Getting Started

RAID Array 310 V3.1 for HP–UX

Installation Guide

EK–SMRAB–IG. B01

Digital Equipment Corporation Maynard, Massachusetts

Second Edition, April 1997

The disclosure of this information does not grant to the user a license under any patents, pending patents, trademarks, or copyrights or other rights of Digital Equipment Corporation, or of any third party.

This software is proprietary to and embodies the confidential technology of Digital Equipment Corporation.

Possession, use or copying of the software described in this publication is authorized only pursuant to a valid written license from Digital Equipment Corporation or an authorized sublicensor.

Digital Equipment Corporation makes no representation that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.

The following are trademarks of Digital Equipment Corporation: DEC, RAID Array 310, StorageWorks, and the Digital Logo.

UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company, Ltd.

All other trademarks and registered trademarks are the property of their respective owners.

Contents

Revision Record

About This Guide

Getting Started

......................................................................................................................vii

....................................................................................................................ix

..................................................................................................................... xiii

1 Unpacking and Setting Up Your RAID Array 310 Subsystem Components

1.1 Introduction..........................................................................................................1–1

1.2 Site Preparation....................................................................................................1–1

1.3 Unpacking the RAID Array 310 ...........................................................................1–2

1.4 Preparing the RAID Array 310 for Operation........................................................1–3

1.5 Mounting the Base ...............................................................................................1–4

1.6 Connecting the Subsystem Power Cords...............................................................1–4

1.7 Connecting the CLI Serial Interface......................................................................1–7

1.7.1 Cabling Kit .......................................................................................................1–7

1.7.2 Serial Connection..............................................................................................1–8

1.7.3 Terminal Connection.........................................................................................1–8

1.7.4 Setting-up the Serial Line using SAM...............................................................1–8

1.7.5 CLI Serial Interface Verification........................................................................1–9

1.8 Installing Disk SBBs in the RAID Array 310 Enclosure .......................................1–9

1.9 Charging the RAID Array Controller Cache Battery...........................................1–10

2 Creating an Initial Controller Configuration

2.1 Introduction..........................................................................................................2–1

2.2 What is the CLI? ..................................................................................................2–2

2.3 Accessing the CLI................................................................................................2–2

2.3.1 Start the Communications Program...................................................................2–2

2.3.2 Establish the Connection with the Controller.....................................................2–2

2.4 Show Initial Configuration...................................................................................2–2

2.5 Add Disks to the Configuration............................................................................2–5

2.6 Setting Up a Communications LUN for a Command Console...............................2–6

2.7 Create a RAIDset..................................................................................................2–7

2.7.1 Initialize the RAIDset........................................................................................2–7

2.7.2 Add the RAIDset as a Logical Unit ...................................................................2–8

2.7.3 Set Writeback Cache .........................................................................................2–8

2.7.4 Verify and Record Your Configuration..............................................................2–9

3 Preparing the HP 9000 Series Systems for Use with the StorageWorks

Controller

3.1 Installing Hardware ..............................................................................................3–1

3.2 Installing the Host Device Driver..........................................................................3–2

3.2.1 Determine the Device Driver Required..............................................................3–2

3.2.2 Verify Host Adapter and Driver.........................................................................3–3

3.2.3 HP-UX Series 800 Patch Installation (10.01 only).............................................3–4

3.2.4 Set the SCSI Bus Address of the RAID Array Controller ..................................3–4

3.2.5 Reboot the System and Verify the Successful Installation..................................3–4

EK–SMRAB–IG. B01 iii

Getting Started – RAID Array 310 V3.1 for HP-UX

4 Installing Command Console Agent on Your Host System

4.1 Introduction ......................................................................................................... 4–1

4.2 Minimum System Requirements.......................................................................... 4–1

4.3 Installing and Configuring CC Agent for HP-UX

............................................... 4–2

4.4 Installing and Configuring Automatically............................................................. 4–2

4.5 Running CC Agent ............................................................................................ 4–10

4.6 Reconfiguring CC Agent.................................................................................... 4–10

4.7 Uninstalling CC Agent....................................................................................... 4–10

4.8 What To Do Next............................................................................................... 4–10

5 Installing the Command Console Client

5.1

5.2

5.3

Introduction Installing the Client Program

........................................................................................................ 5–1

............................................................................ 5–1

Uninstalling Command Console

....................................................................... 5–2

Appendix A Configuration Records – Blank Forms Appendix B Configuration Guidelines Appendix C Upgrading Your Controller Software

C.1 Backing Up Your System.....................................................................................C–1

C.2 Saving the RAID Array 310 Configuration ..........................................................C–1

C.2.1 Record Logical Units........................................................................................C–2

C.3 Upgrading Controller Software Using Windows NT ............................................ C–5

C.4 Windows NT 3.51 Procedures.............................................................................. C–5

C.4.1 Downloading the Software................................................................................C–7

C.5 Firmware Upgrade Procedures for Windows 95 and Windows NT 4.0 ...............C–10

C.5.1 Downloading the Software..............................................................................C–11

C.6 Reverting to Software Image Version 2.7...........................................................C–15

C.7 Manual RAID Array 310 Configuration Restoration ..........................................C–15

Appendix D Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

D.1 Create a STRIPEset (Configuration Example 1)...................................................D–1

D.1.1 Initialize the STRIPEset....................................................................................D–1

D.1.2 Add the STRIPEset as a Logical Unit ...............................................................D–2

D.1.3 Set Writeback Cache.........................................................................................D–2

D.2 Create a MIRRORset (Configuration Example 1).................................................D–2

D.2.1 Initialize the MIRRORset .................................................................................D–2

D.2.2 Add the MIRRORset as a Logical Unit.............................................................D–3

D.2.3 Set Writeback Cache.........................................................................................D–3

D.3 Create a Striped MIRRORset (Configuration Example 2).....................................D–3

D.3.1 Create the MIRRORsets ...................................................................................D–3

D.3.2 Create a STRIPEset from the MIRRORsets ......................................................D–3

D.3.3 Initialize the Striped MIRRORset .....................................................................D–4

D.3.4 Add the Striped MIRRORset as a Logical Unit.................................................D–4

D.3.5 Set Writeback Cache.........................................................................................D–4

D.4 Add Individual Disks as Logical Units (Configuration Example 2) ......................D–5

D.5 Add Drives to the Spareset...................................................................................D–5

iv EK–SMRAB-IG. B01

Contents

Appendix D Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

(continued)

D.6 Failed Set............................................................................................................ D–5

D.7 Verify and Record Your Configuration................................................................D–6

Figures

1–1 Minimum Installation Clearance Measurements....................................................1–2

1–2 Unpacking the RAID Array 310 ...........................................................................1–3

1–3 Mounting the Base ...............................................................................................1–4

1–4 Subsystem AC Power Receptacles........................................................................1–6

1–5 Subsystem CLI Serial Connector..........................................................................1–7

1–6 StorageWorks SCSI Bus Port and Default SCSI ID Assignment.........................1–10

2–1 Distribution Example............................................................................................2–6

C–1 Select Send Binary Files from the Transfers Menu .............................................. C–8

C–2 Select the V31Z.IMG File ................................................................................... C–9

C–3 Select Send File from the Transfer Menu........................................................... C–13

C–4 Select the V31Z.IMG File ................................................................................. C–14

Tables

1–1 Country Specific Power Cords..............................................................................1–5

1–2 Cabling Kit Components......................................................................................1–7

3–1 HP 9000 Drivers...................................................................................................3–2

4–1 Minimum System Requirements...........................................................................4–2

5–1 Minimum CC Client System Requirements..........................................................5–1

C–1 Logical Unit Table...............................................................................................C–3

C–2 Storageset Table.................................................................................................. C–4

EK–SMRAB-IG. B01

Revision Record

This Revision Record provides a concise publication history of this manual. It lists the manual revision levels, release dates, and reasons for the revisions. It also describes how the changes to affected pages are marked in the guide.

The following revision history lists all revisions of this publication and their effective dates. The publication part number is included in the Revision Level column, with the last entry denoting the latest revision. This publication supports the StorageWorks RAID Array 310 Subsystem.

Revision Level Date Summary of Changes

EK–SMRAB–IG. A01 March 1996 Original release. EK–SMRAB–IG. B01 April 1997 Updated to add support for HSOF

V3.1 and StorageWorks Command Console (SWCC) V1.1B.

EK–SMRAB–IG. B01 vii

About This Guide

This section identifies the audience of this guide and describes the contents (chapter by chapter) and structure. I n addition, this section includes a list of associated documents and t he conventions used in this guide.

This guide provides the following:

Getting Started

•

Unpacking and setting-up the RAID Array 310 Subsystem

•

Creating an initial controller interface using the Command Line Interpreter (CLI)

•

Preparing the HP 9000 for use with the RAID Array Controller

•

Installing Command Console Agent and Client

•

Visit our Web Site for the Latest Information

Check out web for the latest drivers, technical tips, and documentation. We can be found in the technical area of our web page, http://www.storage.digital.com/

Intended Audience

This guide is intended for administrators of StorageWorks RAID Array 310 Subsystems. Installing the StorageWorks RAID Array 310 Subsystem requires a general understanding of UNIX system administration and product installation procedures

Document Structure

This guide contains the following chapters:

Chapter 1: Unpacking and Setting Up Your RAID Array 310 Subsystem

This chapter describes the site preparation and unpacking procedures for the RAID Array 310 Subsystem. It also describes the procedure to recharge the controller cache battery.

Chapter 2: Creating an Initial Controller Configuration

This chapter contains instructions for creating an initial configuration for your RAID Array Controller usi ng the Comm and Line Interp reter (CLI). It briefly descri bes the C LI and how to access i t. The con figu rati on s teps incl ude veri fyin g t he defaul t confi gurat io n, adding drives, creating and initializing RAIDsets, identifying the storageset as a unit to the host, and verifying and recording your final configuration.

It also describes setting up an initial LUN to be used for communication with the Command Console GUI.

Components

EK–SMRAB–IG. B01 ix

Getting Started – RAID Array 310 V3.1 for HP-UX

Chapter 3: Preparing the HP 9000 Series Systems for Use with the

StorageWorks Controller

This chapter describes the steps for installing the required device drivers onto HP 9000 Series systems running HP-UX 10.01 or higher. The installation steps include loading the device driver(s) to communicate through the SCSI Adapter to the StorageWorks RAID Array Controller.

Chapter 4: Installing Command Console Agent on Your Host System

This chapter describes how to install a copy of the Command Console (CC) Agent on each of your host systems connected to StorageWorks RAID Array 310 subsyst ems. You can install and configure the CC Agent automatically, using a script, or manually by copying files from the CC Agent distribution CD-ROM and editing Agent configuration and your host system ASCII files.

Chapter 5: Installing the Command Console Client

This chapter describes how to install a copy of the Command Console (CC) Client on each of your client systems.

Appendix A: Configuration Records – Blank Forms

This appendix contains a copy of the tables used in Chapter 2 to record the configuration of your system. If additional copies are required, this table can be reproduced as necessary.

Appendix B: Configuration Guidelines

This appendix contains a list of guidelines that will assist in optimizing the performance of your RAID Array 310 Subsystem.

Appendix C: Upgrading Controller Software

This appendix contains the procedures for backing up and upgrading the controller software.

Appendix D: Configuring STRIPEsets, MIRRORsets, and Striped

This appendix supplements Chapter 2 and contains instructions for configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets.

Associated Documents

In addition to this guide, the following documentation is useful to the reader:

Table 1 Associated Documents

MIRRORsets

Document Title Order Number

RAID Array 310 for HP-UX Release Notes AA–QWTFA–TE RAID Array 310 Configuration and Maintenance Guide EK-SMCS2-UG

RAID Array 310 Deskside Subsystem Hardware User's Guide EK-SMCPL-UG RAID Array 310 Command Console V1.1 User’s Guide AA–R24LA–TE

x EK–SMRAB–IG. B01

Conventions

This guide uses the following documentation conventions:

Table 2 Style Conventions

Style Meaning boldface monospace type

plain monospace type

italic type

# Represents the HP-UX system prompt. Do not type it as

In addition, the following naming convention is followed in describing RAID levels:

Table 3 Nomenclature Conventions

RAID Advisory Board Description RAID Array 310 Usage

About This Guide

To be input by the user and filenames Text For emphasis and manual titles

part of information given here as to be input by the user.

