Sub-Zero QRDO30 User Manual

Model DO30F
Framed (left)

Model DO30U

Unframed

(right)

30" Built-In Double Oven

Electronic controls hide behind a

stainless steel panel. A motor quietly

rotates the control panel into position.

Both ovens of the Wolf 30" built-in

double oven feature the Wolf dual

convection system. It delivers even
temperature and airflow throughout
the oven. Two fans and four heating

elements operate either simultaneously

or in sequence, depending on which

one of the eight different cooking

modes you choose.

Specifications

Overall Dimensions 297/8" W x 50" H x 24" D

Open Oven Door Clearance 203/4"

Usable Oven Interior Capacity*
(per oven) 2.7 cu ft

Oven Interior Dimensions
(per oven) 211/2"W x 161/2"H x 163/8"D

Recommended Cabinet Width 33"

Opening Dimensions 281/2"W x 495/8"H

Minimum Cabinet Depth 24"

Minimum Base Support 400 lbs

Electrical Requirements 240/208 V AC

60 Hz, 50 amp dedicated circuit

Conduit 5' flexible 4-wire

Electrical Rating 8.9 kW at 240 V

6.7 kW at 208 V

Total Amps 37

*Oven capacity is calculated using new AHAM
standards (AHAM OV-1-2005).

Accessories

Bake stone accessory, includes stone,
rack and peel

Two-piece broiler pan and temperature probe

Set of three 30" oven racks

Dehydration racks with door stop

Accessories are available through your Wolf dealer.
To obtain local dealer information, visit the Locator
section of our website, wolfappliance.com.

Product Notes

With the 30" built-in double oven, you have
your choice of the framed or unframed door
style. The framed door style comes in the
classic stainless steel finish only, while the
unframed door style is available in classic,
platinum and carbon stainless steel finishes.

Rotating Glass Touch Control Panel

Classic CarbonPlatinum

Features

Dual convection logic control system

Eight cooking modes in each oven

Rotating glass touch control panel

Cobalt blue porcelain oven interiors

Three removable racks with full-extension
bottom rack and removable six-level rack
guide in each oven

Large viewing triple-pane windows

Dual interior halogen lighting

Hidden bake element and recessed broil
element in each oven

Temperature probe and receptacle in
each oven

Proof feature and dehydration feature
(accessory required) in each oven

Self-clean, delayed start and Sabbath
feature in each oven

Door hinges with hydraulic damper

This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

Model Options DO30F/S DO30U/S DO30U/P DO30U/B

Door Style Framed Unframed Unframed Unframed

Stainless Steel Finish Classic Classic Platinum Carbon

Shipping Weight (lbs) 466 466 466 466

Model DO30F/S shown—framed door style with classic stainless steel finish.
