Summit FF32L User Manual

REFRIGERATOR

Model FF32L

INSTRUCTION MANUAL

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES

AND OPERATING INSTRUCTIONS. KEEP THIS MANUAL IN A SECURE LOCATION.

Write Serial Number (on back of unit) here:

_______________________________

Felix Storch, Inc Summit Appliance Division 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com

Table of Contents

Important Safeguards ............................................................................................. 2 - 3

Location of Parts .......................................................................................................... 4

Installation Instructions ..........................................................................................4 - 6

Before Using Your Refrigerator ........................................................................... 4

Installation of Your Refrigerator ...........................................................................5

Electrical Connection ......................................................................................5 - 6

Operating Your Refrigerator ...................................................................................6 - 7

Setting the Temperature Control ......................................................................... 6

Defrosting Your Refrigerator ................................................................................6

Normal Phenomena .............................................................................................7

Care and Maintenance ............................................................................................7 - 9

Cleaning Your Refrigerator ..................................................................................7

Vacation Time ......................................................................................................7

Moving Your Refrigerator ....................................................................................7

Energy-Saving Tips ............................................................................................. 8

Reversing the Door Swing of Your Refrigerator ...................................................8

Locking the Refrigerator ...................................................................................... 8

Changing the Light Bulb ......................................................................................9

Wiring Diagram .............................................................................................................9

Technical Information ..................................................................................................9

Problems with Your Refrigerator? ............................................................................ 10

Limited Warranty ........................................................................................................11

IMPORTANT SAFEGUARDS

Before the refrigerator is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the refrigerator, follow basic precautions, including the following:

 Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and

do not use an extension cord.

 It is recommended that a separate circuit, serving only your refrigerator be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

 Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or

explosion. And do not store or use gasoline or other flammable vapors and liquids inside or in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

 Do not use inflammable sprays in the vicinity of the refrigerator.  Before proceeding with cleaning and maintenance operations, make sure the power line of the

unit is disconnected.

 Do not connect or disconnect the electric plug when your hands are wet.  Unplug the refrigerator or disconnect power before cleaning or servicing. Failure to do so can

result in electrical shock or death.

 Do not attempt to repair or replace any part of your refrigerator unless it is specifically

recommended in this manual. All other servicing should be referred to a qualified technician.

 Risk of child entrapment!

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still dangerous, even if they will "just sit in the garage a few days."

 Before you throw away your old refrigerator: Take off the doors. Leave the shelves in

place so that children may not easily climb inside.

 Never allow children to operate, play with, or crawl inside the refrigerator.

 Use two or more people to move and install refrigerator. Failure to do so can result in back or

other injury.

 To ensure proper ventilation for your refrigerator, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This unit must be installed in an area protected from the elements, such as wind, rain, water spray or drips.

 The refrigerator should not be located next to ovens, grills or other sources of high heat.  The refrigerator must be installed with all electrical, water and drain connections in accordance

with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in accordance with the National Electrical Code and local codes and ordinances is required.

 Do not kink or pinch the power supply cord of the refrigerator.  The fuse (or circuit breaker) size should be 15 amperes.  It is important for the refrigerator to be leveled in order to work properly. You may need to make

several adjustments to level it.

 Check for leaks after connection.  Never allow children to operate, play with or crawl inside the refrigerator.  This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

 IMPORTANT: Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

 IMPORTANT: Do not damage the refrigerant circuit.  IMPORTANT: Do not use electrical appliances inside the food storage compartment of the

appliance, unless they are of the type recommended by the manufacturer.

 Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

 Do not use this apparatus for other than its intended purpose.

SAVE THESE INSTRUCTIONS
