ST MICROELECTRONICS STM32L431CBT6 Datasheet

Download

STM32L431xx

UFBGA100 (7×7)

LQFP64 (10x10)

UFBGA64 (5x5)

LQFP48 (7x7)

LQFP100 (14x14)

WLCSP64

UFQFPN32 (5x5)

WLCSP49UFQFPN48 (7x7)

Ultra-low-power Arm® Cortex®-M4 32-bit MCU+FPU, 100DMIPS,

up to 256KB Flash, 64KB SRAM, analog, audio

Datasheet - production data

Features

• Ultra-low-power with FlexPowerControl – 1.71 V to 3.6 V power supply – -40 °C to 85/105/125 °C temperature range – 200 nA in V

32x32-bit backup registers – 8 nA Shutdown mode (5 wakeup pins) – 28 nA Standby mode (5 wakeup pins) – 280 nA Standby mode with RTC – 1.0 µA Stop 2 mode, 1.28 µA with RTC – 84 µA/MHz run mode – Batch acquisition mode (BAM) – 4 µs wakeup from Stop mode – Brown out reset (BOR) – Interconnect matrix

• Core: Arm

Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait-state execution from Flash memory, frequency up to 80 MHz, MPU, 100DMIPS and DSP instructions

• Performance benchmark – 1.25 DMIPS/MHz (Drystone 2.1) – 273.55 CoreMark

80 MHz)

• Energy benchmark – 176.7 ULPBench

• Clock Sources – 4 to 48 MHz crystal oscillator – 32 kHz crystal oscillator for RTC (LSE) – Internal 16 MHz factory-trimmed RC (±1%) – Internal low-power 32 kHz RC (±5%) – Internal multispeed 100 kHz to 48 MHz

oscillator, auto-trimmed by LSE (better than

±0.25 % accuracy) – Internal 48 MHz with clock recovery – 2 PLLs for system clock, audio, ADC

mode: supply for RTC and

BAT

32-bit Cortex®-M4 CPU with FPU,

(3.42 CoreMark/MHz @

score

• Up to 83 fast I/Os, most 5 V-tolerant

• RTC with HW calendar, alarms and calibration

• Up to 21 capacitive sensing channels: support

touchkey, linear and rotary touch sensors

• 11x timers: 1x 16-bit advanced motor-control, 1x 32-bit and 2x 16-bit general purpose, 2x 16bit basic, 2x low-power 16-bit timers (available in Stop mode), 2x watchdogs, SysTick timer

• Memories – Up to 256 KB single bank Flash,

proprietary code readout protection

– 64 KB of SRAM including 16 KB with

hardware parity check

– Quad SPI memory interface

• Rich analog peripherals (independent supply) – 1x 12-bit ADC 5 Msps, up to 16-bit with

hardware oversampling, 200 µA/Msps

– 2x 12-bit DAC output channels, low-power

sample and hold – 1x operational amplifier with built-in PGA – 2x ultra-low-power comparators

• 16x communication interfaces – 1x SAI (serial audio interface) –3x I2C FM+(1 Mbit/s), SMBus/PMBus – 4x USARTs (ISO 7816, LIN, IrDA, modem) – 1x LPUART (Stop 2 wake-up) – 3x SPIs (and 1x Quad SPI) – CAN (2.0B Active) and SDMMC interface – SWPMI single wire protocol master I/F – IRTIM (Infrared interface)

• 14-channel DMA controller

• True random number generator

• CRC calculation unit, 96-bit unique ID

May 2018 DS11453 Rev 3 1/208

This is information on a product in full production.

www.st.com

STM32L431xx

• Development support: serial wire debug (SWD), JTAG, Embedded Trace Macrocell™

Table 1. Device summary

Reference Part numbers

STM32L431xx

STM32L431CC, STM32L431KC, STM32L431RC, STM32L431VC, STM32L431CB, STM32L431KB, STM32L431RB

• All packages are ECOPACK2® compliant

2/208 DS11453 Rev 3

STM32L431xx Contents

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3 Functional overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.1 Arm® Cortex®-M4 core with FPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.2 Adaptive real-time memory accelerator (ART Accelerator™) . . . . . . . . . 17

3.3 Memory protection unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.4 Embedded Flash memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.5 Embedded SRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.6 Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.7 Boot modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.8 Cyclic redundancy check calculation unit (CRC) . . . . . . . . . . . . . . . . . . . 20

3.9 Power supply management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.9.1 Power supply schemes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.9.2 Power supply supervisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.9.3 Voltage regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.9.4 Low-power modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.9.5 Reset mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.9.6 VBAT operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.10 Interconnect matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

3.11 Clocks and startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

3.12 General-purpose inputs/outputs (GPIOs) . . . . . . . . . . . . . . . . . . . . . . . . . 36

3.13 Direct memory access controller (DMA) . . . . . . . . . . . . . . . . . . . . . . . . . . 36

3.14 Interrupts and events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3.14.1 Nested vectored interrupt controller (NVIC) . . . . . . . . . . . . . . . . . . . . . . 37

3.14.2 Extended interrupt/event controller (EXTI) . . . . . . . . . . . . . . . . . . . . . . 37

3.15 Analog to digital converter (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

3.15.1 Temperature sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

3.15.2 Internal voltage reference (VREFINT) . . . . . . . . . . . . . . . . . . . . . . . . . . 39

3.15.3 VBAT battery voltage monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

3.16 Digital to analog converter (DAC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

DS11453 Rev 3 3/208

Contents STM32L431xx

3.17 Voltage reference buffer (VREFBUF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

3.18 Comparators (COMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

3.19 Operational amplifier (OPAMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

3.20 Touch sensing controller (TSC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

3.21 Random number generator (RNG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

3.22 Timers and watchdogs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

3.22.1 Advanced-control timer (TIM1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

3.22.2 General-purpose timers (TIM2, TIM15, TIM16) . . . . . . . . . . . . . . . . . . . 44

3.22.3 Basic timers (TIM6 and TIM7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

3.22.4 Low-power timer (LPTIM1 and LPTIM2) . . . . . . . . . . . . . . . . . . . . . . . . 44

3.22.5 Infrared interface (IRTIM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

3.22.6 Independent watchdog (IWDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

3.22.7 System window watchdog (WWDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

3.22.8 SysTick timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

3.23 Real-time clock (RTC) and backup registers . . . . . . . . . . . . . . . . . . . . . . 46

3.24 Inter-integrated circuit interface (I

C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

3.25 Universal synchronous/asynchronous receiver transmitter (USART) . . . 48

3.26 Low-power universal asynchronous receiver transmitter (LPUART) . . . . 49

3.27 Serial peripheral interface (SPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

3.28 Serial audio interfaces (SAI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

3.29 Single wire protocol master interface (SWPMI) . . . . . . . . . . . . . . . . . . . . 51

3.30 Controller area network (CAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

3.31 Secure digital input/output and MultiMediaCards Interface (SDMMC) . . . 52

3.32 Clock recovery system (CRS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

3.33 Quad SPI memory interface (QUADSPI) . . . . . . . . . . . . . . . . . . . . . . . . . 53

3.34 Development support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

3.34.1 Serial wire JTAG debug port (SWJ-DP) . . . . . . . . . . . . . . . . . . . . . . . . . 54

3.34.2 Embedded Trace Macrocell™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

4 Pinouts and pin description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5 Memory mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

6 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1 Parameter conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

4/208 DS11453 Rev 3

STM32L431xx Contents

6.1.1 Minimum and maximum values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1.2 Typical values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1.3 Typical curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1.4 Loading capacitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1.5 Pin input voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

6.1.6 Power supply scheme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

6.1.7 Current consumption measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

6.2 Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

6.3 Operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

6.3.1 General operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

6.3.2 Operating conditions at power-up / power-down . . . . . . . . . . . . . . . . . . 89

6.3.3 Embedded reset and power control block characteristics . . . . . . . . . . . 89

6.3.4 Embedded voltage reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

6.3.5 Supply current characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

6.3.6 Wakeup time from low-power modes and voltage scaling

transition times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

6.3.7 External clock source characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 114

6.3.8 Internal clock source characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . 119

6.3.9 PLL characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

6.3.10 Flash memory characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

6.3.11 EMC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

6.3.12 Electrical sensitivity characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

6.3.13 I/O current injection characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

6.3.14 I/O port characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

6.3.15 NRST pin characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

6.3.16 Extended interrupt and event controller input (EXTI) characteristics . . 137

6.3.17 Analog switches booster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

6.3.18 Analog-to-Digital converter characteristics . . . . . . . . . . . . . . . . . . . . . 138

6.3.19 Digital-to-Analog converter characteristics . . . . . . . . . . . . . . . . . . . . . 151

6.3.20 Voltage reference buffer characteristics . . . . . . . . . . . . . . . . . . . . . . . 156

6.3.21 Comparator characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

6.3.22 Operational amplifiers characteristics . . . . . . . . . . . . . . . . . . . . . . . . . 159

6.3.23 Temperature sensor characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

6.3.24 V

monitoring characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

BAT

6.3.25 Timer characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

6.3.26 Communication interfaces characteristics . . . . . . . . . . . . . . . . . . . . . . 164

DS11453 Rev 3 5/208

Contents STM32L431xx

7 Package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

7.1 LQFP100 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

7.2 UFBGA100 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

7.3 LQFP64 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

7.4 UFBGA64 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

7.5 WLCSP64 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

7.6 WLCSP49 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

7.7 LQFP48 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

7.8 UFQFPN48 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

7.9 UFQFPN32 package information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

7.10 Thermal characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

7.10.1 Reference document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

7.10.2 Selecting the product temperature range . . . . . . . . . . . . . . . . . . . . . . 204

8 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

9 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

6/208 DS11453 Rev 3

STM32L431xx List of tables

List of tables

Table 1. Device summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Table 2. STM32L431xx family device features and peripheral counts . . . . . . . . . . . . . . . . . . . . . . . 13

Table 3. Access status versus readout protection level and execution modes. . . . . . . . . . . . . . . . . 18

Table 4. STM32L431xx modes overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Table 5. Functionalities depending on the working mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 6. STM32L431xx peripherals interconnect matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Table 7. DMA implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Table 8. Temperature sensor calibration values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Table 9. Internal voltage reference calibration values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Table 10. Timer feature comparison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Table 11. I2C implementation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Table 12. STM32L431xx USART/LPUART features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Table 13. SAI implementation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Table 14. Legend/abbreviations used in the pinout table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Table 15. STM32L431xx pin definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Table 16. Alternate function AF0 to AF7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Table 17. Alternate function AF8 to AF15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Table 18. STM32L431xx memory map and peripheral register boundary addresses . . . . . . . . . . . . 81

Table 19. Voltage characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Table 20. Current characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Table 21. Thermal characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Table 22. General operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Table 23. Operating conditions at power-up / power-down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Table 24. Embedded reset and power control block characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . 89

Table 25. Embedded internal voltage reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Table 26. Current consumption in Run and Low-power run modes, code with data processing

running from Flash, ART enable (Cache ON Prefetch OFF) . . . . . . . . . . . . . . . . . . . . . . . 94

Table 27. Current consumption in Run and Low-power run modes, code with data processing

running from Flash, ART disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Table 28. Current consumption in Run and Low-power run modes, code with data processing

running from SRAM1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Table 29. Typical current consumption in Run and Low-power run modes, with different codes

running from Flash, ART enable (Cache ON Prefetch OFF) . . . . . . . . . . . . . . . . . . . . . . . 97

Table 30. Typical current consumption in Run and Low-power run modes, with different codes

running from Flash, ART disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Table 31. Typical current consumption in Run and Low-power run modes, with different codes

running from SRAM1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Table 32. Current consumption in Sleep and Low-power sleep modes, Flash ON . . . . . . . . . . . . . . 99

Table 33. Current consumption in Low-power sleep modes, Flash in power-down . . . . . . . . . . . . . 100

Table 34. Current consumption in Stop 2 mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Table 35. Current consumption in Stop 1 mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Table 36. Current consumption in Stop 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Table 37. Current consumption in Standby mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Table 38. Current consumption in Shutdown mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Table 39. Current consumption in VBAT mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Table 40. Peripheral current consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Table 41. Low-power mode wakeup timings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Table 42. Regulator modes transition times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

DS11453 Rev 3 7/208

List of tables STM32L431xx

Table 43. Wakeup time using USART/LPUART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Table 44. High-speed external user clock characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Table 45. Low-speed external user clock characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Table 46. HSE oscillator characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Table 47. LSE oscillator characteristics (f

= 32.768 kHz) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

LSE

Table 48. HSI16 oscillator characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Table 49.

MSI oscillator characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Table 50. HSI48 oscillator characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Table 51. LSI oscillator characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Table 52. PLL, PLLSAI1 characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Table 53. Flash memory characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Table 54. Flash memory endurance and data retention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Table 55. EMS characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Table 56. EMI characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Table 57. ESD absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Table 58. Electrical sensitivities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Table 59. I/O current injection susceptibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Table 60. I/O static characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Table 61. Output voltage characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Table 62. I/O AC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Table 63. NRST pin characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Table 64. EXTI Input Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Table 65. Analog switches booster characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Table 66. ADC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Table 67. Maximum ADC RAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Table 68. ADC accuracy - limited test conditions 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Table 69. ADC accuracy - limited test conditions 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Table 70. ADC accuracy - limited test conditions 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Table 71. ADC accuracy - limited test conditions 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Table 72. DAC characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Table 73. DAC accuracy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Table 74. VREFBUF characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Table 75. COMP characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158

Table 76. OPAMP characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Table 77. TS characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Table 78. V Table 79. V

monitoring characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

BAT

charging characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

BAT

Table 80. TIMx characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Table 81. IWDG min/max timeout period at 32 kHz (LSI). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

Table 82. WWDG min/max timeout value at 80 MHz (PCLK). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164

Table 83. I2C analog filter characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Table 84. SPI characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

Table 85. Quad SPI characteristics in SDR mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

Table 86. QUADSPI characteristics in DDR mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Table 87. SAI characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Table 88. SD / MMC dynamic characteristics, VDD=2.7 V to 3.6 V . . . . . . . . . . . . . . . . . . . . . . . . . 174

Table 89. eMMC dynamic characteristics, VDD = 1.71 V to 1.9 V . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Table 90. SWPMI electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Table 91. LQPF100 - 100-pin, 14 x 14 mm low-profile quad flat package

mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Table 92. UFBGA100 - 100-ball, 7 x 7 mm, 0.50 mm pitch, ultra fine pitch ball grid

array package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

8/208 DS11453 Rev 3

STM32L431xx List of tables

Table 93. UFBGA100 recommended PCB design rules (0.5 mm pitch BGA) . . . . . . . . . . . . . . . . . 181

Table 94. LQFP64 - 64-pin, 10 x 10 mm low-profile quad flat

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Table 95. UFBGA64 – 64-ball, 5 x 5 mm, 0.5 mm pitch ultra profile fine pitch ball grid array

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Table 96. UFBGA64 recommended PCB design rules (0.5 mm pitch BGA) . . . . . . . . . . . . . . . . . . 186

Table 97. WLCSP64 - 64-ball, 3.141 x 3.127 mm, 0.35 mm pitch wafer level chip scale

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Table 98. WLCSP64 recommended PCB design rules (0.35 mm pitch) . . . . . . . . . . . . . . . . . . . . . 189

Table 99. WLCSP49 - 49-ball, 3.141 x 3.127 mm, 0.4 mm pitch wafer level chip scale

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Table 100. WLCSP49 recommended PCB design rules (0.4 mm pitch) . . . . . . . . . . . . . . . . . . . . . . 193

Table 101. LQFP48 - 48-pin, 7 x 7 mm low-profile quad flat package

mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

Table 102. UFQFPN48 - 48-lead, 7x7 mm, 0.5 mm pitch, ultra thin fine pitch quad flat

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Table 103. UFQFPN32 - 32-pin, 5x5 mm, 0.5 mm pitch ultra thin fine pitch quad flat

package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Table 104. Package thermal characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Table 105. STM32L431xx ordering information scheme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206

Table 106. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

DS11453 Rev 3 9/208

List of figures STM32L431xx

List of figures

Figure 1. STM32L431xx block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 2. Power supply overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 3. Power-up/down sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 4. Clock tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 5. Voltage reference buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Figure 6. STM32L431Vx LQFP100 pinout Figure 7. STM32L431Vx UFBGA100 ballout Figure 8. STM32L431Rx LQFP64 pinout Figure 9. STM32L431Rx UFBGA64 ballout Figure 10. STM32L431Rx WLCSP64 pinout Figure 11. STM32L431Cx WLCSP49 pinout Figure 12. STM32L431Cx LQFP48 pinout Figure 13. STM32L431Cx UFQFPN48 pinout Figure 14. STM32L431Kx UFQFPN32 pinout

Figure 15. STM32L431xx memory map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Figure 16. Pin loading conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Figure 17. Pin input voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Figure 18. Power supply scheme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Figure 19. Current consumption measurement scheme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Figure 20. VREFINT versus temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Figure 21. High-speed external clock source AC timing diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Figure 22. Low-speed external clock source AC timing diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Figure 23. Typical application with an 8 MHz crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Figure 24. Typical application with a 32.768 kHz crystal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Figure 25. HSI16 frequency versus temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Figure 26. Typical current consumption versus MSI frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Figure 27. HSI48 frequency versus temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Figure 28. I/O input characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Figure 29. I/O AC characteristics definition

Figure 30. Recommended NRST pin protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Figure 31. ADC accuracy characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Figure 32. Typical connection diagram using the ADC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Figure 33. 12-bit buffered / non-buffered DAC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Figure 34. SPI timing diagram - slave mode and CPHA = 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

Figure 35. SPI timing diagram - slave mode and CPHA = 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Figure 36. SPI timing diagram - master mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

Figure 37. Quad SPI timing diagram - SDR mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Figure 38. Quad SPI timing diagram - DDR mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Figure 39. SAI master timing waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Figure 40. SAI slave timing waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Figure 41. SDIO high-speed mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Figure 42. SD default mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Figure 43. LQFP100 - 100-pin, 14 x 14 mm low-profile quad flat package outline . . . . . . . . . . . . . . 177

Figure 44. LQFP100 - 100-pin, 14 x 14 mm low-profile quad flat

recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Figure 45. LQFP100 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

Figure 46. UFBGA100 - 100-ball, 7 x 7 mm, 0.50 mm pitch, ultra fine pitch ball grid

array package outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

(1)

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

10/208 DS11453 Rev 3

STM32L431xx List of figures

Figure 47. UFBGA100 - 100-ball, 7 x 7 mm, 0.50 mm pitch, ultra fine pitch ball grid

array package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

Figure 48. UFBGA100 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Figure 49. LQFP64 - 64-pin, 10 x 10 mm low-profile quad flat package outline . . . . . . . . . . . . . . . . 183

Figure 50. LQFP64 - 64-pin, 10 x 10 mm low-profile quad flat package

recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Figure 51. LQFP64 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Figure 52. UFBGA64 – 64-ball, 5 x 5 mm, 0.5 mm pitch ultra profile fine pitch ball grid

array package outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Figure 53. UFBGA64 – 64-ball, 5 x 5 mm, 0.5 mm pitch ultra profile fine pitch ball grid

array package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186

Figure 54. UFBGA64 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

Figure 55. WLCSP64 - 64-ball, 3.141 x 3.127 mm, 0.35 mm pitch wafer level chip scale

package outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188

Figure 56. WLCSP64 - 64-ball, 3.141 x 3.127 mm, 0.35 mm pitch wafer level chip scale

package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Figure 57. WLCSP64 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190

Figure 58. WLCSP49 - 49-ball, 3.141 x 3.127 mm, 0.4 mm pitch wafer level chip scale

package outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Figure 59. WLCSP49 - 49-ball, 3.141 x 3.127 mm, 0.4 mm pitch wafer level chip scale

package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Figure 60. WLCSP49 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Figure 61. LQFP48 - 48-pin, 7 x 7 mm low-profile quad flat package outline . . . . . . . . . . . . . . . . . . 194

Figure 62. LQFP48 - 48-pin, 7 x 7 mm low-profile quad flat package

recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Figure 63. LQFP48 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196

Figure 64. UFQFPN48 - 48-lead, 7x7 mm, 0.5 mm pitch, ultra thin fine pitch quad flat

package outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Figure 65. UFQFPN48 - 48-lead, 7x7 mm, 0.5 mm pitch, ultra thin fine pitch quad flat

package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Figure 66. UFQFPN48 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Figure 67. UFQFPN32 - 32-pin, 5x5 mm, 0.5 mm pitch ultra thin fine pitch quad flat

package outline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Figure 68. UFQFPN32 - 32-pin, 5x5 mm, 0.5 mm pitch ultra thin fine pitch quad flat

package recommended footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Figure 69. UFQFPN32 marking (package top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Figure 70. LQFP64 P

max vs. TA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

DS11453 Rev 3 11/208

Introduction STM32L431xx

1 Introduction

This datasheet provides the ordering information and mechanical device characteristics of

the STM32L431xx microcontrollers.

This document should be read in conjunction with the STM32L43xxx/44xxx/45xxx/46xxx

reference manual (RM0394). The reference manual is available from the

STMicroelectronics website www.st.com.

For information on the Arm

Reference Manual, available from the www.arm.com website.

®(a)

Cortex®-M4 core, please refer to the Cortex®-M4 Technical

a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

12/208 DS11453 Rev 3

STM32L431xx Description

2 Description

The STM32L431xx devices are the ultra-low-power microcontrollers based on the high-

performance Arm

The Cortex-M4 core features a Floating point unit (FPU) single precision which supports all

Arm

single-precision data-processing instructions and data types. It also implements a full

Cortex®-M4 32-bit RISC core operating at a frequency of up to 80 MHz.

set of DSP instructions and a memory protection unit (MPU) which enhances application

security.

The STM32L431xx devices embed high-speed memories (Flash memory up to 256 Kbyte,

Kbyte of SRAM), a Quad SPI flash memories interface (available on all packages) and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix.

The STM32L431xx devices embed several protection mechanisms for embedded Flash memory and SRAM: readout protection, write protection, proprietary code readout protection and Firewall.

The devices offer a fast 12-bit ADC (5 Msps), two comparators, one operational amplifier, two DAC channels, an internal voltage reference buffer, a low-power RTC, one generalpurpose 32-bit timer, one 16-bit PWM timer dedicated to motor control, four general-purpose 16-bit timers, and two 16-bit low-power timers.

