Summit CL2R248 User Manual

Felix Storch, Inc.

Write Serial No. (on lower left corner of

FROST-FREE DRAWER REFRIGERATOR

and DRAWER FREEZER

Model Nos. CL2R248 / CL2F249

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.

inside cabinet) here:

________________________________

INSTRUCTION MANUAL

770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

2

TABLE OF CONTENTS

Appliance Safety

3

Important Safeguards

3 - 4

Location of Parts

5

Installation Instructions

6 - 8

Before Using Your Appliance

6

Installation of Your Applianc e

6

Electrical Connection

6 - 7

Extension Cord

7

Anti-Tip Bracket Installation

7

Installing the Stainless Steel Handles

8

Full Overlay Panel Installation Instruction

8

Operating Your Appliance

9 - 12

Control Panel for CL2R248

9 - 10

Control Panel for CL2F249

10

Sabbath Mode

11

Temperature Memory Function

11

Defrosting

11

Using the Freezer CL2F249

11

Temperature Alarm / Door Alarm

12

Care and Maintenance

13

Cleaning Your Appliance

13

Power Failure

13

Vacation Time

13

Moving Your Appliance

13

Energy-Saving Tips

13

Troubleshooting

14 - 15

Limited Warranty

16

3

APPLIANCE SAFETY

Your safety and the safety of others ar e very important.

We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.

This is the Safety Alert Symbol. The symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the word DANGER or WARNING.

DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.

WARNING means that failure to heed this safety
statement may result in extensive product
damage, serious personal inj ury, or death.

All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.

IMPORTANT SAFEGUARDS

Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precautions,
including the following:

• Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do
not use an extension cord.

• Replace all panels before oper ati ng.

• It is recommended that a separate circuit serving only your appliance be provided. Use receptacles

that cannot be turned off by a switch or pull chain.

• Never clean appliance parts with f lam mable fluids. Thes e f umes can create a f ir e ha zard or explosion.
And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.

• Do not connect or disconnect the electric plug when your hands are wet.

• Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in

electrical shock or death.

• Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other ser vicing should be referred to a qualified technician.

• This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the
greenhouse effect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.

In the event of any damage:

4

– Avoid open flames and anything that creates a spark,
– Disconnect from the power source,
– Air the room in which the appliance is located for several minutes and
– Contact the Service Department for advice.

• The more coolant there is in an appliance, the larger the room in which i t should be installed. In the

event of a leakage, if the appliance is in a small room, there is the danger of combustible gases
building up. For ev er y ounce of coolant, at le ast 325 cubic feet of room spac e is requ ired. The amount
of c oolant in the appliance is stated on the data plate inside the appli ance. It is hazardous for an yone
other than an Authorized Service Person to carry out servicing or repairs to this appliance.

• Take serious care when handling, moving, and using the appliance to avoid either damaging the

refrigerant tubing or increasing the risk of a leak.

• Replacing component par ts and servicing sha ll be done by factory authori zed s er vice per s on ne l, so as

to minimize the risk of possible ignition due to incorrect parts or improper service.

FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL

• Use two or more people to move and install appliance. Failure to do so can result in back or other
injury.

• To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 44°F (7°C) and below 95°F (35°C).

• The appliance should not be located next to ovens, grills or other sources of high heat.

• The appliance must be installed with all electrical, water and drain connections in accordance with

state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances, is required.

• Do not kink or pinch the power supply cord of the appliance.

• The size of the fuse (or circuit breaker) should be 15 amperes.

• It is important that the appliance be leveled in order to work properly. You may need to make several

adjustments to level it.

• All installations must be in accordance with local plumbing code requirements.

• Make certain that the pipes are not pinched, kinked or damaged during installation.

• Check for leaks after connection.

• Never allow children to operate, play with or crawl inside the appliance.

• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may damage

or discolor the interior.

• Use this appliance only for its intended purpose as described in this Instruction Manual.

• Keep fingers out of the “pinch point” areas. Clearances between the drawers and cabinet are

necessarily small. Be careful closing drawers when children are in the area.

Risk of child entrapment!

Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are
still dangerous, even if they will “just sit for a few days”.

