STMicroelectronics STM32MP151A, STM32MP151C, STM32MP151D, STM32MP151F, STM32MP153A Datasheet
...
STM32MP151x STM32MP153x STM32MP157x
Errata sheet
STM32MP151x/3x/7x device errata
Applicability
This document applies to the part numbers of STM32MP151x/3x/7x devices and the device variants as stated in this page.
It gives a summary and a description of the device errata, with respect to the device datasheet and reference manual RM0441
for STM32MP151x, RM0442 for STM32MP153x, and RM0436 for STM32MP157x.
Deviation of the real device behavior from the intended device behavior is considered to be a device limitation. Deviation of the
description in the reference manual or the datasheet from the intended device behavior is considered to be a documentation
erratum. The term “errata” applies both to limitations and documentation errata.
Table 1. Device summary
Reference Part numbers
STM32MP151x STM32MP151A, STM32MP151C, STM32MP151D, STM32MP151F
STM32MP153x STM32MP153A, STM32MP153C, STM32MP153D, STM32MP153F
STM32MP157x STM32MP157A, STM32MP157C, STM32MP157D, STM32MP157F
Table 2. Device variants
Reference
STM32MP151x/3x/7x
STM32MP151x/3x/7x Z 0x2001
1. Refer to the device datasheet for how to identify this code on different types of package.
2. REV_ID[15:0] bitfield of DBGMCU_IDC register.
Device marking
B 0x2000
Silicon revision codes
(1)
REV_ID
(2)
ES0438 - Rev 6 - February 2021
For further information contact your local STMicroelectronics sales office.
www.st.com
1 Summary of device errata
The following table gives a quick reference to the STM32MP151x/3x/7x device limitations and their status:
A = limitation present, workaround available
N = limitation present, no workaround available
P = limitation present, partial workaround available
“-” = limitation absent
Applicability of a workaround may depend on specific conditions of target application. Adoption of a workaround
may cause restrictions to target application. Workaround for a limitation is deemed partial if it only reduces the
rate of occurrence and/or consequences of the limitation, or if it is fully effective for only a subset of instances on
the device or in only a subset of operating modes, of the function concerned.
Table 3. Summary of device limitations
Function Section Limitation
Memory locations might be accessed speculatively due to instruction
fetches when HCR.VM is set
VDIV or VSQRT instructions might not complete correctly when very short
ISRs are used
Store immediate overlapping exception return operation might vector to
incorrect interrupt
TPIU fails to output sync after the pattern generator is disabled in Normal
mode
Limitation of aclk/hclk5/hclk6 to 200 MHz when used as SDMMC1/2 kernel
clock
RCC security settings for Cortex-M4 access are not kept upon wake up
from Standby
Wakeup pin flags cleared at Standby mode exit with MCU_BEN high and
MPU_BEN low
Boundary scan SAMPLE/PRELOAD behavior not compliant with
IEE1149.1
Arm Cortex-A7
core
Arm Cortex-M4
core
System
2.1.1
2.1.2 Cache maintenance by set/way operations can execute out of order A A
2.1.3 PMU events 0x07, 0x0C, and 0x0E do not increment correctly N N
2.1.4 PMU event counter 0x14 does not increment correctly A A
2.1.5 Exception mask bits are cleared when an exception is taken in Hyp mode N N
2.2.1 Interrupted loads to SP can cause erroneous behavior A A
2.2.2
2.2.3
2.3.1
2.3.2 Serial-wire multi-drop debug not supported N N
2.3.3 HSE external oscillator required in some LTDC use cases P P
2.3.4 RCC cannot exit Stop and LP-Stop modes A A
2.3.5 Incorrect reset of glitch-free kernel clock switch P P
2.3.6
2.3.7 Overconsumption in Standby with on‑board 1.8 V regulator bypassed A -
2.3.8 eMMC boot timeout too short A -
2.3.9 Cortex-M4 cannot use I/O compensation on Standby mode exit A A
2.3.10 Missed wake-up events in CSTANDBY N -
2.3.12
2.3.13
2.3.14 Boundary scan data unduly sampled on TCK falling edge A A
2.3.15
STM32MP151x STM32MP153x STM32MP157x
Summary of device errata
Status
Rev.BRev.
Z
A A
A A
A A
A A
P P
N N
N N
A A
ES0438 - Rev 6
page 2/45
STM32MP151x STM32MP153x STM32MP157x
Summary of device errata
Status
Function Section Limitation
2.3.16 Boot with a specific combination of NAND Flash memories fails
2.3.17 Boot with 1-bit error correction on SLC NAND Flash memory fails A -
System
DDRPHYC
GPIO 2.5.1
DMA 2.6.1 USART/UART/LPUART DMA transfer abort D D
DMAMUX
QUADSPI 2.8.1 Memory-mapped read of last memory byte fails P P
ADC
VREFBUF
DAC
DTS 2.12.1 Mode using PCLK & LSE (REFCLK_SEL = 1) should not be used P P
DSI 2.13.1
TIM
LPTIM
2.3.18 Boot fails if eMMC does not answer the first command N -
2.3.19 DLYB limits SDMMC throughput N N
2.3.20 LSE CSS cannot be used in VBAT state N N
2.3.21 Wrong value in Coresight M4 ROM table A A
2.4.1 DDRPHYC overconsumption upon reset or Standby mode exit A -
2.4.2
2.4.3
2.7.1 SOFx not asserted when writing into DMAMUX_CFR register N N
2.7.2 OFx not asserted for trigger event coinciding with last DMAMUX request N N
2.7.3 OFx not asserted when writing into DMAMUX_RGCFR register N N
2.7.4
2.9.1
2.9.2
2.9.3
2.9.4 ADC_AWDy_OUT reset by non-guarded channels A A
2.9.5 ADC ANA0/ANA1 resolution limited when Gigabit Ethernet is used P P
2.9.6 ADC missing codes in differential 16-bit static acquisition P P
2.11.1 VREFBUF Hold mode cannot be used N N
2.11.2 Overshoot on VREFBUF output A A
2.10.1
2.10.2
2.15.1
2.15.2 Consecutive compare event missed in specific conditions N N
2.15.3 Output compare clear not working with external counter reset P P
2.16.1 Device may remain stuck in LPTIM interrupt when entering Stop mode A A
DDR_CLK jitter out of JEDEC requirement for 32-bit LPDDR2/LPDDR3 at
low device Tj
Data corruption at low device Tj combined with low 32-bit LPDDR2/
LPDDR3 I/O supply voltage
GPIO assigned to DAC cannot be used in output mode when the DAC
output is connected to on-chip peripheral
Wrong input DMA request routed upon specific DMAMUX_CxCR register
write coinciding with synchronization event
New context conversion initiated without waiting for trigger when writing
new context in ADC_JSQR with JQDIS = 0 and JQM = 0
Two consecutive context conversions fail when writing new context in
ADC_JSQR just after previous context completion with JQDIS = 0 and
JQM = 0
Unexpected regular conversion when two consecutive injected
conversions are performed in Dual interleaved mode
Invalid DAC channel analog output if the DAC channel MODE bitfield is
programmed before DAC initialization
DMA underrun flag not set when an internal trigger is detected on the
clock cycle of the DMA request acknowledge
DSI PHY compliant with MIPI DPHY v0.81 specification, not with DSI PHY
v1.0
One-pulse mode trigger not detected in master-slave reset + trigger
configuration
Rev.BRev.
N -
A A
A A
N N
A A
A A
A A
A A
A A
N N
N -
P P
Z
ES0438 - Rev 6
page 3/45
STM32MP151x STM32MP153x STM32MP157x
Function Section Limitation
LPTIM
RTC and TAMP
I2C
USART
SPI
FDCAN
OTG_HS 2.22.1
ETH
2.16.2 Device may remain stuck in LPTIM interrupt when clearing event flag
2.16.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle
2.17.1 Incorrect version register N N
2.17.2 Calendar initialization may fail in case of consecutive INIT mode entry A A
2.17.3 Alarm flag may be repeatedly set when the core is stopped in debug N N
2.17.4
2.17.5 REFCKON write protection associated to INIT KEY instead of CAL KEY A A
2.17.6 Tamper flag not set on LSE failure detection N N
2.18.1
2.18.2 Spurious bus error detection in master mode A A
2.18.3 Spurious master transfer upon own slave address match P P
2.18.4 OVR flag not set in underrun condition N N
2.18.5 Transmission stalled after first byte transfer A A
2.19.1 Anticipated end-of-transmission signaling in SPI slave mode A A
2.19.2 Data corruption due to noisy receive line N N
2.20.1 Master data transfer stall at system clock much faster than SCK A A
2.20.2 Corrupted CRC return at non-zero UDRDET setting P P
2.20.3 TXP interrupt occurring while SPI disabled A A
2.20.4 Possible corruption of last-received data depending on CRCSIZE setting A A
2.21.1 Desynchronization under specific condition with edge filtering enabled A A
2.21.2
2.21.3 DAR mode transmission failure due to lost arbitration A A
2.23.1 Incorrect L4 inverse filtering results for corrupted packets N N
2.23.2
2.23.3 Spurious receive watchdog timeout interrupt A A
2.23.4 Incorrect flexible PPS output interval under specific conditions A A
2.23.5 Packets dropped in RMII 10Mbps mode due to fake dribble and CRC error A A
2.23.6 ARP offload function not effective A A
2.23.7 Slight imbalance of AV traffic CBS bandwidth allocation N N
2.23.8 Spurious checksum error upon MTL pending Tx queue flush N N
2.23.9
2.23.10 DMA spurious state upon AXI DMA slave bus error P P
A tamper event fails to trigger timestamp or timestamp overflow events
during a few cycles after clearing TSF
Wrong data sampling when data setup time (tSU;DAT) is shorter than one
I2C kernel clock period
Tx FIFO messages inverted under specific buffer usage and priority
setting
Host packet transmission may hang when connecting through a hub to a
low-speed device
Rx DMA may fail to recover upon DMA restart following a bus error, with
Rx timestamping enabled
Bus error coinciding with start-of-packet corrupts MAC-generated packet
transmission
Summary of device errata
Status
Rev.BRev.
Z
P P
N N
P P
A A
N N
A A
N N
ES0438 - Rev 6
The following table gives a quick reference to the documentation errata.
page 4/45
STM32MP151x STM32MP153x STM32MP157x
Table 4. Summary of device documentation errata
Function Section Documentation erratum
System 2.3.11 SSCG option is not available on PLL3 and PLL4
HASH
2.14.1 Superseded suspend sequence for data loaded by DMA
2.14.2 Superseded suspend sequence for data loaded by the CPU
Summary of device errata
ES0438 - Rev 6
page 5/45
STM32MP151x STM32MP153x STM32MP157x
Description of device errata
2 Description of device errata
The following sections describe limitations of the applicable devices with Arm® core and provide workarounds if
available. They are grouped by device functions.
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
2.1 Arm Cortex-A7 core
Reference manual and errata notice for the Arm® Cortex®-A7 core revision r0p5-REVIDR=0x01 is available from
http://infocenter.arm.com.
2.1.1 Memory locations might be accessed speculatively due to instruction fetches when HCR.VM is
set
This limitation is registered under Arm ID number 844169 and classified into “Category B”. Its impact to the device
is minor.
Description
The ARMv7 architecture requires that when all associated stages of translation are disabled for the current
privilege level, memory locations are only accessed due to instruction fetches within the same or next 4 KB region
as an instruction which has been or will be fetched due to sequential execution. In the conditions detailed below,
the Cortex‑A7 processor might access other locations speculatively due to instruction fetches.
The unwanted speculative instruction fetches may occur when the following conditions are all met:
1. The processor must be executing at PL2 or Secure PL1.
2. Address translation is disabled for the current exception level (by clearing the appropriate SCTLR.M or
HSCTLR.M bit).
3. The HCR.VM bit is set.
As the HCR.VM is reset low, this issue will not manifest during boot code.
Workaround
This issue is most likely to arise in powerdown code, if PL2 or secure PL1 software disables address translation
before the core is powered down.
To work around this erratum, software should ensure that HCR.VM is cleared before disabling address translation
at PL2 or Secure PL1.
2.1.2 Cache maintenance by set/way operations can execute out of order
This limitation is registered under Arm ID number 814220 and classified into “Category B”. Its impact to the device
is limited.
Description
The ARM v7 architecture states that all cache and branch predictor maintenance operations that do not specify an
address execute in program order, relative to each other. However, because of this erratum, an L2 set/way cache
maintenance operation can overtake an L1 set/way cache maintenance operation.
Code that intends to clean dirty data from L1 to L2 and then from L2 to L3 using set/way operations might not
behave as expected. The L2 to L3 operation might happen first and result in dirty data remaining in L2 after the L1
to L2 operation has completed.
If dirty data remains in L2 then an external agent, such as a DMA agent, might observe stale data.
If the processor is reset or powered-down while dirty data remains in L2 then the dirty data will be lost.
ES0438 - Rev 6
page 6/45
STM32MP151x STM32MP153x STM32MP157x
Arm Cortex-A7 core
The failure occurs when the following conditions are all met:
1. A CPU performs an L1 DCCSW or DCCISW operation.
2. The targeted L1 set/way contains dirty data.
3. Before the next DSB, the same CPU executes an L2 DCCSW or DCCISW operation while the L1 set/way
operation is in progress.
