STMicroelectronics STM32WLE5C8, STM32WLE5CB, STM32WLE5CC, STM32WLE5J8, STM32WLE5JB Datasheet

STM32WLE5xx STM32WLE4xx

Errata sheet

STM32WLE5xx, STM32WLE4xx device errata

Applicability

This document applies to the part numbers of STM32WLE5xx, STM32WLE4xx devices and the device variants as stated in this
page.

It gives a summary and a description of the device errata, with respect to the device datasheet and reference manual RM0461.

Deviation of the real device behavior from the intended device behavior is considered to be a device limitation. Deviation of the
description in the reference manual or the datasheet from the intended device behavior is considered to be a documentation
erratum. The term “errata” applies both to limitations and documentation errata.

Table 1. Device summary

Reference Part numbers

STM32WLE5xx

STM32WLE4xx

STM32WLE5C8, STM32WLE5CB, STM32WLE5CC, STM32WLE5J8, STM32WLE5JB, STM32WLE5JC,
STM32WLE5U8, STM32WLE5UB, STM32WLE5UC

STM32WLE4C8, STM32WLE4CB, STM32WLE4CC, STM32WLE4J8, STM32WLE4JB, STM32WLE4JC,
STM32WLE4U8, STM32WLE4UB, STM32WLE4UC

Table 2. Device variants

Reference

STM32WLE5xx, STM32WLE4xx

1. Refer to the device datasheet for how to identify this code on different types of package.

2. REV_ID[15:0] bitfield of DBGMCU_IDCODER register.

Device marking

Z 0x1001

Y 0x1002

Silicon revision codes

(1)

REV_ID

(2)

ES0506 - Rev 2 - April 2021

For further information contact your local STMicroelectronics sales office.

www.st.com

1 Summary of device errata

The following table gives a quick reference to the STM32WLE5xx, STM32WLE4xx device limitations and their
status:

A = workaround available

N = no workaround available

P = partial workaround available

Applicability of a workaround may depend on specific conditions of target application. Adoption of a workaround
may cause restrictions to target application. Workaround for a limitation is deemed partial if it only reduces the
rate of occurrence and/or consequences of the limitation, or if it is fully effective for only a subset of instances on
the device or in only a subset of operating modes, of the function concerned.

Table 3. Summary of device limitations

Function Section Limitation

2.1.1 Interrupted loads to SP can cause erroneous behavior

Core

System

TIM

LPTIM

RTC and TAMP

2.1.2

2.2.1 Wrong DMAMUX synchronization and trigger input connections to EXTI A -

2.2.2

2.2.3 Option byte loading failure at high MSI system clock frequency A -

2.2.4

2.2.5

2.2.6 Voltage drop on the 1.2 V regulated supply when switching MSI to 48 MHz A A

2.2.7 Sensitivity affected by HSE activation in high bandwidth channel A -

2.2.8 Sensitivity degradation in LNA boosted mode A A

2.2.9 SysTick trigger in debug emulation generates HardFault A A

2.2.10 Debug HALT command in debug emulation generates HardFault A -

2.2.11 Potential deadlock condition on wakeup from a lower-power mode A -

2.2.12 JTAG cannot be used without the JTAG NRST pin N -

2.2.13 Flash PCROP is not operating properly N -

2.2.14 TX spurs around carrier at a multiple of HSE clock frequency A A

2.3.1

2.3.2 Consecutive compare event missed in specific conditions N N

2.3.3 Output compare clear not working with external counter reset P P

2.4.1 Device may remain stuck in LPTIM interrupt when entering Stop mode A A

2.4.2

2.4.3 Device may remain stuck in LPTIM interrupt when clearing event flag P P

2.5.1 Alarm flag may be repeatedly set when the core is stopped in debug N N

Store immediate overlapping exception return operation might vector to
incorrect interrupt

Overwriting with all zeros a Flash memory location previously
programmed with all ones fails

A system reset occurs when nRST_SHDW is set and nRST_STDBY is
cleared and Shutdown mode is entered

FLASH_ECCR corrupted upon reset or power-down occurring during
Flash memory program or erase operation

One-pulse mode trigger not detected in master-slave reset + trigger
configuration

ARRM and CMPM flags are not set when APB clock is slower than kernel
clock

STM32WLE5xx STM32WLE4xx

Summary of device errata

Status

Rev.ZRev.

