U N D E R C O U N T E R I C E M A C H I N E
I N STA L L AT I O N &OPE R AT I O N
O N T E N T S
C
Ice Machine Installation 4
Installation Checklist 16
Ice Machine Features 17
Ice Machine Operation 18
Ice Machine Care 23
Troubleshooting Guide 28
Service Information 30
Sub-Zero Warranty 31
Features and specifications indicated herein and
on the website are subject to change at any time
without notice. Check our website, subzero.com,
for the most up-to-date specifications.
As you follow these instructions, you will
notice WARNING and CAUTION symbols.
This blocked information is important for the
safe and efficient installation of Sub-Zero
equipment. There are two types of potential
hazards that may occur during installation.
SUB-ZERO®is a registered trademark of Sub-Zero, Inc.
signals a situation where minor injury or
product damage may occur if you do not
follow instructions.
states a hazard that may cause serious
injury or death if precautions are not
followed.
Another footnote we would like to identify is
IMPORTANT NOTE: This highlights information that is especially relevant to a problemfree installation.
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N A N D O P E R AT I O N
T H A N K YO U
Congratulations on the purchase of your
Sub-Zero ice machine. It produces the same
high quality clear ice that you would expect
from Sub-Zero.
The importance of the installation of the ice
machine cannot be overemphasized. Installation should be done by a qualified installer.
Before you begin the installation process,
it is recommended that you read the entire
installation instructions. There are key details
that you should take special care to observe
during the installation. By reading these
instructions carefully, you will make the
installation process easier, problem-free and,
most importantly, safe.
Any questions or problems about the
installation should be directed to your
Sub-Zero dealer or Sub-Zero customer service
at 800-222-7820. You can also visit our website
at subzero.com.
The Sub-Zero ice machine is protected by a
warranty that is one of the finest in the
industry. Take a moment to read the warranty
statement on page 31 and refer to it should
service become necessary.
The operation information in this book will
answer most of your questions about the
features, operation and maintenance of your
ice machine. If you have questions that are not
addressed here, call Sub-Zero customer
service at 800-222-7820 or visit our website
at subzero.com.
IMPORTANT NOTE:
Your Sub-Zero ice
machine is designed and manufactured with
the highest regard for safety and performance. It meets or exceeds the standards of UL
and CUL. Sub-Zero assumes no liability or
responsibility of any kind for products manufactured by Sub-Zero that have been altered
in any way, including the use of any parts
and/ or other components not specifically
approved by Sub-Zero. Sub-Zero reserves the
right to make design changes and/or
improvements at any time. Specifications and
designs are subject to change without notice.
Do not operate equipment that has been
misused, abused, neglected, damaged, or
altered /modified from that of original
manufactured specifications.
P R O D U C T R E G I S T R AT I O N C A R D
The packet containing this manual also
includes warranty information. Warranty
coverage begins the day your new ice machine
is installed.
IMPORTANT NOTE:
Complete and mail the
product registration card as soon as possible
to validate the installation date. If you do not
return your product registration card, Sub-Zero
will use the date of sale to the Sub-Zero dealer
as the first day of warranty coverage for your
new ice machine.
O N T A C T
C
I N F O R M AT I O N
Sub-Zero
customer service:
800-222-7820
Website:
subzero.com
3
C C E S S O R I E S
A
Optional accessories are available
through your
Sub-Zero dealer. To
obtain local dealer
information, visit
the Showroom
Locator section of
our website,
subzero.com.
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
C E M A C H I N E R E Q U I R E M E N T S
I
odels UC-15I and UC-15IO must have
M
open site (gravity) drain available
(see page 8).
A grounded, polarized electrical power
supply on a separate circuit servicing only
this appliance is required. If GFCI (ground
fault circuit interrupter) is required by your
local electrical code or in an outdoor installation, it must be breaker type, not outlet
type (see page 7).
Must have cold water supply line available
at ice machine (see page 8).
Clearance and air temperature requirements
must be met (see page 6).
If built into a cabinet, ice machine must be
removable for yearly cleaning procedure
(see page 23).
Proper installation requires connection to
the water supply, a drain and a dedicated
lectrical circuit. These connections are
e
the responsibilities of the owner/operator.
Improper connections can result in
personal injury, substantial property
damage and erratic machine operation. If
ou are unsure of your ability to safely
y
connect the ice machine, consult qualified
professionals or contact Sub-Zero.
IMPORTANT NOTE:
Failure to follow these
installation guidelines may affect warranty
coverage.
The model and serial number are listed on the
rating plate in the upper left corner of the ice
bin and on the back of the unit. Refer to the
illustration below.
M O D E L / S E R I A L N U M B E R L O C AT I O N
Models UC-15I, UC-15IP, UC-15IO & UC-15IPO
Rating plate
Dimensions in parentheses are in
millimeters unless otherwise specified.4
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
143/4" (
375)
23" (
584)
335/8"
(854)
4" (102)
18"
(457)
24" (610)
ROUGH
OPENING
DEPTH
LOCATION OF
WATER LINE
8"
(203)
1
/2"
(13)
TOP VIEW
341/2" (876)
ROUGH
OPENING
HEIGHT
335/8" (854)
MINIMUM
HEIGHT
REQUIRED
151/4"min (387)
ROUGH
OPENING WIDTH
POSITION OUTLET
WITH GROUNDING
PRONG ON RIGHT
FRONT VIEW
4"
(
102
)
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
O V E R A L L D I M E N S I O N S
Models UC-15I, UC-15IP, UC-15IO & UC-15IPO
A L L M O D E L S
Overall Width 143/4" (375)
verall Height (levelers in) 33
O
5
(854)
/8"
Overall Depth 23" (584)
Minimum Door Clearance 18" (457)
Rough Opening Width 151/4" (387)
Rough Opening Height 341/2" (876)
Minimum Height Required
(levelers in) 335/8" (854)
Rough Opening Depth 24" (610)
Dimensions may vary ±1/8" (3).
Overall dimensions do not include panels
or handles.
I N S TA L L A T I O N S P E C I F I C A T I O N S
5
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
O C AT I O N O F I C E M A C H I N E
L
he location selected for the ice machine must
T
meet the following criteria. If any of these
criteria are not met, select another location.
