Translation of the Original

Operating Instructions

Short-cut forage wagon

Short-cut forage wagon with

dosing unit

Super-Vitesse CFS 3101, 3501

Super-Vitesse CFS 3101 DO, 3501 DO

71600919 0.000

10.13

R. Kleine Niesse

Chief Designer

Vehicle Technology

Dr. J. Marquering

Head of Development

Dipl.-Kfm. W. Strautmann

Managing Director

EC Declaration of Conformity

according to the EC machinery directive 2006/42/EC, Annex II, 1.A

Manufacturer:

B. Strautmann & Söhne GmbH u. Co. KG Bielefelder Str. 53 D-49196 Bad Laer

Legal person established within the EC and authorized to compile the technical documentation:

B. Strautmann & Söhne GmbH u. Co. KG Bielefelder Str. 53 D-49196 Bad Laer

Description and identification of machine:

Designation: Short-cut forage wagon / Short-cut forage wagon with dosing unit Function: Cutting, charging, transport and distribution of green and dried-out forage Model: Super-Vitesse CFS / Super-Vitesse CFS DO Type: Super-Vitesse CFS 3101, 3501 Super-Vitesse CFS 3101 DO, 3501 DO Vehicle/Machine ID number: W09712000_0S38001 - W09717000_0S38999 Trade name: Super-Vitesse CFS / Super-Vitesse CFS DO

We hereby explicitly declare that the machine complies with all relevant provisions of the following EC directives:

2006/42/EC:2006-05-17 EC machinery directive 2006/42/EC

2004/108/EC:2004-12-15 (Electromagnetic compatibility) Directive 2004/108/EC of the European

Parliament and the Council dated 15 December 2004 for approximation of laws of the member states on the electromagnetic compatibility and for repeal of directive 89/336/EEC

Sources of the applied harmonized standards according to article 7 paragraph 2:

EN ISO 12100:2010 Safety of machinery - Basic concepts, general principles of design - Risk

assessment and risk reduction

EN ISO 13857:2008 Safety of machinery - Safety distances to prevent hazard areas from

being reached by upper and lower limbs

EN ISO 4413:2010 Fluid power - General rules and safety requirements for hydraulic

systems and their components

EN 953:1997+A1:2009 Safety of machinery - Guards - General requirements for the design and

construction of fixed and movable guards

EN 12965:2003+A2:2009 Tractors and machinery for agriculture and forestry - Propeller shafts and

EN 690:1994+A1:2009 Agricultural machinery - Manure spreaders - Safety

EN ISO 4254-1:2009 Agricultural machinery - Safety - Part 1: General requirements

EN ISO 4254-1:2009 Agricultural machinery - Safety - Part 11: Pick-up balers

their guards - Safety

Bad Laer, 01.10.2013

Identification data

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Identification data

Please enter the machine’s identification data here. They are registered on the type plate.

Manufacturer: B. Strautmann & Söhne GmbH u. Co. KG

Vehicle/Machine ID number: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Type:

Year of manufacture:

Manufacturer’s address

B. Strautmann & Söhne GmbH u. Co. KG

Bielefelder Straße 53

D-49196 Bad Laer

Phone: + 49 (0) 5424 802-0

Fax: + 49 (0) 5424 802-64

E-mail: kontakt@strautmann.com

Spare parts order service

B. Strautmann & Söhne GmbH u. Co. KG

Bielefelder Straße 53

D-49196 Bad Laer

Phone: + 49 (0) 5424 802-31

Fax: + 49 (0) 5424 802-64

E-mail: kontakt@strautmann.com

Spare parts catalogue online: www.strautmann-elise.de

Please always refer to the vehicle/machine ID number of your machine when ordering spare parts.

Formal information about the operating instructions

Document number: 71600919 0.000

Date of compilation: 10.13

Reproduction, even in excerpts, only allowed with the permission of B. Strautmann & Söhne GmbH u. Co. KG.

Foreword

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Foreword

Dear customer,

You have decided in favour of a quality product from the large B. Strautmann & Söhne GmbH u. Co. KG product range. We thank you for the confidence you have shown in us.

Upon receipt of the machine, please check for transport damage or missing parts! Check the delivered machine for its completeness, including the ordered optional extras, by means of the delivery note. Only immediate complaints will give reason to compensation!

Read and observe these operating instructions and any other included operating instructions for individual machine components before the first start-up; in case of doubt, the details and information contained in such sub-supplier documentation shall prevail! In particular observe the safety instructions, thus being able to fully benefit from the advantages of your recently acquired machine.

Please make sure that all operators of the machine have read these operating instructions before starting the machine.

The machines are available with various optional extras. Due to the individual equipment of your machine, not all descriptions included in these operating instructions apply to your machine. Optional extras are marked in these operating instructions and are available at extra cost.

In case of any inquiries or problems, please refer to these operating instructions or call us.

Regular service and maintenance and timely replacement of worn-out or damaged parts will result in a longer service life of your machine.

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Contents

1 User information 11

1.1 Purpose of document 11

1.2 Keeping of operating instructions 11

1.3 Location details in the operating instructions 11

1.4 Applied modes of specification 11

1.5 Applied terms 12

2 Product description 13

2.1 Overview – Assemblies 14

2.2 Safety and protective devices 15

2.3 Supply lines between tractor and machine 17

2.3.1 Marking of hydraulic supply lines 17

2.4 Traffic-related equipment 19

2.5 Correct use 20

2.6 Hazardous areas and dangerous spots 20

2.7 Type plate and CE symbol 21

2.8 License plate 22

2.9 Technical data 23

2.9.1 Tyre pressure 24

2.10 Required tractor equipment 25

2.11 Noise specifications 26

3 Safety instructions 27

3.1 Safety-conscious working 27

3.2 Organisational measures 27

3.2.1 User’s obligation 27

3.2.2 Operator’s obligation 27

3.2.3 Qualification of staff 28

3.3 Product safety 29

3.3.1 Safety-conscious operation of machine 29

3.3.2 Safety and protective devices 29

3.3.3 Structural alterations 29

3.3.4 Spare and wearing parts, auxiliary materials 30

3.3.5 Warranty and liability 30

3.4 Basic safety instructions 30

3.4.1 General safety and accident prevention instructions 30

3.4.2 Hydraulic system 32

3.4.3 Electrical system 33

3.4.4 Propeller shaft operation 34

3.4.5 Hitched machines 35

3.4.6 Brake system 35

3.4.7 Axles 36

3.4.8 Tyres 36

3.4.9 Operation of machine 36

3.4.10 Service and maintenance of machine 37

3.5 Activity-related safety instructions and important information 37

3.5.1 Activity-related safety instructions 37

3.5.2 Important information 38

3.6 Warning and instruction signs 39

3.6.1 Warning signs 39

3.6.2 Instruction signs 44

3.6.3 Placing of warning and instruction signs 46

3.7 Risks in case of non-observance of safety instructions and warning signs 47

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

4 Loading and unloading 47

5 Design and function 49

5.1 Pick-up 49

5.1.1 Pick-up drive 50

5.1.2 Silage additive pump 51

5.1.3 Holding-down device with pulley 51

5.2 Feeder rotor 52

5.3 Cutting unit 53

5.4 Transport floor 54

5.4.1 Set feed rate of transport floor (easy-to-use control) 54

5.4.2 Set feed rate of transport floor (ISOBUS control) 54

5.5 Load-protection bars with integrated automatic charging system 55

5.5.1 Easy-to-use control of automatic charging system 55

5.5.2 ISOBUS control of automatic charging system 56

5.5.3 Deactivate automatic charging system and stop transport floor 56

5.6 Tailgate 57

5.6.1 Tailgate on machines without beaters 57

5.6.2 Tailgate on machines equipped with beaters 57

5.6.2.1 Crossover conveyor (optional extra) 58

5.6.3 Lock tailgate 58

5.7 Dosing drums 59

5.8 Access door and ladder 59

5.9 Hydraulic system of machine 60

5.9.1 Electro-hydraulic control block 61

5.9.1.1 Load-sensing hydraulic system 62

5.9.1.2 Electrical system – Emergency manual operation 63

5.9.1.3 Functional diagram for emergency manual operation 64

5.9.2 Hydraulic hose pipes 66

5.9.2.1 Connect hydraulic hose pipes 66

5.9.2.2 Disconnect hydraulic hose pipes 67

5.10 Chassis 67

5.10.1 Bogie tandem chassis 68

5.10.2 Steering axle for follow-up steering 68

5.10.3 Steering axle for electro-hydraulic forced steering axle system SES (only with bottom linkage and ISOBUS control) 68

5.10.3.1 Couple forced steering axle 68

5.10.3.2 Lock forced steering axle 69

5.11 Drawbar 70

5.11.1 Hydraulic folding drawbar 70

5.11.2 Couple drawbar 70

5.11.2.1 Bolt-type coupling 71

5.11.2.2 Ball-type coupling and shell 71

5.11.3 Uncouple drawbar 72

5.11.3.1 Bolt-type coupling 72

5.11.3.2 Ball-type coupling and shell 72

5.12 Drawbar suspension for folding drawbar 73

5.13 Supporting leg 73

5.13.1 Mechanical supporting leg 73

5.13.1.1 Lift mechanical supporting leg to transport position 74

5.13.1.2 Lower mechanical supporting leg to support position 74

5.14 Propeller shaft 75

5.14.1 Couple propeller shaft to tractor 76

5.14.2 Uncouple propeller shaft from tractor 76

5.15 Brake system 77

5.15.1 Dual-line compressed-air brake system 77

5.15.1.1 Dual-line compressed-air brake system with mechanical automatic load-

sensitive brake (ALB) regulator 77

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

5.15.1.2 Dual-line compressed-air brake system with hydraulic automatic loadsensitive brake pressure (ALB) regulator 79

5.15.1.3 Braking axle 80

5.15.1.4 Connect brake and feed line 80

5.15.1.5 Disconnect brake and feed line 81

5.15.2 Hydraulic service brake system 81

5.15.2.1 Emergency brake valve 82

5.15.2.2 Connect hydraulic brake system 83

5.15.2.3 Disconnect hydraulic brake system 84

5.15.3 Parking brake 84

6 Commissioning 85

6.1 Check tractor's compatibility 86

6.1.1 Calculate actual values 86

6.1.2 Preconditions for the operation of tractors with rigid drawbar trailers 87

6.1.2.1 Combination options of coupling devices and drawgears 87

6.1.2.2 Calculate actual DC value for combination to be coupled 88

6.1.2.3 Calculate tractor's admissible towing capacity 89

6.2 Mount body side panels, ropes and body tarpaulin 90

6.3 Mount control set on the tractor 93

6.3.1 Mount easy-to-use control set on the tractor 93

6.3.2 Mount ISOBUS control set on the tractor 93

6.4 Adjust mounting height of folding drawbar 94

6.5 Adjust length of propeller shaft to tractor 95

6.6 Mount shell to folding drawbar 97

6.7 Mount crossover conveyor 97

6.1 Dismount crossover conveyor 100

6.2 Check machine for proper functioning 101

6.3 Start-up after longer downtime 102

7 Operation 103

7.1 Easy-to-use control 103

7.1.1 Design 103

7.1.2 Functions of the easy-to-use control 105

7.1.2.1 Switch road travel mode on 106

7.1.2.2 Switch operating mode on 107

7.1.2.3 Switch machine off 107

7.1.2.4 Switch work lights on/off 108

7.1.2.5 Switch automatic charging system on/off 108

7.1.2.6 Switch transport floor on (level I) 109

7.1.2.7 Double feed rate of transport floor for complete emptying (level II) 110

7.1.2.8 Reverse feed direction of transport floor for a short time 110

7.1.2.9 Change feed rate of transport floor 110

7.1.2.10 Open tailgate 111

7.1.2.11 Close tailgate 111

7.1.2.12 Lift folding drawbar 112

7.1.2.13 Lower folding drawbar 112

7.1.2.14 Retract cutting unit 112

7.1.2.15 Extend cutting unit 113

7.1.2.16 Unlock steering axle 113

7.1.2.17 Lock steering axle 113

7.1.2.18 Lift pick-up 114

7.1.2.19 Lower pick-up 114

7.2 ISOBUS control 114

7.2.1 Design of ISOBUS control 114

7.2.2 Display information in Working menu 118

7.2.3 Functions and their symbols 119

7.2.4 Set machine parameters 133

7.2.4.1 Call up SET menu 134

7.2.4.2 Set machine model 135

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

7.2.4.3 Pre-select steering axle model 135

7.2.4.4 Pre-select filling degree of loaded material in cargo space 136

7.2.5 Calibration (ISOBUS control) 136

7.2.5.1 Calibrate automatic charging system 136

7.2.6 Operating hours counter, service hours counter and transported loads counter 137

7.2.7 Call up Counter menu 138

7.2.8 Reset daily counters 138

7.2.9 Sensor and state overview 139

7.2.9.1 Call up state overview 139

7.3 SES system 140

7.3.1 Design 140

7.3.2 Steering computer displays 141

7.3.3 Error diagnosis 142

8 Hitch and unhitch machine 143

8.1 Hitch machine 143

8.2 Unhitch machine 144

9 Settings 145

9.1 Pick-up 146

9.1.1 Set operating height 146

9.1.2 Set additional roller feelers 146

9.1.3 Set holding-down device with pulley 147

9.2 Set cutting length 148

10 Use of machine 149

10.1 Charging 150

10.1.1 Charging with easy-to-use control 152

10.1.2 Charging with ISOBUS control 152

10.1.3 Determine admissible loading capacity 153

10.1.4 Bulk densities of different materials 154

10.2 Discharging 154

10.2.1 Discharging with easy-to-use control 154

10.2.1.1 Machine without beaters 154

10.2.1.2 Machine equipped with beaters 155

10.2.2 Discharging with ISOBUS control 157

10.2.2.1 Machine without beaters 157

10.2.2.2 Machine equipped with beaters 158

10.3 Eliminate clogging at the pick-up and the feeder rotor 160

10.4 Secure tractor and machine against accidental starting and rolling 161

11 Transport journeys 162

11.1 Transport journeys with partly discharged machine 163

12 Service and maintenance of machine 164

12.1 Service and maintenance plan - Overview 166

12.2 Enter cargo space 168

12.3 Cleaning of machine 168

12.4 Lubrication of machine 169

12.4.1 Lubrication plan 170

12.5 Preservation/Longer downtimes 171

12.6 Check/top up/change gear lubricant oil 171

12.6.1 Quantities when filled and change intervals 171

12.6.2 Feed gearing of transport floor 172

12.6.3 Main gearbox of cutting unit 172

12.6.4 Rotor gear of cutting unit 173

12.6.5 Angular switchgear of cutting unit 173

12.6.6 Angular gear of CFS unit 174

12.6.7 Angular gear of dosing unit 174

12.6.8 Check/Top up oil level 174

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

12.6.9 Change gear lubricant oil 175

12.7 Pick-up 175

12.7.1 Bleed friction clutch of pick-up 175

12.7.2 Check/Retighten tension of roller chain for pick-up drive 177

12.8 CFS drum 177

12.8.1 Bleed friction and compensating clutch of CFS drum 177

12.8.2 Remove/Mount friction and compensating clutch of CFS drum 178

12.8.3 Align switch rods with respect to the switch levers of the angular switchgear (only when equipped with dosing drums) 179

12.9 Feeder rotor 179

12.9.1 Check / Retighten tension of roller chain for feeder rotor drive 180

12.10 Cutting unit 180

12.10.1 Clean cutting unit 181

12.10.1.1 Clean knife security system 181

12.10.2 Remove and install cutting knives 182

12.10.2.1 Remove cutting knives 182

12.10.2.2 Install cutting knives 184

12.10.3 Grind cutting knives 185

12.10.4 Set distance between cutting knives and rotor 185

12.10.5 Check distance between strippers and rotor 186

12.10.6 Set "Cutting unit retracted" sensor 187

12.11 Transport floor 188

12.11.1 Shorten and tighten transport floor chain 189

12.11.2 Lubricate chain tensioners and deflection points of transport floor 190

12.12 Dosing drums 190

12.12.1 Lubricate roller chains of dosing drums 190

12.12.2 Check/Retighten tension of roller chains of dosing drums 190

12.13 Hydraulic system 192

12.13.1 Depressurize hydraulic system 192

12.13.1.1 Depressurise folding drawbar with drawbar suspension 193

12.13.2 Hydraulic hose pipes 193

12.13.2.1 Marking and period of use of hydraulic hose pipes 193

12.13.2.2 Inspection criteria for hydraulic hose pipes 194

12.13.3 Replace hydraulic filter 194

12.14 Tyres 195

12.14.1 Check tyres 195

12.14.2 Change tyres 196

12.15 Brake system 197

12.15.1 Check/Clean in-line filters of compressed-air brake system 197

12.15.2 Set compressed-air brake system 198

12.15.3 Set hydraulic brake system 198

12.16 Maintenance of axles 199

12.16.1 Lubricate knuckle arm bearing 200

12.16.2 Lubricate locking cylinder heads at follow-up steering axle 200

12.16.3 Lubricate brake shaft bearing 200

12.16.4 Lubricate standard slack adjuster 201

12.16.5 Lubricate automatic slack adjuster 201

12.16.6 Tighten wheel nuts 202

12.16.6.1 Tightening torques for wheel nuts 202

12.16.7 Check clearance of wheel hub bearing 202

12.16.8 Check brake linings 203

12.16.9 Check brake 203

12.16.10 Check automatic slack adjuster 203

12.17 Maintenance of Bogie chassis 204

12.18 Tightening torques 204

13 Malfunctions and remedy 206

13.1 Hydraulics 206

13.2 Electrics 207

Contents

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

13.3 Working 208

14 Circuit diagrams 210

14.1 Hydraulics 210

14.2 Hydraulics – Forced steering axle system 212

14.3 Electronics – Easy-to-use and ISOBUS control – Cable harness overview 214

14.4 Electronics – Easy-to-use and ISOBUS control – Valves 216

14.5 Electronics – Easy-to-use and ISOBUS control – Sensors 218

14.6 Electronics – Easy-to-use and ISOBUS control – Control unit 220

14.7 Connection of lighting system 222

14.8 Connection of additional electrical loads 222

User information

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1 User information

The chapter “User information“ provides information about how to use the operating instructions.