4. The targeted L2 set/way is within the group of L2 set/ways that the dirty data from L1 can be allocated to.
If the above conditions are met then the L2 set/way operation can take effect before the dirty data from L1 has
been written to L2.
Note: Conditions (3) and (4) are not likely to be met concurrently when performing set/way operations on the entire
L1 and L2 caches. This is because cache maintenance code is likely to iterate through sets and ways in a
consistent ascending or consistent descending manner across cache levels, and to perform all operations on
one cache level before moving on to the next cache level. This means that, for example, cache maintenance
operations on L1 set 0 and L2 set 0 will be separated by cache maintenance operations for all other sets in the
L1 cache. This creates a large window for the cache maintenance operations on L1 set 0 to complete.
Workaround
Correct ordering between set/way cache maintenance operations can be forced by executing a DSB before
changing cache levels.
2.1.3 PMU events 0x07, 0x0C, and 0x0E do not increment correctly
This limitation is registered under Arm ID number 809719 and classified into “Category C”. Its impact to the device
is minor.
Description
The Cortex-A7 processor implements version 2 of the Performance Monitor Unit architecture (PMUv2). The PMU
can gather statistics on the operation of the processor and memory system during runtime. This event information
can be used when debugging or profiling code.
The PMU can be programmed to count architecturally executed stores (event 0x07), software changes of the PC
(event 0x0C), and procedure returns (event 0x0E). However, because of this erratum, these events do not fully
adhere to the descriptions in the PMUv2 architecture.
As a result of this limitation, the information returned by PMU counters that are programmed to count events
0x07, 0x0C, or 0x0E might be misleading when debugging or profiling code executed on the processor.
The error occurs when the following conditions are met:
Either:
1. A PMU counter is enabled and programmed to count event 0x07. That is: instruction architecturally
executed, condition code check pass, store.
2. A PLDW instruction is executed.
If the above conditions are met, the PMUv2 architecture specifies that the counter for event 0x07 does not
increment. However, the counter does increment.
Or:
1. A PMU counter is enabled and programmed to count event 0x0C. That is: instruction architecturally
executed, condition code check pass, software change of the PC.
2. An SVC, HVC, or SMC instruction is executed.
If the above conditions are met, the PMUv2 architecture specifies that the counter for event 0x0C increments.
However, the counter does not increment.
ES0438 - Rev 6
page 7/45
STM32MP151x STM32MP153x STM32MP157x
Arm Cortex-A7 core
Or:
1. A PMU counter is enabled and programmed to count event 0x0E. That is: instruction architecturally
executed, condition code check pass, procedure return.
2. One of the following instructions is executed:
a. MOV PC, LR
b. ThumbEE LDMIA R9!, {?, PC}
c. ThumbEE LDR PC, [R9], #offset
d. BX Rm, where Rm != R14
e. LDM SP, {?, PC}
If the above conditions are met, the PMUv2 architecture specifies that the counter for event 0x0E increments for
(a), (b), (c) and does not increment for (d) and (e). However, the counter does not increment for (a), (b), (c) and
increments for (d) and (e).
Example:
The processor should execute interrupt handler C, and on completion of handler C should execute the handler
for B. If the conditions above are met, then this erratum results in the processor erroneously clearing the pending
state of interrupt C, and then executing the handler for B twice. The first time the handler for B is executed it
will be at interrupt C's priority level. If interrupt C is pended by a level-based interrupt which is cleared by C's
handler then interrupt C will be pended again once the handler for B has completed and the handler for C will be
executed.
As the STM32 interrupt C is level based, then this interrupt will eventually become re-pending and subsequently
be handled.
Workaround
None.
2.1.4 PMU event counter 0x14 does not increment correctly
This limitation is registered under Arm ID number 805420 and classified into “Category C”. Its impact to the device
is minor.
Description
The Cortex-A7 MPCore processor implements version 2 of the Performance Monitor Unit architecture (PMUv2).
The PMU can gather statistics on the operation of the processor and memory system during runtime. This event
information can be used when debugging or profiling code. When a PMU counter is programmed to count L1
instruction cache accesses (event 0x14), the counter should increment on all L1 instruction cache accesses.
This limitation has the following implications:
1. If SCR.{AW, FW} is set to 0 then the clearing of corresponding bit CPSR.{A, F} to 0 has no effect. The value
of CPSR.{A, F} is ignored.
2. A PMU counter is enabled and programmed to count L1 instruction cache accesses (event 0x14).
3. Cacheable instruction fetches miss in the L1 instruction cache.
If the above conditions are met, the event counter will not increment.
Workaround
To obtain a better approximation for the number of L1 instruction cache accesses, enable a second PMU counter
and program it to count instruction fetches that cause linefills (event 0x01). Add the value returned by this counter
to the value returned by the L1 instruction access counter (event 0x14). The result of the addition is a better
indication of the number of L1 instruction cache accesses.
2.1.5 Exception mask bits are cleared when an exception is taken in Hyp mode
This limitation is registered under Arm ID number 804069 and classified into “Category C”. Its impact to the device
is minor.
ES0438 - Rev 6
page 8/45
STM32MP151x STM32MP153x STM32MP157x
Arm Cortex-M4 core
Description
The Cortex-A7 processor implements the ARM Virtualization Extensions and the ARM Security Extensions.
Exceptions can be routed to Monitor mode by setting SCR.{EA, FIQ, IRQ} to 1. Exceptions can be masked by
setting corresponding bit CPSR.{A, I, F} to 1.
The ARMv7-A architecture states that an exception taken in Hyp mode does not change the value of the mask
bits for exceptions routed to Monitor mode. However, because of this erratum, the corresponding mask bits will be
cleared to 0.
The error occurs when the following conditions are met:
1. One or more exception types are routed to Monitor mode by setting one or more of SCR.{EA, FIQ, IRQ} to 1.
2. The corresponding exception types are masked by setting the corresponding CPSR.{A, F, I} bits to 1.
3. Any exception is taken in Hyp mode.
If the above conditions are met then the exception mask bit CPSR.{A, F, I} is cleared to 0 for each exception type
that meets conditions (1) and (2). The affected mask bits are cleared together regardless of the exception type in
condition (3).
The implications of this erratum are:
• If SCR.{AW, FW} is set to 0 then the clearing of corresponding bit CPSR.{A, F} to 0 has no effect. The value
of CPSR.{A, F} is ignored.
• Otherwise, when CPSR.{A, F, I} is set to 1, Secure code cannot rely on CPSR.{A, F, I} remaining set to 1. An
exception that should be masked might be routed to Monitor mode.
The impact of this limitation is considered to be minor as it is expected that the users will:
1. set SCR.{AW, FW} to 0 when SCR.{EA, FIQ} is set to 1.
2. set SCR.IRQ to 0.
Workaround
None.
2.2
Arm Cortex-M4 core
Errata notice for the Arm® Cortex®-M4 core revision r0p1 is available from http://infocenter.arm.com.
2.2.1 Interrupted loads to SP can cause erroneous behavior
This limitation is registered under Arm ID number 752770 and classified into “Category B”. Its impact to the device
is minor.
Description
If an interrupt occurs during the data-phase of a single word load to the stack-pointer (SP/R13), erroneous
behavior can occur. In all cases, returning from the interrupt will result in the load instruction being executed an
additional time. For all instructions performing an update to the base register, the base register will be erroneously
updated on each execution, resulting in the stack-pointer being loaded from an incorrect memory location.
The affected instructions that can result in the load transaction being repeated are:
• LDR SP, [Rn],#imm
• LDR SP, [Rn,#imm]!
• LDR SP, [Rn,#imm]
• LDR SP, [Rn]
• LDR SP, [Rn,Rm]
The affected instructions that can result in the stack-pointer being loaded from an incorrect memory address are:
• LDR SP,[Rn],#imm
• LDR SP,[Rn,#imm]!
As compilers do not generate these particular instructions, the limitation is only likely to occur with hand-written
assembly code.
ES0438 - Rev 6
page 9/45
STM32MP151x STM32MP153x STM32MP157x
Arm Cortex-M4 core
Workaround
Both issues may be worked around by replacing the direct load to the stack-pointer, with an intermediate load to a
general-purpose register followed by a move to the stack-pointer.
2.2.2 VDIV or VSQRT instructions might not complete correctly when very short ISRs are used
This limitation is registered under Arm ID number 776924 and classified into “Category B”. Its impact to the device
is limited.
Description
The VDIV and VSQRT instructions take 14 cycles to execute. When an interrupt is taken a VDIV or VSQRT
instruction is not terminated, and completes its execution while the interrupt stacking occurs. If lazy context save
of floating point state is enabled then the automatic stacking of the floating point context does not occur until a
floating point instruction is executed inside the interrupt service routine.
Lazy context save is enabled by default. When it is enabled, the minimum time for the first instruction in the
interrupt service routine to start executing is 12 cycles. In certain timing conditions, and if there is only one or two
instructions inside the interrupt service routine, then the VDIV or VSQRT instruction might not write its result to the
register bank or to the FPSCR.
The failure occurs when the following condition is met:
1. The floating point unit is enabled
2. Lazy context saving is not disabled
3. A VDIV or VSQRT is executed
4. The destination register for the VDIV or VSQRT is one of s0 - s15
5. An interrupt occurs and is taken
6. The interrupt service routine being executed does not contain a floating point instruction
7. Within 14 cycles after the VDIV or VSQRT is executed, an interrupt return is executed
A minimum of 12 of these 14 cycles are utilized for the context state stacking, which leaves 2 cycles for
instructions inside the interrupt service routine, or 2 wait states applied to the entire stacking sequence (which
means that it is not a constant wait state for every access).
In general, this means that if the memory system inserts wait states for stack transactions (that is, external
memory is used for stack data), then this erratum cannot be observed.
The effect of this erratum is that the VDIV or VQSRT instruction does not complete correctly and the register bank
and FPSCR are not updated, which means that these registers hold incorrect, out of date, data.
Workaround
A workaround is only required if the floating point unit is enabled. A workaround is not required if the stack is in
external memory.
There are two possible workarounds:
• Disable lazy context save of floating point state by clearing LSPEN to 0 (bit 30 of the FPCCR at address
0xE000EF34).
• Ensure that every interrupt service routine contains more than 2 instructions in addition to the exception
return instruction.
2.2.3 Store immediate overlapping exception return operation might vector to incorrect interrupt
This limitation is registered under Arm ID number 838869 and classified into “Category B (rare)”. Its impact to the
device is minor.
Description
The core includes a write buffer that permits execution to continue while a store is waiting on the bus. Under
specific timing conditions, during an exception return while this buffer is still in use by a store instruction, a late
change in selection of the next interrupt to be taken might result in there being a mismatch between the interrupt
acknowledged by the interrupt controller and the vector fetched by the processor.
ES0438 - Rev 6
page 10/45
STM32MP151x STM32MP153x STM32MP157x
System
The failure occurs when the following condition is met:
1. The handler for interrupt A is being executed.
2. Interrupt B, of the same or lower priority than interrupt A, is pending.
3. A store with immediate offset instruction is executed to a bufferable location.
– STR/STRH/STRB <Rt>, [<Rn>,#imm]
– STR/STRH/STRB <Rt>, [<Rn>,#imm]!
– STR/STRH/STRB <Rt>, [<Rn>],#imm
4. Any number of additional data-processing instructions can be executed.
5. A BX instruction is executed that causes an exception return.
6. The store data has wait states applied to it such that the data is accepted at least two cycles after the BX is
executed.
– Minimally, this is two cycles if the store and the BX instruction have no additional instructions between
them.
– The number of wait states required to observe this erratum needs to be increased by the number of
cycles between the store and the interrupt service routine exit instruction.
7. Before the bus accepts the buffered store data, another interrupt C is asserted which has the same or lower
priority as A, but a greater priority than B.
Example:
The processor should execute interrupt handler C, and on completion of handler C should execute the handler
for B. If the conditions above are met, then this erratum results in the processor erroneously clearing the pending
state of interrupt C, and then executing the handler for B twice. The first time the handler for B is executed it
will be at interrupt C's priority level. If interrupt C is pended by a level-based interrupt which is cleared by C's
handler then interrupt C will be pended again once the handler for B has completed and the handler for C will be
executed.
As the STM32 interrupt C is level based, it eventually becomes pending again and is subsequently handled.
Workaround
For software not using the memory protection unit, this erratum can be worked around by setting DISDEFWBUF
in the Auxiliary Control Register.
In all other cases, the erratum can be avoided by ensuring a DSB occurs between the store and the BX
instruction. For exception handlers written in C, this can be achieved by inserting the appropriate set of intrinsics
or inline assembly just before the end of the interrupt function, for example:
ARMCC:
...
__schedule_barrier();
__asm{DSB};
__schedule_barrier();
}
GCC:
...
__asm volatile ("dsb 0xf":::"memory");
}
2.3
System
2.3.1 TPIU fails to output sync after the pattern generator is disabled in Normal mode
ES0438 - Rev 6
Description
The TPIU includes a pattern generator that can be used by external tool to determine the operating behavior of
the trace port and timing characteristics. This pattern generator includes a mode that transmits the test pattern for
a specified number of cycles, and then reverts to transmitting normal trace data.
page 11/45
STM32MP151x STM32MP153x STM32MP157x
System
When the TPIU is configured to operate in Normal mode (FFCR.EnFCont=0), the synchronization sequence that
is required between the test pattern and the trace data is not generated. Synchronization will be generated at a
later time, as determined by the synchronization counter.
