U10 Jump Starter
User Manual
U10 At A Glance
Thank you for choosing Suaoki.
Suaoki U10 is a 3-in-1 device, functioning as a jump starter to boost flat car battery, as a
portable power bank to charge your electronic devices and as a LED flashlight.
Please read the user manual carefully before use and keep it for future reference. Failure to
follow the instructions may result in injury.
· 1 ·
① LED Flashlight
② USB 5V-2.4A Output
③ Power Button
④ 12V Jumping Port
⑤ Input Port (15V-1A)
⑥ LCD Display
EN
① ② ③
④ ⑤ ⑥
Cautions
1. ONLY use it to start a 12V vehicle (gas engine up to 6L,diesel engine up to5L).
2. DO NOT use the jump starter to start a car when the remaining capacity is less than
30% or when it is still hot.
3. Disconnect the battery clamp from the jump starter and the vehicle immediately after
every starting attempt.
4. DO NOT use the jump starter to start the car in high frequency. Allow at least 30s of
resting time before jump starting a car again.
5. DO NOT charge the product immediately after use or while it is still hot.
6. Please charge the jump starter at least once a month to extend battery life.
7. DO NOT allow the metal teeth of the red clamp to touch the metal teeth of the black
clamp.
8. Please keep this product away from children.
9. Please DO NOT disassemble this product.
10. Please store and charge the jump starter at a dry and well-ventilated place. Keep it
away from corrosive, flammable and explosive materials.
11. DO NOT expose this product to extreme environment where the temperature and
humidity is high.
12. Never burn or incinerate this product because it may explode and generate toxic
fumes and other potentially harmful chemicals.
13. Never insert foreign objects into any input or output ports, because it may cause short
circuit which will damage the battery and even cause fire and personal injury.
14. If you find the jump starter inflates, please stop using it at once.
· 2 ·
Instructions
● Charging the jump starter
Both the power adapter and the car charger can charge the jump starter.
Charging with adapter
First step:
Insert the adapter into a socket.
Second step:
Insert the other end of the adapter into the input port of the jump starter.
EN
