Terrestrial Receiver SRT 8101/8105
User manual
Manuel d’Utilisateur
Manuale Utente
Manual del usuario
Manual do Usuário
Felhasználói kézikönyv
Instrukcja obsługi
Руководство пользователя
Digital High Definition
Picture similar
PART 1 • English
TABLE OF CONTENTS
1.0 INTRODUCTION 2
1.1 Safety Instructions 2
1.2 Storage 2
1.3 Equipment Set-up 3
1.4 Accessories 3
1.5 Usage of external USB devices 3
2.0 YOUR RECEIVER 3
2.1 PIN-CODE DEFAULT: 0000 3
2.2 Front Panel 3
2.3 Rear Panel 4
2.4 Remote Control 4
3.0 CONNECTION 5
3.1 Connecting to a Terrestrial Antenna 5
3.2 Connecting to TV with HDMI cable 5
3.3 Connecting to TV with SCART cable 5
3.4 Connecting to TV with Cinch cable 5
3.5 Connecting to a Digital Audio Amplifier with S/PDIF 5
3.6 Connecting to a Digital Audio Amplifier and TV using HDMI 5
3.7 Connecting a USB storage device 6
4.0 STARTING UP FOR THE FIRST TIME 6
5.0 QUICK GUIDE TO USING YOUR RECEIVER 7
6.0 OPERATION 7
6.1 Changing channels 7
6.2 Info Banner 8
6.3 Selection of audio language 8
6.4 Teletext 8
6.5 Subtitles 8
6.6 Time Shift 8
6.7 EPG (Electronic Programme Guide) 9
6.8 Instant Recording 9
7.0 MAIN MENU 9
7.1 Edit Channel 9
7.2 Installation 11
7.3 System Setup 12
7.4 Tools 14
7.5 Games 16
7.6 Media+ 16
8.0 TROUBLESHOOTING 17
9.0 TECHNICAL SPECIFICATIONS 18
STRONG declares that this item complies with the basic requirements and
other relevant regulations of directives
CE 2004/108/EEC and 73/23EEC; RoHS 2002/95EEC
Subject to alterations. In consequence of continuous research and
development technical specifications, design and appearance of products
may change. All product names are trademarks or registered trademarks of
their respective owners.
© STRONG 2011. All rights reserved.
07 Oct 2011 19:20
English
1
PART 1 • English
1.0 INTRODUCTION
1.1 Safety Instructions
DO NOT INSTALL YOUR RECEIVER:
In a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a surface
which might obstruct the ventilation slots.
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
Safety Precautions
1.2 Storage
Your receiver and its accessories are stored and delivered in a packaging designed to protect against
electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep
the packaging away from children. For transporting the receiver from one place to another or if you
are returning it under warranty conditions, make sure to repack the receiver in its original packaging
with its accessories. Failing to comply with such packaging procedures could void your warranty.
To direct sunlight or any other equipment that generates heat; to rain or intense
moisture; to intense vibration and to any shock which may cause permanent damage
to your receiver or to any magnetic objects, such as loudspeakers, transformers, etc.
Do not use a damaged power cord. It may cause a fire or an electrical shock. Do not
touch a power cord with wet hands. It may cause an electric shock.
When the receiver is not used for a long period of time, you should unplug the power
cord from the wall socket.
Do not use alcohol or ammonia based liquids to clean the receiver. If you wish, you
may clean your receiver with a soft lint-free cloth slightly made damp with a mild
soap solution, only after disconnecting from the mains voltage supply. Make sure no
foreign objects fall through the ventilation slots because this could cause fire or an
electric shock.
Do not place any objects on top of the receiver because this might prevent proper
cooling of the components inside.
Never open the receiver cover. Doing so will void the warranty. It is dangerous to touch
the inside of the receiver due to high voltage currents and possible electrical hazards.
Refer all maintenance or servicing to qualified service personnel.
When you are connecting cables, be sure that the receiver is disconnected from the
mains supply. Wait a few seconds after switching off the receiver before you move the
receiver or disconnect any equipment.
Use only approved extension cords with compatible wiring that is suitable for the
electrical power consumption of the installed equipment. Please ensure that the
electrical power supply corresponds with the voltage on the electrical identification
plate at the back of the receiver.
If the receiver does not operate normally even after strictly following the instructions in
this user manual, it is recommended to consult your dealer.
2
PART 1 • English
1.3 Equipment Set-up
We recommend you consult a professional installer to set up your equipment. Otherwise, please
follow the instructions below:
This manual provides complete instructions for installing and using this receiver. The following
symbols will serve as follow.
WARNING Indicates warning information.
Tips Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver. (Bold Character)
Move to Represents a menu item within a window. (Italic Character)
1.4 Accessories
NOTE: The batteries should not be recharged, disassembled, electrically short-
Refer to the user manual of your TV and antenna.
Make sure that the HDMI cable and outdoor components are in a good condition.
Use only a HDMI 1.3 cable or higher for maximum performance.
If you use TV SCART connection, use then well shielded SCART cable (applies only to
SRT 8105).
