OU
TD
OO
O
U
R
VEN MAN
AL
The Oven Manual
Questions, problems, missing parts? Before returning to your retailer, call our
customer service dep artment at 1(800) 966-8126, Monday - Friday, 8:30 a.m. - 5
p.m., PST.
FOR QUESTIONS OR SERVICE, PLEASE CALL 800.966.8126
Oven Operation 1-2-3
Before Cooking:
Ste p 1 Keep your oven a safe dista nc e away from yo ur pr operty.*
Step 2 Always perform a leak test.*
Ste p 3 Keep children away from the oven.
During Cooking:
(To a vo id tripping saf ety valves , please follow these inst ruc tions carefully!)
Step 1 Turn gas tank on slowly.
Step 2 Use protective gloves when oven gets hot.
After Cooking:
2
The Oven Manual
Step 1 Burn oven for 10-15 minutes to burn off food residue.
Ste p 2 Wait until the oven is completely cooled befor e c losing oven door.
Ste p 3 Clea n up gre ase build-up and co v er your ove n.
* Please refer to the owner's manual f or details.
WARNING
1. Do not store or use gasoline or
other flammable liquids or vapors in
the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use should not be stored in the
vicinity of this or any other a
Always read and understand t he WARNINGS and INSTRUCTIONS that are contained in this
manual before a t tempting to use this outdoo r ove n to pre v ent possible bodily injury or property
damage.
ppliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open oven door.
4. If odor continues, keep away from
the appliance and immediately call
your gas supplier or your fire
department.
3
TABLE OF CONTENTS
Safety Information… …… ……………… ……………. …… …...….………….…… ……. ………………. 4
Package Contents…..………………..…..….……...…...................……………………………………. 6
Hardwar e Cont ent s …… …… …… …… ……………… …… ……………… …….……… ……… …… …. . 7
As sembly Instructions……………… ……. .… …… …… …. ……………… …… ……………… …… …. 8
LP Gas Assemb ly……………………………………………………. .............. .... .................. ... ......... . 1 5
Natural Gas Conversion ………………………………………………………………………………... 21
Operating Instructions..………………………….……...……
………………………..........................29
Care and Mai nten an c e……… …… ……………… ….… …… ……………… …… ……………… …… .. 31
Trou bl eshoot in g …… …… ……………… …… ……………… …… ……………. .…. …… ……… .. ....... 40
Warranty…………………………………………………………………………………………………… 42
Explored Diagram……………….……………………………………………………………….………. 43
Rep lacement Parts List …… .… …… …… …… …… ………… …… …… ………… …………………….45
Island Inst all ation …… ……………… ……………… …… ……………… ……………… ……… …… …. 4 8
4
Safety Information
Please read and understand thi s entire manual before a ttempting to a ssemble, o perate or
insta ll the produc t. I f you have any que stions regard ing the product, please call cu stomer
service at
1. The installat ion of thi s applian ce must conform with loc al codes or, in the abs ence of local codes,
with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Nat
Installation Code, CSA/CGA-B149.1.
2. Th i s oven is in tended for use ou tdoors and should not be us ed i n a building, garage or any ot her
encl osed or covered area.
3. This outdoor oven i s not intended for installation in or on recr eation vehicles and/or boat s.
4. A minimum cl ear ance of 61 cm (24 inches) from combustib le constructions to the sides of the grill
and 61 cm (24 inches) from the back of th e grill
This outdoor c ooking gas appliance mu st not be placed under overhead c om bustible const ru ction.
5. The use of an electrical source requires that when installed, the grill must be electrically grounded
in accordance with local codes or, in the absence of local codes, with ANSI/NFPA 70, or the
Canad ian Elec t ric al Code, CSA C22.1. Keep elect ri cal supp ly cord s and the fuel supp ly hos e
from heated surfaces.
1(800) 966-8126 Monday to Friday fr om 8:30 a.m. to 5 p.m. PST.
ural Gas and Propane
to combustible constructions must be maintained.
away
6. Inspec t the hoses before eac h use for exces sive abras ion or wear, or c uts that may affect safe
operation of the grill. If there is evidence of excessive abrasion or wear , or the hose is cut, it must be
replac ed pr ior t o th e gri ll b eing put in to op erat ion. The rep l acem ent hose ass emb ly mu st be th ose
specified by the manufacturer.
7. Keep your oven in an area clear and free from combustible materi
flammable vapors and liquids.
8. DO NOT obstruct the fl ow of combustion and venti l ation air to this appl iance.
9. Keep the ventilation openings of the tank enclos ure free and clear from debris.
10. Check all gas conn ect ions for leaks with a soap y water solu t ion and b rush . Never us e an op en
flame to check for leaks.
11. Never use charcoal in the oven.
12. Never use the grill in windy areas.
13. Only a 9 kg (20 lb.) LP-gas
cylinder must be constructed and marked in accordance
with the Specifications for LP Gas Cylinders of the U.S.
Department of Transportation (D.O.T.) or the National
Standard of Canada, CAN/CSA-B339, Cylinders,
Spheres and Tubes for Transportation of Dangerous
Goods. A 9 kg (20 lb.) LP-Gas cylinder’s dimensions
are:
cylinder is allowed. The
als, gasoline and other
14. Never use the grill without the drip tray inst alled and
hung under the burner box. Withou
greas e and debris could leak downward and pr oduce a fire hazard.
15. Use only the gas pressure regulator supplied with this appliance.
t the drip tray, hot
5
Safety Information
This regul ator is set for an outlet pressur e of 11.0 WC.
16. The cylinder use d mus t include a collar to pro tect the cy linder valve
17. Do not store a spare LP-gas cylinde r under or near the appliance
18. Nev er fill the c y linder beyond 80 percent full
19. If the inform ation in “17” and “18” is not follo wed exactl y, a fire c ausing death or serious injury
may occur.
20. The outdoor cook i ng gas appliance must be isolated from the gas supply piping system by
closi ng its individ ual manual s hutoff valve during any pressure t esting of th e gas suppl y s ys tem at
test pressures equal to or less th an 1/2 psi (3.5 kPa).
21. CALIFORNIA PROPOSITION 65 WARNING: The burning of gas cooking
bypr oduct s that are on the list of substances known by the State of C al ifornia to cau se c ancer,
reproductive harm, or other bi r th defects. To reduce exposure to these substances, always operate
th i s unit according to the use and car e m anual, ensuring you provide good vent ilation when cook ing
with gas.
——————————————————————————————————————————
—
IMPORTANT: We urge you to read this manual carefully and follow the recommendations
enclos ed. This will ens ure you re ce ive the mos t enjoyable and trouble-free operation of your
new gas grill. We also a dvise you retain this manual for future reference.
——————————————————————————————————————————
—
WARNING: Your outdoor oven has been designed to operate using only the gas
specified by the manufacturer on the rating plate. Do not attempt to operate your grill on
other gases. Failure to follow this warning could lead to a fire hazard and bodily harm and
will void your warranty.