In addition, up to 21 capacitive sensing channels are available.

They also feature standard and advanced communication interfaces.

• Three I2Cs

• Three SPIs

• Three USARTs and one Low-Power UART.

• One SAI (Serial Audio Interfaces)

• One SDMMC

• One CAN

• One SWPMI (Single Wire Protocol Master Interface)

The STM32L431xx operates in the -40 to +85 °C (+105 °C junction), -40 to +105 °C (+125

°C junction) and -40 to +125 °C (+130 °C junction) temperature ranges from a 1.71 to

3.6

V power supply. A comprehensive set of power-saving modes allows the design of low-

power applications.

Some independent power supplies are supported: analog independent supply input for ADC, DAC, OPAMP and comparators. A VBAT input allows to backup the RTC and backup registers.

The STM32L431xx family offers nine packages from 32 to 100-pin packages.

Table 2. STM32L431xx family device features and peripheral counts

Peripheral STM32L431Vx STM32L431Rx STM32L431Cx STM32L431Kx

Flash memory 256KB 128KB 256KB 128KB 256KB 128KB 256KB

SRAM 64KB

Quad SPI Yes

DS11453 Rev 3 13/208

Description STM32L431xx

Table 2. STM32L431xx family device features and peripheral counts (continued)

Peripheral STM32L431Vx STM32L431Rx STM32L431Cx STM32L431Kx

Timers

Comm. interfaces

Advanced control

General purpose

1 (16-bit)

2 (16-bit) 1 (32-bit)

Basic 2 (16-bit)

Low power

SysTick timer

2 (16-bit)

Watchdog timers (indepen

2 dent, window)

SPI 3 2

C3 2

USART LPUART

3 1

2 1

SAI 1

CAN 1

SDMMC Yes No

SWPMI Yes

RTC Yes

Tamper pins 3 2 2 1

Random generator Yes

GPIOs Wakeup pins

Capacitive sensing Number of channels

12-bit ADC Number of channels

38 or 39

21 12 6 3

(1)

12-bit DAC channels 2

Internal voltage reference buffer

Yes

Analog comparator 2

Operational amplifiers

Max. CPU frequency 80 MHz

Operating voltage 1.71 to 3.6 V

14/208 DS11453 Rev 3

STM32L431xx Description

Table 2. STM32L431xx family device features and peripheral counts (continued)

Peripheral STM32L431Vx STM32L431Rx STM32L431Cx STM32L431Kx

Operating temperature

Packages

1. For WLCSP49 package.

Ambient operating temperature: -40 to 85 °C / -40 to 105 °C / -40 to 125 °C

Junction temperature: -40 to 105 °C / -40 to 125 °C / -40 to 130 °C

LQFP100

UFBGA100

WLCSP64

LQFP64

UFBGA64

WLCSP49

LQFP48

UFQFPN48

UFQFPN32

DS11453 Rev 3 15/208

Description STM32L431xx

MSv39204V2

Flash

up to

256 KB

GPIO PORT A

AHB/APB2

EXT IT. WKUP

83 AF

PA[15:0]

TIM1 / PWM

3 compl. channels (TIM1_CH[1:3]N),

4 channels (TIM1_CH[1:4]),

ETR, BKIN, BKIN2 as AF

USART1

RX, TX, CK,CTS,

RTS as AF

SPI1

MOSI, MISO,

SCK, NSS as AF

APB260 M Hz

APB1 30MHz

OUT1

ITF

WWDG

RTC_TS

OSC32_IN

OSC32_OUT

smcard

IrDA

16b

SDIO / MMC

D[7:0]

CMD, CK as AF

VBAT = 1.55 to 3.6 V

JTAG & SW

ARM Cortex-M4

80 MHz

FPU

NVIC

ETM

MPU

DMA2

ART

ACCEL/

CACHE

RNG

FIFO

@ VDDA

BOR

Supply

supervision

PVD, PVM

Int

reset

XTAL 32 kHz

MAN AGT

RTC

FCLK

Standby

interface

IWDG

@VBAT

@ VDD

@VDD

AWU

Reset & clock

control

PCLKx

Voltage

regulator

3.3 to 1.2 V

VDD

Power management

@ VDD

RTC_TAMPx

Backup register

AHB bus-matrix

TIM15

2 channels,

1 compl. channel, BKIN as AF

DAC1

DAC2

TIM6

TIM7

TIM2

D-BUS

SRAM 48 KB

APB1 80 MHz (max)

SRAM 16 KB

I-BUS

S-BUS

DMA1

PB[15:0]

PC[15:0]

PD[15:0]

PE[15:0]

PH[1:0],

PH[3]

GPIO PORT B

GPIO PORT C

GPIO PORT D

GPIO PORT E

GPIO PORT H

16b

TIM16

16b

1 channel,

1 compl. channel, BKIN as AF

OUT2

16b

32b

4 channels, ETR as AF

AHB/APB1

OSC_IN

OSC_OUT

HCLKx

XTAL OSC

4- 16MHz

16 external analog inputs

VREF+

USAR T 2M Bps

Temperature sensor

@ VDDA

SAI1

MCLK_A, SD_A, FS_A, SCK_A, EXTCLK

MCLK_B, SD_B, FS_B, SCK_B as AF

Touch sensing controller

7 Groups of

3 channels max as AF

RC HSI

RC LSI

PLL 1&2

MSI

Quad SPI memory interface

D0[3:0], D1[3:0], CLK0, CLK1 CS

COMP1

INP, INM, OUT

COMP2

INP, INM, OUT

@ VDDA

RTC_OUT

AHB1 80 MHz

CRC

APB2 80MHz

AHB2 80 MHz

FIREWALL

VREF Buffer

@ VDDA

@ VDD

VDD = 1.71 to 3.6 V VSS

TRACECLK

TRACED[3:0]

NJTRST, JTDI,

JTCK/SWCLK

JTDO/SWD, JTDO

ITF

ADC1

HSI48

VDDA, VSSA

VDD, VSS, NRST

CRS

CRS_SYNC

USART2

RX, TX, CK, CTS, RTS as AF

smcard

IrDA

USART3

RX, TX, CK, CTS, RTS as AF

smcard

IrDA

MOSI, MISO, SCK, NSS as AF

SPI2

MOSI, MISO, SCK, NSS as AF

SPI3

I2C1/SMBUS

SCL, SDA, SMBA as AF

I2C2/SMBUS

SCL, SDA, SMBA as AF

I2C3/SMBUS

FIFO

TX, RX as AF

bxCAN1

VOUT, VINM, VINP

OpAmp1

@VDDA

LPUART1

RX, TX, CTS, RTS as AF

SWPMI1

IO RX, TX, SUSPEND as AF

LPTIM1

IN1, IN2, OUT, ETR as AF

LPTIM2

IN1, OUT, ETR as AF

Figure 1. STM32L431xx block diagram

Note: AF: alternate function on I/O pins.

16/208 DS11453 Rev 3

STM32L431xx Functional overview

3 Functional overview

3.1 Arm® Cortex®-M4 core with FPU

The Arm® Cortex®-M4 with FPU processor is the latest generation of Arm® processors for embedded systems. It was developed to provide a low-cost platform that meets the needs of MCU implementation, with a reduced pin count and low-power consumption, while delivering outstanding computational performance and an advanced response to interrupts.

The Arm® Cortex®-M4 with FPU 32-bit RISC processor features exceptional codeefficiency, delivering the high-performance expected from an Arm usually associated with 8- and 16-bit devices.

The processor supports a set of DSP instructions which allow efficient signal processing and complex algorithm execution.

Its single precision FPU speeds up software development by using metalanguage development tools, while avoiding saturation.

With its embedded Arm® core, the STM32L431xx family is compatible with all Arm® tools and software.

Figure 1 shows the general block diagram of the STM32L431xx family devices.

core in the memory size

3.2 Adaptive real-time memory accelerator (ART Accelerator™)

The ART Accelerator™ is a memory accelerator which is optimized for STM32 industrystandard Arm the Arm processor to wait for the Flash memory at higher frequencies.

To release the processor near 100 DMIPS performance at 80MHz, the accelerator implements an instruction prefetch queue and branch cache, which increases program execution speed from the 64-bit Flash memory. Based on CoreMark benchmark, the performance achieved thanks to the ART accelerator is equivalent to 0 wait state program execution from Flash memory at a CPU frequency up to 80 MHz.

Cortex®-M4 processors. It balances the inherent performance advantage of

Cortex®-M4 over Flash memory technologies, which normally requires the

3.3 Memory protection unit

The memory protection unit (MPU) is used to manage the CPU accesses to memory to prevent one task to accidentally corrupt the memory or resources used by any other active task. This memory area is organized into up to 8 protected areas that can in turn be divided up into 8 subareas. The protection area sizes are between 32 bytes and the whole 4 gigabytes of addressable memory.

The MPU is especially helpful for applications where some critical or certified code has to be protected against the misbehavior of other tasks. It is usually managed by an RTOS (realtime operating system). If a program accesses a memory location that is prohibited by the MPU, the RTOS can detect it and take action. In an RTOS environment, the kernel can dynamically update the MPU area setting, based on the process to be executed.

The MPU is optional and can be bypassed for applications that do not need it.

DS11453 Rev 3 17/208

Functional overview STM32L431xx

3.4 Embedded Flash memory

STM32L431xx devices feature up to 256 Kbyte of embedded Flash memory available for storing programs and data in single bank architecture. The Flash memory contains 128 pages of 2 Kbyte.

Flexible protections can be configured thanks to option bytes:

• Readout protection (RDP) to protect the whole memory. Three levels are available:

– Level 0: no readout protection

– Level 1: memory readout protection: the Flash memory cannot be read from or

written to if either debug features are connected, boot in RAM or bootloader is selected

– Level 2: chip readout protection: debug features (Cortex-M4 JTAG and serial

wire), boot in RAM and bootloader selection are disabled (JTAG fuse). This selection is irreversible.

Table 3. Access status versus readout protection level and execution modes

Area

Main

memory

System

memory

Option

bytes

Backup

registers

SRAM2

1. Erased when RDP change from Level 1 to Level 0.

Protection

level

1 Yes Yes Yes No No No

2 Yes Yes Yes N/A N/A N/A

1 Yes No No Yes No No

2 Yes No No N/A N/A N/A

1 Yes Yes Yes Yes Yes Yes

2 Yes No No N/A N/A N/A

1YesYesN/A

2 Yes Yes N/A N/A N/A N/A

1 Yes Yes Yes

2 Yes Yes Yes N/A N/A N/A

User execution

Read Write Erase Read Write Erase

(1)

Debug, boot from RAM or boot

from system memory (loader)

No No N/A

No No No

• Write protection (WRP): the protected area is protected against erasing and programming. Two areas can be selected, with 2-Kbyte granularity.

• Proprietary code readout protection (PCROP): a part of the flash memory can be protected against read and write from third parties. The protected area is execute-only: it can only be reached by the STM32 CPU, as an instruction code, while all other accesses (DMA, debug and CPU data read, write and erase) are strictly prohibited. The PCROP area granularity is 64-bit wide. An additional option bit (PCROP_RDP) allows to select if the PCROP area is erased or not when the RDP protection is changed from Level 1 to Level 0.

(1)

18/208 DS11453 Rev 3

STM32L431xx Functional overview

The whole non-volatile memory embeds the error correction code (ECC) feature supporting:

• single error detection and correction

• double error detection.

• The address of the ECC fail can be read in the ECC register

3.5 Embedded SRAM

STM32L431xx devices feature 64 Kbyte of embedded SRAM. This SRAM is split into two blocks:

• 48 Kbyte mapped at address 0x2000 0000 (SRAM1)

• 16 Kbyte located at address 0x1000 0000 with hardware parity check (SRAM2).

This memory is also mapped at address 0x2000 C000, offering a contiguous address space with the SRAM1 (16 Kbyte aliased by bit band)

This block is accessed through the ICode/DCode buses for maximum performance. These 16 Kbyte SRAM can also be retained in Standby mode.

The SRAM2 can be write-protected with 1 Kbyte granularity.

The memory can be accessed in read/write at CPU clock speed with 0 wait states.

3.6 Firewall

The device embeds a Firewall which protects code sensitive and secure data from any access performed by a code executed outside of the protected areas.

Each illegal access generates a reset which kills immediately the detected intrusion.

The Firewall main features are the following:

• Three segments can be protected and defined thanks to the Firewall registers: – Code segment (located in Flash or SRAM1 if defined as executable protected

area) – Non-volatile data segment (located in Flash) – Volatile data segment (located in SRAM1)

• The start address and the length of each segments are configurable: – Code segment: up to 1024 Kbyte with granularity of 256 bytes – Non-volatile data segment: up to 1024 Kbyte with granularity of 256 bytes – Volatile data segment: up to 48 Kbyte with a granularity of 64 bytes

• Specific mechanism implemented to open the Firewall to get access to the protected areas (call gate entry sequence)

• Volatile data segment can be shared or not with the non-protected code

• Volatile data segment can be executed or not depending on the Firewall configuration

The Flash readout protection must be set to level 2 in order to reach the expected level of protection.

DS11453 Rev 3 19/208

Functional overview STM32L431xx

3.7 Boot modes

At startup, BOOT0 pin or nSWBOOT0 option bit, and BOOT1 option bit are used to select one of three boot options:

• Boot from user Flash

• Boot from system memory

• Boot from embedded SRAM

BOOT0 value may come from the PH3-BOOT0 pin or from an option bit depending on the value of a user option bit to free the GPIO pad if needed.

A Flash empty check mechanism is implemented to force the boot from system flash if the first flash memory location is not programmed and if the boot selection is configured to boot from main flash.

The boot loader is located in system memory. It is used to reprogram the Flash memory by using USART, I2C, SPI or CAN.

3.8 Cyclic redundancy check calculation unit (CRC)

The CRC (cyclic redundancy check) calculation unit is used to get a CRC code using a configurable generator polynomial value and size.

Among other applications, CRC-based techniques are used to verify data transmission or storage integrity. In the scope of the EN/IEC 60335-1 standard, they offer a means of verifying the Flash memory integrity. The CRC calculation unit helps compute a signature of the software during runtime, to be compared with a reference signature generated at linktime and stored at a given memory location.

3.9 Power supply management

3.9.1 Power supply schemes

• VDD = 1.71 to 3.6 V: external power supply for I/Os (V the system analog such as reset, power management and internal clocks. It is provided externally through VDD pins.

• V

= 1.62 V (ADCs/COMPs) / 1.8 (DAC/OPAMP) to 3.6 V: external analog power

DDA

supply for ADCs, DAC, OPAMPs, Comparators and Voltage reference buffer. The V voltage level is independent from the V

• V

= 1.55 to 3.6 V: power supply for RTC, external clock 32 kHz oscillator and

BAT

backup registers (through power switch) when V

Note: When the functions supplied by V

to V

are not used, this supply should preferably be shorted

DDA

voltage.

is not present.

Note: If these supplies are tied to ground, the I/Os supplied by these power supplies are not 5 V

tolerant (refer to

Tabl e 19: Voltage characteristics).

), the internal regulator and

DDIO1

DDA

Note: V

20/208 DS11453 Rev 3

is the I/Os general purpose digital functions supply. V

DDIOx

= VDD.

DDIO1

represents V

DDIOx

DDIO1

, with

STM32L431xx Functional overview

MSv39205V2

Low voltage detector

DDA

domain

BAT

A/D converters Comparators D/A converters Operational amplifiers Voltage reference buffer

domain

I/O ring

SSA

Reset block Temp. sensor PLL, HSI, MSI, HSI48

Standby circuitry (Wakeup logic, IWDG)

Voltage regulator

DDIO1

LSE crystal 32 K osc BKP registers RCC BDCR register RTC

Backup domain

Core Memories Digital peripherals

CORE

domain

CORE

Figure 2. Power supply overview

During power-up and power-down phases, the following power sequence requirements must be respected:

• When VDD is below 1 V, other power supplies (V

) must remain below VDD +

DDA

300 mV.

• When V

is above 1 V, all power supplies are independent.

During the power-down phase, VDD can temporarily become lower than other supplies only if the energy provided to the MCU remains below 1

mJ; this allows external decoupling capacitors to be discharged with different time constants during the power- down transient phase.

DS11453 Rev 3 21/208

Functional overview STM32L431xx

MSv47490V1

0.3

BOR0

3.6

Operating modePower-on Power-down time

DDX

(1)

Invalid supply area V

DDX

< V

+ 300 mV

DDX

independent from V

Figure 3. Power-up/down sequence

1. V

refers to V

DDX

DDA

3.9.2 Power supply supervisor

The device has an integrated ultra-low-power brown-out reset (BOR) active in all modes except Shutdown and ensuring proper operation after power-on and during power down. The device remains in reset mode when the monitored supply voltage V specified threshold, without the need for an external reset circuit.

The lowest BOR level is 1.71V at power on, and other higher thresholds can be selected through option bytes.The device features an embedded programmable voltage detector (PVD) that monitors the V interrupt can be generated when V higher than the VPVD threshold. The interrupt service routine can then generate a warning message and/or put the MCU into a safe state. The PVD is enabled by software.

In addition, the device embeds a Peripheral Voltage Monitor which compares the independent supply voltage V peripheral is in its functional supply range.

power supply and compares it to the VPVD threshold. An

DDA

is below a

drops below the VPVD threshold and/or when VDD is

with a fixed threshold in order to ensure that the

22/208 DS11453 Rev 3

STM32L431xx Functional overview

3.9.3 Voltage regulator

Two embedded linear voltage regulators supply most of the digital circuitries: the main regulator (MR) and the low-power regulator (LPR).

• The MR is used in the Run and Sleep modes and in the Stop 0 mode.

• The LPR is used in Low-Power Run, Low-Power Sleep, Stop 1 and Stop 2 modes. It is

also used to supply the 16 Kbyte SRAM2 in Standby with SRAM2 retention.

• Both regulators are in power-down in Standby and Shutdown modes: the regulator

output is in high impedance, and the kernel circuitry is powered down thus inducing zero consumption.

The ultralow-power STM32L431xx supports dynamic voltage scaling to optimize its power consumption in run mode. The voltage from the Main Regulator that supplies the logic (V

There are two power consumption ranges:

• Range 1 with the CPU running at up to 80 MHz.

• Range 2 with a maximum CPU frequency of 26 MHz. All peripheral clocks are also

) can be adjusted according to the system’s maximum operating frequency.

CORE

limited to 26 MHz.

The V

can be supplied by the low-power regulator, the main regulator being switched

CORE

off. The system is then in Low-power run mode.

• Low-power run mode with the CPU running at up to 2 MHz. Peripherals with

independent clock can be clocked by HSI16.

3.9.4 Low-power modes

The ultra-low-power STM32L431xx supports seven low-power modes to achieve the best compromise between low-power consumption, short startup time, available peripherals and available wakeup sources.

DS11453 Rev 3 23/208

24/208 DS11453 Rev 3

Mode Regulator

(1)

Table 4. STM32L431xx modes overview

CPU Flash SRAM Clocks DMA & Peripherals

(2)

Wakeup source Consumption

(3)

Functional overview STM32L431xx

Wakeup time

Run

Yes O N

MR range2 All except RNG 84 µA/MHz

LPRun LPR Yes ON

MR range 1

Sleep

No ON

MR range2 All except RNG 26 µA/MHz

LPSleep LPR No ON

MR Range 1

Stop 0

No OFF ON

MR Range 2 108 µA

(4)

ON Any

except

(5)

except

Any

PLL

Any

PLL

LSE

LSI

All

97 µA/MHz

N/A

All except USB_FS, RNG N/A 94 µA/MHz

All

Any interrupt or

28 µA/MHz

event

All except USB_FS, RNG

Any interrupt or

event

29 µA/MHz 6 cycles

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1,2)

DAC1

OPAMPx (x=1)

USARTx (x=1...3)

LPUART1

I2Cx (x=1...3)

(6)

(7)

LPTIMx (x=1,2)

***

All other peripherals are

Reset pin, all I/Os

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1..2)

USARTx (x=1...3)

LPUART1

I2Cx (x=1...3)

(6)

(7)

LPTIMx (x=1,2)

SWPMI1

(8)

108 µA

(6)

frozen.

N/A

to Range 1: 4 µs

to Range 2: 64 µs

6 cycles

2.4 µs in SRAM

4.1 µs in Flash

DS11453 Rev 3 25/208

Table 4. STM32L431xx modes overview (continued)

Mode Regulator

Stop 1 LPR No Off ON

Stop 2 LPR No Off ON

(1)

CPU Flash SRAM Clocks DMA & Peripherals

LSE

LSI

LSE

LSI

(2)

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1,2)

DAC1

OPAMPx (x=1)

USARTx (x=1...3)

LPUART1

I2Cx (x=1...3)

(6)

(7)

LPTIMx (x=1,2)

***

All other peripherals are

frozen.

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1..2)

(7)

I2C3

LPUART1

(6)

LPTIM1

***

All other peripherals are

frozen.

Wakeup source Consumption

Reset pin, all I/Os

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1..2)

USARTx (x=1...3)

LPUART1

(6)

I2Cx (x=1...3)

4.34 µA w/o RTC

(6)

4.63 µA w RTC

(7)

LPTIMx (x=1,2)

SWPMI1

(8)

Reset pin, all I/Os

BOR, PVD, PVM

RTC, IWDG

COMPx (x=1..2)

(7)

I2C3

LPUART1

(6)

1.3 µA w/o RTC

1.4 µA w/RTC

LPTIM1

(3)

Wakeup time

6.3 µs in SRAM

7.8 µs in Flash

6.8 µs in SRAM

8.2 µs in Flash

STM32L431xx Functional overview

26/208 DS11453 Rev 3

Mode Regulator

(1)

Table 4. STM32L431xx modes overview (continued)

CPU Flash SRAM Clocks DMA & Peripherals

(2)

Wakeup source Consumption

(3)

Functional overview STM32L431xx

Wakeup time

Standby

LPR

OFF

Power ed Off

Off

SRAM

2 ON

Power

Off

LSE

LSI

BOR, RTC, IWDG

***

All other peripherals are

powered off.

***

I/O configuration can be

Reset pin 5 I/Os (WKUPx) BOR, RTC, IWDG

0.20 µA w/o RTC

0.46 µA w/ RTC

(9)

0.03 µA w/o RTC

0.29 µA w/ RTC

floating, pull-up or pull-down

RTC

***

All other peripherals are

powered off.