Y

A A

A A

N N

A -

A A

P P

P P

ES0506 - Rev 2

page 2/19

Function Section Limitation

A tamper event fails to trigger timestamp or timestamp overflow events
during a few cycles after clearing TSF

Wrong data sampling when data setup time (tSU;DAT) is shorter than one
I2C kernel clock period

RTC and TAMP

I2C

USART

2.5.2

2.5.3 REFCKON write protection associated to INIT KEY instead of CAL KEY A A

2.5.4 Tamper flag not set on LSE failure detection N N

2.5.5 Binary mode: SSR is not reloaded with 0xFFFF FFFF when SSCLR = 1 A A

2.6.1

2.6.2 Spurious bus error detection in master mode A A

2.6.3 OVR flag not set in underrun condition N N

2.6.4 Transmission stalled after first byte transfer A A

2.7.1 Anticipated end-of-transmission signaling in SPI slave mode A A

2.7.2 Data corruption due to noisy receive line N N

2.7.3 DMA stream locked when transferring data to/from USART A A

STM32WLE5xx STM32WLE4xx

Summary of device errata

Status

Rev.ZRev.

Y

N N

P P

ES0506 - Rev 2

page 3/19

STM32WLE5xx STM32WLE4xx

Description of device errata

2 Description of device errata

The following sections describe limitations of the applicable devices with Arm® core and provide workarounds if
available. They are grouped by device functions.

Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

2.1 Core

Reference manual and errata notice for the Arm® Cortex®-M4 FPU core revision r0p1 is available from http://
infocenter.arm.com.

2.1.1 Interrupted loads to SP can cause erroneous behavior

This limitation is registered under Arm ID number 752770 and classified into “Category B”. Its impact to the device
is minor.

Description

If an interrupt occurs during the data-phase of a single word load to the stack-pointer (SP/R13), erroneous
behavior can occur. In all cases, returning from the interrupt will result in the load instruction being executed an
additional time. For all instructions performing an update to the base register, the base register will be erroneously
updated on each execution, resulting in the stack-pointer being loaded from an incorrect memory location.

The affected instructions that can result in the load transaction being repeated are:

• LDR SP, [Rn],#imm

• LDR SP, [Rn,#imm]!

• LDR SP, [Rn,#imm]

• LDR SP, [Rn]

• LDR SP, [Rn,Rm]

The affected instructions that can result in the stack-pointer being loaded from an incorrect memory address are:

• LDR SP,[Rn],#imm

• LDR SP,[Rn,#imm]!

As compilers do not generate these particular instructions, the limitation is only likely to occur with hand-written
assembly code.

Workaround

Both issues may be worked around by replacing the direct load to the stack-pointer, with an intermediate load to a
general-purpose register followed by a move to the stack-pointer.

2.1.2 Store immediate overlapping exception return operation might vector to incorrect interrupt

This limitation is registered under Arm ID number 838869 and classified into “Category B (rare)”. Its impact to the
device is minor.

ES0506 - Rev 2

Description

The core includes a write buffer that permits execution to continue while a store is waiting on the bus. Under
specific timing conditions, during an exception return while this buffer is still in use by a store instruction, a late
change in selection of the next interrupt to be taken might result in there being a mismatch between the interrupt
acknowledged by the interrupt controller and the vector fetched by the processor.

page 4/19

STM32WLE5xx STM32WLE4xx

System

The failure occurs when the following condition is met:

1. The handler for interrupt A is being executed.

2. Interrupt B, of the same or lower priority than interrupt A, is pending.

3. A store with immediate offset instruction is executed to a bufferable location.

– STR/STRH/STRB <Rt>, [<Rn>,#imm]

– STR/STRH/STRB <Rt>, [<Rn>,#imm]!

– STR/STRH/STRB <Rt>, [<Rn>],#imm

4. Any number of additional data-processing instructions can be executed.

5. A BX instruction is executed that causes an exception return.

6. The store data has wait states applied to it such that the data is accepted at least two cycles after the BX is
executed.

– Minimally, this is two cycles if the store and the BX instruction have no additional instructions between

them.

– The number of wait states required to observe this erratum needs to be increased by the number of

cycles between the store and the interrupt service routine exit instruction.

7. Before the bus accepts the buffered store data, another interrupt C is asserted which has the same or lower
priority as A, but a greater priority than B.

Example:

The processor should execute interrupt handler C, and on completion of handler C should execute the handler
for B. If the conditions above are met, then this erratum results in the processor erroneously clearing the pending
state of interrupt C, and then executing the handler for B twice. The first time the handler for B is executed it
will be at interrupt C's priority level. If interrupt C is pended by a level-based interrupt which is cleared by C's
handler then interrupt C will be pended again once the handler for B has completed and the handler for C will be
executed.

As the STM32 interrupt C is level based, it eventually becomes pending again and is subsequently handled.

Workaround

For software not using the memory protection unit, this erratum can be worked around by setting DISDEFWBUF
in the Auxiliary Control Register.