The ice machine may be built into a
cabinet, however the location must allow
removal of the ice machine for cleaning and
servicing. Service diagnostics are
performed from the top of the ice machine.
The location must be free of airborne and
other contaminants.
Do not place the unit within 18" (457) of a
trash compactor or trash/recycling
container.
The air temperature must be at least 50°F
(10°C), but must not exceed 100°F (38°C) for
models UC-15I and UC-15IP and 110°F
(43°C) for models UC-15IO and UC-15IPO.
The location must not be near heat-generating equipment.
The location must not obstruct air flow
through the kickplate (airflow is in and out
the front of the ice machine).
The location must allow enough clearance
for water, drain and electrical connections
at the rear of the ice machine.
Models UC-15IO and UC-15IPO may be
installed outside.
R E A R E Q U I R E M E N T S
A
efore moving the ice machine in place, be
B
sure the finished opening dimensions, electrical and plumbing locations are accurate.
efer to pages 7–11.
R
Be sure your plumber, electrician and
cabinet installer have this information before
finishing work is completed.
Models UC-15I and UC-15IO are gravity drain
models that require a drain tube that is
pitched down from the outlet at the back of
the unit to the sanitary sewer connection.
Models UC-15IP and UC-15IPO have a built
in drain pump that will pump water up to a
drain point, such as a nearby sink. Refer to
specifications on pages 8–9.
IMPORTANT NOTE:
If the ice machine is
installed in a corner, the door swing may be
limited due to handle contact with the wall
or cabinet face.
IMPORTANT NOTE:
The floor under the
ice machine must be at the same level as the
surrounding finished floor.
IMPORTANT NOTE:
When you move the
unit using a hand truck or dolly, position the
dolly on the side of the unit and secure the
door so it does not open while transporting
the unit.
Any finished flooring should be protected
The ice machine must be protected if it
will be subjected to ambient temperatures below 32°F (0°C). Component failure
caused by exposure to freezing temperatures is not covered by the warranty. See
page 27.
6
with appropriate material to avoid any
damage from moving the unit.
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
L E C T R I C A L R E Q U I R E M E N T S
E
repare electrical circuit before installation of
P
your ice machine. Installation requires a
grounded (three-prong), polarized receptacle
ith a separate fuse/circuit breaker in an elec-
w
trical service box.
V O LT A G E
Do not use an extension cord or twoprong adapter. Electrical ground is
required on this appliance. Do not remove
the power supply cord ground prong.
All electrical work, including wire routing and
grounding, must conform to local, state and
national electrical codes. The following precautions must be observed:
MPORTANT NOTE:Observe correct
I
polarity of incoming line voltage.
Incorrect polarity can lead to erratic ice
machine operation and a safety issue.
M I N I M U M C I R C U I T R E Q U I R E M E N T
The minimum circuit requirement is used to
help select the wire size of the electrical
supply. (Minimum circuit requirement is not
the ice machine’s running amp load.)
M A X I M U M B R E A K E R S I Z E A N D
M I N I M U M C I R C U I T A M P E R A G E
Voltage/Phase/ Cycle 115/ 1/60
Maximum Fuse/Circuit Breaker 15
Minimum Circuit Amps 4.1
M P O RT A N T
I
N O T E
You must follow
all National
Electrical Code
regulations. In
addition, be aware
of local codes and
ordinances when
installing your
services.
The ice machine must be grounded.
A separate fuse /circuit breaker must be
provided for each ice machine.
The maximum allowable voltage variation
is +/-10% of the rated voltage at ice
machine start-up (when the electrical load
is highest).
The minimum wire size is #14 for less than
100 feet (30.5 m) or #12 for more than 100
feet (30.5 m) to 200 feet (61 m) (solid
copper conductor only). The recommended
breaker is 15 amp. Local or state electrical
code, length of run or materials used, can
increase the minimum wire gauge required.
A qualified electrician must determine the
proper wire size, although #14 is the
minimum size allowed.
G F C I R E Q U I R E M E N T S
For Models UC-15IO and UC-15IPO or if a
GFCI (ground fault circuit interrupter) is
required by local electrical code, it must be
breaker type.
Dimensions in parentheses are in
millimeters unless otherwise specified.
7
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
P L U M B I N G R E Q U I R E M E N T S
M P O RT A N T
I
N O T E
Plumbing must
conform to state
and local codes.
W A T E R S U P P L Y
Prepare water supply line and drain before
installation of your ice machine. Installation
requires a minimum
1
/4" ID copper cold water
line and compression fitting (not supplied).
Models UC-15I and UC-15IO are supplied with
a drain hose for gravity draining. The optional
drain pump or pump models UC-15IP and
UC-15IPO must be purchased if a gravity drain
is not possible. Both drain methods require
routing to an open site drain. Do not connect
directly to drain line as bacteria from drain line
may contaminate the ice machine.
The included water filter is designed to inhibit
scale formation, filter sediment, and remove
chlorine odor and taste. The life expectancy of
the water filter is 6 months during normal
usage. The ice machine control board will
monitor water usage and indicate when
replacement is required.
W A T E R I N L E T L I N E S
Follow these guidelines to install water inlet
lines:
Do not connect the ice machine to a hot
water supply. Be sure all hot water restrictors installed for other equipment are
working. (Check valves on sink faucets,
dishwashers, etc.)
D R A I N C O N N E C T I O N S
Follow these guidelines when installing drain
lines to prevent drain water from flowing
back into the ice machine and storage bin:
Drain lines must have a 1
eet of run (2.5 cm per meter), and must
f
1
/2" drop per 5
not create traps.
The floor drain must be large enough to
accommodate drainage from all drains.
Drain pump discharge line must terminate at an open site drain.
Maximum rise – 12 feet (3.7 m)
Maximum run – 100 feet (30.5 m)
A P P ROX I M AT E H E I G H T O F
I C E M A C H I N E D R A I N
Standard installation 5" (127)
Improper drainage can lead to water
flowing back into ice machine and poor
performance.
If water pressure exceeds the maximum
recommended pressure (80 psi–551.5 kPA),
obtain a water pressure regulator from your
local plumbing contractor.
Install a water shut-off valve for the ice
making water lines.
Insulate the water inlet line to prevent
condensation.