RAID 0 STRIPEset RAID 1 MIRRORset RAID 0+1 STRIPED MIRRORset RAID 5/3 RAIDset

EK–SMRAB–IG. B01 xi

Getting Started

This section provides an overview for preparing and installing RAID Array 310 for HP-UX. Detailed information is contained in Chapters 1 through 5.

Thank you for purchasing a StorageWorks RAID Array 310 Subsystem. The following is an overview of the installation steps that are required.

NOTE

Installing the StorageWorks RAID Array 310 Subsystem requires a general understanding of the following:

• HP 9000 Series 800 and 700 Computer Systems

• HP-UX 10.01, 10.10, or 10.20

• A fast, wide differential SCSI interconnection on the HP

machine

• Basic hardware installation procedures Or, contact your service representative for installation assistance.

Installation Roadmap

This section provides an overview/road map of the major steps required to install a RAID Array 310 Subsystem. See the specified chapters for detailed procedures. (Depending upon your specific configuration requirements, you may not need to perform all the tasks listed.)

1. Perform the pre-installation steps listed below.

2. Unpack the RAID Array 310 Subsystem (Chapter 1)

3. Create a communications LUN (Chapter 2).

4. Install the SCSI Adapter in your HP system (if necessary)

5. Mount the software medium. The RAID Array 310 software and HP-UX support files are provided on a CD-ROM.

6. Install the Command Console Agent (Chapter 4)

7. Plan your storagesets, which means “mapping out” your Stripeset, Mirrorset and/or RAIDset configuration for the disks to be configured as your RAID Array. A useful tool for this purpose is the blank configuration record forms provided in Appendix A.

8. Create your storage configuration using either the Command Line Interpreter (CLI) or the Command Console Client Graphical User Interface (Chapter 5).

EK–SMRAB–IG. B01 xiii

Getting Started – RAID Array 310 V3.1 for HP–UX

Pre-Installation Steps

Before starting your installation, follow these steps:

•

Verify the availability of user-supplied hardware and software.

•

Inventory the contents of the StorageWorks RAID Array 310 Subsystem platform kit.

•

Inventory the contents of the StorageWorks RAID Array 310 Subsystem.

•

Follow your normal procedures to back up your system files.

Verify User Supplied Hardware and Software

The StorageWorks RAID Array 310 Subsystem requires:

•

A 9000 Series System that supports one of the following fast wide differential (FWD) SCSI adapters:

– Built-in, – HP–PB 28696A – GSC A4107A – HSC A4107A – HSC A2969A

•

The associated system hardware manual

•

Appropriate tools to service your computer

•

The HP–UX operating system V10.01 or higher

•

If version 10.00 is running, upgrade to 10.01 before installing the RAID Array 310

Inventory the StorageWorks RAID Array 310 Platform Kit and Subsystem Components

The Storage Works RAID Array 310 Platform Kit contains the following components:

•

This guide.

•

Release Notes

•

A BN21G-xx SCSI cable with two straight high-density 68-pin connectors

•

RAID Array 310 Controller Firmware License Keys

•

Optional HP–PB 28696A FWD controller, depending on the type of platform kit

NOTE

Retain the Firmware License Keys inf or m at ion in a saf e place. It may be required to re-initialize the RAID Array Controller.

xiv EK–SMRAB–IG. B01

The StorageWorks RAID Array 310 Subsystem provides the following components:

RAID Array 310 Configuration and Maintenance Guide (EK-SMCS2-UG)

•

RAID Array 310 Deskside Subsystem Hardware User's Guide (EK-SMCPL-UG)

•

The StorageWorks RAID Array 310 Subsystem

•

Serial cabling kit (see Section 1.7.1) for connecting the maintenance port of the controller to the serial port of the host computer, a personal computer, or a terminal

•

Power Cables (2)

•

Enclosure Keys

Perform a System Backup

Follow normal procedures to backup your system before installing the subsystem.

Getting Started

EK–SMRAB–IG. B01 xv

Unpacking and Setting Up Your RAID Array 310

Subsystem Components

This chapter describes the site preparation and unpacking procedur es for t he RAID Array 310 Subsystem. It also describes the procedure to r echarge the controller write-back cache battery and making the CLI interface connection between the subsystem and the host system or maintenance terminal.

1.1 Introduction

The installation of your RAID Array 310 subsystem is accomplished by performing the following seven major steps:

•

Unpacking and setting up the mechanical configuration (

•

Connecting ac power and recharging the controller cache battery (

•

Making the serial interface connection between the RAID Array 310 and the host system or maintenance terminal (

•

Creating an initial RAID array controller configuration (

•

Preparing the HP9000 for use with the RAID Array Controller (

1.2 Site Preparation

Before installing the subsystem, make sure that adequate space is available in front of the enclosure for opening the front door (10 inches clearance) and around the enclosure for adequate airflow. See Figure 1–1 for specific space requirements.

Chapter 1

)

Chapter 2

)

Chapter 1

)

Chapter 4

)

EK–SMRAB–IG. B01 1–1

Getting Started - RAID Array 310 V3.1 for HP–UX

Figure 1–1 Minimum Installation Clearance Measurements

1.3 Unpacking the RAID Array 310

The shipping containers provide maximum protection for the subsystem and all components. We recommend that you unpack the subsystem in the installation area.

Before unpacking the equipment, inspect the shipping car ton for signs of external damage. Report any damage to t he local carrier and to your reseller.

Refer to Figure 1–2 and complete the following procedure to unpack the subsystem:

1. Orient the shipping container as shown.

2. Open the container to remove the subsystem and packing material.

3. Remove the top foam blocks.

4. Remove the door.

5. Remove the subsystem.

6. Replace all packing material in the shipping container and store it for future use.

NOTE

1–2 EK–SMRAB–IG. B01

Chapter 1. Unpacking and Setting Up Your RAID Array 310 Subsystem Components

Figure 1–2 Unpacking the RAID Array 310

1.4 Preparing the RAID Array 310 for Operation

Preparing the RAID Array 310 for operation involves the following procedures:

1. Mounting the base as described in Section 1.5.

2. Mounting the door.

3. Installing the disk Storage Building Blocks (SBB's).

4. Connecting the power, SCSI bus, and CLI serial cables.

5. Configuring the RAID Array 310.

6. Charging the controller cache battery.

7. Checking the subsystem for proper operation.

EK–SMRAB–IG. B01 1–3

Getting Started - RAID Array 310 V3.1 for HP–UX

1.5 Mounting the Base

Mount the stabilizing base to the subsystem as follows:

1. Place the subsystem on its top.

2. Align the base with the bottom of the subsystem as shown in Figure 1–3.

3. Install the four hex-head screws through the base into the subsystem and tighten the screws using a 3/16 (5 mm) hex-head or flat-head screwdriver.

4. Set the subsystem on its base and continue the installation process.

Figure 1–3 Mounting the Base

1.6 Connecting the Subsystem Power Cords

The subsystem contains two identical power supplies which provide redundant power to the RAID Array 310. Each supply is equipped with an ac power receptacle for connection to a 125 or 250 Vac power source. The power supply automatically senses and switches itself to accommodate either power source. Table 1–1 lists and describes the Digital power cords available for the subsystem. Since these cords are countryspecific, ensure that your cords match those listed in Table 1–1 for your installation.

Obtain the correct power cords for your ac power source and connect them between the ac receptacles on the power supplies (Figure 1–4) and the ac outlets (the power supply automatically senses the voltage level and will work with either voltage). For optimal fault tolerant operation, connect the supplies to independent ac sources.

1–4 EK–SMRAB–IG. B01

Chapter 1. Unpacking and Setting Up Your RAID Array 310 Subsystem Components

Table 1–1 Country-Specific Power Cords

Country Length Order No.

Australia 2.5 m BN19H-2E C. Europe 2.5 m BN19C-2E Denmark 2.5 m BN19K-2E India 2.5 m BN19S-2E Ireland 2.5 m BN19A-2E Israel 2.5 m BN18L-2E Italy 2.5 m BN19M-2E Japan 2.5 m BN27S-2E N. Zealand 2.5 m BN19H-2E S. Africa 2.5 m BN19S-2E Switzerland 2.5 m BN19E-2E U. K. 2.5 m BN19A-2E U. S. 2.5 m BN27S-2E

EK–SMRAB–IG. B01 1–5

Getting Started - RAID Array 310 V3.1 for HP–UX

Figure 1–4 Subsystem AC Power Receptacles

1–6 EK–SMRAB–IG. B01

Chapter 1. Unpacking and Setting Up Your RAID Array 310 Subsystem Components

1.7 Connecting the CLI Serial Interface

The RAID Array 310 requires a terminal or terminal emulation program connected to the CLI serial connector on the rear panel of the subsystem (see Figure 1–5). The serial interface default settings are 9600 baud, with 8 data bits, 1 stop bit, and no parity.

Figure 1–5 Subsystem CLI Serial Connector

1.7.1 Cabling Kit

Locate and open the cabling kit that was shipped with your RAID Array 310 subsystem. The kit should contain the following components:

Table 1–2 Cabling Kit Components

Qty Digital Part No. Wiring Description

1 BC16E–10 NA 10-foot Terminal Cable 2 H8571–J Straight through DB-9-pin "J" Female to Cable Connector 1 H8575–A Straight through Cable to 25-pin Female Connector 1 H8575–D Crossed Cable to 25-pin Male Connector 1 H8575–E Straight through Cable to 25-pin Male Connector

EK–SMRAB–IG. B01 1–7

Getting Started - RAID Array 310 V3.1 for HP–UX

1.7.2 Serial Connection

From the components listed in Table 1–2, construct a cable to connect the DB-9 CLI serial connector on the subsystem to your terminal or the host serial port as follows:

•

If making a connection to an 800 server serial interface use the BC16E cable, a 9-pin H8571-J connector, and a 25-pin H8575D connector.

•

If making a serial connection to a 700 series workstation use the BC16E cable and two H8571-J connectors.

1.7.3 Terminal Connection

Refer to your terminal documentation for terminal setup instructions.

1.7.4 Setting-up the Serial Line using SAM

Start the System Administrator Utility, SAM, by logging on to the HP system as superuser and typing sam<CR>. Select the <Peripheral Devices> and then the <Terminal and Modems> menu options and enter the Terminal and Modem configuration section. Check if any terminals or modems have been defined on the line to be used for the CLI connection. If any have been defined, delete them via the <Option> menu. Next, add a modem via the <Action> menu. The following window appears:

Select the options indicated in the window and then select OK.

1–8 EK–SMRAB–IG. B01

Chapter 1. Unpacking and Setting Up Your RAID Array 310 Subsystem Components

The following window appears:

Establish the connection with the controller.

1. Now you can access the RAID Array 310 with the command:

cu -l cul0p0

(note that this is the first entry from the list shown above).

2. Press the Enter key. You should see the CLI prompt, which looks similar to: HSZ20>. If no prompt is seen, the serial port may be misconfigured or used by another application. See the “Installing Terminals and Modems” section in HP manual

Installing Peripherals

1.7.5 CLI Serial Interface Verification

Entering the CLI command “SHOW THIS_CONTROLLER” causes the controller to display its description banner verifying the serial connection.

1.8 Installing Disk SBBs in the RAID Array 310 Enclosure

You may install the disk drive SBBs into the RAID Array 310 enclosure at this time. To install an SBB, hold it in both hands, insert it into the guide slots, and firmly push it into the shelf until the mounting tabs snap in place. Figure 1–6 shows a layout of the SCSI bus ports and corresponding SCSI ID assignments in the enclosure. Refer to

Configuration Rules and Restrictions

, included with your system.

Chapter 3,

EK–SMRAB–IG. B01 1–9

Getting Started - RAID Array 310 V3.1 for HP–UX

Figure 1–6 StorageWorks SCSI Bus Port and Default SCSI ID Assignment

1.9 Charging the RAID Array Controller Cache Battery

The Cache Module in the controller contains a battery that may have discharged since the time it was factory-installed.

CAUTION

Loss of power before the write-back cache battery is fully charged may result in the loss of data.

We recommend that you take this opportunity now to recharge the batteries. This is accomplished by doing the following:

Apply power to the controller by pressing the power switch on the front of the subsystem. You should hear a momentary audible tone (beep), and see the indicator LEDs illuminate. In addition, a green LED on the front panel of the subsystem should flash at approximately one Hz. Power on the subsystem for a minimum of 6 hours to fully charge the battery.