Conditions:
The following conditions must all occur:
• The TPIU is configured in normal mode, FFCR.EnFCont==0
• The TPIU is configured with the formatter enabled, FFCR.EnFTC==1
• The pattern generator is enabled in timed mode, Current_test_pattern_mode.PTIMEEN==1
Implications:
The timed mode of the TPIU is intended to permit the TPIU to transition between an initial synchronization
sequence using the pattern generator and functional mode without any further programming intervention. If the
synchronization sequence is not generated at the end of the test pattern, the trace port analyzer is unlikely to
be able to capture the start of the trace stream correctly. Synchronization will be correctly inserted based on the
value configured in the FSCR, once the specified number of frames of trace data have been output.
Workaround
Workaround requires software interaction to detect the completion of the test pattern sequence. In addition,
any trace data present at the input to the TPIU is lost whilst the pattern generator is active. Any trace data
present in the input to the TPIU before the formatter is re-enabled (and synchronization generated) will not be
de-compressible.
1. After enabling the pattern generator, set FFCR.StopOnFl==1 and FFCR.FOnMan==1.
2. Poll FFSR.FtStopped until 1 is read
3. Set FFCR.EnFTC==1
2.3.2 Serial-wire multi-drop debug not supported
Description
The target instance bitfield TINSTANCE[3:0] of the DP_DLPIDR debug port data link protocol identification
register is frozen to 0, which prevents the debug of multiple instances of the same function connected on same
SWD bus.
Workaround
None.
2.3.3 HSE external oscillator required in some LTDC use cases
Description
Due to capacitive load on the LTDC pins, the LTDC used at high or very high speed (OSPEEDR ≥ 1) may impact
the on-chip HSE crystal oscillator clock, which then could lead to a deterioration of USB HS eye diagram.
Note: This does not apply when the LTDC is internally connected to the DSI host, even at high clock frequencies up to
90 MHz, as it does not drive pins.
Workaround
If using the USB HS interface, avoid using the on‑chip HSE oscillator in the use cases summarized in the table.
Instead, get the clock from an external oscillator connected to the HSE pins, as indicated in the table (mandatory
or recommended).
ES0438 - Rev 6
page 12/45
STM32MP151x STM32MP153x STM32MP157x
Table 5. Use of external oscillator on HSE pins
System
LTDC connected to Conditions
3 V < VDD< 3.6 V
f
up to 74.25 MHz (1280x720 at 60 fps)
pixel
OSPEEDR = 1 for all LTDC signals
USB HS used
HDMI bridge close to
HDMI bridge
Parallel LCD load < 30 pf
the device
load ~15 pf
1.7 V < VDD< 2 V
f
up to 74.25 MHz
pixel
Duty cycle = 40 %
0.1 VDD < VIN < 0.9 V
OSPEEDR = 3 for LCD_CLK
OSPEEDR = 2 for all other LTDC signals
3 V < VDD< 3.6 V
f
up to 90 MHz (1366x768 at 60 fps)
pixel
OSPEEDR = 2 for LCD_CLK
OSPEEDR = 1 for all other LTDC signals
USB HS used
3 V < VDD< 3.6 V
f
up to 48 MHz (800x600 at 60 fps)
pixel
OSPEEDR = 1 for LCD_CLK
OSPEEDR = 0 for all other LTDC signals
1.7 V < VDD< 2 V
f
up to 69 MHz (1024x768 at 60 fps)
pixel
Duty cycle = 40 %
0.1 VDD < VIN < 0.9 V
OSPEEDR = 3 for LCD_CLK
OSPEEDR = 2 for all other LTDC signals
External oscillator on
HSE
Mandatory
Recommended
DD
Mandatory
Recommended
DD
2.3.4 RCC cannot exit Stop and LP-Stop modes
Description
When trying to exit Stop or LP-Stop mode, the handshake mechanism between PWRCTRL and RCC can be
wrong due to a too short internal state within the RCC state machine. In extreme case, the PWRCTRL does not
see the RCC signal, thus causing the whole system going to Stop or LP-Stop mode again, respectively.
Workaround
Set the PWRLP_DLY[21:0] bitfield of the RCC_PWRLPDLYCR register to a value equal to or greater than 0x4.
Note: This register is designed to handle LP-Stop mode, but it can also be used in the present case for Stop mode.
2.3.5 Incorrect reset of glitch-free kernel clock switch
Description
The activation of NRST (by external signal, internal watchdog or software) may not properly reset the glitch-free
clock switches inside the RCC.
ES0438 - Rev 6
page 13/45
STM32MP151x STM32MP153x STM32MP157x
As a consequence, the peripheral kernel clock previously used by the application remains selected. If not enabled
again (by default or by SW), there is no kernel clock present on the related peripheral and the BootROM hangs.
Note: USB boot is usually not affected as the application always uses the same clocking scheme depending on
HSE crystal frequency choice. For example, there is no issue for HSE = 24 MHz as hse_ker_ck is used for
OTG clocking. Other peripherals, such as LPTIM, USART, and I2C, should work without care if the previous
application clock is enabled again to ensure that the clock switch is not stuck.
Workaround
Use one of the following measures:
1. By hardware, ensure that the V
DDCORE
– With STPMIC1
By default, a power cycle on VDDCORE (and VDD) is issued upon activating NRST.
– Without STPMIC1
Connect NRST to NRST_CORE (in case VDD is below 2.745V, connection should be done using a
capacitor with a value of 1/10th of the capacitor value present between NRST and GND, ensure also
that potential capacitors between NRST_CORE to GND are removed).
The drawback is that, the debug logic also being reset, it is not possible to debug the boot chain (TF-A and
U-Boot) as any breakpoints set are lost during the power cycle or NRST_CORE activation.
2.
By software:
– For interfaces required during boot, whether Flash memory peripherals (SDMMC1/2, QUADSPI, or
FMC) or USART/UART (USART2/3/6 or UART4/5/7/8), use the same clock as the one used during the
BootROM execution:
◦ If BOOT[2:0] = 000 or 110 (UART boot), set UARTxxSRC[2:0] to 0 (pclk) or 2 (hsi_ker_ck), for all
UART instances not disabled via uart_intances_disabled bitfield of the BSEC OTP WORD 3.
◦ If BOOT[2:0] = 001 or 111 (QUADSPI boot), set QSPISRC[2:0] to 0 (aclk) or 3 (per_ck).
◦ If BOOT[2:0] = 010 or 101 (SDMMC boot), set SDMMC12SRC[2:0] to 0 (hclk6) or 3 (hsi_ker_ck).
– For SD card, the use of HSI (64 MHz) causes raw bandwidth performance penalty as only 32 or
64 MHz could be used instead of respectively 50 MHz (SDR25/DDR50) and 100 MHz (SDR50)
– For eMMC, the use of HSI (64 MHz) causes raw bandwidth performance penalty as only 32 or 64 MHz
could be used instead of respectively 52 MHz (SDR/DDR) or over 100 MHz (HS200). Note that hclk6/
hclk5/aclk are limited to 200 MHz when hclk6 is used as SDMMC1/SDMMC2 kernel clock
◦ If BOOT[2:0] = 011 (FMC boot), set FMCSRC[2:0] to 0 (aclk) or 3 (per_ck)
logic is reset on NRST activation:
System
2.3.6 Limitation of aclk/hclk5/hclk6 to 200 MHz when used as SDMMC1/2 kernel clock
Description
The SDMMC1 and SDMMC2 kernel clock is limited to 200 MHz whereas hclk6 maximum frequency is 266 MHz.
As a consequence, when SDMMC12SRC[2:0] = 0 (hclk6), the AXI bus clock (aclk), AHB5 bus clock (hclk5), and
AHB6 bus clock (hclk6) cannot exceed 200 MHz.
Workaround
Apply one of the following measures:
• When SDMMC12SRC[2:0] = 0, limit aclk/hclk5/hclk6 to 200 MHz.
• Use another SDMMC1/SDMMC2 kernel clock source, that is, set SDMMC12SRC[2:0] to 1, 2, or 3.
2.3.7 Overconsumption in Standby with on‑board 1.8 V regulator bypassed
Description
The device directly supplied from 1.8 V applied on the VDDA1V8_REG pin (with the on-board regulator bypassed
by connecting BYPASS_REG1V8 to VDD) exhibits an overconsumption of about 900 µA in Standby mode (with
the V
DDCORE
VDDA1V8_REG pin.
supply shutdown) or when NRST_CORE is active, due to an excessive leakage through the
ES0438 - Rev 6
page 14/45
Workaround
Shut the VDDA1V8_REG pin supply down during Standby, either using a power switch between VDD and
VDDA1V8_REG pins or a dedicated voltage regulator with shutdown command connected to an OR combination
(for example using diodes) of PWR_ON and NRST signals.
2.3.8 eMMC boot timeout too short
Description
Direct boot from eMMC device (BootROM code execution directly followed by eMMC boot code execution) may
fail, due to eMMC timeout detected during the BootROM code execution, causing a fallback to serial/USB boot
selection.
The issue occurs if after the reset command (CMD0 followed with 0xF0F0F0F0), the JESD84-B51 boot operation
(CMD kept low for over 74 clock cycles), and ACK receipt, the eMMC device does not respond with boot partition
data within 10 ms (time allowed by the BootROM code).
Workaround
For direct boot, use an eMMC device that meets the required timing. Consult the eMMC device vendor
if it is necessary for assessing the robustness of the solution with their eMMC. As an indication, Toshiba
THGBMNG5D1LBAIL, THGBMDG5D1LBAIL, and Kingston EMMC04G-M627-X03U (all 4 Gbyte devices) appear
to operate correctly on the STM32MP157C-EV1 board.
Alternatively, use another kind of Flash memory device, such as SD-card, serial-NOR, serial-NAND, or SLCNAND, to house a part of the boot code to execute directly after the BootROM code, and to be followed by a
second part of the boot code housed in the eMMC device.
STM32MP151x STM32MP153x STM32MP157x
System
2.3.9 Cortex-M4 cannot use I/O compensation on Standby mode exit
Description
As the CSION bit of the RCC_OCENSETR register is secured upon exiting Standby mode, the Cortex-M4 core
cannot enable the CSI oscillator required for activating the I/O compensation function and thus for enabling
high-speed I/O operation of Cortex-M4 peripherals. The Cortex-A7 secure core can set the CSION bit but it is not
systematically woken up upon exiting Standby mode.
Workaround
For I/Os of Cortex-M4 peripherals required on Standby exit and until CSI is started by the Cortex-A7 core, only
use IOSPEEDR[1:0] settings 00 and 01 (as they do not require I/O compensation).
2.3.10 Missed wake-up events in CSTANDBY
Description
While the Cortex‑A7 core is in CSTANDBY mode, WWDG (EXTI event 68) or Cortex‑M4 reset (EXTI event
73) wake‑up event may cause the RCC state to change faster than the state of PWR. As a consequence, the
Cortex‑A7 core does not wake up.
Workaround
None.
2.3.11 SSCG option is not available on PLL3 and PLL4
ES0438 - Rev 6
Description
Some reference manual revisions may omit the information that the spread-spectrum clock generation feature is
not available on PLL3 and PLL4. The bits RCC_PLL3CR and RCC_PLL4CR of the SSCG_CTRL register must be
kept at zero. The registers RCC_PLL3CSGR and RCC_PLL4CSGR must not be used.
page 15/45
STM32MP151x STM32MP153x STM32MP157x
This is a documentation issue rather than a device limitation.
Workaround
Assuming that this instruction is followed, no application workaround is required.
2.3.12 RCC security settings for Cortex-M4 access are not kept upon wake up from Standby
Description
When the Cortex-M4 core wakes up from Standby, the TZEN and MCKPROT bits of the RCC_TZCR register
are set high as by default, regardless their previous settings upon entering Standby. Until the Cortex-A7 core is
started, the operation of the device is limited as follows:
• Some RCC settings are not accessible.
• None of HSE, CSI, LSI, and PLL3 can be started.
• The only possible Cortex-M4 core clock source is HSI (64MHz).
• The only possible per_clk is HSI.
• HSI cannot be set to keep running when Cortex-M4 core goes in CSTOP. (The HSIKERON bit is not
accessible.)
• Peripherals secured by default cannot be accessed by the Cortex-M4 core.
• Only PLL4 on HSI is usable for peripherals having a PLL output as clock source option.
System
Workaround
None.
2.3.13 Wakeup pin flags cleared at Standby mode exit with MCU_BEN high and MPU_BEN low
Description
Upon Standby mode exit while the MCU_BEN bit is high and the MPU_BEN bit low, all wakeup flags in the
PWR_WKUPFR register are unduly cleared, which prevents the detectability of the wakeup source.
Workaround
None.