In all other cases, the erratum can be avoided by ensuring a DSB occurs between the store and the BX
instruction. For exception handlers written in C, this can be achieved by inserting the appropriate set of intrinsics
or inline assembly just before the end of the interrupt function, for example:

ARMCC:

...
__schedule_barrier();
__asm{DSB};
__schedule_barrier();
}

GCC:

...
__asm volatile ("dsb 0xf":::"memory");
}

2.2

System

2.2.1 Wrong DMAMUX synchronization and trigger input connections to EXTI

ES0506 - Rev 2

Description

By error, synchronization and trigger inputs of the DMAMUX peripheral are connected to interrupt output lines of
the EXTI block, instead of being connected to its SYSCFG multiplexer output lines.

page 5/19

STM32WLE5xx STM32WLE4xx

System

The EXTI interrupt lines exhibit a rising-edge transition upon each active transition (rising, falling or both) of
corresponding GPIOs, as defined in the EXTI_RTSRx and EXTI_FTSRx registers.

As a consequence, the falling active edge option of the DMAMUX synchronization and trigger inputs is unusable
because falling edges on these inputs do not occur upon GPIO events but upon clearing the EXTI interrupt
pending flags (by setting the corresponding PIF bits of the EXTI_PRx register).

Workaround

For the DMAMUX synchronization and trigger events to occur upon determined rising or/and falling edge of the
corresponding GPIOs:

• Set the desired active edge polarities of the corresponding GPIOs through the EXTI_RTSRx and
EXTI_FTSRx registers.

• Set the active edge polarity to rising for all corresponding DMAMUX input lines, through the SPOL bits of the
DMAMUX_CxCR register (for synchronization inputs) and the GPOL bits of the DMAMUX_RGxCR register
(for trigger inputs).

• Ensure that EXTI interrupt pending flags corresponding to the GPIOs used for DMAMUX inputs are cleared
in the EXTI interrupt service routine.

Note: This can be ensured if using the HAL_GPIO_IrqHandler function provided by STMicroelectronics.

2.2.2 Overwriting with all zeros a Flash memory location previously programmed with all ones fails

Description

Any attempt to re-program with all zeros (0x0000 0000 0000 0000) a Flash memory location previously
programmed with 0xFFFF FFFF FFFF FFFF fails and the PROGERR flag of the FLASH_SR register is set.

Workaround

None.

2.2.3 Option byte loading failure at high MSI system clock frequency

Description

The option bytes are not loaded correctly upon setting the OBL_LAUNCH bit of the FLASH_CR register when the
frequency of MSI oscillator used as system clock source is higher than 16 MHz.

Workaround

Before loading the option bytes by setting the OBL_LAUNCH bit of the FLASH_CR register, either change the
system clock source to other than MSI oscillator, or set the MSI clock frequency to less than 16 MHz.

2.2.4 A system reset occurs when nRST_SHDW is set and nRST_STDBY is cleared and Shutdown

mode is entered

Description

When the following configuration is selected:

• nRST_SHDW is set

• nRST_STDBY is cleared,

a system reset is generated when Shutdown mode is entered.

ES0506 - Rev 2

Workaround

The only valid configuration to avoid a reset after entering into Shutdown mode is the following:

• nRST_SHDW is set

• nRST_STDBY is set.

page 6/19

STM32WLE5xx STM32WLE4xx

System

2.2.5 FLASH_ECCR corrupted upon reset or power-down occurring during Flash memory program

or erase operation

Description

Reset or power-down occurring during a Flash memory location program or erase operation, followed by a read of
the same memory location, may lead to a corruption of the FLASH_ECCR register content.

Workaround

Under such condition, erase the page(s) corresponding to the Flash memory location.

2.2.6 Voltage drop on the 1.2 V regulated supply when switching MSI to 48 MHz

Description

A voltage drop to 1.08 V may occur on the 1.2 V regulated supply when the MSI frequency is changed as follows:

• from MSI at 400 kHz to MSI at 24 MHz and above

• from MSI at 1 MHZ to MSI at 48 MHz

As a result, the voltage drop may cause CPU HardFault.

Workaround

To ensure there is no impact on the 1.2 V supply, introduce an intermediate MSI frequency change step as
follows:

• Change the MSI frequency range from 400 kHz to 12 MHz, then to 24 MHz and above, as illustrated in these

examples:

– MSI@400 kHz → MSI@12 MHz → MSI@24 MHz

– MSI@400 kHz → MSI@12 MHz → MSI@48 MHz.

• Change the MSI frequency range from 1 MHz to 12 MHz, then to 48 MHz, as illustrated in this example:

MSI@400 kHz → MSI@12 MHz → MSI@48 MHz.

2.2.7 Sensitivity affected by HSE activation in high bandwidth channel

Description

The sensitivity of the high bandwidth channels (HB) EU864 and US928 is affected when HSE is used as system
clock. HSE cannot be used as system clock when channels EU864 or US928 are used. Except if the LoRa

modulation is needed, the user can also replace 32 MHz HSE clock by 31.25 MHz HSE clock.

Workaround

Use a different clock source for the system, for example MSI or HSI with or without PLL.

