Type: CDR910
◆Product Description
・12.95×9.4mm Max.(L ×W), 11.3mm Max. Height.
・Inductance Range: 10 uH～1.0mH
・Rated current range: 0.44～4.8A
・In addition to the standards versions shown here, custom inductors are also available
to meet your exact requirements.
◆ Feature
・Magnetically unshielded construction.
POWER INDUCTORS <SMD Type: CDR Series>
・Ideally used in Communication devices like
・RoHS Compliance.
×DSL modem, router and access point.
◆ Dimensions (mm)
11.3 Max.9.4 Max.
2.54
1
8.5
7.6
2
◆Land Pattern (mm)
2.6
12.95 Max.
2.79 Ref.
2.92 Ref.
7.37 Ref.
Please refer to the sales offices on our website for a representative near you
www.sumida.com 1/2
Type: CDR910
◆Specification
POWER INDUCTORS <SMD Type: CDR Series>
Part Name
※
CDR910NP-100M□
CDR910NP-150M□
CDR910NP-180M□
CDR910NP-220M□
CDR910NP-330M□
CDR910NP-470M□
CDR910NP-680M□
CDR910NP-101M□
CDR910NP-151M□
CDR910NP-221M□
CDR910NP-331M□
CDR910NP-471M□
CDR910NP-681M□
CDR910NP-102M□
Inductance
Stamp
100 10uH±20% 24 (20) 6.88(8.60) 4.80 (5.50)
150 15uH±20% 29 (24) 5.76(7.20) 4.30 (4.90)
180 18uH±20% 32 (26) 5.29 (6.62) 4.00 (4.60)
220 22uH±20% 45 (36) 4.72 (5.90) 3.40 (3.90)
330 33uH±20% 65 (54) 3.76 (4.70) 2.60 (3.00)
470 47uH±20% 85 (68) 3.20 (4.00) 2.42 (2.78)
680 68uH±20% 125 (100) 2.68 (3.35) 1.90 (2.20)
101 100uH±20% 190 (155) 2.18 (2.72) 1.50 (1.72)
151 150uH±20% 280 (230) 1.76 (2.20) 1.20 (1.38)
221 220uH±20% 360 (300) 1.46 (1.83) 1.10 (1.25)
331 330uH±20% 565 (470) 1.20 (1.50) 0.85 (0.96)
471 470uH±20% 820 (670) 1.00 (1.25) 0.71 (0.81)
681 680uH±20% 1260 (1050) 0.84 (1.05) 0.54 (0.62)
102 1000uH±20% 1850 (1522) 0.68 (0.85) 0.44 (0.50)
［Within］
100kHz/1V
D.C.R.(mΩ)
Max.(Typ.)
(at 20℃)
Saturation Current
Max.(Typ.)
（A）※1
Temperature
rise current
Max.(Typ.)
(A)※2
※ Description of part name
CDR910NP-100M□
※1.Saturation current: The DC current at which the inductance decreases to 90% of it’s initial value.
(Ta＝20℃)
※2.Temperature rise current: The DC current at which the temperature rise is △t＝40℃.(Ta＝20℃)
B Box
C Carrier Tape
Please refer to the sales offices on our website for a representative near you
www.sumida.com 2/2
