Instruction Manual

FF511LBIMED 33.5" x 19.25" x 21.38" (H x W x D)

20" wide all-refrigerator for built-in use, with internal fan,
lock, temperature alarm, and hospital grade plug

Highlights:

Flexible design allows built-in or freestanding use in 20" wide
spaces

Factory installed lock provides security you can count on
Simple maintenance with auto defrost interior
Internal fan complete with gel packs for stabilized interior

Slim 20" width Full 4.1 cu.ft. capacity inside conveniently slim footprint
Built-in capable Make the best use of space by installing your appliance under the counter
Fully finished white cabinet Allows the unit to be used freestanding
Factory installed lock Keyed security on the refrigerator door
Automatic defrost Reduced maintenance with auto defrost system
Internal fan with gel packs Fan-forced cooling ensures the unit is evenly cooled from top to bottom
High temperature alarm Warns of temperature fluctuations and includes an external temperature readout on the

door

Hospital grade cord with 'green dot'
plug

Adjustable shelves Rearrange refrigerator space to accommodate all sizes or remove shelves for simple

Interior light Turn the light on and off with a convenient rocker switch

Secure three-pronged cord for added unit safety

cleanup

Specifications:

Height 33.5 up to 34.5"
Width 19.25"
Depth 21.38"
Capacity 4.1 cu.ft.
Ext Depth with Handle 23.0"
Interior Height 1 28.5"
Interior Width 1 15.75"
Interior Depth 1 18.0"
Comp Step Height 8.0"
Comp Step Width 17.0"
Comp Step Depth 6.75"
Height Adjustable true
Shipping Weight 85.0 lbs.
Weight 64.0 lbs.
Canadian Electrical Safety ETL-C
Amps 1.4
US Electrical Safety ETL
Voltage/Frequency 115 V AC/60 Hz
Reversible Factory Reversible
Door Swing RHD
Shelf Quantity 3
Adjustable Shelf true
Shelf Type Wire
Defrost Type Automatic
Height to Hinge Cap 34.0"
Depth with door at 90° 39.5"
Thermostat Type Dial
Fan Type Interior
Light true
Refrigerant Type R134a
High Side PSI 205.0
Freon Oz 1.75
Low Side PSI 103.0
Level Legs Quantity 2
Compressor Warranty 5 Years
Parts/Labor Warranty 1 Year
