STMicroelectronics STM8AF6268, STM8AF6226, STM8AF6223, STM8AF6266, STM8AF6166 User Manual

...

UM1915

User manual

STM8AF safety manual

Introduction

The microcontrollers of the STM8AF Series, featuring different memory densities, packages and peripherals, are designed for automotive applications.

This document describes how to use them in the context of a safety-related system (STM8A-SafeASIL functional safety package), specifying the user's responsibilities for installation and operation, in order to reach the targeted safety integrity level.

This manual applies to the following STM8AF products:

• the STM8AF62 line, which is the mainstay of the automotive STM8A 8-bit MCU: – low density devices with 8 Kbytes of Flash memory: STM8AF6223/26 – medium density devices with 16 to 32 Kbytes of Flash memory: STM8AF624x,

STM8AF6266/68, STM8AF612x/4x and STM8AF6166/68

– high density devices with 32 to 128 Kbytes of Flash memory:STM8AF6269/8x/Ax and

STM8AF6178/99/9A

• the STM8AF52 line: STM8AF automotive MCUs with CAN: – high density devices with 32 to 128 Kbytes of Flash memory: STM8AF52xx and

STM8AF51xx

System designers can avoid going into the details of the ISO26262 functional safety standard application to the STM8AF microcontrollers by following the indications reported in this manual.

This manual is written in compliance with ISO 26262. It also indicates how to use the STM8AF MCUs in the context of other functional safety standards such as IEC 61508.

The safety analysis summarized in this manual takes into account the variation in terms of memory size, number of internal peripherals and the different packages available among the different part numbers of STM8AF microcontrollers.

This manual has to be read along with the technical documentation on related part numbers available on www.st.com/stm8.

October 2019 UM1915 Rev 3 1/43

www.st.com

Contents UM1915

Contents

1 About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 Purpose and scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 Reference normative . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.4 Annexes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 STM8AF device development process . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1 STMicroelectronics standard development process . . . . . . . . . . . . . . . . . . 8

3 STM8AF safety architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.1.1 Definition of the SEooC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.2 STM8AF as a SEooC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3.3 Assumed safety requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.3.1 The target safety metrics (ASIL, SPFM, LFM and PMHF) . . . . . . . . . . . 11

3.3.2 The assumed target time intervals (FTTI and MPFDI) . . . . . . . . . . . . . . 12

3.4 Electrical specifications and environment limits . . . . . . . . . . . . . . . . . . . . 13

3.5 Systematic safety integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.6 Safety mechanisms/measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.6.1 STM8AF core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.6.2 Program Flash memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.6.3 Data EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.6.4 RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.6.5 Boot ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.6.6 Basic enhanced CAN (beCAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.6.7 LINUART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.6.8 USART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.6.9 I2C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.6.10 SPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.11 Analog to digital converter (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.6.12 Advanced control and general purpose timers (TIM 1 and TIM 2/3) . . . 22

3.6.13 Basic timer (TIM 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.6.14 GPIO - Ports A/B/C/D/E/F/G/H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

2/43 UM1915 Rev 3

UM1915 Contents

3.6.15 Address and Data bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

3.6.16 Supply voltage system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.6.17 Reset and clock control subsystems . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.6.18 Auto-wakeup timer (AWU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.6.19 Watchdogs (IWDG, WWDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.6.20 Debug/SWIM (single wire interface module) . . . . . . . . . . . . . . . . . . . . . 27

3.6.21 Interrupt controller (NVIC and EXTI) . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.6.22 Latent fault detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.6.23 Disable and periodic cross-check of unintentional activation

of unused peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.7 Assumption of use (AoU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

3.7.1 List of AoUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

4 Safety analysis results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.1 Hardware random failure analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.1.1 Safety analysis result customization . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4.1.2 General requirements for FFI (freedom from interferences ) . . . . . . . . . 34

4.2 Dependent failures analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.2.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

4.2.2 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

5 List of evidences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Appendix A Change impact analysis for other safety standards. . . . . . . . . . . . 37

A.1 IEC 61508 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

A.1.1 Architectural categories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

A.1.2 Safety metrics re-computation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

A.1.3 Work products. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

UM1915 Rev 3 3/43

List of tables UM1915

List of tables

Table 1. Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Table 2. List of STM8AF assumed requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Table 3. Target safety metric values at the item level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Table 4. List of safety mechanisms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 5. List of general requirements for FFI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Table 6. Some reference architectures for IEC 61508 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Table 7. Mapping between this document content and IEC 61508-2 Annex D requirements . . . . . 40

Table 8. IEC 61508 work product grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table 9. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4/43 UM1915 Rev 3

UM1915 List of figures

List of figures

Figure 1. Definition of the STM8AF as a SEooC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Figure 2. Relationship between assumptions and SEooC development . . . . . . . . . . . . . . . . . . . . . . 10

Figure 3. STM8AF FTTI allocation and cycle time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 4. Correlation matrix between SIL and ASIL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

UM1915 Rev 3 5/43

About this document UM1915

1 About this document

1.1 Purpose and scope

This document is addressed to system designers willing to evaluate the safety of their solutions. It describes how to use STM8AF microcontrollers in the context of a system, specifying the user responsibilities for installation and operation, to reach the desired safety integrity level.

1.2 Terms and abbreviations

safety-related

Acronym Definition

AoU Assumptions to use

ASIL Automotive safety integrity level

CCF Common cause failure

COTS Commercial off-the-shelf

CPU Central processing unit

CRC Cyclic redundancy check

DC Diagnostic coverage

DTI Diagnostic test interval

FIT Failure in time

FTTI Fault tolerant time interval

FMEA Failure mode effect analysis

FMEDA Failure mode effect diagnostic analysis

HFT Hardware fault tolerance

HW Hardware

INTC Interrupt controller

LFM Latent fault metric

MCU Microcontroller unit

MPF Multiple point failures

MPFDI Multiple point fault detection interval

NVIC Nested vector interrupt controller

PMHF Probabilistic metric for random hardware failures

QM Quality management

SFF Safe failure fraction

SIL Safety Integrity level

SEooC Safety element out of context

SPF Single point fault

SPFM Single point fault metric

SW Software

Table 1. Terms and abbreviations

6/43 UM1915 Rev 3

UM1915 About this document

1.3 Reference normative

This document is written in compliance with the ISO 26262 international standard for functional safety of electrical and/or electronic (E/E) systems within road vehicles.

The versions used as reference is:

• ISO 26262:2018 – Road Vehicles Functional Safety Standards

This safety manual follows the list of recommended contents in Annex A, clause A.3.10 of ISO 26262-10.

The other functional safety standard considered in this manual is:

• IEC 61508:1-7 © IEC:2010.

1.4 Annexes

[1] UM2138 FMEDA analysis for STM8AF Series MCUs

[2] UM2139 FMEDA handling for STM8AF Series MCUs

UM2138 is a collection of FMEDA snapshots. It is a static document reporting the safety metrics computed for different detail levels (at microcontroller level and for microcontroller basic functions) for a given combination of safety mechanisms, a given set of assumptions and for a given part number. If a FMEDA computation sheet is needed, contact your local STMicroelectronics sales representative to receive information on expected delivery dates for specific MCU target part numbers.

UM2139 provides clarifications, guidelines and examples on how to handle the FMEDA results for STM8AF MCUs.

UM1915 Rev 3 7/43

STM8AF device development process UM1915

2 STM8AF device development process

The development process of a microelectronic device used in safety critical applications must take into account the adequate management to reduce the probability of systematic faults introduced during the design phase.

ISO 26262-10 Annex A (“A.3.7: Example of techniques or measures to detect or avoid systematic failures during design of a microcontroller”) act as a guidance in tailoring the microcontroller standard design and manufacturer process to the compliance of ISO 26262 requirements. The checklist reported in the named Annex A (Tab l e A. 8 ) helps to related evidences of a given real process.

2.1 STMicroelectronics standard development process

STMicroelectronics (ST) serves four industry domains:

• Standard products.

• Automotive products: ST automotive products are AEC-Q100 compliant. They are

subject to specific stress testing and processing instructions in order to achieve the required quality levels and product stability.

• Automotive safety: a subset of the automotive domain. ST uses as a reference the ISO 26262 Road vehicles Functional safety standard. ST supports customer inquiries regarding product failure rates and FMEDA to support hardware system compliance to established safety goals. ST provides products that are safe in their intended use, working in cooperation with customers to understand the mission profile, adopt common methods and define countermeasures for residual risks.

• Medical products: ST complies with applicable regulations for medical products and applies due diligence in the development and validation of these products.

STMicroelectronics product development process, compliant with the ISO/TS 16949 standard, is a set of interrelated activities dedicated to transform customer specification and market or industry domain requirements into a semiconductor device and all its associated elements (package, module, sub-system, application, hardware, software and documentation), qualified respecting ST internal procedures and able to be manufactured using ST internal or subcontracted technologies.

collect all

8/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

3 STM8AF safety architecture

This section describes the safety architecture to implement when using STM8AF microcontrollers for automotive applications.

3.1 Introduction

The STM8AF microcontroller described in this document is a Safety element out of context (SEooC), that is, a safety element that can be used in different safety applications.

The aim of this section is to define the context of the analysis in terms of assumptions with respect to reference safety requirements as also assumptions with respect to the design external to that SEooC.

As a consequence of the SEooC approach, the goal is not to provide an exhaustive hazard and risk analysis of the system around the microcontroller, but rather to list the system-related information (such as the application-related assumptions for dangerousness factors, frequency of failures and diagnostic coverage already guaranteed by the application) that have been considered during the following steps of the analysis.