Before discarding your old appliance:

• Take off the doors

• Leave the shelves in place so that children may not easily climb inside.

- SAVE THESE INSTRUCTIO NS -

5

LOCATION OF PARTS

Wire Rack

6

INSTALLATION INSTRUCTIONS

BEFORE USING YOUR APPLIANCE

• Remove the exterior and interior packing.

• Before connecting the appliance to the power sourc e, let it stand upright for approximatel y 2 hours.

This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.

• Clean the interior surface with lukewarm water using a soft cloth.

• Install the handles on the drawers, if they are not alrea d y attach ed. ( See pag e 8.)

INSTALLATION OF YOUR APPLIANCE

• The appliance is designed for built-in or recessed or free-standing installation and for indoor only.

• CAUTION: This appliance is not designed for the storage of medicine or other medical products.

• Place your appliance on a floor that is str ong enough to support it when it is f ully loaded. T o level the

unit, adjust the fr ont le ve ling legs.

• For free-standing installation, 5” (127mm) of space between the back and sides of the unit, and 4”

(102mm) at the top, ar e suggested. T his allows the pr oper air circulation to cool the compres sor and
condenser. Even for built-in installat ion, it is a must to k eep ¼” (6.35mm ) space on each side and at
the top and 2” (51mm) at the rear. T ake care that the air vent at the front of the appl iance is never
covered or blocked in any way.

• NOTE: It is recom m ended that you do no t ins tall th e applianc e n ear an o ven, ra diator or ot her heating

source. Direct sunlight may affect the outer coating and heat sources may increase electrical
consumption. Don’t install in a location where the temperature will fall below 44°F (7°C). For best
performance, do not install the appliance behind a cabinet door or block the base grille.

• Avoid locating the unit in moist areas.

• Plug the appliance into an exclusive, properly grounded wall out let.

ELECTRICAL CONNECTION

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by a qualified electrician or an authorized service center.

This appliance should be properly grounded for your safety. The power cord of this appliance is equipped
with a three-prong pl ug which mates w ith standard three-prong wall outlets to minimize the possib ility of
electrical shock.

Do not under any circumstances cut or remove the third (ground) prong from the power cord supplied. For
personal safety, this appliance must be properly grounded. Any questions concerning power and/or
grounding should be directed toward a certified electrician or an authorized service center.

This appliance requir es a standard 115/12 0 Volt AC ~ 60Hz three-prong grounded electrical outlet. Have
the wall outlet and circu it checked b y a qualified electric ian to make s ure the outlet is prop erly grounded.
When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.

To prevent accidental injur y, the cord should be sec ured behind the appliance and n ot left exposed or
dangling.

WARNING

7

The appliance shoul d a l ways be pl ug ged in to its o wn i ndi vidua l electrical outlet whic h has a voltage rati ng
that matches the rating label on the appliance. This provides the best performance and also prevents
overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the
appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the
receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that sho ws cracks or abrasion dam age along its length or at either end.
When moving the appliance, be careful not to damage the power cord.

EXTENSION CORD

Because of potential safety hazards under certain conditions, it is strongly recommended that you do not
use an extension cord with this appliance. However, if you must use an extension cord, it is absolutely
necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord having a grounding
type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.

ANTI-TIP BRACKET INSTALLATION

To reduce the risk of tipping the unit by abnormal usage or improper loading, the appliance must be
secured by properly installing the anti-t ip de vice pac k ed with th e applia nc e.

• Place the anti-tip bracket on the floor as shown in the figure. An anti-tip bracket can be installed on
either right or left side.

• Mark the locations of the 4 holes of the anti-tip bracket on the floor.

• Use a 5/16” masonry drill bit and insert plastic anchors.

• Secure bracket to floor using screws.

• Slide appliance into positio n and make sure the leg engages the anti-tip bracket.

NOTE: If the unit is relocated, the bracket must be removed and installed in the ne w locat ion.

8

INSTALLING THE STAINLESS STEEL HANDLES

This appliance includes two stainless steel handles
that are not required to operate the unit. To install the
handles, follow the instruct i ons belo w:

1. Remove the door gasket.

2. Install the handle with the screws provided. (DO
NOT over-tighten as this will cause damage to the
stainless steel door surface.)