1.1 Purpose of document

These operating instructions:

 describe the operation, service and maintenance of the machine,

 provide important information about safety-conscious and efficient handling of the machine.

Please contact us for further inquiries.

1.2 Keeping of operating instructions

The operating instructions are part of the machine. Therefore, keep these operating instructions:

 always in the immediate vicinity of the machine or in the tractor,

 for further use.

Hand these operating instructions over to the buyer when the machine is sold.

1.3 Location details in the operating instructions

Any directional data in these operating instructions refer to the direction of motion.

1.4 Applied modes of specification

Instructions and responses

Activities which have to be carried out in a predetermined order, are specified as numbered instructions. Always adhere to this order. In some cases, the response of the machine to the respective instruction is marked by an arrow.

Example:

1. Instruction 1

 Response of machine to instruction 1

2. Instruction 2

Lists

Lists without predetermined order are specified as lists with bullet points.

Example:

 Item 1

 Item 2

Position numbers in figures

Numbers in parentheses refer to position numbers in figures. The first number refers to the figure, the second number to the position number in the figure.

Example (Fig. 3/6):

 Figure 3, Position 6

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Term

The term means

third person/party

… all other persons apart from the operator.

risk

… the source of a possible injury or damage to health.

manufacturer

… B. Strautmann & Söhne GmbH u. Co. KG.

machine

… Short-cut forage wagon / Short-cut forage wagon with dosing unit SuperVitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO.

operating element

… the component of an operating element system which is directly actuated by the operator, e. g. by pressing. An operating element may be an adjusting lever, a key button, rotary switch, key etc.

1.5 Applied terms

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

2 Product description

This chapter includes

 comprehensive information about the machine design,

 the designations of the individual assemblies and operating elements.

Please read this chapter in the immediate vicinity of the machine if possible, thus acquainting yourself with the machine in the best possible way.

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 1

2.1 Overview – Assemblies

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Beaters

(2) Body

(3) Tubular support

(4) Automatic charging system

(5) Front grating, top

(6) Front grating, bottom

(7) Conveying unit

(8) Electro-hydraulic control block

(9) Hydraulic folding drawbar for top and

bottom linkage, bottom linkage with forced steering axle

(10) CFS drum

(11) Supporting leg

(12) Holding-down device with pulley

(13) Pick-up

(14) Guide wheel

(15) Chain drive, CFS drum

(16) Additional guide wheel

(17) Chassis

(18) Access door to cargo space

(19) Transport floor feed

(20) Body tarpaulin

(21) Tailgate

(22) Angular gear, rear

(23) Parking brake

(24) Cutting unit

(25) Angular gear CFS

(26) Angular switchgear CFS

(27) Hose holder

WARNING

Risk to people of being crushed, drawn in and becoming entangled due to unprotected powered driving elements during machine operation!

 Start the machine only with the protective devices completely

mounted.

 It is not allowed to open protective devices:

 when the machine is powered,

 as long as the tractor engine is running with the propeller

shaft coupled/the hydraulic system connected,

 if the ignition key is in the tractor and the tractor engine can

be accidentally started with the propeller shaft coupled/the hydraulic system connected,

 if tractor and machine have not been secured against

accidental rolling by means of their respective parking brake and/or the chocks.

Close open protective devices before powering the machine.

2.2 Safety and protective devices

This chapter shows the location of the properly installed protective devices in protective position.

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 2

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Bonnet

(2) Hydraulics protective device

(3) Holding-down device with pulley

(4) Drawbar protective device

(5) Protective casing, pick-up

(6) Hinge carrier, left-hand

(7) Side protector, left-hand

(8) Access door to cargo space

(9) Side protector, beater drive, left-hand

(10) Sensor protective device

(11) Tailgate

(12) Bottom plates for feed shaft

(13) Stripper plate

(14) Side protector, beater drive, right-hand

(15) Tunnel cover for beater drive

(16) Side protector, right-hand

(17) Guide wheels

(18) Hinge carrier, right-hand

(1) Hydraulic connector "Flow line" SN 16 (red)

(2) Hydraulic connector "Return line" SN 20

(blue)

(3) Load-sensing connector SN 6 (only with

available load-sensing connector)

(4) Compressed-air brake, feed line (red)

(5) Compressed-air brake, brake line (yellow)

(6) Lighting connector, 7-pole

(7) Power supply, 3-pole

(8) ISOBUS connector for ISOBUS control unit

(only with available ISOBUS control unit)

(9) Hydraulic connector for hydraulic brake

system with hydraulic clutch according to ISO 5676 (only with available hydraulic brake system)

Fig. 3

Hydraulic connector "Flow line"

 Label Arrows: white Background: red

Hydraulic connector "Return line"

 Label Arrows: white Background: blue

2.3 Supply lines between tractor and machine

2.3.1 Marking of hydraulic supply lines

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Explanation of hydraulic connector symbols

 P: Pressure pipe (red)

 T: Tank line (blue)

Load-sensing connector

 Label

Explanation of the following symbols:

 Load-sensing connector (blue)

 Hydraulic brake system (red)

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Properly fix and check the traffic-related equipment for proper functioning before travelling on public roads and paths.

Fig. 4

(1) Warning plates

(2) Side reflectors (4 on each side of machine)

(3) Chocks

(4) Multi-function light

(5) License plate

(6) Speed sign

(7) Triangular reflectors

2.4 Traffic-related equipment

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

People are not allowed in the hazardous area:

 if the tractor engine is running with the propeller shaft coupled/

the hydraulic/electronic system connected,

 if tractor and machine are not secured against accidental

starting and rolling.

Only if no people are within the hazardous area of the machine, is the operator allowed to:

 move the machine,

 set movable machine parts from transport to working position

and from working to transport position,

 power working tools.

2.5 Correct use

The machine:

 is exclusively intended for normal use in the course of agricultural work,

 is suitable for cutting, charging, transport and distribution of green and dried-out forage,

 is only allowed to be operated by one person from the driver seat of the tractor.

Slopes can be travelled on as follows:

 Traversing hills:

 Direction of motion to the left 20 % uphill/downhill gradient

 Direction of motion to the right 20 % uphill/downhill gradient

 Slope line:

 Uphill 20 % gradient

 Downhill 20 % gradient

The following is also part of the correct use:

 the observance of all instructions contained herein,

 the observance of the specified service and maintenance work on the machine,

 the exclusive use of original spare parts.

Any use beyond this is prohibited and will be regarded as incorrect.

For any damage resulting from incorrect use:

 the user will be solely responsible,

 the manufacturer will not assume any liability.

2.6 Hazardous areas and dangerous spots

The hazardous area is the area within and/or in the vicinity of a machine, in which the safety or health of people might be impaired.

Within the hazardous area, risks occur at dangerous spots which cannot be completely eliminated due to the operational safety of the machine. The risks exist permanently or may occur unexpectedly.

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The complete marking is treated as a document and must not be altered or made unrecognizable.

(1) Type plate with CE symbol

(2) Vehicle/Machine ID number (embossed into

the frame)

(3) ALB plate

Fig. 5

Dangerous spots are marked by warning signs attached to the machine, which warn about existing residual risks.

In these operating instructions, activity-related safety instructions mark the existing residual risks.

Risks may arise:

 due to work-related movements of the machine and its working tools,

 due to substances or foreign objects blown out of the machine,

 due to accidental lowering of the lifted machine/of lifted machine parts,

 due to accidental starting and rolling of the machine / of tractor and machine.

Dangerous spots exist:

 within the drawbar area between tractor and machine,

 within the area of the powered propeller shaft,

 within the area of the powered pick-up,

 within the area of the pick-up, when lifting and lowering the pick-up,

 within the area of the cutting unit, when extending and retracting,

 beneath the machine,

 beneath the lifted, unsecured tailgate,

 within the area of the powered dosing drums,

 within the area of the powered transport floor,

 in the cargo space with the machine powered.

2.7 Type plate and CE symbol

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Information on the type plate:

(1) Manufacturer

(2) Vehicle / Machine ID number

(3) Type

(4) Empty weight [kg]

(5) Gross vehicle weight rating [kg]

(6) Admissible tongue load/front axle load [kg]

(7) Admissible rear axle load [kg]

(8) Approval number

(9) Year of manufacture

(10) Rated speed [min-1]

(11) Admissible hydraulic pressure [bar]

(12) Maximum admissible speed [km/h]

Fig. 6

2.8 License plate

The following license plate sizes are provided:

 for machines with an admissible maximum speed of up to 40 km/h: 255 mm x 130 mm.

 for machines with an admissible maximum speed of more than 40 km/h: 340 mm x 200 mm.

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Type

Super-Vitesse CFS

3101

3101 DO

3501

3501 DO

Gross vehicle weight rating (up to 40 km/h)

18000

Admissible axle load

16000

Admissible tongue load

2000

Empty weight

6900

7400

7100

7600

Capacity, medium compression

m³

50.8

57.8

Capacity according to DIN 11741

m³

X = total length

8.80

9.40

9.60

10.25

Y = total width

2.75

Z = total height

3.95

W = track

2.50

R = wheelbase

1.32

Picking-up width of pick-up

1.90

Number of pick-up tine rows

Pcs.

Tine spacing of pick-up

Ground clearance of pick-up

with lifted folding drawbar approx. 600

P.t.o. speed

min-1

1000

Oil flow rate

min

40 - 90

In case of equipment with bottom hitch and K 80 coupling head (up to 40 km/h) the tongue load and the gross vehicle weight rating are increased by 1000 kg.

Figures, technical data and weights may change due to technical development and are not binding for delivery.

2.9 Technical data

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

max.

4.0

2.0

2.8

3.2

4.0

2.7

4.0

3.2

2.0

4.0

1 bar = 14.5 psi = 100 kPa

65 km/h

20 t

3.6

3.9

3.2

65 km/h

18 t

3.1

3.4

2.7

65 km/h

16 t

3.3

2.5

3.6

3.2

2.9

2.2

40 km/h

20 t

2.7

2.5

3.9

2.3

2.5

3.3

3.0

2.6

2.0

40 km/h

18 t

3.7

2.2

3.5

1.9

2.0

2.9

2.6

2.3

1.7

40 km/h

16 t

3.2

1.9

1.8

3.0

1.6

1.7

2.5

2.2

1.9

1.4 bar

bar

bar 152D

159D

159A8

168A8

148D

154D

163E

160A8

158D

156D

158A8

165D

166A8

Nokian Country King

Michelin Cargo X-BIB

Vredestein Flotation +

Vredestein Flotation Pro

Alliance I-380

Alliance I-328

Nokian Country King

Vredestein Flotation Pro

Trelleborg T404

Vredestein Flotation Trac

Alliance I-380

2.9.1 Tyre pressure

Tyre pressures for tandem axle (22.5“)

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Super-Vitesse CFS

3101

3101 DO

3501

3501 DO

Power required

120

130

P.t.o. speed

min-1

1000

Battery voltage:

 12 V (volt)

Socket for lighting:

 7-pole

Socket for control set:

 3-pole (DIN 9680). The feed line of the 3-pole socket should

have a minimum cable cross section of 4 mm².

 Check the compatibility of the hydraulic oils before connecting

the machine to the hydraulic system of your tractor. For details about checking the compatibility of the hydraulic oils, contact your agricultural machinery dealer if necessary.

 Do not mix mineral oils with bio oils.

Depending on their function, the hydraulic components can be connected to:

 a double-acting control device,

 a single-acting control device and a depressurised return line

leading directly into the hydraulic oil tank of the tractor.

Given a free choice, we recommend a single-acting control device and a depressurised return line. The hydraulic oil flows back into the hydraulic oil tank of the tractor through the free return line with a low back pressure. Thus, a free return line reduces heating-up of the hydraulic oil.

The hydraulic hose pipes are marked by colours at the hydraulic plugs, see chapter „Marking of hydraulic supply lines“, page 17.

2.10 Required tractor equipment

The employed tractor must meet the following requirements, in order to ensure correct use of the machine:

Tractor engine output and p.t.o. speed

Electrical system

Hydraulics

Maximum operating pressure: 200 bar

Delivery rate: min. 40 l/min at 180 bar, max. 100 l/min at 200 bar

Hydraulic oil of machine: HLP 46

Product description

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Hydraulic component

Required control device

Electro-hydraulic control block

Optional:

 1 single-acting control device with return line or

 1 double-acting control device or

 1 load-sensing connector

Electro-hydraulic forced steering axle system (SES system)

1 load-sensing connector

Brake system

Required connectors

Dual-line compressed-air brake system

 1 hose coupling (red) for the feed line

 1 hose coupling (yellow) for the brake line

Hydraulic brake system

1 hydraulic clutch according to ISO 5676

Control devices

Brake system

Additional equipment

When using the SES system, an additional ball head K 50 is required on the right-hand or left-hand side of the tractor's linkage drawbar.

2.11 Noise specifications

The workplace-related emission value (sound pressure level) is 74.0 dB(A), measured during operating mode at the driver's ear, the cabin being closed.

The sound pressure level mainly depends on the tractor used.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Observe all safety instructions included in these operating instructions!

Most accidents are caused by non-observance of simplest safety rules.

By observing all safety instructions included in these operating instructions, you help to prevent accidents.

WARNING

Risk of being crushed, cut, becoming entangled, being drawn in or risk of impact if the tractor and the machine are not in adequate roadworthy and reliable condition!

Check tractor and machine for their road and operational safety before each startup.

The operating instructions:

 must always be kept at the machine's place of operation,

 must always be easily accessible for operating and maintenance

staff.

3 Safety instructions

This chapter contains important information for the user and the operator on how to operate the machine in a safety-conscious and trouble-free way.

3.1 Safety-conscious working

Only operate the machine in perfect safety-related condition.

3.2 Organisational measures

3.2.1 User’s obligation

The user is obliged:

 to observe the general national occupational safety, accident prevention and environmental

protection rules,

 to exclusively have staff operating the machine who:

 know the basic occupational safety and accident prevention regulations,

 have been instructed how to operate the machine,

 have read and understood these operating instructions.

 to keep all warning signs attached to the machine in legible condition,

 to replace any damaged warning signs,

 to provide the necessary personal protective equipment such as protective goggles, work gloves

according to DIN EN 388, safety footwear, protective clothing, skin protectant, etc.