3.1.1 Definition of the SEooC

The automotive industry develops generic elements for different applications and for different customers. These generic elements can be developed concurrently and by different companies in different tiers of the supply chain, as a distributed development. Assumptions are made both on the requirements (including safety requirements) on the element at higher levels of design and also on the design external to the element.

In a safety context, these elements can be developed as a “Safety Element out of Context” (SEooC), as described in ISO 26262-10, Clause 9.

According to ISO 26262, a “safety element out of context (SEooC)” is a safety-related element that is not developed for a specific item, i.e. in the context of a particular vehicle. A SEooC can be a system, an array of systems, a subsystem, a software component or a hardware component.

This document considers the STM8AF as a SEooC to whom an ASIL capability is required, up to and including ASILB, i.e. it can be used in ASILA and ASILB

3.2 STM8AF as a SEooC

The STM8AF is a general purpose RISC microcontroller, suitable for embedded applications and, in particular, for safety related applications.

For a detailed description of the STM8AF functionality refer to the reference manuals, available on www.st.com.

In this document, the SEooC is identified as the STM8AF microcontroller (MCU), referenced as a functional block inserted in a system defined by Figure 1. The MCU acts as the processing unit of the system, i.e. acquiring field data from sensors, processing them according to the implemented algorithm, and taking decisions that bring to specific commands to external actuators. The MCU is connected directly or indirectly to and actuators through communication buses.

environments.

sensors

UM1915 Rev 3 9/43

STM8AF safety architecture UM1915

069

5HPRWH

FRQWUROOHU

5HPRWH

FRQWUROOHU

5HPRWH

FRQWUROOHU

5HPRWH

FRQWUROOHU

6HQVRU

$FWXDWRU

3URFHVVLQJHOHPHQW

6(RR&

670$)

069

$VVXPSWLRQV

$VVXPHGUHTXLUHPHQWV

$VVXPSWLRQVRQGHVLJQ

H[WHUQDOWR6(RR&

6(RR&UHTXLUHPHQWV

6(RR&GHVLJQ

Figure 1. Definition of the STM8AF as a SEooC

Other components, like the external HW components needed to guarantee either the functionality of the STM8AF (external memory, clock quartz) or its safety (e.g. the external watchdog, voltage supervisors) can be connected to the SEooC.

3.3 Assumed safety requirements

A SEooC is developed, according to ISO 2626-10 clause 9, on the basis of assumptions for its

intended functionality, use and context, including external interfaces (Figure 2).

Figure 2. Relationship between assumptions and SEooC development

The validity of the aforementioned assumptions is checked, in the context of the actual item, after the integration of the SEooC.

In this document it is assumed that the concept specification, the hazard and risk analysis, the overall safety requirement specification and the consequent allocation have determined the assumed safety requirements reported in Table 2.

10/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

Table 2. List of STM8AF assumed requirements

ID Assumed requirement

AR01 The SEooC is defined as the STM8AF playing the role of processing unit,

Failures in STM8AF HW part leading to wrong execution of the application

AR02

and/or wrong data computations shall be mitigated to fulfil the ASILB – single-point fault metric at the HW part level at least 90%

as in Figure 1.

program

capability, i.e.

– latent point fault metric at the HW part level at least 60%.

AR03 The STM8AF is assumed to be integrated in a product with a lifetime up to 10

In accordance with ISO 26262-.5, 6.4.8 – Note 1, it is assumed that the

AR04

(Multiple-point fault detection interval) is equal to or lower than the item “power-up to

years.

MPFDI

power-down” cycle (i.e. 1 hour).

AR05 Safety integrity level required for the STM8AF is ASILB.

AR06 It is assumed a FTTI budget allocated to the STM8AFof 250 msec

(1)

It is assumed that the STM8AF implements a safe state defined as one in which either:

AR07

– the application software running on the MCU is informed of the

reaction is possible

(2)

, or

– if the application software cannot be informed, the MCU reset is executed

AR08

1. FTTI value is used for reference only. The end user shall verify that the FTTI value of the final application is

2. The end user shall take into account that hardware random failures affecting the STM8AF can compromise

3. According to ISO 26262-1, the safe state is the operating mode of an item without unreasonable level of

4. The possibility for the SEooC to execute either ASIL, QM and non-safety-related functions together has

On the STM8AF SEooC is not executed together with ASIL, QM and/or non-safety-related software

compatible with the requirements in terms of execution of periodical software-based test (refer to

Section 3.6).

the MCU capability of operating properly (for example failure modes affecting the program counter prevent the correct execution of software).

risk. The ultimate definition of the safe state depends on the end user application

been excluded because not supported by dedicated hardware.

(4)

presence of a fault and a

(3)

3.3.1 The target safety metrics (ASIL, SPFM, LFM and PMHF)

According to AR05, the target for the safety functions is ASILB; therefore every consideration about absolute and relative safety metrics takes ASILB targets, as reported in

Tab le 3.

Single-point fault metric (SPFM) ≥ 90% ≥ 90% Relative

Latent-fault metric (LFM) ≥ 60% ≥ 60% Relative

Probabilistic metric for

Even if safety metrics are defined at item (i.e. at car) level for ISO 26262, the functional safety standard explicitly foresees the computation of those metrics at a lower level.

Table 3. Target safety metric values at the item level

Safety metric defined

Target value

(

system level)

random hardware failures (PMHF) 100 FIT 10 FIT Absolute

UM1915 Rev 3 11/43

(

Target value

SEooC level)

Metric

type

STM8AF safety architecture UM1915

6\VWHPOHYHO)77,

0&8GHWHFWLRQ ):UHDFWLRQ 6:UHDFWLRQ $FWXDWRUUHDFWLRQ

0LFURFRQWUROOHUGXW\ (QGXVHUGXW\ «

069

0LFURFRQWUROOHU)77, 7LPHIRUUHDFWLRQHJ6\VWHPUHVHW

7LPH

In this document any claim and computation in terms of safety metrics is done on the activity safety scope represented by the SEooC block diagram reported in Tabl e 1.

The budget of the PMHF given to the SEooC must be (if possible) lower than 10% of the overall PMHF budget of the safety goal, and therefore (for ASILB) the budget for the STM8AF is 10% * 100 FIT = 10 FIT.

3.3.2 The assumed target time intervals (FTTI and MPFDI)

As illustrated in ISO 26262-1:2001 - Figure 4 - Fault reaction time and fault tolerant time interval, a system must be able to detect faults and move to safe state before a fault can

become a system level hazard.

In ISO 26262-1, the fault tolerant time interval (FTTI) is defined as the time span in which a fault (or faults), can be present in a system before a hazardous event occurs.

Moreover, according to ISO 26262-1:2011, the multiple-point fault detection interval (MPFDI) is the time span to detect multiple-point fault before it can contribute to a multiple-point failure.

From a system point of view, the STM8AF MCU is a safety-related element, to which a portion of the FTTI system budget is assigned to a SEooC (in this case the STM8AF) strongly depends on the application.

Figure 3. STM8AF FTTI allocation and cycle time

associated. As shown in Figure 3, the portion of FTTI

In this document, according to ISO 26262-10, 9.2.3.3 d) it is assumed that any implemented safety mechanisms related to the STM8AF completes its functions in less than the assigned FTTI budget time reported in

This value must be considered as a reference, and can be changed by the MCU/system integrator according to its needs.

It is worth noting that, according to ISO 26262-5, 7.4.3.3, a single point fault must be detected within the FTTI budget allocated to the component.

In this document, in accordance with ISO 26262-.5:2011, 6.4.8 – Note 1, it is assumed that the MPFDI is equal to or lower than the item “power-up to power-down” cycle (i.e. one driving cycle), AR04.

12/43 UM1915 Rev 3

AR06.

UM1915 STM8AF safety architecture

3.4 Electrical specifications and environment limits

The user must not exceed the electrical specification and the environmental limits defined in the list below, as reported in STM8AF datasheets, to guarantee its own safety integrity:

• absolute maximum rating

• operating conditions.

Due to the large number of STM8AF products, the related user manuals/datasheets are not listed in this document; the user is responsible to carefully check the above reported limits in the technical documentation on the related part number available on www.st.com.

3.5 Systematic safety integrity

Due to known device limitations for STM8AF automotive MCUs, the user must follow the errata sheets available on www.st.com

to avoid the introduction of systematic failures.

3.6 Safety mechanisms/measures

This section lists all the safety mechanisms/measures (hardware, software and application level) considered in the safety analysis of the microcontrollers of the STM8AF Series.

According to ISO 26262-1, “…a safety mechanism is a technical solution implemented by

Electrical/Electronic (E/E) functions or elements, or by other technologies, to detect faults or control failures in order to achieve or maintain a safe state”.

It is expected that users are familiar with the STM8AF architecture, and that this document is used in conjunction with the related device datasheet, user manual and reference information. Therefore, in order to avoid any mistake and reduce the amount of information to be shown, no functional details are included in this document.

Note that the part numbers of the STM8AF Series represent different combinations of peripherals (for instance, some of them are not equipped with CAN peripheral). To reduce the number of documents and avoid information-less repetitions, the current safety manual addresses the overall possible peripherals available in the targeted part numbers. Users have to select which peripherals are really available on their meaningless recommendations accordingly.

The implementation guidelines reported in the following section are for reference only. Read the following definitions:

• end user: the final user of STM8AF, in charge of integrating the MCU in a real application (for example an electronic control board)

• application software: the actual software running on the STM8AF, used to implement the safety function.

3.6.1 STM8AF core

Periodical core self-test software - CPU_SM_0

Permanent faults affecting the CPU are addressed through a dedicated software test executing a sequence of instructions and data transfers.

