Summit B41602 User Manual

INSTRUCTION MANUAL

for 2-Burner Cook Top

Model B41602

Felix Storch, Inc.

Summit Appliance Division

770 Garrison Avenue

Bronx, NY 10474

www.summitappliance .com

Page 1

Page 2

Please read these instructions in their entirety before installation and use of your
cook top. SAVE THIS MANUAL FOR FUTURE REFERENCE.

Table of Contents

Technical Information ...........................................................................................2

Installation Instructions ......................................................................................2-8

Safety Instructions ...........................................................................................9-10

Operation.......................................................................................................11-12

Cookware.................................................................................................11

Heating Elements.....................................................................................11

Knobs & Indicator Lights ..........................................................................12

Cleaning...................................................................................................12

Warranty.............................................................................................................13

Technical Information

Model Number: B41602
Description: 2-burner ceramic glass cook top
Electrical Requirements: 240V AC, 60Hz
Power Rating: 1200 watts (each burner)
Diameter of each burner: 6"
Overall Dimensions: 21" x 12" x 2⅝"
Cutout Dimensions: 20" x 10¾" with ¼" radius

!

Page 3

Installation Instructions

Important! Save this documentation for review by
local inspector.

!

STEP #1

Unpacking the Cook Top

Carefully unpack the cook top from its shipping container. If possible, keep the
original shipping carton and protective packaging in the event the unit has to be
returned for service.

Verify and identify the package contents. The following should be included in the
carton. If any components are missing or damaged, call SUMMIT immediately.

(1) Package of mounting screws  Ceramic cook top cleaner

________________________________________

Important! This appliance must be properly installed
and grounded by a qualified technician.

Ceramic glass cook top

Important! Do not remove the clear plastic covering
film on the ceramic glass until cook top is ready to
install.

For future reference, please record the Serial Number

of your cook top here:



Mounting brackets

Page 4

STEP #2

Check the Electrical Supply Requirements

This product must be installed in accordance with national, state and local
electric codes. Here are the electrical requirements for Model B41602:

Maximum Connected Load: 2400 watts
Required Power Supply Input: 240VAC/10A/60Hz
Minimum Wire size: #12AWG

The supply must be from an individual grounded circuit that is protected by a
circuit breaker and rated per the specifications as shown above.

Warning: If the electric power supply does not meet

!

the product specifications, consult with a licensed
electrician before proceeding with installation.
