STYLE EL-DRL Assembly & Use Instructions
Electric height adjustable desk
ASSEMBLY &
USE INSTRUCTIONS
CAUTION/INFORMATION
Make sure no obstacles are in the desk's path.
Make sure the desktop is not touching any walls.
Make sure all cords are appropriate length to
accommodate the change in height.
Keep children away from electric height-adjustable desks,
control units and handsets. There is a risk of injury and electric shock.
Keep all electrical components away from liquids.
Do not set or stand on the desk Frame.
Do not crawl or lie under the desk Frame.
Do not place any objects taller than 50 underneath the desk.cm
Do not open any of the components - the Legs, control Box, or handset.
There is a danger of electric shock.
WARNING
PINCH POINT
keep hands and
fingers clear.
This product is designed with a duty cycle of 10% (2 min. on, 18 min. off)
In the event of a power outage or if the power cord is unplugged,
a manual reset may be necessary - see Step 12.
USE/LIABILITY
This height adjustable desk has electric motors and is designed for use in dry work areas only. The
desk height is adjustable so that it can be positioned at the most ergonomically suitable height.
Any other use is at user's risk.
Under no circumstances does the manufacturer accept warranty claims or liability claims for damages
caused from improper use or handling of the desk frame.
IMPORTANT:
Please read this manual carefully.
If this desk is sold ,please provide this manual to the buyer.
Page1
TOOLS REQUIRED
PARTS
Phillips Head Screwdriver
and/or Power Drill
COMPONENTS
Legs
x3
Foot with
Glides
4MM Allen Wrench
(included)
Crossbar End
x3
x4
Tape measure
Center Rail
x4
Side Bracket
x3
Control Box
HARDWARE
Machine Scre ws :
M6x12
x40
x1
Programmable
Handset
Machine Scre ws :
M6x10
x16
x1
Wood Screws:
ST M5x16
Cables:60cm
x3
x17
Power cord
x1
Cable Clip s
x10
Page2