1. User Manual
2. 1 Remote control unit
3. 2x Batteries (AAA type)
circuited, be mixed or used with other types of batteries.
English
1.5 Usage of external USB devices
It is recommended to use USB 2.0 storage devices or higher. If your device is not
compatible to USB 2.0 specifications, recording, playback and other multimedia
functions of the receiver might not work properly.
To ensure best performance of your USB storage device please format it by this
receiver (menu “Media+”) to FAT32 system. Other file systems are not supported by
the receiver. However, it is possible to use already NTFS formatted disks. STRONG
cannot guarantee compatibility with all types of USB storage devices.
It is advised not to store important information on USB storage devices used with
the receiver. Always make backups of data on your USB storage device before using it
with this receiver. STRONG will not take responsibility for any loss of information or
circumstances caused by loss of information.
2.0 YOUR RECEIVER
2.1 PIN-CODE DEFAULT: 0000
2.2 Front Panel
Fig. 1
3
PART 1 • English
1. 4 digits display: Indicates current time in STAND-BY mode*
2. USB: Connector for USB devices.
3. IR sensor: Point your remote control towards this sensor.
4. Mode indicator: RED indicates that the receiver is in STAND-BY mode.
*Only SRT 8105
Indicates current channel number in OPERATING mode*
GREEN indicates that the receiver is in OPERATING mode.
2.3 Rear Panel
1. ANT IN To connect to your antenna for the reception of broadcast signal.
2. TO TV To connect to the terrestrial antenna input of your TV set.
3. S/PDIF Coaxial To connect your receiver to a digital audio amplifier.
4. HDMI To connect your receiver with your TV set using a HDMI cable.
5. TV SCART To connect your receiver with your TV set using a SCART cable.*
6. Video Connector To connect your receiver with your TV set using a cinch cable.*
7. Audio L/R Connector
To connect your receiver with your TV set using a cinch cable.*
8. Power Cord Your receiver requires a voltage of 220~240V AC (Auto-
*Only SRT 8105
This connection will allow you to watch analogue terrestrial
programmes via the tuner in your TV.
selectable), 50/60Hz ±5%. Check the local power specification
before connecting your receiver to the wall outlet.
2.4 Remote Control
1. q Turns the receiver On/Standby
2. ! Mutes audio output of the receiver
3. PG+/PG Page up/down and 10 channels steps in channel list mode
4. DTV/VCR No function
5. INFO Shows the actual channel information
6. VOL+/VOL Volume up/down
7. MENU Opens the main menu, In menu you will get one step back
8. EXIT Exits from the menu or sub-menu
9. pq Menu Off: Change channel to previous/next.
10. tu Menu Off: Increases/decreases the volume level.
11. OK Menu Off: Displays the current channel list
12. RECORD Records the TV programme to the connected storage device
13. TIMESHIFT Activates the time shift function
14. 0~9 Channel selection or value input
15. EPG Shows the EPG (Electronic Programme Guide) in TV mode
16. RECALL Back to previous shown channel
4
Menu On: Moves the cursor up/down.
Menu On: Change settings for specific Menus
Menu On: Activates the highlighted menu item.
Fig. 2
Fig. 3
PART 1 • English
17. AUDIO Sets the current audio channel to left, right or stereo
18. TV/RADIO Toggles between TV or RADIO mode
19. FAV Favourite group selection
20. FILE Shows the Media Player list
21. TTX Shows Teletext on OSD (On Screen Display)
22. SUBTITLE Shows list of subtitled languages
23. 5 6 Fast rewind / Fast forward
24. Coloured buttons for Multimedia and Teletext functions
3.0 CONNECTION
3.1 Connecting to a Terrestrial Antenna
To receive broadcast signal, your terrestrial indoor or outdoor antenna must be connected to
the ANT IN connector on the back of the receiver. Use a properly shielded antenna cable and
suitable connectors.
The TO TV connector allows you to loop the antenna signal to a second receiver or TV set.
3.2 Connecting to TV with HDMI cable
The TV set shall be connected with the receiver using a good quality HDMI 1.3 or higher cable. This
connection gives the highest possible quality.
3.3 Connecting to TV with SCART cable
SRT 8105 is also equipped with a SCART connector; alternatively, the TV set can be connected to the
receiver using a good quality SCART cable.
3.4 Connecting to TV with Cinch cable
TV sets without SCART or HDMI input(s) can be connected to the receiver using suitable cinch
cables. Connect one end of the cable to the Audio L, R and VIDEO connectors on the back of SRT
8105. Connect the other end to the respective inputs on your TV set.
3.5 Connecting to a Digital Audio Amplifier with S/PDIF
By connecting your receiver to a digital amplifier or home theatre system, you can enjoy the best
possible sound quality and multi-channel audio (depending on broadcast). Connect your Digital
Audio Amplifier or home theatre system with a suitable cinch cable to the S/PDIF connector on the
back of the receiver.