——————————————————————————————————————————
—
fuel generates some
WARNING: M ake certain you r LP ( p rop ane) tank is f illed by a reputab le propane
dealer. An incorrectly fill ed or an overfilled LP tank can be dangerous. Th e overfilled
condition combined with the warming of the LP tank (a hot summer day, tank left in
the sun, etc.) can cause LP gas to be released by the pressure relief val ve on the
tank sin ce the temperat ure increase causes the propane to expand. LP gas released
from the tank is flammable and can be explosive. Refer to your Owner’s Manual for
more informati on concerning f il ling you
r LP tank.
6
P ACKAGE CONTENTS
PART
DESCRIPTION
QUANTITY
PART DESCRIPTION QUANTITY
A Main Body 1 E Grease Tray 1
B Cooking Grill 2 F Smoker Box 1
C Pizza Stone 1 G Flame Tamer 1
D Bottom Grill 1
7
HARDWARE CO NTENTS
The following list is inc luded inside the oven ca rton:
Battery 1 pc
The following list is not include d ins ide the piz za oven ca rton, but needed when the use r is
assembling the piz z a oven.
Phillips Head Screwdriver
1 pc
The fo llow ing list is NOT included inside the piz za ove n carton but is include d inside t he NG
Conversion Kit . I t is needed whe n the gas type is changed fro m LP to NG.
11X11 mm
Wrench 1 pc
Orif ice Removal
Tool 1 pc
Phillips Head Screwdriver 1
pc
Conversion
Screw 1 pc
ij 1.80 Orifice 1 pc 17X19 mm
Wrench 1 pc
Natural Gas Hose 1pc
8
ASSEMBLY I NSTRUCTIONS
Befo r e beginning assembly of pro duc t, make s ure all part s ar e present. Compare parts wit h
package conte nts list and ha r dware contents list. If any part is missing or damaged, do not
attempt to assemble the product.
A sse m bl y tip! (Pl ease lightly tighten the screws during assembly of the cart. When
the cart is completed THEN TIGHTEN ALL THE screws. This will make it easier to
make all the holes al ign properly)
1. Use s c re w M6*40× 2 pcs, nut
M6× 2 pcs and flat washer
18*6.4*1× 2 pcs to fix the weight
under t he base panel. (Note:
These screws MUST be
tightened at this time as it will
be hard to reach them aft er cart
assembly)
2. Use s c re w M6*12×16 pcs to
attach swivel castor with lock×2
pcs and fixed castor×2 pcs onto
the bottom of the base panel.
(Note: The locking wheels
should go in the BACK of the
cart near the weight)
9
3. Use s c re w M6*12×2 pcs to fix
the left side panel onto the base
panel of the sta nd. (Note: The
panel sh ould have the “small
holes at the top” to the front of
the cart assembl y)
4. Use screw M3*12×2 pcs and
nut M3×2 pcs to attach the door
magnet onto the r ight side pane l.
(Note: Please attach t he magn et
BEFORE you put the right side
panel o n. Check to verify that
the magnet points to the FRONT
of the cart . This hold s t he door
closed)
5. Use screw M6*12×2 pcs to fix
the r ight side pa nel onto the base
pane l of the stand. (Note: The
panel sh ould have the “small
holes at the top” to the front of
the cart assembly. The Right
side panel also has the door
magnet)
10
6. Use screw M4*10×4 pcs and
nut M4×4 pcs to attach the
transformer assembly onto the
outs ide of the bac k panel of the
stand. (Note: Th ese screws can
be tightened at this time)
7. Use screw M6*12×5 pcs to
attach the stand base panel ont o
the base panel, between the two
side panels.
11
8. Use screw M4*10×4 pcs to fix
the stand door horizontal beam
between the two side panels.
(Note: Please fasten t he upper
two screws fi rst , and th en t he
lower two screws.)
9. Use screw M4*10×4 pcs
to fix the stand top panel on
the t op of the tw o si de
pane ls and back panel.
(Note: T hese screws can
be tightened at this time)
10. Use screw M5*10×8
pcs to atta ch triangle ×2 pcs
on the bottom of t he base
pane l, leaning a gainst the
two s ide panels. (Note:
These screws can be
tightened at this time)
12
11. First, inse rt the door lower axis
into the hole in the base panel.
Next , push down the door upper
spring axis and let go of the spring
whe n it is pointe d to the hole in the
horizontal beam. (Note: You may
need to add 1 or 2 washers
18*6.4*1 on the b ottom pin so
the door will close evenly)
ALMOST F INISHED!!
12 . Pu t th e oven as s em bly on the
sta nd- top pane l. Use screw
M6*12×4 pcs to fasten the oven
onto the stand. (Note: These
screws can be tightened at this
time)
13
13. Use screw M5*10×16 pcs to
attach side shelf br acket×4 pcs
onto the drawer side panels.
(Note: Arrows face UP)
14. Using o ne of the scre w M 5*10
to fix the match ho lder onto the
front bracket of right side shelf.
(This step may be skippe d if
you do not want or need a
“match holder” on your unit)
15. Use screw M6*12×8 pcs and
special nut TB31-05-03× 8 pcs to
hang side shelf×2 pcs onto the
four br ackets. (Notes (2): Attach
the top set of screws and bolts
and hang the shelf from them to
assist in at t aching the bottom
screws and nuts to t he shelf.
These screws can be tightened
at this time)
14
16. Use screw M4*8×3 pcs to fix
the chimney assembly onto the
top of the ov en exteri or. (Note:
These screws can be t ightened
at this time)
17. Use screw M5*35×4 pcs to fix
the back heat shield onto the back
pane l of the oven. The or der is:
screw back heat shield heat
insulat ion was her flat washer
oven back panel.
18. Put the following acce s so r ies
into the oven and close the oven
door:
- base gr ill×1 pc
- pizza stone×1 pc
- cook ing gr ill ×2 pcs
- smoke r box×1 pc (ha ng on the
cooking grill, exact po s it ion is
according to the foo d positio n
inside t he oven)
- flame tamer×1 pc
15
19. Insert the gre ase tray into the
back of the oven.
20. Insert the battery into the
ele c tronic ignition. Unscrew the
button and place battery posit iv e
(+) tip facing O UT. Screw button
back on.
Your complete oven is now
assembled.
L.P. GAS INST ALL AT ION
Gas grills that are set to operate with L.P. gas come with a high c apacity h ose and regulator
assembly. (Note: Only use the pressure regulator and hose assembly supplied with the grill
or a replacement pressure regulator and hose assembly specified by the manufacturer). This
assembly is designed to conn ect directly to a standard 9 kg (20 lb.) L.P. cylinder. L.P. cylinders are
not included with the grill. L.P. cylinders can be purch
ased separately at an indep endent dealer .
