Strong SRT5432 User Manual

SRT 5432

User Manual

1

Warranty Information

This product comes with a 12 month manufacturer’s warranty from the date of purchase.

This unit has a 30 days replacement warranty for manufacturing faults.

Within this period please return the faulty product with all its supplied accessories to
either the place of purchase or STRONG Australia accompanied by the original

purchase receipt.

After this 30 days period the unit must be returned to STRONG Australia for testing, and
if deemed faulty, will be repaired or replaced at the discretion of STRONG Australia Pty
Ltd. The faulty product can either be sent to STRONG Australia directly or via your

place of purchase for evaluation.

STRONG Australia will cover any reasonable costs incurred in returning the faulty

product for evaluation should the product be deemed as genuinely faulty. If the product is
found to have no fault, the costs incurred in delivering product to and from STRONG
Australia will be the customer.

Our goods come with guarantees that cannot be excluded under Australian Consumer

Law. You are entitled to a replacement or refund for major failure and for compensation

for any reasonably foreseeable loss or damage. You are also entitled to have goods

repaired or replaced if the goods fail to be of acceptable quality and the failure does not

amount to a major failure.

STRONG Australia

60 Wedgewood Rd, Hallam. VIC. 3803

Ph: [phone] FAX: [phone]

2

Content

Instruction .................................................................................................... 4

Reference .................................................................................................... 6

2. Product Overview .................................................................................. 7

2.1 Front Panel ............................................................................................ 7

2.2 Rear Panel .............................................................................................. 8

2.3 Remote Control Unit (RCU) .................................................................. 8

3. Installation .............................................................................................. 9

3.1 Manual scan ......................................................................................... 10

3.2 Auto scan ............................................................................................. 11

3.3 Antenna power setting ......................................................................... 11

3.4 Factory Default .................................................................................... 11

4. Edit Channel ........................................................................................ 11

4.1 TV/Radio Channels .............................................................................. 11

4.2 TV/Radio Favourites ............................................................................ 12

4.3 Sort Channels ....................................................................................... 12

4.4 User Channel List ................................................................................ 12

5. Settings .................................................................................................. 13

5.1 System Settings .................................................................................... 13

5.2 OSD Setup ........................................................................................... 14

5.3 Parental control .................................................................................... 14

5.4 Calendar ............................................................................................... 14

5.5 Color Settings ....................................................................................... 14

6 Clock and Timer Recording ................................................................. 15

7. Expansion.............................................................................................. 16

7.1 Games .................................................................................................. 16

7.2,USB ...................................................................................................... 16

7 About STB .............................................................................................. 18

8. Basic Operation .................................................................................... 18

3

8.1 Audio ................................................................................................... 18

8.2 EPG： .................................................................................................. 18

8.5 Subtitle. ................................................................................................ 19

8.6 Record. ................................................................................................. 19

8.7 Program Information ............................................................................ 19

9. Channel List ......................................................................................... 19

9.1 OK List................................................................................................. 19

9.2 Favorite List ......................................................................................... 20

10. USB Control ....................................................................................... 20

10.1 Recording and Timeshift .................................................................... 20

10.2 PVR List ............................................................................................. 20

11. Additional Information ...................................................................... 21

11.1 Trouble Shooting ............................................................................... 21

12. Technical Specifications ................................................................... 20

Instruction

 Safety Precaution

This STB has been designed and manufactured to satisfy the
international safety standards. Please read the following safety
precautions carefully before operating this receiver.

 Main Supply:

Before operating, please check the units operating voltage is
100-240V AC 50/60HZ

4

Overload:
Do not overload a wall outlet, extension cord or adapter, neither
use damaged power cord or touch it with wet hand as this may
result in electric shock.

Liquid:
The receiver shall not be exposed to dripping or splashing water,
and that no objects filled with liquids, such as base, shall be
placed on the apparatus.

Ventilation:
Keep the slots on top of the receiver uncover to allow sufficient
airflow to the unit. Do not put the receiver on soft furnishings or
carpets. Do not expose the receiver to direct light or do not place
it near a heater or in humid conditions. Do not stack other
electronic equipments on top of the receiver.

Cleaning:
Plug out the receiver from the wall outlet before cleaning. Clean
the receiver by a soft cloth or mild solution of washing-up liquid
(no solvents).

Connection:
Disconnect the receiver from the mains when you connect it to
ANT or disconnect it from ANT. Failure would possibly cause
damage to the ANT.

Location:

5

Put the receiver indoor in order to avoid lightening, raining or
sunlight.

Uncover:
Do not remove the cover, to reduce the risk of electric shock.
Contact qualified and licensed service personnel to repair the
receiver, or contact your dealer.

Reference

Auto Search
Manual Search
PAL/NTSC Conversion
True full Color (32 bits) on screen display (OSD)
2 menu languages supported:English and Thai
Multi-language audio supported
Multi-language DVB Subtitle output
7 days Electronic Program Guide (EPG)
Teletext output through VBI and OSD.
USB 2.0 Interface

Softwareupdate:

If new software becomes available for this model, it can be dow
nloaded from our website (www.strong.com.au) and then placed
onto a USB. Plug in the USB into the USB port on the unit and
then go to:

Menu System Software UpdateUSB Upgrade

6

ProductOverview

2.1 Front Panel

1. USB2.0：One USB 2.0 Host Port.

2. Power /Signal light：Power /signal indicator.

3. Display：It displays channel information. In standby mode it displays local

time.

4. Power button：Switch between operation and standby modes.

5. ▲：Change channel in viewing mode and move the cursor up in menu

mode.

6. ▼；Change channel in viewing mode and move the cursor down in menu
mode

7

2.2 Rear Panel

1）ANT IN：Connect the antenna cable.
2）ANT OUT：Loop out to pass signal through
3）COAXIAL：Digital Audio output (Optical).

4）DV-OUT ：Connect to the TV using an HDMI cable (not supplied)
5）AUDIO（R/L）/ VIDEO：Connect to the TV using RCA cabling

6) DC-5V：Connect to the power using power adapter.

Note: For best results, use HDMI cable and RG6 Quad
Shielded antenna cabling

2.3 Remote Control Unit (RCU)

You can control this receiver by this remote controller with full function.

1. POWER: Switch between operation and standby modes.

2. MUTE: Mute audio.

3. ▶|| : Play/Pause .

4. USB/■ : enter USB menu/stop function.

5. ●: Record.

6. INFO：Display the programme information.

7. IWW/ XXI:Previous/Next.

8. WW:

9. XX:

Rewind

Fast forward.

8