2.3.14 Boundary scan data unduly sampled on TCK falling edge
Description
In Boundary scan mode, the TDI input is sampled on the falling edge of TCK, which is contrary to the IEEE1149.1
requirements and to the device JTAG timing specifications. Depending on the timing of the signal received on the
TDI input, this leads to a risk of data corruption/shift. Other JTAG or SWD modes, such as debug, are exempt of
this limitation. The TDO timing is not affected, either.
Workaround
Ensure that the input signal on the TDI pin holds for at least 1 ns after the TCK falling edge.
Note: The BSDL description file provided takes into account this design issue and adds a dummy cycle.
2.3.15 Boundary scan SAMPLE/PRELOAD behavior not compliant with IEE1149.1
Description
IEEE1149.1 expects the SAMPLE/PRELOAD instruction to be non-invasive. In the device however, it behaves
as an EXTEST instruction, instead. This potentially causes the scanned pins to toggle to levels unsafe from the
application perspective.
ES0438 - Rev 6
page 16/45
STM32MP151x STM32MP153x STM32MP157x
Workaround
Do not use SAMPLE/PRELOAD instruction. Instead, use the specific CUSTOM_HIGHZ instruction (00011) that
allows safe sampling of the pins, by setting them into high-Z state during the sampling phase.
Note: During the board reset phase (for example during the power-up, when NRST is driven low), all the scannable
pins are set to high-Z state. This requires a safe board design ensuring defined pin levels where applicable, for
example through the use of pull-up or pull-down resistors.
2.3.16 Boot with a specific combination of NAND Flash memories fails
Description
The boot process fails in the following configuration:
• SLC NAND Flash memory on FMC is set as the primary boot source (OTP WORD3[29:27] = 001).
• An SLC NAND Flash memory is present and empty (or with only corrupted binary headers).
• Serial NAND Flash memory is set as secondary boot source (OTP WORD3[26:24] = 101).
Workaround
None.
System
2.3.17 Boot with 1-bit error correction on SLC NAND Flash memory fails
Description
With an SLC NAND Flash memory with 1-bit Hamming ECC (either ONFI-compliant Flash memory or 1-bit
Hamming ECC set via the OTP WORD9), connected through the FMC, the BootROM code unduly reads the
three Hamming 1-bit ECC bytes in a reverse order with respect to their programming order. As a result, the ECC
signals data corruption and the boot systematically fails.
Workaround
Apply one of the following measures:
• In the OTP WORD9, set the fmc_ecc_bit_nb[2:0] bitfield to 010 (BCH4) instead to 001 (Hamming). Set all
the other bitfields in accordance with the parameters of the SLC NAND Flash memory used.
• Program the three ECC bytes of the SLC NAND Flash memory spare array in the reverse order.
Caution: If applied to a device version not impacted by the issue, the latter measure causes the boot process to fail.
2.3.18 Boot fails if eMMC does not answer the first command
Description
If an eMMC does not answer (for example, because it is not yet powered) the first command sent to CMD line, the
boot routine remains in an infinite loop with no timeout, which causes the boot process to fail.
Workaround
None.
2.3.19 DLYB limits SDMMC throughput
Description
When DLYB is used SDMMC could exhibit FIFO underrun or overrun due to internal resynchronization and
buffering limitation. This is seen on eMMC HS200 mode, on SD-Card SDR50, and SDR104 mode.
ES0438 - Rev 6
page 17/45
Workaround
Do not use DLYB. With eMMC, use up to DDR mode (52 MHz clock, 104 MBytes/s), with SD-Card, use up to
DDR50 (50 MHz clock, 50 MBytes/s).
2.3.20 LSE CSS cannot be used in VBAT state
Description
Under certain circumstances, switching VSW from VDD to VBAT and vice-versa, could falsely trigger the LSE
CSS. This would stop the RTC clock, generate false tamper detection and result in the unwanted deletion of the
BKPSRAM or Backup REG.
Workaround
Do not enable LSE CSS when VBAT mode is planned to be used.
2.3.21 Wrong value in Coresight M4 ROM table
Description
CM4ROM_PIDR4 and CM4ROM_PIDR0 ROM tables are wrongly defined to 0x04 and 0x50 respectively whereas
they should be set to 0x05 and 0x00 respectively. This only impacts the debugging tools which normally identify
the target using this ROM table.
STM32MP151x STM32MP153x STM32MP157x
DDRPHYC
Workaround
Use DBGMCU_IDC to identify the device.
2.4
DDRPHYC
2.4.1 DDRPHYC overconsumption upon reset or Standby mode exit
Description
Upon reset and upon Standby mode exit, DDRPHY DLLs are not properly disabled, which leads to leakage on
the DDR_ZQ pin causing excessive consumption from V
usage, the consumption becomes as specified and remains as specified during Stop modes.
There is no DDRPHYC overconsumption in Standby mode.
Workaround
Prevent the leakage on the DDR_ZQ pin, by first enabling DDRPHYC in the RCC, then setting the ZQPD bit of
the DDRPHYC_ZQ0CR0 register.
DDCORE
. Once DDRPHYC is initialized for normal DDR
2.4.2 DDR_CLK jitter out of JEDEC requirement for 32-bit LPDDR2/LPDDR3 at low device Tj
Description
At extreme low junction temperatures close to -40°C, the JEDEC JESD209-2B and JESD209-3F (for LPDDR2
and LPDDR3, resp.) maximum allowed jitter specification t
when operating with 32-bit LPDDR2 or LPDDR3 memory devices, despite respecting the design rules as per the
AN5122 application note and despite optimizing the PCB routing for signal integrity.
of ±90 ps at 533 MHz may not be respected
JIT(per)
ES0438 - Rev 6
page 18/45
STM32MP151x STM32MP153x STM32MP157x
GPIO
Workaround
Use one of the following measures or their combination:
• Increase V
• Increase the drive output impedance Z0 to 53 Ω, by setting the ZPROG[3:0] bitfield of the
DDRPHYC_ZQ0CR1 register to 0x8.
DDQ_DDR/VDD2/VDDQ/VDDCA
2.4.3 Data corruption at low device Tj combined with low 32-bit LPDDR2/LPDDR3 I/O supply voltage
Description
Very low device junction temperature (such as below -20°C) increases the risk of data corruption for accesses
to 32-bit LPDDR2/LPDDR3 memory with low I/O supply voltage (V
less. The lower the device junction temperature and the memory I/O supply voltage, the higher the risk.
Note: The use of 16-bit LPDDR2/LPDDR3 memory devices prevents the issue.
Workaround
Ensure that the operating conditions of the end volume product are never worse, in terms of the device
junction temperature and the LPDDR2/LPDDR3 memory I/O supply voltage, than the conditions applied in the
(successful) product engineering and qualification stages. In particular, ensure that the memory I/O supply voltage
always exceeds 1.2 V. Alternatively, use a 16-bit LPDDR2/LPDDR3 memory device.
memory I/O supply (to, for example, 1.25 V).
DDQ_DDR/VDD2/VDDQ/VDDCA
), such as 1.2 V or
2.5 GPIO
2.5.1 GPIO assigned to DAC cannot be used in output mode when the DAC output is connected to
on-chip peripheral
Description
When a DAC output is connected only to an on-chip peripheral, the corresponding GPIO is expected to be
available as an output for any other functions.
However, when the DAC output is configured for on-chip peripheral connection only, the GPIO output buffer
remains disabled and cannot be used in output mode (GPIO or alternate function). It can still be used in input or
analog mode.
This limitation applies to DAC1_OUT1 and DAC1_OUT2 connected to PA4 and PA5, respectively.
Workaround
None.
2.6 DMA
2.6.1 USART/UART/LPUART DMA transfer abort
Description
Some reference manual revisions may unduly present the bit 20 (TRBUFF in the corrected revisions) of the
DMA_SxCR register as reserved, to be kept at reset value (low). This bit must be set to ensure the completion
of USART/UART/LPUART DMA transfer when another DMA transfer is requested concurrently. Otherwise, it may
occur that the other DMA transfer request is not served and that it leads to aborting the ongoing USART/UART/
LPUART DMA transfer.
This is a documentation issue rather than a device limitation.
ES0438 - Rev 6
page 19/45
STM32MP151x STM32MP153x STM32MP157x
Workaround
No application workaround is required if the TRBUFF bit is used as indicated.
2.7 DMAMUX
2.7.1 SOFx not asserted when writing into DMAMUX_CFR register
Description
The SOFx flag of the DMAMUX_CSR status register is not asserted if overrun from another DMAMUX channel
occurs when the software writes into the DMAMUX_CFR register.
This can happen when multiple DMA channels operate in synchronization mode, and when overrun can occur
from more than one channel. As the SOFx flag clear requires a write into the DMAMUX_CFR register (to set
the corresponding CSOFx bit), overrun occurring from another DMAMUX channel operating during that write
operation fails to raise its corresponding SOFx flag.
Workaround
None. Avoid the use of synchronization mode for concurrent DMAMUX channels, if at least two of them potentially
generate synchronization overrun.
DMAMUX
2.7.2 OFx not asserted for trigger event coinciding with last DMAMUX request
Description
In the DMAMUX request generator, a trigger event detected in a critical instant of the last-generated DMAMUX
request being served by the DMA controller does not assert the corresponding trigger overrun flag OFx. The
critical instant is the clock cycle at the very end of the trigger overrun condition.
Additionally, upon the following trigger event, one single DMA request is issued by the DMAMUX request
generator, regardless of the programmed number of DMA requests to generate.
The failure only occurs if the number of requests to generate is set to more than two (GNBREQ[4:0] > 00001).
Workaround
Make the trigger period longer than the duration required for serving the programmed number of DMA requests,
so as to avoid the trigger overrun condition from occurring on the very last DMA data transfer.
2.7.3 OFx not asserted when writing into DMAMUX_RGCFR register
Description
The OFx flag of the DMAMUX_RGSR status register is not asserted if an overrun from another DMAMUX request
generator channel occurs when the software writes into the DMAMUX_RGCFR register. This can happen when
multiple DMA channels operate with the DMAMUX request generator, and when an overrun can occur from more
than one request generator channel. As the OFx flag clear requires a write into the DMAMUX_RGCFR register
(to set the corresponding COFx bit), an overrun occurring in another DMAMUX channel operating with another
request generator channel during that write operation fails to raise the corresponding OFx flag.
ES0438 - Rev 6
Workaround
None. Avoid the use of request generator mode for concurrent DMAMUX channels, if at least two channels are
potentially generating a request generator overrun.
page 20/45
STM32MP151x STM32MP153x STM32MP157x
QUADSPI
2.7.4 Wrong input DMA request routed upon specific DMAMUX_CxCR register write coinciding with
synchronization event
Description
If a write access into the DMAMUX_CxCR register having the SE bit at zero and SPOL[1:0] bitfield at a value
other than 00:
• sets the SE bit (enables synchronization),
• modifies the values of the DMAREQ_ID[5:0] and SYNC_ID[4:0] bitfields, and
• does not modify the SPOL[1:0] bitfield,
and if a synchronization event occurs on the previously selected synchronization input exactly two AHB clock
cycles before this DMAMUX_CxCR write, then the input DMA request selected by the DMAREQ_ID[5:0] value
before that write is routed.
Workaround
Ensure that the SPOL[1:0] bitfield is at 00 whenever the SE bit is 0. When enabling synchronization by setting
the SE bit, always set the SPOL[1:0] bitfield to a value other than 00 with the same write operation into the
DMAMUX_CxCR register.
2.8 QUADSPI
2.8.1 Memory-mapped read of last memory byte fails
Description
Regardless of the number of I/O lines used (1, 2 or 4), a memory-mapped read of the last byte of the memory
region defined through the FSIZE[4:0] bitfield of the QUADSPI_DCR register always yields 0x00, whatever the
memory byte content is. A repeated attempt to read that last byte causes the AXI bus to stall.
Workaround
Apply one of the following measures:
• Avoid reading the last byte of the memory region defined through FSIZE, for example by taking margin in
FSIZE bitfield setting.
• If the last byte is read, ignore its value and abort the ongoing process so as to prevent the AXI bus from
stalling.
• For reading the last byte of the memory region defined through FSIZE, use indirect read.
2.9 ADC
2.9.1 New context conversion initiated without waiting for trigger when writing new context in
ADC_JSQR with JQDIS = 0 and JQM = 0
Description
Once an injected conversion sequence is complete, the queue is consumed and the context changes according to
the new ADC_JSQR parameters stored in the queue. This new context is applied for the next injected sequence
of conversions.
However, the programming of the new context in ADC_JSQR (change of injected trigger selection and/or trigger
polarity) may launch the execution of this context without waiting for the trigger if:
• the queue of context is enabled (JQDIS cleared to 0 in ADC_CFGR), and
• the queue is never empty (JQM cleared to 0 in ADC_CFGR), and
• the injected conversion sequence is complete and no conversion from previous context is ongoing
ES0438 - Rev 6
page 21/45
STM32MP151x STM32MP153x STM32MP157x
Workaround
Apply one of the following measures:
• Ignore the first conversion.
• Use a queue of context with JQM = 1.
• Use a queue of context with JQM = 0, only change the conversion sequence but never the trigger selection
and the polarity.