Connecting a Liquid Propane Gas Tank to the
Grill:
1. Open the doors of the ca binet. Plac e a 9 kg (20
Ib.) tank with foot ring into the tank tray. See Fig. 4.
Make sure the tank valve is in the OFF position.
2. Tighte n the retention screw be s ide the tank tray
to se c u r e the tank. See F ig. 5.
3. Chec k the tank va lve to ensure it has proper
exte r nal mating thr eads to fit the ho se and
regulator as se m bly provided (Type 1 co
nnection
per ANSI Z21.89b-2012).
4. Inspect the va lv e co nnectio n por t of the
regulator as se m bly . Look for damage or
debris. Remo ve any debris. I ns pect ho se for
damage. Never use dam aged or plugged
equipment.
16
5. Make sure all burner knobs are in the OFF position.
6. Connect the hose a nd r egulator ass embly to the tank valve (See Fig. 6). Hand-t ighten
the quic k c oupling nut clockwise to a full stop.
Fig. 6
DO NOT use a wre nch to tighte n because it could damage t he quick coupling nut and res ult
in a ha za r dous condition.
7. Open the tank valv e f ully (c ounte r cloc k wise). Use a so apy water solution to che ck a ll
conne ct ions for leaks bef ore attempting t o light your grill. See “Pre-Operatio n Lea k Te st ing"
on pa ge 19. If a leak is found, turn t he Tank Valve off and do no t use your over unt il the leak
is repaired.
As s hown in Fig. 7a , gas tank must be pla ce v ertically. It
gas tank is not vertica l as s hown in Fig. 7b.
is unsafe to operat e the oven if the
Fig. 7a
Fig. 7b
17
WARNING: T he Typ e I connecti ve coupl ing (see Fi g. 7) supplied with your oven
must no t be replaced with a different t ype of grill/t ank connection system. Removal
will result i n loss of warranty, gas leakage, fire an d severe bodily harm.
Type I
Valve
Hand Wheel
External
Thread
Thermally
Sensitive Nut
PIG 7
Propane
Regulator
Disconnecting a Liquid Propane Gas (LP Gas) Tank from Your Oven:
1. Turn the burner knobs and LP gas tank va lv e to the full OFF position. (Turn clockwis e to
close.)
2. Detach the hose and r egulato r assembly from the LP gas tank valve by turning the quick
coupling nut counterclockw ise .
CAUTION: When the appliance is not in use, the gas must be turned off at the supply
.
tank
18
L.P. TANK INFOR M AT ION
Never use a dented or rusted L.P . ta nk or cylinder with a damaged valve.
L.P. c ylinders are equipped with an O.P .D. (Overfilling Pre v ention Device). The device
shuts off the f low of gas to a c y linder after 80% ca pacity is reac hed. This limits the pote nt ial
for re lease of gas whe n the cylinder is heated, aver ting a fire or pos s ible injury.
The L.P. cylinder m ust have a shut-off valve ter minating in an L.P. gas s upply c y linder
outlet specified, as applicable, for co nnecti
on No. 510 in the standard for compressed gas
cylinder valve outlet a nd inlet conne ction ANSI/ CGA-V - 1. Cylinders must not be sto r ed in a
buildin g, garage, or any other enclosed area. (The L.P. cylinder must have an overfill
prot ection de v ice and a collar to protect the cylinder valve.)
The L.P. gas supply c y linder must be constructed and marked in acco r danc e with the
specifications for L.P. gas c y linders of the U.S. Department of Transpo rtat ion (DOT) or the
National Standard of Canada, CAN/ CA S-B339, “ Cy linders, Spheres and Tubes for the
Transportation of Dangerous Goods and Commission.”
L.P. TANK USE
• When turning the L.P. tank on, make sure to open the valve SLOWLY two (2)
complete turns to ensure proper gas flow. Most gas tanks now come equipped with a
leak detector mechanism internal to the tank. When gas is allowed to escape rapidly,
it shuts off the gas supply. Opening the valve rapidly may simulate a gas leak,
causing the safety device to activate, restricting gas flow and causing low flames.
Opening the valve slowly will ensure this safety feature is not falsely triggered.
• When not in us e, gas supply c y linder v
• The tank supply syst em must be stored upright to allow for vapor withdrawal.
alve is to be in the “OFF” position.
• The regulator and hose as s embly must be ins pected befor e each use of t he oven. If there
is excessive abrasion or wear or if the hose is cut, it must be replaced prior to the grill being
used again.
• Cylinde r s m us t be stored outdoors out of the reac h of children and must not be st ored in a
building, garage or any other enclosed area.
• Only a qua
ref ill t he L.P. tank.
lified gas supplier should
WARNING
DO NOT store a sp are L.P. gas cy lind er under or
• Place dust cap on cylinder valve
outlet wheneve r the cylinder is not in
use. Only insta ll the t ype of dust cap on
the c ylinder valve outlet t hat is
provided with t he c y linder valve . O t her
near the o ven. Never fill the cylinder beyond
80% full.
If this informatio n i s not f ollowed exactly, a f i re
causing death or serious injury may occur.
type s of ca ps or plugs m ay result in
leakage of pr opane.
19
PRE-OP ER ATION LE AK TE STIN G
Alt hough all gas connections on the oven are leak tested prior to shipment , a complete gas
tightness chec k m us t be per formed at the ins tallation site due to possible shift ing dur ing
shipment, installation or excessive pr essure unknowingly being applied to the unit .
Periodically check the whole system for leaks and immediately check the system if the
smell of gas is detec ted.
1. Do not smoke while leak test ing.
2. Ext inguis h all open flames .
3. Nev er leak test with an open fla m
e.
4. Mix a solution of equal parts m ild detergent or liquid soa p and wate r.
5. Turn off the burner control knobs.
6. Turn the top knob of the fuel supply cy linder counterc lockwise two (2) rotations to open.
7. A pply the soap solut ion to connections of t he fuel supply ass embly. If no soap bubbles
appe ar, there is no gas leak. If bubbles form at the co nnections, a leak is de tected. I f a leak
is det ected, immediately turn off the ga s supply, tighten any leaking fittings, turn gas on,
a
nd repeat steps 1-3.
8. Turn off the knob on the fuel supply c ylinder.
9. Turn on the burne r co ntrol knobs for a moment to re lease the pressure in the hose, then
turn the control knobs back off.
10. Wash off soapy so lution with cold water a nd towel dry.
Check all gas supply fittings before ea c h use a nd each time t he gas supply cylinder is
connected to t he re gulator. Hav e a qualifie d s ervice technicia n leak test the oven any time
a part of the gas system is repla
ced.
It is als o recommended that you perform a leak test at least onc e a y ear whether or not the
L.P. gas supply cylinder has been disconnected.
WARNING When leak testing this appliance, make sure to test and t ighten all lo ose
conne ct ions. A slight leak in the system can result in a low flame or hazardous condition.