***

Shutdown OFF

Power ed Off

Off

Power

Off

LSE

I/O configuration can be

floating, pull-up or pull-

1. LPR means Main regulator is OFF and Low-power regulator is ON.

2. All peripherals can be active or clock gated to save power consumption.

3. Typical current at V LPRun/LPSleep.

4. The Flash memory can be put in power-down and its clock can be gated off when executing from SRAM.

5. The SRAM1 and SRAM2 clocks can be gated on or off independently.

6. U(S)ART and LPUART reception is functional in Stop mode, and generates a wakeup interrupt on Start, address match or received frame event.

7. I2C address detection is functional in Stop mode, and generates a wakeup interrupt in case of address match.

8. SWPMI1 wakeup by resume from suspend.

9. The I/Os with wakeup from Standby/Shutdown capability are: PA0, PC13, PE6, PA2, PC5.

10. I/Os can be configured with internal pull-up, pull-down or floating in Shutdown mode but the configuration is lost when exiting the Shutdown mode.

= 1.8 V, 25°C. Consumptions values provided running from SRAM, Flash memory Off, 80 MHz in Range 1, 26 MHz in Range 2, 2 MHz in

down

(10)

Reset pin

5 I/Os (WKUPx)

RTC

0.01 µA w/o RTC

(9)

0.20 µA w/ RTC

12.2 µs

262 µs

STM32L431xx Functional overview

By default, the microcontroller is in Run mode after a system or a power Reset. It is up to the user to select one of the low-power modes described below:

• Sleep mode

In Sleep mode, only the CPU is stopped. All peripherals continue to operate and can wake up the CPU when an interrupt/event occurs.

• Low-power run mode

This mode is achieved with V

supplied by the low-power regulator to minimize the

CORE

regulator's operating current. The code can be executed from SRAM or from Flash, and the CPU frequency is limited to 2 MHz. The peripherals with independent clock can be clocked by HSI16.

• Low-power sleep mode

This mode is entered from the low-power run mode. Only the CPU clock is stopped. When wakeup is triggered by an event or an interrupt, the system reverts to the lowpower run mode.

• Stop 0, Stop 1 and Stop 2 modes

Stop mode achieves the lowest power consumption while retaining the content of SRAM and registers. All clocks in the V

domain are stopped, the PLL, the MSI

CORE

RC, the HSI16 RC and the HSE crystal oscillators are disabled. The LSE or LSI is still running.

The RTC can remain active (Stop mode with RTC, Stop mode without RTC).

Some peripherals with wakeup capability can enable the HSI16 RC during Stop mode to detect their wakeup condition.

Three Stop modes are available: Stop 0, Stop 1 and Stop 2 modes. In Stop 2 mode, most of the V

domain is put in a lower leakage mode.

CORE

Stop 1 offers the largest number of active peripherals and wakeup sources, a smaller wakeup time but a higher consumption than Stop 2. In Stop 0 mode, the main regulator remains ON, allowing a very fast wakeup time but with much higher consumption.

The system clock when exiting from Stop 0, Stop 1 or Stop 2 modes can be either MSI up to 48 MHz or HSI16, depending on software configuration.

• Standby mode

The Standby mode is used to achieve the lowest power consumption with BOR. The internal regulator is switched off so that the V

domain is powered off. The PLL, the

CORE

MSI RC, the HSI16 RC and the HSE crystal oscillators are also switched off.

The RTC can remain active (Standby mode with RTC, Standby mode without RTC).

The brown-out reset (BOR) always remains active in Standby mode.

The state of each I/O during standby mode can be selected by software: I/O with internal pull-up, internal pull-down or floating.

After entering Standby mode, SRAM1 and register contents are lost except for registers in the Backup domain and Standby circuitry. Optionally, SRAM2 can be retained in Standby mode, supplied by the low-power Regulator (Standby with SRAM2 retention mode).

The device exits Standby mode when an external reset (NRST pin), an IWDG reset, WKUP pin event (configurable rising or falling edge), or an RTC event occurs (alarm, periodic wakeup, timestamp, tamper) or a failure is detected on LSE (CSS on LSE).

The system clock after wakeup is MSI up to 8 MHz.

DS11453 Rev 3 27/208

Functional overview STM32L431xx

• Shutdown mode

The Shutdown mode allows to achieve the lowest power consumption. The internal regulator is switched off so that the V

domain is powered off. The PLL, the HSI16,

CORE

the MSI, the LSI and the HSE oscillators are also switched off.

The RTC can remain active (Shutdown mode with RTC, Shutdown mode without RTC).

The BOR is not available in Shutdown mode. No power voltage monitoring is possible in this mode, therefore the switch to Backup domain is not supported.

SRAM1, SRAM2 and register contents are lost except for registers in the Backup domain.

The device exits Shutdown mode when an external reset (NRST pin), a WKUP pin event (configurable rising or falling edge), or an RTC event occurs (alarm, periodic wakeup, timestamp, tamper).

The system clock after wakeup is MSI at 4 MHz.

28/208 DS11453 Rev 3

STM32L431xx Functional overview

Table 5. Functionalities depending on the working mode

(1)

Stop 0/1 Stop 2 Standby Shutdown

Peripheral Run Sleep

Low-

power

run

Low-

power

sleep

VBAT

Wakeup capability

CPU Y - Y - - --------

Flash memory (up to 256 KB)

SRAM1 (48 KB) Y Y

SRAM2 (16 KB) Y Y

Quad SPI O O O O -

Backup Registers Y Y Y Y Y

Brown-out reset (BOR)

(2)

(3)

(2)

(3)

- --------

Y -Y------

Y -Y-O

(4)

----

--------

-Y-Y-Y-Y

YYYYYYYYYY- --

Programmable Voltage Detector

OOOOO

OOO- ----

(PVD)

Peripheral Voltage Monitor (PVMx;

OOOOO

OOO- ----

x=1,3,4)

DMA OOOO-

--------

High Speed Internal (HSI16)

OOOO

(5)

------

Oscillator RC48 O O - - - --------

High Speed External (HSE)

Low Speed Internal (LSI)

Low Speed External (LSE)

Multi-Speed Internal (MSI)

Clock Security System (CSS)

Clock Security System on LSE

OOOO-

OOOOO

OOOO-

OOOOO

--------

-O-O----

-O-O-O-O

--------

OOOOO- --

RTC / Auto wakeup O O O O O OOOOOOOO

Number of RTC Tamper pins

USARTx (x=1,2,3) O O O O O

33333O3O3O3O3

(6)O(6)

- ------

DS11453 Rev 3 29/208

Functional overview STM32L431xx

Table 5. Functionalities depending on the working mode

Stop 0/1 Stop 2 Standby Shutdown

Low-

Peripheral Run Sleep

power

run

Low-power UART (LPUART)

OOOOO

I2Cx (x=1,2) O O O O O

I2C3 OOOOO

SPIx (x=1,2,3) O O O O -

CAN OOOO-

SDMMC1 O O O O -

SWPMI1 OOOO-

SAIx (x=1) O O O O -

ADCx (x=1) O O O O -

DAC1 O O O O O

Low-

power

sleep

(6)O(6)O(6)O(6)

(7)O(7)

(7)O(7)O(7)O(7)

--------

O- ------

--------

(1)

(continued)

Wakeup capability

- ----

- ------

- ----

VBAT

VREFBUF O O O O O

OPAMPx (x=1) O O O O O

COMPx (x=1,2) O O O O O

Temperature sensor O O O O -

Timers (TIMx) O O O O -

Low-power timer 1 (LPTIM1)

Low-power timer 2 (LPTIM2)

Independent watchdog (IWDG)

Window watchdog (WWDG)

OOOOO

OOOO-

--------

OOO- ----

--------

OOO- ----

O- ------

OOOOO- --

--------

SysTick timer O O O O - --------

Touch sensing controller (TSC)

Random number generator (RNG)

OOOO-

(8)

-----------

--------

CRC calculation unit O O O O - --------

GPIOs OOOOO

OOO

(9)

pins

(10)

(11)

pins

(10)

30/208 DS11453 Rev 3

STM32L431xx Functional overview

1. Legend: Y = Yes (Enable). O = Optional (Disable by default. Can be enabled by software). - = Not available.

2. The Flash can be configured in power-down mode. By default, it is not in power-down mode.

3. The SRAM clock can be gated on or off.

4. SRAM2 content is preserved when the bit RRS is set in PWR_CR3 register.

5. Some peripherals with wakeup from Stop capability can request HSI16 to be enabled. In this case, HSI16 is woken up by the peripheral, and only feeds the peripheral which requested it. HSI16 is automatically put off when the peripheral does not need it anymore.

6. UART and LPUART reception is functional in Stop mode, and generates a wakeup interrupt on Start, address match or received frame event.

7. I2C address detection is functional in Stop mode, and generates a wakeup interrupt in case of address match.

8. Voltage scaling Range 1 only.

9. I/Os can be configured with internal pull-up, pull-down or floating in Standby mode.

10. The I/Os with wakeup from Standby/Shutdown capability are: PA0, PC13, PE6, PA2, PC5.

11. I/Os can be configured with internal pull-up, pull-down or floating in Shutdown mode but the configuration is lost when exiting the Shutdown mode.

3.9.5 Reset mode

In order to improve the consumption under reset, the I/Os state under and after reset is “analog state” (the I/O schmitt trigger is disable). In addition, the internal reset pull-up is deactivated when the reset source is internal.

3.9.6 VBAT operation

The VBAT pin allows to power the device VBAT domain from an external battery, an external supercapacitor, or from V

when no external battery and an external supercapacitor are

present. The VBAT pin supplies the RTC with LSE and the backup registers. Three antitamper detection pins are available in VBAT mode.

VBAT operation is automatically activated when VDD is not present.

An internal VBAT battery charging circuit is embedded and can be activated when VDD is present.

Note: When the microcontroller is supplied from VBAT, external interrupts and RTC alarm/events

do not exit it from VBAT operation.

3.10 Interconnect matrix

Several peripherals have direct connections between them. This allows autonomous communication between peripherals, saving CPU resources thus power supply consumption. In addition, these hardware connections allow fast and predictable latency.

Depending on peripherals, these interconnections can operate in Run, Sleep, low-power run and sleep, Stop 0, Stop 1 and Stop 2 modes.

DS11453 Rev 3 31/208

Functional overview STM32L431xx

Table 6. STM32L431xx peripherals interconnect matrix

Interconnect source

Interconnect

destination

Interconnect action

Run

Sleep

Low-power run

Stop 0 / Stop 1

Low-power sleep

TIMx Timers synchronization or chaining Y Y Y Y - -

TIMx

ADCx DAC1

Conversion triggers Y Y Y Y - -

DMA Memory to memory transfer trigger Y Y Y Y - -

COMPx Comparator output blanking Y Y Y Y - -

TIM15/TIM16 IRTIM Infrared interface output generation Y Y Y Y - -

TIM1 TIM2

Timer input channel, trigger, break from analog signals comparison

YYYY - -

COMPx

LPTIMERx

Low-power timer triggered by analog signals comparison

YYYYY

ADCx TIM1 Timer triggered by analog watchdog Y Y Y Y - -

TIM16 Timer input channel from RTC events Y Y Y Y - -

RTC

LPTIMERx

Low-power timer triggered by RTC alarms or tampers

YYYYY

Stop 2

(1)

All clocks sources (internal and external)

CSS CPU (hard fault) RAM (parity error) Flash memory (ECC error) COMPx PVD

GPIO

1. LPTIM1 only.

TIM2 TIM15, 16

TIM1 TIM15,16

Clock source used as input channel for RC measurement and trimming

YYYY - -

Timer break Y Y Y Y - -

TIMx External trigger Y Y Y Y - -

LPTIMERx External trigger Y Y Y Y Y

ADCx DAC1

Conversion external trigger Y Y Y Y - -

(1)

32/208 DS11453 Rev 3

STM32L431xx Functional overview

3.11 Clocks and startup

The clock controller (see Figure 4) distributes the clocks coming from different oscillators to the core and the peripherals. It also manages clock gating for low-power modes and ensures clock robustness. It features:

• Clock prescaler: to get the best trade-off between speed and current consumption,

the clock frequency to the CPU and peripherals can be adjusted by a programmable prescaler

• Safe clock switching: clock sources can be changed safely on the fly in run mode

through a configuration register.

• Clock management: to reduce power consumption, the clock controller can stop the

clock to the core, individual peripherals or memory.

• System clock source: four different clock sources can be used to drive the master

clock SYSCLK:

– 4-48 MHz high-speed external crystal or ceramic resonator (HSE), that can supply

a PLL. The HSE can also be configured in bypass mode for an external clock.

– 16 MHz high-speed internal RC oscillator (HSI16), trimmable by software, that can

supply a PLL

– Multispeed internal RC oscillator (MSI), trimmable by software, able to generate

12 frequencies from 100 kHz to 48 MHz. When a 32.768 kHz clock source is available in the system (LSE), the MSI frequency can be automatically trimmed by hardware to reach better than ±0.25% accuracy. The MSI can supply a PLL.

– System PLL which can be fed by HSE, HSI16 or MSI, with a maximum frequency

at 80 MHz.

• RC48 with clock recovery system (HSI48): internal RC48 MHz clock source can be

used to drive the SDMMC or the RNG peripherals. This clock can be output on the MCO.

• Auxiliary clock source: two ultralow-power clock sources that can be used to drive

the real-time clock:

– 32.768 kHz low-speed external crystal (LSE), supporting four drive capability

modes. The LSE can also be configured in bypass mode for an external clock.

– 32 kHz low-speed internal RC (LSI), also used to drive the independent watchdog.

The LSI clock accuracy is ±5% accuracy.

• Peripheral clock sources: Several peripherals (SDMMC, RNG, SAI, USARTs, I2Cs,

LPTimers, ADC, SWPMI) have their own independent clock whatever the system clock. Two PLLs, each having three independent outputs allowing the highest flexibility, can generate independent clocks for the ADC, the SDMMC/RNG and the SAI.

• Startup clock: after reset, the microcontroller restarts by default with an internal 4 MHz

clock (MSI). The prescaler ratio and clock source can be changed by the application program as soon as the code execution starts.

• Clock security system (CSS): this feature can be enabled by software. If a HSE clock

failure occurs, the master clock is automatically switched to HSI16 and a software

DS11453 Rev 3 33/208

Functional overview STM32L431xx

interrupt is generated if enabled. LSE failure can also be detected and generated an interrupt.

• Clock-out capability:

– MCO: microcontroller clock output: it outputs one of the internal clocks for

external use by the application. Low frequency clocks (LSI, LSE) are available down to Stop 1 low power state.

– LSCO: low speed clock output: it outputs LSI or LSE in all low-power modes

down to Standby mode. LSE can also be output on LSCO in Shutdown mode. LSCO is not available in VBAT mode.

Several prescalers allow to configure the AHB frequency, the high speed APB (APB2) and the low speed APB (APB1) domains. The maximum frequency of the AHB and the APB domains is 80 MHz.

34/208 DS11453 Rev 3

STM32L431xx Functional overview

MSv39206V3

SYSCLK

MCO

LSCO

48 MHz clock to RNG, SDMMC

to ADC

to IWDG

to RTC

to PWR

HCLK

to AHB bus, core, memory and DMA

FCLK Cortex free running clock

to Cortex system timer

to APB1 peripherals

to APB2 peripherals

PCLK1

PCLK2

to SAI1

LSE

HSI16

SYSCLK

to USARTx

x=2..3

to LPUART1

to I2Cx x=1,2,3

to LPTIMx

x=1,2

SAI1_EXTCLK

to SWPMI

to TIMx x=2,6,7

OSC32_OUT

OSC32_IN

MSI

HSI16

HSE

HSI16

LSI

LSE

HSE

SYSCLK

HSE

MSI

HSI16

MSI

SYSCLK

LSE OSC

32.768 kHz

/32

AHB PRESC

/ 1,2,..512

/ 8

APB1 PRESC / 1,2,4,8,16

x1 or x2

HSI16

SYSCLK

LSI

LSE

HSI16

APB2 PRESC / 1,2,4,8,16

to TIMx

x=1,15,16

x1 or x2

to USART1

LSE

HSI16

SYSCLK

/ M

MSI RC

100 kHz – 48 MHz

HSI RC

16 MHz

HSE OSC

4-48 MHz

Clock

detector

OSC_OUT

OSC_IN

/ 1→16

LSI RC 32 kHz

Clock source control

PLLSAI1CLK

PLL48M1CLK

PLLCLK

PLLSAI2CLK

PLL48M2CLK

PLLADC1CLK

HSI16

HSI RC 48 MHz

HSI48

CRS

PLL

PLLSAI1

VCO

/ P

/ R

/ Q

/ P

/ Q

/ R

VCO

PLLCLK

MSI

Figure 4. Clock tree

DS11453 Rev 3 35/208

Functional overview STM32L431xx

3.12 General-purpose inputs/outputs (GPIOs)

Each of the GPIO pins can be configured by software as output (push-pull or open-drain), as input (with or without pull-up or pull-down) or as peripheral alternate function. Most of the GPIO pins are shared with digital or analog alternate functions. Fast I/O toggling can be achieved thanks to their mapping on the AHB2 bus.

The I/Os alternate function configuration can be locked if needed following a specific sequence in order to avoid spurious writing to the I/Os registers.

3.13 Direct memory access controller (DMA)

The device embeds 2 DMAs. Refer to Tab le 7: DMA implementation for the features implementation.

Direct memory access (DMA) is used in order to provide high-speed data transfer between peripherals and memory as well as memory to memory. Data can be quickly moved by DMA without any CPU actions. This keeps CPU resources free for other operations.

The two DMA controllers have 14 channels in total, each dedicated to managing memory access requests from one or more peripherals. Each has an arbiter for handling the priority between DMA requests.

The DMA supports:

• 14 independently configurable channels (requests)

• Each channel is connected to dedicated hardware DMA requests, software trigger is

also supported on each channel. This configuration is done by software.

• Priorities between requests from channels of one DMA are software programmable (4 levels consisting of very high, high, medium, low) or hardware in case of equality (request 1 has priority over request 2, etc.)

• Independent source and destination transfer size (byte, half word, word), emulating packing and unpacking. Source/destination addresses must be aligned on the data size.

• Support for circular buffer management

• 3 event flags (DMA Half Transfer, DMA Transfer complete and DMA Transfer Error)

logically ORed together in a single interrupt request for each channel

• Memory-to-memory transfer

• Peripheral-to-memory and memory-to-peripheral, and peripheral-to-peripheral

transfers

• Access to Flash, SRAM, APB and AHB peripherals as source and destination

• Programmable number of data to be transferred: up to 65536.

DMA features DMA1 DMA2

Table 7. DMA implementation

Number of regular channels 7 7

36/208 DS11453 Rev 3

STM32L431xx Functional overview

3.14 Interrupts and events

3.14.1 Nested vectored interrupt controller (NVIC)

The devices embed a nested vectored interrupt controller able to manage 16 priority levels, and handle up to 67 maskable interrupt channels plus the 16 interrupt lines of the Cortex M4.

The NVIC benefits are the following:

• Closely coupled NVIC gives low latency interrupt processing

• Interrupt entry vector table address passed directly to the core

• Allows early processing of interrupts

• Processing of late arriving higher priority interrupts

• Support for tail chaining

• Processor state automatically saved on interrupt entry, and restored on interrupt exit,

with no instruction overhead

The NVIC hardware block provides flexible interrupt management features with minimal interrupt latency.

3.14.2 Extended interrupt/event controller (EXTI)

The extended interrupt/event controller consists of 37 edge detector lines used to generate interrupt/event requests and wake-up the system from Stop mode. Each external line can be independently configured to select the trigger event (rising edge, falling edge, both) and can be masked independently. A pending register maintains the status of the interrupt requests. The internal lines are connected to peripherals with wakeup from Stop mode capability. The EXTI can detect an external line with a pulse width shorter than the internal clock period. Up to 83 GPIOs can be connected to the 16 external interrupt lines.

DS11453 Rev 3 37/208

Functional overview STM32L431xx

3.15 Analog to digital converter (ADC)

The device embeds a successive approximation analog-to-digital converter with the following features:

• 12-bit native resolution, with built-in calibration

• 5.33 Msps maximum conversion rate with full resolution

– Down to 18.75 ns sampling time

– Increased conversion rate for lower resolution (up to 8.88 Msps for 6-bit

resolution)

• Up to 16 external channels.

• 5 internal channels: internal reference voltage, temperature sensor, VBAT/3,

DAC1_OUT1 and DAC1_OUT2.

• One external reference pin is available on some package, allowing the input voltage range to be independent from the power supply

• Single-ended and differential mode inputs

• Low-power design

– Capable of low-current operation at low conversion rate (consumption decreases

linearly with speed)

– Dual clock domain architecture: ADC speed independent from CPU frequency

• Highly versatile digital interface

– Single-shot or continuous/discontinuous sequencer-based scan mode: 2 groups

of analog signals conversions can be programmed to differentiate background and high-priority real-time conversions

– ADC supports multiple trigger inputs for synchronization with on-chip timers and

external signals

– Results stored into data register or in RAM with DMA controller support

– Data pre-processing: left/right alignment and per channel offset compensation

– Built-in oversampling unit for enhanced SNR

– Channel-wise programmable sampling time

– Three analog watchdog for automatic voltage monitoring, generating interrupts

and trigger for selected timers

– Hardware assistant to prepare the context of the injected channels to allow fast

context switching

3.15.1 Temperature sensor

The temperature sensor (TS) generates a voltage VTS that varies linearly with temperature.

The temperature sensor is internally connected to the ADC1_IN17 input channel which is used to convert the sensor output voltage into a digital value.

The sensor provides good linearity but it has to be calibrated to obtain good overall accuracy of the temperature measurement. As the offset of the temperature sensor varies from chip to chip due to process variation, the uncalibrated internal temperature sensor is suitable for applications that detect temperature changes only.

To improve the accuracy of the temperature sensor measurement, each device is individually factory-calibrated by ST. The temperature sensor factory calibration data are stored by ST in the system memory area, accessible in read-only mode.

38/208 DS11453 Rev 3

STM32L431xx Functional overview

Calibration value name Description Memory address

TS_CAL1

TS_CAL2

Table 8. Temperature sensor calibration values

TS ADC raw data acquired at a temperature of 30 °C (± 5 °C), V

DDA

TS ADC raw data acquired at a temperature of 130 °C (± 5 °C), V

DDA

3.15.2 Internal voltage reference (V

The internal voltage reference (VREFINT) provides a stable (bandgap) voltage output for the ADC and Comparators. VREFINT is internally connected to the ADC1_IN0 input channel. The precise voltage of VREFINT is individually measured for each part by ST during production test and stored in the system memory area. It is accessible in read-only mode.