3. Replace the door gasket.

FULL OVERLAY PANEL INSTALLATION INSTRUCTION

These models are designed for field-installed over lay
panels. The overlay panels cover the stainless steel to
give a built-in appearance . The overlay panel and
appropriate hardware are not included with the unit and
the end user needs to prepare them himself. Please
follow the instructions below for installation:

• Remove any items stored inside the drawers. Press
the left slide release lever down and at the s ame time
lift the correspondi ng right s lide lever up, and pull the
drawer out until it is free of tracks and the cabinet.
(Fig. 1)

• Peel off the gasket and remove the handle by
removing the two screws that attach the handle to the
door.

• Drill the 2 holes shown by using a 3/16” drill bit on the
bottom of drawer door front. (Fig. 2)

• Cut the overlay panels with thickness 3/4” to the
following dimensions:
If reusing the handles that came with the unit, drill
two holes with diameter 3/16” in the overlay panel.
Attach the handle and overlay panel together to the
drawer face using 2 M4x55 screws and through the
upper 2 existing holes inside the door groove. Then
attach the overlay panel to the drawer face using 2
wood screws #10x1.5 (ST4x40) Type AB Phillips and
through the lower 2 existing holes inside the door
groove. (Fig. 3)

• If user-supplied handles will be used, attach the
handles to the overlay panels by using the f lat head
screws and drive the screws flush with the panels.
Then attach the overlay panel to the drawer face us ing the 4 wood screws #10x1.5 (ST4x40) and
through the 4 existing holes inside the door groove.

• Peel back the gaskets, then align the left and right slide channels with the tracks in the cabinet.
Ensuring an even track engagement on both sides, gently push t he drawer into the cabinet until it
stops.

9

OPERATING YOUR APPLIANCE

It is recommended you install the appliance in a place where the ambient temperature is between 44º and
95ºF (7º - 35ºC). If the ambient temperature is above or below the recommended temperatures, the
performance of the unit may be affected. For example, placing your unit in extremely cold or hot
conditions may cause interior temperatures to fluctuate. The expected operating temperature range may
not be reached.

CONTROL PANEL for CL2R248

ON/OFF Power

To turn the appliance ON or OFF, touch the symbol and hold for 5 seconds.
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.

UP

Used to increase (warm) the set temperature by 1°C/1ºF.

DOWN

Used to decrease (cool) the set temperature by 1°C/1ºF.

ºF/ºC Selector

Select the temperature display in Fahrenheit or Celsius degrees. To change the temperature from
Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds.

Setting the Temperature Control

• You can set the temperature by touching the UP and DOWN symbols. When you push either of
the two buttons for the first time, the LED readout will show the original temperature set
previously. (The temperature preset at the factory is 38°F or 3°C.)

• The temperature you are setting will increase by one degree each time you touch the UP
symbol, and will decrease by one degree each time you touch the DOWN symbol.

• The range of the temperature control is from 36°F to 43°F.

• To view the set temperature at any time, touch the UP or DOWN symbol. The set temperature

will flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit
will reappear in the display window.

Interior Light

• The interior light makes it easy to view your items. Touching the LIGHT symbol toggles between
2 modes of operation for the internal lights: functional (default) mode and showcase mode. If

10

you are in functional (default) mode, the lights will turn on only when a drawer is open. If you are
in showcase mode, the lights will be on whether or not the drawer is open.

CONTROL PANEL for CL2F249

ON/OFF Power

To turn the appliance ON or OFF, press and hold the POWER key
NOTE: Pressing the POWER key once can switch off the audible alarm when the alarm is on.

SuperFreeze

SuperFreeze is used to freeze fresh food quickly. The function overrides the thermostat control and
will make the compressor operate continuously. It is not necessary to adjust the thermostat setting
when using this function. When the function is selected, the SuperFreeze indicator will be ON. The
function can be exited by pressing the key again and the indicator will turn OFF. SuperFreeze will
turn off automatically after 8 hours.

UP

Used to increase (warm) the set temperature by 1°C/1ºF.