The software test is built around well-known techniques already addressed by ISO 26262-5, D.2.3.1 (“Self-test by software: limited number of patterns (one channel)”).

devices, and discard the

The

UM1915 Rev 3 13/43

STM8AF safety architecture UM1915

processing unit (CPU) is tested for functional correctness by applying at least one pattern per instruction. The testing of the same class of instruction with multiple not-trivial patterns in order to involve each operand’s input and output bits, at least once equal to “0” e once equal to “1”, is high recommended. The accumulation by means of not-trivial computation (e.g. XOR) of the single instruction test result on the basis of the concept of signature is high recommended. The safety analysis of the CPU hardware has shown that a stress-test for the pipeline structure is high recommended.

The overall test software suite is assumed to be periodically executed with a time period compatible with the ISO 26262 requirements for the relationship between FTTI and the diagnostic test interval (DTI).

Control flow monitoring in application software - CPU_SM_1

A significant part of the failure distribution of STM8AFcore for permanent faults is related to failure modes directly related to program counter loss of control or hang-up. Due to their intrinsic nature, such failure modes are not addressed by a standard software test method based on the execution of sequences of instruction/data access and consequent checks. Therefore it is necessary to implement a run-time control of the application software flow, in order to monitor and detect deviation from the expected behavior. Linking this mechanism to watchdog firing assures that severe loss of control (or, in the worst case, a program counter hang-up) is detected within DTI.

This diagnostic measure also contributes to the transient fault detection affecting the program counter and branch execution subpart in STM8AFcore.

The guidelines for the implementation of the method are the following:

• The different internal states of the application software is well documented and described (the use of a dynamic state transition graph is encouraged).

• The monitoring of the correctness of each transition between different states of application software is implemented.

• The transition through all expected states during the normal application software program loop is checked.

• The function in charge of triggering the system watchdog is implemented in order constrain the triggering (preventing the watchdog reset) also to the correct execution of the above-described method for program flow monitoring.

the

The use of the window feature of the independent watchdog (IWDG) or an external one helps to implement a more robust control flow mechanism fed by a different clock source. In any case the safety metrics do not depend on the watchdog in use (the adoption of independent or external watchdog contributes to the mitigation of dependent failures, see

Section 4.2.2: Clock).

Double computation in application software - CPU_SM_2

A timing redundancy for safety-related computation is considered to detect transient faults affecting the STM8AFsubparts devoted to mathematical computations and data access.

14/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

The guidelines for the implementation of the method are the following:

• The requirement needs to be applied only to safety-relevant computation, that is those that can interfere with the system safety functions. Such computation needs to be therefore carefully identified in the original application software source code.

• Both mathematical operation and comparison are intended as computation.

• The redundant computation for comparison could be implemented according to the

following template: – Original code:

If (VarA > VarB) then { ( execute function) }

– Modified code:

copyVarA:=VarA; copyVarB:=VarB;

If (VarA > VarB) then {

If (copyVarA <= copyVarB) then { (signal_error);

break } ( execute function)

}

• The redundant computation is implemented by using copies of the original data for second computation, and by using an equivalent formula if possible.

• End users are responsible to carefully avoid that the optimization features of the used compiler removes the timing redundancy introduced according to this current condition of use.

Stack hardening for application software - CPU_SM_3

The stack hardening method is required to address faults affecting the CPU register bank. This method is based on source code modification, introducing information redundancy in register-passed information to the called functions.

The guidelines for the implementation of the method are the following:

• Pass also the redundant copy of the passed parameters values (possibly inverted) and execute a coherence check in the function.

• Pass also the redundant copy of the passed pointers and execute a coherence check in the function.

For the parameters not protected by redundancy it is recommended to implement defensive programming techniques (plausibility check of passed values). For example, enumerated fields are to be checked for consistency.

Independent watchdog - CPU_SM_4

Using an external watchdog for the control flow monitoring method (CPU_SM_1) contributes to further reduce potential common cause failures, because the external watchdog is clocked and supplied independently from the STM8AF.

3.6.2 Program Flash memory

Periodical software test for Flash memory - FLASH_SM_0

Permanent faults affecting the system Flash memory (memory cells and address decoder) are addressed through a dedicated software test that checks the memory cell

contents versus the expected value, using signature-based techniques. The use of CRC-based encryption for signature is encouraged.

UM1915 Rev 3 15/43

STM8AF safety architecture UM1915

Without information about the frequency of usage of different occupied Flash memory sections, in with a time period compatible with between FTTI and the diagnostic test

principle, all the ar ea used by t he Flash me mory is assumed to be tested

the ISO 26262 requirements for the relationship

interval (DTI).

Control flow monitoring in application software - FLASH_SM_1

Permanent and transient faults affecting the system Flash memory (that is the memory cells and address decoder) can interfere with the access operation by the CPU, leading to wrong data or instruction fetches. Such wrong data and operation, if able to heavily interfere with the expected flow of the application software, are detected by strong control flow mechanism linked to a system watchdog. For more detailed implementation guidelines for such technique refer to safety mechanism CPU_SM_1.

Note: The implementation of the CPU_SM_1 automatically involves the FLASH_SM_1

implementation.

3.6.3 Data EEPROM

Information redundancy - EEP_SM_0

To address permanent faults affecting the internal EEPROM bank it is required to implement information redundancy techniques. Possible techniques are:

• use redundant copies of safety relevant data and perform coherence checks before

use

• organize data in arrays and compute and check checksum field before use.

Due to their nature, data stored in EEPROM are typically managed directly by the end user application software, therefore it is reasonable to rely on methods implemented in the final software solution.

Software read-back after write operation - EEP_SM_1

To address missing writes on EEPROM cells, it is required that the application software executes a read-back of written data after an update of the EEPROM values. Missing writes are handled as a hardware fault.

3.6.4 RAM

Periodical software test for RAM - RAM_SM_0

To address permanent faults affecting RAM data cells and address decoder it is required to execute a periodical software test on the system RAM. The selection of the algorithm ensures the target coverage for both the RAM cells and the address decoder. user provides also evidences of the effectiveness of the coverage of the selected

Stack hardening for application software - RAM_SM_1

The stack hardening method is used to enhance the application software robustness to RAM faults affecting the address decoder. The method is based on source code modification, introducing information redundancy in the stack-passed information to the

16/43 UM1915 Rev 3

The end

method.

UM1915 STM8AF safety architecture

called functions. This method is relevant in case the combination between the final application software structure and the compiler settings requires a significant use of the stack for passing function parameters.

The guidelines for the implementation of the method are the following:

• Pass also the redundant copy of the passed parameters values (possibly inverted)

and execute a coherence check in the function.

• Pass also the redundant copy of the passed pointers and execute a coherence

check in the function.

• For parameters that are not protected by redundancy, implement defensive

programming techniques such as the plausibility check of the passed values (for example to check the consistency of enumerated fields).

Information redundancy for safety-related variables in application software RAM_SM_2

To address transient faults affecting RAM controller and RAM cells, it is required to implement information redundancy of the safety-related system variables stored in the RAM.

The guidelines for the implementation of this method are the following:

• The system variables that are safety-related (in the sense that a wrong value read

in the RAM affects the safety functions) are well-identified and documented.

• The arithmetic computation and/or decision based on such variables are/is

twice and the two final results are compared.

• Non-numeric variables uses enumerated-type constant values for coding,

trivial patterns (all 0x00 or all 0xFF); application software checks for value assumed by the variables, when used

• Numeric variables are grouped and protected by means of a checksum (for

instance, computed by XOR), updated each variable overwriting and checked at least once per FTTI.

executed

consistence the

avoiding

Note that the implementation of this safety method shows a partial overlap with an already planned method for STM8AFcore (CPU_SM_1); optimizations in implementing both methods are therefore possible (see the description of the CPU_SM_1).

3.6.5 Boot ROM

Control flow monitoring in application software - ROM_SM_0

The boot loader starts executing after reset. Permanent and transient faults affecting the boot ROM can leads to wrong execution of the application software at the end of the boot procedure. Such alteration is detected by a strong control flow mechanism linked system watchdog. For more detailed implementation guidelines o f this technique safety mechanism CPU_SM_1.

Note: The implementation of the CPU_SM_1 automatically involves the ROM_SM_0

implementation.

UM1915 Rev 3 17/43

to a

refer to

STM8AF safety architecture UM1915

3.6.6 Basic enhanced CAN (beCAN)

Periodical read-back of configuration registers - CAN_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of beCAN peripheral respect to its expected value that is previously stored in the RAM and adequately updated after each configuration change. It mainly addresses the transient faults affecting the configuration registers, detecting bit flips . The register test is executed at least once per DTI in order to be able to claim the related diagnostic coverage.

Protocol error signals - CAN_SM_1

The CAN protocol error counters, which are entirely managed by the module at hardware level despite being conceived to detect network-related abnormal conditions, are able to contribute to the detection of the faults leading to error messages generation.

Handling such error signals at application level of is a common technique in embedded applications.

Information redundancy techniques on messages, including end to end safing - CAN_SM_2

The CAN communications are protected by addressing both the permanent and transient faults with the redundant information technique that includes the end to end safing.

For the implementation of redundant information, it is possible to adopt a different approach:

• Multiple sending of the same message, with comparison of the received results.

• Addition by the sender of a checksum field to the message to be verified by the

receiver.

In case the checksum field approach is adopted, the selection of the algorithm for checksum computation ensures a similar protection against message corruption as that ensured by a full redundancy.

For end to end safing, additional measures are implemented:

• Additional field in payload allowing the unique identification of sender/receiver, and

coherence check by receiver side.