3.2.2 Operator’s obligation

Any members of staff charged to operate the machine are obliged:

 to acquaint themselves with the machine before starting operation,

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Only trained and instructed staff is allowed to operate the machine. The user must clearly define the responsibilities of the members of staff for operation, service and maintenance.

A person to be trained must be supervised when operating the machine.

The operator is only allowed to carry out such work as specified in these operating instructions which is not marked as "Shop work".

Only authorised workshops are allowed to carry out work on the machine which requires special expert knowledge. Authorised workshops have qualified staff and adequate means (tools, lifting and supporting equipment) at their disposal to carry out this work properly.

This applies to any work:

 which is not mentioned in these operating instructions,

 which is marked as "Shop work" in these operating instructions.

Person

Activity

Member of staff

especially trained for

the activity 1)

Instructed

person 2)

Person with professional

training (authorized

workshop) 3)

Loading/Transport

X X X

Commissioning

-- X X

Setup

-- X X

Operation

-- X X

Service and maintenance

-- X X

Trouble-shooting

-- X X

Rescue X --

Disposal X --

Legend:

X..allowed

--..not allowed

A person who is able to take on a particular task and is allowed to carry it out for an adequately qualified company.

A person is considered to be instructed if he or she has been informed about the tasks assigned to him or her and possible risks in case of improper behaviour and if he or she has been

 to acquaint themselves with the following regulations and to observe them during work:

 the general national occupational safety, accident prevention and environmental protection

rules,

 the chapter "Basic safety instructions“, page 30,

 the chapter „Warning and instruction signs“, page 39, and the warning signs when operating

the machine,

 the chapters of these operating instructions which are important for the tasks assigned to

them.

If the operator notices that a device is not in a sound safety-related condition, the operator shall be obliged to immediately eliminate this defect. If this is not part of the operator’s scope of tasks or he/she lacks adequate expert knowledge, the operator shall be obliged to report this defect to his/her superior or to the user.

3.2.3 Qualification of staff

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

instructed, if necessary, and if he or she has been advised of the necessary protective devices and measures.

Persons with professional training are considered to be qualified (expert). Due to their professional training and the knowledge of the relevant provisions, they are able to assess the tasks assigned to them and to identify possible risks.

Please note: A qualification which is equivalent to professional training may also be acquired by several years of practice in the corresponding field of work.

3.3 Product safety

3.3.1 Safety-conscious operation of machine

The machine is only allowed to be operated from the driver’s seat of the tractor, provided that no people are within the machine’s hazardous area. Observe the information in the chapter "Hazardous areas and dangerous spots", page 20.

3.3.2 Safety and protective devices

 Only operate the machine when all safety and protective devices are properly fixed and in fully

operable condition.

Defective or removed safety and protective devices might cause dangerous situations.

 Check all safety and protective devices for visible damage and functional ability before starting

the machine.

3.3.3 Structural alterations

 Vehicles provided with an official operating license or vehicle-linked devices and equipment

provided with an official operating license or a road traffic license according to the road traffic regulations must be in the condition specified by that license.

 You are only allowed to carry out structural alterations, extensions or modifications on the

machine with the prior written consent of the manufacturer.

 In case of non-authorized structural alterations, extensions or modifications:

 the declaration of conformity and the CE symbol of the machine will become invalid,

 the operating license according to national and international regulations will become invalid.

 Exclusively use original parts or modification and accessory parts approved by the manufacturer

such that:

 the declaration of conformity and the CE symbol of the machine will remain unaffected,

 the operating license according to national and international regulations will remain

unaffected,

 perfect functioning of the machine will be ensured.

 The manufacturer will not assume any liability for damage resulting from:

 unauthorized alterations of the machine,

 non-approved modification and accessory parts,

 welding and drilling work on load-bearing parts of the machine.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

3.3.4 Spare and wearing parts, auxiliary materials

Immediately replace machine parts which are not in perfect condition.

Exclusively use original parts of the manufacturer or parts approved by the manufacturer such that the operating license according to national and international regulations will remain unaffected. If spare and wearing parts produced by third-party manufacturers are used, their stress-related and safetyconscious design and production will not be ensured.

The manufacturer will not assume any liability for damage resulting from the use of non-approved spare and wearing parts or auxiliary materials.

3.3.5 Warranty and liability

As a basic principle, our "General Sales Terms and Delivery Conditions" shall apply. They have been handed over to the user upon conclusion of contract at the latest.

Any warranty and liability claims in case of personal injury and material damage will be excluded if they are due to one or several of the following reasons:

 improper use of the machine,

 improper assembly, commissioning, operation and maintenance of the machine,

 operation of the machine, the safety devices being defective or the safety and protective devices

having not been properly installed or being not serviceable,

 non-observance of the instructions included in the operating instructions referring to

commissioning, operation and maintenance,

 unauthorized structural alterations on the machine,

 insufficient inspection of machine parts which are subject to wear,

 improperly effected repairs,

 disasters due to foreign objects and force majeure.

3.4 Basic safety instructions

Basic safety instructions:

 shall, as a basic principle, apply to the safe operation of the machine,

 are summarized in the subsections below.

3.4.1 General safety and accident prevention instructions

 Observe the general national safety and accident prevention regulations in addition to the safety

instructions included in this chapter!

 Observe the warning and instruction signs attached to the machine. They provide important

information for the safe and trouble-free operation of the machine!

 Observe the activity-related safety instructions included in the other chapters in addition to the

basic safety instructions included in this chapter!

 Wear your personal protective equipment when carrying out work on the machine!

 Make sure that people leave the immediate vicinity of the machine before moving or starting the

machine! Particularly be aware of children!

 Never carry passengers, animals or objects on the machine! Carrying passengers and transport

of animals or objects are not allowed on the machine!

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Adapt your driving such that you have always safe control over the tractor with the

attached/hitched machine!

Consider your personal abilities as well as the road, traffic, visibility and weather conditions, the

driving characteristics of the tractor and the influences exerted by the attached/hitched machine.

 The following measures are imperative before carrying out any work on the machine such as

adjusting work or trouble-shooting:

 secure the machine against rolling with the machine not hitched to the tractor,

 turn the tractor engine off and secure tractor and machine against accidental starting and

rolling with the machine hitched to the tractor,

 secure lifted machine parts/the lifted machine against accidental lowering.

Hitch and unhitch machine

 Only use appropriate tractors to hitch and transport the machine!

 Properly hitch the machine to the specified devices!

 Be sure not to exceed the following values when hitching the machine to the front and/or rear of a

tractor:

 the gross vehicle weight rating of the tractor,

 the admissible axle loads of the tractor,

 the admissible tongue load at the tractor's coupling spot,

 the admissible towing capacity of the coupling device,

 the admissible load capacities of the tractor tyres,

 the tractor's front axle load must never fall below 20 % of the tractor's empty weight!

The tractor must reach the deceleration specified by the tractor's manufacturer even with

the machine attached / hitched up.

 Secure tractor and machine against rolling before hitching or unhitching the machine!

 People are not allowed between tractor and machine, while the tractor is approaching the

machine!

Present helpers are only allowed to act as a guide next to the vehicles and to enter the space

between the vehicles after the vehicles have completely stopped.

 Put the support device into support position when hitching and unhitching the machine (stability)!

 Risk of crushing and shearing when actuating support devices!

 Hitching and unhitching the machine to or from the tractor requires particular care! Crushing and

shearing zones exist within the area of the coupling spots between tractor and machine!

 Check the connected supply lines. Connected supply lines:

 must easily give way to any movements during cornering without any stress, buckling or

chafing,

 must not chafe against external components!

 Always park the unhitched machine in a stable position! Pay attention to the ground condition.

Beware of soft surfaces.

Use of machine

 Acquaint yourself with all mechanisms and operating elements of the machine and their functions

before starting work! During operation it will be too late.

 Wear close-fitting clothing! Loose-fitting clothing increases the risk of becoming entangled in or

wound up at drive shafts!

 Start the machine only if all protective devices have been installed and are in protective position!

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Observe the maximum load capacity of the attached/hitched machine and the admissible axle

and tongue loads of the tractor! Run the machine with the cargo space being only partly filled if necessary.

 People are not allowed:

 within the operating/hazardous area of the machine,

 within the discharge area of the machine,

 within the turning and swivelling range of movable machine parts,

 beneath lifted and unsecured movable machine parts!

 You are only allowed to operate powered machine parts if there are no people within the

machine’s hazardous area!

 Secure the tractor against accidental starting and rolling before leaving it!

 Safely support folded-up covers before standing underneath them!

Transport of machine

 Before carrying out transport journeys, check:

 the supply lines for proper connection,

 the lighting system for damage, proper functioning and cleanliness,

 the brake and hydraulic system for visible defects,

 whether the parking brake has been completely released,

 the brake system for proper functioning,

 whether the required transport equipment, such as lighting, warning and protective devices,

has been properly mounted on the machine!

 Check the braking effect before starting the journey! The tractor must produce the required

deceleration for the combination of tractor and attached/hitched machine!

 Always ensure sufficient steerability and braking ability of the tractor!

Machines attached/hitched to a tractor and front or tail weights influence the driving

characteristics as well as the steerability and the braking ability of the tractor.

 Observe the maximum loading capacity of the attached/hitched machine and the admissible axle

and tongue loads of the tractor!

 Observe the broad overhang and the flywheel mass of the machine when cornering with

attached/hitched machine!

 Set all movable machine parts to transport position and secure them before carrying out transport

journeys! Use the transport locks provided for this purpose!

3.4.2 Hydraulic system

 Only an authorised workshop is allowed to carry out work on the hydraulic system!

 Make sure that the hydraulic system on the tractor and on the machine has been depressurized

when connecting the hydraulic hose pipes!

 Ensure to properly connect the hydraulic hose pipes!

 Do not block any operating elements on the tractor, which serve to directly initiate hydraulic or

electrical movements of components, e. g. folding, swivelling and sliding operations!

The respective movement must automatically stop as soon as the operating element is released.

This shall not apply to:

 continuous movements of devices,

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 automatically controlled movements of devices,

 movements of devices which, for functional reasons, require an open-centre or pressing

position.

 Before carrying out any work on the hydraulic system:

 put the machine down,

 secure lifted movable machine parts against accidental lowering,

 depressurize the hydraulic system,

 turn the tractor engine off,

 pull the ignition key out,

 apply the parking brake.

 Have hydraulic hose pipes checked for their operational safety by an expert at least once a year!

 Hydraulic hose pipes must be replaced in case of visible defects, damage and ageing! Only use

original hydraulic hose pipes!

 The period of use of the hydraulic hose pipes should not exceed six years (including a maximum

possible shelf life of two years).

 Never try to block leaking hydraulic hose pipes with your hand or fingers! Immediately contact an

authorized workshop if a leak is suspected.

Hydraulic oil squirting out under high pressure may enter the skin and the body and cause

serious injuries.

If injuries caused by hydraulic oil occur, immediately contact the medical services. Risk of

infection!

 Never try to detect leakage points with your bare hands. Risk of serious infection! Use

appropriate means when trying to locate leakage points (cleaning sprays, special leak detector spray)!

3.4.3 Electrical system

 Before carrying out any work on the electrical system, disconnect the minus pole of the battery!

 Always cover the plus pole of the battery as required. Risk of explosion in case of accidental

ground!

 Only use the specified fuses. When using bigger fuses, the electrical system may be destroyed.

Risk of fire!

 Ensure correct order when connecting and disconnecting the battery:

 connection: first connect the plus pole, then the minus pole,

 disconnection: first disconnect the minus pole, then the plus pole!

 Avoid sparking and open fire in the vicinity of the battery! Risk of explosion!

 The machine can be equipped with electronic components and parts, the functioning of which

may be affected by electromagnetic emissions of other devices. Such interferences may be a risk to people if the following safety instructions are not observed:

 In case of a retrofitting of electrical devices or components into the machine and their

connection to the on-board electrical system, the user must check on his own responsibility whether the retrofitted parts interfere with the vehicle electronics or other components.

 Ensure that the retrofitted electrical and electronic components comply with the EMC

directive 2004/108/EC as amended from time to time and bear the CE symbol!

 Never fit the machine with additional work lights without authorisation! The manufacturer will not

assume any liability or warranty for subsequent damage on the electrical system.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

3.4.4 Propeller shaft operation

 The included operating instructions of the propeller shaft manufacturer shall apply!

 Only use the propeller shafts specified by the manufacturer and equipped with the proper

protective devices!

 Always transport the propeller shaft in horizontal position, in order to avoid injuries due to the

propeller shaft halves falling apart!

 Check the propeller shaft:

 protective tube and protective cone of the propeller shaft must be undamaged,

 a protective cover must be mounted to the tractor's and to the machine's p.t.o. shaft! The

 Working with the protective devices being damaged is not allowed!

 Mounting and dismounting of the propeller shaft is only allowed:

 Always ensure proper mounting and securing of the propeller shaft!

 Secure the propeller shaft guard against rotation by installing the chain/s!

 Always mount the wide-angle joint at the pivot point between tractor and machine when using a

 In case of propeller shafts equipped with overload or overrunning clutch, this clutch must always

 Before switching the propeller shaft on, check whether the selected speed and the sense of

 Make sure that people leave the hazardous area of the machine before switching the p.t.o. shaft

 Do not use the coupled propeller shaft as a step!

 Never switch the propeller shaft on with the tractor engine turned off!

 Observe the admissible angular misalignment and the travel of the propeller shaft when

 Observe the transport and working position of the specified tubular covers of the propeller shafts!

 People are not allowed within the range of the rotating propeller shaft when work with the

 Always switch the propeller shaft off if the angular misalignments occurring are too large or when

 Risk of injury due to the flywheel mass of the machine parts continuing to rotate for a short time

protective covers must be in proper condition!

 with the p.t.o. shaft switched off,

 with the tractor engine turned off,

 with the ignition key pulled out,

 with the parking brake applied!

wide-angle propeller shaft!

be mounted at the machine!

rotation of the tractor's p.t.o. shaft have been adjusted to the admissible drive speed and the sense of rotation of the machine!

on!

cornering!

propeller shaft is being carried out!

it is not required!

after the propeller shaft has been switched off!

Do not approach the machine too closely during that time! Do not carry out any work on the

machine until all machine parts have completely stopped.

 Secure tractor and machine against accidental starting and rolling before carrying out any

maintenance, cleaning, lubrication or setup work on machines powered by propeller shafts or before hitching/unhitching them!

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Place the uncoupled propeller shaft on the respective holder!

 Put the protective cover onto the p.t.o. shaft stub after the propeller shaft has been uncoupled!

3.4.5 Hitched machines

 Only couple admissible combinations of tractor and hitched machine!

 Observe the maximum admissible tongue load of the tractor at the coupling device in case of

single-axle machines!

 Always ensure sufficient steerability and braking ability of the tractor!

Machines attached/hitched to a tractor influence the driving characteristics as well as the

steerability and the braking ability of the tractor, in particular single-axle machines with the tongue load being exerted on the tractor.

 Only an authorized workshop is allowed to adjust the height of the drawbar for drawbars with

tongue load!

 Ensure sufficient tongue load at the support device when unhitching and parking a single-axle

machine!

Risk of tipping, particularly in case of unevenly charged machine (stability).

3.4.6 Brake system

 The brake system of the tractor must be compatible with the brake system of the machine!

 Immediately stop the tractor in case of a malfunction of the brake system. Have the malfunction

promptly remedied by an authorized workshop!

 Only authorized workshops or qualified personnel are allowed to carry out adjustment and repair

work on the brake system!

 Have the brake system regularly and thoroughly checked!

In order to maintain the operational safety, the wheel brakes must always be properly adjusted.

 Before carrying out any work in the brake system:

 safely park the machine and secure it against accidental rolling (chocks),

 secure the lifted machine/machine parts against accidental lowering!

 Especially beware when carrying out welding and drilling work and work involving open fire in the

vicinity of brake lines!

 As a basic principle, test the brakes after any adjusting and maintenance work on the brake

system!

Compressed-air brake system

 The compressed-air brake systems of the tractor and of the machine must be compatible!

 Clean the sealing rings at the hose couplings of the feed and brake lines from possible soiling

before hitching the machine!