3.6 Connecting to a Digital Audio Amplifier and TV
using HDMI
Fig. 4
Fig. 4
Fig. 4
Fig. 4
Fig. 5
Fig. 6
English
5
PART 1 • English
By connecting your receiver to the latest digital amplifiers or home theatre systems with HDMI
connections, you will enjoy the best possible sound quality and multi-channel audio (depending on
broadcast). Connect the HDMI output of the receiver to an input of your amplifier, and then connect
the HDMI output of the amplifier to your TV set. Select the correct input on your amplifier to watch
and listen to programmes.
3.7 Connecting a USB storage device
NOTE: We recommend the use of a hard disk drive USB 2.0 or higher for recording
For proper functioning of Time Shift and recording functions, a fast USB device (such as a hard
disk drive) is needed. Interrupted playback or a distorted picture during playback or Time Shift are
indications for a low device speed. STRONG cannot guarantee proper functioning of recoding and or
Time Shift functions with all USB devices.
4.0 STARTING UP FOR THE FIRST TIME
If you use your receiver for the first time, the Welcome “Easy install” menu appears. Use pq to move
the highlight to the setting you wish to alter and use tu to change values. Start by selecting your
language using tu. Once you have selected your language, press q to move the highlight to Region.
Select your region using tu.
Subtitle: Select On to display subtitles per default, Select Off to hide subtitles
Aspect Mode: Use this option to select the aspect ratio of your TV and the preferred
Scan mode: Select All to store scrambled and free to air channels or select Free to store
NOTE: Scrambled channels you cannot watch with this receiver.
Connection: Use this option to select the connection to your TV set. Select HDMI or
Once all settings are made, move the highlight to OK and press OK to continue.
The receiver will now advance to the Aerial Adjustment screen.
This part of the wizard is of great help when setting up your antenna system.
Use pq to move the highlight to the setting you wish to alter and use tu to change values.
The following settings are available:
Antenna Power: Set to On if you use an active antenna. When set to On, 5 V will be present on
Beeper: Select On for an audible indication of signal reception. Off turns the
6
and play back of TV events.
per default.
conversion method. Options are: Auto (automatic detection of aspect ratio),
4:3 Panscan (Displays 16:9 widescreen broadcasts full screen on your 4:3 TV),
4:3 letterbox (black bars on top and under the picture on a 4:3 TV) and 16:9
(use this setting for 16:9 TV sets).
only free to air channels.
SCART. If you are using a cinch cable then this selection is not important
(applies only to SRT 8105).
the ANT IN connector of the receiver. Select Off for passive antennas.
beeper off.
Fig. 7
PART 1 • English
Channel No.: Select a channel that is known to carry a broadcast in your region. The Signal
Once all settings are made, press OK to start scanning.
The receiver will now search for all available channels. Once scanning is finished, the receiver
switches to viewing mode.
TIP: In case the Welcome “Easy install” menu does not appear after switching on
5.0 QUICK GUIDE TO USING YOUR RECEIVER
We at STRONG understand that you can’t wait to enjoy your new high definition digital terrestrial
receiver. The following quick guide will make you familiar with the basic operation of this device. We
do, however, advice you to read the full manual to get the best performance from your receiver.
To turn your receiver ON or to Standby, use the q button on the remote control.
Choose the desired channel with the pq buttons. Alternatively, you can digit the channel number
with the 0~9 buttons on the remote control. Or press OK in viewing mode to display the channel list.
The volume can be adjusted with the tu buttons.
6.0 OPERATION
Your new receiver is equipped with several features to make watching TV a true pleasure. This
paragraph describes these features. Please also read chapter 7.0 to get familiar with the menu of
your receiver.
6.1 Changing channels
Your new receiver is equipped with four ways to change channels.
6.1.1 Direct access via 0~9 buttons
To gain direct access to a certain channel, simply input its number with the 0~9 keys on the remote
control. Channel numbers can be up to four digits long. Entering a number with less than four digits
is possible. Just wait a few seconds and your receiver will switch to the selected channel or press OK
immediately after selecting the channel number.
6.1.2 Channel list
Press OK in viewing mode to display the Channel List. Use pq in the Channel List to highlight your
channel of choice and press OK once to select the highlighted channel. Press OK again to leave the
Channel List.
Strength and Signal Quality bars give a visual indication of the reception.
Adjust your antenna to obtain maximum signal strength and quality.
the receiver the first time, reset the receiver to factory settings by pressing the
MENU button and selecting Load Factory Setting in submenu Tools. (Default
PIN 0000)
Via direct access using the 0~9 buttons.
Via the channel list trough OK button.
Via the PG+ and PG- keys.
Via the pq keys.
English
7
PART 1 • English
TIP: Use tu to toggle between the All Channel list and favourite lists or press
6.1.3 Using the pq or PG+/PG- keys
p switches to the next channel.
q switches to the previous channel.
PG+ switches to the next 10 channels.
PG- switches to the previous 10 channels.
6.2 Info Banner
While watching TV you can press the INFO button any time to get information about the current
channel and event*. Press INFO twice for technical details about the current channel.
*Event information is displayed when available. Availability depends on broadcast.