DOWN

Used to decrease (cool) the set temperature by 1°C/1ºF.

ºF/ºC Selector

Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature
from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the SUPERFREEZE key
for 5 seconds.

Setting the Temperature Control

• You can set the temperature by pressing the UP and DOWN keys. When you press either of the
two keys for the first time, the LED readout will show the original temperature set previously.
(The temperature preset at the factory is 0°F or -18°C.)

• The temperature you are setting will increase by one degree each time you press the UP key,
and will decrease by one degree each time you press the DOWN key.

• The range of the temperature control is from -11°F to 11°F.

• To view the set temperature at any time, press the UP or DOWN key. The set temperature will

flash in the display window for 5 seconds. After 5 seconds, the temperature inside the unit will
reappear in the display window.

Interior Light

The unit is equipped with an interior LED light which will be turned ON when a drawer is open.

for 5 seconds.

11

NOTE:

• If the unit is unplugged or power is lost or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.

• When you use the unit for the first time or restart the unit after it has been shut off for a long time,
there could be a few degrees variance between the temperature you select and the one indicated
on the LED readout. This is normal and is due to the length of the activation time. There should
not be a problem once the unit has been running for a few hours.

SABBATH MODE

Sabbath mode is available for the observance of certain religious holidays. This mode turns off the
displays, interior light and audible alarms and prevents them from turning on again. Normal cooling
operations will still take place.

To initiate Sabbath mode, press the POWER and LIGHT keys at the same time for at least 5 seconds for
CL2R248 or press the POWER and SUPERFREEZE keys at the same time for at least 5 seconds for
CL2F249. The indicator light will flash four times and confirm the Sabbath mode is ON.
Sabbath mode can be exited by repeating the above process. The Sabbath Mod e will automaticall y turn
off after 96 hours.

TEMPERATURE MEMORY FUNCTION

• In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the

previous temperature settings, and when power is recovered, the cabinet temperature will return to
the same set temperature as before the power went off.

DEFROSTING

• Under normal operating conditions, the unit requires no manual defrosting.

• The evaporator behind th e rear wall of the unit defros ts automaticall y. The condensate collects in the

drainage channel behind the rear wall of the unit and flows through the drai na ge h ole into t he drip tray
by the compressor where it evaporates.

• However, frost may accumulate on the evaporator if the un it is r epeated ly open ed in high heat or high

humidity loca tions. If this frost pattern d oes not clear within 24 hours, your unit will require manual
defrosting.

USING THE FREEZER CL2F249

• This unit is designed for the long-term storage of frozen food. Storage time is up to three months.

• The storage life of frozen foods varies and the recommended storage time should not be exceeded.

• Pre-packed commercially frozen food should be stored in accordance with the frozen foods

manufacturer’s instructions for a three-star frozen food storage compartment or home freezer.

• Place frozen food int o the freezer as quic kly as possible af ter purchase. If th ere are instructions on
the packet, carefully follow these instructions regarding storage times.

12

TEMPERATURE AL ARM / DOOR ALARM

• An audible alarm sounds if the storage temperature is not cold enough. The temperatur e disp lay
flashes at the same time.

• The cause of the temperature being too high may be:

– Warm fresh food was placed inside
– Too much warm ambient air flowed in when rearranging and removing food
– Power failure for some time
– The appliance is faulty

• The audible alarm is automatically silenced and the temperature display stops flashing when the
temperature is sufficiently cold again.

• If a drawer has been left open for more than 60 seconds, the alarm will sound. Pressing the POWER
key once can switch off the audible alarm.

13

CARE AND MAINTENANCE

CLEANING YOUR APPLIANCE

• Turn off the power, unplug the appliance, and remove all items, including racks and dividers.

• Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of

baking soda to a quart of water).

• Wash the racks and dividers with a mild detergent solution.

• Wring excess water out of t he s pon ge or c lot h when c l ean ing the area where t he contr ols ar e l ocate d,

or any electrical parts.

• Wash the outside cabin et with warm water and m ild liquid deterge nt. Rinse we ll and wipe dr y with a
clean soft cloth.