 You are only allowed to start the tractor with the hitched machine moving when the pressure

gauge on the tractor indicates 5.0 bar!

 Drain the air reservoir every day!

 Cover the tractor's hose couplings before carrying out journeys without machine!

 Hang the couplings of the feed and brake line on the provided blank connections with the

machine unhitched!

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Do not modify the specified settings at the brake valves!

 Replace the air reservoir if:

 the air reservoir can be moved in the tensioning straps,

 the air reservoir is damaged,

 the type plate at the air reservoir is getting rusty, is loose or is missing!

Hydraulic brake system for export machines

 Hydraulic brake systems are not licensed for road traffic in Germany!

 Only use the specified hydraulic oils when topping up or changing oils. Observe the relevant

regulations when changing hydraulic oils!

3.4.7 Axles

As a basic principle, never overload the axles. Overloading of axles reduces the service life of the axle bearings and causes damage to the axles.

Therefore avoid:

 overloading of the machine,

 bumping into curbs,

 exceeding the speed limit,

 mounting wheels of wrong inserting depth,

 mounting wheels and tyres of wrong dimensions.

3.4.8 Tyres

 Safely park the machine and secure it against accidental lowering and rolling (parking brake,

chocks) before carrying out any work on the tyres!

 Only qualified personnel equipped with appropriate fitting tools is allowed to carry out repair work

on tyres and wheels! Mounting of wheels and tyres requires sufficient know-how and appropriate tools.

 Deflate the tyre before removing it!

 Regularly check the tyre pressure!

 Observe the maximum admissible tyre pressure. Risk of explosion in case of excessive pressure!

 Retighten all fastening screws and nuts according to the manufacturer’s specifications!

3.4.9 Operation of machine

 Ensure that the fastening elements fit properly before each startup of the machine!

 People are not allowed within the operating area!

 Do not approach rotating dosing drums!

 Climbing onto the transport floor is not allowed as long as the tractor engine is running!

 Passengers are not allowed on the machine!

 Unhitch the machine from the tractor only when empty!

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

3.4.10 Service and maintenance of machine

 Carry out the required service and maintenance work on the machine in due time!

 Observe the maintenance intervals for wearing parts!

 Secure the tractor against accidental starting and rolling before carrying out any service or

maintenance work on the machine or climbing onto the machine!

 Existing mechanical, hydraulic, pneumatic and electrical or electronic residual energies may

cause accidental machine movements!

Beware of existing residual energies in the machine when carrying out maintenance work.

Warning signs mark the components with residual energies. For detailed information, refer to the respective chapters of these operating instructions!

 Fix larger assemblies carefully to lifting equipment and secure them before replacing larger

assemblies!

 Secure the lifted machine or lifted machine parts against accidental lowering before carrying out

service or maintenance work on the machine!

 Regularly check screws and nuts for tightness! Retighten loosened screws and nuts!

 Check unscrewed joints for tightness. After finishing maintenance work, check the safety and

protective devices for proper functioning!

 Use appropriate equipment and gloves when replacing working tools with blades!

 Disconnect the generator and battery cable on the tractor before carrying out electrical welding

work on the tractor and/or on the attached/hitched machine!

 Dispose of oils, greases and filters properly!

 Properly handle and dispose of substances and materials used for cleaning the machine,

especially:

 when working on lubrication systems and devices,

 when carrying out cleaning work with solvents!

 Spare parts must at least comply with the specified technical standards of the manufacturer! This

is guaranteed when using original parts!

3.5 Activity-related safety instructions and important information

Activity-related safety instructions and important information are included in the operating instructions. Signal words and symbols help to identify activity-related safety instructions and important information at a glance.

3.5.1 Activity-related safety instructions

Activity-related safety instructions:

 warn about risks which may occur in a certain situation or in connection with a certain behaviour,

 are directly mentioned in front of a hazardous activity in the individual chapters,

 are marked by the triangular hazard symbol and a preceding signal word. The signal word refers

to the seriousness of the risk.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

DANGER

marks a direct danger bearing a high risk, which will cause most serious bodily injury (loss of limbs or long-term harm) or even death if it is not prevented.

Non-observance of the safety instructions marked by “DANGER“ directly causes most serious bodily injury or even death.

WARNING

marks a possible danger bearing a moderate risk, which might cause most serious bodily injury or even death if it is not prevented.

Non-observance of the safety instructions marked by “WARNING“ may cause most serious bodily injury or even death.

CAUTION

marks a possible danger bearing a low risk, which might cause light or moderate bodily injury or material damage if it is not prevented.

Non-observance of the safety instructions marked by "CAUTION" may cause light or moderate bodily injury or material damage.

IMPORTANT

marks an obligation to behave in a particular manner or to act in a certain way, in order to use the machine properly.

Non-observance of these instructions may cause malfunctions of the machine or in its vicinity.

INFORMATION

marks user hints and particularly useful information.

This information will help you to use all functions of your machine in the best possible way.

3.5.2 Important information

Important information:

 provides details for proper use of the machine,

 provides user hints for optimum use of the machine,

 is marked by the following symbols.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The following warning and instruction signs are attached to the machine:

 Warning signs mark dangerous spots on the machine and warn

about residual risks, which cannot completely be eliminated due to the machine’s operational safety.

 Instruction signs include information referring to proper use of

the machine.

Always keep these signs in clean and clearly legible condition! Replace illegible signs. Order the warning and instruction signs according to their order number:

 from the dealer,

 directly via the Strautmann spare parts warehouse

(+ 49 (0) 5424 802-30).

A warning sign consists of 2 pictographs:

(1) Pictograph for description of risk

The pictograph shows the pictographic

description of the risk, surrounded by a triangular hazard symbol.

(2) Pictograph for avoidance of risk

The pictograph shows the pictographic

instruction how to avoid the risk.

Fig. 7

3.6 Warning and instruction signs

3.6.1 Warning signs

Explanations of warning signs

The following list includes:

 in the right-hand column all warning signs attached to the machine,

 in the left-hand column the following details referring to the warning sign on the right-hand side:

 the order number.

 the description of risk, e.g. "Risk of crushing fingers or hand due to accessible movable

machine parts!"

 the consequences in case of non-observance of the instruction(s) how to avoid the risk, e.g.

"This risk may cause most serious injuries involving loss of limbs."

 the instruction(s) how to avoid the risk, e.g. "Never reach into the dangerous spot as long as

the tractor engine is running with the propeller shaft coupled/the hydraulic/ electronic system connected. Make sure that people leave the hazardous area of the machine before moving machine parts."

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Order number and explanation

Warning signs

87010270

Please read and observe the operating and safety instructions before commissioning!

87007120

Risks when carrying out work on the machine such as mounting, adjusting, trouble-shooting and maintenance, due to accidental starting or rolling of tractor and machine!

This risk may cause most serious injuries or even death.

 Secure tractor and machine against accidental starting and rolling before

carrying out any work on the machine.

 Read and observe the instructions in the respective chapters in the operating

instructions depending on the work to be carried out.

87007104

Risk to any part of the body of being crushed if people stand within the swivelling range of the tailgate!

This risk may cause most serious injuries or even death.

 People are not allowed within the swivelling range of the tailgate as long as

the tractor engine is running with the propeller shaft coupled/the hydraulic system connected.

 Make sure that people leave the swivelling range of the tailgate before

opening the tailgate.

87007110

Risk to any part of the body of being crushed due to necessary work underneath unsecured, suspended loads or lifted machine parts!

This risk may cause most serious injuries or even death!

Activate the safety locking mechanism against accidental lowering of suspended loads or lifted machine parts before entering the hazardous area.

87007117

Risk to any part of the body of being drawn in or becoming entangled due to powered working tools!

This risk may cause most serious injuries or even death.

Never enter the cargo space as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/electronic system connected.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

87007122

Risk of electrical shock or burns due to accidental touching of electrical overhead lines or due to inadmissible approach to high-voltage overhead lines!

This risk may cause most serious injuries or even death.

Keep sufficient safe distance to high-voltage overhead lines.

Nominal voltage

Safe distance to overhead lines

up to 1 kV

1 m

over 1 up to 110 kV

3 m

over 110 up to 220 kV

4 m

over 220 up to 380 kV

5 m

nominal voltage unknown

5 m

87007123

Risk due to hydraulic oil squirting out under high pressure, caused by leaking hydraulic hose pipes!

This risk may cause most serious injuries or even death if hydraulic oil squirting out under high pressure enters the skin and the body.

 Never try to block hydraulic hose pipe leaks with your hands or fingers.

 Read and observe the information included in the operating instructions

before carrying out service and maintenance work on hydraulic hose pipes.

87007124

Risk due to explosion or hydraulic oil squirting out under high pressure, caused by the pressure accumulator being under gas and oil pressure!

This risk may cause most serious injuries or even death if hydraulic oil squirting out under high pressure enters the skin and the body.

 Read and observe the information included in the operating instructions

before carrying out any work on the hydraulic system.

 If injuries caused by hydraulic oil occur, immediately contact the medical

services.

87007126

Risk to any part of the body of being rolled over by the machine due to accidental rolling of the machine parked in unsecured condition!

This risk may cause most serious injuries or even death.

Secure the machine against accidental rolling before unhitching the machine from the tractor or before parking the machine. Use the parking brake and/or the chock(s) for this purpose.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

87007130

Risk to any part of the body of being crushed if people stand within the swivelling range of the drawbar between the tractor and the hitched machine!

This risk may cause most serious injuries or even death.

 People are not allowed within the hazardous area between tractor and

machine as long as the tractor engine is running and the tractor has not been secured against accidental rolling.

 Make sure that people leave the hazardous area between tractor and

machine as long as the tractor engine is running and the tractor has not been secured against accidental rolling.

87010276

Risk to any part of the body of being drawn in or becoming entangled due to powered working tools!

This risk may cause most serious injuries or even death.

 Keep sufficient safe distance to powered working tools.

 Ensure that people keep sufficient safe distance to powered working tools.

87010278

Risk of becoming entangled and wound up due to the powered propeller shaft!

This risk may cause most serious injuries or even death.

 Keep sufficient safe distance to the propeller shaft as long as the tractor

engine is running with the propeller shaft coupled/the hydraulic system connected.

 Ensure that people keep sufficient safe distance to the powered propeller

shaft.

87010279

Risk of cuts for fingers and hands due to work on sharp / sharp-edged working tools!

This risk may cause most serious injuries including loss of limbs.

Observe the information in the operating instructions before carrying out work on sharp working tools.

87010280

Risk to hands or arms of being drawn in or becoming entangled in moving power transmission parts!

This risk may cause most serious injuries including loss of limbs.

Never open nor remove protective devices as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/electronic system connected.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

87010281

Risk to fingers or hands of being crushed due to accessible movable machine parts!

This risk may cause most serious injuries including loss of limbs.

Never reach into the hazardous area as long as the tractor engine is running with the propeller shaft coupled/the hydraulic/electronic system connected.

87010282

Risk of crushing, being drawn in or becoming entangled due to unprotected movable machine parts, caused by missing protective devices!

This risk may cause most serious injuries including loss of limbs.

Close open protective devices or mount previously removed protective devices before powering the machine.

87010283

Risk due to substances or foreign objects blown away from or out of the machine to people standing within the hazardous area of the machine!

This risk may cause most serious injuries to any part of the body.

 Keep sufficient safe distance to the hazardous area of the machine.

 Ensure that people keep sufficient safe distance to the hazardous area of the

machine as long as the tractor engine is running.

87010284

Risk to any part of the body of being crushed if people stand beneath the open, unsecured tailgate!

This risk may cause most serious injuries or even death.

 Never stand beneath the open tailgate without securing the tailgate against

accidental lowering.

 Ensure that there are no people beneath the open tailgate.

87010287

Dangerous situations may occur if load-bearing parts break due to mechanical work on frame elements!

This risk may cause most serious injuries or even death.

As a basic principle, the following work is not allowed:

 mechanical processing of the chassis,

 drilling at the chassis,

 boring up of existing holes at the chassis frame or at load-bearing parts,

 welding on load-bearing parts.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

87010289

Risk to any part of the body of being drawn in and becoming entangled due to powered working tools (pick-up and feeder rotor)!

This risk may cause most serious injuries or even death.

 Keep sufficient safe distance to powered working tools.

 Never reach into the hazardous are of powered working tools as long as the

tractor engine is running with the propeller shaft coupled/the hydraulic system connected.

 Ensure that people keep sufficient safe distance to powered working tools.

An instruction sign consists of a pictograph:

(1) Pictograph including information about

proper use of the machine.

The pictograph includes visual or

descriptive information or information summarized in a table.

Fig. 8

87007132

The required drive speed of the machine is 1000 min-1.

Before switching the propeller shaft on, check whether the selected speed and sense of rotation of the tractor's p.t.o. shaft have been adjusted to the admissible speed and sense of rotation of the machine.

87007133

Observe the information for braking axle maintenance included in the operating instructions.

87007134

Risk due to improper cleaning of the machine.

Absolutely observe the information in the chapter "Cleaning of machine", page 168 when using a pressure washer/steam blaster for cleaning the machine.

3.6.2 Instruction signs

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

87010288

This pictograph illustrates fixing points for lifting equipment (jack).

87010285

Close the stop-cock (position 0) to secure the tailgate before carrying out work beneath the lifted tailgate.

Safety instructions

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 9

3.6.3 Placing of warning and instruction signs

The following figures illustrate the position of the warning and instruction signs on the machine.

Loading and unloading

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Observe the information in the chapter "Basic safety instructions", page 30.

WARNING

Risk to people due to uncontrolled movements of the tractor and the machine if insufficient stability and insufficient steerability and braking ability of the tractor occur!

 Properly hitch the machine to the tractor before loading or

unloading the machine onto or from a transport vehicle.

 When hitching and transporting the machine for loading and

unloading, only use a tractor which meets the performance requirements and can safely slow down the machine..

If the machine is equipped with a compressed-air brake system,

you are only allowed to start moving the machine when the pressure gauge on the tractor indicates 5.0 bar.

3.7 Risks in case of non-observance of safety instructions and warning signs

Non-observance of the safety instructions and warning signs may:

 cause risk to people, environment and machine such as:

 risk to people due to non-secured work areas,

 failure of essential machine functions,

 failure of specified methods for the use, service and maintenance of the machine,

 risk to people due to mechanical and chemical effects,

 threat to the environment due to leaking operating media.

 lead to invalidation of any claims for damages.

4 Loading and unloading

Loading and unloading by means of tractor

Loading and unloading

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 10

WARNING

Risk of crushing and/or impact to people if the lifted machine accidentally comes down!

 Use appropriate slings which are able to safely carry the

machine’s weight.

 Never stand within the lifting zone beneath the lifted machine.

Fig. 11

(1) Load bearing points (on both sides)

(2) Contact surface (on both sides); use a suitable base (e.g. hardwood)

Loading and unloading by means of lifting equipment (for lifting into containers)

(1) Spacer

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Observe the information in the chapter "Basic safety instructions", page 30.

The pick-up (1) is movably hinged to the CFS drum and picks up the material to be loaded from the swathe by means of its 6 tine rows.

Lifting and lowering of the pick-up to transport and working position is effected via the control system from the tractor seat by means of two single-acting hydraulic cylinders.

The steerable, rubber-tyred roller feelers (2) move the pick-up into its working position. The roller feelers serve to:

 adapt the pick-up in working position to

uneven terrain.

 set different operating heights for the pick-

up lowered to working position. The operating height is set via the respective perforated strut (3) on both sides of the pick-up.

The pick-up can be equipped with the additional roller feelers (4) (optional extra). The additional roller feelers run outside the track of the tractor thus assisting the roller feelers in guiding the pick-up in working position on particularly soft ground.

Dangerous spots exist within the area of the pick-up due to functional reasons.

Fig. 12

Fig. 13

5 Design and function

The following chapter provides information about the design of the machine, its function and the handling of the individual components.

Some of the machines are illustrated with optional extras. Optional extras are marked in these operating instructions and are available at extra cost.

5.1 Pick-up

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The pick-up is driven by means of the feeder rotor via the angular switchgear (1) and the angular gear CFS (2).

The friction clutch (2) protects the powertrain leading to the pick-up against damage in case of overload and temporary torque peaks at the pickup.

