Page 1
subzero.com 800.222.7820
700
Service Manual
General Information 2
Page 2
General Information
Integrated
(700-3BASE)
Series
1-2
#3758424 - Revision C - November, 2006
TECHNICAL ASSISTANCE
If you should have any questions regarding a 7003 Base Unit and/or this manual, please contact:
Sub-Zero Freezer Company, Inc.
ATTN: Service Department
P.O. Box 44988
Madison, WI 53744 - 4988
Customer Service & Parts / Warranty Claims
Phone #: (800) 222 - 7820
Technical Assistance
Phone #: (800) 919 - 8324
Customer Service & Technical Assistance
Facsimile #: (608) 441 - 5887
Parts / Warranty Claims
Facsimile #: (608) 441 - 5886
Service Department E-Mail Address:
customerservice@subzero.com
Office Hours:
7:00 AM to 7:00 PM Central Time
Monday through Friday
This manual is designed to be used by Authorized Service Personnel only. Sub-Zero Freezer Co., Inc.
assumes no responsibility for any repairs made on Sub-Zero refrigeration units by anyone other than
Authorized Service Technicians.
IMPORTANT SAFETY INFORMATION
Below are the Product Safety Labels used in this
manual. The "Signal Words" used are WARNING
or CAUTION.
When reviewing this manual, please note these
different Product Safety Labels placed at the
beginning of certain sections of this manual. You
must follow the instructions given in the boxes
below the Product Safety Labels in order to avoid
personal injury and/or product damage.
The sample Product Safety Labels below illustrate
the precautions that should be taken when the signal word is observed.
INTRODUCTION
This 700-3 Series Base Unit Technical Service Manual, Part #3758424, has been compiled to provide the
most recent information on safety, installation, set-up, design, operation, features, troubleshooting, wiring
diagrams, and repair procedures of the 700-3 Base units. This information will enable the service technician to troubleshoot and diagnose malfunctions, perform necessary repairs, and return a 700-3 Base unit
to proper operational status.
The service technician should read the complete instructions contained in this training/service manual
before initiating any repairs on a 700-3 Base unit.
INDICATES THAT HAZARDOUS OR UNSAFE PRACTICES COULD RESULT IN SEVERE PERSONAL
INJURY OR DEATH
Indicates that hazardous or unsafe practices could
result in minor personal injury or product and/or
property damage
In addition, please pay attention to the signal word
“NOTE”, which highlights information that is espe-
cially important for the topic being covered.
The information and images contained in this manual are the copyright property of Sub-Zero Freezer Company, Inc.
Neither this manual nor any information or images contained herein may be copied or used in whole or in part with-
out the express written consent of Sub-Zero Freezer Company, Inc. © all rights reserved.
Page 3
General Information
Integrated
(700-3BASE)
Series
1-5
#3758424 - Revision C - November, 2006
WARRANTY INFORMATION
This page summarizes the 2, 5 & 12 Year Warranty
supplied with every unit, as well as the two special warranties: The Non-Residential Warranty which applies to
units installed in non-residential applications, and the
Display/Model Home Warranty which applies to distributor or dealer’s display units and units in model homes,
sold three years after date of manufacture. The last
entries on this page are details and notes about the
warranties.
TWO, FIVE & TWELVE YEAR Warranty Summary
• Two year TOTAL PRODUCT warranty, *parts and
labor.
• Five Year SEALED SYSTEM warranty, **parts and
labor.
• Sixth through Twelfth year LIMITED SEALED SYSTEM warranty, sealed system **parts only.
ONE & FIVE YEAR Non-Residential Warranty
Summary (Example: Office, Yacht, etc.)
• One Year TOTAL PRODUCT warranty, *parts and
labor.
• Five year LIMITED SEALED SYSTEM warranty,
sealed system **parts only.
ONE & FIVE YEAR Display/Model Home Warranty
Summary (Display units sold three years after date
of manufacture)
• One Year TOTAL PRODUCT warranty, *parts and
labor.