NOTE

The controller cache battery LED will continue to flash after the subsystem is powered off.

1–10 EK–SMRAB–IG. B01

Creating an Initial Controller Configuration

This chapter contains instructions for creating an initial configuration for your RAID Array Controller. I t also briefly describes the CLI (Command Line Inter pr et er ) and how t o access it. The configurat ion st eps include verifying the default configuration, adding drives, creating and initializing RAIDsets, declaring the storagesets as units to the host, and verifying and recording your final configuration.

2.1 Introduction

The RAID Array 310 controller can be configured with CLI commands using a terminal or a PC terminal emulator. The emulator should be connected from the PC to the RAID Array serial interface or via the Command Console GUI interface.

Before configuring the storagesets, an initial check using the CLI interface must be made on the state of the controller. For setting up the GUI, you will also need to set up an initial configuration using the CLI interface. Sections 2.1 through 2.5 describe this process.

The Command Console GUI runs on an Intel-based PC with either Windows 95 or Windows NT. It can be used via the serial interface to the RAID Array 310 or by using a networked connection (TCP/IP) to the host with which the RAID Array is connected. In that case, an agent must be installed on the host system. Chapter 4 describes this process.

The agent communicates with the RAID array through a SCSI interface. At least one storage device must be configured on the RAID Array so that the GUI can communicate with the RAID Array via the agent. Sections 2.5 through 2.7.3 describe this procedure.

2.2 What is the CLI?

The Command Line Interpreter (CLI) is the user interface to the RAID Array Controller. Using a connection between the controller’s maintenance port and a Maintenance Terminal, the CLI can be used to view and modify the controller’s configuration. The CLI can also be used to access reports and diagnostic tools. This chapter specifies the CLI commands required to create an initial configuration for the controller.

See “Command Line Interpreter” in the RAID Array 310 Configuration and Maintenance Guide for detailed descriptions of all CLI commands.

EK–SMRAB-IG. B01 2–1

Getting Started – RAID Array 310 V3.1 for HP–UX

The Maintenance Terminal can be any VT100 compatible terminal or terminal emulator. e.g.:

PC with a terminal emulation program, such as the Microsoft Windows Terminal program. You can also use most commercially-available communications programs. DEC VT100 or compatible terminal. On UNIX systems, ‘t ip’, 'kerm it', or ‘cu’ (see man pages) can be used as terminal emulation program.

2.3 Accessing the CLI

Access the CLI using a maintenance terminal. As an example we will describe the use of a PC with a terminal emulation program being used as a maintenance terminal. Refer to Section 1.7 in Chapter 1 of this guide (

Connecting the CLI Interface

maintenance terminal to the RAID 310 controller if necessary.

2.3.1 Start the Communications Program

1. Start the communications program on your PC.

2. Set the communications program to use the serial port that is connected to the controller.

NOTE

) for a description of how to connect the

3. Set the communications parameters to:

• 9600 baud

• 8 bits

• 1 stop bit

• No parity

2.3.2 Establish the Connection with the Controller

From your communication program, issue a connect command to establish a connection with the controller, and then press the Enter key. You should see the CLI prompt, which looks similar to

HSZ20>

2.4 Show Initial Configuration

Enter the following command to verify the controller’s parameters:

HSZ20> SHOW THIS_CONTROLLER FULL

2–2 EK–SMRAB–IG. B01

Chapter 2. Creating an Initial Controller Configuration

The controller responds with a display similar to that shown below:

CONTROLLER:

HSZ20 CX44332211 FIRMWARE V27Z-0, HARDWARE A02 SCSI ADDRESS 7 TIME: NOT SET

HOST PORT:

SCSI TARGET(S) (0, 1, 2) NO PREFERRED TARGETS

CACHE:

16 MEGABYTE WRITE CACHE, VERSION 2 CACHE IS GOOD BATTERY IS GOOD NO UNFLUSHED DATA IN CACHE CACHE_FLUSH_TIMER = DEFAULT (10 SECONDS) CACHE_POLICY=A HOST FUNCTIONALITY MODE=A

LICENSING INFORMATION:

RAID (RAID OPTION) IS ENABLED, LICENSE KEY IS VALID WBCA (WRITEBACK CACHE OPTION) IS ENABLED, LICENSE KEY IS

VALID

MIRR (DISK MIRRORING OPTION) IS ENABLED, LICENSE KEY IS VALID EXTENDED INFORMATION:

TERMINAL SPEED 9600 BAUD,EIGHT BIT,NO PARITY,1 STOP BIT

OPERATION CONTROL:0000004 SECURITY STATE CODE:85780

CONFIGURATION BACKUP DISABLED

Examine the display to verify the following information:

Controller SCSI target number is recommended to be set to 0.

If the target number is not 0, use the following commands to set the SCSI target ID for the controller (ensure that there are no other SCSI devices using the same IDs as configured for the RAID Array 310 controller):

HSZ20> SET THIS_CONTROLLER ID=0

HSZ20> SET THIS_CONTROLLER ID=(0, 1, 2)

If you want to use multiple SCSI Ids (as is done in the following examples).

Cache condition should be GOOD

If the Cache condition is BAD then call your sales person for unit service.

Battery condition should be GOOD

If the battery condition is LOW, allow the battery to charge with the subsystem power on for up to 6 hours. The battery must be fully charged to protect the data in the Write Back Cache. If the battery condition is still LOW after 6 hours of charging, then call your sales person for unit service.

EK–SMRAB–IG. B01 2–3

Getting Started – RAID Array 310 V3.1 for HP–UX

The subsystem can be configured with the battery condition

LOW, however the Write Back Cache cannot be initialized.

NOTE

You can use the

regardless of the write-back cache battery condition.

However, if the

low, the controller does not allow access to any RAIDsets or

mirrorsets.

be fully charged before you can use RAIDsets or mirrorsets.

ADD RAIDSET

CACHE_POLICY

CACHE_POLICY A

ADD MIRRORSET

and

is set to A and the battery is

requires that the cache batteries

commands,

CACHE_POLICY should be A

HSZ20> SET THIS_CONTROLLER CACHE_POLICY=A

Host function mode must be set to A for HP-UX

HSZ20> SET THIS_CONTROLLER HOST_FUNCTION=A

License key should be VALID

If the License key is INVALID then enter the following:

HSZ20> RUN FLS

and follow the menu driven program to enable the license. You will need the WRITE-BACK CACHE, RAID5, and MIRROR License Key page that is provided in the subsystem documentation package.

Configuration backup can be enabled or disabled

Configuration backup will keep RAID Array controller configuration stored on disk, for detailed information regarding configuration backup see the

RAID Array 310

Configuration and Maintenance User’s Guide.

To cause the changed settings on the controller to take effect, restart the controller by:

HSZ20> RESTART THIS_CONTROLLER

NOTE

Up to 14 devices can be supported by the RAID Array 310

controller, the contr oller can represent up to 4 target I D’s on

the Host SCSI-bus.

You can increase the number of addressable units by setting

the controller to respond to up to 4 target ID’s, as long as

those IDs are not used by any ot her device on the host bus.

For example,

SET THIS_CONTROLLER ID=(0,1,2,3)

would set the controller to respond to any of the four IDs. If

you set the controller to more than one ID, you must enclose

the numbers with parentheses and separate them with

commas.

After the RESTART command is initiated, it can take up to 60

seconds for the "CLI" prompt to re-appear.

2–4 EK–SMRAB–IG. B01

2.5 Add Disks to the Configuration

The CONFIG utility locates and adds disks to the controller configuration. Run the CONFIG utility whenever you add new disks to the controller. Enter the following command to start the configuration utility:

HSZ20> RUN CONFIG

The controller responds with a display similar to that shown below. The disk numbers will correspond to the disk locations for your subsystem. (See Figure 2–1.)

Config Local Program Invoked Config is building its tables and determining what devices exist

on the subsystem. Please be patient. add disk100 1 0 0

add disk110 1 1 0 add disk120 1 2 0 add disk130 1 3 0 add disk200 2 0 0 add disk210 2 1 0 add disk220 2 2 0 Config – Normal Termination

Chapter 2. Creating an Initial Controller Configuration

In the previous example, the controller has located 7 new disks. The 3 digit number associated with each disk corresponds to Bus Number, Target Number and Logical Unit Number (LUN). The LUN is always 0. DISK100, in this example, corresponds to the disk located on Bus 1, controller Target 0, and LUN 0. DISK210 corresponds to the disk located on Bus 2, controller Target 1, and LUN 0.

If you want to create a RAIDset for RAID 5, follow the guidelines in Section 2.7. For other raidsets, as listed below, follow the guidelines in Appendix D:

• STRIPEset refers to RAID 0

• MIRRORset refers to RAID 1

• Striped MIRRORset refers to RAID 0+1

EK–SMRAB–IG. B01 2–5

Getting Started – RAID Array 310 V3.1 for HP–UX

Figure 2–1 Distribution Example

2.6 Setting Up a Communications LUN for a Command Console

Before installing the agent on the host system, at least one storage device must be configured on the RAID Array 310. This can be any type of storage device.

Select a storageset that you plan to configure and that is not likely to change. This storageset will also be used by the agent to communicate with the RAID Array. Deleting this storageset (LUN) later will break the connection between the agent and the RAID Array. Create the communications LUN as described in section 2.7 or Appendix D, depending on the type of storageset you want to use.

If an HP 800 system is used with a HP–PB bus SCSI adapter (HP 28696A), a special SCSI driver is needed for the agent to communicate with the RAID Array. This driver is attached to a storage device (SCSI ID, LUN) of the RAID Array. Using this driver prevents the use of that storageset as a normal data device. In order to prevent the loss of a complete storageset as a data device, that set can be broken into partitions. Using a partition with the size of one block for the communication LUN will minimize the loss of storage for data.

Installing and configuring this driver is described in Chapter 3. DIGITAL recommends using the partitioning scheme for other situations as well.

2–6 EK–SMRAB–IG. B01

2.7 Create a RAIDset

The next sections contain examples of two different sets of configuration. Create a RAIDset, Mirrorset, and Stripeset show one set and Create a Striped Mirrorset shows the second set.

If your site requires RAIDsets for storage, you must assign disks to each RAIDset. RAIDsets must have at least three members, and can have as many as fourteen. This example creates one 3member RAIDsets using the ADD RAIDSET command.

HSZ20> ADD RAIDSET RAIDS1 DISK100 DISK200 DISK110

In this example, “RAIDS1” is the name of the RAIDsets, and they are followed by a list of disks to be included in each RAIDset. The names of the RAIDsets are user-defined. Performance of your RAIDsets will be optimized if each RAIDset includes disks from different buses as shown in Figure 2–1. The example above contains disks from two different buses.

2.7.1 Initialize the RAIDset

You must initialize RAIDsets before you can put them into service. When you initialize a RAIDset, you can specify a chunksize. A chunksize is the number of blocks

of data that is transferred to a raidset member at one time. By using the default chunksize, the controller will select a chunksize that works well for most site requirements. Refer to the

Array 310 Configuration and Maintenance Guide

chunksize is specified, the default value is used.

Chapter 2. Creating an Initial Controller Configuration

RAID

for the specific default chunksize. When no

HSZ20> INITIALIZE RAIDS1

or if the save configuration option is used,

HSZ20> INITIALIZE RAIDS1 CHUNKSIZE=DEFAULT SAVE_CONFIGURATION

NOTE

Valid chunksizes are 16–682 blocks. You should use a larger chunksize for applications that make a lot of I/ O requests. Use a smaller chunksize for applications that make r elatively few I/O requests but need to move large amounts of data with each request. When no CHUNKSIZE is specified, t he default value is automatically used. Refer to

Configuration and Maintenance Guide

information.

The SAVE_CONFIGURATION option can be used to save the controller configuration on the disk(s) defined in the containerset. In case of a controller failure, it is possible to retrieve the configuration information from the failed controller to the new controller. It is advised to use this option on more than one disk in different containersets so that the information is stored in a redundant manner. For detailed information describing this option and the way of retrieving controller information in case of a controller replacement, refer to the

Configuration and Maintenance Guide.

the RAID Array 310

for more detailed

RAID Array 310

EK–SMRAB–IG. B01 2–7

Getting Started – RAID Array 310 V3.1 for HP–UX

2.7.2 Add the RAIDset as a Logical Unit

To make a RAIDset available to the host computer, you must add it as a host logical unit with a unique unit number. The unit number is a one or three digit number preceded by “D”, such as “D0” or “D102”. The unit number consists of the controller’s target ID and the Logical Unit (LUN) of the RAIDset for the target. Each target ID can have up to eight LUNs, numbered 0–7.