8
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
L U M B I N G R E Q U I R E M E N T S
P
W A T E R S U P P L Y A N D D R A I N L I N E S I Z I N G / C O N N E C T I O N S
ater Water Ice Machine Tubing Size up to
W
emperature Pressure Fitting Ice Machine Fitting
T
Ice Making
Water Inlet
ater Outlet
W
C-15I and
U
50°F (10°C) Min. 20 psi (137.9 kPA) Min.
1
/4" (6.4) ID
80°F (27°C) Max. 80 psi (551.5 kPA) Max. Copper Tubing inside diameter
3
(19)
/4"
—
— Hose Barb inside diameter
1
/4" (6.4) minimum
3
(19) minimum
/4"
UC-15IO
Water Outlet
UC-15IP and
3
/8" (9.5)
——Hose ID minimum
3
/8" (9.5)
UC-15IPO
NOTE: If air temperature is less than 60°F (16°C), water temperature must be equal to or greater than 50°F (10°C).
M P O RT A N T
I
N O T E
Plumbing must
conform to state
and local codes.
IMPORTANT NOTE:
Although the ice
machine has been designed to be serviced in
place, in some cases it may be necessary to
pull the unit out for service. For that reason
do not restrict access to the unit at the front,
top and bottom.
If a floor is to be installed after the ice
machine, shims the thickness of the floor
should be installed under the unit to keep the
ice machine level with the floor. Also, allow
1
/8" (3) clearance on each side of the unit for
protruding screw heads.
Installations on a slab:
Use a Model
UC-15IPO or UC-15IP, with built-in drain
pump and pump the water to the point of
drainage. Drain pump models will pump
12 feet (3.7 m) high.
Installations over a crawl space or
basement:
If there is not enough room
behind the ice machine for a drain /waste
water receptacle, the drain will have to be
below the floor.
Dimensions in parentheses are in
millimeters unless otherwise specified.
9
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
I N S TA L L AT I O N
I N S TA L L A T I O N P RO C E D U R E
1)
Prepare the site by following the instructions under Electrical Requirements and
Plumbing Requirements on pages 7–9.
2)
Remove ice machine from carton.
3)
Inspect for damage.
4)
Remove literature/warranty packet and
drain hose from inside the ice machine.
5)
Adjust leg levelers. Refer to Leveling on
page 12.
6)
Reverse door if desired. See pages 12–13.
7) Gravity drain model:
Install drain hose to
drain on back of ice machine and route to
open site drain. Refer to Plumbing Requirements on pages 8–9.
Pump model:
Route drain tubing through
drain fitting on the back of the ice machine
and install drain hose on drain pump.
Route other end of drain tubing to drain
site. Refer to Plumbing Requirements on
pages 8–9.
9)
Open the shut-off valve on the water line.
10)
Check all visible connections for water
leakage. Failure to do so could cause
flooding.
11)
Connect electrical plug to grounded (threeprong), polarized outlet. See Electrical
Requirements on page 7.
The ice machine must be grounded in
accordance with national and local
electrical codes. Do not use an extension
cord or adapter.
Improper water supply and drain connections can result in personal injury and
substantial property damage. These
connections are the responsibility of the
owner/operator.
8)
Use compression fitting to connect the
Water Inlet on back of ice machine to the
prepared
1
/4" ID cold water line. Refer to
Plumbing Requirements on pages 8–9.
12)
Drain
Fitting
Water
Inlet
Connect to drain
Place ice machine back in position and
check leveling again. Make any necessary
adjustments.
Dimensions in parentheses are in
millimeters unless otherwise specified.10
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
151/4"min
(387)
OPENING WIDTH
TOP VIEW
TOP VIEW
FRONT VIEW
1
/8" (3)
DRAIN
TUBE
WATER
INLET TUBE
SHUT-OFF
VALVE
DRAIN
TUBE
WATER
INLET
TUBE
SHUT-OFF
VALVE
DRAIN
151/4"min
(387)
OPENING WIDTH
TOP VIEW
TOP VIEW
FRONT VIEW
1
/8" (3)
DRAIN TUBE
SHUT-OFF
VALVE
AIR GAP
DEVICE
DRAIN TUBE
AIR GAP
DEVICE
WATER
INLET TUBE
SHUT-OFF
VALVE
WATER
INLET TUBE
I N S TA L L AT I O N
13)
Prepare sanitizer solution and sanitize
the ice machine according to In Place
Cleaning/Sanitizing Steps 6 and 7 on
page 25.
14)
Put one gallon (4 L) of cold water into a
container that will easily pour under the
ifted water shutters. Refer to page 17 to
l
identify water shutters. Open shutters
and add one gallon (4 L) of cold water.
Watch for proper drainage.
15)
Press
POWER
16)
At initial start-up, ice machine will need
button.
approximately 30 minutes to freeze ice
and up to 5 minutes to harvest the ice.
Wait for first cycle of cubes to drop to
ensure proper installation.
Do not cover the kickplate area.
The unit must be allowed to have ventilation
through these fins. The door panel may hang
in front of the fins, but a decorative kickplate
must not cover the fins.
The kickplate can be painted another color, if
you choose. Follow these easy steps:
Rough up surface to be painted with fine
grit sandpaper.
Wipe with alcohol to ensure it is clean
and dry.
Use an appliance or industrial grade, oil
base, high gloss enamel paint.
I N S TA L L A T I O N S P E C I F I C A T I O N S
Gravity drain model
I N S TA L L A T I O N S P E C I F I C A T I O N S
Pump model
11
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
Flat Head
Screws
I N S TA L L AT I O N
L E V E L I N G
1)
Adjust the levelers close to desired height.
ove the bin into its final position.
2)M
3)
Level the ice machine to assure that the bin
door closes and seals properly. Use a level
on top of the bin. Turn the base of each foot
as necessary to level the bin. Refer to the
illustration below.
S E C U R E T H E I C E M A C H I N E
To secure the ice machine, install two
1
#8 x
/2" flat head screws through each hinge.
Refer to the illustration below.
S I D E P A N E L S
With the Sub-Zero ice machine, you must
securely fasten the side panels to the adjacent
cabinets and floor.
