Streamax C6D User Manual
User manual for C6D
1 - 7
User Manual
For
Camera C6D
For more information, please visit our website www.en.streamax.com
User manual for C6D
2 - 7
Network
WIFI
Support,option
Bluetooth
Support,option
3G/4G
Support,option
Location
GPS
Support
Sensor
6-axis Sensor
Support
Miles/Time Calculation
Vehicle pulse acquisition
Support
LED
It shows the device working status
The indicator light shows the four states of the device:
Power: the device is powered, the red light is always bright;
Normal operation: green light is always bright;
Fault alarm: indicator red light flashes once a second;
Sleep: green light flashes 1 second and off 10 seconds.
Storage
SD Card
SDXC64G/128G/256G optional
Main stream resolution and
frame rate
Inside: 720P @ 30fps
Outside: 1080P @ 30fps
Max.
Main stream stream 1080P @ 30 frames +
720P @ 30 frames,
Image setting
Brightness, Chroma, Contrast, saturation
and sharpness
Video coding
H.265/H.264
Video compression bit rate
500Kbps～6Mbps
Audio compression standard
ADPCM
1. Product characteristics
1.1. Overview
Streamax C6D (3.0) is a kind of cost-effective device designed for mobile video surveillance. Its
characteristics are as follows:
Supports 3G / 4G, Bluetooth, WIFI, 6 axis and other functions, which is easy to install;
It can record the vehicle track for further analysis;
SD card video storage, maximum support 256GB, and it has anti-theft function;
Patented file system to protect passengers’ privacy;
Industrial design requirements, aluminum alloy shell, a large area of heat teeth, good heat
dissipation.
Compact size, light weight. It can be pasted to the glass on the rear side of rearview mirror, which
will not effect the driver driving.
The internal 720P camera is with infrared, recording function, which can clearly capture the driver to
protect the driver’s safety;
The external 1080P camera can clearly record the scene outside. When accidents happen, it could
bu used as evidence for police.
1.2. Specifications
For more information, please visit our website www.en.streamax.com
User manual for C6D
3 - 7
General function
Heartbeat mechanism, multi-level user
management
Intelligent alarm
Not support
CBR / VBR
Support
Audio input
Support
Built-in speaker
Built-in speakers for broadcasts, prompting
drivers or passengers
Camera parameters
Sensor(inside vehicle)
1/3" 1.23M pixel CMOS Sensor
Sensor(outside vehicle)
1/2.9" 2M pixel CMOS Sensor
Electronic Shutter
1/30Second-1/100000 Second
Lens
Inside:2.3mm
Outside:4mm
Lens port
M12
Day/Night IR-Cut
Inside: support
Outside: not support
Wide Dynamic Range
Digital Wide Dynamic Range
Black-light Compensation
Support
S/N
≥48db
IR distance
Inside: 3m
Outside: not support
Ports
USB
Mini-B USB2.0
IPC
1 channel
SD card slot
1
SIM card slot
1
RS232
2 channel
Alarm
2 channel
SPEED
1 channel
Sensor IN
2 channel
Power output
5VDC@500mA，12VDC@500mA
Power supply
DC 9~36V
Normal power consumption
6W
Others
Temperature
-30℃~+70℃
Storage temperature
-40℃~+85℃
Humidity
95%
1.3. Dimension (Unit: mm)