Calibration value name Description Memory address

Table 9. Internal voltage reference calibration values

Raw data acquired at a

VREFINT

temperature of 30 °C (± 5 °C), V

DDA

= V

REF+

= V

REF+

REFINT

= V

REF+

0x1FFF 75A8 - 0x1FFF 75A9

= 3.0 V (± 10 mV)

0x1FFF 75CA - 0x1FFF 75CB

= 3.0 V (± 10 mV)

)

0x1FFF 75AA - 0x1FFF 75AB

= 3.0 V (± 10 mV)

3.15.3 V

battery voltage monitoring

BAT

This embedded hardware feature allows the application to measure the V using the internal ADC channel ADC1_IN18. As the V and thus outside the ADC input range, the VBAT pin is internally connected to a bridge divider by 3. As a consequence, the converted digital value is one third the V

3.16 Digital to analog converter (DAC)

Two 12-bit buffered DAC channels can be used to convert digital signals into analog voltage signal outputs. The chosen design structure is composed of integrated resistor strings and an amplifier in inverting configuration.

battery voltage

voltage may be higher than V

BAT

DDA

voltage.

DS11453 Rev 3 39/208

Functional overview STM32L431xx

MSv40197V1

VREFBUF

Low frequency cut-off capacitor

DAC, ADC

Bandgap +

DDA

100 nF

VREF+

This digital interface supports the following features:

• Up to two DAC output channels

• 8-bit or 12-bit output mode

• Buffer offset calibration (factory and user trimming)

• Left or right data alignment in 12-bit mode

• Synchronized update capability

• Noise-wave generation

• Triangular-wave generation

• Dual DAC channel independent or simultaneous conversions

• DMA capability for each channel

• External triggers for conversion

• Sample and hold low-power mode, with internal or external capacitor

The DAC channels are triggered through the timer update outputs that are also connected to different DMA channels.

3.17 Voltage reference buffer (VREFBUF)

The STM32L431xx devices embed an voltage reference buffer which can be used as voltage reference for ADCs, DAC and also as voltage reference for external components through the VREF+ pin.

The internal voltage reference buffer supports two voltages:

• 2.048 V

• 2.5 V

An external voltage reference can be provided through the VREF+ pin when the internal voltage reference buffer is off.

The VREF+ pin is double-bonded with VDDA on some packages. In these packages the internal voltage reference buffer is not available.

Figure 5. Voltage reference buffer

40/208 DS11453 Rev 3

STM32L431xx Functional overview

3.18 Comparators (COMP)

The STM32L431xx devices embed two rail-to-rail comparators with programmable reference voltage (internal or external), hysteresis and speed (low speed for low-power) and with selectable output polarity.

The reference voltage can be one of the following:

• External I/O

• DAC output channels

• Internal reference voltage or submultiple (1/4, 1/2, 3/4).

All comparators can wake up from Stop mode, generate interrupts and breaks for the timers and can be also combined into a window comparator.

3.19 Operational amplifier (OPAMP)

The STM32L431xx embeds one operational amplifier with external or internal follower routing and PGA capability.

The operational amplifier features:

• Low input bias current

• Low offset voltage

• Low-power mode

• Rail-to-rail input

3.20 Touch sensing controller (TSC)

The touch sensing controller provides a simple solution for adding capacitive sensing functionality to any application. Capacitive sensing technology is able to detect finger presence near an electrode which is protected from direct touch by a dielectric (glass, plastic, ...). The capacitive variation introduced by the finger (or any conductive object) is measured using a proven implementation based on a surface charge transfer acquisition principle.

The touch sensing controller is fully supported by the STMTouch touch sensing firmware library which is free to use and allows touch sensing functionality to be implemented reliably in the end application.

DS11453 Rev 3 41/208

Functional overview STM32L431xx

The main features of the touch sensing controller are the following:

• Proven and robust surface charge transfer acquisition principle

• Supports up to 21 capacitive sensing channels

• Up to 3 capacitive sensing channels can be acquired in parallel offering a very good

response time

• Spread spectrum feature to improve system robustness in noisy environments

• Full hardware management of the charge transfer acquisition sequence

• Programmable charge transfer frequency

• Programmable sampling capacitor I/O pin

• Programmable channel I/O pin

• Programmable max count value to avoid long acquisition when a channel is faulty

• Dedicated end of acquisition and max count error flags with interrupt capability

• One sampling capacitor for up to 3 capacitive sensing channels to reduce the system

components

• Compatible with proximity, touchkey, linear and rotary touch sensor implementation

• Designed to operate with STMTouch touch sensing firmware library

Note: The number of capacitive sensing channels is dependent on the size of the packages and

subject to I/O availability.

3.21 Random number generator (RNG)

All devices embed an RNG that delivers 32-bit random numbers generated by an integrated analog circuit.

3.22 Timers and watchdogs

The STM32L431xx includes one advanced control timers, up to five general-purpose timers, two basic timers, two low-power timers, two watchdog timers and a SysTick timer. The table below compares the features of the advanced control, general purpose and basic timers.

Timer type Timer

Advanced

control

General-

purpose

General-

purpose

TIM1 16-bit

TIM2 32-bit

TIM15 16-bit Up

Table 10. Timer feature comparison

Counter

resolution

Counter

type

Up, down,

Up/down

Up, down,

Up/down

Prescaler

factor

Any integer

between 1

and 65536

Any integer

between 1 and 65536

Any integer

between 1 and 65536

DMA

request

generation

Yes 4 3

Yes 4 No

Yes 2 1

Capture/ compare

channels

Complementary

outputs

42/208 DS11453 Rev 3

STM32L431xx Functional overview

Table 10. Timer feature comparison (continued)

Timer type Timer

General-

purpose

Basic TIM6, TIM7 16-bit Up

TIM16 16-bit Up

Counter

resolution

Counter

type

3.22.1 Advanced-control timer (TIM1)

The advanced-control timer can each be seen as a three-phase PWM multiplexed on 6 channels. They have complementary PWM outputs with programmable inserted deadtimes. They can also be seen as complete general-purpose timers. The 4 independent channels can be used for:

• Input capture

• Output compare

• PWM generation (edge or center-aligned modes) with full modulation capability (0-

100%)

• One-pulse mode output

In debug mode, the advanced-control timer counter can be frozen and the PWM outputs disabled to turn off any power switches driven by these outputs.

Prescaler

factor

Any integer

between 1 and 65536

Any integer

between 1 and 65536

DMA

request

generation

Yes 1 1

Yes 0 No

Capture/ compare

channels

Complementary

outputs

Many features are shared with those of the general-purpose TIMx timers (described in

Section 3.22.2) using the same architecture, so the advanced-control timer can work

together with the TIMx timers via the Timer Link feature for synchronization or event chaining.

DS11453 Rev 3 43/208

Functional overview STM32L431xx

3.22.2 General-purpose timers (TIM2, TIM15, TIM16)

There are up to three synchronizable general-purpose timers embedded in the STM32L431xx (see generate PWM outputs, or act as a simple time base.

• TIM2

It is a full-featured general-purpose timer:

TIM2 has a 32-bit auto-reload up/downcounter and 32-bit prescaler.

This timer features 4 independent channels for input capture/output compare, PWM or one-pulse mode output. It can work with the other general-purpose timers via the Timer Link feature for synchronization or event chaining.

The counter can be frozen in debug mode.

It has independent DMA request generation and support quadrature encoder.

• TIM15 and 16

They are general-purpose timers with mid-range features:

They have 16-bit auto-reload upcounters and 16-bit prescalers.

– TIM15 has 2 channels and 1 complementary channel

– TIM16 has 1 channel and 1 complementary channel

All channels can be used for input capture/output compare, PWM or one-pulse mode output.

The timers can work together via the Timer Link feature for synchronization or event chaining. The timers have independent DMA request generation.

The counters can be frozen in debug mode.

Tabl e 10 for differences). Each general-purpose timer can be used to

3.22.3 Basic timers (TIM6 and TIM7)

The basic timers are mainly used for DAC trigger generation. They can also be used as generic 16-bit timebases.

3.22.4 Low-power timer (LPTIM1 and LPTIM2)

The devices embed two low-power timers. These timers have an independent clock and are running in Stop mode if they are clocked by LSE, LSI or an external clock. They are able to wakeup the system from Stop mode.

LPTIM1 is active in Stop 0, Stop 1 and Stop 2 modes.

LPTIM2 is active in Stop 0 and Stop 1 mode.

44/208 DS11453 Rev 3

STM32L431xx Functional overview

This low-power timer supports the following features:

• 16-bit up counter with 16-bit autoreload register

• 16-bit compare register

• Configurable output: pulse, PWM

• Continuous/ one shot mode

• Selectable software/hardware input trigger

• Selectable clock source

– Internal clock sources: LSE, LSI, HSI16 or APB clock

– External clock source over LPTIM input (working even with no internal clock

source running, used by pulse counter application).

• Programmable digital glitch filter

• Encoder mode (LPTIM1 only)

3.22.5 Infrared interface (IRTIM)

The STM32L431xx includes one infrared interface (IRTIM). It can be used with an infrared LED to perform remote control functions. It uses TIM15 and TIM16 output channels to generate output signal waveforms on IR_OUT pin.

3.22.6 Independent watchdog (IWDG)

The independent watchdog is based on a 12-bit downcounter and 8-bit prescaler. It is clocked from an independent 32 from the main clock, it can operate in Stop and Standby modes. It can be used either as a watchdog to reset the device when a problem occurs, or as a free running timer for application timeout management. It is hardware or software configurable through the option bytes. The counter can be frozen in debug mode.

kHz internal RC (LSI) and as it operates independently

3.22.7 System window watchdog (WWDG)

The window watchdog is based on a 7-bit downcounter that can be set as free running. It can be used as a watchdog to reset the device when a problem occurs. It is clocked from the main clock. It has an early warning interrupt capability and the counter can be frozen in debug mode.

3.22.8 SysTick timer

This timer is dedicated to real-time operating systems, but could also be used as a standard down counter. It features:

• A 24-bit down counter

• Autoreload capability

• Maskable system interrupt generation when the counter reaches 0.

• Programmable clock source

DS11453 Rev 3 45/208

Functional overview STM32L431xx

3.23 Real-time clock (RTC) and backup registers

The RTC is an independent BCD timer/counter. It supports the following features:

• Calendar with subsecond, seconds, minutes, hours (12 or 24 format), week day, date, month, year, in BCD (binary-coded decimal) format.

• Automatic correction for 28, 29 (leap year), 30, and 31 days of the month.

• Two programmable alarms.

• On-the-fly correction from 1 to 32767 RTC clock pulses. This can be used to

synchronize it with a master clock.

• Reference clock detection: a more precise second source clock (50 or 60 Hz) can be used to enhance the calendar precision.

• Digital calibration circuit with 0.95 ppm resolution, to compensate for quartz crystal inaccuracy.

• Three anti-tamper detection pins with programmable filter.

• Timestamp feature which can be used to save the calendar content. This function can

be triggered by an event on the timestamp pin, or by a tamper event, or by a switch to VBAT mode.

• 17-bit auto-reload wakeup timer (WUT) for periodic events with programmable resolution and period.

The RTC and the 32 backup registers are supplied through a switch that takes power either from the V

supply when present or from the VBAT pin.

The backup registers are 32-bit registers used to store 128 bytes of user application data when V

power is not present. They are not reset by a system or power reset, or when the

device wakes up from Standby or Shutdown mode.

The RTC clock sources can be:

• A 32.768 kHz external crystal (LSE)

• An external resonator or oscillator (LSE)

• The internal low power RC oscillator (LSI, with typical frequency of 32 kHz)

• The high-speed external clock (HSE) divided by 32.

The RTC is functional in VBAT mode and in all low-power modes when it is clocked by the LSE. When clocked by the LSI, the RTC is not functional in VBAT mode, but is functional in all low-power modes except Shutdown mode.

All RTC events (Alarm, WakeUp Timer, Timestamp or Tamper) can generate an interrupt and wakeup the device from the low-power modes.

46/208 DS11453 Rev 3

STM32L431xx Functional overview

3.24 Inter-integrated circuit interface (I2C)

The device embeds three I2C. Refer to Table 11: I2C implementation for the features implementation.

The I2C bus interface handles communications between the microcontroller and the serial

C bus. It controls all I2C bus-specific sequencing, protocol, arbitration and timing.

The I2C peripheral supports:

• I2C-bus specification and user manual rev. 5 compatibility:

– Slave and master modes, multimaster capability

– Standard-mode (Sm), with a bitrate up to 100 kbit/s

– Fast-mode (Fm), with a bitrate up to 400 kbit/s

– Fast-mode Plus (Fm+), with a bitrate up to 1 Mbit/s and 20 mA output drive I/Os

– 7-bit and 10-bit addressing mode, multiple 7-bit slave addresses

– Programmable setup and hold times

– Optional clock stretching

• System Management Bus (SMBus) specification rev 2.0 compatibility:

– Hardware PEC (Packet Error Checking) generation and verification with ACK

control

– Address resolution protocol (ARP) support

– SMBus alert

• Power System Management Protocol (PMBus

• Independent clock: a choice of independent clock sources allowing the I2C

communication speed to be independent from the PCLK reprogramming. Refer to

Figure 4: Clock tree.

• Wakeup from Stop mode on address match

• Programmable analog and digital noise filters

• 1-byte buffer with DMA capability

I2C features

Table 11. I2C implementation

(1)

) specification rev 1.1 compatibility

I2C1 I2C2 I2C3

Standard-mode (up to 100 kbit/s) X X X

Fast-mode (up to 400 kbit/s) X X X

Fast-mode Plus with 20mA output drive I/Os (up to 1 Mbit/s) X X X

Programmable analog and digital noise filters X X X

SMBus/PMBus hardware support X X X

Independent clock X X X

Wakeup from Stop 0 / Stop 1 mode on address match X X X

Wakeup from Stop 2 mode on address match - - X

1. X: supported

DS11453 Rev 3 47/208

Functional overview STM32L431xx

3.25 Universal synchronous/asynchronous receiver transmitter (USART)

The STM32L431xx devices have three embedded universal synchronous receiver transmitters (USART1, USART2 and USART3).

These interfaces provide asynchronous communication, IrDA SIR ENDEC support, multiprocessor communication mode, single-wire half-duplex communication mode and have LIN Master/Slave capability. They provide hardware management of the CTS and RTS signals, and RS485 Driver Enable. They are able to communicate at speeds of up to 10Mbit/s.

USART1, USART2 and USART3 also provide Smart Card mode (ISO 7816 compliant) and SPI-like communication capability.

All USART have a clock domain independent from the CPU clock, allowing the USARTx (x=1,2,3) to wake up the MCU from Stop mode using baudrates up to 204 up events from Stop mode are programmable and can be:

• Start bit detection

• Any received data frame

• A specific programmed data frame

All USART interfaces can be served by the DMA controller.

USART modes/features

Table 12. STM32L431xx USART/LPUART features

(1)

USART1 USART2 USART3 LPUART1

Kbaud. The wake

Hardware flow control for modem X X X X

Continuous communication using DMA X X X X

Multiprocessor communication X X X X

Synchronous mode X X X -

Smartcard mode X X X -

Single-wire half-duplex communication X X X X

IrDA SIR ENDEC block X X X -

LIN mode X X X -

Dual clock domain X X X X

Wakeup from Stop 0 / Stop 1 modes X X X X

Wakeup from Stop 2 mode - - - X

Receiver timeout interrupt X X X -

Modbus communication X X X -

Auto baud rate detection X (4 modes) -

Driver Enable X X X X

LPUART/USART data length 7, 8 and 9 bits

1. X = supported.

48/208 DS11453 Rev 3

STM32L431xx Functional overview

3.26 Low-power universal asynchronous receiver transmitter (LPUART)

The device embeds one Low-Power UART. The LPUART supports asynchronous serial communication with minimum power consumption. It supports half duplex single wire communication and modem operations (CTS/RTS). It allows multiprocessor communication.

The LPUART has a clock domain independent from the CPU clock, and can wakeup the system from Stop mode using baudrates up to 220 mode are programmable and can be:

• Start bit detection

• Any received data frame

• A specific programmed data frame

Only a 32.768 kHz clock (LSE) is needed to allow LPUART communication up to 9600 baud. Therefore, even in Stop mode, the LPUART can wait for an incoming frame while having an extremely low energy consumption. Higher speed clock can be used to reach higher baudrates.

LPUART interface can be served by the DMA controller.

Kbaud. The wake up events from Stop

DS11453 Rev 3 49/208

Functional overview STM32L431xx

3.27 Serial peripheral interface (SPI)

Three SPI interfaces allow communication up to 40 Mbits/s in master and up to 24 Mbits/s slave modes, in half-duplex, full-duplex and simplex modes. The 3-bit prescaler gives 8 master mode frequencies and the frame size is configurable from 4 bits to 16 bits. The SPI interfaces support NSS pulse mode, TI mode and Hardware CRC calculation.

All SPI interfaces can be served by the DMA controller.

3.28 Serial audio interfaces (SAI)

The device embeds 1 SAI. Refer to Tab le 13: SAI implementation for the features implementation. The SAI bus interface handles communications between the microcontroller and the serial audio protocol.

The SAI peripheral supports:

• Two independent audio sub-blocks which can be transmitters or receivers with their

respective FIFO.

• 8-word integrated FIFOs for each audio sub-block.

• Synchronous or asynchronous mode between the audio sub-blocks.

• Master or slave configuration independent for both audio sub-blocks.

• Clock generator for each audio block to target independent audio frequency sampling

when both audio sub-blocks are configured in master mode.

• Data size configurable: 8-, 10-, 16-, 20-, 24-, 32-bit.

• Peripheral with large configurability and flexibility allowing to target as example the

following audio protocol: I2S, LSB or MSB-justified, PCM/DSP, TDM, AC’97 and SPDIF out.

• Up to 16 slots available with configurable size and with the possibility to select which

ones are active in the audio frame.

• Number of bits by frame may be configurable.

• Frame synchronization active level configurable (offset, bit length, level).

• First active bit position in the slot is configurable.

• LSB first or MSB first for data transfer.

• Mute mode.

• Stereo/Mono audio frame capability.

• Communication clock strobing edge configurable (SCK).

• Error flags with associated interrupts if enabled respectively.

– Overrun and underrun detection.

– Anticipated frame synchronization signal detection in slave mode.

– Late frame synchronization signal detection in slave mode.

– Codec not ready for the AC’97 mode in reception.

• Interruption sources when enabled:

–Errors.

– FIFO requests.

• DMA interface with 2 dedicated channels to handle access to the dedicated integrated

FIFO of each SAI audio sub-block.

50/208 DS11453 Rev 3

STM32L431xx Functional overview

I2S, LSB or MSB-justified, PCM/DSP, TDM, AC’97 X

Mute mode X

Stereo/Mono audio frame capability. X

16 slots X

Data size configurable: 8-, 10-, 16-, 20-, 24-, 32-bit X

FIFO Size X (8 Word)

SPDIF X

1. X: supported

Table 13. SAI implementation

SAI features Support

3.29 Single wire protocol master interface (SWPMI)

The Single wire protocol master interface (SWPMI) is the master interface corresponding to the Contactless Frontend (CLF) defined in the ETSI TS 102 613 technical specification. The main features are:

• full-duplex communication mode

• automatic SWP bus state management (active, suspend, resume)

• configurable bitrate up to 2 Mbit/s

• automatic SOF, EOF and CRC handling

(1)

SWPMI can be served by the DMA controller.

3.30 Controller area network (CAN)

The CAN is compliant with specifications 2.0A and B (active) with a bit rate up to 1 Mbit/s. It can receive and transmit standard frames with 11-bit identifiers as well as extended frames with 29-bit identifiers. It has three transmit mailboxes, two receive FIFOs with 3 stages and 14 scalable filter banks.

DS11453 Rev 3 51/208

Functional overview STM32L431xx

The CAN peripheral supports:

• Supports CAN protocol version 2.0 A, B Active

• Bit rates up to 1 Mbit/s

• Transmission

– Three transmit mailboxes

– Configurable transmit priority

• Reception

– Two receive FIFOs with three stages

– 14 Scalable filter banks

– Identifier list feature

– Configurable FIFO overrun

• Time-triggered communication option

– Disable automatic retransmission mode

– 16-bit free running timer

– Time Stamp sent in last two data bytes

• Management

– Maskable interrupts

– Software-efficient mailbox mapping at a unique address space

3.31 Secure digital input/output and MultiMediaCards Interface (SDMMC)

The card host interface (SDMMC) provides an interface between the APB peripheral bus and MultiMediaCards (MMCs), SD memory cards and SDIO cards.

The SDMMC features include the following:

• Full compliance with MultiMediaCard System Specification Version 4.2. Card support

for three different databus modes: 1-bit (default), 4-bit and 8-bit

• Full compatibility with previous versions of MultiMediaCards (forward compatibility)

• Full compliance with SD Memory Card Specifications Version 2.0

• Full compliance with SD I/O Card Specification Version 2.0: card support for two

different databus modes: 1-bit (default) and 4-bit

• Data transfer up to 48 MHz for the 8 bit mode

• Data write and read with DMA capability

3.32 Clock recovery system (CRS)

The STM32L431xx devices embed a special block which allows automatic trimming of the internal 48 operational range. This automatic trimming is based on the external synchronization signal, which could be either derived from LSE oscillator, from an external signal on CRS_SYNC pin or generated by user software. For faster lock-in during startup it is also possible to combine automatic trimming with manual trimming action.

MHz oscillator to guarantee its optimal accuracy over the whole device

52/208 DS11453 Rev 3

STM32L431xx Functional overview

3.33 Quad SPI memory interface (QUADSPI)

The Quad SPI is a specialized communication interface targeting single, dual or quad SPI flash memories. It can operate in any of the three following modes:

• Indirect mode: all the operations are performed using the QUADSPI registers

• Status polling mode: the external flash status register is periodically read and an

interrupt can be generated in case of flag setting

• Memory-mapped mode: the external Flash is memory mapped and is seen by the

system as if it were an internal memory

Both throughput and capacity can be increased two-fold using dual-flash mode, where two Quad SPI flash memories are accessed simultaneously.

The Quad SPI interface supports:

• Three functional modes: indirect, status-polling, and memory-mapped

• Dual-flash mode, where 8 bits can be sent/received simultaneously by accessing two

flash memories in parallel.