• Timing monitoring of the message exchange (for example check the message arrival

within the expected time window)

• Check of the message consistence using a message counter in the additional payload

field and checking the right sequence of messages on the receiver side.

The use of a safe communication protocol such as PROFIsafe is recommended for the correct implementation of this safety mechanism.

3.6.7 LINUART

Periodical read-back of configuration registers - LINUART_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of LINUART respect to their expected value (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the

18/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

configuration registers, detecting bit flips . The registers test is executed at least once per DTI.

Protocol error signal - LINUART_SM_1

The LIN protocol errors signals (if used) despite being conceived to detect physical layer related abnormal conditions, are able to contribute to the detection to faults leading to error messages generation. For instance, option parity bit in data byte frame, overrun error.

Handling such error signals at application level is a common technique in embedded applications.

Information redundancy techniques on messages - LINUART_SM_2

The redundant information technique is used to protect the LIN/UART communications by detecting both the permanent and transient faults. There are two different approaches to implement this technique:

• multiple sending of the same message, with comparison of the received results

• addition by the sender of a checksum field to the message to be verified by the

receiver.

In case the checksum field approach is adopted, the selection of the algorithm for checksum computation ensures a similar protection against message corruption as that ensured by a full redundancy. Theoretical demonstrations on coverage capability are admitted, the use of CRC coding is anyway suggested.

The above reported approaches are equivalent; an additional criterion for the selection of the approach is the availability of a quick hardware support on the MCU platform, and the evaluation of the computation capability of the external device exchanging data with STM8AF.

3.6.8 USART

Periodical read-back of configuration registers - UART_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of USART respect to their expected value (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Protocol error signals - UART_SM_1

The UART protocol errors signals (if used) are conceived to detect physical layer related abnormal conditions, and are able to contribute to the detection of faults leading to error messages generation (such as option parity bit in data byte frame, overrun error). Handling such error signals at application level is a common technique in embedded applications.

UM1915 Rev 3 19/43

STM8AF safety architecture UM1915

Information redundancy techniques on messages - UART_SM_2

The redundant information technique is used to protect the USART communications by detecting both the permanent and transient faults. There are two different approaches to implement this technique:

• multiple sending of the same message, with comparison of the received results

• addition by the sender of a checksum field to the message to be verified by the

The above-reported approaches are equivalent; an additional criterion for the selection of the approach is the availability of a quick hardware support on the MCU platform, and the evaluation of the computation capability of the external device exchanging data with STM8AF.

3.6.9 I2C

Periodical read-back of configuration registers - IIC_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of I2C respect to their expected value (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the configuration registers, detecting bit flips . The registers test is executed at least once per DTI.

receiver.

Protocol error signals - IIC_SM_1

The I2C protocol errors signals, despite being conceived to detect physical layer related abnormal conditions, are able to contribute to the detection of faults leading to error messages generation such as for instance the ACK assertion phase, and related checks.

Handling such error signals at application level is a common technique in embedded applications.

Information redundancy techniques on messages - IIC_SM_2

The redundant information technique is used to protect the I2C communications by detecting both the permanent and transient faults. There are two different approaches to implement this method:

• multiple sending of the same message, with comparison of the received results

• addition by the sender of a checksum field to the message to be verified by the

receiver.

20/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

The above-reported approaches are equivalent; an additional criterion for the selection is the evaluation of the computation capability of the external device exchanging data with STM8AF.

3.6.10 SPI

Periodical read-back of configuration registers - SPI_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of SPI respect to their expected values previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Protocol error signals - SPI_SM_1

The SPI protocol errors signals, despite being conceived to detect physical layer related abnormal conditions, are able to contribute to the detection to faults leading to error messages generation such as, for instance, FIFO overrun and Mode error flags.

Handling such error signals at application level is a common technique in embedded applications.

Information redundancy techniques on messages - SPI_SM_2

The redundant information technique is used to protect the SPI communications by detecting both the permanent and transient faults. There are two different approaches to implement this method:

• multiple sending of the same message, with comparison of the received results

• addition by the sender of a checksum field to the message to be verified by the

receiver.

The above-reported approaches are equivalent; an additional criterion for the selection is the evaluation of the computation capability of the external device exchanging data with STM8AF.

3.6.11 Analog to digital converter (ADC)

Periodical read-back of configuration registers - ADC_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of ADC respect to their expected values, previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

UM1915 Rev 3 21/43

STM8AF safety architecture UM1915

Multiple acquisitions by application software - ADC_SM_1

To address the transient faults that affect the ADC module, it is required to implement a timing information redundancy scheme that executes multiple acquisitions of the same signal. This recommendation is most probably satisfied by the end user application software. The usage of multiple acquisitions followed by average operations is a common technique in industrial applications where it is needed to survive with spurious EMI disturbs on sensor lines.

Range check by application software - ADC_SM_2

To address permanent faults affecting ADC module, and also to address failure modes affecting the analog section, it is required that the application software executes a range

/plausibility checks on the measures coming from ADC acquisitions. The guidelines for the implementation of the method are the following:

• The expected data range to be acquired is investigated and adequately

documented. Note that in a well-designed application it is unlikely that during normal operation an input signal has a value very close to or over the upper and below the lower rail limit (saturation in signal acquisition).

• If the application software is aware of the state of the system, this information has

used in the range check implementation. For example, if the ADC value is measurement of a current through a power load, reading an abnormal value instance a current flowing in opposite direction versus the load supply) may fault in the acquisition module.

• As the ADC module is shared between different possible external sources, the

combination of plausibility checks on the different signals acquired helps to cover the whole input range in a very efficient way.

the

(for

indicate a

to be

Note: The implementation of this safety mechanism is strongly application-dependent.

Periodical software test for ADC - ADC_SM_3

To address permanent faults affecting ADC module, and also to address failure modes affecting the analog section, it is required to execute a periodical test on the ADC acquisition section. The method is implemented by acquiring either the internal reference voltage or, alternatively, a reference voltage coming from the external (board) and connected to an input pin, and comparing to the expected value. This test is executed periodically at least once per DTI.

3.6.12 Advanced control and general purpose timers (TIM 1 and TIM 2/3)

As the advanced control and general purpose timers are equipped with different channels, each independent from the others, and possibly programmed to realize the safety mechanism is selected individually for each channel.

Periodical read-back of configuration registers –TIM_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of TIMER respect to their expected values ,previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

different features,

22/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

Dual channel redundancy for counting timers –TIM_SM_1

This method provides a high level of coverage for both permanent and transient faults on the addressed timers. The method is conceived to protect the timers with counting features, for example the timers dedicated to maintain a system time base and/or to generate a timed interrupt for the execution of service routines (like for instance general timing counters update/increase).

The guidelines for the implementation of the method are the following:

• In case of timer used as a time base, use one of the timers as time-base source in the

application software, and the other one just for check. In that case the check for the dual channel redundancy is done at application

• In case of interrupt generation usage, use the first timer as main interrupt source

the service routines, and use the second timer to activate a “checking routine” cross-checks the coherence between the timers.

level.

coherence

for

that

Dual channel redundancy for input capture timers - TIM_SM_2

This method, based on dual channel redundancy scheme, provides a high level of coverage for both the permanent and transient faults on the addressed timers. It is conceived to protect the timers used for external signal acquisition and measurement, like “input capture” and “encoder reading”. The implementation is easy as it simply requires connecting the external signals also to the redundant timer, and performs a coherence check on the measured data at application level. To reduce the potential effect of the common cause failure, it is suggested, for redundancy, to use a channel belonging to a different timer module and mapped to not-adjacent pins on the device package.

Loop-back scheme for PWM outputs –TIM_SM_3

This method uses a loop-back scheme to detect permanent and transient faults on the timer channels used for output waveform generations (output compare, PWM and one-pulse mode). It is implemented by connecting the output signal to a separate channel, either in the same or in another timer, to acquire the generated waveform characteristics.

The guidelines for the implementation of the method for the PWM signal are the following:

• Both frequency and duty cycle of PWM are measured and checked versus the

expected value.

• To reduce the potential effect of common cause failure, it is suggested to use for

loop-back check a channel belonging to a different timer module and mapped adjacent pins on the device package.

This measure can be replaced, under the end-user responsibility, by different loop-back schemes already in place in the final application and rated as equivalent. For example, if the PWM is used to drive an external power load, the measurement of the on-line current value can be used instead of the PWM frequency one.

3.6.13 Basic timer (TIM 4)

Periodical read-back of configuration registers - BTIM_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of TIMER respect to their expected values, previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the

to not-

the

UM1915 Rev 3 23/43

STM8AF safety architecture UM1915

configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Dual channel redundancy for counting timers - BTIM_SM_1

The guidelines for the implementation of the method are the following:

• In case of timer used as a time base, use one of the timers as time-base source in the

application software, and the other one just for check. In that case the check for the dual channel redundancy is done at application

• In case of interrupt generation usage, use the first timer as main interrupt source

the service routines, and use the second timer to activate a “checking routine” cross-checks the coherence between the timers.

3.6.14 GPIO - Ports A/B/C/D/E/F/G/H

Periodical read-back of configuration registers - GPIO_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of GPIO respect to their expected values, previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

level.

coherence

for

that

Dual channel redundancy for input GPIO lines - GPIO_SM_1

To address both permanent and transient faults on GPIO lines used as input, it is required to implement a dual channel redundancy scheme by connecting the external safety-relevant signal to two independent GPIO lines. To reduce the potential impact of common cause failure, it is suggested to use GPIO lines belonging to different I/O ports (for example PORT A and B) and mapped to not-adjacent pins on the device package.