Panels should be fastened to the floor and walls
using ’L’ brackets (hardware not provided). To
help you move the unit into place, rout out an
area in the floor so the ‘L’ bracket will sit flush
with the floor level. Brackets and screws are
provided for mounting the unit to adjoining
cabinets and side panels.
R E V E R S E T H E D O O R S W I N G
The hinged side of the door may be reversed
to the other side if desired.
The Sub-Zero ice machine is shipped with the
door hinged at the right. The door and hinges
re designed for placing the hinges on either
a
the right or the left side of the unit. Moving the
hinges to the left in the pre-drilled holes,
allows the door to pivot from the left side.
Refer to the illustrations below.
IMPORTANT NOTE:
The plastic molding
which covers the top area of the door,
packaged with the ice machine, is required for
this procedure.
1)
To begin, remove the four screws that
secure the door hinges to the ice machine.
Refer to the illustration below.
NOTE:
Remove the shim located between
the cabinet and bottom hinge, this shim
will transfer to the left side bottom hinge.
2)
Remove the hinges from the door by
removing the four screws (two each hinge)
that secure the hinges to the door. Refer to
the illustration below.
Leg leveler
12
Step 1
Securing the ice machine Remove door Remove hinges and plastic
trim piece
Step 2
Step 3
Step 2
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
N S TA L L AT I O N
I
emove the upper plastic trim piece (right
3)R
hand configured) from the door by removing
the two screws that secure it to the door.
hen replace it with left hand trim piece.
T
Refer to the illustration on page 12.
4)
Transfer the hinges to the left side of the
door and re-attach. The upper hinge will
need to become the lower hinge and the
lower hinge will now need to become the
upper. Refer to the illustration below.
5)
Remove the top ice machine cover by
removing the two screws along the back of
the unit. Refer to the illustration below.
emove four screws from the front top rail.
6)R
Refer to the illustration below.
7)
Pivot top rail end for end to expose the two
left hand top hinge screw holes and reinstall.
8)
Remove 2 screws from bottom trim plate
and slide to cover right hand hinge
mounting screw holes and expose left
hand hinge mounting screw holes. Refer to
illustration below.
9)
Install the door using the left-hand door
mounting holes. Install shim removed in
step 1 between the hinge and cabinet.
10)
Check the operation of the door by opening.
Step 6
Step 4
Transfer hinges and reattach Remove top cover Remove front top rail Slide bottom trim plate
Step 5
Step 8
13
Flush with Top and Side
of Panel
A N E L
P
D E S I G N
Additional panel
design information
can be found in
the Sub-Zero
design guide.
Check our website
at subzero.com.
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
N S TA L L AT I O N
I
O O R P A N E L I N S T A L L A T I O N
D
You should be sure of the door panel size and
placement before proceeding with the installation. If you have questions, contact your
Sub-Zero dealer or cabinet supplier. Instructions regarding sizing of the door panel are
provided in the Sub-Zero design guide.
For door handle hardware, a D-style pull
centered on the edge opposite the door hinge
side is recommended. Screw heads may have
to be countersunk to ensure that the hardware
does not interfere with the panel fitting flush
with the unit door.
D O O R P A N E L D I M E N S I O N S
Door Panel Width –1/8" (3) reveal 15" (381)
1
Door Panel Height –
/8" (3) reveal
4" (102) toe space 303/8" (772)
Door Panel Thickness
5
/8" (16) min
Door Panel Weight 15 lbs (6.8 kg) max
1
Dimensions may vary
+_
/8" (3).
emove the handle side bracket attached to
R
the front of the door and set aside.
Place the door panel lying face down on a
protected surface to ensure the front is not
scratched or damaged.
Position the template provided flush with the
upper edge of the door. Be sure you are
following the exact location for the RH or LH
door position. Refer to the illustration below.
IMPORTANT NOTE:
Remember you are
viewing the door panel from the back side in
the illustration. The overall size of the panel
shown is the minimum size necessary to cover
the door of the unit. The exact measurements
of your door panel may vary depending on the
particular installation you are following.
Once you have located the proper position for
the hardware, mark the holes, remove
template, and drill pilot holes for mounting of
the hardware. We recommend starting the first
few holes, positioning the hardware, drilling
remaining pilot holes, and securing the
mounting brackets with the #8 x
1
/2" screws.
Refer to the illustrations below.
14
Template position
Right-hand door panel
Left-hand door panel
Door Stop Pin
Knock-Out
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
N S TA L L AT I O N
I
0 - D E G R E E D O O R S TO P
9
Exercise caution when drilling holes for
mounting hardware. This is especially
critical with inset panels.
nstall the door panel by engaging the tabbed
I
bracket to the door first and then sliding the
hinge side hardware over the positioning
screws. You will have a
1
/4" inch adjustment,
up and down, side to side, with this hardware.
Once you have the door in place, attach the
remaining #8 x
1
/2" screws to the hinge side
mounting bracket and install decorative caps.
If the reveal on the hinge side of the door
panel is less than
a square corner, severe finger pinching or
damage to the unit may occur.
1
/4", and the panel has
The Sub-Zero ice machine has a 90-degree
door stop. Follow these steps for installation:
1)
Open the door approximately 80 degrees.
2)
Insert the stop pin into the bottom door
hinge (pin enters from the top). The pin
must be inserted until the head has made
contact with the hinge body. Refer to the
illustration below.
3)
Insert the stop pin into the top door hinge
(pin enters from the bottom).
4)
Check for proper operation.
H I N G E C O V E R I N S T A L L AT I O N
IMPORTANT NOTE:
Install the hinge covers
after installation of the ice machine is
complete. The 90-degree door stop must be
installed prior to installing the hinge covers.
1)
Remove the backing paper of the adhesive
pads and bond to the hinge.
2)
Install center covers (magnets will secure
these covers). Refer to the illustration
below.
90-degree door stop
Dimensions in parentheses are in
millimeters unless otherwise specified.
Hinge cover installation
IMPORTANT NOTE:
Hinges must be free of
dirt or grease before applying covers.
IMPORTANT NOTE:
It will be necessary to
remove the knock-out in the hinge cover when
the 90-degree door stop is used.