• Units identified with controller target ID 0 have a single digit number which corresponds to

the LUN number. For example, D5 would be target 0, LUN 5.

• Units identified with all other controller targets (1–7) use a 3 digit number. The first digit

corresponds to the controller target number, the second digit is always 0 and the third digit is the LUN number. For example, D205 would be target 2, LUN 5.

The steps to be taken to configure a partitioned storageset are as follows:

HSZ20> create_partition RAIDS0 blocks=1

HSZ20> add unit d0 RAIDS0 partition=1

This creates a partition with the size of one block on a storageset named RAIDS0. D0 means SCSI ID 0 LUN 0, which may be different for your particular situation.

This new unit can now by used as a communications LUN during the installation of the agent as described in Chapter 4.

Now create a data partition:

HSZ20> show RAIDS0

Using this output, you can see the remaining free blocks available for the data part of the storageset.

HSZ20> create_partition RAIDS0 blocks=xxxx

Where xxxx represents the number of free blocks of RAIDS0 identified by the

show

command:

HSZ20> add unit D1 RAIDS0 partition=d

Where d represents the partition number created in the previous command D1 means SCSI ID 0 LUN 1, which may be different for your situation.

2.7.3 Set Writeback Cache

The final step in creating a RAIDset is to enable the writeback cache. A single CLI command enables that feature for the each RAIDset:

HSZ20> SET D0 WRITEBACK_CACHE

Where D0 represents the host logical units of the RAIDsets created above.

2.7.4 Verify and Record Your Configuration

NOTE

Your configuration may be saved on disk using the SAVE

CONFIGURATION command. Refer to the

Configuration and Maintenance Guide

description of this command.

RAID Array 310

for a detailed

You have now completed all the steps required to create an initial configuration on your controller.

2–8 EK–SMRAB–IG. B01

Preparing the HP 9000 Series Systems for Use with

the StorageWorks Controller

This chapter describes t he steps for installing the required device dr ivers onto HP 9000 Series systems running HP-UX 10.01 or higher. The installation steps include loading the device driver(s) to comm unicate through the SCSI Adapter to the StorageWorks RAID Array Controller.

3.1 Installing Hardware

Fast wide differential (FWD) host adapters manufactured by HP can be used with the RAID Array 310 and your HP platform. Install the host adapter in your HP system using the instructions provided with the host adapter documentation before preparing the system to interface with the RAID Array 310. FWD SCSI connectors on add-on or existing host adapters are labeled on the rear panel of your 9000 Series computer.

Do not connect or disconnect the SCSI bus cable with the host powered on as it could damage the host adapter or disrupt system operation. If you need to install a host adapter, do it at this time. Perform the usual back-up and shutdown procedures for your host platform. Turn off power to the host and complete the necessary hardware tasks. Then, power on and reboot the host.

Prevent SCSI bus ID conflicts. The host adapter ID is usually 7 and, if other equipment is connected to the external bus, avoid the used SCSI ID’s. Use the scribed below to determine available device IDs. For optimum RAID array performance, other devices should not be routinely in use on the SCSI bus.

ioscan

command de-

EK–SMRAB–IG. B01 3–1

Getting Started – RAID Array 310 V3.1 for HP–UX

3.2 Installing the Host Device Driver

The procedures for installing HP-UX device driver(s) require you to be familiar with following Hewlett-Packard technical manuals:

Installing Peripherals

•

System Administrator Tasks

•

How HP-UX Works: Concepts for the System Administrator

Installing the disk driver on HP-UX requires the following major steps:

•

Determine the interface required (Section 3.2.1)

•

Verify the availability of the required device driver (Section 3.2.2)

•

Reboot the system and verify the successful installation (Section 3.2.5)

3.2.1 Determine the Device Driver Required

The device drivers you will need for the StorageWorks RAID Array Controller are listed in Table 3–1. This driver is software configurable and is a standard part of the HP-UX operating system. Device files are automatically created for each RAID Array 310 device when you follow the procedures listed in this section.

If you use SAM, you will not need more detailed information than given in the following table. However, if you intend to customize your system's configuration, you will need to refer to " manual. If you need more information on minor numbers, see "

Numbers

Setting Up Devices Using HP-UX Commands

" in the

Installing Peripherals

manual.

" in the

Installing Peripherals

Device Files and Minor

Table 3–1 HP 9000 Drivers

HP FWD SCSI Adapters Drivers

28696A disc3, scsi3 built-in, A4107A, or A2969A sdisk, c720

3–2

EK–SMRAB–IG. B01

Chapter 3. Preparation (HP 9000 Series)

3.2.2 Verify Host Adapter and Driver

Verify that you have the required SCSI Host Adapter and Drivers available to your system.

On a Series 800 System (except for D or K Class machine), type:

# ioscan -f -d scsi3

The output from this command will be similar to:

Class I H/W Path Driver S/W State H/W Type Description ext_bus 0 8 scsi3 CLAIMED INTERFACE HP 28696A,

Fast/Wide SCSI Interface

On a Series 700 System, C, D, J or K Class machine, type:

# ioscan -f -d c720

The output from this command will be similar to:

Class I H/W Path Driver S/W State H/W Type Description ext_bus 0 8/7 c720 CLAIMED INTERFACE GSC built-in,

Fast/Wide SCSI Interface

3.2.2.1 Editing the Kernel Using SAM

1. Execute SAM.

2. Highlight and open Kernel Configuration

3. Highlight and open Drivers

4. Add the necessary drivers Use SAM’s help system to complete the task or refer to “

SAM

” in the

Installing Peripherals

manual.

Adding Device Drivers Using

EK–SMRAB–IG. B01 3–3

Getting Started – RAID Array 310 V3.1 for HP–UX

3.2.2.2 Editing the Kernel Using Commands (if not using SAM)

1. Edit the kernel configuration file using a text editor.

2. Reconfigure the kernel using the Refer to “

Setting up Devices Using HP-UX Commands

uxgen

manual.

3.2.3 HP-UX Series 800 Patch Installation (10.01 only)

Series 800 systems running HP-UX 10.01 require HP kernel patch PHKL_8616 to prevent the SCSI bus from hanging under intensive SCSI I/O conditions. Contact your HP service provider for details about obtaining and installing the patch. Patches and information about the latest patches for HP-UX can be found at HP’s web page:

http://support.mayfield.hp.com/patches/html/patches.html

HP also distributes patches on a regular basis.

3.2.4 Set the SCSI Bus Address of the RAID Array Controller

The SCSI bus address for the RAID Array Controller is set by the CLI in Chapter 2

Creating an Initial Configuration Using the Command Line Interpreter

“

command.

” in the

Installing Peripherals

3.2.5 Reboot the System and Verify the Successful Installation

NOTE

Before proceeding, the RAID Array Controller must be configured. See “Creating a Communication Logical Unit” in Chapter

1. Shutdown the HP system and ensure that all power switches on the RAID Array Controller and on the host computer system are in the off position.

2. Connect the cable between the SCSI adapter’s connector on the back of the HP System and the connector on the front of the RAID Array Controller. This cable is a differential to differential connection and is 3 meters in length.

3. Turn on the power to the RAID Array 450 system.

4. Turn on power to the HP System.

5. During the boot process, device “special” files are created for each logical unit configured on the RAID Array Controller and a Logical Unit (LUN) number is assigned to each storageset configured on the RAID Array Controller.

After rebooting the new kernel, run the host adapter status is OK and all the target LUNs are identified.

ioscan -f

to verify that the drivers are installed,

3–4

EK–SMRAB–IG. B01

Installing Command Console Agent on

Your Host System

This chapter describes how to install a copy of the Command Console (CC) Agent on each of your host systems connected to StorageWorks RAID Array 310 subsystems. You can install and configure the CC Agent automatically, using a script, or m anually by copying files from the CC Agent distribution CD-ROM and editing Agent configuration and your host system ASCII files.

4.1 Introduction

Command Console (CC) Agent for HP-UX is a companion application to the Command Console (CC) Client graphical user interface (GUI) program. CC Agent serves as Client’s assistant in configuring, operating, and monitoring your host’s storage subsystems. CC Agent runs on your host system as a server application. It connects to CC Client sessions via the TCP/IP network protocol.

CC Agent can also be used as a standalone application without the CC Client. In this mode of operation, referred to as Agent Only, the CC Agent monitors the status of the subsystem and provides local and remote notification in the event of a failure. Local notification can be made via E-mail and /or the syslog facility. Remote notification can be made via SNMP messages to an SNMP Monitor. The CC Client is not required for these types of notification. In order to configure the subsystem, use of the CC Client or the CLI would be required.

CC Agent provides a network connection between a host storage subsystem and any number of CC Client sessions running on remote systems. Agent provides access protection on a network address-by-network address basis. You can configure Agent to allow, for instance, one Client session complete configuration access to the storage subsystem, and another Client session might only monitoring capability.

Agent also provides asynchronous fault notification. The program monitors your host’s storage subsystems and sends notification messages to all Client sessions connected to it the moment a fault occurs. You can configure Agent to use TCP notification to Client and SNMP notification to an SNMP-compatible monitoring application.

4.2 Minimum System Requirements

Agent requires the minimum host system resources shown in Table 4–1. The program is designed to operate with Command Console Client Version 1.0 for Windows NT

Windows 95

EK–SMRAB-IG. B01 4–1

and

Getting Started – RAID Array 310 V3.1 for HP–UX

Table 4−1 Minimum System Requirements

Host Feature Requirement

Architecture HP 9000 Series 800, 735, 755, C, D, J, or K-class

computer, 2 MB free space in /tmp directory, and

4 MB free space for Agent installation directory Operating System HP-UX version 10.01, 10.10 or 10.20 Controller Compatibility StorageWorks 2 or 6-port controller running

operating firmware Version 3.0, 5.0 or higher.

4.3 Installing and Configuring CC Agent for HP-UX

CC Agent is the CC Client’s ( the Graphical User Interface) network assistant. You must install and run CC Agent for HP-UX on each host system you wish to connect to the CC Client over the network.

Before you can install an Agent:

•

Your host’s system resources must meet the minimum requirements specified in Section 4.2.

•

You must have created at least one volume (unit) on each storage subsystem to which you want to connect. If your subsystems do not each contain at least one volume, see Chapter 2 to use the controller’s command line interpreter (CLI) software to create one. Subsystems without at least one volume are invisible to Agent and the host operating system.

The fastest and most user-friendly method of configuring an Agent is to use the configuration script. Use of the script is the recommended method for Agent configuration. To install automatically, using the script, go to Section 4.4.

If you wish, however, you can manually configure the Agent by editing the Agent’s configuration files with a text editor. To configure the Agent manually, go to Appendix C.

4.4 Installing and Configuring Automatically

The install program performs the installation at the local host. You must have access to the superuser (root) account on the host.

To install and configure CC Agent automatically, follow these steps:

1. Place the Command Console CD–ROM in your local system’s CD–ROM drive.

2. Mount the CD-ROM. (e.g.,

Change directories to

Unpack the

tar xvf /

To start the installation and configuration scripts, type,

stm_hp.tar

mount_point

The installation program begins, displaying the following:

At the copyright screen, press the ENTER key and the installation menu is displayed.

4–2 EK–SMRAB–IG. B01

mount /dev/dsk/c1t2d0 /cdrom)

/tmp.

Type,

cd /tmp

file in /tmp. Type,

/AGENTS/STM310_HP.TAR

/stgwrks.sh

Chapter 4. Installing the Command Console Agent On Your Host System

***************************************** * Agent and SCSI pass-through driver * * Installation Script * *****************************************

1. Install the SCSI pass-through driver for 800 series NIO systems. NOTE: SYSTEM WILL NEED TO BE REBOOTED

2. Install Agent for all HP-UX systems.

3. Configure the Agent.

4. Exit.

NOTE

The boxed entries in the following example are inquiries from the platform. The text following the entries is a suggested response for the initial install.

Select 1 to install the SCSI pass-thru driver in 800 series NIO systems. Do not select for other HP series 9000 platforms. If you are not sure select 1 and the software will check your machine and exit back to the menu if selection 1 does not need to be run. If the install should be done, the session will continue as follows:

This script will make changes to several system level files and install all application files. You MUST be root to effect these changes!