Most L.P. gas tanks now come equippe d with a leak dete c tor mechanis m internal to the
tank . When gas is allowed to escape rapidly, it s huts off the gas s upply . A leak may
significantly re duc e the gas flow , ma k ing the oven diffic ult to light o r ca us ing low flame s .
If you cannot stop a gas leak, tur n off the gas supply a nd c all your lo ca l gas compa ny . If
necessary, replace the faulty part with the manufacturer’s recommended replacement part.
A slight leak could cause a fire.
20
WARNING Do not use the oven in garage s, bree zewa ys, sheds or any enclos ed ar ea.
Never operate the oven in e nc losed areas as this could lead to a ca r bon m onoxide buildup,
which could result in injury or death. Place t he oven on a level surface. Avoid moving the
oven while it is in operation.
NOTE: The oven will operate best i f it is not facing directly into the wind
PREPARATION FOR NG CONVERSION:
Befo r e beginning convers ion, make sure all parts are present. Compare par ts with pac k age
cont ents. If any part is missing or damaged, do not attem pt to co nv ert. Contact c us tomer
service for replacement parts.
1. Turn off gas supply, and then remove ca p on gas supply side.
2. Rec ommended: Install a s hut-of f valve on gas s upply s ide befo re ins talling the socket.
3.
Socke t should be inst alled by an authorized technicia n in accordance with the national
fuel gas code (NFPA 54/ANSI223.1) .
4. Be fore inserting plug, turn on gas supply and leak test all co nnections including the s tem
of the shut-off valve and the opening of the soc k et. For best results, use a n ammonia-free
soap and water so lution.
NATURAL GAS INSTR U CTION :
Socket
Sleeve
Plug
1. To connect, pus h back socket
sleeve (Fig. 1).
2. Insert plug and release sleeve (Fig.
Fig. 1
2).
Sleeve
3. Push plug until sleeve sna p
s
Socket
forw ard (Fig. 3). (Gas will flow
automatically. Failure to connect plug
properly to sock et will inhibit gas flow
to the appliance.)
Fig. 2
4. Test co nnection with ammonia-f re e
soap and water solution.
To disconnect
1. Pull sleeve ba c k . Pull plug out o f
socket. (Gas is automatically shut off.)
2. Clos e shut-off valve and replace
dust caps on socke t and plug.
21
Socket
Sleeve
Fig. 3
WARNING:
Place the oven on a flat, level surface.
Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is
closed, and tank is dis c onnecte d from regulator and remov ed from grill.
NG CONVERSION INSTRUCTION:
Before the conversion, make sure all control knobs are in the OFF position, LP tank valve is
closed, and tank is dis c onnecte d from regulator and r emove d from oven.
Before the conversion, make sure
all control kno bs are in the OFF
posit ion, LP tank va lv e is c losed,
and tank is disco nnec ted from
regulator and rem oved from ove n.
Next , op en th e door and remove
the two cooking grids, s moker
box, pizza stone, base oven and
flame tamer.
Loosen the screws that are used
to fasten the burner (see picture at
right). Us e a 10x12 mm Wrench t o
remove the thermocouple (right
side of the burner) out from the
burner. Next, pull o ut the ignitio n
wire from the elect ro nic igniter.
Finall y, tak e out th e whole bur ner.
22
Use a screwdriver to loosen the
screw that is used to fasten the
burner cover. Turn the burner
cover until the hole marked “NG”
overlaps with the fixing hole on the
burner. Put the screw back into
the holes and tighten again.
Use orifice removal tool to remove
theij 1.2 LP o r if ice from the
oven. And then use the same tool
to fix theij 1.8 NG or ifice back to
the position.
23
Put the burner back into the oven
and insert the ignit ion wire int o the
original position. Use the 10x12
mm spanner to fix the
ther m ocouple back into the ove n
aga in. Finally, fasten the burner
with the original screws.
Put ba c k the two cook ing gr ids,
smok er box, pizza s tone and base
grill int o the right positio n.
Use t he 17X19 mm wrench to
remove the regulator and then put
on the NG hose. Fasten the hose
using 17X19 mm wrench.
24
Use the screw driver to put the
conversion sc rew into the kno b.
When co nv erting to natural ga s,
plea s e be aware that the low heat
set ting of the main burners and
searing burner is “ NG LOW,” as
shown on the control panel. “LP
LOW” se t ting is not a pplied when
converting to natural gas.
WA RNING: Please remember th is is an outdoor gas oven. Many areas of th e
gril l generate extreme heat. W e have taken every precaution to protect you from the
contact areas. However, it is impossible to isolate all high-temperature areas.
Therefore, use good judgment and a certain degree of caution when cooking on this
product. We suggest a covered, protected hand during operation of the oven. Do not
move t he oven when it i s in operat ion or hot to the touch. Wait until the unit is turned
off and properly cooled down before moving it. Failure to follow this
warning could
result in personal injury.
25
IMPORTANT:
After your outdoor oven is converted to nat ur al gas, the wor k ing pr essure for natur al gas is
7-inche wate r colum n (WC). Ga s pr essure is affected by gas line s iz e and the length of gas
line run from house. Follow the recommenda tions in the c hart below.
From House to Oven
Distance Tubing Size
Up to 25 ft. 3/8 in. DIA
26 – 50 ft. 1/2 in. DI A
51 – 100 ft. 2/3 in. of run 3/4 in.
1/3 in. of run 1/2 in.
Over 101 ft. 3/4 in. DI A
Burner LP Gas Natural Gas
Main Bur ner 16,000 BTU / Hr 16,000 BTU / Hr
CAUTION:
If low flames or bur ner problems are observed after converting from LP G to NG, the natural
gas line s m ay not be large enough. Refer to the “Fr om House to O ven” char t above for
natur al gas supply line specifications. Please contact a plumbe r to assure pro per pressure
at 7- inc h water co lum n.
DO NOT RETURN YOUR GRI LL TO THE STORE.
26
Never attach an unregulated gas line to the appliance. Connection to an unregulated
gas line can cause excessive heat o r f ire.
Verify the type of gas s upply to be used, either Natur al Gas (N.G.) or Liquid Propane (L.P.),
and make sure the ser ial plate agrees with that of the supply . Conversion kits are available
separately for an additio nal cost, which will enable yo u to convert your ove n from L.P. to N.G.
or to co nv ert your oven f ro m N.G . to L.P. Please see your loca l de
aler for more information.
Always have a qualif ied service tech nician p erf orm difficult conversi ons or
modifications.
For natural gas inst allations, an installer must supply a gas s hutoff valve t hat is easily
accessible to t he oven. All installer supplied parts m us t conform to loc al codes, or in the
absence of local codes, with the National Electrical Code, ANSI/NFPA 70- 2002, and the
National Fue l Gas Code, NFPA 54-2002/ANSI Z 223.1-2002.