2.2.8 Sensitivity degradation in LNA boosted mode

Description

Reduced performance is observed in some specific LNA boost mode use cases. There is a potential loss of
sensitivity of approximately up to 1.5 dB on rev Z and 0.75 dB in rev Y, versus specification for LoRa® and GFSK

modulation at 915 MHz.

®

ES0506 - Rev 2

Workaround

None.

page 7/19

STM32WLE5xx STM32WLE4xx

2.2.9 SysTick trigger in debug emulation generates HardFault

Description

When the CPU enters its deepsleep state and debug emulation is active, the CPU SysTick is still running and
able to trigger interrupts. The CPU is woken up and fetches code from the system Flash memory. As the Flash
memory is not active, the CPU starts fetching code from a resource that is not available, and receives random
data from the bus, causing HardFault.

When the debug emulation is active and the CPU enters its deepsleep state, the system exhibits unpredictable
behavior due to the SysTick activity.

Workaround

Always disable SysTick before the CPU enters its deepsleep state. This consistently prevents any interrupt
triggering and any possibility of HardFault.

2.2.10 Debug HALT command in debug emulation generates HardFault

Description

When the CPU is in deepsleep state with active debug emulation and a debug HALT - debug RUN command
sequence is submitted, the CPU wakes up and starts fetching data from Flash memory. As Flash memory is
unavailable, the CPU receives random data from the bus which causes HardFault.

Debug cannot be performed on the system when the CPU is in deepsleep state and debug emulation is active.

System

Workaround

Change the debug sequence to perform a detach/attach procedure before any "HALT/RUN". Also enable the
CDBGPWRUP wakeup on the AIEC before the CPU goes in deepsleep state.

2.2.11 Potential deadlock condition on wakeup from a lower-power mode

Description

Following multiple wakeups from Stop 1, Stop 2 or Standby, the power supply management block may not restart
properly. This occurs on a specific timing of the wakeup event and Run duration.

The issue may occur in the event of an asynchronous wakeup when the MCU remains in Run for less than 60 µs
after a wakeup.

When this issue happens, the power consumption in Run mode does not correspond to the datasheet. The global
power consumption is not impacted.

Workaround

If it is key to control accurately the power consumption, use one of the following measures:

• General workaround (valid also if SMPS is used before entering wakeup): wait for the LDO to reach a stable

condition before entering a low‑power mode.

A software implementation solution is to check that the LDORDY bit of the PWR_SR2 register is set before
entering a low‑power mode.

• LDO use case only (SMPS was not used before entering wakeup): the deadlock condition, which can

potentially occur at wakeup from a low‑power mode, can be solved by generating a pulse on the SMPSEN
bit of the PWR_CR5 register controlling the SMPS activation.

A software implementation solution is to toggle the SMPSEN bit of the PWR_CR5 register at each wakeup
from low‑power mode.

ES0506 - Rev 2

page 8/19

2.2.12 JTAG cannot be used without the JTAG NRST pin

Description

When CPU1 is in deepsleep state with active debug emulation and CPU2 is stopped as well, and a debug HALT

- debug RUN command sequence is submitted, CPU1 wakes up and starts to fetch from Flash memory. In this
condition, the Flash memory is off, CPU1 retrieves random information from the bus which causes a HardFault.

By default after reset, PB4 is configured as alternate function for JTAG NRESET function. If this pin is reused
in another configuration (GPIO, analog or alternate function for another function), the product JTAG NRESET
internal signal is forced to 0.

Workaround

None.

2.2.13 Flash PCROP is not operating properly

Description

The PCROP protection on the Flash memory area does not work as expected.

Workaround

STM32WLE5xx STM32WLE4xx

TIM

None.

2.2.14 TX spurs around carrier at a multiple of HSE clock frequency

Description

Unwanted spurs may occur around the transmission carrier with frequency that is an integer multiple of the HSE
clock frequency. For example, around 480 MHz or 864 MHz if the HSE clock frequency is 32 MHz.

Workaround

Apply one of the following measures:

• Choose the HSE clock frequency so that its integer multiples are at least 1.5 MHz away from the desired

transmission carrier frequency.

• Do not use transmission channels within the range of ±1.5 MHz around carrier frequencies that are integer

multiples of the HSE clock frequency.

Note:

The first measure cannot be applied if the application requires LoRa® modulation that imposes the use of
32 MHz HSE clock.

2.3 TIM

2.3.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration

Description

ES0506 - Rev 2

The failure occurs when several timers configured in one-pulse mode are cascaded, and the master timer is
configured in combined reset + trigger mode with the MSM bit set:

OPM = 1 in TIMx_CR1, SMS[3:0] = 1000 and MSM = 1 in TIMx_SMCR.

The MSM delays the reaction of the master timer to the trigger event, so as to have the slave timers cycle­accurately synchronized.