• SDR and DDR support

• Fully programmable opcode for both indirect and memory mapped mode

• Fully programmable frame format for both indirect and memory mapped mode

• Each of the 5 following phases can be configured independently (enable, length,

single/dual/quad communication)

– Instruction phase

– Address phase

– Alternate bytes phase

– Dummy cycles phase

– Data phase

• Integrated FIFO for reception and transmission

• 8, 16, and 32-bit data accesses are allowed

• DMA channel for indirect mode operations

• Programmable masking for external flash flag management

• Timeout management

• Interrupt generation on FIFO threshold, timeout, status match, operation complete, and

access error

DS11453 Rev 3 53/208

Functional overview STM32L431xx

3.34 Development support

3.34.1 Serial wire JTAG debug port (SWJ-DP)

The Arm® SWJ-DP interface is embedded, and is a combined JTAG and serial wire debug port that enables either a serial wire debug or a JTAG probe to be connected to the target.

Debug is performed using 2 pins only instead of 5 required by the JTAG (JTAG pins could be re-use as GPIO with alternate function): the JTAG TMS and TCK pins are shared with SWDIO and SWCLK, respectively, and a specific sequence on the TMS pin is used to switch between JTAG-DP and SW-DP.

3.34.2 Embedded Trace Macrocell™

The Arm® Embedded Trace Macrocell™ provides a greater visibility of the instruction and data flow inside the CPU core by streaming compressed data at a very high rate from the STM32L431xx through a small number of ETM pins to an external hardware trace port analyzer (TPA) device. Real-time instruction and data flow activity be recorded and then formatted for display on the host computer that runs the debugger software. TPA hardware is commercially available from common development tool vendors.

The Embedded Trace Macrocell™ operates with third party debugger software tools.

54/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

MSv39214V2

LQFP100

VSS

PH0-OSC_IN

PH1-OSC_OUT

NRST

PC0

PC1

PC2

PC3

VSSA

VREF-

VREF+

VDDA

PA0

PA1

PA2

PC15-OSC32_OUT

VDD

PE5

VBAT

PC14-OSC32_IN

PE2

PE3

PE4

PE6

PC13

89888786858483828180797877

100

37383940414243444546474849

262728

PA3

VSS

PA5

PC4

PB2

VDD

PA4

PC5

PE8

PE11

PA6

PA7

PE9

PE12

PE15

PB0

PB1

PE13

PB10

VSS

PE7

PE10

PE14

PB11

VDD

PC9

PC7

PC6

PD15

PD14

PD13

PD12

PD11

PD10

PD9

PD8

PB15

PB14

PB13

PB12

PA8

PC8

PA13

PA11

PA9

VDD

VSS

VDD

PA12

PA10

VDD

VSS

PB9

PB7

PB3

PE1

PE0

PB6

PD6

PD3

PB8

PH3/BOOT0

PD5

PD2

PC12

PB5

PB4

PD1

PC11

PA15

PD7

PD4

PD0

PC10

PA14

4 Pinouts and pin description

Figure 6. STM32L431Vx LQFP100 pinout

(1)

1. The above figure shows the package top view.

DS11453 Rev 3 55/208

Pinouts and pin description STM32L431xx

MSv39213V2

PE3 PE1 PB8 PH3/BOOT0 PD7 PD5 PB4 PB3 PA15 PA14 PA13 PA12

123456789101112

PE4 PE2 PB9 PB7 PB6 PD6 PD4 PD3 PD1 PC12 PC10 PA 11

PC13 PE5 PE0 VDD PB5 PD2 PD0 PC11 VDD PA10

PC14-

OSC32_IN

PE6 VSS PA9 PA 8 PC9

PC15-

OSC32_OUT

VBAT VSS PC8 PC7 PC6

PH0-OSC_IN VSS VSS VSS

PH1-

OSC_OUT

VDD VDD VDD

PC0 NRST VDD PD15 PD14 PD13

VSSA PC1 PC2 PD12 PD11 PD10

VREF- PC3 PA2 PA5 PC4 PD9 PD8 PB15 PB14 PB13

VREF+ PA0 PA 3 PA6 PC5 PB2 PE8 PE10 PE12 PB10 PB11 PB12

VDDA PA1 PA4 PA 7 PB0 PB1 PE7 PE9 PE11 PE13 PE14 PE15

UFBGA100

MSv39212V2

LQFP64

VBAT

PC14-OSC32_IN

PC15-OSC32_OUT

PH0-OSC_IN

PH1-OSC_OUT

NRST

PC0

PC1

PC2

PC3

VSSA/VREF-

VDDA/VREF+

PA0

PA1

PA2

PC13

5352515049

646362

2829303132

171819

PA3

VSS

PA5

PC4

PB2

VDD

PA4

PC5

PB11

PA6

PA7

VSS

PB0

PB1

PB10

VDD

PA13

PA12

PA11

PA10

PA9

PA8

PC9

PC8

PC7

PC6

PB15

PB14

PB13

PB12

VSS

VDD

VSS

PH3/BOOT0

PB5

PC12

PB9

PB8

PB4

PC10

PB7

PB6

PA15

PB3

PD2

PC11

PA14

Figure 7. STM32L431Vx UFBGA100 ballout

1. The above figure shows the package top view.

Figure 8. STM32L431Rx LQFP64 pinout

(1)

56/208 DS11453 Rev 3

1. The above figure shows the package top view.

STM32L431xx Pinouts and pin description

MSv39211V2

PC14-

OSC32_IN

PC13 PB9 PB4 PB3 PA15 PA14 PA13

12345678

PC15-

OSC32_OUT

VBAT PB8 PH3/BOOT0 PD2 PC11 PC10 PA12

PH0-OSC_IN VSS PB7 PB5 PC12 PA11

PH1-

OSC_OUT

VDD PB6

NRST PC1 PC0

VSSA/VREF- PC2

PC3 PA 0

VDDA/VREF+ PA1 PA 4

PA3

PA2

PC4

PB1

PB0

VDD

VSS

PA7

PA6

PA5

VDD

VSS

PB11

PB10

PB15

PC7

PA8

PC5

PB2

PC6

VDD

VSS

PA10 PA9

PB12

PB13

PB14

PC8

PC9

MSv39210V2

VDD PA15 PC12 PD2 PB3 PB7 VSS VDD

12345678

VSS PA14 PC11 PB4 PB6 PB9 VBAT PC13

PA12 PA13 PC10 PB5 PH3/BOOT0

PC14-

OSC32_IN

PA9 PA10 PA 11

PC7 PC9 PA8

PC6 PB15

PB14 PB13

VDD VSS PB11

PB12

PC8

PB1

PA6

PA5

PA4

PC0

PB10

PB2

PB0

PC5

PC4

VDD

PA1

PA0

PC2

PH1-

OSC_OUT

PA7

PA3

PA2

PC3

NRST

PB8

PC15-

OSC32_OUT

VSS

VDDA/VREF+

VSSA/VREF-

PC1

PH0-OSC_IN

MSv39209V2

VDD PA14 PB3 PB4 PH3/BOOT0 VSS VDD

1234567

VSS PA13 PA15 PB5 PB8 VBAT PC13

PA11 PA10 PA12 PB6 PB9

PA8 PA 9 PB15

PB14 PB13 PB10

PB12 PB11

VDD VSS PB2

PA7

PB0

PA5

PA2

NRST

PB1

PA6

PA3

PB7

PA1

VDDA/VREF+

VSSA/VREF-

PH0-OSC_IN

PA4

PA0

PC3

PH1-

OSC_OUT

PC15-

OSC32_OUT

PC14-

OSC32_IN

Figure 9. STM32L431Rx UFBGA64 ballout

1. The above figure shows the package top view.

Figure 10. STM32L431Rx WLCSP64 pinout

(1)

1. The above figure shows the package top view.

Figure 11. STM32L431Cx WLCSP49 pinout

1. The above figure shows the package top view.

DS11453 Rev 3 57/208

(1)

Pinouts and pin description STM32L431xx

MSv39208V2

LQFP48

VBAT

PC13

PC14-OSC32_IN

PC15-OSC32_OUT

PH0-OSC_IN

PH1-OSC_OUT

NRST

VSSA/VREF-

VDDA/VREF+

PA0

PA1

PA2

393740

484746

222421

131415

PA3

PA4

PA7

PB2

VDD

PA5

PA6

PB10

PB0

PB1

PB11

VSS

VDD

VSS

PA13

PA12

PA11

PA10

PA9

PA8

PB15

PB14

PB13

PB12

VDD

VSS

PH3/BOOT0

PB5

PA14

PB9

PB8

PB4

PB7

PB6

PB3

PA15

MSv39207V2

UFQFPN48

VBAT

PC13

PC14-OSC32_IN

PC15-OSC32_OUT

PH0-OSC_IN

PH1-OSC_OUT

NRST

VSSA/VREF-

VDDA/VREF+

PA0

PA1

PA2

393740

484746

222421

131415

PA3

PA4

PA7

PB2

VDD

PA5

PA6

PB10

PB0

PB1

PB11

VSS

VDD

VSS

PA13

PA12

PA11

PA10

PA9

PA8

PB15

PB14

PB13

PB12

VDD

VSS

PH3/BOOT0

PB5

PA14

PB9

PB8

PB4

PB7

PB6

PB3

PA15

Figure 12. STM32L431Cx LQFP48 pinout

1. The above figure shows the package top view.

Figure 13. STM32L431Cx UFQFPN48 pinout

(1)

1. The above figure shows the package top view.

58/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

MSv37605V2

UFQFPN32

VDD

PC14-OSC32_IN

PC15-OSC32_OUT

NRST

VDDA/VREF+

PA0/CK_IN

PA1

PA2

323130

91011

PA3

PA4

PA7

VSS

PA5

PA6

PB0

PB1

PA14

PA13

PA12

PA11

PA10

PA9

PA8

VDD

VSS

PH3/BOOT0

PB5

PA15

PB7

PB6

PB4

PB3

Figure 14. STM32L431Kx UFQFPN32 pinout

1. The above figure shows the package top view.

Name Abbreviation Definition

Pin name

Pin type

Table 14. Legend/abbreviations used in the pinout table

Unless otherwise specified in brackets below the pin name, the pin function during and after reset is the same as the actual pin name

S Supply pin

I Input only pin

(1)

I/O Input / output pin

FT 5 V tolerant I/O

TT 3.6 V tolerant I/O

RST Bidirectional reset pin with embedded weak pull-up resistor

I/O structure

Option for TT or FT I/Os

(1)

(2)

I/O, Fm+ capable

I/O, with Analog switch function supplied by V

Notes Unless otherwise specified by a note, all I/Os are set as analog inputs during and after reset.

Alternate

functions

Additional

functions

1. The related I/O structures in Table 15 are: FT_f, FT_fa.

2. The related I/O structures in Table 15 are: FT_a, FT_fa, TT_a.

Functions selected through GPIOx_AFR registers

Functions directly selected/enabled through peripheral registers

DS11453 Rev 3 59/208

DDA

Pinouts and pin description STM32L431xx

Pin Number

Table 15. STM32L431xx pin definitions

Pin functions

Pin name

(function

Additional

functions

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

after

reset)

Pin type

LQFP64

UFBGA64

LQFP100

UFBGA100

I/O structure

Alternate functions

Notes

TRACECK,

--- - - - - 1 B2 PE2 I/O FT -

TSC_G7_IO1,

SAI1_MCLK_A,

EVENTOUT

TRACED0,

--- - - - - 2 A1 PE3 I/O FT -

TSC_G7_IO2,

SAI1_SD_B, EVENTOUT

TRACED1,

--- - - - - 3 B1 PE4 I/O FT -

TSC_G7_IO3,

SAI1_FS_A, EVENTOUT

TRACED2,

--- - - - - 4 C2 PE5 I/O FT -

TSC_G7_IO4, SAI1_SCK_A,

EVENTOUT

--- - - - - 5 D2 PE6 I/O FT -

TRACED3, SAI1_SD_A,

EVENTOUT

RTC_TAMP3,

WKUP3

- 1 1 B6 B7 1 B2 6 E2 VBAT S - - - -

RTC_TAMP1,

RTC_TS,

RTC_OUT,

- 2 2B7B82A2 7 C1 PC13 I/O FT

(1)

(2)

EVENTOUT

WKUP2

2 3 3 C7 C8 3 A1 8 D1

PC14-

OSC32_I

I/O FT

(1)

(2)

EVENTOUT OSC32_IN

N (PC14)

3 4 4 C6 C7 4 B1 9 E1

PC15-

OSC32_

OUT

I/O FT

(1)

(2)

EVENTOUT OSC32_OUT

(PC15)

--- - - - - 10F2 VSS S - - - -

--- - - - - 11G2 VDD S - - - -

PH0-

- 5 5D7D85C112 F1

OSC_

I/O FT - EVENTOUT OSC_IN

IN (PH0)

PH1-

- 6 6D6D76D113 G1

OSC_

OUT

I/O FT - EVENTOUT OSC_OUT

(PH1)

4 7 7 D5 D6 7 E1 14 H2 NRST I/O RST - - -

60/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

I/O structure

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

Notes

--- -D58E315H1 PC0 I/OFT_fa-

--- -E89E216J2 PC1 I/OFT_fa-

Alternate functions

LPTIM1_IN1, I2C3_SCL,

LPUART1_RX,

LPTIM2_IN1,

LPTIM1_OUT,

LPUART1_TX,

Pin functions

EVENTOUT

I2C3_SDA,

EVENTOUT

Additional

functions

ADC1_IN1

ADC1_IN2

--- -E710F217J3 PC2 I/OFT_a-

LPTIM1_IN2,

SPI2_MISO, EVENTOUT

ADC1_IN3

LPTIM1_ETR,

- - - E6 E6 11 G1 18 K2 PC3 I/O FT_a -

SPI2_MOSI, SAI1_SD_A,

LPTIM2_ETR,

ADC1_IN4

EVENTOUT

- - - - - - - 19 J1 VSSA S - - - -

- - - - - - - 20 K1 VREF- S - - - -

-88E7F812F1 - -

- - - - - - - 21 L1 VREF+ S - - -

VSSA/ VREF-

S-- - -

VREFBUF_

OUT

--- - - - - 22M1 VDDA S - - - -

599F7G813H1 - -

- 1010F6 F714G2 23 L2 PA0 I/O FT_a -

VDDA/

VREF+

S-- - -

TIM2_CH1,

USART2_CTS,

COMP1_OUT,

SAI1_EXTCLK,

TIM2_ETR, EVENTOUT

OPAMP1_

VINP,

COMP1_INM,

ADC1_IN5,

RTC_TAMP2,

WKUP1

OPAMP1_

6--- --- - -

PA0 /

CK_IN

I/O FT_a -

TIM2_CH1,

USART2_CTS,

COMP1_OUT,

SAI1_EXTCLK,

TIM2_ETR, EVENTOUT

VINP,

COMP1_INM,

ADC1_IN5,

RTC_TAMP2,

WKUP1,

CK_IN

71111G7G715H224 M2 PA1 I/O FT_a -

TIM2_CH2, I2C1_SMBA,

SPI1_SCK,

USART2_RTS_DE,

TIM15_CH1N,

EVENTOUT

OPAMP1_

VINM,

COMP1_INP,

ADC1_IN6

DS11453 Rev 3 61/208

Pinouts and pin description STM32L431xx

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

81212E5F616F3 25 K3 PA2 I/O FT_a -

I/O structure

Alternate functions

Notes

TIM2_CH3, USART2_TX,

LPUART1_TX,

QUADSPI_BK1_NCS,

COMP2_OUT,

TIM15_CH1, EVENTOUT

Pin functions

Additional

functions

COMP2_INM,

ADC1_IN7,

WKUP4,

LSCO

TIM2_CH4, USART2_RX,

LPUART1_RX,

91313E4G617G326 L3 PA3 I/O TT_a -

--- -H818C227E3 VSS S - - - -

--- -H719D228H3 VDD S - - - -

10 14 14 G6 E5 20 H3 29 M3 PA4 I/O TT_a -

11 15 15 F5 F5 21 F4 30 K4 PA5 I/O TT_a -

12 16 16 F4 G5 22 G4 31 L4 PA6 I/O FT_a -

13 17 17 F3 H6 23 H4 32 M4 PA7 I/O FT_fa -

--- -D424H533K5 PC4 I/OFT_a-

--- -E425H634L5 PC5 I/OFT_a-

QUADSPI_CLK,

SAI1_MCLK_A,

TIM15_CH2, EVENTOUT

SPI1_NSS, SPI3_NSS,

USART2_CK,

SAI1_FS_B,

LPTIM2_OUT,

EVENTOUT

TIM2_CH1, TIM2_ETR,

SPI1_SCK,

LPTIM2_ETR,

EVENTOUT

TIM1_BKIN, SPI1_MISO,

COMP1_OUT,

USART3_CTS,

LPUART1_CTS,

QUADSPI_BK1_IO3,

TIM1_BKIN_COMP2,

TIM16_CH1, EVENTOUT

TIM1_CH1N, I2C3_SCL,

SPI1_MOSI,

QUADSPI_BK1_IO2,

COMP2_OUT,

EVENTOUT

USART3_TX,

EVENTOUT

USART3_RX,

EVENTOUT

OPAMP1_

VOUT,

COMP2_INP,

ADC1_IN8

COMP1_INM, COMP2_INM,

ADC1_IN9,

DAC1_OUT1

COMP1_INM, COMP2_INM,

ADC1_IN10,

DAC1_OUT2

ADC1_IN11

ADC1_IN12

COMP1_INM,

ADC1_IN13

COMP1_INP,

ADC1_IN14,

WKUP5

62/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

I/O structure

14 18 18 G5 F4 26 F5 35 M5 PB0 I/O FT_a -

15 19 19 G4 H5 27 G5 36 M6 PB1 I/O FT_a -

- 2020G3G428G6 37 L6 PB2 I/O FT_a -

--- - - - - 38M7 PE7 I/O FT -

Alternate functions

Notes

TIM1_CH2N, SPI1_NSS,

USART3_CK,

QUADSPI_BK1_IO1,

COMP1_OUT,

SAI1_EXTCLK,

TIM1_CH3N,

USART3_RTS_DE,

LPUART1_RTS_DE,

QUADSPI_BK1_IO0,

LPTIM2_IN1,

RTC_OUT, LPTIM1_OUT, I2C3_SMBA, EVENTOUT

TIM1_ETR, SAI1_SD_B,

Pin functions

EVENTOUT

Additional

functions

ADC1_IN15

COMP1_INM,

ADC1_IN16

COMP1_INP

--- - - - - 39L7 PE8 I/O FT -

--- - - - - 40M8 PE9 I/O FT -

--- - - - - 41L8 PE10 I/O FT -

--- - - - - 42M9 PE11 I/O FT -

--- - - - - 43L9 PE12 I/O FT -

--- - - - - 44M10 PE13 I/O FT -

--- - - - - 45M11 PE14 I/O FT -

TIM1_CH1N,

SAI1_SCK_B,

EVENTOUT

TIM1_CH1, SAI1_FS_B,

EVENTOUT

TIM1_CH2N,

TSC_G5_IO1,

QUADSPI_CLK,

SAI1_MCLK_B,

EVENTOUT

TIM1_CH2,

TSC_G5_IO2,

QUADSPI_BK1_NCS,

EVENTOUT

TIM1_CH3N, SPI1_NSS,

TSC_G5_IO3,

QUADSPI_BK1_IO0,

EVENTOUT

TIM1_CH3, SPI1_SCK,

TSC_G5_IO4,

QUADSPI_BK1_IO1,

EVENTOUT

TIM1_CH4, TIM1_BKIN2,

TIM1_BKIN2_COMP2,

SPI1_MISO,

QUADSPI_BK1_IO2,

EVENTOUT

DS11453 Rev 3 63/208

Pinouts and pin description STM32L431xx

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

I/O structure

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

--- - - - - 46M12 PE15 I/O FT -

- 21 21 E3 H4 29 G7 47 L10 PB10 I/O FT_f -

-2222F2H330H748 L11 PB11 I/O FT_f -

Notes

Alternate functions

TIM1_BKIN_COMP1,

QUADSPI_BK1_IO3,

TIM2_CH3, I2C2_SCL,

SPI2_SCK, USART3_TX,

LPUART1_RX,

QUADSPI_CLK,

COMP1_OUT, SAI1_SCK_A,

TIM2_CH4, I2C2_SDA,

USART3_RX,

LPUART1_TX,

QUADSPI_BK1_NCS,

COMP2_OUT,

Pin functions

TIM1_BKIN,

SPI1_MOSI,

EVENTOUT

TSC_SYNC,

EVENTOUT

Additional

functions

16 23 23 G2 H2 31 D6 49 F12 VSS S - - - -

17 24 24 G1 H1 32 E6 50 G12 VDD S - - - -

TIM1_BKIN,

TIM1_BKIN_COMP2,

I2C2_SMBA, SPI2_NSS,

USART3_CK,

- 25 25 F1 G3 33 H8 51 L12 PB12 I/O FT -

- 26 26 E2 G2 34 G8 52 K12 PB13 I/O FT_f -

LPUART1_RTS_DE,

TSC_G1_IO1,

SWPMI1_IO,

SAI1_FS_A,

TIM15_BKIN,

EVENTOUT

TIM1_CH1N, I2C2_SCL,

SPI2_SCK,

USART3_CTS,

LPUART1_CTS,

TSC_G1_IO2,

SWPMI1_TX, SAI1_SCK_A, TIM15_CH1N,

EVENTOUT

64/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

I/O structure

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

Notes

- 27 27 E1 G1 35 F8 53 K11 PB14 I/O FT_f -

- 28 28 D3 F2 36 F7 54 K10 PB15 I/O FT -

--- - - - - 55K9 PD8 I/O FT -

Alternate functions

TIM1_CH2N, I2C2_SDA,

USART3_RTS_DE,

TSC_G1_IO3,

SWPMI1_RX,

SAI1_MCLK_A,

TIM15_CH1, EVENTOUT

RTC_REFIN, TIM1_CH3N,

TSC_G1_IO4,

SWPMI1_SUSPEND,

TIM15_CH2, EVENTOUT

USART3_TX,

Pin functions

SPI2_MISO,

SPI2_MOSI,

SAI1_SD_A,

EVENTOUT

Additional

functions

--- - - - - 56K8 PD9 I/O FT -

USART3_RX,

EVENTOUT

USART3_CK,

--- - - - - 57J12 PD10 I/O FT -

TSC_G6_IO1,

EVENTOUT

USART3_CTS,

--- - - - - 58J11 PD11 I/O FT -

TSC_G6_IO2, LPTIM2_ETR,

EVENTOUT

USART3_RTS_DE,

--- - - - - 59J10 PD12 I/O FT -

TSC_G6_IO3,

LPTIM2_IN1,

EVENTOUT

TSC_G6_IO4,

- - - - - - - 60 H12 PD13 I/O FT -

LPTIM2_OUT,

EVENTOUT

- - - - - - - 61 H11 PD14 I/O FT - EVENTOUT -

- - - - - - - 62 H10 PD15 I/O FT - EVENTOUT -

TSC_G4_IO1,

--- -F137F663E12 PC6 I/O FT -

SDMMC1_D6,

EVENTOUT

TSC_G4_IO2,

--- -E138E764E11 PC7 I/O FT -

SDMMC1_D7,

EVENTOUT

DS11453 Rev 3 65/208

Pinouts and pin description STM32L431xx

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

after

reset)