Current user is root.

Do you wish to continue? [Y,n] :

Type y, then the

You are running an 800 NIO system.

Do you want to continue adding a passthrough driver for a new device? [Y,n] :

Type y then the

Available Host Adapters: ext_bus 0 8 scsi3 CLAIMED INTERFACE HP 28696A- Wide SCSI ID=7 Please enter the H/W Path of the host adapter that the RAID array is connected to. ---->

From the ioscan line display for this example, Type 8, then the

ENTER

key.

ENTER

key. Check this

digit position on your display.

Please enter the Target of the pass-through device. ---->

This is the SCSI target assigned to communicate with the SCSI pass-thru driver (the communication LUN that was created previously, see Chapter 2 for details). For this example, Type 0, then the

ENTER

key.

EK–SMRAB–IG. B01 4–3

Getting Started – RAID Array 310 V3.1 for HP–UX

Please enter the LUN of the pass-through device. ---->

This is the SCSI LUN assigned to communicate with the SCSI pass-thru driver in Chapter

2. For this example, Type 0, then the

The H/W Path of the host adapter device is: 8 The Target of the pass-through device is: 0 The LUN of the pass-through device is: 0 Do you want to make any changes? [y,N]

ENTER

key.

Type n, then the

Building new kernel... Compiling conf.c... Loading the kernel...

Old kernel is saved as /stand/vmunix.prev Do you want to reboot? [Y,n] : System needs to be rebooted to use new kernel.

ENTER

key.

If you don't reboot, the install script again displays the menu (note that you must reboot the system before you can start the CC Agent). If you do reboot, restart the installation and configuration script. Example:

Next, install the Agent; type 2 the

/opt/steam/bin/stgwrks.sh

ENTER

key.

After the copyright, select install agent (2) from the main menu. After the copyright message, the user is checked for root privilege.

When root user has been determined, the script confirms:

Current user is root.

Do you wish to continue? [Y,n]:

Type y, then the

ENTER

key.

Enter the name for the passthrough device special file. This will be created as /dev/rdsk/________ default is spt.

The install script prompts for the name of the device special file. Type the ENTER key to keep the name spt or type the NEW_NAME then ENTER.

Enter the target of the passthrough RAID device. If the target is not known then see the Getting Started Manual on creating a

communications LUN. Target :

For this example, type 0, then the

Enter the LUN of the passthrough RAID device. If the LUN is not known then see the Getting Started Manual on creating a

communications LUN. LUN :

4–4 EK–SMRAB–IG. B01

ENTER

key.

Chapter 4. Installing the Command Console Agent On Your Host System

key.

ENTER

key.

ENTER

to continue.

For this example, type 0, then the

Waiting... Class I H/W Path Driver S/W State H/W Type Description

ext_bus 0 8 scsi3 CLAIMED INTERFACE HP 28696A - Fast/Wide SCSI Interface ext_bus 2 16 scsi3 CLAIMED INTERFACE HP 28696A - Fast/Wide SCSI Interface

Enter the hex Instance number of the host adapter that the array is connected to. (Column I in table above) Instance #:

For this example, type 0, then the

The special file /dev/rdsk/spt will be created for Instance 0, target 0, LUN 0. Do you want to make any changes [y,N] :

Type n, then the

ENTER

key.

Pass-through driver special file /dev/rdsk/spt has been created. Press

Enter a target directory for installation or press return to use the default (default = /opt) :

Type

/opt

, then the

ENTER

Change this only if you want to install to other than the default area /opt. Type the

ENTER

key.

Installing the STEAM Agent in /opt/steam.

Is this okay? [Y,n]

Type y, then the

Adding an entry to /etc/services for the Client using port 4998 Is this OK? [Y,n]

ENTER

key.

Specifies the port number the installation program will assign for the Command Console Client GUI to communicate with the Command Console Agent. If the default port is already used, press N and specify a new even-numbered port. Type y, then the

Adding an entry to /etc/services for STEAM AGENT using port 4999 Is this OK? [Y,n] y

ENTER

key.

Specifies the port number the installation program will assign for the Command Console Agent to send notifications to the Command Console Client GUI. If the default port is already used, press N and specify a new port (port specified above + 1).

Type y, then the

Updating inittab file...done

The Install program updates the

ENTER

key.

inittab

file so that every time the host system boots the

Agent starts.

Enter the directory which contains the device special files .

/dev/rdsk

Type

Enter a password for use with the STEAM Agent (4->16 characters): Verify the password :

, then the

ENTER

key.

EK–SMRAB–IG. B01 4–5

Getting Started – RAID Array 310 V3.1 for HP–UX

To Configure the subsystem using the Command Console GUI, you need to setup a password. The install program does not echo what you type.

The STEAM Agent can operate with other SNMP applications. For this reason, it needs information about the Agent manufacturer and the Enterprise object identifier for use with its MIB.

Enter the name of the Agent manufacturer (no default) :

Digital Equipment Corp.

Type,

The Enterprise OID can be customized. Note that this value must be consistent with the Agent's MIB! The default vendor-specific setting is "36.2.15.21.".

, then the

ENTER

key.

Would you like to enter a new value? [y, n] : Type n, then the

Adding a Client system

---------------------Enter the host name of the Client system :

ENTER

key.

In the event of a component failure, the CC Agent is capable of providing local or remote notification. Local notification is provided via e-mail and a system error log. Remote notification is provided to the command console for display or paging. Users that wish to only have local HP platform notification can disable messages to the client by entering the following information during CC Agent installation or Agent Maintenance (Adding a Client System):

Enter the host name of the Client System: Enter the Access Level:

Enter the notification Level:

Specify names for the hosts from which you will run the GUI. Enter the host name of the Client system :

local host

Type "host_name" of the machine running the GUI, then the

Enter the subsystem access privilege (which controls the level of access a client has for communicating with the storage subsystems). The possible options are:

0 = Overall Status Monitor Event Changes with Notification 1 = Detailed Status View Event Changes with the GUI 2 = Configuration

All of the options in this category

Enter Access Level (0, 1, 2) :

Type 2, then press the

The Agent server can notify a client when an error condition occurs. Notification schemes available are:

0 = No Error Notification (Still have E-Mail and Syslog)

ENTER

key.

ENTER

key.

4–6 EK–SMRAB–IG. B01

Chapter 4. Installing the Command Console Agent On Your Host System

1 = Notification via a TCP/IP Socket

(E-Mail, syslog, GUI shows color status indications.) 2 = Notification via the SNMP protocol (E-Mail, syslog, and Informed of only predefined events) 3 = Notification via both TCP/IP and SNMP

(All of the options in this category) Enter Error Notification Level (0, 1, 2, 3) :

Type 1, then the

Adding client- name: <host name> access level: 2 error notification: 0 Is this information correct? [Y,n]

Verify the information then type y or n, and then

Would you like to add another client? [y,N]

Type n, then press the

Adding a storage subsystem

--------------------------

Enter subsystem host name :

Enter the subsystem name, e.g.

Enter the character special file name for accessing the storage subsystem

(e.g. "rrza19c" or "spt" or "hdisk4")

Enter the device name e.g.

Enter monitoring interval, in seconds (0 => no monitoring):

120

Type

, then the

ENTER

key.

hp_ storage1

spt

and press the

key.

ENTER

key.

, and then press the

ENTER

key.

ENTER

key.

Enter the interval of the notification in seconds.

Adding subsystem- name: hp_storage1 access device: /dev/rdsk/spt monitoring interval: 120 Is this information correct? [Y,n]

Verify the information type y or n, and the

Would you like to add another subsystem? [y,N]

Type y or n, and then the

Would you like to enable mail notification? [Y,n]

Type y, then the

Adding a User for Mail Notification Enter the e-mail address of the user:

EK–SMRAB–IG. B01 4–7

ENTER

key.

ENTER

key

Getting Started – RAID Array 310 V3.1 for HP–UX

Type the User e-mail address, then the

Enter the error notification level for this user. The user will be notified of errors at this level and above. The possible options are:

1 = Fatal Errors 2 = Warning and Fatal Errors 3 = Info, Warning and Fatal Errors

Enter Notification Level (1, 2, 3) :

Type 1, then the

Adding Notification User-- name: Error Notification Level: Fatal Errors Is this information correct? [Y,n]

Type y, then the

Would you like to add another user? [y,N]

Type n, then the

Username Notification Level

-- Hit RETURN to continue --

The STEAM Agent package has been successfully installed.

Would you like to execute the Agent now? [Y,n]

ENTER

key.

Authorized mail notification list

ENTER

key.

Type y, then the

The STEAM Agent has been started.

The installation process is complete. ***************************************** * Enterprise Storage Management (steam) * * Agent and SCSI pass-through driver * * Installation Script * *****************************************

1. Install the SCSI pass-through driver for 800 series NIO systems. NOTE: SYSTEM WILL NEED TO BE REBOOTED

2. Install Agent for all HP-UX systems.

3. Configure the Agent.

4. Exit.

----------------------------------------Select a number :4

Type 4, and then the

ENTER

key.

4–8 EK–SMRAB–IG. B01

Chapter 4. Installing the Command Console Agent On Your Host System

The StorageWorks and Command Console Agent Installation and Configuration Menu. You can make configuration changes at any time by typing:

/installation_directory

/steam/bin/stgwrks.sh

This allows changes to be made to the configuration and operation of the CC Agent. When the Agent Maintenance Option is selected and changes are made to the CC Agent, it must be restarted for changes to become effective. The changes which require a restart of the CC Agent include:

•

Change Agent Password

•

Change SNMP Enterprise OID

•

Add, Remove or Modify a Client

•

Add, Remove or Modify a Subsystem

•

Toggle Error Log Notification

To restart the CC Agent from the Agent Maintenance Menu:

•

Select Start/Stop the Agent from the Agent Maintenance Menu

•

If STEAM Agent is Running is displayed, enter y to terminate the Agent. Then repeat the menu selection and enter y to start the Agent.

•

If STEAM Agent is Not Running is displayed, enter y to start the Agent.

Type y, then press the

Agent Admin Options Storage Subsystem Options

------------------- -------------------------

1) Change Agent Password 12) View Subsystems

2) Change SNMP Enterprise OID 13) Add a Subsystem

3) Start/Stop the Agent 14) Remove a Subsystem

4) Toggle Agent Startup on Boot 15) Modify a Subsystem

5) Uninstall Agent Agent Notification Options Client Options

-------------------------- --------------

6) Toggle Error Log Notification 16) View Clients

7) Toggle Mail Notification 17) Add a Client

8) View Mail Notification List 18) Remove a Client

9) Add User to Mail Notification List 19) Modify a Client

10) Remove User from Mail Notification List

11) Modify Mail Notification List Exit:

--- Q) Quit

ENTER

key.

RAID Array 310 v3.1 Configuration Menu

--------------------------------------

For example to stop the Agent type 3, then the

Agent Start/Stop

---------------The STEAM Agent's current state is : RUNNING Would you like to terminate it? [Y,n]

EK–SMRAB–IG. B01 4–9

ENTER

key.

Getting Started – RAID Array 310 V3.1 for HP–UX

NOTE

If you type “y”, t he output is shown below. Be sure to re-enter the configuration menu and restart the Agent.

Type y, then press the

The STEAM Agent has been terminated.

-- Hit RETURN to continue --

ENTER

key.

The Agent configuration menu is displayed again. Type q, then the

ENTER

key to return to the main menu.

4.5 Running CC Agent

Your Agent program was automatically started when you installed it, and it was installed to restart automatically if it stops for any reason.

The installation script places an entry in the “/etc/inittab” file to implement automatic execution of the Agent. The tag field in the file is “swcc”.

4.6 Reconfiguring CC Agent

You can reconfigure previously-installed Agents using the configuration program. To reconfigure an Agent, execute the “config.sh” Bourne-shell script in the

installation_directory/

“/

steam/bin” subdirectory and follow the prompts.

4.7 Uninstalling CC Agent

You can remove any Agent program using the uninstall program. You have two options to remove an Agent:

•

Run the Agent configuration script on the host and Select Option 5. Run the “config.sh” script in the “/

•

Run the Agent uninstall script on the host. Execute the command:

/installation_directory/steam/bin/uninstal.sh /installation_directory

installation_directory/

steam/bin” subdirectory.