2.9.2 Two consecutive context conversions fail when writing new context in ADC_JSQR just after
previous context completion with JQDIS = 0 and JQM = 0
Description
When an injected conversion sequence is complete and the queue is consumed, writing a new context in
ADC_JSQR just after the completion of the previous context and with a length longer that the previous context,
may cause both contexts to fail. The two contexts are considered as one single context. As an example, if the first
context contains element 1 and the second context elements 2 and 3, the first context is consumed followed by
elements 2 and 3 and element 1 is not executed.
This issue may happen if:
• the queue of context is enabled (JQDIS cleared to 0 in ADC_CFGR), and
• the queue is never empty (JQM cleared to 0 in ADC_CFGR), and
• the length of the new context is longer than the previous one
ADC
Workaround
If possible, synchronize the writing of the new context with the reception of the new trigger.
2.9.3 Unexpected regular conversion when two consecutive injected conversions are performed in
Dual interleaved mode
Description
In Dual ADC mode, an unexpected regular conversion may start at the end of the second injected conversion
without a regular trigger being received, if the second injected conversion starts exactly at the same time than the
end of the first injected conversion. This issue may happen in the following conditions:
• two consecutive injected conversions performed in Interleaved simultaneous mode (DUAL[4:0] of
ADC_CCR = 0b00011), or
• two consecutive injected conversions from master or slave ADC performed in Interleaved mode
(DUAL[4:0]of ADC_CCR = 0b00111)
Workaround
• In Interleaved simultaneous injected mode: make sure the time between two injected conversion triggers is
longer than the injected conversion time.
• In Interleaved only mode: perform injected conversions from one single ADC (master or slave), making sure
the time between two injected triggers is longer than the injected conversion time.
2.9.4 ADC_AWDy_OUT reset by non-guarded channels
ES0438 - Rev 6
Description
ADC_AWDy_OUT is set when a guarded conversion of a regular or injected channel is outside the programmed
thresholds. It is reset after the end of the next guarded conversion that is inside the programmed thresholds.
However, the ADC_AWDy_OUT signal is also reset at the end of conversion of non-guarded channels, both
regular and injected.
page 22/45
STM32MP151x STM32MP153x STM32MP157x
Workaround
When ADC_AWDy_OUT is enabled, it is recommended to use only the ADC channels that are guarded by a
watchdog.
If ADC_AWDy_OUT is used with ADC channels that are not guarded by a watchdog, take only ADC_AWDy_OUT
rising edge into account.
2.9.5 ADC ANA0/ANA1 resolution limited when Gigabit Ethernet is used
Description
The following ADC1 and ADC2 input pins might be impacted by adjacent PA0 and PG13 activity when used for
ETH in Gigabit mode.
Workaround
16-bit and 14-bit data resolutions are not recommended on these pins when Gigabit Ethernet is used. This limits
data resolution configuration to 8 bits, 10 bits or 12 bits.
2.9.6 ADC missing codes in differential 16-bit static acquisition
In differential mode, static signal acquisition shows missing codes in 16-bit mode. Dynamic signal acquisition is
not affected as the energy of missing codes is negligible.
DAC
Workaround
In applications where missing codes matter, avoid using 16-bit data resolutions on static acquisition.
2.10 DAC
2.10.1 Invalid DAC channel analog output if the DAC channel MODE bitfield is programmed before
DAC initialization
Description
When the DAC operates in Normal mode and the DAC enable bit is cleared, writing a value different from 000
to the DAC channel MODE bitfield of the DAC_MCR register before performing data initialization causes the
corresponding DAC channel analog output to be invalid.
Workaround
Apply the following sequence:
1. Perform one write access to any data register.
2. Program the MODE bitfield of the DAC_MCR register.
2.10.2 DMA underrun flag not set when an internal trigger is detected on the clock cycle of the DMA
request acknowledge
Description
ES0438 - Rev 6
When the DAC channel operates in DMA mode (DMAEN of DAC_CR register set), the DMA channel underrun
flag (DMAUDR of DAC_SR register) fails to rise upon an internal trigger detection if that detection occurs during
the same clock cycle as a DMA request acknowledge. As a result, the user application is not informed that an
underrun error occurred.
This issue occurs when software and hardware triggers are used concurrently to trigger DMA transfers.
Workaround
None.
page 23/45
2.11 VREFBUF
2.11.1 VREFBUF Hold mode cannot be used
Description
VREFBUF can be configured to operate in Hold mode to reduce current consumption.
When VREFBUF enters Hold mode (by setting both HIZ and ENVR bits of the VREFBUF_CSR register), the
VREF+ I/O transits to high impedance mode. If not discharged externally, the capacitor on the VREF+ pin keeps
its charge and voltage. Exiting VREFBUF Hold mode (by clearing the HIZ bit) in this condition might lead to a
voltage overshoot on the VREF+ output.
Workaround
None.
2.11.2 Overshoot on VREFBUF output
Description
An overshoot might occur on VREFBUF output if VREF+ pin has residual voltage when VREFBUF is enabled
(ENVR is set in VREFBUF_CSR register).
STM32MP151x STM32MP153x STM32MP157x
VREFBUF
Workaround
2.12
Let the voltage on the VREF+ pin drop to 1 V under the target V
VREFBUF buffer off (ENVR is cleared and HIZ is cleared in VREFBUF_CSR register) allowing sufficient time to
discharge the capacitor on the VREF+ pin through the VREFBUF pull-down resistor.
REFBUF_OUT
DTS
. This can be achieved by switching
2.12.1 Mode using PCLK & LSE (REFCLK_SEL = 1) should not be used
Description
The DTS cannot be used with PCLK enabled while REFCLK is set to LSE (REFCLK_SEL = 1).
Workaround
Only use mode with REFCLK = PCLK (REFCLK_SEL = 0).
2.13
DSI
2.13.1 DSI PHY compliant with MIPI DPHY v0.81 specification, not with DSI PHY v1.0
Description
The DSI PHY does not comply with the DSI PHY v1.0 specification. Instead, it operates in compliance with the
MIPI DPHY v0.81 specification.
ES0438 - Rev 6
Workaround
None.
page 24/45
STM32MP151x STM32MP153x STM32MP157x
HASH
2.14 HASH
2.14.1 Superseded suspend sequence for data loaded by DMA
Description
The section HASH / Context swapping / Data loaded by DMA / Current context saving of some reference manual
revisions may suggest the following suspend sequence for using HASH with DMA:
1. Clear the DMAE bit to disable the DMA interface.
2. Wait until the current DMA transfer is complete (wait for DMAS = 0 in the HASH_SR register).
This recommendation is obsolete and superseded with the following sequence that suspends then resumes the
secure digest computing in order to swap the context:
Suspend:
1. In Polling mode, wait for BUSY = 0. If the DCIS bit of the HASH_SR register is set, the hash result is
available and the context swapping is useless. Otherwise, go to step 2.
2. In Polling mode, wait for BUSY = 1.
3. Disable the DMA channel. Then clear the DMAE bit of the HASH_CR register.
4. In Polling mode, wait for BUSY = 0. If the DCIS bit of the HASH_SR register is set, the hash result is
available and the context swapping is useless. Otherwise, go to step 5.
5. Save the HASH_IMR, HASH_STR, HASH_CR, and HASH_CSR0 to HASH_CSR37 registers. The
HASH_CSR38 to HASH_CSR53 registers must also be saved if an HMAC operation is ongoing.
Resume:
1. Reconfigure the DMA controller so that it proceeds with the transfer of the message up to the end if it is not
interrupted again. Do not forget to take into account the words already pushed into the FIFO if NBW[3:0] is
higher than 0x0.
2. Program the values saved in memory to the HASH_IMR, HASH_STR, and HASH_CR registers.
3. Initialize the hash processor by setting the INIT bit of the HASH_CR register.
4. Program the values saved in memory to the HASH_CSRx registers.
5. Restart the processing from the point of interruption, by setting the DMAE bit.
Note: To optimize the resume process when NBW[3:0] = 0x0, HASH_CSR22 to HASH_CSR37 registers do not need
to be saved then restored as the FIFO is empty.
This is a documentation issue rather than a product limitation.
Workaround
No application workaround is required as long as the new sequence is applied.
2.14.2 Superseded suspend sequence for data loaded by the CPU
Description
The section HASH / Context swapping / Data loaded by software of some reference manual revisions may
instruct that “the user application must wait until DINIS ≠ 1 (last block processed and input FIFO empty) or NBW 0
(FIFO not full and no processing ongoing)”.
This instruction is obsolete and superseded with the following:
When the DMA is not used to load the message into the hash processor, the context can be saved only when no
block processing is ongoing.
To suspend the processing of a message, proceed as follows after writing 16 words 32-bit (plus one if it is the first
block):
1. In Polling mode, wait for BUSY = 0, then poll if the DINIS status bit is set to 1. In Interrupt mode, implement
the next step in DINIS interrupt handler (recommended).
ES0438 - Rev 6
page 25/45
STM32MP151x STM32MP153x STM32MP157x
2. Store the contents of the following registers into memory:
– HASH_IMR
– HASH_STR
– HASH_CR
– HASH_CSR0 to HASH_CSR37 and, if an HMAC operation is ongoing, also HASH_CSR38 to
HASH_CSR53
To resume the processing of a message, proceed as follows:
1. Write the HASH_IMR, HASH_STR, and HASH_CR registers with the values saved in memory.
2. Initialize the hash processor by setting the INIT bit of the HASH_CR register.
3. Write the HASH_CSRx registers with the values saved in memory.
4. Restart the processing from the point of interruption.
Note: To optimize the resume process when NBW[3:0]=0x0, HASH_CSR22 to HASH_CSR37 registers do not need to
be saved then restored as the FIFO is empty.
This is a documentation issue rather than a product limitation.
Workaround
No application workaround is required as long as the new sequence is applied.
TIM
2.15 TIM
2.15.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration
Description
The failure occurs when several timers configured in one-pulse mode are cascaded, and the master timer is
configured in combined reset + trigger mode with the MSM bit set:
OPM = 1 in TIMx_CR1, SMS[3:0] = 1000 and MSM = 1 in TIMx_SMCR.
The MSM delays the reaction of the master timer to the trigger event, so as to have the slave timers cycleaccurately synchronized.
If the trigger arrives when the counter value is equal to the period value set in the TIMx_ARR register, the
one-pulse mode of the master timer does not work and no pulse is generated on the output.
Workaround
None. However, unless a cycle-level synchronization is mandatory, it is advised to keep the MSM bit reset, in
which case the problem is not present. The MSM = 0 configuration also allows decreasing the timer latency to
external trigger events.
2.15.2 Consecutive compare event missed in specific conditions
Description
Every match of the counter (CNT) value with the compare register (CCR) value is expected to trigger a compare
event. However, if such matches occur in two consecutive counter clock cycles (as consequence of the CCR
value change between the two cycles), the second compare event is missed for the following CCR value
changes:
in edge-aligned mode, from ARR to 0:
•
– first compare event: CNT = CCR = ARR
– second (missed) compare event: CNT = CCR = 0
•
in center-aligned mode while up-counting, from ARR-1 to ARR (possibly a new ARR value if the period is
also changed) at the crest (that is, when TIMx_RCR = 0):
– first compare event: CNT = CCR = (ARR-1)
– second (missed) compare event: CNT = CCR = ARR
ES0438 - Rev 6
page 26/45
STM32MP151x STM32MP153x STM32MP157x
• in center-aligned mode while down-counting, from 1 to 0 at the valley (that is, when TIMx_RCR = 0):
– first compare event: CNT = CCR = 1
– second (missed) compare event: CNT = CCR = 0
This typically corresponds to an abrupt change of compare value aiming at creating a timer clock single-cyclewide pulse in toggle mode.
As a consequence:
• In toggle mode, the output only toggles once per counter period (squared waveform), whereas it is expected
to toggle twice within two consecutive counter cycles (and so exhibit a short pulse per counter period).
• In center mode, the compare interrupt flag does note rise and the interrupt is not generated.
Note: The timer output operates as expected in modes other than the toggle mode.
Workaround
None.
2.15.3 Output compare clear not working with external counter reset
Description
The output compare clear event (ocref_clr) is not correctly generated when the timer is configured in the following
slave modes: Reset mode, Combined reset + trigger mode, and Combined gated + reset mode.
The PWM output remains inactive during one extra PWM cycle if the following sequence occurs:
1. The output is cleared by the ocref_clr event.
2. The timer reset occurs before the programmed compare event.
LPTIM
Workaround
Apply one of the following measures:
• Use BKIN (or BKIN2 if available) input for clearing the output, selecting the Automatic output enable mode
(AOE = 1).
• Mask the timer reset during the PWM ON time to prevent it from occurring before the compare event (for
example with a spare timer compare channel open-drain output connected with the reset signal, pulling the
timer reset line down).
2.16 LPTIM
2.16.1 Device may remain stuck in LPTIM interrupt when entering Stop mode
Description
This limitation occurs when disabling the low-power timer (LPTIM).
When the user application clears the ENABLE bit in the LPTIM_CR register within a small time window around
one LPTIM interrupt occurrence, then the LPTIM interrupt signal used to wake up the device from Stop mode may
be frozen in active state. Consequently, when trying to enter Stop mode, this limitation prevents the device from
entering low-power mode and the firmware remains stuck in the LPTIM interrupt routine.
This limitation applies to all Stop modes and to all instances of the LPTIM. Note that the occurrence of this issue
is very low.
