Subaru Crosstrek Quick Reference Manual

2017 Quick Reference Guide

2

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Remote keyless entry system

Remote
transmitter key
(if equipped)

Access key
(if equipped)

Lock/Unlock doors

PANIC

* Grip the driver’s door handle to unlock the

driver’s door. Grip the front passenger’s door
handle to unlock all doors and the rear gate.

All doors and the rear gate will be locked/unlocked by the following procedures carrying the
access key on your person. (The driver should always carry the access key.)

Keyless access function (if equipped)

Side door (front door handles only):

Rear gate:

1

All doors and the rear gate will be locked.

2

The driver’s door will be unlocked.

(To unlock all doors and the rear gate, briey

press the button a second time within 5
seconds.)

3

The rear gate will be unlocked.

4

The horn will sound and the hazard warning

ashers will ash.

BASIC OPERATION

For detailed operating and safety information, please refer to
your Owner’s Manual.

2

3
4

1

1
2

3

4

Lock

Unlock*

Door lock sensor

Grip

Touc h

Press

Unlock

Lock

Press

3

Ignition switch must be in

ACC

or ON position.

1

Select side to adjust.

2

To adjust the mirror, move the switch in the

direction of your desired position.

Adjust each component

1

Forward and backward adjustment

2

Seat height adjustment (Driver’s seat only)

3

Seatback reclining adjustment

Front seat

Tilt/telescopic steering wheel

Remote control mirror switch

1

Adjust the seat position and pull the tilt/

telescopic lock lever down.

2

Move the steering wheel to the desired level.

3

Pull the lever up to lock the steering wheel in

place.

Make sure that the steering wheel is securely
locked by moving it up and down, and forward and
backward.

1

2

3

2

1

2

3

2

1 2

4

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Start/Stop engine

To start engine:

STEP1:

Carry the access key, and sit in the driver’s
seat.

STEP2:

Apply the parking brake.

STEP3:

Shift the select lever into the P position.

STEP4:

Depress the brake pedal until the indicator on

the push-button ignition switch turns green.

STEP5:

While depressing the brake pedal, press the

push-button ignition switch.

To stop engine:

STEP1:

Stop the vehicle completely.

STEP2:

Move the select lever to the P position.

STEP3:

Press the push-button ignition switch.

Every time the button is pressed without depressing the brake pedal, the power is switched
in the sequence of

OFF➞ACC➞ON➞OFF

.

OFF

(Tu rn ed o f f )

ACC

(Orange)

ON

(Orange)

Change of the power supply (Without starting engine)

The key can be turned from

ACC

to

LOCK

only when
the key is pushed in while turning it (all models) and
the select lever is in the P position (CVT models).

Push-button ignition switch (if equipped)

Ignition switch (if equipped)

Operation

indicator

5

531

R

42

To change gears, fully depress the clutch pedal,
move the shift lever, and gradually let up on the
clutch pedal.

Operate Select lever/Shift lever

Continuously variable transmission (if equipped)

Manual transmission (if equipped)

Shift paddle:

Gearshifts can be performed using the shift paddle
behind the steering wheel.

With the brake pedal depressed, shift while
pressing the Select lever button in.

Shift while pressing the Select lever button
in.

Shift without pressing the Select lever
button.

Rear view camera:

When the ignition switch is ON and the select lever is
set to R, the rear view camera automatically displays
the rear view image behind the vehicle.

M = Manual mode

With the vehicle either moving or stationary, move the select lever from the D position to the

M

position to select the manual mode.

Select lever

button

Downshift

Upshift

6

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

1

Headlights

2

 Headlightasher,High/Lowbeamchange

(dimmer)

3

Turn signal

Headlight switch/Turn signal lever/Front fog light switch (if equipped)

A

4

Front fog lights (if equipped)

To turn on the front fog lights, rotate dial to .

Front fog lights operate only when headlight switch
is in...

-

position.

-

AUTO

position and the headlights are on.

*

For models equipped with

AUTO

position.

MAIN PARTS AND OPERATION

A

G

H

I

D

F

E

4

3

3

1

2

B C

*

*

7

1

Windshield wiper

To operate the wiper, rotate knob to;

: Mist (for a single wipe)
: Off
: Intermittent
: Low speed
: High speed

2

Wiper intermittent time control

3

Windshield washer

4

Rear window wiper and washer

To operate the wiper, rotate knob to;

: Continuous
: Intermittent

: Off
: Washer

Rotate knob to . The washer uid sprays and the
wiper operates.

Wiper and washer switch

B

To turn on the hazard warning asher, push the button.
Use the hazard warning asher when you have to park

under emergency conditions.

 Hazardwarningasherswitch

C

Turn the dial to adjust the illumination brightness of the
instrument panel.
To brighten, turn the control dial upward.
To darken, turn the control dial downward.
When the control dial is turned fully upward, the
illumination brightness becomes the maximum and the
automatic dimming function does not work at all.

Illumination brightness control dial

D

1

2

3

4

Models without
multifunction display

Models with
multifunction display

8

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

1

Defroster button:

Turn the airow mode selection dial.

