G AS R ANGETOPS
USE &CARE INFORMATION
CONTENTS
Wolf Gas Rangetops 3
Safety Instructions and Precautions 4
Wolf Gas Rangetop Features 8
Wolf Gas Rangetop Operation 10
Wolf Gas Rangetop Care 20
Wolf Service Information 22
Wolf Warranty 23
WOLF®is a registered trademark of Wolf Appliance Company, LLC
As you read this Use & Care Information,
take particular note of the CAUTION and
ARNING symbols when they appear.
W
This information is important for safe and
ficient use of the Wolf equipment.
ef
signals a situation where minor injury or
oduct damage may occur if you do not
pr
follow instructions.
states a hazard that may cause serious
injury or death if precautions are not
followed.
mation may
In addition, this Use & Car
ANT NOTE which highlights
signal an IMPOR
mation that is especially important.
infor
T
e Infor
WOLF GAS RANGETOPS
THANK YOU
Your purchase of a Wolf gas rangetop attests
to the importance you place upon the quality
nd performance of your cooking equipment.
a
We understand this importance and have
designed and built your gas rangetop with
uality materials and workmanship to give
q
you years of dependable service.
We know you are eager to start cooking, but
before you do, please take some time to read
this Use & Care Information. Whether you are
a beginning cook or an expert chef, it will be
to your benefit to familiarize yourself with the
safety practices, features, operation and care
recommendations of the Wolf gas rangetop.
If the information in this book is
not followed exactly, a fire or
explosion may result, causing
property damage, personal injury
or death.
IMPORTANT NOTE:
Installation and service must be
performed by a qualified installer,
vice agency or the gas supplier.
ser
CONTACT
INFORMATION
Wolf Customer
Service:
800-332-9513
Website:
wolfappliance.com
We appreciate your choice of a Wolf Appliance product and welcome any suggestions
or comments you may have. To share your
opinions with us, please call 800-332-9513.
Your Wolf gas rangetop is protected by a
warranty that is one of the finest in the
industry. Take a moment to read the warranty
statement on page 23 and refer to it should
service become necessary.
IMPORTANT NOTE:
plate for type of gas. The rating plate is
located under the drip pan that supports the
cooking grates, on the left inside wall of the
rangetop. The rating plate for French Top
models (except Model RT484F) is located on
the right inside wall. Refer to the illustration
on page 8. If this appliance does not correspond to your type of gas (natural or LP),
contact your Wolf dealer.
Check the product rating
Warranty service must be performed
by a Wolf authorized service center.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
A ventilation hood is recommended
for use with the Wolf gas rangetop.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your
building.
Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’
s instr
uctions.
If you cannot reach your gas
supplier
, call the fire department.
3
SAFETY INSTRUCTIONS AND PRECAUTIONS
WHAT TO DO
IMPORTANT NOTE: Read all
instructions before using this
appliance.
Read this Use & Care Information
carefully
rangetop to reduce the risk of fire,
electric shock or injury to persons.
Ensure proper installation and
servicing. This appliance must be
properly installed and grounded by
a qualified technician.
Have installer show you where the
gas supply shut-off valve is located
in your home.
to turn off the gas to the rangetop.
Before performing any service, turn
off the gas supply by closing the gas
shut-off valve and unplug the
rangetop electrical power cord from
the wall receptacle.
Keep igniters clean and dry for
proper lighting and performance for
the burners.
In the event that a burner goes out
and gas escapes,
a door. Wait at least five minutes
before using the rangetop.
Keep appliance area clear and free
from combustible material.
before using your new gas
Learn how and where
open a window or
Wear proper apparel. Never let loose
clothing or other flammable materials come in contact with the burners
while in operation. Fabric may ignite
and cause personal injury.
When deep fat frying, be certain that
the pan is large enough to accommodate the desired volume of food
without overflow caused by bubbling
of the fat. Never leave a deep fat
fryer unattended. Avoid deep fat
frying of moist or frost-covered
foods, as foods with high water
content may cause spattering or
spilling of the hot fat. Heat fat
slowly, and stir together any combinations of oils and fats prior to
applying heat. Utilize a deep fat
frying thermometer to avoid heating
the fat to temperatures above the
flash point.
Always use dry pot holders when
removing pans from the rangetop.
Wet or damp pot holders can cause
steam burns. Do not use a towel or
bulky cloth in place of pot holders.
Choose pans with easily grasped
handles
cooking. Refer to Cookware Selection on page 20.
When cooking, set burner controls
so that the flame heats only the
bottom of the pan
extend beyond the bottom of the pan.
that will stay cool while
and does not
4
WHAT TO DO
WHAT NOT TO DO
Always turn panhandles inward so
they do not extend over adjacent
work areas, burners or the edge of
the rangetop.
Always check the positions of the
control knobs
to make certain the
rangetop is off when you are
finished cooking.
Always light each burner prior to
placing a pan on the burner grate.
Also, turn the control knob to the
OFF position before removing a pan
from the burner grate.
Keep any ventilation filters clean to
avoid grease fires.
Always set pans gently onto the
grates
and center them so that they
are well balanced.