6.3 Selection of audio language
Some channels support a choice of audio formats and/or languages. To select another audio stream,
press AUDIO in viewing mode. A list with available audio streams will now be displayed. Use pq to
select the desired stream and confirm with OK. The audio channel as stereo, mono, left and right can
be selected with the tu buttons.
6.4 Teletext
Your receiver includes a fully featured Teletext. To access Teletext, press the TTX button in viewing
mode and use the 0~9 buttons to input the number of the page you wish to see. The coloured
buttons of the remote control allow you to jump to selected pages directly, as indicated on the bottom
of the teletext screen. Use the pq buttons to select one page up or down, use tu buttons to select
subpages. Press EXIT or TTX to get back to viewing mode.
6.5 Subtitles
Some channels support a choice of subtitle languages. Press SUBTITLE in viewing mode to display a
list of available subtitle languages. Select your subtitle of choice with pq and press OK to confirm.
Press EXIT to leave without making changes.
6.6 Time Shift
Time Shift allows you to pause live broadcasts and resume playback later. Press TIMESHIFT in
viewing mode to activate this mode. On screen will appear a message Timeshift On, live TV keeps
playing. To pause press 2 (PAUSE) button and press u (PLAY) to resume Time shifted playback.
Press 5 6 for Fast rewind/Fast forwards. Press 3 (STOP) to return to live TV.
Press EXIT to exit Time Shift mode.
NOTE: Time Shift needs a connected USB storage device with sufficient free space
FAV for a list of available favourite lists.
and sufficient speed in order to work properly.
8
PART 1 • English
6.7 EPG (Electronic Programme Guide)
The Electronic Programme Guide is a very useful function that allows you to view event schedules
and information and to mark programmes for recording. To access the EPG, press the EPG button
in viewing mode. Use pq to select the desired channel and tu to select the desired event. Press
OK to display detailed information on the selected event. Use EXIT to quit the detailed information
screen. Press RED to get to the Step Time function. Use tu to select the desired step and OK to
execute it. Press EXIT to quit the Step Time function. Press GREEN to set a timer for a selected event.
Refer to section 7.3.4 for details on the timer function.
NOTE: Availability of EPG data depends on broadcast.
6.8 Instant Recording
Your new receiver allows you to make an instant recording of the programme you are watching.
Simply press 4 to start the recording. To enter the duration for the recording, press 4 again. Use the
0~9 keys to input the desired recording time.
During the recording a recording sign will be shown on the upper right of your TV screen. To stop the
recording, press 3. Select Yes and press OK again to stop the recording.
*Please connect an USB storage device with sufficient free space before you start a recording.
7.0 MAIN MENU
The main menu gives you access to settings, multimedia functions and built in games. To access the
main menu, press MENU in viewing mode. The main menu consists of the following sub menus:
Edit Channel, Installation, System Setup, Tools, Game and Media+.
Throughout the main menu, MENU or EXIT can be used to get back to the previous screen.
7.1 Edit Channel
Use pq to select Edit Channel and press OK or u to enter.
Use pq to highlight the desired sub menu and press OK to select.
Press EXIT or t to get back to the main menu.
7.1.1 TV Channel List
In Edit Channel menu select TV Channel List with pq and press OK to enter.
Use tu to change the channel group (assumed you have already set up favourite groups).
Select the desired channel with pq. Press OK to view the selected channel in the preview box.
7.1.1.1 Adding channels to favourite lists
Channels from the TV Channel List can be added to up to 8 different favourite groups. Press FAV
while in TV Channel List to access this function. The FAV sign on the top of the screen will move up
to indicate that the favourite function is selected. Use pq to select a channel you wish to add to
a favourite group. When the highlight is on the desired channel, press OK. A list with all available
favourite lists will now pop up. Use pq to select the favourite list you wish to add the channel to and
press OK, press EXIT to finalize the process. Favoured channels will be marked with a heart symbol.
English
9
PART 1 • English
Once all changes are made, press EXIT twice. A confirmation banner will pop up. Select Yes to save
the changes or No to discard.
7.1.1.2 Locking channels
Locked channels can only be watched after entering the pin code. (DEFAULT PIN: 0000)
To lock or unlock a channel, press RED while in TV Channel List. The red Lock sign on the top of the
screen will move up to indicate that the Lock function is selected. Use pq to select the desired
channel and press OK to lock or unlock it. You are asked to input the pin code. (DEFAULT PIN: 0000)
Locked channel will be marked with the symbol. Locking/unlocking multiple channels in one
session is possible. Once all changes are made, press EXIT twice. A confirmation banner will pop up.
Select Yes to save the changes or No to discard. Locking/unlocking multiple channels in one session
is possible.
7.1.1.3 Skipping channels
Channels marked with Skip will be skipped when zapping channels with the pq buttons. Despite
that, these channels are still available from the channel list.
To mark channels for skipping, press GREEN while in TV Channel List. The Skip symbol on the top of
the screen will move up to indicate that the Skip function is selected. Use pq to select the desired
channel and press OK to mark or unmark it for skipping. Channels set for skipping will be marked
with the symbol. Once all changes are made, press EXIT twice. A confirmation banner will pop up.