All pipe sealants must be an a pproved type and
resistant to the actions of L.P. gases. Never
use pipe sealant on f lare fittings. All gas connect ions should be made by a competent qualified
serv ic e technician and in accordance with local codes and ordinances. I n the absence of loc al
codes, the installation must comply with the National Fuel Gas Code, NFPA 54-2002/ANSI
Z223.1-2002. Ga s co nv ersion kits may be pur c hased separately. When ordering gas
conversion kits, have the model number and the type of gas (N.G. or L.P.) used for your
oven on hand.
This oven must be isolated fro m the ga s s upply piping system by closing its individual ma nual
shut-off valve during any pressure testing o f the gas supply piping system at test pressures
equa l to or less than 1/2 PSIG (3.5 kPa ).
The installation of this o ve n must co nform with lo ca l codes, or in the absence of lo ca l c odes,
with National Fuel Code, NF PA 54-2002/ANSI Z223.1a-2002.
Ins tallation in Canada must be in accordance with the Standard CSA B 149.1 or
B149.2
(installation code fo r ga s burning applianc es and equipm ent) a nd local codes.
27
.
Clea r ance to combus tible const r uc t ion: A minimum o f 61 cm (24 inches) from the sides and
back m us t be maintained from the gas gr ill above
and be low the cooking sur face to adjacent vertical
combus tible co ns tructio n.
Clea r ance to non-combustible co ns t r uc tion: A
minimum of 61 cm (24 inches) clearance from the
back of the grill to non-c ombustible construction is
required.
Storag e of an outdoor ga s coo k ing appliance
indoo r is permissible only if the cylinder is
disconnected and
remove d from the applia nc e.
28
WARNING Heat and smoke exhaust out of
the c him ney and t he v entilation holes on t he bottom
of two oven side pane ls (Se e Fig. 8). Make sure to
keep anything tha t could be dama ged by heat or
smoke away from the heat and smoke exhaust
holes.
GENERAL RULES
Do not leave the oven unatt ended while cooking!
1. Ma ke s ur e the oven has bee n leak-teste d and is pr operly located.
2. Light t he grill burner s us ing the instr uc t ions provide d in this manual.
3. Turn the contro l k nobs to desired temperat ur e - High o r Low - and preheat the grill for 10
minute s before cooking.
4. A djus t heat sett ings to meet your cooking needs for desired res ults.
5. A llow grill to cool down, wipe of f any splatters or grease and clean the drip t r ay a
6. Do not put a cover on t he gr ill while it is s till hot as it could sta r t a fire.
s needed.
Do not att e m pt t o “light ” the gr ill if the odor of gas is
present!!
BEFORE AND AFTER LIGHTING
1. Ensure your ove n is located on a le ve l s ur face.
2. Kee p the gas oven area clean and fre e from combustible materials, gasoline, and other
flammable vapors and liquids.
3. Ensure nothing is obstructing the flow of combustion and ventilation air.
4. Ensure the ve ntilation of the c y linder enclosure is fre e and clear of debris.
5. V is ually chec k burner fl
WARNING Check t he gas supply line for cuts, wear or abrasion.
Always keep your face and body as far away from the oven as possible when lighting.
ames.
29
Operating Instructions
OVEN B URNE R LIGHTING
Warning: Do not lean over oven when lighting.
Turn off LP s upply at cylinder when appliance is
not in us e.
Main Bur ner Lighting Illustration:
1. Chec k that the contro l k nobs are in the OFF
position.
2. Open valve at tank fully by turning
counterclockwise.
3. The door must always be in the OPEN position
for lighting;
4. Push t he Electronic Ignition down 3 to 4 se co nds
while turning the c ontrol knob to the HIGH posit ion.
The burne r s hould ignite.
If ignit ion doe s not take place wit hin 5 se
immediately turn the control knob to the OFF position. Wait
5 minute s and repea t step 4 above or refe r to match lighting
instruct ions in manual.
If by chance the electronic ignit er does not light the burner,
the bur ner may be lit with a match attached to the match
extender, located on the inside of the cabinet door.
Remove the base gr ate and pizza stone. Kee p yo ur face as
far away from the burne r s ur face as poss ible and pass the
mat c h ex tender to the po r ts of the main burner tubes.
Position the mat c h near the burner ports and push and turn
the control knob co unterclockwise to t he “HIGH” position. After the burner has lit, turn the kno b
to the "LP LOW" positio n and carefully place t he f lame tamer s and gr ates back in pos ition.
Then turn the co nt ro l k nob to the desired setting.
NOTE: If the oven will not light after several attempts see t he Troubleshooting section
of this manual. Turn the control knobs to the OFF position when not in
conds,
Main Bu rner Contro l Knob
use.
Keep any electrical supply cords and the fuel supply
away from any heated surfaces.
30
USING THE GRILL LIGHT
Light Operation Instru ct ion
1. Ma ke s ur e t he light’s power switch on the control panel is in the “OFF” positio n.
2. Connect power plug to properly gr ounded outlet.
3. Turn the light’s power switch to “ON.”
WARNING
Keep any electrical supply cord away from any heated surface.
IMPAIRED VENTILATION OF HOT AIR FROM OVEN - In order for the burners to function
properly, hot air created by the burners must have a way to escape. The burners may become
deprived of oxygen, causing them to back f ir e, especially if the bur ner output is set at HIGH. If
this occurs repeatedly, the burners may crack. This is the rea son yo ur oven was designed with
ventilation louve rs. These design feat ure s give the hot air an escape route. Accordingly, never
o
perate yo ur oven with very lit tle or no open space at the cooking surfac e ( the cooking grids
provide sufficient space). Also, never cover the ventilation louvers with foil or other materials
that prevent air flow. Specifically, do not cover the entire surface with foil, a large pan, etc.
Normal:Soft blue flames
Out of Adjustment:Hard blue
flames-too much air
Poor Combustion:wavy,yellow
flames-too little air
31
Care & Maintenance
GENERAL MAINTE NANCE
- Keep outdoor cooking gas appliance area clear and free from combus tible mate r ials,
gasoline and other flammable vapors and liquids .
- Do not obs truct the f low of combustion and ventilation a ir .
- Keep the ventilation ope nings of the cylinde r enclosur e free and clear from debris.
- Vis ually chec k the burners.
GENERAL CLEANING
IM PORTANT: Before cleaning, make sure all cont ro ls are off and the oven is cool. A lways
follow label inst ruc tions on cleaning products.
For ro utine clea ning, wash with so ap and wate r us ing a soft cloth or sponge. Rinse with clean
water and dry at once with a s oft, lint-free cloth to avoid spots and streak s.
To avoid scra tching the surfa ce, do not use steel wool to clea n the oven.
Use a grill c over to protect finish from weat her.
GREASE CUP
The gre ase cup sho uld be cleaned periodically to prevent heavy buildup of debris .
NOTE: Allow the grease cup to coo l b ef ore attemp tin g to clean.
Import ant: Do not leave the oven outside during inclement weather unless it is covered.