UFBGA100

Pin type

I/O structure

Alternate functions

Notes

TSC_G4_IO3,

--- -F339E865E10 PC8 I/O FT -

SDMMC1_D0,

TSC_G4_IO4,

--- -E240D866D12 PC9 I/O FT -

SDMMC1_D1,

MCO, TIM1_CH1,

USART1_CK,

18 29 29 D1 E3 41 D7 67 D11 PA8 I/O FT -

SWPMI1_IO, SAI1_SCK_A, LPTIM2_OUT,

TIM1_CH2, I2C1_SCL,

USART1_TX,

19 30 30 D2 D1 42 C7 68 D10 PA9 I/O FT_f -

TIM15_BKIN,

TIM1_CH3, I2C1_SDA,

20 31 31 C2 D2 43 C6 69 C12 PA10 I/O FT_f -

USART1_RX,

SAI1_SD_A, EVENTOUT

TIM1_CH4, TIM1_BKIN2,

COMP1_OUT,

21 32 32 C1 D3 44 C8 70 B12 PA11 I/O FT -

USART1_CTS,

TIM1_BKIN2_COMP1,

TIM1_ETR, SPI1_MOSI,

22 33 33 C3 C1 45 B8 71 A12 PA12 I/O FT -

USART1_RTS_DE,

CAN1_TX, EVENTOUT

23 34 34 B2 C2 46 A8 72 A11

PA13

(JTMS-

SWDIO)

I/O FT

JTMS-SWDIO, IR_OUT,

(3)

SWPMI1_TX,

SAI1_SD_B, EVENTOUT

- 35 35 B1 B1 47 D5 - - VSS S - - - -

Pin functions

EVENTOUT

SAI1_FS_A,

EVENTOUT

SPI1_MISO,

CAN1_RX,

EVENTOUT

Additional

functions

-3636A1A148E573C11 VDD S - - - -

--- - - - - 74F11 VSS S - - - -

--- - - - - 75G11 VDD S - - - -

JTCK-SWCLK,

LPTIM1_OUT,

I2C1_SMBA,

SWPMI1_RX,

24 37 37 A2 B2 49 A7 76 A10

PA14

(JTCK-

SWCLK)

I/O FT

(3)

SAI1_FS_B, EVENTOUT

66/208 DS11453 Rev 3

STM32L431xx Pinouts and pin description

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

25 38 38 B3 A2 50 A6 77 A9

UFBGA100

PA15

(JTDI)

I/O FT

I/O structure

(3)

--- -C351B778B11 PC10 I/O FT -

--- -B352B679C10 PC11 I/O FT -

Alternate functions

Notes

JTDI, TIM2_CH1,

TIM2_ETR, USART2_RX,

SPI1_NSS, SPI3_NSS,

USART3_RTS_DE,

TSC_G3_IO1,

SWPMI1_SUSPEND,

SPI3_SCK, USART3_TX,

TSC_G3_IO2, SDMMC1_D2,

USART3_RX, TSC_G3_IO3, SDMMC1_D3,

Pin functions

Additional

functions

EVENTOUT

SPI3_MISO,

EVENTOUT

- - - - A3 53 C5 80 B10 PC12 I/O FT -

--- - - - - 81C9 PD0 I/O FT -

--- - - - - 82B9 PD1 I/O FT -

--- -A454B583C8 PD2 I/O FT -

--- - - - - 84B8 PD3 I/O FT -

--- - - - - 85B7 PD4 I/O FT -

--- - - - - 86A6 PD5 I/O FT -

SPI3_MOSI,

USART3_CK, TSC_G3_IO4,

SDMMC1_CK,

EVENTOUT

SPI2_NSS, CAN1_RX,

EVENTOUT

SPI2_SCK, CAN1_TX,

EVENTOUT

USART3_RTS_DE,

TSC_SYNC,

SDMMC1_CMD,

EVENTOUT

SPI2_MISO,

USART2_CTS,

QUADSPI_BK2_NCS,

EVENTOUT

SPI2_MOSI,

USART2_RTS_DE,

QUADSPI_BK2_IO0,

EVENTOUT

USART2_TX,

QUADSPI_BK2_IO1,

EVENTOUT

--- - - - - 87B6 PD6 I/O FT -

DS11453 Rev 3 67/208

USART2_RX,

QUADSPI_BK2_IO2,

SAI1_SD_A, EVENTOUT

Pinouts and pin description STM32L431xx

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

after

reset)

Pin type

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

UFBGA100

I/O structure

--- - - - - 88A5 PD7 I/O FT -

PB3

26 39 39 A3 A5 55 A5 89 A8

(JTDOTRACE

I/O FT_a

(3)

SWO)

27 40 40 A4 B4 56 A4 90 A7

PB4

(NJTRST)

I/O FT_fa

(3)

28 41 41 B4 C4 57 C4 91 C5 PB5 I/O FT -

29 42 42 C4 B5 58 D3 92 B5 PB6 I/O FT_fa -

30 43 43 D4 A6 59 C3 93 B4 PB7 I/O FT_fa -

Alternate functions

Notes

USART2_CK,

QUADSPI_BK2_IO3,

JTDO-TRACESWO,

TIM2_CH2, SPI1_SCK,

USART1_RTS_DE,

SAI1_SCK_B,

NJTRST, I2C3_SDA,

SPI1_MISO, SPI3_MISO,

USART1_CTS,

TSC_G2_IO1,

SAI1_MCLK_B,

LPTIM1_IN1, I2C1_SMBA,

SPI1_MOSI, SPI3_MOSI,

USART1_CK, TSC_G2_IO2, COMP2_OUT,

TIM16_BKIN,

LPTIM1_ETR, I2C1_SCL,

USART1_TX, TSC_G2_IO3,

TIM16_CH1N,

LPTIM1_IN2, I2C1_SDA,

USART1_RX, TSC_G2_IO4,

Pin functions

EVENTOUT

SPI3_SCK,

EVENTOUT

SAI1_SD_B,

EVENTOUT

SAI1_FS_B,

EVENTOUT

Additional

functions

COMP2_INM

COMP2_INP

COMP2_INM,

PVD_IN

31 44 44 A5 C5 60 B4 94 A4

PH3/

BOOT0

I/O FT - EVENTOUT BOOT0

- 45 45 B5 C6 61 B3 95 A3 PB8 I/O FT_f -

- 46 46 C5 B6 62 A3 96 B3 PB9 I/O FT_f -

68/208 DS11453 Rev 3

I2C1_SCL, CAN1_RX,

SDMMC1_D4,

SAI1_MCLK_A,

TIM16_CH1, EVENTOUT

IR_OUT, I2C1_SDA,

SPI2_NSS, CAN1_TX,

SDMMC1_D5,

SAI1_FS_A, EVENTOUT

STM32L431xx Pinouts and pin description

Table 15. STM32L431xx pin definitions (continued)

Pin Number

Pin name

(function

UFQFPN32

LQFP48

UFQFPN48

WLCSP49

WLCSP64

LQFP64

UFBGA64

LQFP100

after

reset)

UFBGA100

Pin type

I/O structure

Alternate functions

Notes

- - - - - - - 97 C3 PE0 I/O FT - TIM16_CH1, EVENTOUT -

- - - - - - - 98 A2 PE1 I/O FT - EVENTOUT -

32 47 47 A6 A7 63 D4 99 D3 VSS S - - - -

1 48 48 A7 A8 64 E4 100 C4 VDD S - - - -

1. PC13, PC14 and PC15 are supplied through the power switch. Since the switch only sinks a limited amount of current (3 mA), the use of GPIOs PC13 to PC15 in output mode is limited:

- The speed should not exceed 2 MHz with a maximum load of 30 pF

- These GPIOs must not be used as current sources (e.g. to drive an LED).

2. After a Backup domain power-up, PC13, PC14 and PC15 operate as GPIOs. Their function then depends on the content of the RTC registers which are not reset by the system reset. For details on how to manage these GPIOs, refer to the Backup domain and RTC register descriptions in the RM0394 reference manual.

3. After reset, these pins are configured as JTAG/SW debug alternate functions, and the internal pull-up on PA15, PA13, PB4 pins and the internal pull-down on PA14 pin are activated.

Pin functions

Additional

functions

DS11453 Rev 3 69/208

70/208 DS11453 Rev 3

Table 16. Alternate function AF0 to AF7

AF0 AF1 AF2 AF3 AF4 AF5 AF6 AF7

(1)

Pinouts and pin description STM32L431xx

Port A

Port

SYS_AF

PA0-TIM2_CH1-----USART2_CTS

PA1 - TIM2_CH2 - - I2C1_SMBA SPI1_SCK -

PA2-TIM2_CH3-----USART2_TX

PA3-TIM2_CH4-----USART2_RX

PA4 - - - - - SPI1_NSS SPI3_NSS USART2_CK

PA5 - TIM2_CH1 TIM2_ETR - - SPI1_SCK - -

PA6 - TIM1_BKIN - - - SPI1_MISO COMP1_OUT USART3_CTS

PA7 - TIM1_CH1N - - I2C3_SCL SPI1_MOSI - -

PA8MCOTIM1_CH1-----USART1_CK

PA9 - TIM1_CH2 - - I2C1_SCL - - USART1_TX

PA10 - TIM1_CH3 - - I2C1_SDA - - USART1_RX

PA11 - TIM1_CH4 TIM1_BKIN2 - - SPI1_MISO COMP1_OUT USART1_CTS

PA12 - TIM1_ETR - - - SPI1_MOSI -

PA13JTMS-SWDIOIR_OUT------

TIM1/TIM2/

LPTIM1

TIM1/TIM2 USART2 I2C1/I2C2/I2C3 SPI1/SPI2 SPI3

USART1/ USART2/

USART3

USART2_RTS_

USART1_RTS_

PA14 JTCK-SWCLK LPTIM1_OUT - - I2C1_SMBA - - -

PA15 JTDI TIM2_CH1 TIM2_ETR USART2_RX - SPI1_NSS SPI3_NSS

USART3_RTS_

Table 16. Alternate function AF0 to AF7

AF0 AF1 AF2 AF3 AF4 AF5 AF6 AF7

(1)

(continued)

STM32L431xx Pinouts and pin description

DS11453 Rev 3 71/208

Port B

Port

SYS_AF

PB0 - TIM1_CH2N - - - SPI1_NSS - USART3_CK

PB1-TIM1_CH3N-----

PB2 RTC_OUT LPTIM1_OUT - - I2C3_SMBA - - -

PB3

PB4 NJTRST - - - I2C3_SDA SPI1_MISO SPI3_MISO USART1_CTS

PB5 - LPTIM1_IN1 - - I2C1_SMBA SPI1_MOSI SPI3_MOSI USART1_CK

PB6 - LPTIM1_ETR - - I2C1_SCL - - USART1_TX

PB7 - LPTIM1_IN2 - - I2C1_SDA - - USART1_RX

PB8----I2C1_SCL---

PB9 - IR_OUT - - I2C1_SDA SPI2_NSS - -

PB10 - TIM2_CH3 - - I2C2_SCL SPI2_SCK - USART3_TX

PB11 - TIM2_CH4 - - I2C2_SDA - - USART3_RX

PB12 - TIM1_BKIN -

PB13 - TIM1_CH1N - - I2C2_SCL SPI2_SCK - USART3_CTS

JTDO-

TRACESWO

TIM1/TIM2/

LPTIM1

TIM2_CH2 - - - SPI1_SCK SPI3_SCK

TIM1/TIM2 USART2 I2C1/I2C2/I2C3 SPI1/SPI2 SPI3

TIM1_BKIN_

COMP2

I2C2_SMBA SPI2_NSS - USART3_CK

USART1/ USART2/

USART3

USART3_RTS_

USART1_RTS_

PB14 - TIM1_CH2N - - I2C2_SDA SPI2_MISO -

PB15 RTC_REFIN TIM1_CH3N - - - SPI2_MOSI - -

USART3_RTS_

72/208 DS11453 Rev 3

Table 16. Alternate function AF0 to AF7

AF0 AF1 AF2 AF3 AF4 AF5 AF6 AF7

(1)

(continued)

Pinouts and pin description STM32L431xx

Port C

Port

SYS_AF

PC0 - LPTIM1_IN1 - - I2C3_SCL - - -

PC1 - LPTIM1_OUT - - I2C3_SDA - - -

PC2 - LPTIM1_IN2 - - - SPI2_MISO - -

PC3 - LPTIM1_ETR - - - SPI2_MOSI - -

PC4-------USART3_TX

PC5-------USART3_RX

PC6--------

PC7--------

PC8--------

PC9--------

PC10------SPI3_SCKUSART3_TX

PC11------SPI3_MISOUSART3_RX

PC12------SPI3_MOSIUSART3_CK

PC13--------

PC14--------

TIM1/TIM2/

LPTIM1

TIM1/TIM2 USART2 I2C1/I2C2/I2C3 SPI1/SPI2 SPI3

USART1/ USART2/

USART3

PC15--------

Table 16. Alternate function AF0 to AF7

AF0 AF1 AF2 AF3 AF4 AF5 AF6 AF7

(1)

(continued)

STM32L431xx Pinouts and pin description

DS11453 Rev 3 73/208

Port D

Port

SYS_AF

PD0 - - - - - SPI2_NSS - -

PD1 - - - - - SPI2_SCK - -

PD2-------

PD3 - - - - - SPI2_MISO - USART2_CTS

PD4 - - - - - SPI2_MOSI -

PD5-------USART2_TX

PD6-------USART2_RX

PD7-------USART2_CK

PD8-------USART3_TX

PD9-------USART3_RX

PD10-------USART3_CK

PD11-------USART3_CTS

PD12-------

PD13--------

TIM1/TIM2/

LPTIM1

TIM1/TIM2 USART2 I2C1/I2C2/I2C3 SPI1/SPI2 SPI3

USART1/ USART2/

USART3

USART3_RTS_

USART2_RTS_

USART3_RTS_

PD14--------

PD15--------

Port EPE0--------

74/208 DS11453 Rev 3

Table 16. Alternate function AF0 to AF7

AF0 AF1 AF2 AF3 AF4 AF5 AF6 AF7

(1)

(continued)

Pinouts and pin description STM32L431xx

Port E

Port

SYS_AF

PE1--------

PE2TRACECK-------

PE3TRACED0-------

PE4TRACED1-------

PE5TRACED2-------

PE6TRACED3-------

PE7-TIM1_ETR------

PE8-TIM1_CH1N------

PE9-TIM1_CH1------

PE10-TIM1_CH2N------

PE11-TIM1_CH2------

PE12 - TIM1_CH3N - - - SPI1_NSS - -

PE13 - TIM1_CH3 - - - SPI1_SCK - -

PE14 - TIM1_CH4 TIM1_BKIN2

TIM1/TIM2/

LPTIM1

TIM1/TIM2 USART2 I2C1/I2C2/I2C3 SPI1/SPI2 SPI3

TIM1_BKIN2_

COMP2

- SPI1_MISO - -

USART1/ USART2/

USART3

PE15 - TIM1_BKIN -

PH0--------

Port H

1. Please refer to Table 17 for AF8 to AF15.

PH1--------

PH3--------

TIM1_BKIN_

COMP1

- SPI1_MOSI - -

Table 17. Alternate function AF8 to AF15

(1)

STM32L431xx Pinouts and pin description

AF8 AF9 AF10 AF11 AF12 AF13 AF14 AF15

DS11453 Rev 3 75/208

Port A

Port

LPUART1 CAN1/TSC QUADSPI

SDMMC1/

COMP1/ COMP2/

SAI1

TIM2/TIM15/

TIM16/LPTIM2

EVENTOUT

SWPMI1

PA0 - - - - COMP1_OUT SAI1_EXTCLK TIM2_ETR EVENTOUT

PA1 - - - - - TIM15_CH1N EVENTOUT

PA2 LPUART1_TX -

QUADSPI_

BK1_NCS

COMP2_OUT - TIM15_CH1 EVENTOUT

PA3 LPUART1_RX - QUADSPI_CLK - SAI1_MCLK_A TIM15_CH2 EVENTOUT

PA4-----SAI1_FS_BLPTIM2_OUTEVENTOUT

PA5------LPTIM2_ETREVENTOUT

PA6 LPUART1_CTS -

PA7 - -

QUADSPI_

BK1_IO3

QUADSPI_

BK1_IO2

TIM1_BKIN_

COMP2

- TIM16_CH1 EVENTOUT

COMP2_OUT - - EVENTOUT

PA8 - - - SWPMI1_IO SAI1_SCK_A LPTIM2_OUT EVENTOUT

PA9 - - - - SAI1_FS_A TIM15_BKIN EVENTOUT

PA10 - - - SAI1_SD_A - EVENTOUT

PA11 - CAN1_RX -

TIM1_BKIN2_

COMP1

- - EVENTOUT

PA12 - CAN1_TX - - - - EVENTOUT

PA13 - - - SWPMI1_TX SAI1_SD_B - EVENTOUT

PA14 - - - - SWPMI1_RX SAI1_FS_B - EVENTOUT

PA15 - TSC_G3_IO1 -

SWPMI1_

SUSPEND

- - EVENTOUT

76/208 DS11453 Rev 3

Table 17. Alternate function AF8 to AF15

AF8 AF9 AF10 AF11 AF12 AF13 AF14 AF15

(1)

(continued)

Pinouts and pin description STM32L431xx

Port B

Port

LPUART1 CAN1/TSC QUADSPI

PB0 - -

LPUART1_RTS

PB1

PB2 - - - - - - EVENTOUT

PB3 - - - - SAI1_SCK_B - EVENTOUT

PB4 - TSC_G2_IO1 - - SAI1_MCLK_B - EVENTOUT

PB5 - TSC_G2_IO2 - COMP2_OUT SAI1_SD_B TIM16_BKIN EVENTOUT

PB6 - TSC_G2_IO3 - - - SAI1_FS_B TIM16_CH1N EVENTOUT

PB7 - TSC_G2_IO4 - - - - EVENTOUT

PB8 - CAN1_RX - SDMMC1_D4 SAI1_MCLK_A TIM16_CH1 EVENTOUT

PB9 - CAN1_TX - SDMMC1_D5 SAI1_FS_A - EVENTOUT

PB10 LPUART1_RX TSC_SYNC QUADSPI_CLK COMP1_OUT SAI1_SCK_A - EVENTOUT

PB11 LPUART1_TX -

PB12

_DE

LPUART1_RTS

_DE

TSC_G1_IO1 - SWPMI1_IO SAI1_FS_A TIM15_BKIN EVENTOUT

QUADSPI_

BK1_IO1

QUADSPI_

BK1_IO0

QUADSPI_

BK1_NCS

SDMMC1/

COMP1/ COMP2/ SWPMI1

COMP1_OUT SAI1_EXTCLK - EVENTOUT

- - LPTIM2_IN1 EVENTOUT

COMP2_OUT - - EVENTOUT

SAI1

TIM2/TIM15/

TIM16/LPTIM2

EVENTOUT

PB13 LPUART1_CTS TSC_G1_IO2 - SWPMI1_TX SAI1_SCK_A TIM15_CH1N EVENTOUT

PB14 - TSC_G1_IO3 - SWPMI1_RX SAI1_MCLK_A TIM15_CH1 EVENTOUT

PB15 - TSC_G1_IO4 -

SWPMI1_

SUSPEND

SAI1_SD_A TIM15_CH2 EVENTOUT

Table 17. Alternate function AF8 to AF15

AF8 AF9 AF10 AF11 AF12 AF13 AF14 AF15

(1)

(continued)

STM32L431xx Pinouts and pin description

DS11453 Rev 3 77/208

Port C

Port

LPUART1 CAN1/TSC QUADSPI

PC0 LPUART1_RX - - - - LPTIM2_IN1 EVENTOUT

PC1 LPUART1_TX - - - - - EVENTOUT

PC2 - - - - - - EVENTOUT

PC3 - - - - SAI1_SD_A LPTIM2_ETR EVENTOUT

PC4 - - - - - - EVENTOUT

PC5 - - - - - - EVENTOUT

PC6 - TSC_G4_IO1 - SDMMC1_D6 - - EVENTOUT

PC7 - TSC_G4_IO2 - SDMMC1_D7 - - EVENTOUT

PC8 - TSC_G4_IO3 - SDMMC1_D0 - - EVENTOUT

PC9 - TSC_G4_IO4 SDMMC1_D1 - - EVENTOUT

PC10 - TSC_G3_IO2 - SDMMC1_D2 - - EVENTOUT

PC11 - TSC_G3_IO3 - SDMMC1_D3 - - EVENTOUT

PC12 - TSC_G3_IO4 - SDMMC1_CK - - EVENTOUT

PC13------ -EVENTOUT

SDMMC1/

COMP1/ COMP2/ SWPMI1

SAI1

TIM2/TIM15/

TIM16/LPTIM2

EVENTOUT

Port D

PC14------ -EVENTOUT

PC15------ -EVENTOUT

PD0 - CAN1_RX - - - - - EVENTOUT

PD1 - CAN1_TX - - - - - EVENTOUT

PD2 - TSC_SYNC -

SDMMC1_

CMD

- - EVENTOUT

78/208 DS11453 Rev 3

Table 17. Alternate function AF8 to AF15

AF8 AF9 AF10 AF11 AF12 AF13 AF14 AF15

(1)

(continued)