• Use an approved sta inless steel clean er to clean th e doors and handles. D o not use steel wool or a
steel brush on the stainless steel.

CAUTION:
Failure to unplu g the appliance before cleaning could result in electric al shock or other personal injury

POWER FAILURE

Most power failures are corrected within a few hours and should not affect the temperature of your
appliance if you minim ize the num ber of t imes the drawers are opened. If the power is goin g to be off f or
a longer period of time, you need to take the proper steps to protect the contents.

VACATION TIME

• Short vacations: Leave the appliance operating during vacations of less than three weeks.

• Long vacations: If the appliance will not be used for several m onths, remove all items and tur n off

the appliance. Clean and dry the interior thorough ly. To prevent odor and m old growth, leave the
drawers open slightly, blocking them open if necessary.

MOVING YOUR APPLIANCE

1. Remove all items.

2. Securely tape down all loose items (racks, dividers) inside your appliance.

3. Turn the adjustable legs up to the base to avoid damage.

4. Tape the drawers shut.

5. Be sure the appliance stays secure in the upright position during transportation. Also, protect the
outside of the appliance with a blanket or similar item.

ENERGY-SAVING TIPS

• The appliance should be located in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight.

• Ensure that the unit is adequately ventilated. Never cover air vents.

• Do not keep the drawers open any longer than necessary.

• Let hot foods c ool to room temperature befor e placing in the unit. Ov erloading the unit forces th e

compressor to run longer.

• Be sure to wrap foo ds properly, and wipe contai ners dry before placing t hem in the unit. This c uts
down on frost build-up inside the unit.

• Unit bins and racks should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the unit less efficient.

• Organize and label food to reduce drawer openings and extend ed searc hes. R emove as many items
as needed at one time, and close the drawer as soon as possible.

.

14

TROUBLESHOOTING

PROBLEM

POSSIBLE CAUSE

REMEDY

fuse.

dusty.

the dust.

replace it.

panel.

adjustable feet.

The rattling noise may come from the flow of the refrigerant, which is normal. As each

cause popping and crackling noises.

adjustable feet.

You can solve many common problems easily, saving you the cost of a possible service call. Try the
suggestions below to see if you can solve the problem before calling the servicer.

Troubleshooting Guide

Appliance
does not
operate.

Appliance is
not cold
enough.

Appliance
turns itself on
and off
frequently.

• Appliance is not connected to a power
supply.

• The appliance is turned off.

• Tripped circuit breaker or blown fuse

• The temperature is not set correctly.

• The ambient temperature could require

a lower temperature setting.

• Drawers were opened too often.

• A drawer was not closed completely.

• Drawer is not hermetically sealed.

• The condenser is too dirty.

• The ventilation opening is b locked or too

• The room temperature is higher than

average.

• A large amount of food has been added
to the unit.

• Drawers are opened t oo of ten.

• A drawer is not closed completely.

• A drawer gasket does not seal properly.

• Connect the appliance.

• Switch on the appliance.

• Switch on circuit breaker or replace

• Check the set temperature.

• Set a lower temperature.

• Do not open drawers more often than

necessary.

• Close drawer properly.

• Check the seal and clean or replace.

• Clean the condenser when necessary.

• Clear the obstructions and clean off

• Put the appliance in a cooler place.

• Leave the appliance to work for a

while until the set temperature has
been reached.

• Do not open the drawers more often
than necessary.

• Close drawer properly.

• Check the drawer seal and clean or

• Appliance is not connected to a power

supply.
The light does
not work.

Vibrations

The appliance
seems to
make too
much noise.

Drawers
will not close
properly.

• Tripped circuit breaker or a blown fuse.

• The light was switched off on the control

• The appliance is not properly leveled.

cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your
appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls may

• The appliance is not properly level. • Level the app lianc e wit h the

• The appliance is not properly leveled.

• The gaskets are dirty.

• The racks or bins are out of position.

• Connect the appliance.

• Switch on circuit breaker or replace

fuse.

• Switch on the light.

• Level the appliance with the

• Level the appliance with the

adjustable feet.

• Clean the drawer gaskets.

• Check the racks and bins and refit

correctly.