15
S U B - Z E RO I C E M A C H I N E I N S T A L L AT I O N
I N S TA L L AT I O N C H E C K L I S T
O N T A C T
C
I N F O R M AT I O N
Sub-Zero
customer service:
800-222-7820
Website:
subzero.com
IMPORTANT NOTE:
To ensure a safe and
proper installation, the following checklist
should be completed by the installer to ensure
that no part of the installation has been
overlooked.
Any questions or problems about the installation should be directed to your Sub-Zero
dealer or Sub-Zero customer service at
800-222-7820. You can also visit our website
at subzero.com.
Check to see if the unit is operating before
you install. If not, is the unit plugged in? Is
the water turned on?
If applicable, is the door panel installed
properly?
Have any installation or service problems
been noted on the product registration
card? Instruct the owner to register the
product.
Is the ice machine level?
Has all of the internal packing been
removed?
Has the ice machine been installed where
the incoming water temperature will remain
in the range of 50–80°F (10–27°C)?
Is the ice machine drain line routed to an
open site drain for gravity drains and per
instructions for pump units?
Has the owner /operator been instructed
regarding maintenance and the use of
cleaner and sanitizer?
Has the ice machine and bin been sanitized?
Have the water and drain connections been
examined for leaks?
NOTE:
If air temperature is less than 60°F
(16°C), water temperature must be equal to or
greater than 50°F (10°C).
If you are storing or disposing of your old
refrigerator, freezer or ice machine please
do it safely. Remove the doors or tightly
secure the doors closed. Child entrapment accidents can be tragic.
Have all of the electrical and water connections been made?
Has the supply voltage been tested and
verified against the information on the
rating plate?
Is there proper clearance in front of the
kickplate for air circulation?
Has the ice machine been installed where
ambient temperatures will remain in the
range of 50–100°F (10–38°C) for models
UC-15I and UC-15IP, and 50–110°F (10–43°C)
for models UC-15IO and UC-15IPO?
16
S U B - Z E RO I C E M A C H I N E F E AT U R E S
C E M A C H I N E F E A T U R E S
I
ndercounter ice machine
U
Models UC-15I and UC-15IO have a gravity
drain, while Models UC-15IP and UC-15IPO
have a built-in pump to allow greater installation flexibility.
24" (610) depth design for a complete
integrated look
Door accepts custom panels
Automatic ice maker provides high-quality,
clear ice
Ice storage bin capacity of up to 25 lbs
(11 kg)
utomatic defrost
A
Reversible door swing
Front venting with removable kickplate
allows unit to be serviced from the front
Solid core door with gasket and door closer
L approved for US and Canada
U
Two, five and twelve year residential
warranty – exclusions apply, see warranty
at the end of this guide
A R R A N T Y
W
Sub-Zero products
are covered by a
two, five and
twelve year residential warranty
(exclusions apply).
See warranty
details at the end
of this guide.
M O D E L S U C - 1 5 I , U C - 1 5 I P, U C - 1 5 I O & U C - 1 5 I P O
Ice Machine
Control panel
Water shutters
Water reservoir
Large capacity
ice storage bin
Water filter
Kickplate Rating plate
Reversible door hinge
Bin light
Ice scoop
Gasket
Dimensions in parentheses are in
millimeters unless otherwise specified.
17
S U B - Z E RO I C E M A C H I N E O P E R AT I O N
B E F O R E STA RT I N G T H E I C E M A C H I N E
S A N I T I Z E
It is important to clean and sanitize the ice
machine prior to use to ensure optimum ice
quality.
To ensure proper operation, follow the Opera-
ional Checks on pages 20–22. Starting the ice
t
machine and completing the Operational
Checks are the responsibilities of the
owner/operator.
Adjustments and maintenance procedures
outlined in this manual are not covered by the
warranty.
Do not operate equipment that has been
misused, abused, neglected, damaged, or
ltered /modified from that of original
a
manufactured specifications.
Do not store food or beverage in the ice
achine.
m
18
S U B - Z E RO I C E M A C H I N E O P E R AT I O N
C O N T R O L PA N E L
F U N C T I O N S
POWER Button (Green)
ressing thePOWERbutton once will activate
P
the ice machine and green
Pressing the
e-activate the ice machine.
d
POWER
POWER
light.
button a second time will
Automatic Ice Making Light (Blue)
The
ICE
light is illuminated when the ice
machine is in the ice making position. The light
is off when the ice machine is in the clean
cycle.
Delay Start
Pressing the
DELAY
button will initiate a delay
cycle. The ice machine will not run until the
delay time expires.
Pressing the button once will illuminate the
2
hour light and initiate a two hour delay
period.
Pressing the button a second time will illuminate the4hour light and initiate a four
hour delay period.
CLEAN Button (Green)
Pressing the
cycle and de-activate the
CLEAN
button will initiate a clean
ICE
light. The
CLEAN
light will flash during the clean cycle to
indicate the proper time to add ice machine
cleaner or sanitizer.
Replace Filter (Red)
When the ice machine completes 8000
freeze/harvest cycles the light will illuminate to
indicate the filter needs replacement. Depressing the
CLEAN
button for 6 seconds will reset
the counter and light.
Pressing the button a third time will illuminate the
8
hour light and initiate an eight
hour delay period.
Pressing the button a fourth time will cancel
the delay cycle.
I C E M A C H I N E C O N T RO L P A N E L
19
S U B - Z E RO I C E M A C H I N E O P E R AT I O N
S E Q U E N C E O F O P E R AT I O N
Depending on ambient conditions and cold
water supply temperature, the ice making
process will take approximately 30 minutes.
1) Initial Start-Up or Start-Up After
Automatic Shut-Off — Water Fill
Before the compressor starts, the water inlet
valve will purge old water from the system for
about 3 minutes.
2) Refrigeration System Start-Up
The compressor starts after the Water Fill cycle
and remains on throughout the Freeze and
Harvest cycles. The condenser fan motor starts
and runs throughout the Freeze cycle.
3) Freeze
The water pump sprays water into the inverted
cups.
The water freezes layer by layer, until an ice
cube forms in each cup. The control system
will adjust the length of the Freeze cycle to
conditions.
4) Harvest
The water pump shuts off and the water inlet
valve starts up to assist harvest and refill the
water sump.
O P E R AT I O N A L C H E C K S
Sub-Zero ice machines are factory-operated
and adjusted before shipment. Normally, new
installations do not require any adjustment.
