Digital High Definition Cable Receiver
SRT 3000
Installation Instructions
Installationsanleitung Bruger manual Pokyny k instalaci Pokyny k inštalácii Ръководство за бърз монтаж Telepítési Utasítás
Supplied by STRONG & Co, Japan Represented by
STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna
Austria
Email: support_at@strong.tv
23 May 2016 13:43
Your receiver is delivered with USB multimedia support. After downloading the optional software for recording via USB from our webshop at www.strong.tv, the receiver can be upgraded to support the recording function via USB. This user manual describes the full functionality including the recording function and may not be applicable if the software for recording via USB has not yet been installed.
Licenses
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH THE MPEG-2 STANDARD FOR ENCODING V IDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green Circle, Suite 400E, Greenwood Village, Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited.
This product contains one or more programs protected under international and U.S. copyright laws as unpublished works. They are confidential and proprietary to Dolby® Laboratories. Their reproduction or disclosure, in whole or in part, or the production of derivative works therefrom without the express permission of Dolby® Laboratories is prohibited. Copyright 2003-2009 by Dolby® Laboratories. All rights reserved.
English
27 May 2016 17:10
1
Table of Content
1.0 Introduction |
3 |
1.1 Safety Instructions |
3 |
1.2 Storage |
3 |
1.3 Equipment Set-up |
3 |
1.4 Accessories |
4 |
1.5 Usage of external USB devices |
4 |
2.0 Your Receiver |
4 |
2.1 DEFAULT PIN: 1234 |
4 |
2.2 Front Panel |
4 |
2.3 Rear Panel |
4 |
2.4 Remote Control |
5 |
2.5 Installing the batteries |
5 |
2.6 Using the remote control |
5 |
3.0 Connection |
6 |
3.1 Connecting to cable TV |
6 |
3.2 Connecting to TV with HDMI cable |
6 |
3.3 Connecting to TV with SCART cable |
6 |
3.4 Connecting to a Digital Audio Amplifier with S/PDIF |
6 |
3.5 Connecting to a Digital Audio Amplifier and TV using HDMI |
6 |
3.6 Connecting a USB storage device |
6 |
4.0 Starting up for the first time |
7 |
4.1 DVB-C Installation |
7 |
5.0 Quick guide to using your receiver |
7 |
6.0 Operation |
8 |
6.1 Changing channels |
8 |
6.2 Info Banner |
8 |
6.3 Selection of audio language |
8 |
6.4 Teletext |
8 |
6.5 Subtitles |
9 |
6.6 Timeshift* |
9 |
6.7 EPG (Electronic Programme Guide) |
9 |
6.8 Instant Recording* |
9 |
7.0 Main Menu |
9 |
7.1 Edit Channel |
9 |
7.2 Installation |
11 |
7.3 System Setup |
12 |
7.4 Tools |
14 |
7.5 Media* |
15 |
8.0 Troubleshooting |
17 |
9.0 Technical Specifications |
18 |
STRONG declares that this item complies with the basic requirements and other relevant regulations of directives 2004/108/EC and 73/23/EC, RoHS 2002/95/EC
Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby Audio and the double-D symbol are registered trademarks of Dolby Laboratories. All other product names are trademarks or registered trademarks of their respective owners.
© STRONG 2016. All rights reserved.
2
1.0Introduction
1.1Safety Instructions
DO NOT INSTALL YOUR RECEIVER:
In a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a surface which might obstruct the ventilation slots.
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
To direct sunlight or any other equipment that generates heat; to rain or intense moisture; to intense vibration and to any shock which may cause permanent damage to your receiver or to any magnetic objects, such as loudspeakers, transformers, etc.
Do not use a damaged power cord. It may cause a fire or an electric shock. Do not touch a power cord with wet hands. It may cause an electric shock.
When the receiver is not used for a long period of time, you should unplug the power cord from the wall socket.Do not use alcohol or ammonia based liquids to clean the receiver. If you wish, you may clean your receiver with a soft lint-free cloth slightly made damp with a mild soap solution, and only after disconnecting from the mains voltage supply. Make sure no foreign objects fall through the ventilation slots because this could cause fire or an
electric shock.