If you do not know what the location is, examine the file “/etc/.STEAMDIR”.

4.8 What To Do Next

The HP-UX operating system has now been modified to communicate with the RAID Array Controller. In order to use the RAID Array from the HP System, you must do the following steps:

1. Create new storagesets on your RAID Array and assign SCSI target and LUN IDs to each storageset created. You can use either the CLI (see Appendix C) or the Command Console Client (see Appendix D). LUNs created on the Array must be assigned consecutively starting with LUN 0.

2. To make the storagesets available to the HP-UX System do the following:

3. At the system prompt, type

ioscan -f

the HP System acknowledges the new hardware.

then press the

ENTER

key. Verify that

4–10 EK–SMRAB–IG. B01

Chapter 4. Installing the Command Console Agent On Your Host System

4. Type

insf -e,

then press the

ENTER

key. The HP system will create the device special files needed to communicate with each storageset. (Use verify).

Use SAM to set up the filesystem or refer to the

System Administration Tasks

instructions on the following tasks:

•

Adding the RAID storageset to volume groups

•

Creating file systems or swap area in logical volumes

•

Determining the mount point directory on your system

•

Using the

•

Editing the

mount

command to mount the device on your system

/etc/checklist

file if you want this device mounted each time you boot the

system.

NOTE

If changes are made on the RAID Array 310 before they are removed from the system, they cannot be removed from the system with SAM. If configuration changes are required in the RAID Array 310 that affect the file system, make t he changes in the following order:

Back up your filesystem. Unmount the units that are changing in the file system.

ioscan -nf

manual for

Remove the changed areas from the f ile system. Use SAM or operating system level commands.

Re-configure the RAID array. Add the new configuration to the file system. Restore your back up to your new file system.

If you wish to inst all the Command Console Client at this point, proceed to Appendix B.

EK–SMRAB–IG. B01 4–11

Installing the Command Console Client

This chapter describes how to install a copy of the Command Console (CC) Client on each of your client systems.

5.1 Introduction

The Command Console (CC) Client is the Graphical User Interface (GUI) for configuring and monitoring your StorageWorks RAID Array 310 subsystem. It runs only on an Intel PC with Windows 95 or Windows NT. Install the Client software on your system using the information described below.

5.2 Installing the Client Program

NOTE

The version of Command Console that is bundl ed with St orageWork s RAID Arrays is lic ensed t o manage a s i ngle ar ray on one hos t s er v er. To manage multiple hosts from a client management station, Command Console Plus must be purchased.

Install a copy of the Command Console Client program on each of the Intel-based systems on your network from which you want to configure or monitor a StorageWorks RAID Array 310 subsystem.

Before you can install Client, make sure that the system you’ll be installing it on meets the minimum requirements listed in Table 5–1.

Table 5−1 Minimum CC Client System Requirements

Architecture Intel 486/66 MHz, 16 MB memory, 10 MB free disk

space, CD-ROM drive

Operating system Windows NT 3.51 (build 1057 or later) or Windows 95

(build 950 or later) Graphics Subsystem SVGA or better. 800 x 600 minimum screen resolution. Input devices Keyboard, mouse Modem Optional Serial port (for

connection via serial port only)

Network adapter TCP/IP-compatible network . Controller

compatibility

Standard, PC serial port capable of at least 9600 baud.

Controller running operating firmware Version 3.1 or

higher.

EK–SMRAB–IG. B01 5–1

Getting Started – RAID Array 310 V3.1 for HP–UX

NOTE

To ensure a complete installation, uninstall Command Console before replacing it with another version.

To install Command Console on Windows NT:

1. Place the RAID 310 CD in the CD-ROM drive.

2. Open the File menu in the Program Manager.

3. Select the RUN option.

4. In the text box, type

drive_letter:\client\install

5. Follow the instructions in the setup program to complete the installation.

To install Command Console on Windows 95:

1. Place the CD in the CD-ROM drive.

2. Select “My Computer”.

3. Double click on the CD-ROM drive icon.

4. Double click on the “client” icon.

5. Double click on “install.bat” icon.

6. Follow the instructions in the setup program to complete the installation. Your Client program is installed!

and click OK.

Repeat these steps to instal l a copy of CC cli ent on each of the syst ems from which you want to configure and monitor a StorageWorks RAID Array 310 subsystem.

This completes the installation of the Command Console Client. Refer to Appendix D to start it.

5.3 Uninstalling Command Console

To uninstall Command Console, click the “Remove Command Console” icon in Windows NT. In Windows 95, use the “Add/Remove Programs” utility in the Control Panel.

5–2 EK–SMRAB–IG. B01

Configuration Records – Blank Forms

This appendix contains copies of the two tables used in Chapter 2 to record the conf iguration of your system. If additional copies are required, these tables can be reproduced as necessary.

EK–SMRAB–IG. B01 A–1

Getting Started - RAID Array 310 V3.1 for HP–UX

Date_____________ LUN Uses

A–2 EK–SMRAB–IG. B01

Configuration Guidelines

This appendix contains a list of guidelines that will as sist in opt imizing t he perfo rmance of your RAI D Arr ay 310 Subsystem.

Use the following guidelines, as appropriate, to optimize you system performance.

1. Evenly distribute the devices across separate ports. This permits parallel activities on

the controller’s available ports to the attached devices.

2. Intermix higher and lower performance devices on the same port, that is, use 7200

rpm and 5400 rpm drives on the same port.

3. Evenly distribute logical units across separate targets, that is, use different SCSI IDs,

if possible. RAID Array 310 supports a maximum of four SCSI IDs.

4. Avoid configuring multiple mirrorsets with the first members being on the same

port. That is use:

add mirrorset m1 disk100 disk200 add mirrorset m2 disk210 disk110

Instead of using:

add mirrorset m1 disk100 disk200 add mirrorset m2 disk110 disk110

The default mirrorset read selection algorithm will choose the first member of the

mirrorset if the mirrorset does not already have a read queue.

5. If write performance is important, the wri teback cache s hould be tu rned ON for each

unit. The default value is OFF.

6. If transfer sizes are small (less than 8 KB), use the default maxi-

mum_cached_transfer size (32). Transfers that exceed the default maximum_cached_transfer size will never go into the cache. For most random access benchmarks, it is best to set this number high (for example, 1024).

EK–SMRAB–IG. B01 B–1

Upgrading Controller Software

This appendix contains the procedures for backing up and upgrading the controller software.

C.1 Backing Up Your System

Before performing the upgrade, backup all data and files from your RAID Array 310 subsystem.

C.2 Saving the RAID Array 310 Configuration

In the following steps, you need to record your configuration for use in the event that the configuration is not correctly preserved during the software upgrade.

First, record the controller configuration. Display the controller info by using the CLI command:

HSZ20> show this_controller full

Record the following information in the blanks bel ow (SCSI Target s, Preferred Targets , Cache Flush Timer, Cache Policy, and Host Functionality Mode):

Fill in the blanks below.

Controller: ZG43700116 HSZ20 Controller Software, Hardware A02 Not configured for dual-redundancy SCSI address 7 Time: NOT SET Host port: SCSI target(s) ________ Preferred target(s) ________ Cache: 16 megabyte write cache, version 2 Cache is GOOD Battery is GOOD

No unflushed data in cache CACHE_FLUSH_TIMER = DEFAULT (10 seconds) CACHE_POLICY = _____

Host Functionality Mode = A Licensing information: RAID (RAID Option) is ENABLED, license key is VALID WBCA (Writeback Cache Option) is ENABLED, license key is VALID MIRR (Disk Mirroring Option) is ENABLED, license key is VALID

EK–SMRAB–IG. B01 C–1

Getting Started – RAID Array 310 V3.1 for HP–UX

Extended information: Terminal speed 9600 baud, eight bit, no parity, 1 stop bit Operation control: 00000004 Security state code: 95018 Configuration backup disabled

C.2.1 Record Logical Units

List the Logical Units by entering:

HSZ20>

LUN Uses D100 S28

Switches: RUN NOWRITE_PROTECT READ_CACHE WRITEBACK_CACHE MAXIMUM_CACHED_TRANSFER_SIZE = 32

State: ONLINE to this controller Not reserved PREFERRED_PATH = THIS_CONTROLLER

Size: 20547350 blocks

D200 M1

Switches: RUN NOWRITE_PROTECT READ_CACHE WRITEBACK_CACHE MAXIMUM_CACHED_TRANSFER_SIZE = 32

State: ONLINE to this controller Not reserved PREFERRED_PATH = THIS_CONTROLLER

show unit full

Size: 4109470 blocks

Record, and mark when enabled, the information in the following table. The top line shows how to record entries for D100 of the sample.

C–2 EK–SMRAB–IG. B01

Table C–1 Logical Unit Table

Appendix C. Upgrading Controller Software

LUN USES RUN WRITE

PROTECT

D100 S28 X X X 32

READ

CACHE

WRITEBACK

CACHE

MAX

CACHED

TRANSFER

SIZE

Next, list the storagesets you have configured:

SWXRC> show storagesets full

The controller responds with a display similar to that shown below:

Name Storageset Uses Used by S28 stripeset DISK130 D100

DISK220

Switches:

CHUNKSIZE = 256 blocks State: NORMAL DISK130 (member 0) is NORMAL DISK220 (member 1) is NORMAL Size: 50268168 blocks

M1 mirrorset DISK100 D200

DISK110

Switches:

POLICY (for replacement) = BEST_PERFORMANCE COPY (priority) = NORMAL READ_SOURCE = LEAST_BUSY

MEMBERSHIP = 2, 2 members present

EK–SMRAB–IG. B01 C–3

Getting Started – RAID Array 310 V3.1 for HP–UX

Record the storageset information in the Storageset Table (Table C–2). The first row shows how to record for S28 of the sample:

NOTE

Not all column headings apply to all storagesets

Table C–2 Storageset Table

NAMESTORAGE-

S28 Stripeset DISK130

SET

USES USED BY POLICY COPY READ

DISK220

D100 256

SOURCE

RECONSTRUCT

CHUNK-

SIZE

FAIL

AUTOSPARE NOAUTOSPARE ED SET

C–4 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

C.3 Upgrading Controller Software Using Windows NT

To upgrade software on these subsystems to Version V31Z, copy a new version of the software image from the CD−ROM, on which the new software image was distributed, to the controller. To do this, you need the following:

•

The software distribution CD−ROM that cam e i n t h e S t o rag eWo rks RAID Array 3 10 upgrade kit.

•

Windows 3.1 or 3.11, Windows for WorkGroups, Windows NT, or Windows 95 running on a PC with a CD−ROM drive an d a serial connect ion to th e RAID Array subsystem.

•

A terminal emulation program that runs the Kermit protocol and supports binary transfers.

In addition, stop any terminate-and-stay-ready (TSR) programs, such as screen savers, that may be running on that server.

It takes approximately 40 minutes to download the new software image at 19200 baud. To begin upgrading the controller software, start and setup the terminal emulation program as specified below.

If you are using Windows 95 or Windows NT 4.0, skip to sect ion C.5.

C.4 Windows NT 3.51 Procedures

1. Open the Windows

2. Select

File

from the menu bar and click Change the group name from Accessories to RAID Manager or C ommand Console. (This step is optional).

3. If you copied Terminal to either the RAID Manager or Command Console group, go to that group now.

4. Click on

5. Click

Terminal

File

from the menu bar followed by

•

Change the icon description name from Terminal to HSZ Term.

•

Press the Tab key which highlights arrow cursor key once. Next , press the spacebar an d type: the OK button.

Accessories

to highlight the icon.

NOTE

and click to highlight the

Copy

or F8 to copy the Terminal icon.

Properties

. From the Properties menu:

TERMINAL.EXE

Terminal

program.

. Now press the right

HSZ.TRM

Click

EK–SMRAB–IG. B01 C–5

Getting Started – RAID Array 310 V3.1 for HP–UX

6. Double-click the HSZ term icon. You should receive the error message, “C annot find the settings file HSZ.TRM”. Click OK. After the Terminal Program starts, select the

Communications

option from the

parameters:

•

Baud rate = 9600

•

Data Bits = 8 (default)

•

Stop Bits = 1(default)

•

Parity = None (default)

•

Flow Control = Xon/Xoff (default) or None

•

Connector = (appropriate Com port)

Settings

menu. Set these communication

7. Click

File

from the Terminal menu bar and choose

Save As…

Click OK.