If the trigger arrives when the counter value is equal to the period value set in the TIMx_ARR register, the
one-pulse mode of the master timer does not work and no pulse is generated on the output.

page 9/19

STM32WLE5xx STM32WLE4xx

Workaround

None. However, unless a cycle-level synchronization is mandatory, it is advised to keep the MSM bit reset, in
which case the problem is not present. The MSM = 0 configuration also allows decreasing the timer latency to
external trigger events.

2.3.2 Consecutive compare event missed in specific conditions

Description

Every match of the counter (CNT) value with the compare register (CCR) value is expected to trigger a compare
event. However, if such matches occur in two consecutive counter clock cycles (as consequence of the CCR
value change between the two cycles), the second compare event is missed for the following CCR value
changes:

in edge-aligned mode, from ARR to 0:

•

– first compare event: CNT = CCR = ARR

– second (missed) compare event: CNT = CCR = 0

•

in center-aligned mode while up-counting, from ARR-1 to ARR (possibly a new ARR value if the period is
also changed) at the crest (that is, when TIMx_RCR = 0):

– first compare event: CNT = CCR = (ARR-1)

– second (missed) compare event: CNT = CCR = ARR

•

in center-aligned mode while down-counting, from 1 to 0 at the valley (that is, when TIMx_RCR = 0):

– first compare event: CNT = CCR = 1

– second (missed) compare event: CNT = CCR = 0

This typically corresponds to an abrupt change of compare value aiming at creating a timer clock single-cycle­wide pulse in toggle mode.

As a consequence:

• In toggle mode, the output only toggles once per counter period (squared waveform), whereas it is expected

to toggle twice within two consecutive counter cycles (and so exhibit a short pulse per counter period).

• In center mode, the compare interrupt flag does note rise and the interrupt is not generated.

Note: The timer output operates as expected in modes other than the toggle mode.

TIM

Workaround

None.

2.3.3 Output compare clear not working with external counter reset

Description

The output compare clear event (ocref_clr) is not correctly generated when the timer is configured in the following
slave modes: Reset mode, Combined reset + trigger mode, and Combined gated + reset mode.

The PWM output remains inactive during one extra PWM cycle if the following sequence occurs:

1. The output is cleared by the ocref_clr event.

2. The timer reset occurs before the programmed compare event.

Workaround

Apply one of the following measures:

• Use BKIN (or BKIN2 if available) input for clearing the output, selecting the Automatic output enable mode

(AOE = 1).

• Mask the timer reset during the PWM ON time to prevent it from occurring before the compare event (for

example with a spare timer compare channel open-drain output connected with the reset signal, pulling the
timer reset line down).

ES0506 - Rev 2

page 10/19

STM32WLE5xx STM32WLE4xx

2.4 LPTIM

2.4.1 Device may remain stuck in LPTIM interrupt when entering Stop mode

Description

This limitation occurs when disabling the low-power timer (LPTIM).

When the user application clears the ENABLE bit in the LPTIM_CR register within a small time window around
one LPTIM interrupt occurrence, then the LPTIM interrupt signal used to wake up the device from Stop mode may
be frozen in active state. Consequently, when trying to enter Stop mode, this limitation prevents the device from
entering low-power mode and the firmware remains stuck in the LPTIM interrupt routine.

This limitation applies to all Stop modes and to all instances of the LPTIM. Note that the occurrence of this issue
is very low.

Workaround

In order to disable a low power timer (LPTIMx) peripheral, do not clear its ENABLE bit in its respective LPTIM_CR
register. Instead, reset the whole LPTIMx peripheral via the RCC controller by setting and resetting its respective
LPTIMxRST bit in RCC_APByRSTRz register.

2.4.2 ARRM and CMPM flags are not set when APB clock is slower than kernel clock

LPTIM

Description

When LPTIM is configured in one shot mode and APB clock is lower than kernel clock, there is a chance that
ARRM and CMPM flags are not set at the end of the counting cycle defined by the repetition value REP[7:0]. This
issue can only occur when the repetition counter is configured with an odd repetition value.

Workaround

To avoid this issue the following formula must be respected:

{ARR, CMP} ≥ KER_CLK / (2* APB_CLK),

where APB_CLK is the LPTIM APB clock frequency, and KER_CLK is the LPTIM kernel clock frequency. ARR
and CMP are expressed in decimal value.

Example: The following example illustrates a configuration where the issue can occur:

• APB clock source (MSI) = 1 MHz , Kernel clock source (HSI) = 16 MHz

• Repetition counter is set with REP[7:0] = 0x3 (odd value)

The above example is subject to issue, unless the user respects:

{CMP, ARR} ≥ 16 MHz / (2 * 1 MHz)

→ ARR must be ≥ 8 and CMP must be ≥ 8

Note: REP set to 0x3 means that effective repetition is REP+1 (= 4) but the user must consider the parity of the value

loaded in LPTIM_RCR register (=3, odd) to assess the risk of issue.