Fig. 14

The pick-up and the dosing drums are driven by means of the feeder rotor via the angular switchgear (1), the angular gear CFS (2) and the rear angular gear.

The clutches (3, 4) of the angular switchgear are coupled with the hydraulic cylinders of the tailgate via the hydraulic cylinders (5, 6). When opening and closing the tailgate:

 the hydraulic cylinder (5) actuates the clutch

(3) and engages or disengages the powertrain (7) leading to the dosing drums.

 the hydraulic cylinder (6) actuates the clutch

(4) and engages or disengages the powertrain (8) leading to the pick-up.

The friction clutch (9) protects the powertrain leading to the pick-up against damage in case of overload and temporary torque peaks at the pickup.

Fig. 15

5.1.1 Pick-up drive

Machine without dosing drums

Machine with dosing drums

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Switch silage additive pump on/off

Actuate switch (1) at the hydraulics protective device to switch the pump on or off.

Power supply: 12 V

Maximum current: 3 A

Observe the information in the chapter "Switch cargo space lighting on/off", page 126.

WARNING

Risk of being drawn in and becoming entangled by the powered pick-up!

Never use the machine without holding-down device with pulley (1), as holding-down-device and pulley also serve as a protective device.

5.1.2 Silage additive pump

Optional extra

The drive of the silage additive pump is connected with the open-centre position of the pick-up via the control system.

If the pick-up is switched to open-centre position with the control system switched on, the silage additive pump sprays silage additives.

The open-centre position of the pick-up must be switched off at the control set to interrupt the spraying of silage additives, in order to possibly reduce the dosage of the silage additive.

Easy-to-use control

ISOBUS control

Switch on silage additive pump

1. Press and hold the Lighting cargo space key once.

 The silage additive pump is switched on.

Switch off silage additive pump

1. Press and hold the Lighting cargo space key once again.

 The silage additive pump is switched off.

5.1.3 Holding-down device with pulley

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

When picking up the material to be loaded, the holding-down device and the advancing pulley (1) press the material against the spring-loaded tines of the pick-up. The distance set between the holding-down device/pulley and the pick-up is vital for proper picking-up of the material from the swathe.

The length of the chains (2) determines the distance between holding-down device/pulley and pick-up:

 large swathe = large distance between

holding-down device/pulley and pick-up

 small swathe = small distance between

holding-down device/pulley and pick-up

Fig. 16

The feeder rotor (1) interacts with the cutting unit (2) and transports the material picked up by the pick-up (3) through the conveyor duct into the cargo space. The CFS drum (4) conveys the picked-up material into the outer parts of the feeder rotor which are subject to less strain, thus distributing the strain over the entire width of the feeder rotor and the cutting unit.

Strippers (5) protrude into the gaps between the conveying tines (6) of the feeder rotor thus preventing the feeder rotor from becoming clogged.

Fig. 17

5.2 Feeder rotor

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The cutting unit (1) engages into the conveyor duct (2). The cutting unit can be extended into and retracted from the conveyor duct by means of two double-acting hydraulic cylinders (3) actuated via the control set:

 for elimination of blockages,

 for return of cutting knives evaded to the

rear to their original position,

 for removal and installation of cutting

knives.

The number of cutting knives (4) mounted in the cutting unit determines the cutting length of the loaded material. 36 cutting knives can be mounted. The shortest theoretical cutting length is then 39 mm.

Fig. 18

Blunt cutting knives (1) can be turned over once. Thus, the grinding interval doubles.

Each individual cutting knife is able to evade foreign objects. If a cutting knife encounters a foreign object, it will evade to the rear and remain in that position. This knife security system protects the cutting knives against damage.

In order to return the cutting knife to its working position, the cutting unit must be completely retracted and extended once.

Fig. 19

The knife bag (1) for unused cutting knives or spare cutting knives is positioned at the righthand front of the axle support close to the parking brake.

Fig. 20

5.3 Cutting unit

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The sensor (1) monitors the position of the cutting unit.

A light barrier monitors the position of the individual cutting knives and the soiling degree of the cutting unit. The light barrier consists of the transmitter (2) and the receiver (3).

The following positions of the "Cutting Unit" symbol are available on the control set:

 "Cutting unit extended" position if the cutting

unit has been completely extended into the conveyor duct.

 "Cutting unit retracted" position if the cutting

unit has not been extended into the conveyor duct.

 "Cutting knife out" position:

 as soon as a cutting knife evades to

the rear,

 as soon as the cutting unit is heavily

soiled.

Fig. 21

The chains (1) of the transport floor are equipped with U-sections (2) and ensure consistent feeding of the loaded material when charging and discharging. Automatic chain tensioners tighten the chains.

The transport floor is driven hydraulically via two feed gearings.

The control set serves to:

 switch the transport floor on and off,

 variably adjust the feed rate of the transport

floor. The controllable volume flow of the hydraulic oil is 2-80 l/min.

 reverse the feed direction of the transport

floor for a short time (max. 3 seconds), e. g. to eliminate blockages occurred at the dosing drums during discharge.

Fig. 22

5.4 Transport floor

5.4.1 Set feed rate of transport floor (easy-to-use control)

Observe the information in the chapter "Change feed rate of transport floor", page 110.

5.4.2 Set feed rate of transport floor (ISOBUS control)

The feed rate of the transport floor depends on the set filling degree. Observe the information in the chapter "Pre-select filling degree of loaded material in cargo space", page 136.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Switch the automatic charging system on for uniform and complete filling of the cargo space.

The automatic charging system:

● has to be switched on only once,

● automatically switches the transport floor on and off during charging,

● is automatically deactivated if the easy-to-use control set generates an acoustic signal (horn sound) and a visual signal ("Forage wagon full"),

● is automatically activated if the forage wagon has been emptied and the pick-up is lowered the next time,

● remains switched on until the automatic charging system is manually switched off.

The automatic charging system only works with the pick-up lowered.

The automatic charging system:

● is mounted at the load-protection bars and mainly consists of the sensing band (1), the gear shifting gate (2) and the limit switch (3),

● is connected with the hydraulic drive of the transport floor in ON mode,

During charging, the loaded material piles up at the front panel of the cargo space. If the loaded material piling up deflects the sensing band (1) upwards, the hydraulic drive of the transport floor starts and conveys the loaded material backwards. The transport floor stops as soon as the loaded material does not deflect the sensing band (1) upwards any more.

The position of the gear shifting gate (2) with respect to the sensing band (1) determines the switch-on behaviour for the transport floor. The gear shifting gate (2) can be fixed to the sensing band (1) in different positions, in order to change the filling degree of the cargo space.

Low filling degree = smaller deflection of sensing band

High filling degree = larger deflection of sensing band

● Sensing band in upper switch position

→ The automatic charging system is switched on.

Fig. 23

Auto

5.5 Load-protection bars with integrated automatic charging system

5.5.1 Easy-to-use control of automatic charging system

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The automatic charging system (1):

 can be switched on and off via the ISOBUS

control set,

 mainly consists of the sensing band (2), the

actuating plug (3) and the control dial (4),

 switches the transport floor automatically on

and off for uniform and complete filling of the cargo space,

 permits to adapt the filling degree of the

loaded material in the cargo space in 5% steps.

Fig. 24

The higher the set filling degree, the higher the transport floor feed rate and the smaller the filling capacity.

5.5.2 ISOBUS control of automatic charging system

When using the machine as a forage wagon, the loaded material piles up at the front grating of the cargo space during charging. The loaded material piling up deflects the sensing band upwards and actuates the control dial via the actuating plug.

As soon as the deflected sensing band reaches the lowest set position, the transport floor automatically starts running at low feed rate and conveys the loaded material to the back. Increasing filling of the front section of the cargo space initiates a further deflection of the sensing band. The feed rate of the transport floor increases in proportion to the deflection of the sensing band.

As soon as the deflected sensing band reaches the highest set position, the loaded material is conveyed to the back at maximum feed rate. The transport floor stops as soon as the front section in the cargo space has been cleared and the loaded material does not deflect the sensing band upwards any more.

A calibration of the automatic charging system helps to separately set the lowest position of the sensing band for switching the transport floor on and off and the highest position of the sensing band to switch over to maximum feed rate. Observe the information in the chapter "Calibrate automatic charging system", page 136.

5.5.3 Deactivate automatic charging system and stop transport floor

Machine without dosing drums

An electrical pressure switch as signal generator for the automatic charging system is mounted on the inside of the tailgate. If the machine is fully charged:

 the ISOBUS control set will generate an acoustic signal (horn sound) and a visual signal "Forage

wagon full".

 the automatic charging system will be deactivated and the automatic feed function for the

transport floor will be switched off.

Machine with dosing drums

The bottom dosing drum will evade to the rear if the loaded material applies a particular pressure to this dosing drum. The switching plate releases an electrical pressure switch and disconnects the automatic charging system and the hydraulic drive of the transport floor. The control set simultaneously displays the message "Forage wagon full".

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

When lifting the tailgate, the hydraulic cylinders first vertically lift the tailgate out of its locking mechanism. The tailgate then swivels upwards to the rear and raises completely.

When lowering the tailgate, it initially comes down due to its dead weight. The hydraulic cylinders only come into operation at the last moment to close the tailgate and lower it vertically onto the locking pin for being locked.

An electrical pressure switch as signal generator for the automatic charging system is mounted on the inside of the tailgate.

Fig. 25

When opening the tailgate, the hydraulic cylinders (1) swivel the tailgate (2) back upwards. The tailgate can then be opened at different opening widths.

The first opening width of the tailgate (discharge position) can be individually set via the control set and the tailgate is automatically moved to that position when pressing the Lift tailgate key. When releasing and pressing the Lift tailgate key again, the tailgate rises as long as the key is pressed or until the tailgate has been completely lifted.

Fig. 26

These measures are intended to prevent the loaded material from being too strongly pressed against the dosing drums and the drums from becoming clogged during discharge.

During discharge, the hydraulic drive of the transport floor automatically restarts as soon as the loaded material is no longer applying any pressure to the bottom dosing drum.

5.6 Tailgate

The tailgate can be swivelled hydraulically and closes the cargo space on the rear side. The tailgate is lifted and lowered by means of two hydraulic cylinders via the control set.

5.6.1 Tailgate on machines without beaters

5.6.2 Tailgate on machines equipped with beaters

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Forage wagons equipped with beaters can be fitted with the crossover conveyor for stablefeeding or for charging the following conveying devices.

The crossover conveyor (1):

 is mounted at the rear below the beaters,

 is powered by a hydraulic motor,

 can be powered in two driving directions.

Depending on the driving direction, the green fodder is discharged on the right- or left-hand side of the forage wagon.

The ISOBUS control set serves to

 switch the crossover conveyor on and off,

 change the driving direction.

Fig. 27

The tailgate can be locked via the stop-cock to secure it against accidental lifting and lowering.

The stop-cock is positioned on the right-hand side of the tailgate.

The table shows the meaning of the stop-cock positions.

Fig. 28

Stop-cock

Tailgate

Activity

0 - closed

lifted and locked

trouble-shooting, cleaning, service and

maintenance work

I - open

not locked

lifting and lowering possible

charging discharging

5.6.2.1 Crossover conveyor (optional extra)

5.6.3 Lock tailgate

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Machines with the type designation "DO" are equipped with 2 or 3 beaters (1), depending on the version.

The p.t.o. shaft of the tractor powers the bottom beater via the propeller shaft, main gearbox, front drive shaft, front angular gear, claw clutch, lateral drive shaft and rear angular gear. The individual beaters are connected with each other by means of roller chains. Each roller chain is equipped with a chain tensioner.

Hydraulic disconnection of transport floor

The bottom beater:

 is movably mounted on the left-hand side in

the direction of motion.

 evades to the rear if the loaded material

applies a particular pressure to this beater.

The switching plate releases an electrical

pressure switch and disconnects the hydraulic drive of the transport floor. The control set simultaneously displays the message "Forage wagon full".

These measures are intended to prevent the loaded material from being too strongly pressed against the beaters and the beaters from becoming clogged during discharge.

During discharge, the hydraulic drive of the transport floor automatically restarts as soon as the loaded material is no longer applying any pressure to the bottom beater.

Fig. 29

Access door (1), ladder (2) and handle (3) permit access to the cargo space. The locking mechanism (4) secures the closed access door and the folded-up ladder in transport position.

Fig. 30

5.7 Dosing drums

5.8 Access door and ladder

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 The actuating speed of the hydraulic functions (hydraulic

components) depends on the tractor's hydraulic system.

Depending on the tractor model, a correction of the set actuating

speed at the tractor's control device/the machine's control block may be necessary.

 For information about the required control devices, refer to the

chapter "Required tractor equipment", page 25. For information about the hose markings, refer to the chapter "Marking of hydraulic supply lines", page 17.

(1) Hose holder for proper deposition of supply

lines.

Fig. 31

5.9 Hydraulic system of machine

The hydraulic system of the machine:

 can be operated at a maximum of 100 l/min.,

 has been designed for open or closed-centre hydraulic systems. The conversion from open to

closed-centre hydraulic system is carried out by means of the load-sensing screw at the electrohydraulic control block.

All hydraulic functions of the machine are operated via the control set. The individual hydraulic components of the machine are connected to the electro-hydraulic control block of the machine for this purpose.

The hydraulic system of the machine is ready for operation if:

 the electro-hydraulic control block has been connected to the hydraulic system of the tractor and

 the oil circulation between tractor and machine has been switched on via the control device on

the tractor.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Electro-hydraulic control block

(2) Basic block with proportional directional

control valves for transport floor drive with:

(2.1) Connecting aperture for load-sensing

control line

(2.2) Proportional directional control valve

for transport floor

(2.3) Pressure limiting valve for priority

function (190 bar) (2.4) Pick-up (2.5) Reverse transport floor (2.6) Pre-selection solenoids

(2.7) Load-sensing screw for disabling the

pressure regulator with the load-

sensing control line mounted:

 Screw unscrewed = fixed

displacement pump

 Screw screwed in = LS-mode

(3) Intermediate plate with directional seat

valves for:

(3.1) Folding drawbar and drawbar

suspension (3.2) Tailgate and switchgear, dosing unit

circuit (3.3) Cutting knives

(3.4) Pressure limiting valve for cutting unit

The pressure limiting valve is set to 140 bar, in order to prevent the cutting unit and the cutting knives from being damaged, while the cutting unit is extended into the conveyor duct.

Optional:

(4) End plate with directional seat valves for

steering axle

(5) End plate with directional seat valves for

tridem lift axle (not available here)

Fig. 32

Fig. 33

5.9.1 Electro-hydraulic control block

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Connect the hydraulic system only after it has been

depressurized.

 Turn the tractor engine off before connecting the hydraulic

system.

 Always connect the load-sensing control line when connecting

the hydraulic connector "Flow line" directly to the hydraulic pump of the tractor.

Tractor

machine

Fig. 34

Open the pressure regulator via the load-sensing screw in the electrohydraulic control block when the hydraulic connector "Flow line" has been connected to the control device of the tractor. Unscrew the loadsensing screw as far as it will go for this purpose.

Disconnect the load-sensing control line from the load-sensing connector of the tractor before operating the machine with free pressure regulator.

5.9.1.1 Load-sensing hydraulic system

The electro-hydraulic control block of the machine is directly connected with the hydraulic pump of the tractor via the load-sensing control line. The current machine demand for hydraulic oil determines the pressure and the delivery rate of the tractor's hydraulic pump.

(1) Electro-hydraulic control block of the machine

(2) Load-sensing control line

(3) Adjustable hydraulic pump of tractor

(4) Hydraulic connector "Return line", connected to a free return port, not via control device

(5) Hydraulic connector "Flow line", directly connected to hydraulic pump of tractor, oil supply not via

control device

Connect load-sensing control line

1. Screw the load-sensing control line (2) into the connecting aperture (Fig. 32/2.1) of the electrohydraulic control block.

2. Lock the pressure regulator in the electro-hydraulic control block. For this purpose

2.1 screw the load-sensing screw (Fig. 32/2.7) in as far as it will go.

3. Connect the load-sensing control line (2) to the load-sensing connector of the tractor.

4. Connect the hydraulic connector "Return line" (4) to a free return port of the tractor.

5. Connect the hydraulic connector "Flow line" (5) directly to the hydraulic pump of the tractor.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

DANGER

Risk due to dangerous movements of movable components when actuating the emergency manual operation function!

