Specifications

Exterior Finish Classic Stainless Steel

Bottom of Hood to Countertop 24" to 30"

Duct Size 8" round

Discharge Vertical

Transition 8" to 10" round

Electrical Requirements 110/120 V AC

60 Hz, 15 amp dedicated circuit

Blower Options

450 CFM Internal Blower

600 or 1100 CFM In-Line Blower

600, 900, 1200 or 1500 CFM Remote
Blower

Cooktop wall hoods are sold as a shell only, an
internal, in-line or remote blower will be required.
For additional information on blowers, visit our
website, wolfappliance.com.

Accessories

36" classic stainless steel wall shield

Flue extension to accommodate 10'
ceilings

8" to 10" round transition

Accessories are available through your Wolf dealer.
To obtain local dealer information, visit the Locator
section of our website, wolfappliance.com.

Product Notes

Cooktop wall ventilation hoods are available in
the classic stainless steel finish. They are sold
as a shell only, internal, in-line and remote
blower options are available.

The telescopic chimney flue fits 8' to 9'
ceilings and a flue extension to accommodate
10' ceilings is available as a sales accessory.
A transition with backdraft damper is included
with the hood.

IMPORTANT NOTE: Wolf cooktop wall hoods
are recommended for use with Wolf electric
and gas cooktops and integrated modules.
For Wolf dual fuel ranges, gas ranges, sealed
burner rangetops and gas rangetops, a Pro
ventilation hood should be used.

Model Options CTWH30

Overall Dimensions 30" W x 21" D

Overall Height (chimney collapsed/ full extension) 301/2" / 481/2"

Shipping Weight (lbs) 85

Features

Heavy-duty stainless steel seamless
construction with classic finish

Front mounted controls with LED indicator

Three-speed blower control

Filter clean timer lets you know when the
filter needs cleaning

Delay-off mode automatically turns unit off

Sealed halogen lighting with three settings

Stainless steel filter cover with dishwasher­safe aluminum mesh filter

Heat sentry feature automatically turns unit
on when heat is sensed and automatically
adjusts blower speed

Model CTWH30 shown above Model CT30E/S
electric cooktop and Model SO30F/S built-in oven.

Model CTWH30

Cooktop Wall Hood

Powerful multi-speed blowers draw

odors and smoke into the five-layer

mesh filter. Filters remove easily for

cleaning. The sculpted classic stainless

steel hood not only provides the power

you expect from Wolf, but also the

beauty you have come to appreciate as

well. This wall mount cooktop ventilation

hood has a telescopic chimney flue

that adjusts to reach the ceiling with

a finished look.

Halogen LightingFront-Mounted Controls

Model CTWH30 Cooktop Wall Hood
