Page 1
USER
GUIDE
PS
PAS
Page 2
1 Introduction
1 Read the User Guide
1 Unpacking
2 Safety Instructions
3 Technical Specification
4 Warranty
5 Service Information
INDEX
INDEX
www.studiomaster.com
www.studiomaster.com
PS
PAS
Page 3
1
INTRODUCTION
Thank you for buying this Studiomaster product.
The PAS/PS
range of compact powered and unpowered speakers are
ideal for anywhere you need a clear, responsive aand compact sounds
system.
The PAS8 and PAS6 feature a built in 50W amplifier with volume and
EQ (tone) control.
All PAS/PS speakers come complete with wall mounting brackets.
READ THE USER GUIDE
The PAS/PS range are very easy to use, although to get the best from
your new purchase, we recommend you read this User Guide before
getting down to any serious work.
It also contains important safety information.
UNPACKING
Remove your Studiomaster product from its packaging and ensure that
along with this User Guide you have an A.C. power cord / mains lead
(PAS models only) and a warranty card.
Retain the packing carton in the eventuality that the unit needs to be
returned for service or repair, and please complete and return your
warranty card. Returning the completed warranty card does not
diminish your statutory rights in any way.
EXPECT THE BEST
EXPECT THE BEST
WEEE Mark
If you want to dispose of this product,
do not mix with general household
waste. There are separate collection
systems for used electronic products in
accordance with legislation under the
WEEE Directive (Directive 2002/96/EC)
and is effective only within the
European Union.
PS
PAS
Page 4
2
www.studiomaster.com
www.studiomaster.com
1. (PAS MODELS ONLY) Before connecting the A.C.
power cord make sure the Voltage selector (located on
the side of the unit) is set to your local supply voltage.
For supplies between 220 and 240V use the 230V
position. For supplies between 110 and 120V use the
115V position.
2. (PAS MODELS ONLY) Only use the A.C. power cord /
mains lead supplied with the product. Replace if it
becomes damaged in any way.
3. (PAS MODELS ONLY) Never operate without, or
remove the safety ground (earth) from the A.C. power
cord / mains lead.
4. Do not attempt to remove any screws or panels.
There are no user serviceable parts inside.
5. Do not operate the unit next to heat sources such as
radiators.
6. The unit should not be operated or stored near rain or
moisture.
7. This equipment must not be exposed to dripping or
splashing and no objects filled with liquids should be
placed on top of it.
8. Write the serial number in the box provided in the
Warranty section for future reference.
9. If the unit gets damaged, has been dropped or appears
to have developed a fault refer to the Service
Information section for details.
WARNING (PAS MODELS ONLY)
THIS APPARATUS MUST BE EARTHED (GROUNDED)
READ THIS BEFORE YOU USE YOUR PRODUCT
WARNING
THESE PRODUCTS ARE CAPABLE OF VERY HIGH VOLUME LEVELS AND PROLONGED EXPOSURE CAN RESULT IN HEARING DAMAGE
PS
PAS
Page 5
3
EXPECT THE BEST
EXPECT THE BEST
FACTS & FIGURES
TECHNICAL SPECIFICATION
PAS6 PAS8 PS6 PS8
Speaker 6" High Output Design 8" High Output Design 6" High Output Design 8" High Output Design
HF Unit High Frequency Tweeter High Frequency Tweeter High Frequency Tweeter High Frequency Tweeter
Finish Black Moulded Plastic Black Moulded Plastic Black Moulded Plastic Black Moulded Plastic
Power Output 1% THD 50W 50W - Power - - 50W 50W
Distortion (amp) 30W @ 8ohms - 0.01% 30W @ 8ohms - 0.01% - -
Power Supply 230V range +/-10% ~50/60Hz
115V range +/-10% ~50/60Hz
Size (w x h x d) metric 230mm x 360mm x 220mm 280mm x 410mm x 250mm 230mm x 360mm x 220mm 280mm x 410mm x 250mm
imperial 9.1" x 14.2" x 8.7" 11" x 16.1" x 9.8" 9.1" x 14.2" x 8.7" 11" x 16.1" x 9.8"
Weight (net) 5kg (11lb) 6kg (13.2lb) 4kg (8.8lb) 5kg (11lb)
Weight (shipping) 6kg (13.2lb) 7kg (15.4lb) 5kg (11lb) 6kg (13.2lb)
PS
PAS
Page 6
4
The Manufacturer warrants all Studiomaster products to be free
from defects in materials and workmanship for a period of one
year from date of purchase. The Manufacturer reserves the right
to the final decision on all warranty claims.
Exclusions to Warranty Cover
Damage caused by accident, misuse, improper
installation or neglect.
Damage caused by repair, modification or service by
persons not authorised by Studiomaster.
Products on which the serial number has been
defaced, altered or removed.
Who is Protected
This warranty is enforceable by the original purchaser and any
subsequent owner(s) during the warranty period, providing a
copy of the original sales receipt is submitted whenever a
warranty service is required.
It is recommended that you complete and mail the Warranty
Registration Card supplied with your product.
For your reference in the event of a warranty or service repair,
please complete the following information and attach a copy or
your original sales receipt.
Model :
Serial Number :
Purchase Date :
Purchased From :
Note : THIS WARRANTY DOES NOT AFFECT YOUR
STATUTORY RIGHTS
www.studiomaster.com
www.studiomaster.com
www.studiomaster.com
ARE YOU COVERED?
WARRANTY
PS
PAS
Page 7
5
If you have a problem with your Studiomaster product or think it
has developed a fault you should first carefully check the Trouble
Shooting section in this guide. If this does not solve the problem
or if the product is physically damaged, contact your local dealer
or distributor for service details.
Should it be recommended you return the product to your
nearest Studiomaster Service Centre you must first contact
them.
You will be asked for the product type and serial number. You
will then be given a Returns Authorisation (RA) number.
Pack the unit in its original carton to protect it from shipping
damage.
You must have the Returns Authorisation number clearly marked
on the outside of the carton or we may refuse the delivery.
Studiomaster cannot be held responsible for damage resulting
from the equipment being packed incorrectly.
Label the equipment clearly with your name and address and
include a clear description of the fault. The more information you
supply helps the service engineer, minimising repair cost when
out of warranty.
Important : No liability will be accepted by Studiomaster for any
transit damage to units not returned in their original packing, for
warranty repairs or otherwise.
EXPECT THE BEST
EXPECT THE BEST
EXPECT THE BEST
In Accordance with our progressive product development, Studiomaster / Studioking Limited reserve
the right to change features and specifications without prior notice.
HOW TO GET MY PRODUCT REPAIRED
SERVICE INFORMATION
PS
PAS
Page 8
www.studiomaster.com
Studioking Limited
7 Eden Way, Pages Industrial Park, Leighton Buzzard, Bedfordshire LU7 4TZ UK
Tel : 44 (0)1525 217111 Fax : 44 (0)1525 378466 Email : [email protected]
EXPECT THE BEST
EXPECT THE BEST
PASM ENG V3
MADE IN CHINA