Before actuating the emergency manual operation function, make sure that third persons leave the machine’s hazardous area.

Unscrew the knurled screws completely again after having carried out the emergency manual operation function.

Fig. 35

5.9.1.2 Electrical system – Emergency manual operation

In case of failure of the electrical system, the solenoids for switching the directional control/seat valves can be actuated directly at the electro-hydraulic control block (1) via the emergency manual operation function.

 Pre-selection valves (2):

Use a blunt object (3) to push in the armature of the solenoid at the respective control valve to

actuate the required hydraulic functions.

 Intermediate plates (4) and end plates (5):

Screw in the knurled screw (6) at the required directional control/seat valve.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Solenoid valves

Functions

Retract (out)

Extend (in)

Lift

Lower

Lift

Lower

Lift

Lower

Forward

Reverse

Unlocked

Locked

Lift

Lower

ccw rotation *

cw rotation *

Closed *

Open

(X)Y12

(X)Y13

(X)Y1

(X)Y2

(X)Y3

(X)Y9

(X)Y10

(X)Y4

(X)Y6

(X)Y7

(X)Y22

(X)Y21

5.9.1.3 Functional diagram for emergency manual operation

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Solenoid valves

Functions

Retract (out)

Extend (in)

Lift

Lower

Lift

Lower

Lift

Lower

Forward

Reverse

Unlocked

Locked

Lift

Lower

ccw rotation *

cw rotation *

Closed *

Open

(X)Y15 *

(X)Y14 *

(X)Y16 *

(X)Y17 *

(X)Y30

(X)Y31

Optional extra

The following example explains the procedure for actuating the emergency manual operation function.

Example:

Retract cutting unit

1. Screw in the knurled screws (1, 2) at the directional seat valves (X)Y12 and (X)Y13.

2. Use a blunt object to push in the armature of the solenoid (X)Y31 (3).

 The cutting unit retracts.

3. Unscrew the knurled screws completely again.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 36

WARNING

Risk of infection to people due to hydraulic oil squirting out under high pressure and entering the body!

Make sure that the hydraulic system on the tractor and on the machine has been depressurized when connecting and disconnecting the hydraulic hose pipes. Always swivel the operating element at the control device on the tractor to open-centre position.

WARNING

Risk of being crushed, cut, becoming entangled, being drawn in and risk of impact to people due to malfunctions caused by improperly connected hydraulic hose pipes!

 Check the assignment of the hydraulic hose pipes at the control

block of the machine if the coloured markings (dust caps) are missing:

 P = Pressure line

 T (R;S) = Return line

5.9.2 Hydraulic hose pipes

5.9.2.1 Connect hydraulic hose pipes

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Check the compatibility of the hydraulic oils before connecting

the machine to the hydraulic system of your tractor.

 Do not mix mineral oils with bio oils!

 Observe the maximum admissible operating pressure of the

hydraulic oil.

 Only connect clean hydraulic plugs and hydraulic sleeves.

 Slip the hydraulic plug into the hydraulic sleeve until the

hydraulic plug noticeably locks.

 Check the coupling spots of the hydraulic hose pipes for correct

and tight seat.

 Connected hydraulic hose pipes:

 must easily give way to any movements during cornering

without any stress, buckling or chafing,

 must not chafe against external components.

CAUTION

Risk of burns due to contact with hot hydraulic hose pipe components!

Do not touch considerably warmed-up components of the hydraulic hose pipes (particularly do not touch any hydraulic plugs and hydraulic sleeves).

Dru

1. Swivel the respective operating element at the control device on the tractor to open-centre position.

2. Connect the hydraulic hose pipes to the control devices of the tractor:

2.1 Pressure pipe to a single-acting or double-acting control device.

2.2 Return pipe to a depressurized return port if possible.

5.9.2.2 Disconnect hydraulic hose pipes

Dru

1. Swivel the respective operating element at the control device on the tractor to open-centre position.

2. Unlock the hydraulic plugs from the hydraulic sleeves.

3. Use the dust caps to protect the hydraulic plugs and the hydraulic sleeves against soiling.

4. Put the hydraulic hose pipes down onto the hose holder.

5.10 Chassis

Depending on the machine's equipment, the chassis consists of:

 a Bogie tandem chassis:

 with follow-up steering

 with forced steering axle (only in case of bottom linkage)

 with dual-line compressed-air brake system and mechanical automatic load-sensitive brake

pressure regulator

 a hydro-pneumatic tandem chassis with hydraulic levelling system:

 with follow-up steering

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Observe the fact that the steering rod is spring-loaded!

 When coupling the steering rod, a certain resistance must be

overcome.

 During uncoupling, the steering rod is pulled towards the

drawbar and held there.

The shell/drawbar lug must be fixed to the coupling device of the tractor free of clearance if possible, such that the forced steering axle can properly work.

 with forced steering axle (only in case of tandem chassis with bottom linkage)

 with dual-line compressed-air brake system and mechanical automatic load-sensitive brake

pressure regulator

5.10.1 Bogie tandem chassis

3-leaf parabolic springs serve as a compensating rocker arm in the bogie tandem chassis. In case of bumps, the large swing paths ensure an even load distribution onto both axles.

5.10.2 Steering axle for follow-up steering

The unlocked steering axle for follow-up steering:

 can move freely and follows the turning radius of the corner during cornering,

 ensures careful treatment of farmland during cornering,

 reduces tyre wear during cornering on paved areas.

The steering axle is unlocked and locked from the tractor via the control unit.

5.10.3 Steering axle for electro-hydraulic forced steering axle system SES (only with bottom linkage and ISOBUS control)

Optional extra

The the wheels of the steering axles for the electro-hydraulic forced steering axle system are electronically controlled from the tractor via a steering rod by means of the SES system.

The steering axle:

 has been designed for ball-type couplings,

 improves the manoeuvrability of the hitched machine and prevents the tyres from being

excessively worn during forward and reverse cornering,

 does not require any engaging,

 is locked in Discharge mode A I up to 12 km/h,

 can be unlocked and relocked by actuating the Discharge mode A I for turning the machine in

front of the bunker silo.

5.10.3.1 Couple forced steering axle

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1. Hitch the machine to the tractor.

2. Secure tractor and machine against accidental starting and rolling.

3. Couple and secure the steering rod (1) with the ball head to the right-hand side of the tractor.

Set the steering rod such that the left-hand

edge of the lever (2) is positioned in one line with the right-hand edge of the orientation notch (3) (A) if tractor and machine are in one line.

4. Completely turn the steering wheel of the tractor.

5. Carefully start to move until the left-hand edge of the lever is flush with the right-hand edge of the respective lateral orientation notch (4).

 The wheels of the tractor should now be in

contact with the drawbar.

 If the steering range was exceeded, the

"Steering axle unlocked" symbol is flashing and a beep is emitted. The passive steering is activated.

Fig. 37

 If the system returns to the specified

steering range, the "Steering axle unlocked" symbol goes out and a beep is emitted.

6. Check any free space and possible steering angles for collision.

The screen shows:

In the case of the electro-hydraulic forced steering axle system, the

key has a touch-control design.

1. Press the key as long as the steering axle shall be locked.

 The "Steering axle locked" symbol appears

and a beep is emitted. The steering axle is locked in "Straight" position.

 If the symbol is flashing, the steering axle

could not be completely locked. Check the steering system.

The screen shows:

5.10.3.2 Lock forced steering axle

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The hydraulic folding drawbar (1) serves to increase the ground clearance of the pick-up (2) when travelling over the silo.

Lifting and lowering of the folding drawbar:

 is carried out by means of two double-

acting hydraulic cylinders (3),

 is carried out via the easy-to-use control or

ISOBUS control.

Fig. 38

Depending on the design of the tractor's coupling device, the folding drawbar can be coupled to the tractor by means of a top hitch or bottom hitch.

Depending on the design of the tractor's coupling device, the drawgear may be:

 a drawbar lug 40 according to DIN 11043

for a bolt-type coupling according to DIN 11028/ISO 6489-2,

 a shell 80 (1) for a ball-type coupling 80.

Fig. 39

WARNING

Risk of being crushed, drawn in, becoming entangled and risk of impact to people if the machine accidentally loosens from the tractor!

 Check whether the coupling device on your tractor is licensed for

taking up the machine's drawgear.

Absolutely observe the information in the chapter "Preconditions

for the operation of tractors with rigid drawbar trailers"“, page 87.

 Properly hitch the machine to the tractor and secure it.

 Never use damaged or deformed trailer systems.

5.11 Drawbar

The machine is equipped with a hydraulic folding drawbar.

5.11.1 Hydraulic folding drawbar

5.11.2 Couple drawbar

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk of being crushed and of impact to people standing between tractor and machine while the machine is being hitched!

Make sure that people leave the hazardous area between tractor and machine before approaching the machine.

Present helpers are only allowed to act as a guide next to the tractor and the machine and to enter the space between the tractor and the machine after the vehicles have completely stopped.

WARNING

Risk of being crushed, drawn in, becoming entangled and risk of impact to people if the machine accidentally loosens from the tractor!

 Before travelling on extremely uneven ground/over bunker silos,

ensure that there is enough free space at the holding downdevice above the shell.

 Mount the shorter holding-down device at the tractor's ball-type

coupling in case of insufficient free space.

Lubricate the coupling device every day to minimize wear on the ball head and the shell. Lubricate the area between the holding-down device and the surface of the shell as well.

(1) Shorter holding-down device for ball-type

coupling

Fig. 40

5.11.2.1 Bolt-type coupling

1. Prepare for coupling:

1.1 Lock the grab jaw of a bolt-type coupling with movable grab jaw (non-automatic bolt-type coupling).

1.2 Open the hitch, i. e. it should be in a pre-coupling position (automatic bolt-type coupling).

2. Reverse the tractor until the bolt-type coupling engages into the drawbar lug.

3. Secure the tractor against accidental starting and rolling.

4. Check that the connection is secure after coupling:

4.1 Secure the inserted coupling bolt by positive locking (non-automatic bolt-type coupling).

4.2 Ensure that the automatic bolt-type coupling is locked (control pin, end position of operating lever, etc.).

5. Connect the supply lines.

6. Release the parking brake of the machine.

7. Lift the supporting leg to transport position.

5.11.2.2 Ball-type coupling and shell

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk of being crushed, cut, drawn in, becoming entangled and risk of impact to people due to insufficient stability of the unhitched machine!

 Park the empty machine on even, firm ground.

 Secure the machine against rolling.

1. Secure the tractor against accidental starting and rolling.

2. Secure the machine against rolling. Observe the information in the chapter "Secure tractor and machine against accidental starting and rolling".

3. Lower the supporting leg to support position such that the drawbar no longer transmits any tongue load to the tractor.

4. Disconnect the supply lines.

5. Place the supply lines onto the hose holder.

6. Prepare unhitching:

 Remove the coupling bolt (non-automatic bolt-type coupling).

 Open the trailer hitch (automatic bolt-type coupling).

7. Move the tractor forward.

1. Prepare for coupling:

1.1 Remove grease and dirt from the ball head, the holding-down device and the shell.

1.2 Lubricate the ball head and the surface of the shell with new grease.

1.3 Unlock the holding-down device at the bearing block.

1.4 Swivel the holding-down device to coupling position.

1.5 Clean and grease the ball head.

2. Connect the supply lines.

3. Approach the machine as closely as possible such that the ball head can take up the shell.

4. Lower the drawbar by means of the supporting leg until the ball head engages in the shell.

5. Lock and secure the holding-down device at the bearing block.

6. Release the parking brake of the machine.

7. Lift the supporting leg to transport position.

5.11.3 Uncouple drawbar

5.11.3.1 Bolt-type coupling

5.11.3.2 Ball-type coupling and shell

1. Lift the folding drawbar.

2. Secure the machine against rolling.

3. Unlock the holding-down device at the bearing block.

4. Swivel the holding-down device to coupling position.

5. Lower the supporting leg to support position such that the shell disengages from the ball head.

6. Move the tractor forward (approx. 25 cm).

7. Secure tractor and machine against accidental starting and rolling.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The drawbar suspension of the hydraulic folding drawbar (1) ensures an even smoother ride during transport journeys and consists of a hydraulic accumulator and a control block (4). Hydraulic accumulator and control block interact with the hydraulic cylinders (3) of the folding drawbar.

With the drawbar suspension switched on, the machine fully filled and the hydraulic cylinders extended by approx. 20 mm, the deflection is approx. 10 mm. For the empty machine, the deflection is accordingly less.

The drawbar suspension:

 is only allowed to be switched on during

transport journeys,

 must, as a basic principle, be switched off

when charging and discharging the machine.

Fig. 41

WARNING

Risk to people of crushing fingers and hands when lifting the supporting leg to transport position!

When lifting the supporting leg, keep sufficient safe distance to the supporting leg as long as parts are moving.

WARNING

Risk to people of crushing their feet beneath the lowering supporting leg!

When lowering the supporting leg, keep sufficient safe distance to the supporting leg as long as parts are moving.

8. Lock and secure the holding-down device at the bearing block.

9. Disconnect the supply lines.

10. Place the supply lines onto the hose holder.

11. Move the tractor forward.

5.12 Drawbar suspension for folding drawbar

Optional extra

The drawbar suspension is switched on via Road travel mode by means of the easy-to-use control or the ISOBUS control.

5.13 Supporting leg

5.13.1 Mechanical supporting leg

The machine is equipped with a mechanical supporting leg, which supports the unhitched machine.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk to feet of being crushed if the lifted supporting leg accidentally falls down!

Check whether the locking bolt has completely engaged into the borehole and properly locks the supporting leg in its transport position.

1. Lift the machine hitched to the tractor via the hydraulic folding drawbar (1).

 The supporting leg is relieved.

2. Pull the locking bolt (3) out of the borehole.

3. Use one hand to grip the handle (4) and lift the supporting leg (2) until the locking bolt engages into the borehole (5).

4. Check whether the locking bolt has completely engaged into the borehole and properly locks the supporting leg in its transport position.

Fig. 42

WARNING

Risk to people of being crushed due to the unhitched and improperly supported machine falling over!

After lowering the supporting leg to working position, check whether the locking bolt has completely engaged into the borehole and properly locks the supporting leg in its support position.

1. Lift the machine hitched to the tractor via the hydraulic folding drawbar (1).

2. Use one hand to grip the handle (4) of the supporting leg (2).

3. Use the other hand to pull the locking bolt (3) out of the borehole.

4. Lower the supporting leg until the locking bolt engages into the borehole.

5. Check whether the locking bolt has properly engaged into the borehole and properly locks the supporting leg in its support position.

6. Lower the machine via the hydraulic folding drawbar until the machine rests on the supporting leg.

 The folding drawbar no longer transmits any

tongue load to the tractor.

Fig. 43

5.13.1.1 Lift mechanical supporting leg to transport position

5.13.1.2 Lower mechanical supporting leg to support position

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk to people of becoming entangled and wound up due to an unsecured propeller shaft or damaged protective devices!

 Never use the propeller shaft without protective device or with a

damaged protective device or without proper handling of the clip chain.

 Before starting operation, always check:

 all protective devices of the propeller shaft for proper

mounting and functioning,

 whether there is sufficient free space around the propeller

shaft in any operating state. Insufficient free space will lead to damage on the propeller shaft.

 Immediately have damaged or missing parts of the propeller

shaft replaced by original parts from the propeller shaft manufacturer.

Observe the fact that only an authorized workshop is allowed to

repair a propeller shaft.

WARNING

Risk to people of becoming entangled and wound up due to unprotected propeller shaft parts within the power transmission area between the tractor and the powered machine!

Only carry out work with the drive unit between tractor and powered machine completely protected.

 The unprotected parts of the propeller shaft must always be

protected by means of a protective cover mounted on the tractor and a protective sleeve mounted on the machine.

 Check whether the protective cover mounted on the tractor or

the protective sleeve mounted on the machine and the safety and protective devices of the extended propeller shaft overlap by at least 50 mm. If not, the machine must not be powered via the propeller shaft.

 Proper use and maintenance of the propeller shaft prevent

serious accidents.