Pinouts and pin description STM32L431xx

Port D

Port

LPUART1 CAN1/TSC QUADSPI

PD3 - -

PD4 - -

PD5 - -

PD6 - -

PD7 - -

PD8 - - - - - - EVENTOUT

PD9 - - - - - - EVENTOUT

PD10 - TSC_G6_IO1 - - - - EVENTOUT

PD11 - TSC_G6_IO2 - - - LPTIM2_ETR EVENTOUT

PD12 - TSC_G6_IO3 - - - LPTIM2_IN1 EVENTOUT

PD13 - TSC_G6_IO4 - - - LPTIM2_OUT EVENTOUT

PD14 - - - - - - EVENTOUT

QUADSPI_BK2

_NCS

QUADSPI_BK2

_IO0

QUADSPI_BK2

_IO1

QUADSPI_BK2

_IO2

QUADSPI_BK2

_IO3

- - - - EVENTOUT

- - SAI1_SD_A - EVENTOUT

- - - - EVENTOUT

SDMMC1/

COMP1/ COMP2/ SWPMI1

SAI1

TIM2/TIM15/

TIM16/LPTIM2

EVENTOUT

Port E

PD15 - - - - - - EVENTOUT

PE0 - - - - - TIM16_CH1 EVENTOUT

PE1 - - - - - - EVENTOUT

PE2 - TSC_G7_IO1 - - SAI1_MCLK_A - EVENTOUT

PE3 - TSC_G7_IO2 - - SAI1_SD_B - EVENTOUT

PE4 - TSC_G7_IO3 - - - SAI1_FS_A - EVENTOUT

Table 17. Alternate function AF8 to AF15

AF8 AF9 AF10 AF11 AF12 AF13 AF14 AF15

(1)

(continued)

STM32L431xx Pinouts and pin description

DS11453 Rev 3 79/208

Port E

Port

LPUART1 CAN1/TSC QUADSPI

PE5 - TSC_G7_IO4 - - - SAI1_SCK_A - EVENTOUT

PE6-----SAI1_SD_A-EVENTOUT

PE7-----SAI1_SD_B-EVENTOUT

PE8-----SAI1_SCK_B-EVENTOUT

PE9-----SAI1_FS_B-EVENTOUT

PE10 - TSC_G5_IO1 QUADSPI_CLK - - SAI1_MCLK_B - EVENTOUT

PE11 - TSC_G5_IO2

PE12 - TSC_G5_IO3

PE13 - TSC_G5_IO4

PE14 - -

PE15 - -

PH0------ -EVENTOUT

QUADSPI_BK1

_NCS

QUADSPI_BK1

_IO0

QUADSPI_BK1

_IO1

QUADSPI_BK1

_IO2

QUADSPI_BK1

_IO3

- - - - EVENTOUT

SDMMC1/

COMP1/ COMP2/ SWPMI1

SAI1

TIM2/TIM15/

TIM16/LPTIM2

EVENTOUT

Port H

1. Please refer to Table 16 for AF0 to AF7.

PH1------ -EVENTOUT

PH3------ -EVENTOUT

Memory mapping STM32L431xx

MSv36892V2

0xFFFF FFFF

0xE000 0000

0xC000 0000

0xA000 1000

0x8000 0000

0x6000 0000

0x4000 0000

0x2000 0000

0x0000 0000

Cortex™-M4

with FPU

Internal

Peripherals

SRAM1

CODE

OTP area

System memory

Flash memory

Flash, system memory

or SRAM, depending on

BOOT configuration

AHB2

AHB1

APB2

APB1

0x5006 0C00

0x4800 0000

0x4002 4400

0x4002 0000

0x4001 5800

0x4001 0000

0x4000 9800

0x4000 0000

0x1FFF FFFF

0x1FFF 0000

0x0804 0000

0x0800 0000

0x0004 0000

0x0000 0000

Reserved

0x1000 4000

0x1000 0000

SRAM2

QUADSPI

registers

Options Bytes

0x1FFF 7000

0x1FFF 7400

0x1FFF 7800

0x1FFF 7810

Reserved

QUADSPI registers

0xBFFF FFFF

0xA000 1400

0xA000 1000

Reserved

0x5FFF FFFF

0x9000 0000

QUADSPI Flash

bank

SRAM2

0x2000 C000

0xA000 0000

5 Memory mapping

Figure 15. STM32L431xx memory map

80/208 DS11453 Rev 3

STM32L431xx Memory mapping

Table 18. STM32L431xx memory map and peripheral register boundary addresses

Bus Boundary address Size(bytes) Peripheral

0x5006 0800 - 0x5006 0BFF 1 KB RNG

0x5004 0400 - 0x5006 07FF 158 KB Reserved

0x5004 0000 - 0x5004 03FF 1 KB ADC

0x5000 0000 - 0x5003 FFFF 16 KB Reserved

0x4800 2000 - 0x4FFF FFFF ~127 MB Reserved

AHB2

0x4800 1C00 - 0x4800 1FFF 1 KB GPIOH

0x4800 1400 - 0x4800 1BFF 2 KB Reserved

0x4800 1000 - 0x4800 13FF 1 KB GPIOE

0x4800 0C00 - 0x4800 0FFF 1 KB GPIOD

0x4800 0800 - 0x4800 0BFF 1 KB GPIOC

0x4800 0400 - 0x4800 07FF 1 KB GPIOB

0x4800 0000 - 0x4800 03FF 1 KB GPIOA

0x4002 4400 - 0x47FF FFFF ~127 MB Reserved

0x4002 4000 - 0x4002 43FF 1 KB TSC

(1)

AHB1

APB2

0x4002 3400 - 0x4002 3FFF 1 KB Reserved

0x4002 3000 - 0x4002 33FF 1 KB CRC

0x4002 2400 - 0x4002 2FFF 3 KB Reserved

0x4002 2000 - 0x4002 23FF 1 KB FLASH registers

0x4002 1400 - 0x4002 1FFF 3 KB Reserved

0x4002 1000 - 0x4002 13FF 1 KB RCC

0x4002 0800 - 0x4002 0FFF 2 KB Reserved

0x4002 0400 - 0x4002 07FF 1 KB DMA2

0x4002 0000 - 0x4002 03FF 1 KB DMA1

0x4001 5800 - 0x4001 FFFF 42 KB Reserved

0x4001 5400 - 0x4000 57FF 1 KB SAI1

0x4001 4800 - 0x4000 53FF 3 KB Reserved

0x4001 4400 - 0x4001 47FF 1 KB TIM16

0x4001 4000 - 0x4001 43FF 1 KB TIM15

0x4001 3C00 - 0x4001 3FFF 1 KB Reserved

0x4001 3800 - 0x4001 3BFF 1 KB USART1

0x4001 3400 - 0x4001 37FF 1 KB Reserved

DS11453 Rev 3 81/208

Memory mapping STM32L431xx

Table 18. STM32L431xx memory map and peripheral register boundary addresses

(continued)

Bus Boundary address Size(bytes) Peripheral

0x4001 3000 - 0x4001 33FF 1 KB SPI1

0x4001 2C00 - 0x4001 2FFF 1 KB TIM1

0x4001 2800 - 0x4001 2BFF 1 KB SDMMC1

0x4001 2000 - 0x4001 27FF 2 KB Reserved

APB2

0x4001 1C00 - 0x4001 1FFF 1 KB FIREWALL

0x4001 0800- 0x4001 1BFF 5 KB Reserved

0x4001 0400 - 0x4001 07FF 1 KB EXTI

0x4001 0200 - 0x4001 03FF

0x4001 0030 - 0x4001 01FF VREFBUF

0x4001 0000 - 0x4001 002F SYSCFG

0x4000 9800 - 0x4000 FFFF 26 KB Reserved

0x4000 9400 - 0x4000 97FF 1 KB LPTIM2

0x4000 8C00 - 0x4000 93FF 2 KB Reserved

0x4000 8800 - 0x4000 8BFF 1 KB SWPMI1

0x4000 8400 - 0x4000 87FF 1 KB Reserved

1 KB

COMP

(1)

APB1

0x4000 8000 - 0x4000 83FF 1 KB LPUART1

0x4000 7C00 - 0x4000 7FFF 1 KB LPTIM1

0x4000 7800 - 0x4000 7BFF 1 KB OPAMP

0x4000 7400 - 0x4000 77FF 1 KB DAC1

0x4000 7000 - 0x4000 73FF 1 KB PWR

0x4000 6800 - 0x4000 6FFF 2 KB Reserved

0x4000 6400 - 0x4000 67FF 1 KB CAN1

0x4000 6000 - 0x4000 63FF 1 KB CRS

0x4000 5C00- 0x4000 5FFF 1 KB I2C3

0x4000 5800 - 0x4000 5BFF 1 KB I2C2

0x4000 5400 - 0x4000 57FF 1 KB I2C1

0x4000 4C00 - 0x4000 53FF 2 KB Reserved

0x4000 4800 - 0x4000 4BFF 1 KB USART3

0x4000 4400 - 0x4000 47FF 1 KB USART2

0x4000 4000 - 0x4000 43FF 1 KB Reserved

0x4000 3C00 - 0x4000 3FFF 1 KB SPI3

0x4000 3800 - 0x4000 3BFF 1 KB SPI2

0x4000 3400 - 0x4000 37FF 1 KB Reserved

0x4000 3000 - 0x4000 33FF 1 KB IWDG

82/208 DS11453 Rev 3

STM32L431xx Memory mapping

Table 18. STM32L431xx memory map and peripheral register boundary addresses

(continued)

Bus Boundary address Size(bytes) Peripheral

0x4000 2C00 - 0x4000 2FFF 1 KB WWDG

0x4000 2800 - 0x4000 2BFF 1 KB RTC

0x4000 1800 - 0x4000 27FF 4 KB Reserved

APB1

1. The gray color is used for reserved boundary addresses.

0x4000 1400 - 0x4000 17FF 1 KB TIM7

0x4000 1000 - 0x4000 13FF 1 KB TIM6

0x4000 0400- 0x4000 0FFF 3 KB Reserved

0x4000 0000 - 0x4000 03FF 1 KB TIM2

(1)

DS11453 Rev 3 83/208

Electrical characteristics STM32L431xx

MS19210V1

MCU pin

C = 50 pF

MS19211V1

MCU pin

6 Electrical characteristics

6.1 Parameter conditions

Unless otherwise specified, all voltages are referenced to VSS.

6.1.1 Minimum and maximum values

Unless otherwise specified, the minimum and maximum values are guaranteed in the worst conditions of ambient temperature, supply voltage and frequencies by tests in production on 100% of the devices with an ambient temperature at T the selected temperature range).

Data based on characterization results, design simulation and/or technology characteristics are indicated in the table footnotes and are not tested in production. Based on characterization, the minimum and maximum values refer to sample tests and represent the mean value plus or minus three times the standard deviation (mean ±3).

6.1.2 Typical values

= 25 °C and TA = TAmax (given by

Unless otherwise specified, typical data are based on TA = 25 °C, VDD = V are given only as design guidelines and are not tested.

Typical ADC accuracy values are determined by characterization of a batch of samples from a standard diffusion lot over the full temperature range, where 95% of the devices have an error less than or equal to the value indicated

6.1.3 Typical curves

Unless otherwise specified, all typical curves are given only as design guidelines and are not tested.

6.1.4 Loading capacitor

The loading conditions used for pin parameter measurement are shown in Figure 16.

6.1.5 Pin input voltage

The input voltage measurement on a pin of the device is described in Figure 17.

Figure 16. Pin loading conditions Figure 17. Pin input voltage

(mean ±2).

= 3 V. They

DDA

84/208 DS11453 Rev 3

STM32L431xx Electrical characteristics

MSv41628V1

Level shifter

logic

Kernel logic

(CPU, Digital

& Memories)

Backup circuitry

(LSE, RTC,

Backup registers)

OUT

Regulator

GPIOs

1.55 – 3.6 V

n x 100 nF

+1 x 4.7 μF

n x VSS

n x VDD

VBAT

CORE

Power switch

DDIO1

ADCs/ DACs/ OPAMPs/ COMPs/ VREFBUF

VREF+

VREF-

DDA

10 nF

+1 μF

VDDA

VSSA

REF

100 nF

+1 μF

6.1.6 Power supply scheme

Figure 18. Power supply scheme

Caution: Each power supply pair (V

capacitors as shown above. These capacitors must be placed as close as possible to, or below, the appropriate pins on the underside of the PCB to ensure the good functionality of the device.

DD/VSS

, V

DDA/VSSA

etc.) must be decoupled with filtering ceramic

DS11453 Rev 3 85/208

176

Electrical characteristics STM32L431xx

MSv41629V1

BAT

DDA

DD_VBAT

6.1.7 Current consumption measurement

Figure 19. Current consumption measurement scheme

The I

DD_ALL

including the current supplying VDD, V

parameters given in Table 26 to Ta b le 38 represent the total MCU consumption

DDA

and V

BAT

6.2 Absolute maximum ratings

Stresses above the absolute maximum ratings listed in Tab le 19: Voltage characteristics,

Tabl e 20: Current characteristics and Table 21: Thermal characteristics may cause

permanent damage to the device. These are stress ratings only and functional operation of the device at these conditions is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability. Device mission profile (application conditions) is compliant with JEDEC JESD47 qualification standard, extended mission profiles are available on demand.

Table 19. Voltage characteristics

Symbol Ratings Min Max Unit

DDX

|V

- V

(2)

DDx

External main supply voltage (including

, V

DDA

BAT

)

Input voltage on FT_xxx pins

Input voltage on any other pins V

Variations between different V

pins of the same domain

DDX

power

-0.3 4.0 V

-0.3 min (VDD, V

-0.3 4.0

-50mV

(1)

(3)(4)

) +

4.0

DDA

VInput voltage on TT_xx pins VSS-0.3 4.0

SSx-VSS

1. All main power (VDD, V the permitted range.

maximum must always be respected. Refer to Table 20: Current characteristics for the maximum allowed injected

2. V

current values.

3. This formula has to be applied only on the power supplies related to the IO structure described in the pin definition table.

4. To sustain a voltage higher than 4 V the internal pull-up/pull-down resistors must be disabled.

Variations between all the different ground

pins

(5)

DDA

, V

) and ground (VSS, V

BAT

-50mV

) pins must always be connected to the external power supply, in

SSA

86/208 DS11453 Rev 3

STM32L431xx Electrical characteristics

5. Include VREF- pin.

Table 20. Current characteristics

Symbol Ratings Max Unit

(1)

140

100

IV

DD(PIN)

SS(PIN)

Total current into sum of all V

Total current out of sum of all V

Maximum current into each V

Maximum current out of each V

power lines (source)

ground lines (sink)

power pin (source)

ground pin (sink)

Output current sunk by any I/O and control pin except FT_f 20

IO(PIN)

I

IO(PIN)

INJ(PIN)

(3)

Output current sunk by any FT_f pin 20

Output current sourced by any I/O and control pin 20

Total output current sunk by sum of all I/Os and control pins

Total output current sourced by sum of all I/Os and control pins

Injected current on FT_xxx, TT_xx, RST and B pins, except PA4, PA5

(2)

100

-5/+0

(4)

Injected current on PA4, PA5 -5/0

|I

1. All main power (VDD, V in the permitted range.

2. This current consumption must be correctly distributed over all I/Os and control pins. The total output current must not be sunk/sourced between two consecutive power supply pins referring to high pin count QFP packages.

3. Positive injection (when V specified maximum value.

4. A negative injection is induced by V

characteristics for the maximum allowed input voltage values.

5. When several inputs are submitted to a current injection, the maximum |I injected currents (instantaneous values).

INJ(PIN)

Total injected current (sum of all I/Os and control pins)

, V

DDA

) and ground (VSS, V

BAT

> V

) is not possible on these I/Os and does not occur for input voltages lower than the

DDIOx

< VSS. I

INJ(PIN)

) pins must always be connected to the external power supplies,

SSA

must never be exceeded. Refer also to Table 19: Voltage

(5)

is the absolute sum of the negative

INJ(PIN)

Table 21. Thermal characteristics

Symbol Ratings Value Unit

STG

Storage temperature range –65 to +150 °C

Maximum junction temperature 150 °C

DS11453 Rev 3 87/208

176

Electrical characteristics STM32L431xx

6.3 Operating conditions

6.3.1 General operating conditions

Table 22. General operating conditions

Symbol Parameter Conditions Min Max Unit

HCLK

PCLK1

PCLK2

Internal AHB clock frequency - 0 80

Internal APB1 clock frequency - 0 80

Internal APB2 clock frequency - 0 80

Standard operating voltage -

1.71

(1)

MHzf

3.6 V

ADC or COMP used 1.62

DAC or OPAMP used 1.8

Analog supply voltage

DDA

Backup operating voltage - 1.55 3.6 V

BAT

VREFBUF used 2.4

ADC, DAC, OPAMP, COMP, VREFBUF not used

TT_xx I/O -0.3 V

I/O input voltage

All I/O except TT_xx -0.3

3.6 V

+0.3

DDIOx

Min(Min(V V

DDA

5.5 V)

)+3.6 V,

(2)(3)

LQFP100 - 476

LQFP64 - 444

Power dissipation at

= 85 °C for suffix 6

= 105 °C for suffix 7

Ambient temperature for the suffix 6 version

Ambient temperature for the

suffix 7 version

Ambient temperature for the suffix 3 version

Junction temperature range

(4)

LQFP48 - 350

UFBGA100 - 350

UFBGA64 - 307

UFQFPN48 - 606

UFQFPN32 - 523

WLCSP64 - 434

WLCSP49 - 416

Maximum power dissipation –40 85

Low-power dissipation

(5)

–40 105

Maximum power dissipation –40 105

Low-power dissipation

(5)

–40 125

Maximum power dissipation –40 125

Low-power dissipation

(5)

–40 130

Suffix 6 version –40 105

Suffix 3 version –40 130

°C

°CSuffix 7 version –40 125

88/208 DS11453 Rev 3

STM32L431xx Electrical characteristics

1. When RESET is released functionality is guaranteed down to V

2. This formula has to be applied only on the power supplies related to the IO structure described by the pin definition table. Maximum I/O input voltage is the smallest value between Min(V

, V

3. For operation with voltage higher than Min (V disabled.

is lower, higher PD values are allowed as long as TJ does not exceed T

4. If T

characteristics).

5. In low-power dissipation state, T

Thermal characteristics).

can be extended to this range as long as TJ does not exceed T

) +0.3 V, the internal Pull-up and Pull-Down resistors must be

DDA

BOR0

Min.

, V

)+3.6 V and 5.5V.

DDA

(see Section 7.10: Thermal

Jmax

(see Section 7.10:

Jmax

6.3.2 Operating conditions at power-up / power-down

The parameters given in Tab le 23 are derived from tests performed under the ambient temperature condition summarized in Tab le 22.

Symbol Parameter Conditions Min Max Unit

VDD

VDDA

Table 23. Operating conditions at power-up / power-down

VDD rise time rate

fall time rate 10 

rise time rate

DDA

fall time rate 10 

DDA

0 

µs/V

The requirements for power-up/down sequence specified in Section 3.9.1: Power supply

schemes must be respected.

6.3.3 Embedded reset and power control block characteristics

The parameters given in Tab le 24 are derived from tests performed under the ambient temperature conditions summarized in Table 22: General operating conditions.

RSTTEMPO

Table 24. Embedded reset and power control block characteristics

Symbol Parameter Conditions

Reset temporization after

BOR0

(2)

BOR0 is detected

(2)

Brown-out reset threshold 0

Rising edge 1.62 1.66 1.7

Falling edge 1.6 1.64 1.69

Rising edge 2.06 2.1 2.14

BOR1

Brown-out reset threshold 1

Falling edge 1.96 2 2.04

Rising edge 2.26 2.31 2.35

BOR2

Brown-out reset threshold 2

Falling edge 2.16 2.20 2.24

Rising edge 2.56 2.61 2.66

BOR3

Brown-out reset threshold 3

Falling edge 2.47 2.52 2.57

Rising edge 2.85 2.90 2.95

BOR4

Brown-out reset threshold 4

Falling edge 2.76 2.81 2.86

(1)

Min Typ Max Unit

rising - 250 400 s

DS11453 Rev 3 89/208

176

Electrical characteristics STM32L431xx

Table 24. Embedded reset and power control block characteristics (continued)

Symbol Parameter Conditions

(1)

Min Typ Max Unit

PVD0

PVD1

PVD2

PVD3

PVD4

PVD5

PVD6

hyst_BORH0

hyst_BOR_PVD

(BOR_PVD)

PVM3

PVM4

Programmable voltage detector threshold 0

PVD threshold 1

PVD threshold 2

PVD threshold 3

PVD threshold 4

PVD threshold 5

PVD threshold 6

Hysteresis voltage of BORH0

Hysteresis voltage of BORH (except BORH0) and PVD

(3)

BOR

(2)

(except BOR0) and

PVD consumption from V

peripheral voltage

DDA

monitoring

peripheral voltage

DDA

monitoring

Rising edge 2.1 2.15 2.19

Falling edge 2 2.05 2.1

Rising edge 2.26 2.31 2.36

Falling edge 2.15 2.20 2.25

Rising edge 2.41 2.46 2.51

Falling edge 2.31 2.36 2.41

Rising edge 2.56 2.61 2.66

Falling edge 2.47 2.52 2.57

Rising edge 2.69 2.74 2.79

Falling edge 2.59 2.64 2.69

Rising edge 2.85 2.91 2.96

Falling edge 2.75 2.81 2.86

Rising edge 2.92 2.98 3.04

Falling edge 2.84 2.90 2.96

Hysteresis in continuous

-20-

mode

Hysteresis in other mode

-30-

--100-mV

--1.11.6µA

Rising edge 1.61 1.65 1.69

Falling edge 1.6 1.64 1.68

Rising edge 1.78 1.82 1.86

Falling edge 1.77 1.81 1.85

hyst_PVM3

hyst_PVM4

(PVM1)

(2)

IDD

(PVM3/PVM4)

(2)

1. Continuous mode means Run/Sleep modes, or temperature sensor enable in Low-power run/Low-power sleep modes.

2. Guaranteed by design.

3. BOR0 is enabled in all modes (except shutdown) and its consumption is therefore included in the supply current characteristics tables.

PVM3 hysteresis - - 10 - mV

PVM4 hysteresis - - 10 - mV

PVM1 consumption from V

PVM3 and PVM4 consumption from V

90/208 DS11453 Rev 3

--0.2-µA

--2-µA

STM32L431xx Electrical characteristics

6.3.4 Embedded voltage reference

The parameters given in Tab le 25 are derived from tests performed under the ambient temperature and supply voltage conditions summarized in Table 22: General operating

conditions.