15

Display “E0”,

“E7” indicates door switch failure.

Has a drawer been open for longer than 60

to the unit.

If yes, close the drawer.

• The display temperature is out of range.

• Only temperatures within the range

This is normal.

“E1”. “E2”,
“E3”, “E4”,
“E5” or “E7”.

• “E0”indicates the communication error
for 3 zone models.

• “E1” or “E2” indicates that the air
temperature sensor has failed.

• “E3” or “E4”indicates that the defrost
sensor in the evaporator has failed.

• “E5” indicates defrost heater failure.

•

• Call for service.

seconds? If not, then the temperature has
risen higher or fallen lower than the

The alarm
sounds and
the
temperature
display
flashes.

The icon “--” is
lit and flashing
in the
temperature
display.

If you've checked the table above and find that you still need help with your appliance, call our Customer
Service facility at
questions.

temperature that has been set. This could
be due to:

• The appliance drawers being opened
too often.

• The ventilation opening being covered
or too dusty.

• A lengthy interruption in the power
supply.

• A large amount of food has been added

800-932-4267 between 9:00AM and 5:00PM ET. We will do our best to answer your

• Do not open drawers more often than
necessary.

• Clear the obstructions and clean off
the dust.

• Leave the appliance to work for a
while until the set temperature has
been reached.

0~99°F/-9~37°C for CL2R248 and the
range -49~99°F/-45~37°C for
CL2F249 can be displayed. If the
temperature is not within this range,
the icon “--” will be displayed instead.

16

FELIX STORCH, INC.

For parts and accessory ordering,

FELIX STORCH, INC.

Within the 48 contig uous United States, for on e year from the date of purchas e, when this appliance is
operated and maintained a c c ording to ins truc ti ons atta c hed to or f ur nishe d with the product, warrantor w ill
pay for factory-specif ied parts and repair labor to correct def ects in materials or workmanship. Ser vice
must be provided by a des ignated service company. Outside the 48 s tates, all parts are warranted for
one year from manufacturing defects. Plastic parts, shelves and cabinets are warranted to be
manufactured to comm ercially acceptable standards , and are not covered from damage dur ing handling
or breakage.

1. The compressor is covered for 5 years.

2. Replacement does not include labor.

ITEMS WARRANTOR WILL NOT PAY FOR:

1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to
replace or repair fuses or to correct wiring or plumbing.

2. Service calls to repair or replace appliance light bulbs or broken shelves. Consumable parts (such as
filters) are excluded from warranty coverage.

3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper
installation, installation not in accordance with electrical or plumbing codes, or use of products not
approved by warrantor.

4. Replacement parts or repair labor costs for units operated outside the United States.

5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.

6. Expenses for travel and transportation for product service in remote locations.

7. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not
installed in accordance with published installation instructions.

CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
PRODUCT REPAIR AS PROVIDED HEREIN. IMPLIED W ARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR.
WARRANTOR SHALL NOT BE LIABLE FOR INCI DENTAL OR CONS EQUENTIAL DAMAG ES. SOME
STATES DO N OT ALL OW THE EX CLUSIO N OR LIMIT ATION OF INCI DENT AL O R CONS EQUEN TIAL
DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF
MERCHANTABI LIT Y OR F ITNESS, SO T HESE EXCL USION S OR LI MITAT ION S MAY NO T A PPLY T O
YOU. THIS WAR RANTY GIVE S YOU SPEC IFIC LEG AL RIGHTS AN D YOU MA Y ALSO HAVE O THER
RIGHTS, WHICH VARY FROM STATE TO STATE.

www.summitappliance.com

LIMITED WARRANTY

ONE-YEAR LIMITED WARRANTY

5-YEAR COMPRESSOR WARRANTY

DISCLAIMER OF IMPLIED WARRANTIES;

LIMITATION OF REMEDIES

770 Garrison Avenue

770 Garrison Avenue

Bronx, NY 10474

Bronx, NY 10474

Phone: [phone]

Phone: [phone]

Fax: [phone]

Fax: [phone]

www.summitappliance.com

troubleshooting and helpful hints, visit:

www.summitappliance.com/support

Printed in China