NOTE

It is recommended that the window be maximized while upgrading the firmware or when running other diagnostics.

Click OK when you complete the settings. Press the Enter key and the default prompt appears.

8. Set the controller prompt by typing:

set this_controller prompt=HSZ20>

NOTE

Wherever “HSZ20>” is the string, it should be 1 t o 16 char act er s long and enclosed in quotes

9. To change the controller's baud rate to 19200, type:

set this_controller terminal_speed=19200

10. Change the Terminal program’s baud rate to match the controller's.

NOTE

. Type in HSZ.TRM.

Remember to change the Command Console software baud rate from 9600 to 19200.

11. Press the Enter key and the HSZ20> prompt appears. Now you are ready to begin downloading the software.

C–6 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

C.4.1 Downloading the Software

To download the new software, follow these steps:

1. Insert the distribution CD-ROM containing the binary file of the new software image into a CD-ROM drive of a computer connected to the RAID Array controller.

2. Copy the firmware image from the CD-ROM software directory (\firmware\v3.1) into a temporary directory on the system disk.

3. Start the terminal program with the communications settings as specified above.

4. Press the

Enter

key to get to the

5. Invoke the CLCP utility, at the

Select an option from the following list:

Code Load and Patch Utility Main Menu

0: Exit 1: Enter Code LOAD utility 2: Enter Code PATCH utility

Enter option number (0..2) ? 1

HSZ20>

prompt.

prompt, type:

run clcp

6. Type: 1 and press Return. The utility displays the following message:

You have selected the Code Load Utility. This utility is used to load a new software image into the program card currently inserted in the controller.

Type ^Y or ^C (then RETURN) at any time to abort code load. The code image may be loaded using SCSI Write Buffer commands

through the SCSI Host Port, or using KERMIT protocol through the Maintenance Terminal Port.

0: Exit 1: Enter the SCSI Host Port 2: Use the Maintenance Terminal Port

Enter option number (0..2) [0] ? 2

7. Type: 2 and press the Return key. The utility displays the following message:

---------------------------------------------

Perform the following steps before continuing:

*get new image file on the serial line host computer *configure KERMIT with the following parameters: terminal speed 19200 baud, eight bit, no parity, 1 stop bit

It will take approximately 35 to 45 minutes to perform the code load operation.

WARNING: proceeding with Code Load will overwrite the current content of your program code with a new image. Enter Y (then RETURN) to continue

[N] ? y

Start KERMIT now…

EK–SMRAB–IG. B01 C–7

Getting Started – RAID Array 310 V3.1 for HP–UX

8. Exit any MS-Windows sessions and select

Binary Transfers

from the

to start Kermit.

9. Select

10. Select

Kermit

and click OK.

Send Binary File

from the

Transfers

menu to begin downloading the new

software as shown in Figure B-1

CAUTION

You must use a binary transfer mode. Failure to use a binary transfer mode will result in corruption of the controller software

Figure C–1 Select Send Binary Files from the Transfers Menu

Settings

11. Select the V31Z.IMG file and Click OK as shown in figure C-2.

NOTE

The following figures show a sample software version level and not the software version level that you will actually download. The correct software vers ion level is specified in the text of t his procedure.

C–8 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

Figure C−2 Select the V31Z.IMG File

When the download completes, the utility displays the following message before reprogramming the controller's program care:

CAUTION

Do not interrupt the power to the RAID subsystem while the CLCP Utility r eprograms the contro ller. The CLCP utility sa ves the software in non-volatile RAM on the controller. Any interruption of this procedure will result in the inability of the subsystem to reboot.

KERMIT file transferred successfully. Program card is being re-programmed with new file.

*** Do not interrupt this step ***

Manufacturer code read from memory card= 8989 Device Code read from memory card= bdbd

12. If the main menu appears, press 0 to exit the utility.

13. Verify that this process successfully copied the new version of the software onto the controller.

At the CLI prompt, type

HSZ20>

show this_controller

EK–SMRAB–IG. B01 C–9

Getting Started – RAID Array 310 V3.1 for HP–UX

The CLI displays information indicating the current software version of the controller similar to the following:

Controller Model: HSZ20 Serial Number: CX54300265 Hardware version: A02(02) Software Version:V31Z

Informational Report Instance Code: 0102030A Last Failure Code:86000020 (No Last Failure Parameters)

Controller:

HSZ20 CX54300265 Software V31Z, Hardware A02 Not configured for dual-redundancy SCSI address 7 Time: NOT SET

Host Port:

SCSI target(s) (0, 1, 2, 3), Preferred target(s) (0, 1, 2, 3)

TRANSFER_RATE_REQUESTED = 10MB Cache: 16 megabyte write cache, version 2 Cache is GOOD Battery is GOOD No unflushed data in cache CACHE_FLUSH_TIMER = DEFAULT (10 seconds) CACHE_POLICY = A Host Functionality Mode = A

C.5 Firmware Upgrade Procedures for Windows 95 and Windows NT 4.0

Before beginning, connect a serial line between the com port on your PC and the serial port on the RAID Array 310. To begin upgrading the controller software, start and set up the terminal emulation program as specified below:

1. Click the highlight

2. To t he right of Accessori es, select create a new terminal session.

3. Enter select the OK icon.

Start

button and cursor to the Program menu. At the right of the menu bar,

Accessories.

HSZ Term

Hyperterminal

. Click the

Hyperterminal

as the Connection Description name. Press the

Tab

key once and

menu to

C–10 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

4. At the “Connect To” menu, change the connection settings for your particular system setup by pressing the

Enter

key. Choose the appropriate com port for your system and

click OK.

NOTE

COM1 is the default connection setting

5. Change the Port Settings baud rate from 2400 to 9600 bits per second.

6. Select

Xon/Xoff

Non

e as the Flow Control setting. Click OK. This will return you to

your newly-created Terminal session.

7. Press the

Enter

key again and you should receive the default prom pt. At the prompt,

type ?. The controller will provide a list of available commands.

NOTE

For a list of additional command options, type the command followed by a space plus a ?.

8. Click

File

at the menu bar. Choose Save, to save the configuration you have just

created.

9. Set the controller prompt by typing at the prompt:

set this_controller prompt=”HSZ20>”

NOTE

Wherever the controller pr ompt is HSZ20>, its string should be 1 to 16 characters long and enclosed in quotes.

10. Change the controller’s baud rate to 19200 by typing:

HSZ20> set this_controller terminal_speed=19200

11. Change the Terminal’s baud rate to match the controller’s.

CAUTION

Remember to change the Command Console software baud rate from 9600 to 19200.

12. Press the

Enter

key and the

HSZ20>

prompt appears. Now you are ready to begin

downloading the software.

EK–SMRAB–IG. B01 C–11

Getting Started – RAID Array 310 V3.1 for HP–UX

C.5.1 Downloading the Software

To download the new software, follow these steps:

NOTE

The Code Load/Code Patch (CLCP) Ut ilit y m ess ages s hown ar e for a RAID Array 310 Subsystem. The CLCP Utility me ssages for other RAID Array subsystems are similar.

1. Insert the distribution CD−ROM containing the binary file of the new software image into a CD−ROM drive of a computer connected to the RAID Array controller.

2. Copy the firmware image from the CD−ROM software directory -

D:\firmware\v31z.img

3. Start the terminal program with the communications settings as specified above.

onto a temporary directory on the system disk.

4. Press the

Enter

key to get to the

5. Invoke the CLCP utility, at the

Select an option from the following list: Code Load and Patch Utility Main Menu

0: Exit 1: Enter Code LOAD utility 2: Enter Code PATCH utility

Enter option number (0..2) ? 1

HSZ20>

prompt.

prompt, type:

run clcp

6.Type: 1 and press the Return key. The utility displays the following message:

You have selected the Code Load Utility. This utility is used to load a new software image into the program card currently inserted in the controller.

Type ^Y or ^C (then RETURN) at any time to abort code load. The code image may be loaded using SCSI Write Buffer commands

through the SCSI Host Port, or using KERMIT protocol through the Maintenance Terminal Port.

0: Exit 1: Enter the SCSI Host Port 2: Use the Maintenance Terminal Port

Enter option number (0..2) [0] ? 2

C–12 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

7. Type: 2 and press the Return key. The utility displays the following message:

Perform the following steps before continuing:

• get new image file on the serial line host computer

• * configure KERMIT with the following parameters:

• terminal speed 19200 baud, eight bit, no parity,

• 1 stop bit

It will take approximately 35 to 45 minutes to perform the code load operation.

WARNING: proceeding with Code Load will overwrite the current content of your program code with a new image. Enter Y (then RETURN) to continue

[N] ? y

Start KERMIT now…

8. Select

Send File

from the

Transfer

menu.

Figure C–3 Select Send File from the Transfer Menu

9. Type the location of the firmware image file (V31Z.IMG) in the Filename box.

Kermit

Select

EK–SMRAB–IG. B01 C–13

in the Protocol box and click the

Send

button.

Getting Started – RAID Array 310 V3.1 for HP–UX

Figure C−4 Select the V31Z.IMG File

When the download completes, the utility displays the following message before reprogramming the controller's program care:

CAUTION

KERMIT file transferred successfully. Program card is being reprogrammed with new file.

*** Do not interrupt this step ***

Manufacturer code read from memory card= 8989 Device Code read from memory card= bdbd

10. If the main menu appears, press 0 to exit the utility.

11. Verify that this process successfully copied the new version of the software onto the controller.

12. At the CLI prompt, type

HSZ20>

show this_controller

The CLI displays information indicating the current software version of the controller similar to the following:

Controller Model: HSZ20 Serial Number: CX54300265 Hardware version: A01 Software Version:V31Z-0 Informational Report Instance Code: 0102030A Last Failure Code:86000020 (No Last Failure Parameters) HSZ20>show this_controller

C–14 EK–SMRAB–IG. B01

Appendix C. Upgrading Controller Software

Controller:

HSZ20 CX54300265 Software V31Z, Hardware A02 Not configured for dual-redundancy SCSI address 7 Time: NOT SET

Host Port:

SCSI target(s) (0, 1, 2, 3), Preferred target(s) (0, 1, 2, 3)

TRANSFER_RATE_REQUESTED = 10MB Cache: 16 megabyte write cache, version 2 Cache is GOOD Battery is GOOD No unflushed data in cache CACHE_FLUSHED_TIMER = DEFAULT (10 seconds) CACHE_POLICY = A Host Functionality Mode = A.

C.6 Reverting to Software Image Version 2.7

To request release V2.7, substitute V27Z.IMG for V31Z.IMG in the previous section as the correct software image filename. V27Z.IMG is stored in directory (firmware\V27).

C.7 Manual RAID Array 310 Configuration Restoration

The configuration of the storage sets on the RAID array 310 is usually unaffected by changing the software version. The configuration parameters, however, should be logged before performing any upgrade.

EK–SMRAB–IG. B01 C–15

Configuring STRIPEsets, MIRRORsets, and

Striped MIRRORsets

This appendix supplements Chapter 2 and contains instr uct ions for configur ing

and Striped MIRRORsets.

D.1 Create a STRIPEset (Configuration Example 1)

If your site requires STRIPEsets for storage, you must assign disks to each STRIPEset. STRIPEsets must have at least two members, and can have as many as fourteen. This example creates a two-member STRIPEset using the ADD STRIPESET command.

HSZ20> ADD STRIPESET STRIPE1 DISK130 DISK220

In this example, “STRIPE1” is the name of the STRIPEset, and it is followed by a list of the disks to be included in the STRIPEset. The names of the STRIPEsets are userdefined. Performance of your STRIPEsets will be optimized if each STRIPEset includes disks from different buses as shown in Figure 2–1 in Chapter 2. The example above contains disks from different buses.

D.1.1 Initialize the STRIPEset

You must initialize STRIPEsets before you can put them into service. When you initialize a STRIPEset, you can optionally specify a chunksize. The chunksize is the number of blocks of data that are transferred at one time or the width of the stripe. By using the default chunksize, the controller will select a chunksize that works well for most site requirements.

STRIPEsets, MI RRO Rset s,

HSZ20> INITIALIZE STRIPE1 SAVE_CONFIGURATION

EK–SMRAB-IG. B01 D–1

NOTE

Valid chunksizes are 16 – 32768 blocks. You should use a larger chunksize for applications that make a lot of I/O requests. Use a smaller chunksize for applications t hat make relatively few I/O requests, but need to move large am ounts of data with each request.