• Five year LIMITED SEALED SYSTEM warranty,
sealed system **parts only.
Warranty Details:
• * Total Product Parts includes, but is not limited to the
following:
Electronic Control System Components, Fan & Light
Switches, Fan Motors & Blades, Defrost & Drain
Heaters, Defrost Terminators, Drain Pans, Drain Tubes,
Wiring, Light sockets & bulbs, Icemakers, Water
Valves, Door hinges, Door closers & Cams,
Compressor Electricals, etc. . .
• ** Sealed System Parts include the following:
Compressors, Condensers, Evaporators, Filter-Driers,
Heat-exchangers, All Tubing That Carries the Freon.
NOTE: Condenser Fan Motors, Freon, Solder and
compressor electricals are NOT
considered sealed
system parts.
Warranty Notes:
• All warranties begin at the time of the unit's initial
installation.
• All Warranty and Service information collected by SubZero is arranged and stored under the unit serial number. This information is now also stored under the customer's last name.
NOTE: Sub-Zero still requests that you have the
model and serial number available whenever contacting the factory or parts distributor.
• The serial number tag is located on the left side wall of
the upper drawer compartment. (See Figures 1-1, for
serial tag layout)
Figure 1-1. Serial Tag Layout
(The serial number tag is located on the left side wall of the upper drawer compartment.)
700BCI 3
0000000
6.0 oz
6.5 A R134a
Jan2004
Model Number
Serial Number
Manufacture Date
Refrigerant Charge
Total Amps Refrigerant Type
REFRIGERATOR
PRODUCT SERVICE 1-800-222-7820
MODEL
FREEZER CO., INC.
FREEZER
MADISON, WI
SERIAL NUMBER
TOTAL AMPS
115Vac, 60Hz, 1 Phase
REFRIGERANT
LISTED HOUSEHOLD
REFRIGERATOR OR FREEZER
U
R
O
L
CUS
LISTED
776N
Date Code
ALSO VERIFIED IN
ACCORDANCE WITH
ENERGY STANDARD
CAN/CSA-C300-91
Page 4
General Information
Integrated
(700-3BASE)
Series
1-6
#3758424 - Revision C - November, 2006
MODEL DESCRIPTIONS
This page briefly describes the Models 700BC-3, 700BCI-3, 700BF-3, 700BFI-3 and 700BR-3.
Figure 1-2. Model 700BC-3 & 700BCI-3
Upper
Refrigerator
Zone
Lower
Freezer
Zone
Figure 1-3. Model 700BR-3
Two Drawer
All Refrigerator
(One Zone)
Figure 1-4. Model 700BF-3 & 700BFI-3
Two Drawer
All Freezer
(One Zone)
Model 700BC-3 (Figure 1-2)
700 Series, Base Combination, 3rd Design Build
(Combination Refrigerator / Freezer with Two Temperature
Zones - Upper Refrigerator over Freezer)
(Overall Dimensions = 34” H x 27” W x 24” D)
Model 700BCI-3 (Figure 1-2)
700 Series, Base Combination, Icemaker Incl., 3rd
Design Build
(Combination Refrigerator / Freezer with Two Temperature
Zones - Upper Refrigerator over Freezer)
(Overall Dimensions = 34” H x 27” W x 24” D)
Model 700BR-3 (Figure 1-3)
700 Series, Base Refrigerator, 3rd Design Build
(Refrigerator with One Temperature Zone)
(Overall Dimensions = 34” H x 27” W x 24” D)
Model 700BF-3 (Figure 1-4)
700 Series, Base Freezer, 3rd Design Build
(Freezer with One Temperature Zone)
(Overall Dimensions = 34” H x 27” W x 24” D)
Model 700BFI-3 (Figure 1-4)
700 Series, Base Freezer, Icemaker Incl., 3rd Design
Build
(Freezer with One Temperature Zone)
(Overall Dimensions = 34” H x 27” W x 24” D)