Start the ventilation hood approximately five minutes before cooking.
This establishes an air curtain and
improves the capture of vapor and
moisture.
Clean only those parts listed in this
book.
Do not repair or replace any part of
the rangetop
unless specifically
recommended in literature accompanying this appliance. All service
should be referred to a qualified
technician.
Do not obstruct the flow of air. Your
kitchen must have an adequate
supply of fresh air to ensure proper
combustion and ventilation.
Do not use aluminum foil to line any
part of the rangetop.
Never use the rangetop to warm or
heat the room.
Do not block or obstruct the holes
in the rangetop
below the control
knobs. Blocking these holes may
affect burner operation and may
result in a hazard.
When using the rangetop, do not
touch the grates, burner caps,
burner bases or any other parts in
proximity to the flame. These
components may be hot enough to
cause burns.
NEVER use this appliance as a
space heater to heat or war
oom. Doing so may r
r
carbon monoxide poisoning and
heating of the rangetop.
over
esult in
m the
5
SAFETY INSTRUCTIONS AND PRECAUTIONS
WHAT NOT TO DO
If the rangetop is near a window, do
not use long curtains as a window
treatment, as they could blow over
the rangetop and create a fire
hazard.
Do not leave children alone or
unattended
rangetop is in use. Never allow
children to sit or stand on the appliance. Do not let children play with
the rangetop.
Do not store items of interest to
children above or at the back of the
rangetop,
appliance to reach items and be
injured.
Do not use water on grease fires.
Smother the flame or use a dry
chemical or foam-type extinguisher.
Never leave the appliance
unattended when in use.
and greasy spills may smoke and/or
ignite.
Do not cover the burners and grates
with anything except properly
selected utensils. Decorative covers
should not be used.
Do not heat unopened food
containers,
and cans. Pressure buildup may
cause the container to burst and
cause injury.
in the area where the
as they could climb on the
Boilovers
such as baby food jars
Do not store flammable materials
near burners
flammable substances accumulate
on the rangetop.
Do not use abrasive or caustic
cleaners or detergents
appliance, as these may cause
permanent damage. Do not use
aerosol cleaners, as these may be
flammable or cause corrosion of
metal parts.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
Do not clean the rangetop while it is
still hot.
cloth, wait until the rangetop has
cooled sufficiently to prevent steam
burns. Also, some cleaners can
produce harmful or unpleasant
fumes if applied to hot surfaces.
Refer to Care Recommendations on
page 21.
Do not allow aluminum foil, plastic,
paper or cloth to come in contact
with a hot burner or grate. Do not
allow pans to boil dry.
or let grease or other
on this
If using a damp sponge or
6
SAFETY PRECAUTIONS
TO REDUCE THE RISK OF INJURY
TO PERSONS IN THE EVENT OF
A RANGETOP GREASE FIRE,
OBSERVE THE FOLLOWING:
Smother flames with a closefitting lid, baking sheet or other
metal tray; then turn off the gas
burner. Be careful to prevent
burns. If the flames do not go out
immediately, evacuate and call
the fire department.
Do not use water on grease fires.
Never pick up a flaming pan—
you may be burned.
USE AN EXTINGUISHER ONLY IF:
You know you have a Class ABC
extinguisher
and you already know
how to operate it.
CALIFORNIA PROPOSITION 65
Burning gas cooking fuel generates some by-products that are
on the list of substances known
to cause cancer or reproductive
harm. To minimize exposure to
these substances, always operate
this unit according to the instructions contained in this book and
provide good ventilation.
COMMONWEALTH OF
MASSACHUSETTS
Installations and repairs must be
performed by a qualified or
licensed contractor, plumber or gas
fitter,
qualified or licensed by the
state, province or region where this
appliance is being installed.
The fire is small and contained in
the area where it started.
The fire department is being called.
You can fight the fire with your back
to an exit
(NFPA Fire Safety Tips).
Use only gas shut-off valves
approved for use
ovince or r
pr
within the state,
egion wher
e this
appliance is being installed.
A flexible gas connector, when
used, must not exceed 3' (.9 m).
7
WOLF GAS RANGETOP FEATURES
GAS RANGETOP FEATURES
WOLF
WARRANTY
Wolf products are
covered by a two
and five year
residential
warranty (exclusions apply). See
warranty details
at the end of this
guide.
Natural or LP gas models
Fits standard 24" (610) deep cabinets with
zero clearance for easy installation
Classic stainless steel exterior finish
arge red control knobs with four position
L
settings and chrome bezels—optional black
knobs available
Dual brass surface burners, all with simmer
capabilities and automatic reignition at all
settings
16,000 Btu/hr (4.7 kW) burners with 500
Btu/hr (.1 kW) delivered at simmer
Optional 11" (279) infrared 16,000 Btu/hr
charbroiler (4.7 kW)
Optional 11" (279) infrared 18,000 Btu/hr
griddle (5.3 kW) or double griddle
Optional 15,000 Btu/hr (4.4 kW) French Top
Porcelain-coated cast iron top grates
Stainless steel drip tray on ball bearing
slides
igh altitude conversion kits available
H
CSA certified for US and Canada
Two and five year residential warranty
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
GAS RANGETOP
Model RT484CG 48" (1219) shown
Infrared charbroiler
(optional)
ofile stainless
o-pr
Pr
steel island trim
Dual brass
burners
Location of rating
plate inside rangetop
Pull-out drip tray
Location of the rating plate for Fr
NOTE:
models (except Model RT484F) is on the right
inside wall of the rangetop.