 When coupling the propeller shaft, observe:

 the admissible drive speed of the machine,

 the correct driving direction of the propeller shaft,

 the correct fitting length of the propeller shaft, see chapter

"Adjust length of propeller shaft to tractor", page 95,

 the correct fitting position of the propeller shaft. The tractor

symbol on the protective tube of the propeller shaft indicates the propeller shaft connection at the tractor.

 Before switching the propeller shaft on, observe the safety

instructions for propeller shaft operation.

5.14 Propeller shaft

The power transmission between tractor and machine is effected by means of the propeller shaft.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1. Clean and lubricate the p.t.o. shaft on the tractor.

2. Hitch the machine to the tractor.

3. Check whether the p.t.o. shaft has been switched off.

4. Slip the locking mechanism of the propeller shaft onto the p.t.o.shaft of the tractor until it noticeably engages. When coupling the propeller shaft, observe the included operating instructions for the propeller shaft.

5. Secure the propeller shaft guard at the tractor and at the machine against rotating by means of the clip chains (1):

5.1 Fix the clip chains at right angles to the

propeller shaft if possible.

5.2 Fix the clip chains such that a

sufficient swivelling range of the propeller shaft is ensured in any operating state. Clip chains must not get entangled in tractor or machine components.

6. Ensure that there is sufficient free space around the propeller shaft in any operating state. Insufficient free space will lead to damage on the propeller shaft.

Fig. 44

CAUTION

Risk of burns due to contact with hot propeller shaft components!

Do not touch considerably warmed-up propeller shaft components (particularly do not touch any couplings).

Clean and lubricate the propeller shaft before longer downtimes.

1. Pull the propeller shaft locking mechanism off the tractor's p.t.o.shaft.

2. Place the propeller shaft onto the respective holder (1).

Fig. 45

5.14.1 Couple propeller shaft to tractor

5.14.2 Uncouple propeller shaft from tractor

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Observe the fact that the braking axle needs to run in during the

first service hours – the brake lining is adjusting to the brake drum. Full braking power is only reached after this running-in period.

 Check the brake system for proper functioning before carrying

out transport journeys.

Observance of the maintenance intervals is indispensable for proper functioning of the dual-line compressed-air brake system.

WARNING

Risk due to insufficient braking ability of the machine if the mechanical ALB regulator has not been properly set!

The setting dimension (L) at the ALB regulator must not be modified. The setting dimension (L) must correspond to the value indicated on the WABCO-ALB plate.

5.15 Brake system

Depending on the machine’s equipment, the brake system consists of:

 a dual-line compressed-air brake system possibly equipped with automatic load-sensitive brake

pressure regulator and parking brake for an admissible maximum speed of 25 km/h or 40 km/h or 60 km/h.

 a hydraulic service brake system (optional extra for export) with parking brake for an admissible

maximum speed of 25 km/h or 40 km/h respectively. The hydraulic service brake system has been designed for connection to a controlled hydraulic service brake system of a tractor.

5.15.1 Dual-line compressed-air brake system

The brake system consists of:

 a braking axle with a dual-line compressed-air brake system and parking brake for an admissible

maximum speed of 25 km/h or 40 km/h or 60 km/h.

 an automatic load-sensitive brake pressure regulator (ALB regulator). The ALB regulator

automatically controls the required braking force depending on the loading condition of the hitched machine.

The brake system acts on the braking axle/s.

5.15.1.1 Dual-line compressed-air brake system with mechanical automatic load-sensitive brake (ALB) regulator

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Feed line with hose coupling (red)

(2) Brake line with hose coupling (yellow)

(3) Blank connection for brake line

(4) Trailer brake valve

(5) ALB regulator (mechanical)

(6) Release valve

(7) Operating element for release valve (can

only be actuated in uncoupled condition):

 push in as far as it will go and the

service brake system releases, e. g. for manoeuvring the unhitched machine

 pull out as far as it will go and the

machine is braked again by means of the system pressure coming from the air reservoir

(8) Diaphragm brake cylinder

(9) Compressed-air reservoir

(10) Drain valve

(11) Test connection in front of ALB regulator

(12) Test connection behind ALB regulator

(13) Test connection, diaphragm brake cylinder

(14) Test connection, compressed-air reservoir

(15) Parking brake

Fig. 46

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk due to insufficient braking ability of the machine if the travelling height of the hydraulic levelling system has not been properly set!

The hydraulic levelling system properly triggers the hydraulic ALB regulator only with the travelling height properly set.

Check the travelling height of the hydraulic levelling system every day and readjust it if necessary.

(1) Feed line with hose coupling (red)

(2) Operating element for release valve (can

only be actuated in uncoupled condition):

 push in as far as it will go and the

service brake system releases, e. g. for manoeuvring the unhitched machine

 pull out as far as it will go and the

machine is braked again by means of the system pressure coming from the air reservoir

(3) Brake line with hose coupling (yellow)

(4) Blank connection for brake line

(5) Trailer brake valve with release valve

(6) Diaphragm brake cylinder

(7) ALB regulator (hydraulic), activated via the

hydraulic levelling system of the tandem chassis

(8) Hydraulic cylinders of the hydraulic levelling

system

(9) Compressed-air reservoir

(10) Drain valve

(11) Test connection, compressed-air reservoir

(12) Test connection, diaphragm brake cylinder

(13) Parking brake

Fig. 47

5.15.1.2 Dual-line compressed-air brake system with hydraulic automatic load-sensitive brake pressure (ALB) regulator

Tandem chassis

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Diaphragm brake cylinder

(2) Slack adjuster for brake camshaft

(3) Brake camshaft

(4) Connecting rods for parking brake

(5) Test connection for pressure gauge

Fig. 48

WARNING

Risk of crushing, cuts, becoming entangled, being drawn in and risk of impact to people due to improper functioning of the service brake system!

 When connecting the brake and feed line, ensure that:

 the sealing rings of the hose couplings are clean,

 the sealing rings of the hose couplings seal tightly.

 Immediately replace damaged sealing rings.

 Drain the air reservoir every day before the first trip.

 Only start the tractor with the hitched machine moving when the

pressure gauge of the compressed-air brake system on the tractor indicates 5.0 bar.

 Check the course of the connected brake lines! The brake lines

must not chafe against external components.

WARNING

Risk of crushing, cuts, becoming entangled, being drawn in and risk of impact to people if the machine rolls due to the service brake system being released!

Always connect the hose coupling of the brake line (yellow) first and then the hose coupling of the feed line (red).

The machine's service brake system immediately comes off the brake position if the red hose coupling is connected.

5.15.1.3 Braking axle

5.15.1.4 Connect brake and feed line

1. Open the caps of the hose couplings on the tractor.

2. Remove the hose coupling of the brake line (yellow) from the blank connection.

3. Properly fix the hose coupling of the brake line (yellow) to the yellow marked coupling device at the tractor.

4. Remove the hose coupling of the feed line (red) from the blank connection.

5. Properly fix the hose coupling of the feed line (red) to the red marked coupling device at the tractor.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk of crushing, cuts, becoming entangled, being drawn in and risk of impact to people if the machine rolls due to the service brake system being released!

Always disconnect the hose coupling of the feed line (red) first and then the hose coupling of the brake line (yellow).

The machine's service brake system only moves to brake position if the red hose coupling is disconnected.

It is imperative to observe this order, as otherwise the service brake system will be released and the non-braked machine may start to move.

When the machine is unhitched or torn off, the feed line connected to the trailer brake valve bleeds. The trailer brake valve automatically switches over thus actuating the service brake system in accordance with the automatic load-sensitive brake pressure control.

(1) Hydraulic sleeve ISO 5676

Fig. 49

 When connecting the feed line (red), the system pressure coming from the tractor automatically

pushes the push button for the release valve on the trailer brake valve out.

6. Release the parking brake and/or remove the chocks.

5.15.1.5 Disconnect brake and feed line

1. Release the hose coupling of the feed line (red).

2. Release the hose coupling of the brake line (yellow).

3. Fix the hose couplings to the blank connections.

4. Close the caps of the hose couplings at the tractor.

5.15.2 Hydraulic service brake system

The controlled hydraulic service brake system is connected to the special brake valve of the tractor. If the brake pedal on the tractor is pressed, the machine is slowed down.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(2) Hydraulic cylinder of braking axle

Fig. 50

WARNING

Risk of infection to people due to hydraulic oil squirting out under high pressure and entering the body!

Always ensure to depressurize the pressure accumulator before carrying out work on the hydraulic system.

If injuries caused by hydraulic oil occur, immediately contact the medical services.

The brakes must be tested before each journey to refill the pressure accumulator.

The emergency brake valve does not replace the parking brake!

5.15.2.1 Emergency brake valve

If the machine is torn off, the ripcord will actuate the emergency brake valve. The hydraulic oil then flows from the pressure accumulator into the brake cylinders, thus initiating the braking process.

Couple:

1. Fasten the ripcord to the tractor such that in case of the machine being torn off, the ripcord is in a horizontal position between tractor and machine.

Couple after emergency braking:

1. Connect the brake hose to the tractor.

2. Set the brake valve at the tractor such that the hydraulic oil can flow back to the tractor.

3. Press the drain valve at the emergency brake valve.

 The hydraulic oil flows back to the tractor and the pressure accumulator is depressurized.

4. Insert the ripcord with the clip connector into the borehole of the operating lever.

5. Set the operating lever back to its initial position.

6. Actuate the brake system of the machine several times.

 The pressure accumulator is filled and the emergency brake valve is ready for operation again.

Uncouple:

1. Make sure that the hydraulic pipe between tractor and machine has been depressurized.

2. Secure tractor and machine against accidental rolling by means of the parking brake.

3. Remove the ripcord from the tractor.

Design and function

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1. Connect the brake hose to the tractor.

2. Set the brake valve at the tractor such that the hydraulic oil can flow back to the tractor.

3. Press the drain valve (7) at the emergency brake valve (3).

 The hydraulic oil flows back to the tractor

and the pressure accumulator is depressurized.

Fig. 51

(1) Ripcord

(2) Coupling box

(3) Emergency brake valve

(4) Pressure accumulator

(5) Brake cylinder

(6) Brake drum

(7) Drain valve

 Only couple clean hydraulic clutches.

 Clean hydraulic plug and hydraulic sleeve if necessary.

 Slip the hydraulic plug into the hydraulic sleeve until the

hydraulic plug noticeably locks.

 Check the coupling spot of the hydraulic brake line for correct

and tight seat.

 The connected hydraulic brake line:

 must easily give way to any movements during cornering

without any stress, buckling or chafing,

 must not chafe against external components.

 Check the hydraulic brake system for proper functioning before

carrying out transport journeys.

1. Remove the hydraulic sleeve (1) from the machine's blanked-off connecting piece (2).

2. Couple the machine's hydraulic sleeve to the tractor's hydraulic plug of the hydraulic brake system.

3. Release the parking brake of the machine.

Fig. 52

Depressurize pressure accumulator

5.15.2.2 Connect hydraulic brake system

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

(1) Crank handle; in adjusting position (2)

(2) Adjusting position

(3) Resting position; swivelled by 180°

compared to the adjusting position

Fig. 53

Ensure that the cable does not rest on or chafe against other vehicle components.

With the parking brake released, the cable shall slightly sag.

Correct the setting of the parking brake if the tension path of the spindle (4) is no longer sufficient.

5.15.2.3 Disconnect hydraulic brake system

1. Apply the parking brake of the machine.

2. Uncouple the hydraulic sleeve (Fig. 52/1).

3. Slip the hydraulic sleeve onto the machine's blanked-off connecting piece (Fig. 52/2).

5.15.3 Parking brake

The applied parking brake secures the unhitched machine against rolling. The parking brake is actuated via spindle and cable when turning the crank handle.

Release parking brake

1. Swivel the crank handle (1) from resting position (3) by 180° to adjusting position (2).

2. Turn the crank handle anticlockwise until the cable (5) is relieved.

 The parking brake is released.

3. Swivel the crank handle to resting position.

Apply parking brake

1. Swivel the crank handle (1) from resting position (3) by 180° to adjusting position (2).

2. Turn the crank handle clockwise.

 The parking brake is applied via the cable (5).

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

 Before commissioning, the operator must:

 have read and understood these operating instructions.

 lubricate all lubrication points.

 When commissioning the machine, additionally observe the

information included in the chapters:

 "Operator’s obligation", page 27,

 "Qualification of staff", page 28,

 "Basic safety instructions", page 30,

 "Warning and instruction signs", page 39,

 "Service and maintenance of machine", page 164.

Observance of these chapters serves your safety.

 Before each startup, the operator must check the tractor and the

machine for their road and operational safety.

 Only use appropriate tractors to hitch and transport the machine.

 Check the following adjustments when changing the tractor:

 Length of propeller shaft. Observe the information in the

chapter "Adjust length of propeller shaft to tractor", page 95,

 Setting of pressure regulator. Observe the information in

the chapter "Load-sensing hydraulic system", page 62.

Readjust if necessary.

 Tractor and machine must comply with the national road traffic

regulations.

Owner (user) and driver (operator) of the vehicle are responsible

for observing the national road traffic regulations.

WARNING

Risk of crushing, shearing, cuts, becoming entangled and being drawn in to people if operating elements used to actuate movable components carrying out dangerous movements are blocked!

Do not block any operating elements which serve to initiate movable components to carry out dangerous movements, e. g. folding, swivelling or sliding operations of components.

The movement must automatically stop as soon as the operating element is released.

This shall not apply to movements of devices:

 in continuous action for constant loads,

 with automatic control,

 which, for functional reasons, require an open-centre or pressing

position.

6 Commissioning

This chapter will provide information:

 on how to proceed when commissioning your machine,

 on how to check whether the machine is licensed for being attached/hitched to your tractor.

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk due to incorrect use of the tractor if this causes failure of components, insufficient stability and insufficient steerability and braking ability of the tractor!

 Check your tractor for compatibility before attaching/hitching the

machine to the tractor.

Only attach/hitch the machine to appropriate tractors.

 Carry out a brake test to check whether the tractor reaches the

required deceleration with the machine attached / hitched up.

The gross vehicle weight rating of the tractor, which is specified in the operating instructions/in the tractor's vehicle registration certificate, must exceed the sum of:

 the tractor's empty weight,

 the ballasting mass,

 the tongue load of the hitched machine.

6.1 Check tractor's compatibility

The following features are crucial prerequisites for the compatibility of the tractor:

 the gross vehicle weight rating of the tractor,

 the admissible axle loads of the tractor,

 the admissible tongue load/towing capacity at the coupling device of the tractor,

These details are registered on the type plate, in the vehicle registration certificate and in the

operating instructions of the tractor.

 the load-bearing capacities of the tyres mounted on the tractor.

The tractor's front axle load must never fall below 20 % of the tractor's empty weight.

The tractor must reach the deceleration specified by the tractor's manufacturer even with the machine attached/hitched up.

6.1.1 Calculate actual values

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk due to failure of components caused by incorrect use of the tractor!

Ensure:

 that the coupling device at the tractor has a sufficient admissible

tongue load rating for the actually existing tongue load.

 that the coupling device at the tractor and the drawgear at the

rigid drawbar trailer are able to take up the towed load of the rigid drawbar trailer (towed load = axle load). Calculate the tractor’s admissible towing capacity if necessary.

 that the tractor's axle loads and weights influenced by the

tongue load are within the admissible limits. Check the weight in case of doubt.

 that the static, actual rear-axle load of the tractor will not exceed

the admissible rear-axle load rating.

 that the gross vehicle weight rating of the tractor will not be

exceeded.

 that the admissible load-bearing capacities of the tyres mounted

on the tractor are not exceeded.

Maximum admissible tongue load

Tractor's coupling device

Machine's drawgear

2000 kg

Bolt-type coupling DIN 11028, ISO 6489-0

Drawbar lug 40 reinforced DIN 11026, ISO 5692-2

Drawbar lug 40 DIN 74054-1/2, ISO 8755

Non-automatic bolt-type coupling DIN 11025

Drawbar lug 40 DIN 74054-1/2, ISO 8755

4000 kg ≤ 40 km/h 2000 kg > 40 km/h

Tow-hook (hitch hook) ISO 6489-1

Drawbar lug (hitch ring) ISO 20019

Drawbar lug (hitch ring) ISO 5692-1

Draw pin (Piton-Fix) ISO 6489-4

Drawbar lug (hitch ring) ISO 5692-1

4000 kg ≤ 40 km/h 2000 kg > 40 km/h

Ball-type coupling 80

Shell 80

6.1.2 Preconditions for the operation of tractors with rigid drawbar trailers

6.1.2.1 Combination options of coupling devices and drawgears

The following table shows admissible combination options of the tractor's coupling device and the machine's drawgear depending on the maximum admissible tongue load.