Loop-back configuration for output GPIO lines - GPIO_SM_2

To address both permanent and transient faults on GPIO lines used as output, it is required to implement a loop-back scheme, connecting the output to a different GPIO line programmed as input and used to check the expected value on output port. To reduce the potential impact of common cause failure, it is suggested to use GPIO lines belonging to different I/O ports (for example PORT A and B) and mapped to not-adjacent pins on the device package.

3.6.15 Address and Data bus

Periodical software test for interconnections - BUS_SM_0

The intra-chip connection resources need to be periodically tested for permanent faults detection. Note that STM8AF MCUs have no hardware safety mechanism to protect these structures. The test executes a connectivity test of these shared resources, including the

24/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

testing of the arbitration mechanisms between peripherals. This method, based on the periodical execution of software-based tests is executed at least once per DTI.

Note that the implementation of this safety method is overlapped by already planned methods for the configuration register checks for the STM8AF peripherals (e.g. CAN_SM_0).

Implementation of all such methods is equivalent to the implementation of BUS_SM_0.

Information redundancy in intra-chip data exchanges - BUS_SM_1

Both permanent and transient faults affecting the intra-chip connection features are addressed by information redundancy techniques implemented on the messages exchanged inside the MCU.

Note that the implementation of this safety method is overlapped by already planned methods related to information redundancy for the STM8AF peripherals (e.g. CAN_SM_2).

Implementation of all such methods is equivalent to the implementation of BUS_SM_1.

3.6.16 Supply voltage system

Periodical read-back of configuration registers - VSUP_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of the Power control logic respect to their expected values, previously stored in RAM and adequately updated after each configuration change. It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Supply voltage monitoring - VSUP_SM_1

It is required to detect early the under- and over-voltage conditions that are potential sources of failure at MCU level. The power supply values close to the operating limits reported in device datasheet are considered at the same level as hardware faults and lead to similar recovery actions by the application software.

The usage of an external monitoring power supply device outside the MCU can ensure the protection against potential common cause failures.

Warning: To reduce the risk of an over-voltage condition, it is highly

recommended maximum ratings for voltage (see Section 3.4).

that end users respect the absolute

Independent watchdog - VSUP_SM_2

The independent watchdog is fed directly by VDD; therefore, major failures in the 1.8 V supply for digital logic (core/peripherals) do not affect its behavior but may lead to a violation of the IWDG window for the key value writing by the application software, leading to a system reset.

UM1915 Rev 3 25/43

STM8AF safety architecture UM1915

3.6.17 Reset and clock control subsystems

Periodical read-back of configuration registers - CLK_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of the Reset and Clock Control logic respect to their expected values (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Clock Security System (CSS) - CLK_SM_1

The Clock Security System (CSS) detects the loss of HSE and LSE clock activity and executes the corresponding recovery action, e.g. switch-off HSE and commute on the HSI. For this reason it is able to detect potential abnormal situations:

• loss of external clock,

• abnormal activation of HSE (or LSE) despite being disabled by design.

The CSS detection of abnormal condition is considered as equivalent to hardware faults and brings to similar recovery actions by the application software.

Independent watchdog - CLK_SM_2

The independent watchdog is fed by a dedicated oscillator; therefore, major failures on clock generation at system level does not affect its behavior but may lead to a violation of the IWDG window for the key value write by the application software, leading to a system reset. Note that the efficiency of this safety mechanism is strongly dependent on the correct window setting and handling for the IWDG. The refresh of the IWDG has to be implemented to bring alteration of the program flow able to bypass the time window limit.

3.6.18 Auto-wakeup timer (AWU)

The AWU is used to provide an internal wakeup time base that is used when the MCU goes into Active-halt power saving mode.

Periodical read-back of configuration registers - AWU _SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of the watchdogs respect to their expected values (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Software test for auto-wakeup timer at startup - AWU _SM_1

This safety mechanism ensures the right functionality of the auto-wakeup timer. At startup, the software test programs the auto-wakeup timer with the required time interval, stores a specific flag in the RAM and waits for the reset signal. After the wake-up, the software understands that the AWU has correctly triggered, and does not execute the procedure again. This method has to be applied only in case the implemented safety goal plans the use of the auto-wakeup feature.

26/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

3.6.19 Watchdogs (IWDG, WWDG)

Periodical read-back of configuration registers - WDG_SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, executes a periodical check of the configuration registers of the watchdogs respect to their expected values (previously stored in RAM and adequately updated after each configuration change). It mainly addresses transient faults affecting the configuration registers, detecting bit flips. The registers test is executed at least once per DTI.

Software test for watchdog at startup - WDG_SM_1

This safety mechanism ensures the right functionality of the internal watchdogs in use. At startup, the software test programs the watchdog with the required expiration timeout, stores a specific flag in the RAM and waits for the reset signal. After the watchdog reset, the software understands that the watchdog has correctly triggered, and does not execute the procedure again.

3.6.20 Debug/SWIM (single wire interface module)

Independent watchdog - DBG_SM_0

The debug unintentional activation due to hardware random fault results in a massive disturbance of the independent watchdog or alternately, the other system watchdog WWDG or an external one.

3.6.21 Interrupt controller (NVIC and EXTI)

Periodical read-back of configuration registers - INTC _SM_0

This diagnostic measure, typically referred to as “Read back periodic by software of configuration registers”, is implemented by executing a periodical check of the configuration registers of each used system peripheral respect to its expected value, previously stored in RAM and adequately updated after each configuration change. It mainly addresses the transient faults that affect the configuration registers, by detecting bit flips. The register test is executed at least once per DTI.

Expected and unexpected interrupt check - INTC_SM_1

According to ISO 26262-5 Table D.1 recommendations, a safety mechanism/measure for incorrect interrupt executions and for omission of or continuous interrupts must be implemented. The method of expected and unexpected interrupt check is implemented at application software level. It contributes to detect both permanent and transient fault for all the above-reported failure modes affecting interrupt handling.

The guidelines for the implementation of the method are the following:

• The list of the implemented interrupt for the MCU is well documented, reporting also

the expected frequency of each request when possible (for example the interrupts related to ADC conversion completion, therefore coming on a deterministic way).

• Individual counters are maintained for each served interrupt request, in order to detect

in a given time frame the cases of a) no interrupt at all b) too many interrupt requests (“babbling idiot” interrupt source). The control of the time frame duration must be

UM1915 Rev 3 27/43

STM8AF safety architecture UM1915

regulated according to the individual interrupt expected frequency.

• Interrupt vectors related to unused interrupt source point to a default handler that

reports, in case of triggering, a faulty condition (unexpected interrupt).

• In case an interrupt service routine is shared between different sources, a plausibility

check on the caller identity is implemented.

• Interrupt requests related to not-safety-relevant peripherals are handled with the same

method here described, despite their originator safety classification; in order to decrease the complexity of this method implementation, the use of polling instead of interrupt for not-safety-relevant peripherals is suggested.

3.6.22 Latent fault detection

ISO 26262 considers also a metric for “latent” faults. The latent fault is a multiple-point fault which presence is not detected by a safety mechanism nor perceived by the driver within the multiple-point fault detection interval. In practical words, the latent fault is a combination of a fault in a safety mechanism - that by itself does NOT cause the violation of the safety goal (function) - and a fault in the mission logic supervised by that safety mechanism.

The following reported methods mainly address latent fault for the planned safety mechanism at MCU level.

Independent Watchdog - LAT_SM_0

Each safety mechanism implemented as periodical software testing runs on the CPU. Possible faults in the safety mechanism are therefore faults in the “support” for the execution that is the CPU. The independent watchdog is considered here as safety mechanism addressing the program counter failures due to the CPU hardware random faults.

Periodical core self-test software - LAT_SM_1

As the major part of the safety mechanism described in this safety manual is implemented by software, the periodical core self-test software execution able to detect faults in the STM8 CPU acts as safety mechanism for latent faults. For implementation details refer to the description of CPU_SM_0 safety mechanism.

3.6.23 Disable and periodic cross-check of unintentional activation of unused

peripherals

This section reports the safety mechanism that addresses peripherals not used by the safety application, or not used at all.

Unused peripherals disable - FFI_SM_0

This method contributes to the reduction of the probability of cross-interferences caused by peripherals not used by the software application. It is implemented by end users, taking care of disabling by software (for instance during the system boot) each peripheral that is not used.

Periodical read-back of interference avoidance registers - FFI_SM_1

This method contributes to the reduction of the probability of cross-interferences between peripherals that can potentially conflict on the same output pins, including for instance unused peripherals (refer to FFI_SM_0). This diagnostic measure executes a periodical

28/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

check of the below described registers respect to their expected values (previously stored in RAM and adequately updated after each configuration change). The register test is executed at least once per DTI.

The configuration registers to be tested with this method are those related to clock disabling features for peripherals and those related to the enabling of alternate functions on

3.7 Assumption of use (AoU)

This section describes the Assumptions of use (AoU) of the STM8AF that the MCU/system integrator considers (together with the requirements listed in Tab le 2: List of STM8AF

assumed requirements) with respect to its intended use.

The AoUs are different from the HW safety requirements of STM8AF. The AoUs are requirements for the MCU/system integrator.

3.7.1 List of AoUs

Table 4 summarizes the AoUs to be fulfilled by users of the STM8AF MCUs.

The results shown in Section 4: Safety analysis results are valid under the condition that the AoU, described herein, and the assumed requirements listed in Tab le 2, are fulfilled by the STM8AF MCU/system integrator.