Select Yes to save the changes or No to discard.
7.1.1.4 Moving channels
To enable the Move function, press YELLOW while in TV Channel List. The Move symbol on the top of
the screen will move up to indicate that the Move function is selected. Use pq to select the desired
channel and press OK to select it. You can now move the selected channel up or down the channel
list using pq. Once the channel is on the desired position, press OK again. The channel is now fixed
on its new position. Once all changes are made, press EXIT twice. A confirmation banner will pop up.
Select Yes to save the changes or No to discard.
7.1.1.5 Editing channels
The Edit function allows you to Sort, Rename or Delete channels. To enter the Edit menu, press BLUE
while in TV Channel List. The Edit Channel menu will appear.
Sort
Press RED to enter the Sort menu.
Use pq to select the desired sorting method and press OK to confirm.
Possible methods are:
Name (A-Z): Sorting in alphabetical order from A to Z.
Name (Z-A): Sorting in alphabetical order from Z to A.
Free/Scramble: First in the list will be Free-To-Air channels.
Lock: All unlocked channels will placed first in the list.
Default: Sorting by searched Order (from lowest to highest frequency or by LCN
numbering).
10
PART 1 • English
Rename
Press GREEN in Edit Channel to enable the Rename function. The Rename sign will move up to
indicate that Rename is selected. Use pq to highlight the desired channel and press OK to select it.
A text field will now pop up at the right of the screen. Use tu pq to select the desired characters
and enter them with OK. Once you have finished editing, press BLUE to enter the changes. Once all
changes are made, press EXIT twice. Select Yes to save the changes or No to discard.
Delete
Press BLUE in Edit Channel to enable the Delete function. The Delete sign will move up to indicate
that Delete is selected. Use pq to highlight the desired channel and press OK to mark it for deletion.
The receiver asks you to enter the pin code. Once you have marked all channels you wish to delete,
press EXIT twice. A confirmation banner will be displayed. Select Yes to delete the marked channels
or No to cancel.
7.1.2 Radio Channel List
Basically, the operation of the Radio Channel List is the same as in the TV Channel List. The only
difference is that in Radio Channel List there is no video information, so it will always display the radio
logo at the right preview screen.
7.1.3 Delete all
Use this menu to delete all stored channels. Select Delete All with pq and press OK. The receiver
asks you to enter the pin code. (Default pin:0000). In the confirmation window select Yes with tu
and press OK to delete or select No to cancel.
WARNING! The Delete all function will permanently delete all current channels and all
favourite lists from your receiver, and you are not able to leave the menu until
you search for channels again.
7.2 Installation
7.2.1 Auto Scan
Use pq to select Installation and press OK or u to advance.
Select Auto Scan with pq and press OK to enter.
Use tu to toggle between FTA Only Yes or No. When FTA Only is set to Yes, scrambled channels
won’t be stored in the channel list. Use pq to highlight Search. Now press OK to start auto scan.
The receiver will store all newly found channels in the channel list.
7.2.2 Channel Scan
Use pq to select Installation, press OK or u to advance.
Use pq to select Channel Scan and press OK to enter.
Use tu to toggle between available scan modes: By Channel and By Frequency.
If By Channel is selected, use the cursor buttons to select Scan Band and Channel No. If By Frequency
is selected, use the cursor buttons to select Frequency and Bandwidth. Highlight Search and press OK
to start scanning. Newly found channels will be stored in the channel list.
English
11
PART 1 • English
7.2.3 Antenna Adjustment
Use pq to select Installation, press OK or u to advance.
Use pq to select Aerial Adjustment and press OK to enter.
Use pq move the highlight to the setting you wish to alter and use tu to change values.
The following settings are available:
Antenna Power: Set to On if you use an active antenna. When set to On, 5 V will be present on
Beeper: Select On for an audible indication of signal reception. Off turns the
Channel No.: Select a channel that is known to carry a broadcast in your region. The Signal
Press EXIT to leave the Antenna Adjustment screen.
7.2.4 LCN (Logical Channel Numbering)
If LCN (Logical Channel Numbering) is activated and an LCN signal is provided by the operator,
channels will be stored in an operator defined order. Set LCN to On to activate operator defined
channel numbering or Off to store channels in found order.
7.3 System Setup
This menu allows you to manage the system settings of your receiver. It consists of the following submenus: Language, TV System, Local Time Setting, Timer Setting, Parental Lock, OSD Setting, Favourite
and Auto Standby.
Press pq to highlight desired menu and press OK advance to the next screen. Use pq to move
the highlight to the desired setting. Values can be changed with tu. Press EXIT to leave.
7.3.1 Language
This menu allows you to set up your language preferences.
Language: Use tu to select the desired language for the On Screen Display.
First Audio: Use tu to select the desired Audio language.
Second Audio: Use tu to select a language that will be played when the language selected
Subtitle Language: Use tu to select the preferred subtitle language.
Subtitles: Use tu to select the preferred subtitle type to be displayed automatically.