ench T
Infrared griddle
(optional)
op
Porcelain-coated
cast iron top grates
Large red control
knobs
Stainless steel
exterior finish
Griddle indicator
light
8
WOLF GAS RANGETOP FEATURES
GAS RANGETOP ACCESSORIES
These optional accessories are available
through your Wolf dealer. To obtain local
ealer information, visit the Locator section
d
of our website, wolfappliance.com.
1
10
/2" (267) classic stainless steel riser
Standard (two-piece) or island (three-piece)
trim in classic stainless steel
Black control knobs (red knobs come with
the rangetop)
Porcelain-coated cast iron wok grate
Porcelain-coated cast iron S-grates
Hardwood cutting board
High altitude conversion kit
VENTILATION OPTIONS
It is recommended that you operate the
Wolf gas rangetop with one of the following
ro ventilation hoods. Contact your Wolf
P
dealer for details.
Pro Wall Hood – 22" (559), 24" (610) or
7" (686) depths and 30" (762) to 66" (1676)
2
widths in classic stainless steel.
Pro Island Hood – 36" (914) to 66" (1676)
widths in classic stainless steel.
Pro Hood Liner – available in widths to
accommodate 30" (762) to 60" (1524) hood
shells.
All Pro ventilation hoods have welded seams,
sealed halogen lighting and removable, dishwasher-safe stainless steel filters.
ACCESSORIES
Optional accessories are available
through your
Wolf dealer. To
obtain local dealer
information, visit
the Locator section
of our website,
wolfappliance.com.
Dimensions in parentheses are in
millimeters unless otherwise specified.
9
WOLF GAS RANGETOP OPERATION
Center Cap
Porcelain To pOuter Burner
Ring
Igniter
Drip Pan
Center CapIgniter
Burner Base
Cross
Ring
SURFACE BURNERS
A spark electrode ignites each surface burner.
his control eliminates the need for continuous
T
open flame pilots. For added safety and
convenience, each burner is designed with an
lectronic reignition system. This feature
e
enables any burner to relight automatically in
the event it is accidentally extinguished.
Each surface burner provides a rating of 16,000
Btu/hr (4.7 kW) on
HIGH
with 500 Btu/hr
(.1 kW) delivered at simmer.
In case of a power outage, you can relight the
surface burners manually. Turn the control
knob to
HIGH
, then use a minimum 6" (152)
igniter to manually light the burner.
Manually relight each bur
Do not try to manually relight the French
Top, charbr
oiler or griddle.
ner individually
.
BURNER ASSEMBLY
fter cleaning or removing burner parts for
A
any reason, it is extremely important that you
reassemble the burners correctly. The outer
urner ring and center burner cap do not have
b
a special orientation, but must be seated flat.
Failure to position the burner parts
correctly could cause flames or gas to
escape and burn between parts, resulting
in poor combustion or damage to your
gas rangetop.
10
Upper bur
ner parts and alignment
Base burner parts and alignmentManually relighting the burner
WOLF GAS RANGETOP OPERATION
O
F
F
H
I
G
H
L
O
W
M
E
D
S
I
M
CONTROL KNOBS
The control knobs are positioned to correspond to the surface burners they regulate.
ach knob is designed to be a ”push-to-turn”
E
knob. Although this is a child-safe design,
children should never be left unattended in the
itchen when the rangetop is in use.
k
o light a surface burner,push in and turn
T
the corresponding control knob counterclockwise to
HIGH
. You will hear a clicking sound.
This is the electronic igniter. Once the burner is
lit, continue turning the knob counterclockwise
to the desired setting. There are four
settings—
SIM
HIGH,MED
(simmer). You will feel a slight detent in
(medium),
LOW
and
the knob rotation when each setting is aligned.
Never leave the gas rangetop unattended
when in use. Be cautious when cooking
food in fat or grease. It can become hot
enough to ignite.
TEMPERATURE SETTING GUIDE
SETTING USES
IM (simmer)
S
elting, holding chocolate
M
Melting butter
Heating, holding delicate sauces
Warming foods
Melting large quantities
immering sauces
S
Steaming rice
LOW Heat
Frying eggs
Heating milk, cream sauces and
soups, gravies and puddings
Panfrying
Simmering large quantities
Boiling vegetables in water
MED (medium) Heat
Sautéing
Browning
Braising
Quick frying
HIGH Heat
Boiling water
Heating broth soups, stocks
Deep fat frying (to heat oil only)
Fast boiling large quantities
Surface burner control knob
Dimensions in parentheses are in
millimeters unless other
wise specified.
11
WOLF GAS RANGETOP OPERATION
FLAME HEIGHT AND APPEARANCE
Select a flame that is just high enough to
maintain the desired cooking speed and is
ized to fit the base diameter of the pan. Refer
s
to the illustrations below. Never extend the
flame beyond the base of the pan.