Workaround
ES0438 - Rev 6
In order to disable a low power timer (LPTIMx) peripheral, do not clear its ENABLE bit in its respective LPTIM_CR
register. Instead, reset the whole LPTIMx peripheral via the RCC controller by setting and resetting its respective
LPTIMxRST bit in RCC_APByRSTRz register.
page 27/45
STM32MP151x STM32MP153x STM32MP157x
2.16.2 Device may remain stuck in LPTIM interrupt when clearing event flag
Description
This limitation occurs when the LPTIM is configured in interrupt mode (at least one interrupt is enabled) and
the software clears any flag in LPTIM_ISR register by writing its corresponding bit in LPTIM_ICR register. If the
interrupt status flag corresponding to a disabled interrupt is cleared simultaneously with a new event detection,
the set and clear commands might reach the APB domain at the same time, leading to an asynchronous interrupt
signal permanently stuck high.
This issue can occur either during an interrupt subroutine execution (where the flag clearing is usually done), or
outside an interrupt subroutine.
Consequently, the firmware remains stuck in the LPTIM interrupt routine, and the device cannot enter Stop mode.
Workaround
To avoid this issue, it is strongly advised to follow the recommendations listed below:
• Clear the flag only when its corresponding interrupt is enabled in the interrupt enable register.
• If for specific reasons, it is required to clear some flags that have corresponding interrupt lines disabled in
the interrupt enable register, it is recommended to clear them during the current subroutine prior to those
which have corresponding interrupt line enabled in the interrupt enable register.
• Flags must not be cleared outside the interrupt subroutine.
Note: The proper clear sequence is already implemented in the HAL_LPTIM_IRQHandler in the STM32Cube.
LPTIM
2.16.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle
Description
The compare match event (CMPM), auto reload match event (ARRM), PWM output level and interrupts are
updated with a delay of one kernel clock cycle.
Consequently, it is not possible to generate PWM with a duty cycle of 0% or 100%.
The following waveform gives the example of PWM output mode and the effect of the delay:
LPTIM_ARR 0x0A
LPTIM_CMP 0x06
LPTIM_CNT
PWM output
0x05 0x06 0x07 0x08 0x09 0x0A 0x00 0x01 0x02
CMPM = 1
ARRM = 1
ES0438 - Rev 6
Workaround
Set the compare value to the desired value minus 1. For instance in order to generate a compare match when
LPTM_CNT = 0x08, set the compare value to 0x07.
page 28/45
STM32MP151x STM32MP153x STM32MP157x
2.17 RTC and TAMP
2.17.1 Incorrect version register
Description
The RTC_VERR and the TAMP_VERR registers do not provide the correct IP revision information.
Workaround
None.
2.17.2 Calendar initialization may fail in case of consecutive INIT mode entry
Description
If the INIT bit of the RTC_ICSR register is set between one and two RTCCLK cycles after being cleared, the
INITF flag is set immediately instead of waiting for synchronization delay (which should be between one and two
RTCCLK cycles), and the initialization of registers may fail. Depending on the INIT bit clearing and setting instants
versus the RTCCLK edges, it can happen that, after being immediately set, the INITF flag is cleared during one
RTCCLK period then set again. As writes to calendar registers are ignored when INITF is low, a write occurring
during this critical period might result in the corruption of one or more calendar registers.
RTC and TAMP
Workaround
After existing the initialization mode, clear the BYPSHAD bit (if set) then wait for RSF to rise, before entering the
initialization mode again.
Note: It is recommended to write all registers in a single initialization session to avoid accumulating synchronization
delays.
2.17.3 Alarm flag may be repeatedly set when the core is stopped in debug
Description
When the core is stopped in debug mode, the clock is supplied to subsecond RTC alarm downcounter even
though the device is configured to stop the RTC in debug.
As a consequence, when the subsecond counter is used for alarm condition (the MASKSS[3:0] bitfield of the
RTC_ALRMASSR and/or RTC_ALRMBSSR register set to a non-zero value) and the alarm condition is met just
before entering a breakpoint or printf, the ALRAF and/or ALRBF flag of the RTC_SR register is repeatedly set by
hardware during the breakpoint or printf, which makes any tentative to clear the flag(s) ineffective.
Workaround
None.
2.17.4 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles
after clearing TSF
Description
ES0438 - Rev 6
With the timestamp on tamper event enabled (TAMPTS bit of the RTC_CR register set), a tamper event is ignored
if it occurs:
• within four APB clock cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, while
the TSF flag is not yet effectively cleared (it fails to set the TSOVF flag)
• within two ck_apre cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, when the
TSF flag is effectively cleared (it fails to set the TSF flag and timestamp the calendar registers)
Workaround
None.
page 29/45
STM32MP151x STM32MP153x STM32MP157x
2.17.5 REFCKON write protection associated to INIT KEY instead of CAL KEY
Description
The write protection of the REFCKON bit is unlocked if the key sequence is written in RTC_WPR with the
privilege and security rights set by the INITPRIV and INITSEC bits, instead of being set by the CALPRIV and
CALSEC bits.
Workaround
Unlock the INIT KEY before writing REFCKON.
2.17.6 Tamper flag not set on LSE failure detection
Description
With the timestamp on tamper event enabled (the TAMPTS bit of the RTC_CR register set), the LSE failure
detection (LSE clock stopped) event connected to the internal tamper 3 fails to raise the ITAMP3F and ITAMP3MF
flags, although it duly erases or blocks (depending on the internal tamper 3 configuration) the backup registers
and other device secrets, and the RTC and TAMP peripherals resume normally upon the LSE restart.
Note: As expected in this particular case, the TSF and TSMF flags remain low as long as LSE is stopped as they
require running RTCCLK clock to operate.
I2C
Workaround
None.
2.18 I2C
2.18.1 Wrong data sampling when data setup time (t
Description
The I2C-bus specification and user manual specify a minimum data setup time (t
• 250 ns in Standard mode
• 100 ns in Fast mode
• 50 ns in Fast mode Plus
The device does not correctly sample the I2C-bus SDA line when t
(I2C-bus peripheral clock) period: the previous SDA value is sampled instead of the current one. This can result in
a wrong receipt of slave address, data byte, or acknowledge bit.
Workaround
Increase the I2C kernel clock frequency to get I2C kernel clock period within the transmitter minimum data setup
time. Alternatively, increase transmitter’s minimum data setup time. If the transmitter setup time minimum value
corresponds to the minimum value provided in the I2C-bus standard, the minimum I2CCLK frequencies are as
follows:
• In Standard mode, if the transmitter minimum setup time is 250 ns, the I2CCLK frequency must be at least
4 MHz.
• In Fast mode, if the transmitter minimum setup time is 100 ns, the I2CCLK frequency must be at least
10 MHz.
• In Fast-mode Plus, if the transmitter minimum setup time is 50 ns, the I2CCLK frequency must be at least
20 MHz.
) is shorter than one I2C kernel clock period
SU;DAT
) as:
SU;DAT
is smaller than one I2C kernel clock
SU;DAT
ES0438 - Rev 6
page 30/45
STM32MP151x STM32MP153x STM32MP157x
2.18.2 Spurious bus error detection in master mode
Description
In master mode, a bus error can be detected spuriously, with the consequence of setting the BERR flag of the
I2C_SR register and generating bus error interrupt if such interrupt is enabled. Detection of bus error has no effect
on the I2C-bus transfer in master mode and any such transfer continues normally.
Workaround
If a bus error interrupt is generated in master mode, the BERR flag must be cleared by software. No other action
is required and the ongoing transfer can be handled normally.
2.18.3 Spurious master transfer upon own slave address match
Description
When the device is configured to operate at the same time as master and slave (in a multi- master I2C-bus
application), a spurious master transfer may occur under the following condition:
• Another master on the bus is in process of sending the slave address of the device (the bus is busy).
• The device initiates a master transfer by bit set before the slave address match event (the ADDR flag set in
the I2C_ISR register) occurs.
• After the ADDR flag is set:
– the device does not write I2C_CR2 before clearing the ADDR flag, or
– the device writes I2C_CR2 earlier than three I2C kernel clock cycles before clearing the ADDR flag
In these circumstances, even though the START bit is automatically cleared by the circuitry handling the ADDR
flag, the device spuriously proceeds to the master transfer as soon as the bus becomes free. The transfer
configuration depends on the content of the I2C_CR2 register when the master transfer starts. Moreover, if the
I2C_CR2 is written less than three kernel clocks before the ADDR flag is cleared, the I2C peripheral may fall into
an unpredictable state.
I2C
Workaround
Upon the address match event (ADDR flag set), apply the following sequence.
Normal mode (SBC = 0):
1. Set the ADDRCF bit.
2. Before Stop condition occurs on the bus, write I2C_CR2 with the START bit low.
Slave byte control mode (SBC = 1):
1. Write I2C_CR2 with the slave transfer configuration and the START bit low.
2. Wait for longer than three I2C kernel clock cycles.
3. Set the ADDRCF bit.
4. Before Stop condition occurs on the bus, write I2C_CR2 again with its current value.
The time for the software application to write the I2C_CR2 register before the Stop condition is limited, as the
clock stretching (if enabled), is aborted when clearing the ADDR flag.
Polling the BUSY flag before requesting the master transfer is not a reliable workaround as the bus may become
busy between the BUSY flag check and the write into the I2C_CR2 register with the START bit set.
2.18.4 OVR flag not set in underrun condition
Description
In slave transmission with clock stretching disabled (NOSTRETCH = 1 in the I2C_CR1 register), an underrun
condition occurs if the current byte transmission is completed on the I2C bus, and the next data is not yet written
in the TXDATA[7:0] bitfield. In this condition, the device is expected to set the OVR flag of the I2C_ISR register
and send 0xFF on the bus.
ES0438 - Rev 6
page 31/45
STM32MP151x STM32MP153x STM32MP157x
However, if the I2C_TXDR is written within the interval between two I2C kernel clock cycles before and three APB
clock cycles after the start of the next data transmission, the OVR flag is not set, although the transmitted value is
0xFF.
Workaround
None.
2.18.5 Transmission stalled after first byte transfer
Description
When the first byte to transmit is not prepared in the TXDATA register, two bytes are required successively,
through TXIS status flag setting or through a DMA request. If the first of the two bytes is written in the I2C_TXDR
register in less than two I2C kernel clock cycles after the TXIS/DMA request, and the ratio between APB clock
and I2C kernel clock frequencies is between 1.5 and 3, the second byte written in the I2C_TXDR is not internally
detected. This causes a state in which the I2C peripheral is stalled in master mode or in slave mode, with clock
stretching enabled (NOSTRETCH = 0). This state can only be released by disabling the peripheral (PE = 0) or by
resetting it.
Workaround
Apply one of the following measures:
• Write the first data in I2C_TXDR before the transmission starts.
• Set the APB clock frequency so that its ratio with respect to the I2C kernel clock frequency is lower than 1.5
or higher than 3.
USART
2.19 USART
2.19.1 Anticipated end-of-transmission signaling in SPI slave mode
Description
In SPI slave mode, at low USART baud rate with respect to the USART kernel and APB clock frequencies, the
transmission complete flag TC of the USARTx_ISR register may unduly be set before the last bit is shifted on the
transmit line.
This leads to data corruption if, based on this anticipated end-of-transmission signaling, the application disables
the peripheral before the last bit is transmitted.
Workaround
Upon the TC flag rise, wait until the clock line remains idle for more than the half of the communication clock
cycle. Then only consider the transmission as ended.
2.19.2 Data corruption due to noisy receive line
Description
In UART mode with oversampling by 8 or 16 and with 1 or 2 stop bits, the received data may be corrupted if a
glitch to zero shorter than the half-bit occurs on the receive line within the second half of the stop bit.
Workaround
None.
ES0438 - Rev 6
page 32/45
STM32MP151x STM32MP153x STM32MP157x
2.20 SPI
2.20.1 Master data transfer stall at system clock much faster than SCK
Description
With the system clock (spi_pclk) substantially faster than SCK (spi_ker_ck divided by a prescaler), SPI master
data transfer can stall upon setting the CSTART bit within one SCK cycle after the EOT event (EOT flag raise)
signaling the end of the previous transfer.
Workaround
Apply one of the following measures:
• Disable then enable SPI after each EOT event.
• Upon EOT event, wait for at least one SCK cycle before setting CSTART.
• Prevent EOT events from occurring, by setting transfer size to undefined (TSIZE = 0) and by triggering
transmission exclusively by TXFIFO writes.
2.20.2 Corrupted CRC return at non-zero UDRDET setting
Description
SPI
With non-zero setting of UDRDET[1:0] bitfield, the SPI slave can transmit the first bit of CRC pattern corrupted,
coming wrongly from the UDRCFG register instead of SPI_TXCRC. All other CRC bits come from the
SPI_TXCRC register, as expected.
Workaround
Keep TXFIFO non-empty at the end of transfer.
2.20.3 TXP interrupt occurring while SPI disabled
Description
SPI peripheral is set to its default state when disabled (SPE = 0). This flushes the FIFO buffers and resets their
occupancy flags. TXP and TXC flags become set (the latter if the TSIZE field contains zero value), triggering
interrupt if enabled with TXPIE or EOTIE bit, respectively. The resulting interrupt service can be spurious if it
tries to write data into TXFIFO to clear the TXP and TXC flags, while both FIFO buffers are inaccessible (as the
peripheral is disabled).