Teletext: Use tu to select the preferred teletext language (when available.)
7.3.2 TV System
Use this menu to match your receiver to your TV set. The following settings are available:
Video Resolution: Toggles between 576i up to 1080p. Please use a setting that matches your
NOTE: Selection is only applicable on HDMI.
the ANT IN connector of the receiver. Select Off for passive antennas.
beeper off.
Strength and Signal Quality bars give a visual indication of the reception.
Adjust your antenna to obtain maximum signal strength and quality.
at First Audio isn’t available.
TV’s specifications. After a selection is made, you will be asked to confirm.
12
PART 1 • English
Aspect Mode: Use this option to select the aspect ratio of your TV and the preferred
Connection: Use this option to select the connection to your TV set. Select HDMI or TV
Digital Audio Output: Toggles between PCM and Bitstream output. When PCM is selected, all audio
7.3.3 Local Time Setting
Here you can set up your region and time zone.
Region: Use tu to select the region you live in.
GMT Usage: Set to On for broadcaster defined time or to Off to input time and
GMT Offset: Allows you to adjust the time zone you live in. This option is only available
Summer Time: Select Off or On to add one hour extra for summer time during the summer.
Date: Date and Time settings are available only when GMT Usage is set to Off. Use
Time: Date and Time settings are available only when GMT Usage is set to Off. Use
7.3.4 Timer Setting
This menu allows you to set up to 8 timed events for recording or waking up the receiver.
Use pq to select Timer Setting from the System Setup menu and press OK to enter.
The receiver will display a list with 8 timers, followed by their respective status. Select the timer you
wish to set or change with pq and press OK to proceed.
The timer setup menu will now be displayed.
The following settings are available:
Timer Mode: Choose between Off (Timer inactive), Once or Daily (Timer will be executed
Timer Service: Choose between Channel (Timer will wake up the receiver) or Record (Timer
Wakeup Channel: Use tu to select the channel the timer will wake up with.
Wakeup Date: Use the 0~9 buttons to input the date for the timed event.
Wakeup Time: Use the 0~9 buttons to input the desired start time.
Duration: Use the 0~9 buttons to input the timer duration.
Once all settings are according to your wishes, use pq to move the highlight to Save and press OK
to confirm. To quit the timer without saving your settings, move the highlight to Cancel.
conversion method. Options are: Auto (automatic detection of aspect ratio),
4:3 Panscan (Displays 16:9 widescreen broadcasts full screen on your 4:3 TV),
4:3 letterbox (black bars on top and under the picture on a 4:3 TV) and 16:9
(use this setting for 16:9 TV sets).
SCART.
will be converted to stereo audio. Bitstream enables multi-channel audio on
the digital output.
date manually.
when GMT Usage is set to On.
The GMT Offset range is "-11:30 ~ +12:00", increasing by half hours
progressively. The cities matching the set GMT Offset are displayed at the
bottom of the screen.
the 0~9 buttons to enter the date. Press EXIT to proceed.
the 0~9 buttons to enter the time. Press EXIT to proceed.
every day).
will start to record the scheduled event).
English
13
PART 1 • English
7.3.5 Parental Lock
This menu allows you to protect the installation menu and/or channels with a password. You can also
enter a new password in the Parental Lock menu.
Use pq to select Parental Lock from the System Setup menu and press OK to proceed. You will be
asked to enter your pin code. (DEFAULT: 0000)
Menu Lock: Locks the installation menu. You can set Menu Lock to On or Off.
Channel Lock: Choose between: Off, AGE 10, AGE 12, AGE 16 and AGE 18. Channels with
New Password: Enter your new password (4 digits) here.
Confirm Password: Re-enter your password here to confirm.
7.3.6 OSD Setting
This menu allows you to change settings for: OSD Timeout and OSD Transparency.
OSD timeout: Sets the time after which on screen banners and messages disappear. The
OSD Transparency: To set the OSD transparency from Off ~ 40% with 10% steps.
Load Default OSD Setting:
Press OK to clear all OSD settings and reset to default values.
7.3.7 Favourite
This menu allows you to personalize the names of the 8 available favourite lists.
Use pq to select Favourite from the System Setup Menu and press OK to proceed. The names of all
groups are now displayed. Select the desired favourite group with pq and press OK to edit its name.
A text field will now pop up at the right of the screen. Use tu pq to select the desired characters
and enter them with OK. Once you have finished editing, press BLUE to save the changes. Once all
changes are made, press EXIT twice.
7.3.8 Auto Standby
Auto Standby is a new feature that helps you with reducing power consumption. When set to On, the
receiver will turn to standby if it doesn’t receive any commands for three hours. Set Auto Standby to
Off to avoid the automatic switch down.
7.4 Tools
Press MENU in viewing mode to enter the Main Menu.
Select the Tools submenu with pq and press OK or u to enter.
Use pq to highlight the desired submenu and press OK proceed.
Press EXIT to leave.
7.4.1 Receiver Information
This submenu shows receiver specific information such as hardware version and software version.