The flame on natural gas should be blue with a
eeper blue core. There should be minimal
d
trace of a yellow flame. A yellow flame indicates an improper mixture of air and gas or
impurities in the gas supply to the rangetop. If
this occurs consistently, call a Wolf authorized
service center to adjust the mixture. With LP
gas, some yellow tipping to the flame is
acceptable and may not require an adjustment.
A ”popping” sound may be noticed with LP
gas when the surface burner is turned off. This
is normal.
GRATE PLACEMENT
Position the porcelain-coated, cast iron grates
with the five fingers of each grate facing
toward the front of the gas rangetop. The back
of each grate has three fingers, which face the
back. Rubber pads located under the grate
support legs rest on the burner drip pan. Refer
to the illustration below.
BEFORE USING YOUR RANGETOP
Before using for the first time, you should
clean your gas rangetop thoroughly with hot
ater and a mild detergent. Rinse and dry with
w
a soft cloth. This removes any residual oil and
grease left on the surface from the manufac-
uring process. Refer to Care Recommenda-
t
tions on page 21.
IMPORTANT NOTE:
Before using your gas
rangetop, check that the surface burners are
assembled correctly.
Griddles and French Tops need to go through a
”burn in” period to clean oils from the bottom
of these assemblies. To prevent food from
sticking and to protect the surface from
moisture, it is necessary to season the griddle
and French Top prior to use. Refer to the
following pages for specific instructions on
using the optional charbroiler, griddle and
French Top.
The use of proper cookware is very important.
Refer to Cookware Selection on page 20 for
cookware recommendations.
12
Cast Iron Gr
Placement
Inner and outer burners at HIGHInner burner at SIMMER
Grate placement
ate
WOLF GAS RANGETOP OPERATION
Wire Mesh
Screen
Blank-Off
Plate
Igniter
Stainless
Steel
Grate
INFRARED CHARBROILER
This optional feature is designed with a 16,000
Btu/hr (4.7 kW) infrared burner to give the
ighest quality and most efficient method of
h
gas grilling. The burner becomes an orangered color at the surface of the ceramic tile, and
hen it glows, it transfers an intense heat to
w
the food. This sears the outside of the food,
leaving the inside tender and juicy.
The infrared burner is designed to operate at
100% heat output. HIGH is the only setting on
the knob. For even cooking, we recommend
using the charbroiler blank-off plate when
grilling most food.
Do not use cookware on the charbroiler
grate.
BLANK-OFF PLATE
o give the charbroiler a more even heat
T
output, install the blank-off plate packaged in
a separate envelope with your gas rangetop.
3
his 2
T
x 11" (70 x 279) stainless steel plate
/4"
is placed directly on the ceramic tiles.
IMPORTANT NOTE:
Install the blank-off plate
when the charbroiler is off and is completely
cool. Be sure to remove the plastic film from
the blank-off plate before installing.
To install the blank-off plate,
remove the
stainless steel grate and wire mesh screen.
Position the blank-off plate in the middle of the
ceramic tiles and reinstall the wire mesh
screen. Make sure that the wire mesh screen
is positioned with the notch at the left rear.
Reinstall the stainless steel grate. Refer to the
illustrations below.
Use caution when placing the blank-of
plate directly onto the ceramic tiles so
they are not chipped or otherwise
damaged. Avoid any contact with the
igniter; it is fragile and can chip or break.
f
Charbroiler stainless steel grate
Dimensions in parentheses are in
millimeters unless otherwise specified.
Blank-off plate installation
13
WOLF GAS RANGETOP OPERATION
O
F
F
H
I
G
H
INFRARED CHARBROILER
CHARBROILER OPERATION
MPORTANT NOTE: The stainless steel cover
I
must be removed prior to operation of the
charbroiler.
Turn the control knob counterclockwise to
the
HIGH
setting. You will hear the clicking
sound of the igniter lighting the burner.
Preheat charbroiler for about 10 minutes
before adding the food. The ceramic tiles
will have an orange-red glow.
To turn the charbroiler off, turn the control
OFF
knob clockwise to the
To prevent flare-ups, never leave the
charbroiler during use.
position.
CHARBROILING TIPS
urn on the ventilation hood five minutes
T
prior to using the charbroiler.
If the knob is not set fully at
HIGH
, the
burner may turn blue and the automatic
igniter will begin sparking. Turn the knob
back to
HIGH
.
Always select lean meat or trim fat before
grilling. Flaming may occur when grilling
meat and poultry with excessive fat.
To minimize flare-ups when grilling chicken
breasts and thighs, remove the skin. Brush
pieces with peanut or vegetable oil to
reduce sticking to the grate.
If flare-ups occur, quickly move the food to
another place on the grate with long tongs.
Apply basting sauce halfway through
cooking time.
Use a minute timer as a reminder to turn
the food over halfway through cooking
time.
The suggested grilling times in the
Charbroiler Grilling Guide on page 15 are
approximate. Actual times depend on the
quantity, thickness and starting temperature
of the food.