2.4.3 Device may remain stuck in LPTIM interrupt when clearing event flag

Description

ES0506 - Rev 2

This limitation occurs when the LPTIM is configured in interrupt mode (at least one interrupt is enabled) and
the software clears any flag in LPTIM_ISR register by writing its corresponding bit in LPTIM_ICR register. If the
interrupt status flag corresponding to a disabled interrupt is cleared simultaneously with a new event detection,
the set and clear commands might reach the APB domain at the same time, leading to an asynchronous interrupt
signal permanently stuck high.

This issue can occur either during an interrupt subroutine execution (where the flag clearing is usually done), or
outside an interrupt subroutine.

Consequently, the firmware remains stuck in the LPTIM interrupt routine, and the device cannot enter Stop mode.

page 11/19

STM32WLE5xx STM32WLE4xx

RTC and TAMP

Workaround

To avoid this issue, it is strongly advised to follow the recommendations listed below:

• Clear the flag only when its corresponding interrupt is enabled in the interrupt enable register.

• If for specific reasons, it is required to clear some flags that have corresponding interrupt lines disabled in

the interrupt enable register, it is recommended to clear them during the current subroutine prior to those
which have corresponding interrupt line enabled in the interrupt enable register.

• Flags must not be cleared outside the interrupt subroutine.

Note: The proper clear sequence is already implemented in the HAL_LPTIM_IRQHandler in the STM32Cube.

2.5 RTC and TAMP

2.5.1 Alarm flag may be repeatedly set when the core is stopped in debug

Description

When the core is stopped in debug mode, the clock is supplied to subsecond RTC alarm downcounter even
though the device is configured to stop the RTC in debug.

As a consequence, when the subsecond counter is used for alarm condition (the MASKSS[3:0] bitfield of the
RTC_ALRMASSR and/or RTC_ALRMBSSR register set to a non-zero value) and the alarm condition is met just
before entering a breakpoint or printf, the ALRAF and/or ALRBF flag of the RTC_SR register is repeatedly set by
hardware during the breakpoint or printf, which makes any tentative to clear the flag(s) ineffective.

Workaround

None.

2.5.2 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles

after clearing TSF

Description

With the timestamp on tamper event enabled (TAMPTS bit of the RTC_CR register set), a tamper event is ignored
if it occurs:

• within four APB clock cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, while

the TSF flag is not yet effectively cleared (it fails to set the TSOVF flag)

• within two ck_apre cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, when the

TSF flag is effectively cleared (it fails to set the TSF flag and timestamp the calendar registers)

Workaround

None.

2.5.3 REFCKON write protection associated to INIT KEY instead of CAL KEY

Description

The write protection of the REFCKON bit is unlocked if the key sequence is written in RTC_WPR with the
privilege and security rights set by the INITPRIV and INITSEC bits, instead of being set by the CALPRIV and
CALSEC bits.

ES0506 - Rev 2

Workaround

Unlock the INIT KEY before writing REFCKON.

page 12/19

STM32WLE5xx STM32WLE4xx

2.5.4 Tamper flag not set on LSE failure detection

Description

With the timestamp on tamper event enabled (the TAMPTS bit of the RTC_CR register set), the LSE failure
detection (LSE clock stopped) event connected to the internal tamper 3 fails to raise the ITAMP3F and ITAMP3MF
flags, although it duly erases or blocks (depending on the internal tamper 3 configuration) the backup registers
and other device secrets, and the RTC and TAMP peripherals resume normally upon the LSE restart.

Note: As expected in this particular case, the TSF and TSMF flags remain low as long as LSE is stopped as they

require running RTCCLK clock to operate.

Workaround

None.

2.5.5 Binary mode: SSR is not reloaded with 0xFFFF FFFF when SSCLR = 1

Description

When SSCLR bit of the RTC_ALRMxSSR register is set when in binary mode, SSR is reloaded with
0xFFFF FFFF at the end of the ck_apre cycle when RTC_SSR is set to RTC_ALRxBINR (x stands for either
A or B)

RTC_SSR is not reloaded with 0xFFFF FFFF if RTC_ALRxBINR is modified while RTC_SSR is set to
RTC_ALRxBINR. Rather, SSR continues to decrement.

I2C

Workaround

The workarounds are described for alarm A, and can be applied in the same manner for alarm B. Two
workarounds are proposed, the second one requires to use the second alarm.

• Wait for one ck_apre cycle after an alarm A event before changing the RTC_ALRABINR register value.

• Do not reprogram RTC_ALRABINR following the alarm A event itself. Instead, use alarm B configured

with RTC_ALRBBINR set to 0xFFFF FFFF, and reprogram RTC_ALRABINR after the alarm B event. This
ensures that one ck_apre cycle elapses following the alarm A event.