2

, Rear window defogger button:

Press the button to turn on rear window defogger,
outside mirror defogger and windshield wiper deicer
(if equipped). The function will automatically shut off
after approximately 15 minutes.

*The illustration of the print is Type A.

Defroster button/Rear window defogger button

E

Hood lock release knob

F

1

Lock switch

2

For driver’s window

3

For front passenger’s window

4

For rear left window

5

For rear right window

Power window switches

G

To unlock all doors and the rear gate

To lock all doors and the rear gate

Power door locking switch

H

1

2

Pull

1

2

4

5

3

9

 Fuelllerlidreleaselever

I

This indicates that the fuel ller door (lid) is

located on the right side of the vehicle.

Located on the edge of each rear door.
When the lever is in the

LOCK

position, the rear door

cannot be opened from the inside.

Child safety locks

Pull the upper part of
the anchor and slide
the anchor down.

Front seat shoulder belt anchor height

To lower To rai se

Slide the anchor up.

Right side

10

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

FUNCTION FOR MORE COMFORTABLE DRIVE

1

Cruise control main button:

To activate and

deactivate

2

RES/SET switch:

▲RES/+ side : To increase the speed/To resume
▼SET/- side : To set speed/To decrease the speed

3

CANCEL button:

To temporarily cancel

Cruise control enables you to maintain a constant vehicle speed without holding your foot on
the accelerator pedal and it is operative when the vehicle speed is 40 km/h (25 mph) or more.

Cruise control buttons (if equipped)

B

Models without EyeSight system

Audio control buttons

A

These buttons allow the driver to control audio functions
without taking his/her hands off the steering wheel.

A

I

H

E B C D

G F

1

2

3

11

Information display (if equipped)

C

1

Outside temperature indicator

2

Driving information display

3

Clock

Control switch:

To adjust the time shown by the clock,

press the + button or the - button.

1

(CRUISE) switch

2

(Following distance setting) switch

3

RES/+ switch

4

SET/- switch

EyeSight is a driving support system that uses a range of functions to assist the driver in
making decisions in order to provide for more safe and comfortable driving and to reduce
driver fatigue.

Models with EyeSight system

Multi function display (if equipped)

D

1

Outside temperature indicator

2

Top display

3

Clock

4

Driving information display

Control switch:

By operating ▲ or ▼ of the control
switch, the screens and selection
items can be switched. When the

ENTER

button is pushed, the item

can be selected and set.

1 2 3

Control

switch

1

2

3

4

Control

switch

1 2 3

4

12

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

1

Fuel gauge

2

Warning screen/Basic screen

3

Cruise control information display

4

Warning indicator

5

Select lever/gear position indicator

6

Odometer/double trip meter

Control switch:

By operating ▲ or ▼ of the control

switch, the screens and selection
items can be switched. When the

/

SET

switch is pulled toward you, the

item can be selected and set.

km/h

km

Multi information display (if equipped)

E

If the BSD/RCTA OFF switch is pressed, the BSD/
RCTA warning indicator and BSD/RCTA OFF indicator
are displayed on the multi information display of the
combination meter, and the BSD/RCTA is deactivated.

The BSD/RCTA consists of rear radar with Blind Spot

Detection, Lane Change Assist and Rear Cross Trafc

Alert.

The system noties the driver when vehicles in the blind

area are approaching from behind in the neighboring lanes.

BSD/ RCTA

BSD/RCTA OFF switch (if equipped)

F

1

2

3

4

6

5

Control

switch

Press

13

Press the switch to deactivate the Vehicle Dynamics Control system. It may be helpful to
temporarily deactivate the Vehicle Dynamics Control system to escape from the following
situations.

- a standing start on a steeply sloping road with a snowy, gravel-coverd, or otherwise
slippery surface

- extrication of the vehicle when its wheels are stuck in mud or deep snow

Do not deactivate the system except when absolutely necessary.

Vehicle Dynamics Control mode

Vehicle Dynamics Control OFF mode

Indicator lights on the combination meter

Vehicle Dynamics Control OFF switch

H

Seat heater (if equipped)

I

1

HI : Rapid heating

2

LO : Normal heating

1

2

If the steering responsive fog lights OFF switch is
pressed, the steering responsive fog lights OFF
indicator is displayed on the Multi information display of
the combination meter, and the steering responsive fog
lights system is deactivated.

Steering responsive fog lights OFF switch (Models with EyeSight system)

G

The steering responsive fog lights system automatically turns the front fog light on and
off based on the steering angle and vehicle speed when entering a curve or driving on
curved roads.
The system is intended to help prevent accidents by enabling better visibility of curves
ahead and early recognition of any disabled vehicles or other obstacles.

Steering responsive fog lights system

Press

14

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Moonroof switches (if equipped)

Tilting Sliding

1

Raise

2

Lower

1

Open

2

Close

2

1

2

1

Lane Departure Warning OFF switch (Models with EyeSight system)

Press and hold this switch for approximately 2 seconds
or longer to turn off the Lane Departure Warning and
Lane Sway Warning functions.