14
Charbroiler control knob
WOLF GAS RANGETOP OPERATION
INFRARED CHARBROILER
CHARBROILER CARE
o keep the charbroiler looking its best, it is
T
recommended that you clean it after every use.
Charbroiler Grate
(stainless steel): When
cool, lift off and set in the sink. Pour very
hot water over the cooked-on residue.
Cover with wet dish towels and pour more
hot water over it. Allow the hot, moist
conditions to help loosen the residue.
Remove remaining food soil with a soapfilled scouring pad. Rinse and dry.
Charbroiler Frame
(stainless steel):
Remove from the gas rangetop. Soak in hot
water and dish detergent. Wash thoroughly,
scrubbing with scouring pad, if needed.
Blank-off Plate
(stainless steel): Wash with
hot water and detergent. Use a soap-filled
scouring pad to remove as much cooked-on
food soil as possible. The plate will turn a
metallic blue color due to the high heat; this
is a permanent change.
Igniter
(ceramic): Avoid contact with the
igniter; it is fragile and can chip or break.
Mesh Screen
(stainless steel): Use a wire
brush to loosen any charred food particles.
CHARBROILER GRILLING GUIDE
FOOD GRILLING TIME*
eef
B
Ground beef patties,
1
1 lb (.5 kg),
teaks,
S
/2" (13) thick 12–15 min (medium well)
1
3
–
/2"
(13–19) thick 8–9 min (rare)
/4"
10–12 min (medium)
14–16 min (well done)
Chicken
Breasts, boneless and skinless 20–23 min
easts, bone in 30–33 min
Br
Thighs, boneless and skinless 30 min
Fish
Steaks, 1/2"–3/4" (13–19) thick 10–12 min
Fresh Vegetables
Bell peppers 10–12 min
Corn on the cob, husked 15–20 min
Corn on the cob, in the husk 30–40 min
Mushrooms 6–7 min
*Grilling times are with the blank-off plate installed.
Allow the charbr
sufficiently before cleaning.
Dimensions in parentheses are in
millimeters unless otherwise specified.
oiler sur
face to cool
15
WOLF GAS RANGETOP OPERATION
INFRARED GRIDDLE
The steel griddle plate operates at 18,000
Btu/hr (5.3 kW). It is thermostatically
ontrolled, which means once the set tempera-
c
ture is reached, the heat cycles to hold that
temperature. To prevent food from sticking and
o protect the surface from moisture, it is
t
necessary to ”season” the griddle prior to use.
This seasoning process as well as general use
will change the appearance of the griddle.
SEASON THE GRIDDLE
The griddle is shipped with a protective oil,
use hot water and detergent to clean the
surface. Rinse and dry.
Turn on the ventilation hood five minutes
prior to using the griddle.
The griddle needs to go through a ”burn
in” period. Turn the griddle on at 350˚F
(175˚C) for 30 minutes to clean oils from the
bottom of the griddle. After 30 minutes,
turn the griddle off and allow it to cool.
To season, pour 1 teaspoon (5 ml) of
peanut or vegetable oil per 11" (279) griddle
in the center; spread evenly with a paper
towel, avoiding the corners. Be careful not
to apply too much oil. Excess oil will leave
a gummy residue that will have to be
removed.
GRIDDLE OPERATION
MPORTANT NOTE:The stainless steel cover
I
must be removed prior to operating the
griddle.
Turn on the ventilation hood five minutes
prior to using the griddle.
To heat the griddle,
push in the control
knob and turn counterclockwise to the
desired temperature. It is normal to hear a
clicking sound. This is the electronic
ignition lighting the burner. When the
burner is lit, the thermostat will control the
temperature.
When the griddle is preheated, the griddle
indicator light will go out. The light will
cycle on and off as the thermostat requires
more heat to maintain the set temperature.
This will allow heat to be evenly distributed
and the griddle to maintain the set
temperature.
The double griddle has two burners with
separate control knobs that act independently of each other. If only one griddle is
being used, there will be some heat transfer
to the inactive griddle.
To turn the griddle off,
knob clockwise to the
turn the control
OFF
position.
16
Push and turn the control knob to 350˚F
(175˚C). Heat until you see the first signs of
. When the
smoke. Tur
n the griddle
off
griddle has cooled and is only slightly
m, wipe off any excess oil. Let the
war
griddle cool completely.
Repeat with another teaspoon of oil. The
brown appearance will darken with use.
Be cautious when cooking food high in
fat. It can become hot enough to ignite.
WOLF GAS RANGETOP OPERATION
O
F
F
0
0
2
0
0
1
5
0
2
5
0
3
0
0
3
1
0
0
4
5
0
Griddle Drain Hole
Grease
Collection Tray
Pull-Out
Drip Tray
INFRARED GRIDDLE CARE
Using a metal spatula, scrape grease into
the grease collection tray.
When the surface has cooled, wipe it with a
aper towel to remove excess grease or oil.
p
Scrape the griddle clean. Pour
1
/2 cup (.1 L)
warm water and 1 teaspoon (5 ml) griddle
cleaner onto the griddle and scrape the
grease into the grease collection tray. Rinse
the griddle with
1
/2 cup (.1 L) warm water
and dry with paper towels.