The following table lists the assumptions of use and for each of them shows the degree of recommendation using the typical ISO 26262 coding in order to keep the text consistent with the standard and to facilitate their interpretation by the user. For each AoU, the degree of recommendation to use the corresponding method depends on the ASIL and is categorized as follows:

• “++” indicates that the assumption is highly recommended for the identified ASIL

• “+” indicates that the assumption is recommended for the identified ASIL

• “o” indicates that the assumption has no recommendation for or against its usage

the identified ASIL.

I/O pins.

for

Table 4 provides a summary of the safety concept recommendations reported in Section 3.6.

The assumptions of use are reported in the form of safety mechanism (SM) requirements.

The “X” marker in the Perm and Trans columns of Table 4 indicates that the related safety mechanism is effective for such fault model.

STM8AF function

STM8 core

Diagnostic Description

CPU_SM_0 Periodical core self-test software ++ X -

CPU_SM_1

CPU_SM_2

CPU_SM_3

CPU_SM_4 Independent watchdog o X X

Table 4. List of safety mechanisms

ASIL

Perm Trans

Control flow monitoring in application software

Double computation in application

Stack hardening for a

UM1915 Rev 3 29/43

pplication software + X X

++ X X

++ - X

STM8AF safety architecture UM1915

Table 4. List of safety mechanisms (continued)

STM8AF function

Program

Flash memory

EEPROM

Data

RAM

Boot ROM ROM_SM_0

beCAN

LINUART

Diagnostic Description

FLASH_SM_0 Periodical software test for Flash memory ++ X -

FLASH_SM_1

FLASH_SM_3 Option byte write protection M - -

EEP_SM_0 Information redundancy ++ X -

EEP_SM_1

RAM_SM_0 Periodical software test for RAM ++ X -

RAM_SM_1

RAM_SM_2

CAN_SM_0

CAN_SM_1 Protocol error signals + X X

CAN_SM_2

LINUART_SM_0

LINUART_SM_1 Protocol error signals + X X

LINUART_SM_2

Control flow monitoring in application software

Software read-back after

Stack hardening for

Information redundancy for system variables in application software

Control flow monitoring in application software

Periodical read-back of configuration registers

Information redundancy techniques messages, including End to End safing

Periodical read-back of configuration registers

Information redundancy techniques messages

write operation + X X

application software + X X

ASIL

Perm Trans

+X X

++ X X

++ X -

++ X X

++ X -

++ X X

UART

I2C

SPI

UART_SM_0

UART_SM_1 Protocol error signals + X X

UART_SM_2

IIC_SM_0

IIC_SM_1 Protocol error signals + X X

IIC_SM_2

SPI_SM_0

SPI_SM_1 Protocol error signals + X X

SPI_SM_2

Periodical read-back of configuration registers

Information redundancy techniques messages

Periodical read-back of configuration registers

Information redundancy techniques messages

Periodical read-back of configuration registers

Information redundancy techniques messages

++ X X

30/43 UM1915 Rev 3

UM1915 STM8AF safety architecture

Table 4. List of safety mechanisms (continued)

STM8AF function

ADC

TIM1

and

TIM2/3

TIM4

GPIO

Address

and

Data bus

Supply voltage

system

Clock

and

Reset

WAURTC

WDG

and

IWDG

ASIL

Diagnostic Description

ADC_SM_0

ADC_SM_1

Periodical read-back of configuration registers

Multiple acquisition by application software

Perm Trans

++ X X

++ - X

ADC_SM_2 Range check by application software ++ X X

ADC_SM_3 Periodical software test for ADC + X -

TIM_SM_0

TIM_SM_1

TIM_SM_2

Periodical read-back of configuration registers

Dual channel redundancy for counting timers

Dual channel redundancy for input capture timers

++ X X

TIM_SM_3 Loop-back scheme for PWM outputs ++ X X

BTIM_SM_0

BTIM_SM_1

GPIO_SM_0

GPIO_SM_1

Periodical read-back of configuration registers

Dual channel redundancy for counting timers

Periodical read-back of configuration registers

Dual channel redundancy for input GPIO lines

++ X X

GPIO_SM_2 Loop-back scheme for output GPIO lines ++ X X

GPIO_SM_3 GPIO port configuration lock register + - -

BUS_SM_0

BUS_SM_1

VSUP_SM_0

Periodical software test interconnections

Information redundancy in intra-chip exchanges

Periodical read-back of configuration registers

for

data

++ X -

++ X X

VSUP_SM_1 Supply voltage monitoring ++ X -

VSUP_SM_2 Independe nt watchdog ++ X -

CLK_SM_0

Periodical read-back of configuration registers

++ X X

CLK_SM_1 CSS (Clock Security System) ++ X -

CLK_SM_2 Independent watchdog ++ X -

CLK_SM_3 Internal clock cross-measure + X -

WAU_SM_0

WAU_SM_1

WDG_SM_0

Periodical read-back of configuration registers

Software test for auto-wakeup timer at startup

Periodical read-back of configuration registers

++ X X

+X X

++ X X

WDG_SM_1 Software test for watchdog at startup o X -

UM1915 Rev 3 31/43

STM8AF safety architecture UM1915

Table 4. List of safety mechanisms (continued)

STM8AF function

Debug DBG_SM_0 Independent watchdog ++ X X

Interrupt

controller

Software-

Part

interference)

based safety

separation

(no

Diagnostic Description

INTC_SM_0

INTC_SM_1

LAT_SM_0 Inde pendent watchdog + X -

LAT_SM_1 Periodical core self-test software + X -

FFI_SM_0 Unused peripherals disable ++ - -

FFI_SM_1

Periodical read-back of configuration registers

Expected and unexpected interrupt check by application software

Periodical read-back of interference avoidance registers

ASIL

Perm Trans

++ X X

++ - -

The above-described safety mechanism/measures are implemented with different levels of abstraction, depending on their nature: the more a safety mechanism is implemented as application-independent, the wider is its possible use on a wide range of end-user applications.

32/43 UM1915 Rev 3

UM1915 Safety analysis results

4 Safety analysis results

This section reports the results of the safety analysis of the STM8AF MCU, according to ISO 26262 (in particular ISO 26262-10 Annex A).

ISO 26262-10 Annex A is a guideline about how to perform a safety analysis of a microcontroller according to ISO 26262.

Shortly, the ISO 26262 has three main objectives:

• To improve functional safety by reducing the HW random failures, i.e. failures that

can occur unpredictably during the lifetime of a hardware element and that follow a probability distribution. They are quantified using safety “metrics”, as described in

Section 3.3.1: The target safety metrics (ASIL, SPFM, LFM and PMHF).

• To improve functional safety by reducing or avoiding dependent failures, i.e.

whose probability of simultaneous or successive occurrence cannot be simply as the product of the unconditional probability of each failure. They common cause failures and cascading failures. They are analyzed in a way by means of checklists, as described in Section 4.2.

• To reduce or avoid the systematic failures, i.e. failures, related in a deterministic

way to a certain cause, that can only be eliminated by a change of the design or of the manufacturing process, operational procedures, documentation or other relevant factors.

As mentioned before, the target for the safety functions is ASILB; therefore every consideration about absolute and relative safety metrics takes ASILB targets.

It is worth to recap here that ASILB report as target limits 90% for SPF (overall system) and 100 FIT for PMHF (100 FIT is indeed the overall budget available for the for STM8AF the allocated budget is be lower).

system, therefore

expressed

include

qualitative

failures

4.1 Hardware random failure analysis

The analysis for random hardware failures of STM8AF devices reported in this safety manual is executed according to ISO 26262 and to the following steps.

The STM8AF has been divided into parts and sub-parts according to the procedure defined in ISO 26262-10. Then, for identified starting from the extended based on

Each failure mode has been analyzed in terms of its “end effect” at the STM8AF I/O level. Detailed results of the qualitative analysis are reported in [2].

About safety metrics, both relative (SPFM, LFM) and absolute (PMHF) have been computed. The results are not reported in this section but in [2].

In summary, with the adoptions of the safety mechanism and conditions of use reported in

Section 3.7: Assumption of use (AoU), it is possible for the STM8AF family devices to

achieve the ASILB target.

detailed analyses.

each part and sub-part, the failure modes have been

ones specified by ISO 26262-5, Annex D and then significantly

UM1915 Rev 3 33/43

Safety analysis results UM1915

4.1.1 Safety analysis result customization

The safety analysis executed for STM8AF devices and contained in this safety manual is considered to be safety relevant, that is able to interfere with the safety function, to all microcontroller parts, with no exclusion. This is in line with the conservative approach to be followed during the analysis of a general-purpose microcontroller, in order to be agnostic versus the final application. This means that no STM8AF module has been declared as “non safety-related”, and therefore all STM8AF modules are included in SPF computations.

In end-user applications, not all the STM8AF parts/modules are used for the implementation of the safety function. Requiring the implementation of the respective safety mechanism for those parts could result in overkill; as a consequence, a dedicated analysis has been done. According to this analysis, the end user can define the selected STM8AF parts as “non safety-related” under the following conditions:

• collect rationales and evidences that the parts play no role in safety function

implementation

• collect rationales and evidences that the parts do not interfere with the safety

function during normal operation

• fulfill the below-reported general condition for the mitigation of the intra-MCU

interferences (Table 5)

The end user is allowed for “non safety-related” parts to do the following:

• discard the part contribution from metrics computations in FMEDA

• not implement the related safety mechanisms listed in Ta b le 3 .

See [1] for more information.

4.1.2 General requirements for FFI (freedom from interferences )

A dedicated analysis has highlighted a list of general requirements to be followed by end users to be authorized to declare selected STM8AF parts as “not safety relevant”. The analysis considers two situations: the part is not used at all (disabled), or the part is a function that is not safety-related (for example a GPIO port driving a “power-on” LED on the electronic board), and considers the possible interferences due to random faults affecting not-safety-relevant parts.

