Studebaker SB6065 Owner's Manual

0

TURNTABLE CASSETTE AM/FM STEREO

RECEIVER AND CD RECORDER

SB6065 OWNER’S MANUAL

PLEASE READ THIS USER MANUAL COMPLETELY BEFORE

OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR

FUTURE REFERENCE.

1

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE

PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET REFER

SERVICING TO QUALIFIED PERSONNEL ONLY.

THE CAUTION MARKING IS LOCATED AT THE BACK OF THE UNIT
THE RATING PLATE IS LOCATED AT THE BACK OF THE UNIT

CAUTION:

PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN

THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS

BOOKLET FOR FUTURE REFERENCE.

THIS SET HAS BEEN DESIGNED AND MANUFACTURED TO ASSURE PERSONAL SAFETY.

IMPROPER USE CAN RESULT IN ELECTRIC SHOCK OR FIRE HAZARD. THE

SAFEGUARDS INCORPORATED IN THIS UNIT WILL PROTECT YOU IF YOU OBSERVE THE

FOLLOWING PROCEDURES FOR INSTALLATION, USE AND SERVICING. THIS UNIT DOES

NOT CONTAIN ANY PARTS THAT CAN BE REPAIRED BY THE USER.

THE SYMBOL FOR CLASS II (DOUBLE INSULATION)

DO NOT REMOVE THE CABINET COVER OR YOU MAY BE EXPOSED TO

DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL ONLY.

IMPORTANT SAFETY INSTRUCTIONS

1. READ THESE INSTRUCTIONS.

2. KEEP THESE INSTRUCTIONS.

3. HEED ALL WARNINGS.

4. FOLLOW ALL INSTRUCTIONS.

5. DO NOT USE THIS APPARATUS NEAR WATER.

6. CLEAN ONLY WITH A DRY CLOTH.

2

7. DO NOT BLOCK ANY OF THE VENTILATION OPENINGS. INSTALL IN ACCORDANCE WITH THE

MANUFACTURER’S INSTRUCTIONS.

8. DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS, HEAT REGISTERS,

STOVES, OR OTHER APPARATUS (INCLUDING AMPLIFIERS) THAT PRODUCE HEAT.

9. DO NOT DEFEAT THE SAFETY PURPOSE OF THE POLARIZED OR GROUNDING – TYPE PLUG.

A POLARIZED PLUG HAS TWO BLADES WITH ONE WIDER THAN THE OTHER. A GROUNDING

TYPE PLUG HAS TWO BLADES AND A THIRD GROUNDING PRONG. THE WIDE BLADE OR THE

THIRD PRONG IS PROVIDED FOR YOUR SAFETY. IF THE PROVIDED PLUG DOES NOT FIT

INTO YOUR OUTLET, CONSULT AN ELECTRICIAN FOR REPLACEMENT OF THE OBSOLETE

OUTLET.

10. PROTECT THE POWER CORD FROM BEING WALKED ON OR PINCHED PARTICULARLY AT

PLUGS, CONVENIENCE RECEPTACLES AND THE POINT WHERE THEY EXIT FROM THE

APPARATUS.

11. ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE MANUFACTURER.

12. USE ONLY WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE SPECIFIED

BY THE MANUFACTURER, OR SOLD WITH THE APPARATUS. WHEN A

CART IS USED, USE CAUTION WHEN MOVING THE CART/APPARATUS

COMBINATION TO AVOID INJURY FROM TIP-OVER.

13. UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN

UNUSED FOR LONG PERIODS OF TIME.

14. REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL. SERVICING IS REQUIRED

WHEN THE APPARATUS HAS BEEN DAMAGED IN ANYWAY, SUCH AS POWER-SUPPLY CORD

OR PLUG IS DAMAGED, LIQUID HAS BEEN SPILLED OR OBJECTS HAVE FALLEN INTO THE

APPARATUS, THE APPARATUS HAS BEEN EXPOSED TO RAIN OR MOISTURE, DOES NOT

OPERATE NORMALLY OR HAS BEEN DROPPED.

15. THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO

OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON APPARATUS.

16. MAINS PLUG IS USED AS DISCONNECT DEVICE AND IT SHOULD REMAIN READILY OPERABLE

DURING INTENDED USE. IN ORDER TO DISCONNECT THE APPARATUS FROM THE MAINS

COMPLETELY, THE MAINS PLUG SHOULD BE DISCONNECTED FROM THE MAINS SOCKET

OUTLET COMPLETELY.