Workaround
Keep TXP and TXC (the latter if the TSIZE field contains zero value) interrupt disabled whenever the SPI
peripheral is disabled.
2.20.4 Possible corruption of last-received data depending on CRCSIZE setting
Description
ES0438 - Rev 6
With the CRC calculation disabled (CRCEN = 0), the transfer size bitfield set to a value greater than zero
(TSIZE[15:0] > 0), and the length of CRC frame set to less than 8 bits (CRCSIZE[4:0] < 00111), the last data
received in the RxFIFO may be corrupted.
Workaround
Keep the CRCSIZE[4:0] bitfield at its default setting (00111) during the data reception if CRCEN = 0 and
TSIZE[15:0] > 0.
page 33/45
STM32MP151x STM32MP153x STM32MP157x
2.21 FDCAN
2.21.1 Desynchronization under specific condition with edge filtering enabled
Description
FDCAN may desynchronize and incorrectly receive the first bit of the frame if:
• the edge filtering is enabled (the EFBI bit of the FDCAN_CCCR register is set), and
• the end of the integration phase coincides with a falling edge detected on the FDCAN_Rx input pin
If this occurs, the CRC detects that the first bit of the received frame is incorrect, flags the received frame as faulty
and responds with an error frame.
Note: This issue does not affect the reception of standard frames.
Workaround
Disable edge filtering or wait for frame retransmission.
2.21.2 Tx FIFO messages inverted under specific buffer usage and priority setting
Description
FDCAN
Two consecutive messages from the Tx FIFO may be inverted in the transmit sequence if:
• FDCAN uses both a dedicated Tx buffer and a Tx FIFO (the TFQM bit of the FDCAN_TXBC register is
cleared), and
• the messages contained in the Tx buffer have a higher internal CAN priority than the messages in the Tx
FIFO.
Workaround
Apply one of the following measures:
• Ensure that only one Tx FIFO element is pending for transmission at any time:
The Tx FIFO elements may be filled at any time with messages to be transmitted, but their transmission
requests are handled separately. Each time a Tx FIFO transmission has completed and the Tx FIFO gets
empty (TFE bit of FDACN_IR set to 1) the next Tx FIFO element is requested.
• Use only a Tx FIFO:
Send both messages from a Tx FIFO, including the message with the higher priority. This message has to
wait until the preceding messages in the Tx FIFO have been sent.
• Use two dedicated Tx buffers (for example, use Tx buffer 4 and 5 instead of the Tx FIFO). The following
pseudo-code replaces the function in charge of filling the Tx FIFO:
Write message to Tx Buffer 4
Transmit Loop:
Request Tx Buffer 4 - write AR4 bit in FDCAN_TXBAR
Write message to Tx Buffer 5
Wait until transmission of Tx Buffer 4 complete (IR bit in FDCAN_IR),
read TO4 bit in FDCAN_TXBTO
Request Tx Buffer 5 - write AR5 bit of FDCAN_TXBAR
Write message to Tx Buffer 4
Wait until transmission of Tx Buffer 5 complete (IR bit in FDCAN_IR),
read TO5 bit in FDCAN_TXBTO
2.21.3 DAR mode transmission failure due to lost arbitration
Description
In DAR mode, the transmission may fail due to lost arbitration at the first two identifier bits.
ES0438 - Rev 6
page 34/45
STM32MP151x STM32MP153x STM32MP157x
OTG_HS
Workaround
Upon failure, clear the corresponding Tx buffer transmission request bit TRPx of the FDCAN_TXBRP register and
set the corresponding cancellation finished bit CFx of the FDCAN_TXBCF register, then restart the transmission.
2.22 OTG_HS
2.22.1 Host packet transmission may hang when connecting through a hub to a low-speed device
Description
When the USB on-the-go high-speed peripheral connects to a low-speed device via a hub, the transmitter internal
state machine may hang. This leads, after a timeout expiry, to a port disconnect interrupt.
Workaround
None. However, increasing the capacitance on the data lines may reduce the occurrence.
2.23
ETH
2.23.1 Incorrect L4 inverse filtering results for corrupted packets
Description
Received corrupted IP packets with payload (for IPv4) or total (IPv6) length of less than two bytes for L4 source
port (SP) filtering or less than four bytes for L4 destination port (DP) filtering are expected to cause a mismatch.
However, the inverse filtering unduly flags a match and the corrupted packets are forwarded to the software
application. The L4 stack gets incomplete packet and drops it.
Note: The perfect filtering correctly reports a mismatch.
Workaround
None.
2.23.2 Rx DMA may fail to recover upon DMA restart following a bus error, with Rx timestamping
enabled
Description
When the timestamping of Rx packets is enabled, some or all of the received packets can have Rx timestamp
which is written into a descriptor upon the completion of the Rx packet/status transfer.
However, due to a defect, when bus error occurs during the descriptor read (that is subsequently used as context
descriptor to update the Rx timestamp), the context descriptor write is skipped by DMA. Also, Rx DMA does
not flush the Rx timestamp stored in the intermediate buffers during the error recovery process and enters Stop
state. Due to this residual timestamp in the intermediate buffer, Rx DMA, after being restarted, does not transfer
packets.
Workaround
Issue a soft reset to drop all Tx packets and Rx packets present inside the controller at the time of bus error. After
the soft reset, reconfigure the controller and re-create the descriptors.
Note: The workaround introduces additional latency.
ES0438 - Rev 6
page 35/45
STM32MP151x STM32MP153x STM32MP157x
2.23.3 Spurious receive watchdog timeout interrupt
Description
Setting the RWTU[1:0] bitfield of the ETH_DMAC0RXIWTR register to a non-zero value while the RWT[7:0]
bitfield is at zero leads to a spurious receive watchdog timeout interrupt (if enabled) and, as a consequence, to
executing an unnecessary interrupt service routine with no packets to process.
Workaround
Ensure that the RWTU[1:0] bitfield is not set to a non-zero value while the RWT[7:0] bitfield is at zero. For setting
RWT[7:0] and RWTU[1:0] bitfields each to a non-zero value, perform two successive writes. The first is either a
byte-wide write to the byte containing the RWT[7:0] bitfield, or a 32-bit write that only sets the RWT[7:0] bitfield
and keeps the RWTU[1:0] bitfield at zero. The second is either a byte-wide write to the RWTU[1:0] bitfield or a
32-bit write that sets the RWTU[1:0] bitfield while keeping the RWT[7:0] bitfield unchanged.
2.23.4 Incorrect flexible PPS output interval under specific conditions
Description
The use of the fine correction method for correcting the IEEE 1588 internal time reference, combined with a large
frequency drift of the driving clock from the grandmaster source clock, leads to an incorrect interval of the flexible
PPS output used in Pulse train mode. As a consequence, external devices synchronized with the flexible PPS
output of the device can go out of synchronization.
ETH
Workaround
Use the coarse method for correcting the IEEE 1588 internal time reference.
2.23.5 Packets dropped in RMII 10Mbps mode due to fake dribble and CRC error
Description
When operating with the RMII interface at 10 Mbps, the Ethernet peripheral may generate a fake extra nibble of
data repeating the last packet (nibble) of the data received from the PHY interface. This results in an odd number
of nibbles and is flagged as a dribble error. As the RMII only forwards to the system completed bytes of data,
the fake nibble would be ignored and the issue would have no consequence. However, as the CRC error is also
flagged when this occurs, the error-packet drop mechanism (if enabled) discards the packets.
Note: Real dribble errors are rare. They may result from synchronization issues due to faulty clock recovery.
Workaround
When using the RMII 10 MHz mode, disable the error-packet drop mechanism by setting the FEP bit of the
ETH_MTLRXQ0OMR or ETH_MTLRXQ1OMR register. Accept packets of transactions flagging both dribble and
CRC errors.
2.23.6 ARP offload function not effective
Description
When the Target Protocol Address of a received ARP request packet matches the device IP address set in the
ETH_MACARPAR register, the source MAC address in the SHA field of the ARP request packet is compared with
the device MAC address in ETH_MACA0LR and ETH_MACA0HR registers (Address0), to filter out ARP packets
that are looping back.
Instead, a byte-swapped comparison is performed by the device. As a consequence, the packet is forwarded to
the application as a normal packet with no ARP indication in the packet status, and the device does not generate
an ARP response.
For example, with the Address0 set to 0x665544332211:
• If the SHA field of the received ARP packet is 0x665544332211, the ARP response is generated while it
should not.
ES0438 - Rev 6
page 36/45
STM32MP151x STM32MP153x STM32MP157x
• If the SHA field of the received ARP packet is 0x112233445566, the ARP response not is generated while it
should.
Workaround
Parse the received frame by software and send the ARP response if the source MAC address matches the
byte-swapped Address0.
2.23.7 Slight imbalance of AV traffic CBS bandwidth allocation
Description
When a queue is enabled for AV traffic (TXQEN[1:0] = 10 in ETH_ MTLTXQ0OMR or ETH_ MTLTXQ1OMR
register) and CBS algorithm selected (AVALG = 1 and CC = 0 in the ETH_MTLTXQ1ECR register), the expected
behavior is as follows:
• A queue is eligible for transmission when its credit is positive. Higher credit gives more chance for a queue
to be served.
• Credit of any non-empty pending (not currently served) queue is incremented at a programmable rate during
the data transmission from another queue.
• Credit of the queue transmitting data is decremented at a programmable rate.
• Credit of any empty queue is nullified.
However, during the transmission from one queue, pending empty queues unduly keep their credits, instead of
being nullified.
As a consequence, when an empty queue with undue non-zero credit receives data to transmit, it has a slightly
higher chance to be served and thus wins more continuous bandwidth than expected from the CBS algorithm
specification.
This non-conformity is negligible with most applications.
ETH
Workaround
None.
2.23.8 Spurious checksum error upon MTL pending Tx queue flush
Description
Transmit checksum engine signals packet transmission errors via IHE (IP header error) and PCE (payload
checksum error) flags.
When a flush of a pending (not currently served) MTL Tx FIFO queue 0 or 1 is initiated (by setting the FTQ bit
of the ETH_MTLTXQ0OMR or ETH_MTLTXQ1OMR register, respectively), the MTL sends a dummy Tx status
indicating the flushed packets. The checksum engine is expected to ignore this dummy Tx status.
However, when multiple transmit queues with checksum offload engines are enabled and the drop Tx status
disabled (DTXSTS = 0 in the ETH_MTLOMR register), the checksum engine unduly takes into account the
dummy Tx status. The MAC Tx status of the packet under transmission then returns zeros in its checksum field,
instead of the due value.
As a consequence, the checksum engine may spuriously signal transmission error for the packet under
transmission and for the following packet.
Note: The defect is expected to have no impact to the user application as the checksum error flags are intended for
debug purposes only.
Workaround
None.
ES0438 - Rev 6
page 37/45
STM32MP151x STM32MP153x STM32MP157x
2.23.9 Bus error coinciding with start-of-packet corrupts MAC-generated packet transmission
Description
A bus error coinciding with the start of a new packet unduly aborts the transmission of any internally MACgenerated packet (ARP, PTO, Pause). As a consequence, the packet is sent on the line as a runt frame with
corrupted FCS.
The aborted packet is not retransmitted and can cause:
• flow control failure in case of Pause/PFC packet corruption
• delay in ARP handshake from ARP offload engine (the ARP stack recovers because it sends ARP requests
periodically)
• delay in PTP response/SYNC packets generated by the PTP offload engine (the PTP stack recovers
because it sends request packets periodically)
The occurrence rate of this failure is very low.
Workaround
None.
2.23.10 DMA spurious state upon AXI DMA slave bus error
ETH
Description
Normally, upon an AXI DMA slave bus error, the ETH controller triggers a fatal bus error interrupt (by setting the
FBE bit of the ETH_DMACSR register) and stops the corresponding DMA channel by clearing the ST bit of the
ETH_DMAC0TXCR or ETH_DMAC1TXCR register. The software can then recreate the list of descriptors and
restart the Tx DMA channel (set the ST bit).
However, in the following cases, the DMA controller fails to recover from the bus error or it corrupts the TSO/USO
header data:
• when the bus error occurs for a packet transfer initiated by a Tx DMA channel 1 and the OSF bit of the
ETH_DMAC0TXCR or ETH_DMAC1TXCR register is set
• when the TSO/USO segmentation is enabled in the Tx descriptor
Workaround
Reset and reconfigure the ETH controller by software, then re-create the descriptors. This restores the normal
DMA controller operation, although it causes the loss of all latent Tx and Rx packets in the ETH controller and
adds processing latency.
ES0438 - Rev 6
page 38/45
Revision history
STM32MP151x STM32MP153x STM32MP157x
Table 6. Document revision history
Date Version Changes
1-Feb-2019 1 Initial release.