The maximum admissible tongue load for your tractor is directly indicated on the type plate of the coupling device/in the operating instructions/in the vehicle registration certificate of your tractor.

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk to people due to failure of components caused by breaking coupling devices between tractor and machine in case of incorrect use of the tractor!

 Only combine compatible coupling devices and drawgears.

 Calculate the actual DC value of your combination consisting of

tractor and rigid drawbar trailer to check the coupling device of your tractor for the required DC value. The actual calculated D

value for the combination must be less than or equal to (≤) the specified DC value of the coupling device of your tractor and the drawgear of the rigid drawbar trailer. If this is not the case, the admissible towing capacity for your tractor must be calculated. In each case, the lowest DC value shall be relevant.

 Calculate the admissible towing capacity of your tractor if the

calculated DC value for the combination is higher than the specified DC value of the coupling device of your tractor or of the drawgear of the rigid drawbar trailer. This calculated towing capacity must not be exceeded when charging your rigid drawbar trailer.

DC = g x T x C

T + C

Fig. 54

DC value of combination

Gross vehicle weight rating of your tractor in [t]

(see operating instructions/vehicle registration certificate of tractor)

Axle load/sum of axle loads of the machine charged with the admissible mass (loading capacity) in [t] without tongue load

Gravitational acceleration (9.81 m/s²)

Actual calculated DC value for the combination

Specified DC values of the tractor's coupling device and the machine's drawgear



6.1.2.2 Calculate actual DC value for combination to be coupled

The actual DC value of a combination to be coupled is calculated as follows:

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

The DC value:

 for the coupling device is directly indicated on the type plate of

the coupling device/in the operating instructions/in the vehicle registration certificate of your tractor.

In case of differing values on the type plates of the trailer bracket

and the coupling device, the lower value shall be relevant.

 for the drawgear is directly indicated on the type plate of the

drawgear.

Gross vehicle weight rating of the tractor:

14 t

Admissible axle load(s) of the rigid drawbar trailer:

18 t

DC = 9.81 m/s² x 14 t x 18 t

= 77.2 kN

14 t + 18 t

C = T x DC

g x T - DC

Gross vehicle weight rating of your tractor in [t]

(see operating instructions/vehicle registration certificate of tractor)

DC:

Lowest DC value of your tractor's coupling device/of your machine's drawgear/of the combination

Gravitational acceleration (9.81 m/s²)

Gross vehicle weight rating of the tractor:

14 t

DC value of tractor's coupling device

70 t

DC value of machine's drawgear:

77.5 t

DC value for the combination to be coupled:

77.2 t

C = 14 t x 70 kN

= 14.5 t

9.81 m/s2 x 14 t - 70 kN

Example

6.1.2.3 Calculate tractor's admissible towing capacity

The lowest DC value of your tractor's coupling device or of the drawgear of your rigid drawbar trailer determines the admissible towing capacity C of your tractor. In case of rigid drawbar trailers, the tractor's towing capacity is equal to the axle load(s) of the rigid drawbar trailer.

The admissible towing capacity of your tractor determines the admissible load capacity of your rigid drawbar trailer. This calculated towed load/axle load must not be exceeded when charging your rigid drawbar trailer.

Example

Due to the DC value of the tractor's coupling device, the admissible axle load is 14.5 t. This calculated axle load must not be exceeded when charging your rigid drawbar trailer.

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

DANGER

Risk of electrical shock or burns due to machine components accidentally touching electrical overhead lines or approaching high-voltage overhead lines in an inadmissible manner!

Make sure not to exceed the maximum vehicle height of 4 m.

Two people are required for mounting the attachment sections, ropes and the body tarpaulin.

Fig. 55

Positions of tubular supports Super-Vitesse CFS

3101

3101 DO

3501

3501 DO

A X X X X

B X X X

C X X

6.2 Mount body side panels, ropes and body tarpaulin

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Fig. 56

1. Secure tractor and machine against accidental starting and rolling.

2. Mount the tubular supports (1) loosely to the fixing supports (2); positions of tubular supports see Fig. 55, page 90.

3. Enter the cargo space through the access door.

4. Fold the side panel extensions (3) up one after the other.

5. Screw the side panel extensions (3) to the tubular supports (1).

6. Swivel the upper front grating (4) and the load-protection bars (5) up.

7. Screw the upper front grating (4) to the side panel extensions (3).

8. Swivel the load-protection bars (5) up.

9. Insert the bolts (6) into the mounts (7).

10. Secure the bolts (6) by means of the splitpins provided for that purpose.

11. Screw the tubular supports (1) to the body supports (2) such that the maximum vehicle height of 4 m is not exceeded.

12. Mount the tarpaulin (1).

Fig. 57

On machines without beaters

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

12. Mount the connecting tube (1).

13. Put the body tarpaulin (3) across the connecting tube (1).

The hemstitch of the body tarpaulin is

equipped with slots to accommodate the eyes (5) at the tailgate.

14. Push the tarpaulin rod (4) through the eyes (5) at the tailgate and through the hemstitch of the tarpaulin.

15. Secure the tarpaulin rod (4) at both ends against slipping out by means of the safety bolts (6).

Fig. 58

16. Thread each rope with the loop (1) through a hole (2) in the load-protection bars.

17. Put the other end (3) of the rope through the loop (2).

Fig. 59

18. Pull the ropes from the bottom through the eyes of the central tubular support.

Fig. 60

On machines equipped with beaters

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

19. Hang the rope hooks of the rubber clamps into the rear tubular support (machines without beaters) or into the body tarpaulin (machines equipped with beaters).

20. Bend the rope hooks such that they are closed. Thus, unhooking of the ropes will be prevented.

Fig. 61

1. Fix the control set (1) in the cabin within view and reach to the right of the driver seat.

2. Plug the 3-pole plug (DIN 9680) of the power cable (2) into the socket of the tractor.

(Pole 15/30 = Plus; Pole 31 = Minus)

3. Plug the control cable (3) of the control set into the socket of the power unit.

Fig. 62

 Do not draw the current from the light socket.

 Retrofit the 3-pole socket if your tractor is not equipped with a 3-

pole socket. An appropriate retrofit kit is available.

 A constant power supply of 12 V is required. The 3-pole socket

must be protected by a fuse of at least 25 A.

 The feed line of the 3-pole socket must have a minimum cable

cross section of 4 mm2.

6.3 Mount control set on the tractor

6.3.1 Mount easy-to-use control set on the tractor

6.3.2 Mount ISOBUS control set on the tractor

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1. Fix the control set (1) in the cabin within view and reach to the right of the driver seat.

2. Connect the signal plug (2) of the control set with the signal socket (3) of the mobile cable harness or with the signal socket of the tractor (if available).

3. Plug the 3-pole plug (4) (DIN 9680) of the mobile cable harness into the 3-pole socket of the tractor.

(Pole 15/30 = Plus; Pole 31 = Minus)

This is not necessary if the tractor is

equipped with an ISOBUS cable harness.

4. Depending on the machine's equipment, plug:

 the ISO socket (5) of the mobile cable

harness into the ISO plug of the control unit on the machine.

 the ISO plug of the control unit into the

ISO socket of the tractor.

Fig. 63

Only an authorised workshop is allowed to adjust the mounting height of the folding drawbar!

WARNING

Risk of being crushed, drawn in, becoming entangled and risk of impact to people if the hitched machine accidentally loosens from the tractor due to worn drawbar lug and coupling bolt!

Ensure that there is enough free space between the drawbar lug and the coupling bolt when lifting the folding drawbar.

The distance X must be 1180 mm between the ground and the machine frame with the forage wagon with lowered folding drawbar hitched up to the tractor.

The mounting height of the folding drawbar in relation to the machine frame must be aligned by means of the threaded spindles of the hydraulic cylinders if the actual distance X is not 1180 mm.

Use the rear borehole of the respective screw-on seat (1) if you cannot reach the required distance X, in particular in case of bottom linkage.

Fig. 64

6.4 Adjust mounting height of folding drawbar

Shop work

You must have the mounting height of the folding drawbar adjusted to the respective tractor model by an authorised workshop, in order to ensure that the lowered pick-up can properly adapt to uneven terrain. Only a properly adjusted mounting height of the folding drawbar guarantees best possible picking-up of the material to be loaded.

Assembly instructions for authorized workshop:

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

1. Park the tractor and the hitched machine on even ground.

2. Lower the folding drawbar by completely retracting the hydraulic cylinders of the folding drawbar.

3. Secure tractor and machine against accidental starting and rolling.

4. Unscrew the counter nut (2) of the threaded spindle (3).

5. Turn the piston rod (4) of the two hydraulic cylinders alternately in the required direction.

 Increase distance X = turn piston rod

clockwise

 Reduce distance X = turn piston rod

counterclockwise

Adjust the two threaded spindles evenly.

Fig. 65

6. Retighten the counter nuts of the threaded spindles.

7. Start the tractor engine.

8. Completely lift the folding drawbar.

9. Ensure that there is enough free space between the drawbar lug and the coupling bolt. The coupling bolt must not chafe against the borehole of the drawbar lug.

Change the level of the bolt-type coupling at

the tractor if the coupling bolt is chafing in the borehole of the drawbar lug.

10. Ensure that there is sufficient free space around the propeller shaft in any operating state. Insufficient free space will lead to damage on the propeller shaft.

Fig. 66

WARNING

Risk to people of being drawn in and becoming entangled due to assembly work on the propeller shaft carried out improperly or due to unauthorized structural alterations!

Only an authorized workshop is allowed to carry out structural alterations on the propeller shaft. Observe the included operating instructions of the propeller shaft manufacturer.

Adjustment of the propeller shaft length is allowed if observing the required minimum transverse contact ratio.

Structural alterations to the propeller shaft which are not specified in the included operating instructions for the propeller shaft are not allowed.

6.5 Adjust length of propeller shaft to tractor

Shop work

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

WARNING

Risk to people due to blown out objects if the length of the propeller shaft has been improperly adjusted thus being compressed during cornering!

Have the length of the propeller shaft checked in all operating states by an authorized workshop and adjusted if necessary before coupling the propeller shaft to your tractor for the first time.

This will prevent propeller shaft compression or insufficient transverse contact ratio.

 Absolutely observe the operating instructions provided by the propeller shaft

manufacturer along with the propeller shaft when determining the length and shortening the propeller shaft!

 The adjustment of the propeller shaft only applies to the current tractor model.

Readjustment of the propeller shaft may be necessary if hitching the machine to another tractor.

4. Slip the locking mechanism of the propeller shaft half with the tractor symbol (Fig. 67) on the protective tube onto the p.t.o. shaft of the tractor until the locking mechanism noticeably engages.

Fig. 67

Fig. 68

Assembly instructions for authorized workshop:

1. Hitch the machine to the tractor (do not couple the propeller shaft).

2. Take the shortest operating position of the propeller shaft.

The shortest operating position is reached when driving onto the silo with the folding drawbar

completely lifted. Depending on the tractor's drawgear, the propeller shaft halves slide together by approx. 150 mm when driving onto the silo with the folding drawbar lifted.

3. Pull the propeller shaft apart.

5. Slip the locking mechanism of the other propeller shaft half onto the p.t.o. shaft of the machine until the M16 screw can be inserted into the C-slot of the p.t.o. shaft, and tighten the M16 screw at a tightening torque of 200 Nm.

6. Shorten the propeller shaft, such that the minimum free space (X) is at least 40 mm in its shortest operating position (Fig. 68).

7. Reinsert the shortened propeller shaft halves into each other.

8. Lubricate the p.t.o. shaft of the tractor and the propeller shaft of the machine before coupling the propeller shaft.

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Only an authorised workshop is allowed to mount the shell to the folding drawbar.

1. Mount the washer (1).

2. Fasten the shell (2) by means of the two screws (3).

3. Tighten the nuts of the screws (3) at a tightening torque of 2300 Nm.

Fig. 69

Two people are required for mounting the crossover conveyor.

1. Hitch the machine to the tractor.

2. Check whether the tailgate is completely closed. If not, close the tailgate completely.

3. Completely lower the folding drawbar.

4. Secure tractor and machine against accidental starting and rolling.

5. Adjust the lamp brackets (1) with respect to the tailgate (2):

5.1 Lift the lamp brackets (1).

5.2 Pull the locking bolt (3) out as far as it

will go.

5.3 Tilt the lamp bracket (1) over to the

rear.

5.4 Position the lamp bracket (1) in the

rear keyhole profile (4) by means of the locking bolt (3).

5.5 Press the lamp bracket (1) down

again.

6. Unlock the tailgate from its closed position:

6.1 Always use one hand to hold the

Fig. 70

6.6 Mount shell to folding drawbar

Shop work

Assembly instructions for authorized workshop:

6.7 Mount crossover conveyor

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

tailgate while removing the two locking bolts (5).

6.2 Unlock and remove the two locking

bolts (5).

 The tailgate swivels downwards /

backwards (Fig. 71).

7. Insert the two locking bolts (5) into the upper boreholes of the side bars (6) and secure them.

 Thus, the tailgate cannot swivel forward

again.

8. Fasten both receiver pipes (7) in the front borehole (8).

9. Remove both locking bolts (9) from each receiver crossbeam (10).

10. Insert one locking tube (11) each at the front of the crossover conveyor.

11. Lift the crossover conveyor above the locking tubes and put the crossover conveyor down onto the pulleys in upright position.

12. Roll the crossover conveyor beneath the transport floor such that the receiver crossbeams (10) can take up the crossover conveyor.

13. Lift the crossover conveyor into the receiver crossbeams.

14. Secure the crossover conveyor in each receiver crossbeam (10) by means of the two locking bolts (9).

15. Insert the locking tubes (11) at the bottom of the crossover conveyor.

16. Remove the locking bolt from each locating hook (12).

Fig. 71

Commissioning

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

17. Swivel the crossover conveyor upwards (Fig. 72).

18. Put the crossover conveyor down onto the locating hooks (12) on both sides.

19. Push the locking tubes (11) into the crossover conveyor.

20. Insert the locking bolt (13) into each locating hook 12).

 Crossover conveyor and locking tubes are

secured.

Fig. 72

21. Connect the hydraulic hose pipes (14) of the hydraulic motor (15) with the coupling devices provided for that purpose (16).

22. Close the stop-cock (17) to secure the tailgate against accidental opening.

Opening of the tailgate with the crossover

conveyor mounted will damage the tailgate and the crossover conveyor.

23. Activate the crossover conveyor at the ISOBUS control set if necessary.

 The crossover conveyor is ready for use

and is operated via the ISOBUS control set.

Fig. 73

Commissioning

100

Super-Vitesse CFS 3101, 3501 / Super-Vitesse CFS 3101 DO, 3501 DO 10.13

Two people are required for dismounting the crossover conveyor.

1. Hitch the machine to the tractor.

2. Completely lower the folding drawbar.

3. Secure tractor and machine against accidental starting and rolling.

4.Disconnect the hydraulic hose pipes (14) coming from the hydraulic motor (15) at the coupling devices provided for that purpose (16).

Fig. 74

5. Disconnect the crossover conveyor and swivel it to the ground:

5.1 Remove the locking bolt (13) from each locating hook (12).

5.2 Pull the locking tubes (11) out of the crossover conveyor by approx. 15 cm.

5.3 Lift the crossover conveyor out of the locating hooks (12) and swivel it to the ground.

5.4 Insert the locking bolt (13) into each locating hook (12).

5.5 Insert the locking tubes (11) at the top of the crossover conveyor.

Fig. 75

Strautmann Super-Vitesse CFS 3101, Super-Vitesse CFS 3501, Super-Vitesse CFS 3101 DO, Super-Vitesse CFS 3501 DO Operating Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 User information

1.1 Purpose of document

1.2 Keeping of operating instructions

1.3 Location details in the operating instructions

1.4 Applied modes of specification

1.5 Applied terms

2 Product description

2.1 Overview – Assemblies
