Summit CM421BLBI7FR Specification Sheet

CM421BLBI7FR

34" x 19.25" x 21.38" (H x W x D)

Commercially listed 20" wide built-in undercounter
refrigerator-freezer with a lock, custom door for slide-in
panels and black exterior

Highlights:

Flexible design allows built-in or freestanding use in 20"
wide spaces

ETL-S listed for commercial use
Slide your own panel into the door frame for an easy

custom look

Product Features:

Commercially listed ETL-S listed to NSF standards for commercial use
Slim 20" width Full 4.1 cu.ft. capacity inside conveniently slim footprint
Built-in capable Make the best use of space by installing your appliance under the counter
Fully finished black cabinet Allows the unit to be used freestanding
Stainless steel door frame Two-piece "U"-shaped door frame accepts slide-in custom panels (panel size: 19 1/4" W x 31

1/4" H at up to 1/4" thick)
Reversible door User reversible door swing
Factory installed lock Top-mounted for convenient security
Hospital grade cord with 'green dot' plug Secure three-pronged cord for added unit safety
Manual defrost Efficient performance with reliable temperature stability

SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified

770 Garrison Avenue Bronx, NY 10474 USA TEL [phone] FAX [phone] [e-mail] www.summitappliance.com

CM421BLBI7FR Specifications:

Overview

Height of Cabinet 33.5" (85 cm)
Height to Hinge Cap 34.0" (86 cm)
Width 19.25" (49 cm)
Depth 21.38" (54 cm)
Depth with door at 90° 39.5" (100 cm)
Capacity 4.1 cu.ft. (116 L)
Defrost Type Manual
Door Panel-Ready
Cabinet Black
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 64.0 lbs. (29 kg)
Shipping Weight 85.0 lbs. (39 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years

Refrigerator-Freezer

Door Swing RHD
Reversible Yes
Adjustable Shelves Yes
Crisper Qty 1
Crisper Finish Transparent
Crisper Cover Glass
Interior Light Yes
Refrigerator - Interior

Height
Refrigerator - Interior Width 15.75" (40 cm)
Refrigerator - Interior

Depth
Refrigerator - Shelf Type Glass
Refrigerator - Shelf Qty 2
Thermostat Type Dial
Refrigerant Type R134a
Refrigerant Amount 1.75 oz.
High Side PSI 205.0
Low Side PSI 103.0
Level Legs 2

28.75" (73 cm)

17.75" (45 cm)

Wheels 2