Added errata in Section 1 Summary of device errata and
Section 2 Description of device errata:
• Overconsumption in Standby with on‑board 1.8 V regulator bypassed
• eMMC boot timeout too short
• Cortex-M4 cannot use I/O compensation on Standby mode exit
• Missed wake-up events in CSTANDBY
• DDR_CLK jitter out of JEDEC requirement for 32-bit LPDDR2/LPDDR3
at low device Tj
• Data corruption at low device Tj combined with low 32-bit LPDDR2/
LPDDR3 I/O supply voltage
17-Sep-2019 2
25-Nov-2019 3
21-Jan-2020 4
• Invalid DAC channel analog output if the DAC channel MODE bitfield is
programmed before DAC initialization
• DMA underrun flag not set when an internal trigger is detected on the
clock cycle of the DMA request acknowledge
• OVR flag not set in underrun condition
• Transmission stalled after first byte transfer
• Possible corruption of last-received data depending on CRCSIZE
setting
• Desynchronization under specific condition with edge filtering enabled
• Tx FIFO messages inverted under specific buffer usage and priority
setting
• DAR mode transmission failure due to lost arbitration
Added:
• Table 4. Summary of device documentation errata
• SSCG option is not available on PLL3 and PLL4 erratum
in Table 4. Summary of device documentation errata and
Section 2 Description of device errata
Added errata in Section 1 Summary of device errata and
Section 2 Description of device errata:
• RCC security settings for Cortex-M4 access are not kept upon wake up
from Standby
• GPIO assigned to DAC cannot be used in output mode when the DAC
output is connected to on-chip peripheral
• Wakeup pin flags cleared at Standby mode exit with MCU_BEN high
and MPU_BEN low
• Boundary scan data unduly sampled on TCK falling edge
• Boundary scan SAMPLE/PRELOAD behavior not compliant with
IEE1149.1
• New context conversion initiated without waiting for trigger when writing
new context in ADC_JSQR with JQDIS = 0 and JQM = 0
• Two consecutive context conversions fail when writing new context in
ADC_JSQR just after previous context completion with JQDIS = 0 and
JQM = 0
• Unexpected regular conversion when two consecutive injected
conversions are performed in Dual interleaved mode
• Consecutive compare event missed in specific conditions
• Output compare clear not working with external counter reset
• Anticipated end-of-transmission signaling in SPI slave mode
• Data corruption due to noisy receive line
• Host packet transmission may hang when connecting through a hub to
a low-speed device
ES0438 - Rev 6
page 39/45
STM32MP151x STM32MP153x STM32MP157x
Date Version Changes
Added silicon revision Z.
Added errata in Section 1 Summary of device errata and
Section 2 Description of device errata:
• Boot with a specific combination of NAND Flash memories fails
• Boot with 1-bit error correction on SLC NAND Flash memory fails
• Boot fails if eMMC does not answer the first command
• VREFBUF Hold mode cannot be used
28-Apr-2020 5
24-Feb-2021 6
• Overshoot on VREFBUF output
• Superseded suspend sequence for data loaded by DMA
• Superseded suspend sequence for data loaded by the CPU
• A tamper event fails to trigger timestamp or timestamp overflow events
during a few cycles after clearing TSF
• REFCKON write protection associated to INIT KEY instead of CAL KEY
• Tamper flag not set on LSE failure detection
Added errata in Section 1 Summary of device errata and
Section 2 Description of device errata:
• DLYB limits SDMMC throughput
• USART/UART/LPUART DMA transfer abort
• LSE CSS cannot be used in VBAT state
• Wrong value in Coresight M4 ROM table
• ADC_AWDy_OUT reset by non-guarded channels
• USART/UART/LPUART DMA transfer abort
• LPTIM events and PWM output are delayed by 1 kernel clock cycle
• Slight imbalance of AV traffic CBS bandwidth allocation
• Spurious checksum error upon MTL pending Tx queue flush
• Bus error coinciding with start-of-packet corrupts MAC-generated
packet transmission
• DMA spurious state upon AXI DMA slave bus error
Modified:
• Incorrect reset of glitch-free kernel clock switch
Removed:
• Tx DMA may halt while fetching TSO header under specific conditions
ES0438 - Rev 6
page 40/45
STM32MP151x STM32MP153x STM32MP157x
Contents
Contents
1 Summary of device errata..........................................................2
2 Description of device errata........................................................6
2.1 Arm Cortex-A7 core ............................................................6
2.1.1 Memory locations might be accessed speculatively due to instruction fetches when
HCR.VM is set ..........................................................6
2.1.2 Cache maintenance by set/way operations can execute out of order .................6
2.1.3 PMU events 0x07, 0x0C, and 0x0E do not increment correctly ......................7
2.1.4 PMU event counter 0x14 does not increment correctly ............................8
2.1.5 Exception mask bits are cleared when an exception is taken in Hyp mode .............8
2.2 Arm Cortex-M4 core ............................................................9
2.2.1 Interrupted loads to SP can cause erroneous behavior ............................9
2.2.2 VDIV or VSQRT instructions might not complete correctly when very short ISRs are used 10
2.2.3 Store immediate overlapping exception return operation might vector to incorrect interrupt .
.....................................................................10
2.3 System ......................................................................11
2.3.1 TPIU fails to output sync after the pattern generator is disabled in Normal mode ....... 11
2.3.2 Serial-wire multi-drop debug not supported ....................................12
2.3.3 HSE external oscillator required in some LTDC use cases ........................12
2.3.4 RCC cannot exit Stop and LP-Stop modes ....................................13
2.3.5 Incorrect reset of glitch-free kernel clock switch ................................13
2.3.6 Limitation of aclk/hclk5/hclk6 to 200 MHz when used as SDMMC1/2 kernel clock ......14
2.3.7 Overconsumption in Standby with on‑board 1.8 V regulator bypassed ...............14
2.3.8 eMMC boot timeout too short ..............................................15
2.3.9 Cortex-M4 cannot use I/O compensation on Standby mode exit ....................15
2.3.10 Missed wake-up events in CSTANDBY .......................................15
2.3.11 SSCG option is not available on PLL3 and PLL4 ...............................15
ES0438 - Rev 6
2.3.12 RCC security settings for Cortex-M4 access are not kept upon wake up from Standby...16
2.3.13 Wakeup pin flags cleared at Standby mode exit with MCU_BEN high and MPU_BEN low 16
2.3.14 Boundary scan data unduly sampled on TCK falling edge ........................16
2.3.15 Boundary scan SAMPLE/PRELOAD behavior not compliant with IEE1149.1 ..........16
2.3.16 Boot with a specific combination of NAND Flash memories fails ....................17
2.3.17 Boot with 1-bit error correction on SLC NAND Flash memory fails ..................17
page 41/45
STM32MP151x STM32MP153x STM32MP157x
Contents
2.3.18 Boot fails if eMMC does not answer the first command ...........................17
2.3.19 DLYB limits SDMMC throughput ............................................17
2.3.20 LSE CSS cannot be used in VBAT state ......................................18
2.3.21 Wrong value in Coresight M4 ROM table .....................................18
2.4 DDRPHYC ...................................................................18
2.4.1 DDRPHYC overconsumption upon reset or Standby mode exit ....................18
2.4.2 DDR_CLK jitter out of JEDEC requirement for 32-bit LPDDR2/LPDDR3 at low device Tj . 18
2.4.3 Data corruption at low device Tj combined with low 32-bit LPDDR2/LPDDR3 I/O supply
voltage ...............................................................19
2.5 GPIO........................................................................19
2.5.1 GPIO assigned to DAC cannot be used in output mode when the DAC output is connected
to on-chip peripheral .....................................................19
2.6 DMA ........................................................................19
2.6.1 USART/UART/LPUART DMA transfer abort ...................................19
2.7 DMAMUX ....................................................................20
2.7.1 SOFx not asserted when writing into DMAMUX_CFR register .....................20
2.7.2 OFx not asserted for trigger event coinciding with last DMAMUX request .............20
2.7.3 OFx not asserted when writing into DMAMUX_RGCFR register ....................20
2.7.4 Wrong input DMA request routed upon specific DMAMUX_CxCR register write coinciding
with synchronization event ................................................21
2.8 QUADSPI ....................................................................21
2.8.1 Memory-mapped read of last memory byte fails ................................21
2.9 ADC ........................................................................21
2.9.1 New context conversion initiated without waiting for trigger when writing new context in
ADC_JSQR with JQDIS = 0 and JQM = 0.....................................21
2.9.2 Two consecutive context conversions fail when writing new context in ADC_JSQR just after
previous context completion with JQDIS = 0 and JQM = 0 ........................22
2.9.3 Unexpected regular conversion when two consecutive injected conversions are performed
in Dual interleaved mode .................................................22
2.9.4 ADC_AWDy_OUT reset by non-guarded channels ..............................22
2.9.5 ADC ANA0/ANA1 resolution limited when Gigabit Ethernet is used .................23
2.9.6 ADC missing codes in differential 16-bit static acquisition .........................23
2.10 DAC ........................................................................23
2.10.1 Invalid DAC channel analog output if the DAC channel MODE bitfield is programmed before
DAC initialization........................................................23
ES0438 - Rev 6
page 42/45
STM32MP151x STM32MP153x STM32MP157x
Contents
2.10.2 DMA underrun flag not set when an internal trigger is detected on the clock cycle of the
DMA request acknowledge ................................................23
2.11 VREFBUF ...................................................................24
2.11.1 VREFBUF Hold mode cannot be used .......................................24
2.11.2 Overshoot on VREFBUF output ............................................24
2.12 DTS.........................................................................24
2.12.1 Mode using PCLK & LSE (REFCLK_SEL = 1) should not be used ..................24
2.13 DSI .........................................................................24
2.13.1 DSI PHY compliant with MIPI DPHY v0.81 specification, not with DSI PHY v1.0 .......24
2.14 HASH .......................................................................25
2.14.1 Superseded suspend sequence for data loaded by DMA .........................25
2.14.2 Superseded suspend sequence for data loaded by the CPU ......................25
2.15 TIM .........................................................................26
2.15.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration ......26
2.15.2 Consecutive compare event missed in specific conditions ........................26
2.15.3 Output compare clear not working with external counter reset .....................27
2.16 LPTIM .......................................................................27
2.16.1 Device may remain stuck in LPTIM interrupt when entering Stop mode ..............27
2.16.2 Device may remain stuck in LPTIM interrupt when clearing event flag ...............28
2.16.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle.................28
2.17 RTC and TAMP ...............................................................29
2.17.1 Incorrect version register..................................................29
2.17.2 Calendar initialization may fail in case of consecutive INIT mode entry...............29
2.17.3 Alarm flag may be repeatedly set when the core is stopped in debug ................29
2.17.4 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles
after clearing TSF .......................................................29
2.17.5 REFCKON write protection associated to INIT KEY instead of CAL KEY .............30
2.17.6 Tamper flag not set on LSE failure detection ...................................30
2.18 I2C .........................................................................30
2.18.1 Wrong data sampling when data setup time (t
period ................................................................30
2.18.2 Spurious bus error detection in master mode ..................................31
2.18.3 Spurious master transfer upon own slave address match .........................31
ES0438 - Rev 6
) is shorter than one I2C kernel clock
SU;DAT
page 43/45
STM32MP151x STM32MP153x STM32MP157x
Contents
2.18.4 OVR flag not set in underrun condition .......................................31
2.18.5 Transmission stalled after first byte transfer ...................................32
2.19 USART ......................................................................32
2.19.1 Anticipated end-of-transmission signaling in SPI slave mode ......................32
2.19.2 Data corruption due to noisy receive line......................................32
2.20 SPI .........................................................................33
2.20.1 Master data transfer stall at system clock much faster than SCK ...................33
2.20.2 Corrupted CRC return at non-zero UDRDET setting .............................33
2.20.3 TXP interrupt occurring while SPI disabled ....................................33
2.20.4 Possible corruption of last-received data depending on CRCSIZE setting.............33
2.21 FDCAN ......................................................................34
2.21.1 Desynchronization under specific condition with edge filtering enabled...............34
2.21.2 Tx FIFO messages inverted under specific buffer usage and priority setting...........34
2.21.3 DAR mode transmission failure due to lost arbitration ............................34
2.22 OTG_HS.....................................................................35
2.22.1 Host packet transmission may hang when connecting through a hub to a low-speed device
.....................................................................35
2.23 ETH.........................................................................35
2.23.1 Incorrect L4 inverse filtering results for corrupted packets.........................35
2.23.2 Rx DMA may fail to recover upon DMA restart following a bus error, with Rx timestamping
enabled ...............................................................35
2.23.3 Spurious receive watchdog timeout interrupt...................................36
2.23.4 Incorrect flexible PPS output interval under specific conditions .....................36
2.23.5 Packets dropped in RMII 10Mbps mode due to fake dribble and CRC error ...........36
2.23.6 ARP offload function not effective ...........................................36
2.23.7 Slight imbalance of AV traffic CBS bandwidth allocation ..........................37
2.23.8 Spurious checksum error upon MTL pending Tx queue flush ......................37
2.23.9 Bus error coinciding with start-of-packet corrupts MAC-generated packet transmission ..38
2.23.10 DMA spurious state upon AXI DMA slave bus error .............................38
Revision history .......................................................................39
ES0438 - Rev 6
page 44/45
STM32MP151x STM32MP153x STM32MP157x
IMPORTANT NOTICE – PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and improvements to ST
products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST
products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of
Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service
names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2021 STMicroelectronics – All rights reserved
ES0438 - Rev 6
page 45/45
Loading...