It also displays our web address www.strong.tv. Please have the Receiver Information screen on hand
when you call our hotline. The person who answers your call might ask for the information given in
this screen.
a parental rating above the chosen age will be protected with a password (if
available in your local broadcast.)
range is 1~10 seconds.
14
PART 1 • English
7.4.2 Load Factory Setting
This option allows you to reset the receiver to factory settings, which clears all stored channels.
WARNING! By resetting your receiver to factory default, all your settings and stored
Use pq to select "Load Factory Setting" in the Tools menu and press OK. You are asked to
input password.
Input the correct password using the 0~9 buttons (default: 0000). A confirmation window
is displayed.
Select Yes to return to factory settings. Select No to cancel.
Press EXIT to leave.
7.4.3 S/W Upgrade by OTA
This receiver is equipped with an Over The Air software upgrade option. An Over The Air update
might not be available in your region. Please visit our website www.strong.tv or contact your local
service hotline for more information about this option.
7.4.4 Upgrade by USB
This feature allows you to upgrade your receiver’s software via the USB port. If new software is
available for your receiver, it can be downloaded from our website www.strong.tv.Place the software
file (unzipped) in the root directory of your USB storage device (HDD, memory stick etc.) and insert
this device into the USB port of the receiver.
Select Upgrade by USB from the Tools menu and press OK to proceed.
The upgrade menu will now be displayed.
Use pq to select Upgrade Mode and choose option Allcode.
Use pq to select Upgrade File and choose the file containing the new software.
Once all settings are made, move the highlight to Start and press OK to start the upgrade process.
After a few seconds, the receiver asks: “Are you sure to burn flash?”. Select Yes to finalize the upgrade
or No to quit without upgrading.
WARNING! After an update the receiver restarts automatically. During the upgrade
7.4.5 Remove USB device safely
Select Remove USB device safely from the tools menu and press OK. The receiver will display a
message indicating that you can safely remove your storage device from the receiver.
NOTE: After performing this function, the USB device is no longer accessible from
channels will be permanently deleted. Please use this option with care.
process NEVER disconnect the receiver from the mains or switch off the
power! Doing so might damage your receiver and will void warranty!
your receiver. To gain access to your storage device again, re insert it or switch
the receiver to standby and on again.
English
15
PART 1 • English
7.5 Games
Your receiver is equipped with two games which can be played on your TV screen using the receiver
remote control.
Use pq to select Game from the Main menu and press OK or u to proceed.
Select one of the available games (Othello or Sudoku) using pq and press OK to start the game.
Follow the directions on screen.
Use EXIT to quit a game.
7.6 Media+
The Media+ menu consists of the following submenus: Media Player, Record Manager, DVR HDD
Information, HDD Format, DVR Configuration and Jump.
Use pq to highlight the desired menu and press OK to enter.
Press EXIT to quit.
7.6.1 Media Player
This function allows you to play MPEG, AVI, MP3, JPG many other type files from connected storage
device (see details in technical part).
Select Media Player from the Media+ menu and press OK to proceed.
Use pq browse the connected USB device and use OK to open maps. Press OK to play the
highlighted selection.
The help banner at the bottom of the screen explains all buttons used in the Media player. Press EXIT
to quit.
NOTE: You can also access the Media Player from viewing mode with the FILE key on
7.6.2 Record Manager
The Record Manager gives you access to previously recorded events.
Select Record Manager from the Media+ menu and press OK to enter.
Use pq to highlight the recording you wish to play and press OK start playback.
Press EXIT to exit.
During playback, it is possible to perform the following actions:
YELLOW (2) To pause the playback. To resume playback, press BLUE (1).
5 6 For fast forward or fast rewind during playback.
RED (3) Press to stop playback and return to Record Manager.
NOTE: You can also access the Record Manager from viewing mode with the RED
The help banner at the bottom of the screen explains all buttons used in this record manager to edit.
Press EXIT to save the settings and quit the menu.
7.6.3 DVR HDD Information
This option shows relevant information about the connected USB device.
16
the remote control.
key on the remote control.
PART 1 • English
Select DVR HDD Information from the Media+ menu and press OK to enter.
Press EXIT to leave.
7.6.4 HDD Format
The HDD format menu allows you to format the connected USB device.
WARNING! Formatting will permanently delete ALL data stored on the connected device.
Select HDD Format from the Media+ menu and press OK to enter. Use tu to select the partition you
wish to format (Partition 1 is set per default) and press q to highlight Format. Press OK to proceed,
select FAT or Cancel, or press EXIT to leave without formatting.
NOTE It is possible to use already NTFS formatted USB disks.
7.6.5 DVR Configuration
This menu allows you to make settings for Time Shift and recording.
Select DVR Configuration from the Media+ menu and press OK to enter.
Use pq to move the highlight and tu to change settings.
Press EXIT to quit.
Time Shift: On or Off. When Time Shift is set to Off, Time Shift becomes inactive.
Time Shift to Record: On or Off. When set to On, is Time Shift also possible during record.