17. BATTERY PACK OR BATTERY INSTALLED SHOULD NOT BE EXPOSED TO EXCESSIVE HEAT

SUCH AS SUNSHINE, FIRE OR THE LIKE.

18. DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH

THE SAME OR EQUIVALENT TYPE.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG

TO WIDE SLOT. FULLY INSERT THE PLUG TO MAIN POWER

SOCKET.

3

CAUTION

Note: This product complies with DHHS Rule 21 Subchapter J at date of manufacture.

Follow the advice below for safe and appropriate operation.

ON PROTECTION AGAINST LASER ENERGY EXPOSURE

o As the laser beam used in this compact disc player is harmful to the eyes, do not

attempt to disassemble the casing.

o Stop operation immediately if any liquid or solid object should fall into the cabinet.
o Do not touch the lens or poke at it. If you do, you may damage the lens and the player

may not operate properly.

o Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD

door is still open.

o This unit employs a laser. The use of controls or adjustment or performance of

procedures other than those specified here may result in exposure to hazardous
radiation.

ON PLACEMENT

• Do not use the unit in places which are extremely hot

,

cold, dusty or humid.

• Place the unit on a flat and even surface.

• Do not restrict the air-flow of the unit by placing it in a place with poor ventilation, by covering it

with a cloth or by placing it on a carpet.

ON CONDENSATION

• When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit.

• When there is condensation inside the unit, the unit may not function normally. Let it stand for
1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit before
use.

Should any trouble occur, remove the power source and refer servicing to qualified personnel.

PRECAUTION FOR USE

• UNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.

• DO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAINS

VOLTAGE AND ALL OTHER CONNECTIONS HAVE BEEN MADE.

• DO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF

SEVERAL CENTIMETERS AROUND THE UNIT FOR VENTILATION.

4

IMPORTANT NOTES

Avoid installing the unit in locations described below:

• Places exposed to direct sunlight or close to heat radiating appliances such as

electric heaters.

• Places subject to constant vibration.

• Dusty, humid or moist places.

COMPLIANCE WITH FCC REGULATIONS

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

NOTE : This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

PROTECT YOUR FURNITURE!!

This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving when you

operate the controls. These ‘feet’ are made from non-migrating rubber material specially

formulated to avoid leaving any marks or stains on your furniture. However certain types of oil

based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’ to

soften, and leave marks or a rubber residue on the furniture.

To prevent any damage to your furniture we strongly recommend that you purchase small

self-adhesive felt pads, available at hardware stores and home improvement centers everywhere,

and apply these pads to the bottom of the rubber ‘feet’ before you place the product on fine

wooden furniture.

5

LOCATION OF CONTROLS AND INDICATORS

MAIN UNIT

1) DIAL POINTER

2) LCD DISPLAY

3) POWER OFF/SOURCE/TUNER

MODE SELECTOR

4) POWER LED INDICATOR

5) VOLUME CONTROL KNOB

6) CD SKIP DOWN

BUTTON

7) FINALIZATION BUTTON

8) EXTRA BASS ON/OFF BUTTON

9) CD RECORD

BUTTON

10) CD TRAY

11) CD/TAPE/PHONO/AUX FUNCTION BUTTONS

12) RADIO BAND SELECTOR

13) FM STEREO LED INDICATOR

14) TUNING KNOB

15) REMOTE IR SENSOR

16) CD SKIP UP

BUTTON

17) CD STOP

BUTTON

18) CD TRAY OPEN/CLOSE

BUTTON

19) CD PLAY/PAUSE

BUTTON

20) 3.5MM AUX-IN JACK

21) 3.5 MM HEADPHONE JACK

22) TAPE FAST FORWARD / EJECT BUTTON

23) CASSETTE DOOR DUST COVER

24) 45 RPM RECORD ADAPTOR

25) 33/45/78 RPM SPEED SELECTOR

26) TONE ARM HOLDER

27) FM WIRE ANTENNA

28) LINE OUT SOCKET (L/R)

29) TURNTABLE AUTO STOP SWITCH

30) AC POWER CORD

31) TURNTABLE DUST COVER

Caution:

Usage of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service
personnel.