To ensure proper operation, always follow the
Operational Checks:
when starting the ice machine for the first
time
after a prolonged out of service period
after cleaning and sanitizing
NOTE:
Routine adjustments and maintenance
procedures are not covered by the warranty.
W A T E R L E V E L
The ice machine maintains the correct water
level. The water level is not adjustable.
B I N T H E R M O S T A T A D J U S T M E N T
The bin thermostat stops the ice machine
when the bin is full. Turn the thermostat to the
left to decrease the level of ice in bin or to the
right to increase the level of ice in bin.
20
The evaporator is warmed, allowing the cubes
to release from the evaporator and drop into
the storage bin. The control system will adjust
the length of the Harvest cycle to conditions
and regulate whether the condenser fan will
run.
At the end of the Harvest cycle, the ice
machine will start another Freeze cycle
(Step 3).
5) Automatic Shut-Off
The level of ice in the storage bin controls the
ice machine shut-off. When the bin is full, ice
will contact the bin thermostat bulb holder.
The bin thermostat bulb cools, which stops the
ice machine.
The ice machine remains off until ice no longer
contacts the bin thermostat bulb holder and
the thermostat bulb warms up. The increase in
temperature will restart the ice machine
(Step 1).
S U B - Z E RO I C E M A C H I N E O P E R AT I O N
P E R AT I O N A L C H E C K S
O
E S T I N G A N D A D J U S T I N G T H E
T
B I N T H E R M O S T A T
The bin thermostat stops the ice machine
when the bin is full. It is preset for normal
ambient temperatures and adjustments are
usually not required.
The thermostat is functioning correctly if,
when three ice cubes are placed on the thermostat tube for 5 minutes, the ice machine
stops. The ice machine should restart 5
minutes after the cubes are removed.
f the ice machine stops before the bin is full or
I
runs after the bin is full, ambient temperatures
are probably high or low and the bin thermo-
tat can be adjusted as follows:
s
Power is supplied to ice machine during
this procedure. Avoid contact with the
fan blade and the electrical connections.
1)
To access the thermostat, remove the four
screws attaching the kickplate and tilt
forward to remove.
2)
Turn the thermostat to the left to decrease
the level of ice before automatic shut-off.
Turn to the right to increase the level of ice
before automatic shut-off.
Bin
thermostat
tube
3)
Reassemble the kickplate.
Bin thermostat
Bin thermostat tube Bin thermostat
21
S U B - Z E RO I C E M A C H I N E O P E R AT I O N
O P E R AT I O N A L C H E C K S
C U B E W E I G H T A D J U S T M E N T
The cube weight can be increased from the
factory setting by adjusting the finish time.
Additional finishing time check:
Press and hold the
1)
POWER
button for 5
seconds.
2)
Count the flashes on the
ICE
light.
The light will flash once for each additional
minute of freeze cycle time.
Adjusting finishing time:
Adjust in 1 minute increments and allow the
ice machine to run several freeze /harvest
cycles, then inspect the ice cubes. If a heavier
cube weight is desired add another minute of
freeze time and repeat the process.
1)
Press and hold the
2)
Press and release the
POWER
CLEAN
button.
button once
for each additional minute of freeze cycle
time desired.
3)
Five minutes is the maximum additional
freeze time that can be added. Pressing the
CLEAN
button 6 times will reset the finish-
ing time to zero additional minutes.
22
Cube weight increases or decreases
depending on the amount of dimple
in the cube
S U B - Z E RO I C E M A C H I N E C A R E
L E A N I N G
C
ou are responsible for maintaining the ice
Y
machine in accordance with the instructions in
this manual. Maintenance procedures are not
overed by the warranty.
c
If you do not understand the procedures
or the safety precautions that must be
followed, call your local Sub-Zero authorized service center to perform the maintenance procedures for you.
We recommend that you perform the following
maintenance procedures a minimum of once
every six months to ensure reliable, troublefree operation and maximum ice production.
o ensure efficient operation, Sub-Zero recom-
T
mends an annual cleaning performed by a
qualified service company. The ice machine
ill require disassembly, cleaning and sanitiza-
w
tion. For the name and number of an authorized service center in your area check the
ontact and support section of our website or
c
call 800-222-7820.
Basic cleaning and maintenance of your ice
machine, will increase its reliability, increase
performance, and help save on water and
power consumption. Ice production will be
maintained and unwanted repairs due to maintenance issues will be minimized.
C L E A N I N G S C H E D U L E
After prolonged
Maintenance Weekly Semi-annual shutdown At start-up
Clean cabinet exterior
Sanitize ice bin
Replace water filter*
Clean condenser coil
Check ice quality
*Poor water quality may require more frequent cleaning, sanitizing and water filter replacements.
23
S U B - Z E RO I C E M A C H I N E C A R E
E X T E R I O R C L E A N I N G
S T A I N L E S S S T E E L E X T E R I O R
To clean the exterior of a stainless steel model,
use a soft, nonabrasive stainless steel cleaner
like Signature polish and apply with a soft
100% lint-free cloth. Signature polish is available from Signature Limited Laboratory,
P. O. Box 13436, Dayton, Ohio 45413, or call
877-376-5474.
To bring out the natural luster of the stainless
steel, lightly wipe the surface with a waterdampened microfiber cloth followed by a dry
polishing chamois. All work should follow the
grain direction of the finish. Better results are
obtained by keeping the cloth in continuous
contact with the stainless steel.
C L E A N I N G T H E C O N D E N S E R
Disconnect electric power to the ice
machine at the electric service switches
efore cleaning the condenser.
b
dirty condenser restricts airflow, resulting in
A
excessively high operating temperatures. This
reduces ice production and shortens component life. Clean the condenser at least every six
months. Follow the steps below.
1)
Remove the four screws attaching the kickplate and tilt forward. Clean kickplate
openings before replacing.
2)
Clean the outside of the condenser with a
soft brush or a vacuum with a brush attachment. Clean from top to bottom, not side to
side. Be careful not to bend the condenser
fins.
3)
Shine a flashlight through the condenser to
check for dirt between the fins. If dirt or
grease remains between the fins or the
condenser fins are bent or flattened, consult
your service representative.