Do not place any objects on top of the receiver because this might prevent proper cooling of the components inside.
Safety Precautions
Never try to open the receiver. It is dangerous to touch the inside of the receiver due to high voltages and possible electrical hazards. Opening the receiver will void the warranty of the product. Refer all maintenance or servicing to suitably qualified personnel.
When you are connecting cables, be sure that the receiver is disconnected from the mains supply voltage. Wait a few seconds after switching off the receiver before you move the receiver or disconnect any equipment.
It is a necessity that you only use an approved extension and compatible wiring that is suitable for the electrical power consumption of the installed equipment. Please ensure that the electrical power supply corresponds with the voltage on the electrical identification plate at the back of the receiver.
If the receiver does not operate normally even after strictly following the instructions in this user manual, it is recommended to consult your dealer.
1.2 Storage
Your receiver and its accessories are stored and delivered in a packaging designed to protect against electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep the packaging away from children. When transporting the receiver from one place to another or if you are returning it under warranty conditions, make sure to repack the receiver in its original packaging with its accessories. Failing to comply with such packaging procedures could damage the product and void your warranty.
1.3 Equipment Set-up
We recommend you consult a professional installer to set up your equipment. Otherwise, please follow the instructions below:
Refer to the user manual of your TV.
Make sure that the HDMI cable is in a good condition.
If you use TV SCART connection, use then well shielded SCART cable.
This manual provides complete instructions for installing and using this receiver. The following symbols will serve as follow.
Warning Tips MENU
Move to
English
3
1.4 Accessories
Installation Instructions1 remote control unit2x batteries (AAA type)
Warning: The batteries should not be recharged, disassembled, electrically short-circuited, be mixed or used with other types of batteries. If rechargeable accumulators instead of batteries are going to be used (e.g. NiMH), we recommend using types with low self-discharge to ensure long time operation of your remote control.
1.5 Usage of external USB devices
It is recommended to use USB 2.0 storage devices or higher. If your device is not compatible to USB 2.0 specifications, recording, playback and other multimedia functions of the receiver might not work properly.*
To ensure best performance of your USB storage device please format it via your receiver (through the menu “Media”) to FAT32 system. Other file systems are not supported by the receiver. However, it is possible to use already NTFS formatted disks.
STRONG cannot guarantee compatibility with all types of USB storage devices.
If you are going to use external USB HDDs (Hard Disk Drives), please consider that power specifications may exceed the supported output of your receiver (max. 5 V/800 mA). If so, please connect your USB HDD to an according external power adapter.
It is advised not to store important information on USB storage devices used with the receiver. Always make backups of data on your USB storage device before using it with this receiver. STRONG will not take responsibility for any loss of information or circumstances caused by loss of information.
* This user manual describes the full functionality including the recording function and may not be applicable if the software for recording via USB has not yet been installed.
2.0Your Receiver
2.1DEFAULT PIN: 1234
2.2Front Panel
|
IR sensor |
Fig. 1 |
1. |
Point your remote control towards this sensor. |
|
2. |
Display |
Indicates current time in STANDBY mode or current channel number in OPERATING |
|
Mode indicator |
mode |
3. |
RED indicates that the receiver is in STANDBY mode. |
|
|
USB |
GREEN indicates that the receiver is in OPERATING mode. |
4. |
Connector for USB storage devices. |
2.3 Rear Panel
|
CABLE IN |
Fig. 2 |
1. |
Connect your receiver to the wall connector provided by the cable operator |
|
2. |
CABLE OUT |
Connect your receiver to another digital receiver or to a TV to keep using its internal |
|
S/PDIF COAX. |
(analogue) tuner (loop through function) |
3. |
Connect your receiver to a digital home theatre, AV receiver or digital audio |
|
|
HDMI |
amplifier. |
4. |
Connect your receiver with your TV set using an HDMI cable. |
|
5. |
TV SCART |
Connect your receiver with your TV set using a SCART cable. |
4