The requirement for the end user is to implement the safety mechanism detailed in

Diagnostic despite any evaluation about their contribution to the safety metrics

computations. Those safety mechanisms are reported in Table 5.

Diagnostic Description

INTC_SM_0 Periodical read-back of configuration registers

INTC_SM_1 Expected and unexpected interrupt check by application software

FFI_SM_0 Unused peripheral disable

FFI_SM_1 Periodical read-back of interference avoidance registers

BUS_SM_0 Periodical software test for interconnections

GPIO_SM_1 Dual channel redundancy for input GPIO lines

Table 5. List of general requirements for FFI

used for signaling hardware

GPIO_SM_2 Loop-back configuration for output GPIO lines

34/43 UM1915 Rev 3

UM1915 Safety analysis results

AR08 is a consequence of the performed FFI analysis.

4.2 Dependent failures analysis

The analysis of dependent failures is important for microcontrollers. The main sub-classes of dependent failures are the Common Cause Failures (CCF).

According to ISO 26262 they need to be addressed on a qualitative basis (ISO 262629:2011, 7.4.1 Note3) but an evaluation can be supported by appropriate checklists.

Measures for the resolution of CCF need to include the measures for preventing their root causes, or for controlling their effects, or for reducing the coupling factors. The ISO 2626210:2011, Annex A includes a paragraph dedicated to initiators and measures for dependent failures. The ISO 26262-9:2011, 7.4.4 Note1 says that IEC 61508 provides information that can be used as a basis to establish such checklists. Anyway, as there are no on-chip redundancies on STM8AF devices, the CCF quantification through method is not required.

The STM8AF device architecture and structure are potential sources of dependent failures. These are analyzed in the following sections. The referred safety mechanisms are described in detail in Section 3.6: Safety mechanisms/measures.

4.2.1 Power supply

Power supply is a potential source of dependent failures, because any alteration can affect many parts, leading to not-independent failures. The following address and mitigate those dependent failures:

• VSUP_SM_1: detection of abnormal value of supply voltage;

• VSUP_SM_2: the independent watchdog has a different supply source from the digital

core of the MCU, and this diversity helps to mitigate dependent failures related to the main supply alterations.

BetaIC computation

safety mechanisms

The adoption of such safety mechanisms is therefore strongly recommended despite their minor contribution to the safety metrics to reach the required safety integrity level. Refer to

Section 3.6.16: Supply voltage system for the detailed safety mechanism descriptions.

4.2.2 Clock

System clocks are a potential source of dependent failures, because alterations in the clock characteristics (frequency, jitter) can affect many parts, leading to not-independent failures. The following safety mechanisms address and mitigate those dependent failures:

• CLK_SM_1: the clock security system is able to detect hard alterations (stop) of system clock and activate the adequate recovery actions.

• CLK_SM_2: the independent watchdog has a dedicated clock source. The frequency alteration of the system clock leads to the watchdog window violations by the triggering routine on the application software, leading to the MCU reset by watchdog.

The adoption of such safety mechanism is strongly recommended despite their minor contribution to the safety metrics to reach the required safety integrity level. The use of system watchdog (WWDG) increases the overall capability to keep the

Refer to Section 3.6.17: Reset and clock control subsystems for detailed safety mechanisms description.

flow under control.

UM1915 Rev 3 35/43

List of evidences UM1915

5 List of evidences

The Safety case stores all the information related to the safety analysis performed to derive the results and conclusions reported in this safety manual.

These contents are not public, but can be made available for possible competent bodies audit and inspections.

36/43 UM1915 Rev 3

UM1915 Change impact analysis for other safety standards

Appendix A

Change impact analysis for other safety standards

The safety analysis reported in this user manual is carried out according to ISO 26262 safety norm. In this appendix a change impact analysis with respect to different safety standard is performed. The following topics are considered for each addressed safety norm:

• Differences in the suggested hardware architecture (architectural categories), and how to map what is foreseen in the new safety norm on the standard safety architectures of ISO 26262.

• Differences in the safety integrity level definitions and metrics computation and how to recompute and judge the safety performances of STM8AF according to the new standard.

• Work products required by the new safety norms, and how to remap or rework if needed existing ones resulting as output of the ISO 26262 compliance activity.

The safety standard examined within this change impact analysis is the following:

• IEC 61508:1-7 – ed. 2 ©IEC: 2010: Functional safety of electrical/electronic/programmable electronic safety-related systems.

A.1 IEC 61508

The IEC 61508 is the international norm for functional safety of electrical/electronic/programmable electronic (E/E/PE) safety-related systems.

methods,

devices

The ISO 26262 standard is derived from the IEC 61508 standard.

As ISO 26262, the IEC 61508 standard defines four safety integrity levels (SILs), based on the assessment of the hazard and risk analysis, with SIL1 being the lowest and SIL4 being the highest.

Despite automotive level of safety integrity (ASIL) defined in ISO 26262 (with a scale from A, the lowest level, to D, the highest level), comes from its parent standard SIL definition, there is no direct correlation between IEC 61508 and ISO 26262 ASIL levels as the ASIL in ISO 26262 is not stated in probabilistic terms while the SIL in IEC 61508 it is.

A correlation matrix between SIL and ASIL values has been empirically identified by TÜV SÜD and is illustrated in Figure 4.

UM1915 Rev 3 37/43

Change impact analysis for other safety standards UM1915

069

,(&

6DIHW\,QWHJULW\/HYHO

6,/









,62

$XWRPRWLYH6DIHW\,QWHJULW\/HYHO

$6,/

40 

Figure 4. Correlation matrix between SIL and ASIL

In the IEC 61508 scope, end-users can rely on SIL decomposition to define system architectures where the highest SIL requirements are fulfilled by using lower SILs redundant sub systems but respecting the requirements in part 2 §7.4.4.2.4. Following the rules, an SIL3 safety goal can be decomposed leading to an item made of two SIL2 independent elements. Thus, end-users can positively match SEooC assumptions in the form of STM8AF AoU (refer to Section 3.7: Assumption of use (AoU)). Then the safety requirements of the system under development can integrate the STM8AF MCU together with the related safety mechanisms defined in this manual, in items performing up to SIL3 safety functions.

A.1.1 Architectural categories

IEC 61508-6, Annex B requires representing a safety system by means of subsystem block diagram and representing each subsystem as one or more 1oo1, 1oo2, 2oo2, 1oo2D, 1oo3 or 2oo3 voted groups.

In principle, the safety architectures targeted in this document can be mapped to “1oo1” or “1oo1d” if HFT = 0 is selected, or “1oo2” or “1oo2d if HFT = 1 if

Architecture

1oo1 0

Hardware

tolerance (HFT)

Table 6. Some reference architectures for IEC 61508

fault

Architecture of a single set of components/ component having tolerance.

Failure of a unit can lead to a loss of the safety function.

Description

selected (see Ta bl e 6).

no hardware fault

1oo1d 0

1oo2 1

38/43 UM1915 Rev 3

Architecture of a single set of components/ component with a section, having no hardware fault tolerance.

Failure of a unit can lead to a loss of the safety function.

Architecture of two set of components/ component connected having a hardware fault tolerance of 1.

Failure of a unit does not lead to a loss of the safety function.

diagnostic

in parallel,

UM1915 Change impact analysis for other safety standards

Table 6. Some reference architectures for IEC 61508 (continued)

Architecture

1oo2d 1

2oo2 0

tolerance (HFT)

Hardware

fault

Architecture of two set of components / component connected a diagnostic section, having a hardware fault tolerance of 1.

Failure of a unit does not lead to a loss of the safety function.

Architecture of two set of components/ component connected having no hardware fault tolerance.

In 2oo2 the diagnostic section is optional.

Even if the ISO 26262 does not define any reference architecture, the description of the SEooC made in this document (Section 3.2: STM8AF as a SEooC) and its representation by means of the block diagram represented in Figure 1, allow mapping the SEooC to the 1oo1 architecture, including the STM8AF microcontroller as compliant item.

The reference block diagram of such architecture is the same represented in Figure 1, simply replacing the word “SEooC” with “Compliant item”.

If a mapping to a different architecture (1oo2, 1oo2d or 2oo2 architecture) is required, the user has to make reference to the part 6 of the IEC 61508 (IEC 61508-8).

A.1.2 Safety metrics re-computation

Hardware metrics in IEC 61508 standard have been defined with a slightly different perspective with respect to the ISO 26262.

Description

in parallel with

in parallel,

IEC 61508 is mainly focused on the capability of identification of the safe failure fraction (SFF), defined as the percentages of failures that are safe or detected and so do not lead to the violation of a safety goal. The mathematic definition for SFF is identical to the one for SPF in ISO 26262.

Latent faults are Not Applicable, as IEC 61508 does not define this metric.

Considering the metrics computation, the main differences between IEC 61508 and ISO 26262 are related to how the safe faults are computed and how the failure rate of diagnostic is computed with the mission.

The differences in failure rates related to hardware diagnostics are assumed to be negligible; hardware-native safety failures in STM8AF are very few, and with very little weight in terms of gate count. Therefore, the safety analysis already performed for SPF target can be reused for the SFF targets in IEC.

For such kind of Commercial Off-the-Shelf (COTS) microcontroller, the natural target in IEC scenario is 1oo1 SIL 2 (90% is the SFF target for permanent and transient). As these are the same targets for ASILB case, one can assume that the same set of conditions of use/safety mechanisms apply.

Metrics computations are detailed in [2].