Clean the grease collection tray on the drip
tray and drain hole after each use. Do not
allow grease to accumulate in the tray and
become a fire hazard.
To remove the grease collection tray, slide
the drip tray out, then lift out the grease
collection tray. Clean the grease collection
tray with soapy water and a clean cloth.
Refer to the illustration below.
Reapply a small amount of peanut or
vegetable oil to the griddle with a clean
cloth after each cleaning.
GRIDDLE COOKING GUIDE
TEMPERATURE FOOD
00˚F (95˚C)
2
old cooked food at serving
H
temperature
250˚F (120˚C)
350˚F (175˚C)
Eggs
French toast, pancakes, grilled
sandwiches
375˚F (190˚C)
Bacon, pork chops, lamb steaks,
sausage, flattened boneless chicken
400˚F (205˚C)
Vegetables, sliced or grated
Occasionally remove the seasoning, clean
the griddle thoroughly and reapply. To
remove, add white vinegar and water or
club soda to a slightly warm surface. Scrub
with a fine wire brush or a fine-grit griddle
brick. Repeat if necessary. After cleaning,
apply a light coat of oil for seasoning.
Griddle control knob
Dimensions in parentheses are in
millimeters unless otherwise specified.
Griddle grease collection tray
17
WOLF GAS RANGETOP OPERATION
HIGH
HIGH
HIGH
LOW
LOW
LOW
LOW
MED MED
Center Plate Hook
Center Plate
French Top
Center Plate
Observation Slots
FRENCH TOP
The 15,000 Btu/hr (4.4 kW) French Top is an
optional feature that provides a 22" (559)
ooking surface with the hottest temperature
c
under the center plate and the lowest temperature near the edges. This design makes it
ossible to use several pans at once for a
p
variety of cooking tasks. For example, fry
chicken toward the center, while simmering a
sauce in one corner and keeping vegetables
warm in a different corner. Place the pan or
pans toward the edge according to their
contents and quantity. Refer to the illustrations
below.
The cooking surface is made of polished cast
iron that is an excellent heat conductor. The
several rings allow for the solid surface to
expand with the heat while remaining flat. The
rings also provide thermal breaks in the cast
iron that distribute the heat in a graduated
intensity, hottest in the center and coolest
around the edges.
SEASON THE FRENCH TOP
he French Top is shipped with a protective
T
oil, use hot water and detergent to clean
the surface. Rinse and dry.
Turn on the ventilation hood five minutes
prior to using the French Top.
The French Top needs to go through a
”burn in” period. Turn on the French Top
for 30 minutes to clean oils from the
bottom side of the surface. After 30
minutes, turn the French Top off and allow
it to cool.
To season, spread a light coating of peanut
or vegetable oil on a towel or cloth. While
surface is still slightly warm, apply oil
evenly until it is absorbed into the cast iron.
Be careful not to apply too much oil. Excess
oil will leave a gummy residue that will
have to be removed.
It is normal for the cast iron to darken with
use to a bluish-black color.
When this seasoning technique is applied
correctly, the surface will be protected from
moisture. Its appearance darkens with use, a
sign that the French Top has been fully
tempered and is properly seasoned. Regular
maintenance will become easier.
French Top center plate
18
French Top heating zones
French Top center plate removal
WOLF GAS RANGETOP OPERATION
FRENCH TOP
FRENCH TOP OPERATION
MPORTANT NOTE:The stainless steel cover
I
must be removed prior to operating the French
Top.
Turn on the ventilation hood five minutes
prior to using the French Top.
To use the French Top,
control knob counterclockwise to the
push and turn the
HIGH
setting. You will hear the clicking sound of
the igniter lighting the burner.
Preheat for 25 to 30 minutes before cooking
on the French Top. This allows the solid
cast iron plate to heat thoroughly.
To raise or lower the cooking heat, slide the
pan either toward (higher heat) or away
from (lower heat) the center plate. This
gives you total control over the most
delicate sauces. It is not necessary to adjust
the flame height.
To turn the French Top off,
control knob clockwise to the
turn the
OFF
position.
FRENCH TOP COOKING TIPS
FRENCH TOP CARE
t is best to maintain a seasoned surface to
I
protect the cast iron from moisture.
Clean entire surface after each use while it
is slightly warm. Wipe the surface with a
mild detergent (e.g., Dawn) and water.
Rinse and dry.
Maintain the French Top as you would a
cast iron skillet; keep it free from moisture.
Reapply a light coating of peanut or
vegetable oil to the French Top after each
use until a sheen develops.
Periodically, it may be necessary to strip the
oil and stains from the plate. Apply a small
amount of white vinegar and water to the
surface while it is slightly warm. Repeat
until excess oil has been removed.
The French Top burner is located below the
center plate. The plate remains in place
during cooking but it can be lifted off to
check or service the burner. Use the center
plate hook provided with your rangetop as
shown in the illustration on page 18.
Always cook in pans. Do not cook food
directly on the surface.
Never remove the center plate when
cooking.
When bringing large amounts of water to a
boil, it is fastest to do it on one of the
surface burners.