24
S U B - Z E RO I C E M A C H I N E C A R E
I N T E R I O R C L E A N I N G
Perform an in place cleaning/sanitizing procedure monthly and a cleaning/sanitizing procedure every 6 months for efficient operation. If
the ice machine requires more frequent
cleaning and sanitizing, consult a qualified
service company to test the water quality and
recommend appropriate water treatment. An
extremely dirty ice machine must be taken
apart for cleaning and sanitizing.
Damage to the ice machine evaporator
caused by incorrect chemical usage is not
covered by the warranty. Use only
Sub-Zero approved ice machine cleaner
(7013400) and sanitizer (7013401) only.
I N P L A C E C L E A N I N G / S A N I T I Z I N G
This procedure allows semi-annual in place
cleaning of all surfaces that come in contact
with the water system.
IMPORTANT NOTE:
Contact qualified service
personnel for disassembly.
The quality of your potable water supply may
require more frequent cleaning intervals.
Use ice machine cleaner to remove lime scale
or other mineral deposits. Ice machine sanitizer disinfects and removes algae and slime.
NOTE:
All ice must be removed from the bin.
1)
Prepare 4 oz (118 ml) of undiluted ice
machine cleaner (7013400 only) in a
container that will fit easily under the lifted
water shutters. Refer to page 17 to identify
the water shutters.
2)
Press the
CLEAN
button. The ice machine
will initiate a 2 minute harvest to remove
any remaining ice from the evaporator.
3)
Remove all ice from the bin.
4)
Wait 3 minutes until the
CLEAN
light
flashes, then add the prepared cleaner by
lifting the water shutters and pouring
directly into the spray area.
5)
The ice machine will automatically time out
a ten minute cleaning cycle, followed by
eight rinse cycles, and stop. The
CLEAN
light will turn off to indicate the clean cycle
is complete. This entire cycle lasts approximately 30 minutes.
6)
Prepare 1 tablespoon (15 ml) of undiluted
ice machine sanitizer (7013401 only) in a
container that will fit into the same area.
7)
Press the
until the
CLEAN
CLEAN
button. Wait 3 minutes
light flashes, then add the
prepared sanitizer by lifting the water
shutters and pouring directly into the spray
area. The ice machine will automatically
time out a ten minute sanitizing cycle,
followed by eight rinse cycles, and stop.
The
CLEAN
light will turn off to indicate the
sanitizing cycle is complete. This entire
cycle lasts approximately 30 minutes.
Follow all labels and warnings on cleaner
and sanitizer bottles.
Dimensions in parentheses are in
millimeters unless otherwise specified.
NOTE:
The ice machine will automatically
continue from the previous point before the
clean cycle was initiated.
a)
If the ice machine was in the ice making
cycle, the control board will start ice
making again.
b)
If the ice machine was in the off cycle,
the control board will turn off.
25
S U B - Z E RO I C E M A C H I N E C A R E
AT E R F I LT E R R E P L AC E M E N T
W
o replace the water filter incoming water does
T
not need to be turned off. The unit is equipped
with an auto bypass feature which bypasses
he filter when removed.
t
1)
Turn the filter1/4 turn counter clockwise and
it will pop out.
2)
Reverse the process to re-install.
IMPORTANT NOTE:
Poor water quality may
require more frequent cleaning, sanitizing and
water filter replacement.
26
Water filter replacement
S U B - Z E RO I C E M A C H I N E C A R E
C E M A C H I N E M A I N T E N A N C E
I
E M O V A L F R O M S E R V I C E , L O N G T E R M
R
S T O R AG E A N D W I N T E R I Z AT I O N
Special precautions must be taken if the ice
machine is to be removed from service for an
extended period of time or exposed to ambient
temperatures of 32°F (0°C) or below.
If water is allowed to remain in the ice
machine in freezing temperatures, severe
damage to some components could
result. Damage of this nature is not
covered by the warranty.
ollow the procedure below.
F
1)
Perform a cleaning and sanitizing procedure
to prevent mildew growth.
2)
Disconnect the electric power at the circuit
breaker or the electric service switch.
3)
Turn off the water supply.
4)
Remove the water from the water reservoir.
5)
Disconnect and drain the incoming icemaking water line at the rear of the ice
machine.
6)
Disconnect vinyl hose from water pump
and allow to drain.
7)
Make sure water is not trapped in any of
the water or drain lines. Compressed air
can be used to blow out the lines.
8)
Use a spray bottle and a solution of 1 tablespoon (15 ml) sanitizer to 1 gal (4 L) water
and spray all interior surfaces. Do not rinse,
allow to air dry.
9)
Block the door partially open to provide air
exchange and prevent mildew growth.
Dimensions in parentheses are in
millimeters unless otherwise specified.
27
S U B - Z E RO T R O U B L E S H O OT I N G G U I D E
T R O U B L E S H O OT I N G G U I D E
P R O B L E M P O S S I B L E C A U S E P O S S I B L E S O L U T I O N
E R V I C E
S
C E N T E R
Contact your
Sub-Zero dealer or
check the Locator
section of our
website,
subzero.com, for
the authorized
service center
nearest you.
Ice machine will
not run
Ice machine runs and
no ice is produced
No electrical power to the Replace the fuse, reset the breaker,
ice machine turn on the main switch or plug in
ice machine.
POWER
button has not been Refer to page 19 and activate the
depressed ice machine.
Bin thermostat incorrectly Adjust bin thermostat, refer to
adjusted page 21.
Drain pump safety switch Verify line is not kinked or crimped
is open then call for service.
No water to ice machine Correct water supply.
Incorrect incoming water pressure Water pressure must be 20–80 psi
(1.4 bar–5.5 bar).
Spray nozzles blocked with Clean and sanitize the ice machine,
mineral buildup refer to pages 23–25.
Ambient temperature is too high Ambient temperature must be
or low between 50–100°F (10–38°C) for
models UC-15I and UC-15IP, and
between 50–110°F (10–43°C) for
models UC-15IO and UC-15IPO.
Water filter is clogged Complete semi-annual maintenance,
refer page 23.
28
S U B - Z E RO T R O U B L E S H O OT I N G G U I D E
T R O U B L E S H O OT I N G G U I D E
P R O B L E M P O S S I B L E C A U S E P O S S I B L E S O L U T I O N
Freeze cycle is long,
low ice production
Ice quality is poor,
cubes are shallow,
incomplete or white
Water temperature is too high Connect a cold water supply, verify
check valves in faucets and other
equipment are functioning correctly.