2.6 I2C

2.6.1 Wrong data sampling when data setup time (t

Description

The I2C-bus specification and user manual specify a minimum data setup time (t

• 250 ns in Standard mode

• 100 ns in Fast mode

• 50 ns in Fast mode Plus

The device does not correctly sample the I2C-bus SDA line when t

(I2C-bus peripheral clock) period: the previous SDA value is sampled instead of the current one. This can result in
a wrong receipt of slave address, data byte, or acknowledge bit.

) is shorter than one I2C kernel clock period

SU;DAT

) as:

SU;DAT

is smaller than one I2C kernel clock

SU;DAT

ES0506 - Rev 2

page 13/19

Workaround

Increase the I2C kernel clock frequency to get I2C kernel clock period within the transmitter minimum data setup
time. Alternatively, increase transmitter’s minimum data setup time. If the transmitter setup time minimum value

corresponds to the minimum value provided in the I2C-bus standard, the minimum I2CCLK frequencies are as
follows:

• In Standard mode, if the transmitter minimum setup time is 250 ns, the I2CCLK frequency must be at least

4 MHz.

• In Fast mode, if the transmitter minimum setup time is 100 ns, the I2CCLK frequency must be at least

10 MHz.

• In Fast-mode Plus, if the transmitter minimum setup time is 50 ns, the I2CCLK frequency must be at least

20 MHz.

2.6.2 Spurious bus error detection in master mode

Description

In master mode, a bus error can be detected spuriously, with the consequence of setting the BERR flag of the
I2C_SR register and generating bus error interrupt if such interrupt is enabled. Detection of bus error has no effect

on the I2C-bus transfer in master mode and any such transfer continues normally.

STM32WLE5xx STM32WLE4xx

I2C

Workaround

If a bus error interrupt is generated in master mode, the BERR flag must be cleared by software. No other action
is required and the ongoing transfer can be handled normally.

2.6.3 OVR flag not set in underrun condition

Description

In slave transmission with clock stretching disabled (NOSTRETCH = 1 in the I2C_CR1 register), an underrun
condition occurs if the current byte transmission is completed on the I2C bus, and the next data is not yet written
in the TXDATA[7:0] bitfield. In this condition, the device is expected to set the OVR flag of the I2C_ISR register
and send 0xFF on the bus.

However, if the I2C_TXDR is written within the interval between two I2C kernel clock cycles before and three APB
clock cycles after the start of the next data transmission, the OVR flag is not set, although the transmitted value is
0xFF.

Workaround

None.

2.6.4 Transmission stalled after first byte transfer

Description

When the first byte to transmit is not prepared in the TXDATA register, two bytes are required successively,
through TXIS status flag setting or through a DMA request. If the first of the two bytes is written in the I2C_TXDR
register in less than two I2C kernel clock cycles after the TXIS/DMA request, and the ratio between APB clock
and I2C kernel clock frequencies is between 1.5 and 3, the second byte written in the I2C_TXDR is not internally
detected. This causes a state in which the I2C peripheral is stalled in master mode or in slave mode, with clock
stretching enabled (NOSTRETCH = 0). This state can only be released by disabling the peripheral (PE = 0) or by
resetting it.

ES0506 - Rev 2

page 14/19

STM32WLE5xx STM32WLE4xx

USART

Workaround

Apply one of the following measures:

• Write the first data in I2C_TXDR before the transmission starts.

• Set the APB clock frequency so that its ratio with respect to the I2C kernel clock frequency is lower than 1.5

or higher than 3.

2.7

USART

2.7.1 Anticipated end-of-transmission signaling in SPI slave mode

Description

In SPI slave mode, at low USART baud rate with respect to the USART kernel and APB clock frequencies, the
transmission complete flag TC of the USARTx_ISR register may unduly be set before the last bit is shifted on the
transmit line.

This leads to data corruption if, based on this anticipated end-of-transmission signaling, the application disables
the peripheral before the last bit is transmitted.

Workaround

Upon the TC flag rise, wait until the clock line remains idle for more than the half of the communication clock
cycle. Then only consider the transmission as ended.

2.7.2 Data corruption due to noisy receive line

Description

In UART mode with oversampling by 8 or 16 and with 1 or 2 stop bits, the received data may be corrupted if a
glitch to zero shorter than the half-bit occurs on the receive line within the second half of the stop bit.

Workaround

None.

2.7.3 DMA stream locked when transferring data to/from USART

Description

When a USART is issuing a DMA request to transfer data, if a concurrent transfer occurs, the requested transfer
may not be served and the DMA stream may stay locked.

Workaround

Use the alternative peripheral DMA channel protocol by setting bit 20 of the DMA_SxCR register.