Rain water can collect inside of the oven, the oven cart or the grease cu p i f left
uncovered. If th e grease cup is n ot cleaned af t er u se and the o ven is left un covered, th e
grease cup will fill with water causing grease and water to spill into the oven cart. We
recommend cl eaning and stori ng t h e grease cu p af t er every use.
DRIP TRAY
32
The drip tr ay should be cleaned periodically according t o the using situa tion.
NOTE: Allow the drip tray to cool before attempting t o clean.
COOKING GRATES
The co oking grates can be cleaned immediate ly after coo k ing is c ompleted and after t ur ning
off the oven. Wear a barbecue mitt and scrub the cooking grates with a damp cloth. If the oven
is allowed to coo l down, clea ning the grates will be easier if removed from the oven and
cleaned with a mild detergent.
STAINLESS STEEL
After initial usage, area s o f the oven may disco lor from the intense heat given off by the
burners.
This is normal. Purchase a m ild s tainless steel cleaner and rub in the dir ection of the gra in of
the me tal. Spe cks of grease can gat her on the surfa ce of the stainle ss stee l and bake on to the
surface and give a worn appearance. For removal, use a non-abrasive oven cleaner in
conjunction with a stainles s cleaner.
NOTE: Always scrub in the direction of the grai n.
GRILL LIGHT
Bulb Rep lacement
IM PORTANT SAF ETY INSTRUCTIONS
Lighted lamp is HOT:
WARNING -TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, EXPOSURE TO
EXCESSIVE UV RADIATION, OR INJURY TO PERSONS.
1. Turn off/unplug a nd allow to co ol before replacing bulb (lamp).
2. Bulb (lamp) get s HOT quickly! Only co ntact sw itch/plug when turning o n.
3. Do not touch hot lens, guard, or enc losure.
4. Do not remain in light if skin fee ls warm.
5. Do not look directly at lighted lamp.
6. Keep lamp away from materials that may burn.
7. Use only with a 10-watt or smaller bulb (lamp).
8. Do not touch the bulb (lamp) at any time. Use a so ft c loth. Oil fro m s k in may damage bulb
(lamp).
9. Do not operate
the portable luminaries wit h a m is s ing or dama ged guard, la m p c ontainme nt
barrier, or UV filter.
33
Definitions:
(+) Gua rd – Guard is a portion of portable lumina rie s unit that preve nts inadv erte nt co ntact wit h
the bulb. It may be integrated with the UV filt er or lamp cont ainment ba r r ier or as part of an
enclosu re or shad e.
(+) Lamp c ontainme nt barrier – lamp containment barrie r is a por t ion of a porta ble luminaries
unit that enclo s es the bulb.
(+) UV filter – UV filte r is a portion of a por table luminaries unit that limits ultraviolet ( UV )
emissio
ns.
1. Turn off/unplug a nd allow to
cool before re placing bulb (lamp).
Next , op en th e door and remove
the two cooking grills , smoker box,
pizza stone, base grill and flame
tamer.
2. Use screw driver to loosen
M5*35 scre w * 4 pcs that f ix the
hea t shield. And then remove t he
hea t shield.
34
3. Use screw driver to loosen the
screw that f ix the light assy.
4. Use one hand to hold the metal
back part of the light and one
handle to hold the f ro nt glass
cover and then take them apart.
Then yo u c an replace the bulb.
5. After replac ement, use o ne
hand to ho ld the meta l back part of
the light and o ne handle to hold
the front glas s cover and then clip
them together in the right pos ition.
35
6. Use M4*10 screw to fix the light
assy. on to the b ack panel of the
oven.
7. Use s c re w M 5*35× 4 pcs to fix
the back heat shield onto the back
pane l of the oven. The or der is:
screw back heat shield heat
insulat ion washer flat washer
oven back panel.
36
8. Finally, put back the two
cooking grills, sm oker box , pizz a
sto ne, base grill a nd flame tame r
into the oven. Now yo u have
finishe d r eplacing t he bulb.
Cleaning Method
Follow Steps below for glass cover remova l. Use a damp tow el to clean t he surface of glass
cover. Make sure the glass cover is completely dry befo r e reinstalling.
WARNING
Make sure the light switch is on “OFF” position and power plug is disconnected from
power ou t let prio r to cl eaning the glass cover.
WARNING
The l ight glass cover should not be in contact with water or any other liquid when it is
warm. Sudden changes of temperature m ay cause cracks on glass cover.
WARNING
To ensure continued protection against electric shock:
1. Connect to properly grounded outlets only.
2. Do n o t expose to rain .
3. Keep extension cord connections dry and off the ground.
Bulb sp ecification
Bulb Type: Halogen
Wattage: 20 watts per bulb
Volt age: 12 volt s
Please contact customer service at 1(800) 966-812 6 for assistance on bulb replacement.
37
Replacing Battery for Electrical Igniter:
1. Rem ove the igniter cap by turning clockwise;
2. Replace the battery;
3. When inst alling new battery, ensure it is installed w ith
the proper polarity;
4. Put on the igniter cap back by t ur ning
counterclockwise.
WARNING:
1. To protect agains t electr ic s hoc k, do not imme r se co r d or plugs in wate r o r other liquid.
2. Unplug f r om the outlet when not in use and before c leaning. Allo w to cool before putt ing on
or ta k ing off parts.
3. Do not operate
any outdoor c ooking gas appliance with a damaged cord, plug, or after the
applia nc e malfunctions or has been damaged in any manner. Contac t the manufacturer for
repair.
4. Do not let the cord hang over the edge of a table or touch hot surfaces.
5. Do not use an outdoor cooking ga s appliance for purpo se s o t her than intende d.
6. When connect ing, first co nnect plug to the outdoor coo k ing gas appliance then plug
applia nc e into the outlet.
7. Use only a Ground Fault Interrupter (GFI) prot ected cir c uit with this o ut door c ooking gas
appliance.
8. Nev er remove t he gr ounding plug or us e with a two-pr ong adaptor .
9. Use only extension cords with a three-prong grounding plug, rated for the power of the
equipment, and appr oved for outdoor use with a W-A ma r k ing.
OVEN DOOR CLEANING
1. Loosen the M4*10 screw * 4
pcs that fix the oven door and then
take the oven door apart from the
oven.
38
2. Loosen the M4*10 screw * 7
pcs that fix the doo r ex terior and
interior, and then loosen the
M4*10 scre w * 4 pcs that f ix the
doo r hinge. Then loose n the
shoulder screw that attaches the
doo r handle.
3. Use spanner 19# to loosen the
nut that fix the temperature gauge.
And t hen you can completely
separate the oven door exterior
and interior so as to do the
cleaning.
4. After cleaning, y ou need to
re-assemble the oven door. Put
the door in terior on to th e ext er i or
and ma ke every screw hole in line
with each other. Use M4*10 screw
* 7 pcs to fix the door interior and
exte r ior. And the n use shoulder
screw to fix the handle onto the
doo r . Finally, use M4*10 screw * 4
pcs to fix the hinge onto the doo r.