Dirty condenser Clean condenser, see page 24.
High air temperature entering Air temperature must not exceed
condenser 100°F (38°C) for models UC-15I and
UC-15IP, and 110°F (43°C) for models
UC-15IO and UC-15IPO.
Water filtration is poor Replace the filter.
Water inlet valve stuck open Turn off ice machine. If water
or leaking continues to enter ice machine, the
water inlet valve must be replaced.
Call for service.
Water inlet valve is not working Water inlet valve must be replaced.
Call for service.
Refrigeration problem Call for service.
Kickplate is obstructed Remove obstruction.
Ice machine is dirty Clean and sanitize the ice machine,
see pages 23–25.
Water filtration is poor Replace the filter.
Water softener is working Repair the water softener.
improperly (if applicable)
Poor incoming water quality Contact a qualified service company
to test the quality of the incoming
water and make appropriate filter
recommendations.
Dimensions in parentheses are in
millimeters unless otherwise specified.
29
S E RV I C E I N F O R M AT I O N
S E RV I C E I N F O R M AT I O N
O N T A C T
C
I N F O R M AT I O N
Sub-Zero
customer service:
800-222-7820
Website:
subzero.com
If you do need service, be sure to have the
model and serial number of your unit when
you call. You’ll find these numbers on the
rating plate. Refer to the illustration on page 4.
For warranty purposes, you will also need the
date of installation and the name of your SubZero dealer. Record this information below for
future reference.
Model Number
Serial Number
Installation Date
Sub-Zero Authorized Service Center and Phone
Sub-Zero Dealer and Phone
B E F O R E C A L L I N G F O R S E RV I C E
P R O D U C T R E G I S T R A T I O N
Register your new Sub-Zero today so that we
may ensure your satisfaction. You may register
by one of the following options:
1)
Mail in the completed Sub-Zero product
egistration card.
r
2)
Register online at
3)
Register by phone by calling the Sub-Zero
subzero.com
.
customer service department at
800-222-7820
.
The model and serial numbers of your unit
are printed on the enclosed Sub-Zero product
registration card. If you provide us with your
e-mail address, we will send you exciting new
product updates and recipes as they become
available, along with information on special
events.
Before calling a Sub-Zero authorized service
center, refer to the Troubleshooting Guide on
pages 28–29. Check the household fuse or
circuit breaker to see if it has been blown or
tripped and that the electrical connection to
the appliance has not been disconnected.
A power outage may also have caused a
disruption in service.
The information and images in this book are the
copyright property of Sub-Zero, Inc. Neither this
book nor any information or images contained
herein may be copied or used in whole or in part
without the express written permission of
Sub-Zero, Inc.
©Sub-Zero, Inc. all rights reserved.
30
Sub-Zero Products Limited Warranty
R
ESIDENTIAL USE ONLY
FULL FIVE YEAR SEALED SYSTEM WARRANTY
LIMITED SIXTH THROUGH TWELFTH YEAR WARRANTY ON THE SEALED SYSTEM
FULL TWO YEAR WARRANTY ON TOTAL PRODUCT*
FULL FIVE YEAR SEALED SYSTEM WARRANTY
For five years from the date of original installation, your Sub-Zero warranty covers all parts and labor to repair or
replace any components that prove to be defective in materials or workmanship in the sealed system. The sealed
s
ystem consists of the compressor, condenser, evaporator, drier and all connecting tubing.
FULL TWO YEAR WARRANTY*
For two years from the date of original installation, your Sub-Zero warranty covers all parts and labor to repair or
r
eplace any part of the product, that proves to be defective in materials or workmanship.
LIMITED SIXTH THROUGH TWELFTH YEAR SEALED SYSTEM WARRANTY
From the 6th through the 12th year from the date of original installation, your Sub-Zero warranty covers all parts
that prove to be defective in materials or workmanship in the sealed system (parts only). The sealed system
consists of the compressor, condenser, evaporator, drier and all connecting tubing.
TERMS APPLICABLE TO EACH WARRANTY
All service provided by Sub-Zero under the above warranty must be performed by an authorized Sub-Zero service
center, unless otherwise specified by Sub-Zero. Service will be provided in the home during the normal business
hours. This warranty applies only to products installed for normal residential use. Details regarding a non-residential warranty are available upon request.
The warranty applies only to products installed in any one of the fifty states of the United States, the District of
Columbia or the ten provinces of Canada. This warranty does not cover any parts or labor to correct any defect
caused by negligence, accident or improper use, maintenance, installation, service or repair, including but not
limited to improper removal and reinstallation (whether in the unit or at a remote location) of the condensing unit.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT SUB-ZERO WILL
PROVIDE, EITHER UNDER THESE WARRANTIES OR UNDER ANY WARRANTY ARISING BY OPERATION OF
LAW. SUB-ZERO WILL NOT BE RESPONSIBLE FOR ANY CONSEQUENTIAL OR IN CIDENTAL DAMAGES
ARISING FROM THE BREACH OF THESE WARRANTIES OR ANY OTHER WARRANTIES, WHETHER EXPRESS,
IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other
legal rights, which vary from state to state.
To receive parts and/or service and the name of the Sub-Zero authorized service center nearest you, contact your
Sub-Zero dealer, distributor or the Sub-Zero Customer Service Department, P.O. Box 44130, Madison Wisconsin, 53744-4130; check the Contact & Support section of our website, subzero.com, or call 800-222-7820.
*Stainless Steel (classic, platinum and carbon) doors, panels, product frames and stainless interior surfaces are
covered by a limited 60 day parts and labor warranty for cosmetic defects.
*Replacement water filter and air purification cartridges are not covered by the product warranty.
31
S U B - Z E R O , I N C . P. O. B O X
4 4 1 3 0
M A D I S O N , W I
5 3 7 4 4 - 4 1 3 0 80 0 - 2 2 2 - 7 8 2 0
S U B Z E R O . C O M
7 0 1 2 2 0 6 R E V- B 0 0 0 0 0 2 6 2 8
7 / 2 0 0 9
Loading...