This bit is reserved in the documentation and must be used only on the stream that manages data transfers for
USART peripherals.

ES0506 - Rev 2

page 15/19

Revision history

STM32WLE5xx STM32WLE4xx

Table 4. Document revision history

Date Version Changes

06-Nov-2020 1 Initial release.

Added:

• JTAG cannot be used without the JTAG NRST pin

• Flash PCROP is not operating properly

• TX spurs around carrier at a multiple of HSE clock frequency

• Binary mode: SSR is not reloaded with 0xFFFF FFFF when SSCLR = 1

21-Apr-2021 2

• die revision Y

Updated:

• Sensitivity affected by HSE activation in high bandwidth channel

• Sensitivity degradation in LNA boosted mode

• Potential deadlock condition on wakeup from a lower-power mode

Removed VDIV or VSQRT instructions might not complete correctly when
very short ISRs are used in Core.

ES0506 - Rev 2

page 16/19

STM32WLE5xx STM32WLE4xx

Contents

Contents

1 Summary of device errata..........................................................2

2 Description of device errata........................................................4

2.1 Core .........................................................................4

2.1.1 Interrupted loads to SP can cause erroneous behavior ............................4

2.1.2 Store immediate overlapping exception return operation might vector to incorrect interrupt 4

2.2 System .......................................................................5

2.2.1 Wrong DMAMUX synchronization and trigger input connections to EXTI ..............5

2.2.2 Overwriting with all zeros a Flash memory location previously programmed with all ones

fails ...................................................................6

2.2.3 Option byte loading failure at high MSI system clock frequency .....................6

2.2.4 A system reset occurs when nRST_SHDW is set and nRST_STDBY is cleared and

Shutdown mode is entered .................................................6

2.2.5 FLASH_ECCR corrupted upon reset or power-down occurring during Flash memory

program or erase operation.................................................7

2.2.6 Voltage drop on the 1.2 V regulated supply when switching MSI to 48 MHz ............7

2.2.7 Sensitivity affected by HSE activation in high bandwidth channel ....................7

2.2.8 Sensitivity degradation in LNA boosted mode ...................................7

2.2.9 SysTick trigger in debug emulation generates HardFault ..........................8

2.2.10 Debug HALT command in debug emulation generates HardFault ....................8

2.2.11 Potential deadlock condition on wakeup from a lower-power mode...................8

2.2.12 JTAG cannot be used without the JTAG NRST pin ...............................9

2.2.13 Flash PCROP is not operating properly........................................9

2.2.14 TX spurs around carrier at a multiple of HSE clock frequency.......................9

2.3 TIM ..........................................................................9

2.3.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration .......9

2.3.2 Consecutive compare event missed in specific conditions ........................10

2.3.3 Output compare clear not working with external counter reset .....................10

2.4 LPTIM .......................................................................11

2.4.1 Device may remain stuck in LPTIM interrupt when entering Stop mode .............. 11

2.4.2 ARRM and CMPM flags are not set when APB clock is slower than kernel clock .......11

2.4.3 Device may remain stuck in LPTIM interrupt when clearing event flag ...............11

2.5 RTC and TAMP ...............................................................12

ES0506 - Rev 2

page 17/19

STM32WLE5xx STM32WLE4xx

Contents

2.5.1 Alarm flag may be repeatedly set when the core is stopped in debug ................12

2.5.2 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles

after clearing TSF .......................................................12

2.5.3 REFCKON write protection associated to INIT KEY instead of CAL KEY .............12

2.5.4 Tamper flag not set on LSE failure detection ...................................13

2.5.5 Binary mode: SSR is not reloaded with 0xFFFF FFFF when SSCLR = 1 .............13

2.6 I2C .........................................................................13

2.6.1 Wrong data sampling when data setup time (t

) is shorter than one I2C kernel clock

SU;DAT

period ................................................................13

2.6.2 Spurious bus error detection in master mode ..................................14

2.6.3 OVR flag not set in underrun condition .......................................14

2.6.4 Transmission stalled after first byte transfer ...................................14

2.7 USART ......................................................................15

2.7.1 Anticipated end-of-transmission signaling in SPI slave mode ......................15

2.7.2 Data corruption due to noisy receive line......................................15

2.7.3 DMA stream locked when transferring data to/from USART .......................15

Revision history .......................................................................16

ES0506 - Rev 2

page 18/19

STM32WLE5xx STM32WLE4xx

IMPORTANT NOTICE – PLEASE READ CAREFULLY

STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and improvements to ST
products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST
products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.

Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of
Purchasers’ products.

No license, express or implied, to any intellectual property right is granted by ST herein.

Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.

ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service
names are the property of their respective owners.

Information in this document supersedes and replaces information previously supplied in any prior versions of this document.

© 2021 STMicroelectronics – All rights reserved

ES0506 - Rev 2

page 19/19