UM1915 Rev 3 39/43

Change impact analysis for other safety standards UM1915

A.1.3 Work products

Tab le 7, mapping this document content with respect to the requirements listed in the IEC

61508-2 Annex D, acts as a checklist in guidance in providing the evidences of the compliance of the IEC 61508 requirements.

Table 7. Mapping between this document content and IEC 61508-2 Annex D requirements

D2.1 a) a functional specification of the functions capable of

D2.1 b) identification of the hardware and/or software the compliant item

IEC 61508 requirement (part 2 annex D) Reference

being performed

configuration of

Section 3: STM8AF safety architecture

Section 3.2: STM8AF as a SEooC

D2.1 c) constraints on the use of the compliant item and/or which analysis of the behavior or failure rates

D2.2 a) the failure modes of the compliant item due to random failures, that result in a failure of the function and that diagnostics internal to the compliant item;

D2.2 b) for every failure mode in a), an estimated failure rate;

D2.2 c) the failure modes of the compliant item due to random failures, that result in a failure of the function and that are detected by diagnostics internal to the compliant item;

D2.2 d) the failure modes of the diagnostics, internal to the compliant item due to random hardware failures, that result in a failure of the diagnostics to detect failures of the function;

D2.2 e) for every failure mode in c) and d), the estimated failure

D2.2 f) for every failure mode in c) that is detected by the compliant item, the diagnostic test interval;

D2.2 g) for every failure mode in c) the outputs of the compliant the internal diagnostics;

D2.2 h) any periodic proof test and/or maintenance

D2.2 i) for those failure modes, in respect of a specified capable of being detected by external diagnostics, sufficient information shall be provided to facilitate

D2.2 j) the hardware fault tolerance;

D2.2 k) the classification as type A or type B of that part of the that provides the function (see 7.4.4.1.2 and

the development of an external diagnostics capability.

of the item are based

are not detected by

7.4.4.1.3);

assumptions on

hardware

rate;

diagnostics internal to

item initiated by

requirements;

function, that are

compliant item

Section 3.2: STM8AF as a SEooC

Section 3.7: Assumption of use (AoU)

Section 3.3: Assumed safety requirements

Section 3.2: STM8AF as a SEooC

Section 3.7: Assumption of use (AoU)

Section 3: STM8AF safety architecture

Table 8 lists the work products required by the IEC 61508 standard and their mapping with

the work products from ISO 26262 compliance activity:

40/43 UM1915 Rev 3

UM1915 Change impact analysis for other safety standards

Table 8. IEC 61508 work product grid

IEC 61508 ISO 26262

Information to be provided

Design

requirements

specification

Design

requirements specification relating to safety functions

Design

requirements specification relating to safety

IEC

61508-2

7.2.2

7.2.3.2

7.2.3.3

Reference

Technical safety

requirements specification

Part 4

Clause

6.5.1 Safety manual

integrity

Safety validation planning 7.3.2 Validation plan 6.5.3

E/E/PE system design and development

Integration 7.5.2

7.4.2 to

7.4.11

System design

Item

integration and testing

plan Integration testing

specification(s) Integration

7.5.1 to

7.5.4

8.5.1 to

8.5.3

testing report(s)

E/E/PE system installation, commissioning, operation and

7.6.2 - -

maintenance procedures

E/E/PE system safety validation 7.7.2 Validation report 9.5.2

Document

End user

responsibility

E/E/PE system modification 7.8.2 - -

E/E/PE system verification 7.9.2 System

Functional safety assessment 8

verification report 6.5.2

Functional safety

assessment report

10.5.1

UM1915 Rev 3 41/43

Revision history UM1915

Revision history

Date Revision Changes

07-Jul-2015 1 Initial version.

18-May-2018 2

01-Oct-2019 3

Table 9. Document revision history

Updated Introduction, Section 1.3: Reference normative, Section 1.4:

Annexes, Section 3.4: Electrical specifications and environment limits, Section 3.6: Safety mechanisms/measures, Section 4: Safety analysis results, Section 4.1: Hardware random failure analysis, Section 4.1.1: Safety analysis result customization, Section 4.1.2: General requirements for FFI (freedom from interferences ), Section 4.2: Dependent failures analysis, Section 5: List of evidences, Appendix A: Change impact analysis for other safety standards and its subsections.

Updated Table 2: List of STM8AF assumed requirements, Table 4:

List of safety mechanisms, Table 6: Some reference architectures for IEC 61508 and Table 8: IEC 61508 work product grid.

Updated Figure 1: Definition of the STM8AF as a SEooC, Figure 2:

Relationship between assumptions and SEooC development, Figure 3: STM8AF FTTI allocation and cycle time and Figure 4: Correlation matrix between SIL and ASIL.

Removed former Section 2.2: YOGITECH fRMethodology process,

Appendix A: Overview of fRMethodology, B.1: IEC 60730-1:2010, B.2: Architectural categories, B.3: Safety metrics re-computation

and B.4: Work products. Minor text edits across the whole document.

Updated functional safety documentation framework. Updated Section 1.3: Reference normative. Minor text edits across the whole document.

42/43 UM1915 Rev 3

UM1915

IMPORTANT NOTICE – PLEASE READ CAREFULLY

STMicroelectronics International NV and its affiliates (“ST”) reserve the right to make changes corrections, enhancements, modifications, and improvements to ST products and/or to this document any time without notice.

This document is provided solely for the purpose of obtaining general information relating to an ST product. Accordingly, you hereby agree to make use of this document solely for the purpose of obtaining general information relating to the ST product. You further acknowledge and agree that this document may not be used in or in connection with any legal or administrative proceeding in any court, arbitration, agency, commission or other tribunal or in connection with any action, cause of action, litigation, claim, allegation, demand or dispute of any kind. You further acknowledge and agree that this document shall not be construed as an admission, acknowledgment or evidence of any kind, including, without limitation, as to the liability, fault or responsibility whatsoever of ST or any of its affiliates, or as to the accuracy or validity of the information contained herein, or concerning any alleged product issue, failure, or defect. ST does not promise that this document is accurate or error free and specifically disclaims all warranties, express or implied, as to the accuracy of the information contained herein. Accordingly, you agree that in no event will ST or its affiliates be liable to you for any direct, indirect, consequential, exemplary, incidental, punitive, or other damages, including lost profits, arising from or relating to your reliance upon or use of this document.

Purchasers should obtain the latest relevant information on ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgment, including, without limitation, the warranty provisions thereunder.

In that respect please note that ST products are not designed for use in some specific applications or environments described in above mentioned terms and conditions.

Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of purchasers’ products.

Information furnished is believed to be accurate and reliable. However, ST assumes no responsibility for the consequences of use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license, express or implied, to any intellectual property right is granted by ST herein.

Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.

ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks.All other product or service names are the property of their respective owners.

Information in this document supersedes and replaces information previously supplied in any prior versions of this document.

UM1915 Rev 3 43/43

STMicroelectronics STM8AF6268, STM8AF6226, STM8AF6223, STM8AF6266, STM8AF6166 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 About this document

1.1 Purpose and scope

1.2 Terms and abbreviations

Table 1. Terms and abbreviations

1.3 Reference normative

1.4 Annexes

2 STM8AF device development process

2.1 STMicroelectronics standard development process

3 STM8AF safety architecture

3.1 Introduction

3.1.1 Definition of the SEooC

3.2 STM8AF as a SEooC

Figure 1. Definition of the STM8AF as a SEooC

3.3 Assumed safety requirements

Figure 2. Relationship between assumptions and SEooC development

Table 2. List of STM8AF assumed requirements

3.3.1 The target safety metrics (ASIL, SPFM, LFM and PMHF)

Table 3. Target safety metric values at the item level

3.3.2 The assumed target time intervals (FTTI and MPFDI)

Figure 3. STM8AF FTTI allocation and cycle time

3.4 Electrical specifications and environment limits

3.5 Systematic safety integrity

3.6 Safety mechanisms/measures

3.6.1 STM8AF core

3.6.2 Program Flash memory

3.6.3 Data EEPROM

3.6.4 RAM

3.6.5 Boot ROM

3.6.6 Basic enhanced CAN (beCAN)

3.6.7 LINUART

3.6.8 USART

3.6.9 I2C

3.6.10 SPI

3.6.11 Analog to digital converter (ADC)

3.6.12 Advanced control and general purpose timers (TIM 1 and TIM 2/3)

3.6.13 Basic timer (TIM 4)

3.6.14 GPIO - Ports A/B/C/D/E/F/G/H

3.6.15 Address and Data bus

3.6.16 Supply voltage system

3.6.17 Reset and clock control subsystems

3.6.18 Auto-wakeup timer (AWU)

3.6.19 Watchdogs (IWDG, WWDG)

3.6.20 Debug/SWIM (single wire interface module)

3.6.21 Interrupt controller (NVIC and EXTI)

3.6.22 Latent fault detection

3.7 Assumption of use (AoU)

3.7.1 List of AoUs

Table 4. List of safety mechanisms

4 Safety analysis results

4.1 Hardware random failure analysis

4.1.1 Safety analysis result customization

4.1.2 General requirements for FFI (freedom from interferences )

Table 5. List of general requirements for FFI

4.2 Dependent failures analysis

4.2.1 Power supply

4.2.2 Clock

5 List of evidences

A.1 IEC 61508

Figure 4. Correlation matrix between SIL and ASIL

A.1.1 Architectural categories

Table 6. Some reference architectures for IEC 61508

A.1.2 Safety metrics re-computation

A.1.3 Work products

Table 7. Mapping between this document content and IEC 61508-2 Annex D requirements

Table 8. IEC 61508 work product grid

Revision history

Table 9. Document revision history