Record Type: TS or PS. When TS is selected, recordings will also include subtitles and
Record Selection Select the partition the receiver will record on.
Standby after record: On or Off. Select if receiver must go to standby mode after Timer record.
7.6.6 Jump
The jump interval setting allows you to define the length of the fast search interval during playback
of previously recorded events. The player will jump forward or back with the set amount of time each
time you press 6 or 5.
Select Jump from the Media+ menu and press OK to enter.
Use tu to select the desired search interval. Possible settings are: 30 Sec, 1 Min, 5 Min, 10 Min,
30 Min.
Press EXIT to leave the menu.
8.0 TROUBLESHOOTING
There may be various reasons for abnormal operation of the receiver. Check the receiver according to
the procedures shown below. If the receiver does not work properly after checking it, please contact
your dealer or the local Service Hotline. Do NOT try to open or disassemble the receiver. It may cause
a dangerous situation and warranty will be void.
Please make a backup copy of all data you wish to keep before entering the
HDD Format menu. STRONG cannot be held responsible for loss of data
from USB devices used with this receiver.
teletext (when available). PS makes recordings without these extras.
English
17
PART 1 • English
Problem Possible cause What to do
LED indicator not lit Mains lead unplugged Check mains plug
No signal found Aerial is disconnected
No picture or sound on TV HDMI is not selected on
Scrambled channel
Message
No response to remote
control
Forgotten PIN code Contact local Service Hotline
After moving the receiver
to another room/area you
are no longer able to receive
digital reception
The receiver switches
off automatically.
Aerial is damaged/misaligned
Out of digital signal area
Active antenna requires to
switch ON antenna power/
external power
your TV or Amplifier or is
set to higher resolution as
TV supports
TV is not switched on
Channel is scrambled Select alternative channel
Receiver off
Remote not aimed correctly
Front panel obstructed
Remote batteries exhausted
Antenna signals are too weak Press the INFO button on
Auto Standby function enabled. Disable auto standby. See
Check aerial lead
Check aerial
Check with dealer
Switch receiver’s Antenna
Power ON/connect
external power
Switch to correct TV input
Select lower resolution
on receiver
Switch TV on
Plug in and turn on plug
Aim remote at front panel
Check for obstructions
Replace remote batteries
or send email to our Support
via www.strong.tv
remote 2x to call up signal
bars and adjust antenna for
(maximum) reception
or rescan channels
section 7.3.8 for details.
9.0 TECHNICAL SPECIFICATIONS
Demodulator:
Demodulator: COFDM; 16 QAM/64 QAM, QPSK
Transmission mode: 2 K - 8 K
Video Decoder:
Profile level: MPEG-2 MP@ML, AVC/H264HP@L4.1, MPEG4
Video resolutions: 576i/576P/720P/1080i/1080P
Decoding & Video out: PAL
Aspect ratio: 4:3 Letterbox, 4:3 Pan & Scan, 16:9, Auto
ASP supported
18
PART 1 • English
Audio Decoder:
Audio support: AAC/DD+/AC3/PCM
MPEG MusiCam Layer 2
Sampling rate: 32, 44.1, 48 KHz
Audio mode: Stereo, Joint Stereo, Dual Mono, Mono
Tuner:
Front End: DVB-T, UHF & VHF Tuner
Input frequency range: 174 – 230 MHz (VHF) and 470 - 862 MHz (UHF)
Loop through frequency range: 47 - 862 MHz
Input signal level: -82 ~-20 dBm
Memory and System:
Flash memory: 2 MBytes
SDRAM: 64 Mbytes
Multimedia:
Video playback: MPEG-1 and MPEG-2 encoded (mpg), VOB, AVI,
Audio playback MP3**
Picture view JPEG format**
Connectors:
ANT IN - IEC Female
TO TV - IEC Male
TV SCART (RGB, CVBS, Audio L&R)*
HDMI 1.4
S/PDIF: coaxial output Cinch
Cinch (Audio L&R and Video CVBS)*
USB 2.0 port: 5 V/800 mA (max.) supported
*SRT 8105 only
**STRONG cannot guarantee the playback of video files although extensions are listed, as it depends on codec used, data bit rate and resolution .
General Data:
Supply Voltage: 220 - 240 V AC (SMPS), 50/60 Hz
Power Consumption: SRT 8101: 4.95 W (typ), 8.00 W (max)
SRT 8105: 6.98 W (typ.), 8.00 W (max)
Power consumption in Standby: SRT 8101: 0.67 W
Operating Temperature: 0°~ 40°C
Storage Temperature: -30°~ 80°C
Operating Humidity Range: 10~85%, RH, Non-condensing
Size (WxDxH) in mm: SRT 8101: 138 x 112 x 40
Net-weight: SRT 8101: 0.35 kg
STRONG declares that this item complies with the basic requirements and other relevant regulations of directives
MKV, TS, M2T, M2TS, MPEG-4 and MOV**
SRT 8105: 1.03 W
SRT 8105: 188 x 135 x 44
SRT 8105: 0.505 kg
English
19
PART 1 • English
20
Loading...