Never leave pans on a high heat zone
unattended. Be cautious when cooking
food in fat or grease. It can become hot
enough to ignite.
Allow the French Top surface to cool
sufficiently befor
e cleaning.
Dimensions in parentheses are in
millimeters unless otherwise specified.
19
WOLF GAS RANGETOP CARE
Drip Pan
Removal Hook
Porcelain Top
ACCESSORIES
Optional accessories are available
through your
Wolf dealer. To
obtain local dealer
information, visit
the Locator section
of our website,
wolfappliance.com.
COOKWARE SELECTION
For best results, we recommend medium- to
heavy-weight pans that have a flat base, metal
andle and a good-fitting cover. Look for pans
h
that are made of materials with good heat
conductivity, such as aluminum and copper.
Use the following guidelines when selecting
ookware for the rangetop:
c
Select high-sided (deep) pans rather than
ones with very wide bases and low sides.
High sides will minimize boilovers.
When using pans made of cast iron,
enameled steel or glass ceramic, or coated
with a nonstick finish, select lower flame
settings. High heat applied to such materials will cause ”hot spots” and scorching.
Cover pans while cooking; covers improve
cooking efficiency. Water boils faster, using
less fuel, and the kitchen stays cooler.
Use the front burners for larger pans. The
pans are easier to handle, especially when
hot.
Pans with oversize bases that extend
beyond the rangetop frame
used. On
HIGH
settings, heat may be
should not
be
trapped beneath the pan causing permanent damage to the surface finish.
Use a wok with a flat bottom.
CLEANING THE RANGETOP
RANGETOP CLEANING TIPS
ait until surfaces are cool before cleaning.
W
Wipe up spills and spatters as they occur
and immediately after the rangetop has
cooled. If spatters are allowed to cook on,
they may permanently damage or stain the
finish.
Use caution when spraying cleaners. Some
contain caustic ingredients that can damage
adjacent parts and finishes. Protect adjacent
parts by masking them off before spraying.
Do not spray cleaners on electrical controls,
igniters, wires or switches.
Refer to pages 13–19 for specific care
instructions for the charbroiler, griddle and
French Top.
DRIP PAN REMOVAL
The drip pan removal hook (part #722218) is
provided with the rangetop to lift and remove
the porcelainized steel top for cleaning.
To remove the drip pan,
first remove the cast
iron grates. Insert the vinyl-coated end of the
drip pan removal hook into one of the oblong
holes in the drip pan. Lift upward and set
the drip pan aside for cleaning. Refer to the
illustration below.
20
Porcelain top removal
WOLF GAS RANGETOP CARE
CARE RECOMMENDATIONS
COMPONENT CARE RECOMMENDATION
Exterior Finish
Bull-Nose
and Riser
Stainless steel
Burner Base
and Cap
Porcelain enamel
and brass
Drip Pan
Porcelain enamel
(glossy finish
on steel)
Do not use abrasive cleaners; they will permanently scratch the surface.
Salt and some cooking liquids may pit and stain the surface. Always remove
hese spills immediately. Use a spray degreaser to remove fingerprints and
t
greasy spatters. Spray on a cloth and wipe surface. Buff dry immediately to
avoid streaking. For hard water stains, use white vinegar and water.
Exterior Cleaning: Use a soft, nonabrasive stainless steel cleaner like
Signature Polish (see side note) and apply with a soft lint-free cloth. To bring
out the natural luster, lightly wipe the surface with a water-dampened
microfiber cloth, followed with a dry microfiber cloth. All work should follow
the grain direction of the finish. Better results are obtained by keeping the
cloth in continuous contact with the metal.
Allow burner base and cap to cool first. Wash in warm water and liquid
detergent. Rinse and dry.
Spray degreasers and mild abrasive cleaners may be used.
Caution! Do not use abrasive cleaners (e.g., Comet); they will permanently scratch the surface.
Salt and some cooking liquids may pit and stain the surface. Always remove
these spills immediately. For general care, use a clean cloth or sponge; wipe
with warm water and a mild dish detergent. Rinse and dry immediately. Use
a spray degreaser to remove fingerprints and greasy spatters. Spray on a
cloth and wipe surface. Buff dry immediately to avoid streaking. For hard
water stains, use white vinegar and water.
SIGNATURE
POLISH
Signature Polish
is available from
Signature Limited
Laboratory,
P.O. Box 13436,
Dayton, Ohio
45413-0436, or
call 877-376-5474
(toll free).
ner Grates
Bur
Porcelain-coated,
cast iron
Control Knobs
Plastic (red or black)
Control Panel
Stainless steel
Spark Igniters
Ceramic
Remove from gas rangetop top and place on a flat surface near the sink.
Nonabrasive cleaners to use include: Hot water and liquid detergent, paste of
baking soda and water, plastic pad or sponge.
Spray degreasers and mild abrasive cleaners may be used.
Wipe with damp cloth and mild soap and water; rinse and dry.
Never soak
or use abrasive cleaners; they will scratch the finish and remove markings.
Use a spray
before wiping panel.