Symbol Parameter Conditions Min Typ Max Unit

Table 25. Embedded internal voltage reference

REFINT

S_vrefint

Internal reference voltage –40 °C < TA < +130 °C 1.182 1.212 1.232 V

ADC sampling time when

(1)

reading the internal reference

-4

voltage

start_vrefint

DD(VREFINTBUF

Start time of reference voltage buffer when ADC is enable

buffer consumption

REFINT

when converted by

)

V from V ADC

--812

- - 12.5 20

Internal reference voltage

V

REFINT

spread over the temperature

VDD = 3 V - 5 7.5

range

Coeff

DDCoeff

REFINT_DIV1

REFINT_DIV2

REFINT_DIV3

1. The shortest sampling time can be determined in the application by multiple iterations.

2. Guaranteed by design.

Temperature coefficient –40°C < TA < +130°C - 30 50

Long term stability 1000 hours, T = 25°C - 300 1000

Voltage coefficient 3.0 V < VDD < 3.6 V - 250 1200

1/4 reference voltage

1/2 reference voltage 49 50 51

3/4 reference voltage 74 75 76

(2)

--µs

24 25 26

(2)

µs

µA

ppm/°C

ppm

ppm/V

REFINT

DS11453 Rev 3 91/208

176

Electrical characteristics STM32L431xx

MSv40169V1

1.185

1.19

1.195

1.2

1.205

1.21

1.215

1.22

1.225

1.23

1.235

-40 -20 0 20 40 60 80 100 120

°C

Mean Min Max

Figure 20. V

versus temperature

REFINT

92/208 DS11453 Rev 3

STM32L431xx Electrical characteristics

6.3.5 Supply current characteristics

The current consumption is a function of several parameters and factors such as the operating voltage, ambient temperature, I/O pin loading, device software configuration, operating frequencies, I/O pin switching rate, program location in memory and executed binary code.

The current consumption is measured as described in Figure 19: Current consumption

measurement scheme.

Typical and maximum current consumption

The MCU is placed under the following conditions:

• All I/O pins are in analog input mode

• All peripherals are disabled except when explicitly mentioned

• The Flash memory access time is adjusted with the minimum wait states number,

depending on the f to CPU clock (HCLK) frequency” available in the RM0394 reference manual).

• When the peripherals are enabled f

The parameters given in Tab le 26 to Ta bl e 39 are derived from tests performed under ambient temperature and supply voltage conditions summarized in Tab le 22: General

operating conditions.

frequency (refer to the table “Number of wait states according

HCLK

= f

PCLK

HCLK

DS11453 Rev 3 93/208

176

94/208 DS11453 Rev 3

Symbol Parameter

DD_ALL

(Run)

Supply

current in

Run mode

Table 26. Current consumption in Run and Low-power run modes, code with data processing

Conditions TYP MAX

= f

HCLK

HSE

up to 48MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

running from Flash, ART enable (Cache ON Prefetch OFF)

Voltage scaling

HCLK

25 °C 55 °C 85 °C 105 °C 125 °C 25 °C 55 °C 85 °C 105 °C 125 °C

26 MHz 2.37 2.38 2.44 2.52 2.66 2.7 2.7 2.8 2.9 3.2

16 MHz 1.5 1.52 1.57 1.64 1.79 1.7 1.7 1.8 2.0 2.3

8 MHz 0.81 0.82 0.87 0.94 1.08 0.9 0.9 1.0 1.2 1.5

Range 2

4 MHz 0.46 0.47 0.52 0.59 0.73 0.5 0.6 0.6 0.8 1.1

2 MHz 0.29 0.3 0.34 0.41 0.55 0.3 0.4 0.4 0.6 0.9

1 MHz 0.2 0.21 0.25 0.32 0.46 0.2 0.3 0.3 0.5 0.8

100 kHz 0.12 0.13 0.17 0.24 0.38 0.1 0.2 0.2 0.4 0.7

80 MHz 8.53 8.56 8.64 8.74 8.92 9.5 9.6 9.7 9.9 10.3

72 MHz 7.7 7.73 7.8 7.9 8.08 8.6 8.6 8.7 8.9 9.3

64 MHz 6.86 6.9 6.97 7.06 7.23 7.7 7.7 7.8 8.0 8.3

Electrical characteristics STM32L431xx

(1)

Unit

Range 1

48 MHz 5.13 5.16 5.23 5.32 5.49 5.8 5.8 6.0 6.1 6.5

32 MHz 3.46 3.48 3.55 3.64 3.8 3.9 4.0 4.1 4.2 4.6

24 MHz 2.63 2.64 2.71 2.79 2.96 3.0 3.0 3.1 3.3 3.6

16 MHz 1.8 1.81 1.87 1.96 2.12 2.0 2.1 2.2 2.3 2.7

2 MHz 211 230 280 355 506 273.8 301.1 360.4 502.7 815.9

DD_ALL

(LPRun)

Supply

current in

Low-power

run mode

= f

HCLK

MSI

all peripherals disable

1 MHz 117 134 179 254 404 154.7 184.6 249.6 398.4 712.4

400 kHz 58.5 70.4 116 189 338 80.2 111.5 179.7 330.8 643.4

100 kHz 30 41.1 85.2 159 308 46.5 76.6 147.1 299.1 611.2

1. Guaranteed by characterization results, unless otherwise specified.

µA

DS11453 Rev 3 95/208

Symbol Parameter

DD_ALL

(Run)

Supply

current in

Run mode

Supply

DD_ALL

(LPRun)

current in

Low-power

run

Table 27. Current consumption in Run and Low-power run modes, code with data processing

Conditions TYP MAX

= f

HCLK

HSE

up to 48MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

= f

HCLK

MSI

all peripherals disable

Voltage

scaling

Range 2

Range 1

running from Flash, ART disable

HCLK

25 °C 55 °C 85 °C 105 °C 125 °C 25 °C 55 °C 85 °C 105 °C 125 °C

26 MHz 2.66 2.68 2.73 2.81 2.96 3.0 3.1 3.2 3.3 3.6

16 MHz 1.88 1.9 1.94 2.02 2.17 2.1 2.2 2.3 2.4 2.7

8 MHz 1.05 1.06 1.11 1.18 1.33 1.2 1.2 1.3 1.4 1.7

4 MHz 0.6 0.62 0.66 0.73 0.87 0.7 0.7 0.8 0.9 1.2

2 MHz 0.36 0.37 0.34 0.48 0.62 0.4 0.4 0.5 0.6 0.9

1 MHz 0.23 0.25 0.25 0.36 0.5 0.3 0.3 0.4 0.5 0.8

100 kHz 0.12 0.14 0.17 0.25 0.39 0.1 0.2 0.2 0.4 0.7

80 MHz 8.56 8.61 8.69 8.79 8.97 9.6 9.7 9.8 10.0 10.3

72 MHz 7.74 7.79 7.86 7.96 8.14 8.7 8.7 8.8 9.0 9.4

64 MHz 7.63 7.68 7.75 7.85 8.04 8.6 8.6 8.7 8.9 9.3

48 MHz 6.36 6.4 6.48 6.58 6.76 7.2 7.3 7.4 7.6 7.9

32 MHz 4.56 4.6 4.66 4.76 4.93 5.2 5.2 5.3 5.5 5.8

24 MHz 3.45 3.48 3.54 3.64 3.8 3.9 4.0 4.1 4.2 4.6

16 MHz 2.48 2.51 2.56 2.65 2.82 2.8 2.9 3.0 3.1 3.5

2 MHz 310 317 364 440 593 375.3 400.9 456.7 595.3 909.6

1 MHz 157 173 226 296 448 204.8 234.2 298.2 445.8 758.9

400 kHz 72.6 89 130 206 356 99.7 131.2 199.7 349.3 663.7

100 kHz 32.3 46 89.7 164 314 52.4 82.1 153.3 301.2 616.9

STM32L431xx Electrical characteristics

(1)

Unit

µA

1. Guaranteed by characterization results, unless otherwise specified.

96/208 DS11453 Rev 3

Table 28. Current consumption in Run and Low-power run modes, code with data processing

Conditions TYP MAX

Symbol Parameter

= f

HSE

up to

DD_ALL

(Run)

Supply

current in

Run mode

HCLK

48MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

Supply

DD_ALL

(LPRun)

current in

low-power

run mode

1. Guaranteed by characterization results, unless otherwise specified.

= f

HCLK

MSI

all peripherals disable FLASH in power-down

Voltage scaling

Range 2

Range 1

running from SRAM1

(1)

HCLK

25 °C 55 °C 85 °C

105 °C125

°C

25 °C 55 °C 85 °C

26 MHz 2.42 2.43 2.49 2.56 2.71 2.7 2.7 2.8 3.0 3.3

16 MHz 1.54 1.55 1.6 1.67 1.82 1.7 1.7 1.8 2.0 2.3

8 MHz 0.82 0.84 0.88 0.95 1.1 0.9 1.0 1.0 1.2 1.5

4 MHz 0.47 0.48 0.52 0.59 0.73 0.5 0.6 0.6 0.8 1.1

2 MHz 0.29 0.3 0.34 0.41 0.55 0.3 0.4 0.4 0.6 0.9

1 MHz 0.2 0.21 0.25 0.32 0.46 0.2 0.3 0.3 0.5 0.8

100 kHz 0.12 0.13 0.17 0.24 0.38 0.1 0.2 0.2 0.4 0.7

80 MHz 8.63 8.68 8.74 8.84 9.01 9.5 9.6 9.7 9.9 10.2

72 MHz 7.79 7.83 7.9 7.99 8.17 8.6 8.6 8.8 8.9 9.3

64 MHz 6.95 6.99 7.05 7.15 7.32 7.7 7.7 7.9 8.0 8.4

48 MHz 5.19 5.22 5.29 5.38 5.55 5.8 5.8 5.9 6.1 6.5

32 MHz 3.51 3.53 3.6 3.68 3.85 3.9 4.0 4.1 4.2 4.6

24 MHz 2.66 2.68 2.74 2.83 2.99 3.0 3.0 3.1 3.3 3.6

16 MHz 1.82 1.84 1.89 1.98 2.14 2.0 2.1 2.2 2.3 2.7

2 MHz 205 228 275 352 501 276.5 302.3 358.4 502.5 816.4

1 MHz 111 126 175 248 397 151.3 180.9 245.3 390.7 703.4

400 kHz 49.2 62.7 108 181 330 73.3 104.0 170.8 321.0 632.4

100 kHz 21.5 33.3 76.6 151 299 36.4 67.7 137.2 287.8 600.8

105 °C125

°C

Electrical characteristics STM32L431xx

Unit

µA

STM32L431xx Electrical characteristics

Table 29. Typical current consumption in Run and Low-power run modes, with different codes

running from Flash, ART enable (Cache ON Prefetch OFF)

Symbol Parameter

DD_ALL

(Run)

Supply

current in

Run mode

Supply

DD_ALL

(LPRun)

current in

Low-power

run

Conditions TYP

Volt age scaling

HCLK

= f

HSE

to 48 MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

= f

HCLK

MSI

= 2 MHz

all peripherals disable

Code 25 °C 25 °C

Reduced code

(1)

2.37

Coremark 2.69 103

Dhrystone 2.1 2.74 105

= 26 MHz

Range 2

Fibonacci 2.58 99

HCLK

While(1) 2.30 88

Reduced code

(1)

8.53

Coremark 9.68 121

Dhrystone 2.1 9.76 122

= 80 MHz

Range 1

Fibonacci 9.27 116

HCLK

While(1) 8.20 103

Reduced code

(1)

211

Coremark 251 126

Dhrystone 2.1 269 135

Fibonacci 230 115

Unit

µA

TYP

Unit

µA/MHz

107

µA/MHz

106

µA/MHz

While(1) 286 143

1. Reduced code used for characterization results provided in Table 26, Table 27, Table 28.

DS11453 Rev 3 97/208

176

Electrical characteristics STM32L431xx

Table 30. Typical current consumption in Run and Low-power run modes, with different codes

running from Flash, ART disable

Conditions TYP

Symbol Parameter

Voltage

scaling

Code 25 °C 25 °C

Reduced code

(1)

2.66

Coremark 2.44 94

Dhrystone 2.1 2.46 95

= 26 MHz

Range 2

Fibonacci 2.27 87

HCLK

While(1) 2.20 84.6

Reduced code

(1)

Coremark 8.00 100

Dhrystone 2.1 7.98 100

= 80 MHz

Range 1

Fibonacci 7.41 93

HCLK

While(1) 7.83 98

Reduced code

(1)

Coremark 342 171

Dhrystone 2.1 324 162

Fibonacci 324 162

DD_ALL

(Run)

DD_ALL

(LPRun)

Supply

current in

Run mode

Supply

current in

Low-power

run

= f

HCLK

HSE

up to 48 MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

= f

HCLK

MSI

= 2 MHz

all peripherals disable

While(1) 384 192

1. Reduced code used for characterization results provided in Table 26, Table 27, Table 28.

8.56

310

Unit

µA

TYP

Unit

102

µA/MHz

107

µA/MHz

155

µA/MHz

Table 31. Typical current consumption in Run and Low-power run modes, with different codes

running from SRAM1

Conditions TYP

Symbol Parameter

Voltage

scaling

Code 25 °C 25 °C

Reduced code

(1)

2.42

Coremark 2.18 84

Dhrystone 2.1 2.40 92

= 26 MHz

Range 2

Fibonacci 2.40 92

HCLK

While(1) 2.29 88

Reduced code

(1)

Coremark 7.76 97

Dhrystone 2.1 8.55 107

= 80 MHz

Range 1

Fibonacci 8.56 107

HCLK

While(1) 8.12 102

Reduced code

(1)

Coremark 188 94

Dhrystone 2.1 222 111

Fibonacci 204 102

DD_ALL

(Run)

DD_ALL

(LPRun)

Supply

current in

Run mode

Supply

current in

Low-power

run

= f

HCLK

HSE

up to 48 MHz included, bypass mode PLL ON above 48 MHz all peripherals disable

= f

HCLK

MSI

= 2 MHz

all peripherals disable

While(1) 211 106

1. Reduced code used for characterization results provided in Table 26, Table 27, Table 28.

Unit

8.63

205

µA

TYP

Unit

µA/MHz

108

µA/MHz

103

µA/MHz

98/208 DS11453 Rev 3

Table 32. Current consumption in Sleep and Low-power sleep modes, Flash ON

Conditions TYP MAX

Symbol Parameter

= f

HSE

MSI

HCLK

to 48 MHz

DS11453 Rev 3 99/208

DD_ALL

(Sleep)

Supply

current in

sleep

mode,

included, bypass mode pll ON above 48 MHz all peripherals disable

Supply

DD_ALL

(LPSleep)

current in

low-power

sleep

HCLK

all peripherals disable

mode

1. Guaranteed by characterization results, unless otherwise specified.

Voltage scaling

Range 2

Range 1

(1)

HCLK

25 °C 55 °C 85 °C 105 °C 125 °C 25 °C 55 °C 85 °C 105 °C 125 °C

26 MHz 0.68 0.69 0.74 0.81 0.95 0.8 0.8 0.9 1.0 1.3

16 MHz 0.46 0.48 0.52 0.59 0.73 0.5 0.6 0.6 0.8 1.1

8 MHz 0.29 0.30 0.34 0.41 0.55 0.3 0.4 0.4 0.6 0.9

4 MHz 0.20 0.21 0.25 0.32 0.46 0.2 0.3 0.3 0.5 0.8

2 MHz 0.16 0.17 0.21 0.28 0.42 0.2 0.2 0.3 0.4 0.7

1 MHz 0.13 0.15 0.19 0.26 0.40 0.1 0.2 0.3 0.4 0.7

100 kHz 0.11 0.13 0.17 0.24 0.38 0.1 0.2 0.2 0.4 0.7

80 MHz 2.23 2.25 2.30 2.38 2.54 2.5 2.5 2.6 2.8 3.1

72 MHz 2.02 2.04 2.10 2.18 2.34 2.2 2.3 2.4 2.5 2.9

64 MHz 1.82 1.84 1.89 1.98 2.14 2.0 2.1 2.1 2.3 2.6

48 MHz 1.34 1.36 1.42 1.50 1.66 1.5 1.6 1.7 1.8 2.2

32 MHz 0.93 0.95 1.01 1.09 1.25 1.1 1.1 1.2 1.4 1.7

24 MHz 0.73 0.75 0.80 0.88 1.04 0.8 0.9 1.0 1.1 1.4

16 MHz 0.53 0.55 0.60 0.68 0.84 0.6 0.6 0.7 0.9 1.2

2 MHz 71.8 80.7 125 200 350 91.1 122.7 191.3 341.5 653.5

1 MHz 45.0 57.3 101 176 325 63.2 95.4 165.4 316.5 628.7

400 kHz 27.0 40.7 84.6 158 308 43.9 75.8 147.2 297.6 609.2

100 kHz 22.8 30.9 63.3 113.2 207.7 35.2 67.9 140.9 290.8 602.4

STM32L431xx Electrical characteristics

Unit

µA

100/208 DS11453 Rev 3

Symbol Parameter

Table 33. Current consumption in Low-power sleep modes, Flash in power-down

Conditions TYP MAX

Voltage

scaling

HCLK

25 °C 55 °C 85 °C 105 °C 125 °C 25 °C 55 °C 85 °C 105 °C 125 °C

Electrical characteristics STM32L431xx

(1)

Unit

2 MHz 58.7 70.7 103.2 153.7 248.5 80 113 180 330 641

DD_ALL

(LPSleep)

Supply current

in low-power

sleep mode

= f

HCLK

MSI

all peripherals disable

1 MHz 39.4 47.2 79.3 129.6 224.8 53 86 154 304 616

400 kHz 20.8 30.8 62.1 112.5 207.8 35 67 137 286 597

100 kHz 14.3 23.1 55.1 105.7 201.5 27 58 130 279 590

1. Guaranteed by characterization results, unless otherwise specified.

Table 34. Current consumption in Stop 2 mode

Conditions TYP MAX

Symbol Parameter

-V

1.8 V 1 2.54 8.74 19.8 43.4 2.0 5.6 21.1 50.8 116.0

DD_ALL

(Stop 2)

Supply current in Stop 2 mode, RTC disabled

2.4 V 1.02 2.59 8.89 20.2 44.3 2.1 5.8 21.6 52.3 119.6

3.6 V 1.23 2.88 9.56 21.6 47.3 2.3 6.1 23.0 55.8 127.9

1.8 V 1.3 2.82 9.02 20.1 43.6 2.5 6.2 21.6 51.3 116.3

RTC clocked by LSI

2.4 V 1.39 2.95 9.24 20.5 44.6 2.8 6.4 22.3 52.8 120.0

3.6 V 1.76 3.42 10.1 22.1 47.8 3.3 7.2 24.1 56.7 128.7

1.8 V 1.36 2.9 9.1 20.1 43.7 - - - - -

DD_ALL

(Stop 2 with

RTC)

Supply current in Stop 2 mode, RTC enabled

RTC clocked by LSE bypassed at 32768 Hz

2.4 V 1.48 3.09 9.44 20.8 45 - - - - -

3.6 V 3.58 6.17 13.9 26.6 53 - - - - -

1.8 V 1.28 2.81 9.13 20.8 - - - - - -

RTC clocked by LSE

(2)

quartz

2.4 V 1.39 2.93 9.34 21.3 - - - - - -

in low drive mode

3.6 V 1.86 3.45 10.2 22.8 - - - - - -

(1)

25 °C 55 °C 85 °C 105 °C 125 °C 25 °C 55 °C 85 °C 105 °C 125 °C

3 V 1.06 2.67 9.11 20.7 45.5 2.1 5.9 22.2 53.7 123.2

3 V 1.5 3.11 9.55 21.1 45.8 3.0 6.8 23.0 54.5 123.8

3 V 1.83 3.67 10.4 22.3 47.3 - - - - -

3 V 1.59 3.1 9.64 21.8 - - - - - -

µA

Unit

µA

ST MICROELECTRONICS STM32L431CBT6 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

Table 1. Device summary

1 Introduction

2 Description

Figure 1. STM32L431xx block diagram

3 Functional overview

3.1 Arm® Cortex®-M4 core with FPU

3.2 Adaptive real-time memory accelerator (ART Accelerator™)

3.3 Memory protection unit

3.4 Embedded Flash memory

Table 3. Access status versus readout protection level and execution modes

3.5 Embedded SRAM

3.6 Firewall

3.7 Boot modes

3.8 Cyclic redundancy check calculation unit (CRC)

3.9 Power supply management

3.9.1 Power supply schemes

Figure 2. Power supply overview

Figure 3. Power-up/down sequence

3.9.2 Power supply supervisor

3.9.3 Voltage regulator

3.9.4 Low-power modes

3.9.5 Reset mode

3.9.6 VBAT operation

3.10 Interconnect matrix

Table 6. STM32L431xx peripherals interconnect matrix

3.11 Clocks and startup

Figure 4. Clock tree

3.12 General-purpose inputs/outputs (GPIOs)

3.13 Direct memory access controller (DMA)

Table 7. DMA implementation

3.14 Interrupts and events

3.14.1 Nested vectored interrupt controller (NVIC)

3.14.2 Extended interrupt/event controller (EXTI)

3.15 Analog to digital converter (ADC)

3.15.1 Temperature sensor

Table 8. Temperature sensor calibration values

Table 9. Internal voltage reference calibration values

3.16 Digital to analog converter (DAC)

3.17 Voltage reference buffer (VREFBUF)

Figure 5. Voltage reference buffer

3.18 Comparators (COMP)

3.19 Operational amplifier (OPAMP)

3.20 Touch sensing controller (TSC)

3.21 Random number generator (RNG)

3.22 Timers and watchdogs

3.22.1 Advanced-control timer (TIM1)

3.22.2 General-purpose timers (TIM2, TIM15, TIM16)

3.22.3 Basic timers (TIM6 and TIM7)

3.22.4 Low-power timer (LPTIM1 and LPTIM2)

3.22.5 Infrared interface (IRTIM)

3.22.6 Independent watchdog (IWDG)

3.22.7 System window watchdog (WWDG)

3.22.8 SysTick timer

3.23 Real-time clock (RTC) and backup registers

3.24 Inter-integrated circuit interface (I2C)

Table 11. I2C implementation

3.25 Universal synchronous/asynchronous receiver transmitter (USART)

Table 12. STM32L431xx USART/LPUART features

3.26 Low-power universal asynchronous receiver transmitter (LPUART)

3.27 Serial peripheral interface (SPI)

3.28 Serial audio interfaces (SAI)

Table 13. SAI implementation

3.29 Single wire protocol master interface (SWPMI)

3.30 Controller area network (CAN)

3.31 Secure digital input/output and MultiMediaCards Interface (SDMMC)

3.32 Clock recovery system (CRS)

3.33 Quad SPI memory interface (QUADSPI)

3.34 Development support

3.34.1 Serial wire JTAG debug port (SWJ-DP)

3.34.2 Embedded Trace Macrocell™

4 Pinouts and pin description

Table 14. Legend/abbreviations used in the pinout table

5 Memory mapping

Figure 15. STM32L431xx memory map

6 Electrical characteristics

6.1 Parameter conditions