39
5. Use s panner or hand directly to
tighten the nut that fix the
tem perature ga uge on the glass.
You can set the torque of the
spanner at 4.0kgf *c m.
6. Use M4*10 screw * 4 pcs to fix
the door onto the oven. Now you
have finished cleaning the oven
door.
40
TROUBLESHOOTING
Many s olutions giv en here can ma ke yo ur gr illing experience sa fer and more enjoyable. You
can also call the cu st om er service department at 1-866- 410-0408, 8 a.m. – 5 p .m., PST,
Monday to Friday.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Grill w ill not
light.
Burner flame is
yellow and gas
odor can be
smelled.
1. The ignit ion wire came off the
ele c trical igniter/va lve .
2. The distance between the ignit ion
pin and the burner is greater than 3~5
mm.
3. The ignit ion wire is broken.
4. The battery has died.
5. The battery is in the wrong polarity.
6. The electro de tip does not produce
sparks at the burner port.
7. No gas supplied.
8. A ir s hutter opening is too big.
1. The air shutter opening is not
properly set.
2. Spide r s or insects block the air
shutter.
3. Po s s ible gas leaks .
1. Rec onnect the ignition wire to the
electrical igniter/valve.
2. Loosen the ignition pin and adjust
the distanc e, then fas ten it agai n .
3. Call customer service for a
replacement ignition w ire .
4. Install a new AA battery.
5. Change the batte r y polarity.
6. Reins tall the electrode.
7. Turn on the regulator valve.
8. Loosen the air shutter and adjust
the opening to a smaller size.
1. Loosen the air shutter and adjus t
the opening to have blue flames.
1/4 in. opening for LPG.
1/8 in. or less opening for NG.
2. Clean blockages.
3. Check for the source of gas leaks.
Excessive
flare-up.
1. Grilling f atty meats.
2. Knobs on “HIGH.”
3. Spray water on gas flames.
4. Hood closed when grilling.
1. Mo ve the meats to the wa r m ing
rack if flare up cont inues until fla m e
settles down.
2. Grill fatty meats when the grids are
cold while the knobs are on the “ LP
LOW” (w hen using LP Gas) or “NG
LOW” (when using Natural Gas)
setting.
3. Never spray water on gas flames.
4. Hood up when grilling.
Burner blows
out.
1. LP tank is empty.
2. Burner is not a ligned with the
cont r ol valve.
3. Gas supply is not sufficie nt.
1. Refill the LP Tank.
2. Install the burner correctly.
3. Chec k the gas supply hose and
make sure there are no leaks and no
knots.
Low heat with
the knob in
“HIGH”
position.
1. Low heat is found in natural gas
models.
2. Ports are blocked.
3. LP tank has run out.
1. This model is set for 7 in. natural
gas usage. Plea se c hec k yo ur natural
gas supply system to have correct
gas pressure. Regulator is not
need ed f or NG m od el.
Check the orific e if you insta lled NG
nozzles. Conversion kit provides the
following nozzles:
41
Low heat, LP
gas.
Low heat,
natur al gas.
Coo k ing light
will no t turn on.
TROUBLESHOOTING
The pro pane regulator assembly
incorporates an excess flow device
designed to supply the grill with
sufficient gas flow. Rapid changes in
pressure can trigger the excess flow
device, providing a low flame and low
temperature.
Gas pre s s ure is significantly affected
by gas line and length of gas line from
house gas line.
1. No power supply.
2. Defective Ha logen bulb.
3. Internal wiring issue.
Burner Orifice Size
Main Burner
ĭ 1.8 mm
2. Clear ports of any obstructions.
3. Refill the LP tank.
Please follow these instructions:
1. Make sure all burners are “OFF.”
2. Open the tank valv e and wait 5
minutes.
3. Light t he burner one at a time
following the lighting instruct ions
liste d on the door liner and Page 25
and 26.
Check y our gas line and make
corr ections by following the chart
below:
From House to Grill
Distance Tubing Size
Up to 25 ft. 3/8 in. DIA
26 – 50 ft. 1/2 in. DIA
51 – 100 ft.
Ove r 101 ft. 3/4 in. DIA
2/3 in. of run 3/4 in.
1/3 in. of run 1/2 in.
1. Chec k power supply a nd m ake
sure it is properly plugged in.
2. Replace the bulb.
3. Chec k the wiring connections
under the fire box. A ll wire
connections must be tigh t. If any
wires are damaged they should be
replaced.
42
WARRANTY
Summ erset P ro f essional Grills Oven Limited Warranty
5 year warranty on workmanship on The Oven covering construction and materials
3 year warranty on burner
1 year warranty all int ernal parts, grates, burner covers, igniter, light and exter nal parts
Proof of purchase is required to access this warranty program, which is in eff ect from the
date of pur c hase. Customers w ill be subject to parts, shipping, and handling fe es if unable to
provide proof of the pur c hase or afte r the warrant y has ex pir ed.
If you have any ques tions or problems, call custom er service department at 1(800)
966-8126,8:30 a.m. – 5 p.m., PST, Monday to Friday.
Warranty Prov
This wa r r anty is non-tr ansferable and does not cov er failures due to misuse of improper
installation or maintenance.
This wa r r anty is fo r re pair or repla ce me nt of defective parts only. We are not responsible for
incident al or consequential damages or labor costs.
This wa r r anty doe s no t cover corrosion or discoloration after the oven is used, o r lac k of
maint enance, hos tile environment, acc idents, alterations , abuse or ne glect.
This
warranty does not cover damage caused by heat, abrasive and chemical cleaners, or any
damage to other components used in the installation or operation of the gas oven.
Paint is not warrant ed and may require touch-up. Items considered to be consuma ble such as
batteries are not covered under this war r anty.
Some s tate s do not allow t he limita tion or exclusio n of incide nt al or co nsequentia l da mage s, so
the above limitations or exclusions may not a
rights, and you may also have other rights that vary from state to state.
isions:
pply to yo u. This war r anty gives you specific legal
AMD DIRECT
17322 Gothard St.
Huntington Beach, CA 926 47
1(800) 966-8126
www.summersetgrills.com
info@summersetgrills.com
43
Exploded Diagram
For replacement parts, call our cu st omer service d epartment at 1(800) 966-8126 8:3 0
a.m. – 5 p.m., PST, Monday to Friday.