Getting Started – RAID Array 310 V3.1 for HP–UX

D.1.2 Add the STRIPEset as a Logical Unit

To make a STRIPEset available to the host computer, you must add it as a host logical unit with a unique unit number. The unit number is a one or three digit number preceded by “D”, such as “D0” or “D102”. The unit number is made of the controller’s target ID and the Logical Unit (LUN) of the STRIPEset for the target. Each target ID can have up to eight LUNs, numbered 0–7.

•

Units identified with controller target ID 0 have a single digit number which corresponds to the LUN number. For example, D5 would be target 0, LUN 5.

•

Units identified with all other controller targets (1–7) use a 3 digit number. The first digit corresponds to the controller target number, the second digit is always 0 and the third digit is the LUN number. For example, D205 would be target 2, LUN 5.

Identify the STRIPEsets as host logical units by using the ADD UNIT command.

HSZ20> ADD UNIT D100 STRIPE1

This example creates LUN 0 for controller target ID 1 (specified earlier with the SET THIS_CONTROLLER command).

D.1.3 Set Writeback Cache

The final step in creating a STRIPEset is to enable the writeback cache. A single CLI command enables that feature for the entire STRIPEset:

HSZ20> SET D100 WRITEBACK_CACHE

Where D100 represents the host logical unit of the STRIPEset created above.

D.2 Create a MIRRORset (Configuration Example 1)

If your site requires MIRRORsets for storage, you must assign disks to each MIRRORset. MIRRORsets must have at least two members, and can have as many as six. This example creates a two-member MIRRORset using the ADD MIRRORSET command.

HSZ20> ADD MIRRORSET MIRROR1 DISK120 DISK210

In this example, “MIRROR1” is the name of the MIRRORset, and it is followed by a list of the disks to be included in the MIRRORset. The names of the MIRRORsets are userdefined. Performance of your MIRRORsets will be optimized if each MIRRORset includes disks from different buses as shown in Figure 2–1 in Chapter 2. The example above contains disks from two different buses.

D.2.1 Initialize the MIRRORset

You must initialize a MIRRORset before you can put it into service.

HSZ20> INITIALIZE MIRROR1

D–2 EK–SMRAB–IG. B01

Appendix D. Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

D.2.2 Add the MIRRORset as a Logical Unit

To make a MIRRORset available to the host computer, you must add it as a host logical unit with a unique unit number. The unit number is a one or three digit number preceded by “D”, such as “D0” or “D102”. The unit number is made of the controller’s target ID and the Logical Unit (LUN) of the MIRRORset for the target. Each target ID can have up to eight LUNs, numbered 0–7.

•

Units identified with controller target ID 0 have a single digit number which corresponds to the LUN number. For example, D5 would be target 0, LUN 5.

•

Identify the MIRRORsets as host logical units by using the ADD UNIT command.

HSZ20> ADD UNIT D200 MIRROR1

This example uses the controller target ID of 2 and LUN 0.

D.2.3 Set Writeback Cache

The final step in creating the MIRRORset is to enable the writeback cache. A single CLI command enables that feature for the entire MIRRORset:

HSZ20> SET D200 WRITEBACK_CACHE

Where D200 represents the host logical unit of the MIRRORset created above.

D.3 Create a Striped MIRRORset (Configuration Example 2)

If your site requires striped MIRRORsets for storage, you must assign disks to MIRRORsets and then assign the MIRRORsets to a STRIPEset.

D.3.1 Create the MIRRORsets

MIRRORsets must have at least two members, and can have as many as six. This example creates 2, two-member MIRRORsets using the ADD MIRRORSET command.

HSZ20> ADD MIRRORSET MIRROR3 DISK100 DISK200 HSZ20> ADD MIRRORSET MIRROR4 DISK110 DISK210

In this example, “MIRROR3” and “MIRROR4” are the names of the MIRRORsets, and they are followed by a list of the disks to be included in each MIRRORsets.

D.3.2 Create a STRIPEset from the MIRRORsets

Striped MIRRORsets must have at least two members, and can have as many as fourteen. This example creates a two-member STRIPEset using the ADD STRIPESET command.

HSZ20> ADD STRIPESET MIRSTR1 MIRROR3 MIRROR4

In the previous example, “MIRSTR1” is the name of the striped MIRRORset, and it is followed by a list of MIRRORsets to include in the STRIPEset. The name of the STRIPEset is user-defined. Performance of your striped MIRRORset will be optimized if each MIRRORset includes disks from different buses.

EK–SMRAB–IG. B01 D–3

Getting Started – RAID Array 310 V3.1 for HP–UX

D.3.3 Initialize the Striped MIRRORset

You must initialize the striped MIRRORset before you can put it into service. When you initialize a STRIPEset, you can optionally specify a chunksize. The chunksize

is the number of blocks of data that are transferred at one time. By using the default chunksize, the controller will select a chunksize that works well for most site requirements.

HSZ20> INITIALIZE MIRSTR1 SAVE_CONFIGURATION

Valid chunksizes are 16–32768 blocks. You should use a larger chunksize for applications that make a lot of I/O requests. Use a smaller chunksize for applications t hat make relatively few I/O requests, but need to move large am ounts of data with each request.

D.3.4 Add the Striped MIRRORset as a Logical Unit

To make a striped MIRRORset available to the host computer, you must add it as a host logical unit with a unique unit number. The unit number is a one or three digit number preceded by “D”, such as “D0” or “D102”. The unit number is made of the controller’s target ID and the Logical Unit (LUN) of the striped MIRRORset for the target. Each target ID can have up to eight LUNs, numbered 0–7.

NOTE

•

Units identified with controller target ID 0 have a single digit number which corresponds to the LUN number. For example, D5 would be target 0, LUN 5.

•

Identify the striped MIRRORset as a host logical unit by using the ADD UNIT command.

HSZ20> ADD UNIT D300 MIRSTR1

Where 300 represents the host logical unit of the striped MIRRORset created above.

D.3.5 Set Writeback Cache

The final step in creating the MIRRORset is to enable the writeback cache. A single CLI command enables that feature for the entire striped MIRRORset:

HSZ20> SET D300 WRITEBACK_CACHE

Where D300 represents the host logical unit of the striped MIRRORset described above.

D–4 EK–SMRAB–IG. B01

Appendix D. Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

D.4 Add Individual Disks as Logical Units (Configuration Example 2)

Before you can put an individual disk into service, it must be initialized:

HSZ20> INITIALIZE DISK120 HSZ20> INITIALIZE DISK220

If you require individual Disks to be available to the host as Logical Units, you must now identify the Disks as host logical units by using the ADD UNIT command.

HSZ20> ADD UNIT D1 DISK120 HSZ20> ADD UNIT D2 DISK220 SAVE_CONFIGURATION

In this example, disk DISK120 and DISK220 are identified to the host as units D1 (Target 0, LUN 1) and D2 (Target 0, LUN 2) respectively.

D.5 Add Drives to the Spareset

If a disk in a RAIDset or MIRRORset goes bad, the controller will replace it with a disk from the Spareset, if one exists. If the Spareset is empty, a RAIDset will run “reduced,” and you should replace the disabled disk as soon as possible. For maximum availability, you should keep at least one drive in the spareset.

The Spareset always exists in the controller configuration, even if there are no drives assigned to it. Assign drives to the Spareset with the ADD SPARESET command.

HSZ20> ADD SPARESET DISK130

In this example, DISK130 was assigned to the Spareset.

D.6 Failed Set

Failed drives are automatically added in the FAILEDSET. Failed drives that are replaced with new drives that SPARESET. To enable this feature, use the command:

HSZ20> SET FAILEDSET AUTOSPARE

You can remove or insert devices at any time, with the following restrictions:

•

Do not remove or insert devices before the CLI prompt appears during a controller initialization.

•

Do not insert devices while the controller is still recognizing a device removal (indicated by flashing LEDs).

•

Do not remove or insert devices while the controller is running a local program such as DILX or VTDPY.

•

Wait 50 seconds after inserting one disk drive before inserting a second disk drive.

do not contain

metadata can be automatically placed in the

EK–SMRAB–IG. B01 D–5

Getting Started – RAID Array 310 V3.1 for HP–UX

The Auto New Spare feature only operates when the newly-inserted disk drive does not contain any metadata, such as a disk drive from the factory. You can use the transportable function to initialize a used device so that it no longer contains metadata by issuing the following CLI commands:

HSZ20> SET

HSZ20> INITIALIZE

disk-name

TRANSPORTABLE

To initialize additional disks, simply remove the first disk and replace it with another, then retype the

TRANSPORTABLE

INITIALIZE

commands as long as you use the same SCSI-location.

command. You do not need to reenter the

When the drive is moved into the spareset, some metadata is written on it and it is no longer transportable. Additional metadata is written on it when it is moved from the spareset into a RAIDset or MIRRORset.

D.7 Verify and Record Your Configuration

NOTE

Your configuration may be saved on disk using the SAVE CONFIGURATION command. Refer to the

Configuration and Maintenance Guide

description of this command.

You have now completed all the steps required to create an initial configuration on your controller. In the following steps, verify and record your configuration for future reference. Additional worksheets are provided in Appendix A for recording changes to the configuration.

ADD DISK

RAID Array 310

for a detailed

SET

First, verify the Logical Units you have configured:

HSZ20> SHOW UNITS

The controller responds with a display similar to that shown below:

Configuration Example 1:

LUN Uses

----------------------------------------D100 STRIPE1 D200 MIRROR1

Configuration Example 2:

LUN Uses

----------------------------------------D1 DISK120 D2 DISK220 D300 MIRSTR1

Record the information in the following table:

D–6 EK–SMRAB–IG. B01

Appendix D. Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

Date__________________ LUN Uses

EK–SMRAB–IG. B01 D–7

Getting Started – RAID Array 310 V3.1 for HP–UX

Next, verify the storagesets you have configured:

HSZ20> SHOW STORAGESETS

The controller responds with a display similar to that shown below:

Configuration Example 1:

Name Storageset Uses Used by

---------------------------------------------------------------STRIPE1 stripeset DISK130 D100

MIRROR1 mirrorset DISK120 D200

RAIDS1 raidset DISK100 D0

FAILEDSET failedset

Configuration Example 2:

Name Storageset Uses Used by

---------------------------------------------------------------MIRSTR1 stripeset MIRROR3 D300

MIRROR3 mirrorset DISK100 MIRSTR1

MIRROR4 mirrorset DISK110 MIRSTR1

SPARESET spareset DISK130

DISK220

DISK210

DISK200 DISK110

MIRROR4

DISK200

DISK210

Record the information in the following table. In the event of a controller failure, the information that you recorded here will assist you in reconstruction of the storagesets on your RAID Array 310.

Record the information in the following table:

D–8 EK–SMRAB–IG. B01

Appendix D. Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

Date__________________

Name Storageset Uses Used By

EK–SMRAB–IG. B01 D–9

Getting Started – RAID Array 310 V3.1 for HP–UX

Single-device units and devices that have not been added to units are not shown in this report. To display these devices, enter the following:

HSZ20> SHOW DEVICES

The controller responds with a display similar to that shown below:

Configuration Example 1:

Name Type Port Targ Lun Used by

-------------------------------------------------------------DISK100 disk 1 0 0 RAIDS1 DISK110 disk 1 1 0 RAIDS1 DISK120 disk 1 2 0 MIRROR1 DISK130 disk 1 3 0 STRIPE1 DISK200 disk 2 0 0 RAIDS1 DISK210 disk 2 1 0 MIRROR1 DISK220 disk 2 2 0 STRIPE1

Configuration Example 2:

Name Type Port Targ Lun Used by

---------------------------------------------------------DISK100 disk 1 0 0 MIRROR3 DISK110 disk 1 1 0 MIRROR4 DISK120 disk 1 2 0 D1 DISK130 disk 1 3 0 SPARESET DISK200 disk 2 0 0 MIRROR3 DISK210 disk 2 1 0 MIRROR4 DISK220 disk 2 2 0 D2

Record the information in the following table:

D–10 EK–SMRAB–IG. B01

Appendix D. Configuring STRIPEsets, MIRRORsets, and Striped MIRRORsets

Date__________________

Name Type Port Targ Lun Used By

EK–SMRAB–IG. B01 D–11

StorageWorks EK–SMRAB–IG Installation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