Pre-Collision Braking System OFF switch (Models with EyeSight system)

Press and hold this switch for approximately 2 seconds
or longer to turn off the Pre-Collision Braking System
and Pre-Collision Throttle Management.

When there is the risk of a rear-end collision with an obstacle in front, the EyeSight
system helps to minimize or prevent a collision by warning the driver. If the driver still
does not take evasive action to avoid a collision, the brakes can be automatically applied
just before the collision in order to reduce impact damage, or if possible, prevent the
collision. If the driver takes evasive action to avoid a collision, Pre-Collision Brake Assist
will operate in order to help the driver to prevent the collision.

Pre-Collision Braking System

When vehicle speed is approximately 50 km/h (30 MPH) or more, this function warns

the driver if the system detects that the vehicle is likely to depart the trafc lane.

Lane Departure Warning

15

Some warning/indicator lights illuminate for a few seconds in order to check themselves
when the ignition switch is turned ON.

Warning lights

Refer to your Owner’s Manual for countermeasures when each warning light comes on.
If necessary, consult your authorized SUBARU dealer.

Oil pressure warning

The engine oil pressure is too
low.

Engine low oil level warning

The engine oil level decreases to
the lower limit.

All-wheel Drive warning (CVT models)

Tires of different diameter tted/

air pressure excessively low.

SRS airbag system warning

SRS airbag system and/
or seatbelt pretensioners
malfunction.

Power steering warning

The electric power steering
system malfunction.

AT OIL TEMP warning (CVT models)

Transmission uid temperature

is too hot./Transmission control
system malfunction.

Seatbelt warning

Remind the driver to fasten
seatbelt.

Charge warning

Charging system malfunction.

Front passenger’s seatbelt warning

PASSENGER

Remind the front passenger to
fasten seatbelt.
Location: next to Information
display/Multi function display.

CHECK ENGINE warning/Malfunction
indicator

Engine/Emission control system
malfunction.

Door open warning

Any door or the rear gate is not
fully closed.

Low fuel warning

Fuel tank is nearly empty. Rell

fuel immediately.

Brake system warning

Parking brake on/Low brake uid level/EBD System malfunction.
(Anti-lock Brake System warning light illuminates simultaneously)

MAIN WARNING AND INDICATOR LIGHTS

16

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Windshieldwasheruidwarning

The uid level in the windshield washer uid tank decreases to the lower limit.

Access key warning

The access key is not inside the vehicle. For other situations, refer to your
Owner’s Manual.

Automatic headlight beam leveler warning

Automatic headlight beam leveler malfunction.

ABS warning

Anti-lock Brake System malfunction/EBD System malfunction (Brake System
warning light illuminates simultaneously).

BSD/RCTA warning

Blind Spot Detection/Rear Cross Trafc Alert (BSD/RCTA) malfunction.

Hill start assist warning/Hill start assist OFF indicator

Warning :

Hill start assist system malfunction.

Indicator :

Hill start assist system OFF.

Vehicle Dynamics Control warning/Vehicle Dynamics Control operation indicator

Warning :

Vehicle Dynamics Control system malfunction.

Indicator :

Flashes during activation of the skid suppression function and the
traction control function.

Steering responsive fog lights warning/
Steering responsive fog lights OFF indicator

Warning :

The steering responsive fog lights system malfunction.

Indicator :

The steering responsive fog lights system is deactivated.

Coolant temperature low indicator/Coolant temperature high warning

llumination in BLUE :

Insufcient warming up of the engine.

Illumination/blinking in RED :

Engine overheating/almost overheating.

Blinking in RED and BLUE alternately :

Electrical system malfunction.

17

Indicator lights

The following indicators show the current status of your car. Refer to your Owner’s Manual
for more information.

Turn signal
indicator

Headlight
indicator

High beam
indicator

Front fog light
indicator

Security
indicator

BSD/RCTA OFF
indicator

Front passenger’s frontal
airbag ON/OFF indicators

Vehicle Dynamics
Control OFF indicator

Cruise control indicator Cruise control set indicator

Lane Departure Warning OFF
indicator

Pre-Collision Braking System
OFF indicator

18

◆

Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.

Notes

19

Notes

All illustrations, specications, features and photographs contained in this brochure are based on product information available at the time of
its printing, and may not be completely accurate following its publication. Colours shown may vary due to reproduction variations in the printing
process, and some vehicle par ts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes

at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specications and models, or to change
their prices. Please visit our Web site for the latest information and specications. For detailed operating and safety information, please consult

your Owner’s Manual. For complete details on product updates, warranties or the Subaru C. A.R.E. program, please contact your Subaru dealer.
Crosstrek and Subaru are registered trademarks. Printed in Canada. © 2016 Subaru Canada, Inc. 2017 model year.

subaru.ca

Environmental Management System (EMS)

ISO14001:2004cer tiedbySGS

www.subaru-earth.com

SUBARU CANADA, INC. /FUJI HEAVY INDUSTRIES LTD.

SBQRGXV17E09.16