8
9
10
46
5
17
18
29
30
20
53
57
40
6
21
27
2628
5554
56
22
4241
7
14
1211
13
36
45
47
48
15
32333435
3837
44
49 50
58
16
19
31
39
51
52
234
1
232425
43
60
61
74
73
72
71
59
62
44
63
70
68
69
65
6664
67
Exploded Diagram
No. Part Name QTY No. Part Name QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Heat spacer 4
Back heat-shield 1
Light assy. 1
Light bracket 1
Handle latch 1
Gas pi pe 1
Chimney assy. 1
Cooking grill 2
Smok er box assy. 1
Pizza stone 1
Bottom grill 1
Interior assy. 1
Round burner assy. 1
Exterior 1
Fascia heat shield 1
Oven front panel 1
Back panel 1
Grease tray 1
Electronic igniter 1
Nozzle stator 1
Valve 1
Viewing window 2
Door handle assy. 1
Door heat shield assy. 1
Left glass fixing bracket 1
Bottom glass fixing bracket 1
Round tem p . gauge 1
Right glass fix ing bracke t 1
Control fascia 1
Kno b be zel 1
Control knob 1
Light switch 1
Oven door assy. 1
Oven door hing e 2
Glass pressin g 1
Left side shelf bracket 2
Oven left supporting assy. 1
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
Grease tray left bracket 1
Oven back support 1
Grease tray right bracket 1
Oven right supporting assy. 1
Light transformer 1
Mat ch ho l de r 1
Camp st ove s uper i or girder 1
Right side shelf bracket 2
Side be d pla te as sy. 2
Rail support 2
Two part roller rail 2
Drawer fascia 1
Door handle 2
Drawer 1
Drawer interi or 1
Grease tray 1
Grease tray stator 2
Fat cup 1
Spring hinge assy. 1
Oven su pportin g beam 1
Trolley top panel 1
Trolley door horizontal beam 1
Trolley left side pan el assy. 1
Triangle fortified 2
Trolley back panel 1
Magnet 1
Trolley right side panel assy. 1
Door axis 1
Trolley door exterior 1
Trolley door interior 1
Tank tray assy. 1
Tank fastener 1
Base tray assy. 1
Weight 1
Swivel castor without lock 2
Swivel castor with lock 2
Flame Tamer 1
45
BG070-01 Oven
1、
Exterior * 1 pc
Repla c ement Par t s
2. BG070-02-00B Oven
Interior * 1 pc
3. BG070-24 Burner
Bracket Beam * 1 pc
4. BG070B-03-01 Oven
Back Panel * 1 pc
5. BG070-03A Oven
Back Heat Shield * 1 pc
9. BG070-32A Pizza
Stone * 1 pc
13. BG070B-03-02 Light
Bezel * 1 pc
6. BG070-10-00B Burner
Assy. * 1 pc
10. BG070-13-00 Smoker
Box * 1 pc
14. BG0904B-01-10
Light Assy. * 1 pc
7. BG070-18 Cooking
Grate * 2 pcs
11. BG070-08-00C
Chimney Assy. * 1 pc
15. BG070B-70 Grease
Stopper * 1 pc
8. BG070-17B Base
Grate * 1 pc
12. BG070B-05A Control
Fascia * 1 pc
16. BG070-19A Gas Pipe
* 1 pc
17. BG070-20A Valve
Assy. * 1 pc
21. BG070B-66 Orifice
Holder * 1 pc
18. DHL-128-1Q-2D-1
Electric Igniter * 1 pc
22. BG070B-09-03-00
Oven Door Heat Shield *
1 pc
19. BG179-94 Control
Knob * 1 pc
23. BG070B-09-00B
Oven Door Assy. * 1 pc
46
20. BG179-73-00 Knob
Bezel * 1 pc
24. BG070-45 Oven Door
Hinge * 2 pc
Repla c ement Par t s
25. BG070B-38 Oven
Door Glass * 2 pc
29. BG070B-30-01 Left
Sideshelf Bracket * 2
pcs
33. BG070B-59 Oven
Back Seal Panel Oven
Left Holder Panel * 1 pc
26. BG070-30 Temp.
Gauge * 1 pc
30. BG070B-30-02 Right
Sideshelf Bracket * 2
pcs
34. BG070B-60-01
Grease Tray Left
Bracket Oven Left
Holder Panel * 1 pc
27. BG070-12-00 Oven
Door Handle Assy. * 1 pc
31. BG070B-57-00 Oven
Left Holder Panel * 1 pc
35. BG070B-60-02
Grease Tray Right
Bracket Oven Left
Holder Panel * 1 pc
28. BG070-76-00
Sideshelf * 2 pcs
32. BG070B-58-00 Oven
Right Holder Panel * 1
pc
36. BG070B-71 Oven
Upper Beam * 1 pc
37. BG070B-65 Oven
Supporting Beam * 1 pc
41. BG0614B-04-13
Drawer Rail * 2 pcs
45. BG070B-62-00 Fat
Cup Assy. * 1 pc
38. BG070B-64 Drawer
Rail Bracket * 2 pcs
42. MCG4-04-01 Handle *
2 pcs
46. TYQ-9B-LL516-00
Hose and Regulator * 1
pc
39. BG070-75 Drawer *
1 pc
43. BG070B-61 Grease
Tray * 1 pc
47. DGP350NP-55-00
Match Holder * 1 pc
40. BG070B-63-00
Drawer Fascia * 1 pc
44. BG070B-69 Fat Cup
Bracket * 2 pcs
48. BG070B-73-00 Flame
Tamer Assy. * 1 pc
47
Repla c ement Par t s
49. BG070B-53 Trolley
Top Panel * 1 pc
53. BG070B-52 Trolley
Back Panel Assy. * 1 pc
57. DGP350SNP-30-00
Cylinder Tray Assy. * 1
pc
50. BG070B-54 Trolley
Door Horizontal Beam *
1 pc
54. BG070B-55 Trolley
Door Exterior * 1 pc
58. BG070-78-00 Trolley
Base Panel Assy. * 1 pc
51. BG070B-50-00
Trolley Left Sidepanel
Assy. * 1 pc
55. BG070B-56 Trolley
Door Interior * 1 pc
59. BG1073B-52 Swivel
Castors * 2 pcs (with
lock)
52. BG070B-51-00
Trolley Right Sidepanel
Assy. * 1 pc
56. BG070-40 Triangle
Bracket * 2 pcs
60. BG1073B-52B Swivel
Castors * 2 pcs (without
lock)
61. M5*30 Screw * 4 pcs 62. M6*12 Screw * 37
pcs
65．BG070-41
PVC Feet Washer * 8 pcs
69．M5*35 Screw * 4 pcs 70．M5*10 Screw * 24
66．ES22-A10-4 PVC
Feet * 4 pcs
pcs
63. M4*10 Screw * 12
pcs
67．ST1222-09-09 Oven
Back Panel Heat
Insulation Washer * 4
pcs
71．M3*12 Screw * 2pcs
64．M4*8 Screw * 3 pcs
68． M6*40 Screw * 2 p cs
48
Repla c ement Par t s
Attach the “installation flanges” to your oven. This will s upport y our
oven in the is land. (Sold Separately)
After your island is made with the correct cut out dimensions, and you have your
flanges attached, slid e your oven into your c ut out. Then plu g in your electrical
and c onnect gas to your oven.
“Built In” Cut Out Dimensions
49
Loading...