Keep dry; never spray water or cleaner directly on the igniter.
cleaning ar
degreaser to remove fingerprints and food soils. Spray on a cloth
Do not spray directly on panel around valve stems.
When
, be careful that the cloth does not catch
ound the sur
face bur
ner
on the igniter and damage it.
21
WOLF SERVICE INFORMATION
SERVICE INFORMATION
CONTACT
INFORMATION
Wolf Customer
Service:
800-332-9513
Website:
wolfappliance.com
When requesting information, literature,
replacement parts or service, always refer to
he model and serial number of your gas
t
rangetop. This information is found on the
product rating plate. The rating plate is located
nder the drip pan that supports the cooking
u
grates, on the left inside wall of the rangetop.
The rating plate for French Top models (except
Model RT484F) is located on the right inside
wall. Refer to the illustration on page 8. Record
the rating plate information below for future
reference.
Model Number
Serial Number
Installation Date
Wolf Authorized Service Center and Phone
Wolf Dealer and Phone
PRODUCT REGISTRATION
egister your new Wolf product today so that
R
we may ensure your satisfaction. You may
register by one of the following options:
1)
Mail in the completed Wolf Product
Registration Card.
2)
Register online at
3)
Register by phone by calling the Wolf
wolfappliance.com
.
Customer Service Department at
800-332-9513
.
The model and serial numbers of your appliance are printed on the enclosed Wolf Product
Registration Card. If you provide us with your
e-mail address, we will send you exciting new
product updates and recipes as they become
available, along with information on special
events.
BEFORE CALLING FOR SERVICE
Before calling your Wolf authorized service
center, check the household fuse or circuit
eaker to see if it has been blown or tripped
br
and that the electrical connection to the
appliance has not been disconnected. A power
outage may also have caused a disruption in
vice.
ser
The information and images are the copyright
property of Wolf Appliance Company, LLC,
an affiliate of Sub-Zero Freezer Company, Inc.
Neither this book nor any information or images
contained herein may be copied or used in
whole or in part without the express written
permission of Wolf Appliance Company, LLC,
an affiliate of Sub-Zero Freezer Company, Inc.
©Wolf Appliance Company, LLC all rights
ved.
eser
r
22
W OLF A PPLIANCE P RODUCTS
L IMITED W ARRANTY
RESIDENTIAL USE ONLY
FULL TWO YEAR WARRANTY*
or two years from the date of original installation, your Wolf Appliance product warranty covers all
F
parts and labor to repair or replace any part of the product that proves to be defective in materials
or workmanship. All service provided by Wolf Appliance Company under the above warranty must
be performed by a Wolf Appliance authorized service center, unless otherwise specified by Wolf
ppliance Company. Service will be provided in the home during normal business hours.
A
LIMITED THIRD THROUGH FIFTH YEAR WARRANTY
From the third through fifth year from the date of original installation, Wolf Appliance Company will
repair or replace the following parts that pr
emove and replace defective parts is not covered. Wolf Appliance Company recommends that you
r
use a Wolf Appliance authorized service center to perform such service.
Gas Burners (excluding appearance), Electric Heating Elements, Blower Motors (vent hoods),
Electronic Control Boards, Magnetron Tubes and Induction Generators
LIMITED LIFETIME WARRANTY
For the life of the product, Wolf Appliance Company will repair or replace any BBQ body or BBQ hood
that rusts through due to defective material or workmanship. Labor to remove and replace defective
parts is not covered. Wolf Appliance Company recommends that you use a Wolf Appliance authorized service center to perform such service.
ove to be defective in materials or workmanship. Labor to
TERMS APPLICABLE TO EACH WARRANTY
The warranty applies only to products installed for normal residential use. The warranty applies only
to products installed in any one of the fifty states of the United States, the District of Columbia or
the ten provinces of Canada. This warranty does not cover any parts or labor to correct any defect
caused by negligence, accident or improper use, maintenance, installation, service or repair.
THE REMEDIES DESCRIBED ABOVE FOR EACH WARRANTY ARE THE ONLY ONES THAT WOLF
APPLIANCE COMP
ARRANTY
W
RESPONSIBLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM THE
BREACH OF THIS WARRANTY OR ANY OTHER WARRANTY, WHETHER EXPRESS, IMPLIED OR
STATUTORY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific legal rights and
you may also have other legal rights that vary from state to state.
o receive parts and/ or service and the name of the Wolf Appliance authorized service center
T
nearest you, contact Wolf Appliance Company, LLC, P.O. Box 44848, Madison, Wisconsin 53744;
check the Locator section of our website, wolfappliance.com, or call 800-332-9513.
* Stainless Steel (classic, platinum and carbon) doors, panels and product frames are covered by a
limited 60 day parts and labor warranty for cosmetic defects.
ANY, LLC WILL PROVIDE, EITHER UNDER THIS WARRANTY OR UNDER ANY
. WOLF APPLIANCE COMPANY, LLC WILL NOT BE
ARISING BY OPERA
TION OF LA
W
23
OLF APPLIANCE COMPANY, LLC P. O. BOX 44848 MADISON, WI 53744 800-332-9513 WOLFAPPLIANCE.COM
W
807585
3/2006
Loading...
