Sub-Zero QRCT36EU User Manual
Model CT36EU
36" Unframed Electric Cooktop
With Wolf’s unframed electric cooktops
there’s no stainless steel trim, just the
sophisticated, minimalist exterior subtly
patterned design to hide any unsightly
scratches. Five heating elements with
eight zones offers exceptional control of
temperature for cooking utensils of
every size. All of the heating elements
offer True Simmer along with one
element that enables you to set a
temperature for melting.
Specifications
Overall Dimensions 36" W x 4" H x 21" D
Maximum Element Power
(1) Triple-Zone 2700 W / 2200 W / 1050 W
(1) Dual-Zone 2200 W / 750 W
(3) Single-Zone 1800 W, 1500 W and 1200W
Element Outer Diameter
Triple-Zone 11
7
/8"
Dual-Zone 9
1
/8"
Single-Zone 77/8", 71/8" and 61/2"
Recommended Cabinet Width 39"
Minimum Height Clearance 4"
Minimum Cabinet Depth 223/4"
Countertop Cut-Out 343/8"W x 193/8"D
Electrical 240 V AC / 60 Hz / 50 amp
Requirements 208 V AC / 60 Hz / 40 amp
Conduit 4' flexible 3-wire
Electrical Rating 9.4 kW at 240 V AC
7.1 kW at 208 V AC
Product Notes
The 36" unframed electric cooktop can be
mounted flush with the top of the countertop
or as a frameless installation sitting on top of
the countertop surface.
IMPORTANT NOTE: Flush mount installations
are intended for granite, solid surface or stone
countertop surfaces only. Failure to use a high
heat resistant surface will result in countertop
damage if hot cooking utensils are accidentally moved off the cooking surface.
Touch Controls
Model CT36EU
Design Unframed
Shipping Weight (lbs) 60
Features
Easy-to-clean black ceramic glass surface
is resistant to scratching, staining, impact
and heat—translucent surface allows you
to see the glow of hot elements
Illuminated electronic touch controls with
graduated control lighting
Five ribbon-type radiant heating elements
with eight temperature zones
One triple-zone, one dual-zone and three
single-zone elements
True Simmer setting on all elements and
melt setting on one element
Hot surface indicators on all elements
High frequency pulsation elements
improve cooking performance and control
Temperature limiter to ensure that safe
operating temperature of ceramic glass
is never exceeded
Child safety lock key and universal off
This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Model CT36EU
Translucent Surface
Model CT36EU in flush mounted installation
