STMicroelectronics STM32G431C6, STM32G431C8, STM32G431CB, STM32G431K6, STM32G431K8 Datasheet
...
STM32G431xx STM32G441xx
Errata sheet
STM32G431xx/441xx device errata
Applicability
This document applies to the part numbers of STM32G431xx/441xx devices and the device variants as stated in this page.
It gives a summary and a description of the device errata, with respect to the device datasheet and reference manual RM0440.
Deviation of the real device behavior from the intended device behavior is considered to be a device limitation. Deviation of the
description in the reference manual or the datasheet from the intended device behavior is considered to be a documentation
erratum. The term “errata” applies both to limitations and documentation errata.
Table 1. Device summary
Reference Part numbers
STM32G431xx
STM32G441xx STM32G441CB, STM32G441KB, STM32G441MB, STM32G441RB, STM32G441VB
STM32G431C6, STM32G431C8, STM32G431CB, STM32G431K6, STM32G431K8, STM32G431KB,
STM32G431M6, STM32G431M8, STM32G431MB, STM32G431R6, STM32G431R8, STM32G431RB,
STM32G431V6, STM32G431V8, STM32G431VB
Table 2. Device variants
Reference
STM32G431xx/441xx
STM32G431xx/441xx Y 0x2002
STM32G431xxx/441xx X 0x2003
1. Refer to the device datasheet for how to identify this code on different types of package.
2. REV_ID[15:0] bitfield of DBGMCU_IDCODE register.
Device marking
Z 0x2001
Silicon revision codes
(1)
REV_ID
(2)
ES0431 - Rev 7 - April 2021
For further information contact your local STMicroelectronics sales office.
www.st.com
1 Summary of device errata
The following table gives a quick reference to the STM32G431xx/441xx device limitations and their status:
A = workaround available
N = no workaround available
P = partial workaround available
Applicability of a workaround may depend on specific conditions of target application. Adoption of a workaround
may cause restrictions to target application. Workaround for a limitation is deemed partial if it only reduces the
rate of occurrence and/or consequences of the limitation, or if it is fully effective for only a subset of instances on
the device or in only a subset of operating modes, of the function concerned.
Table 3. Summary of device limitations
Function Section Limitation
2.1.1 Interrupted loads to SP can cause erroneous behavior
Core
System
DMA 2.3.1
DMAMUX
ADC
COMP 2.6.1 Comparator previously not fully tested in production N N -
2.1.2
2.1.3
2.2.1 Full JTAG configuration without NJTRST pin cannot be used A A A
2.2.2
2.2.3 Unstable LSI when it clocks RTC or CSS on LSE P P P
2.2.4
2.4.1 SOFx not asserted when writing into DMAMUX_CFR register N N N
2.4.2
2.4.3 OFx not asserted when writing into DMAMUX_RGCFR register N N N
2.4.4
2.5.1
2.5.2
2.5.3
2.5.4 ADC_AWDy_OUT reset by non-guarded channels A A A
2.5.5 End of 10/8/6-bit ADC conversion disturbing other ADCs A - -
2.5.6 ADC input channel switching disturbs ongoing conversions P - -
2.5.7
2.5.8 ADC channel 0 converted instead of the required ADC channel - A -
VDIV or VSQRT instructions might not complete correctly when very
short ISRs are used
Store immediate overlapping exception return operation might vector
to incorrect interrupt
FLASH_ECCR corrupted upon reset or power-down occurring during
Flash memory program or erase operation
PCROP_RDP option bit production value not inline with the
specification
DMA disable failure and error flag omission upon simultaneous
transfer error and global flag clear
OFx not asserted for trigger event coinciding with last DMAMUX
request
Wrong input DMA request routed upon specific DMAMUX_CxCR
register write coinciding with synchronization event
New context conversion initiated without waiting for trigger when
writing new context in ADC_JSQR with JQDIS = 0 and JQM = 0
Two consecutive context conversions fail when writing new context
in ADC_JSQR just after previous context completion with JQDIS = 0
and JQM = 0
Unexpected regular conversion when two consecutive injected
conversions are performed in Dual interleaved mode
Wrong ADC result if conversion done late after calibration or previous
conversion
STM32G431xx STM32G441xx
Summary of device errata
Status
Rev.ZRev.YRev.
X
A A A
A A A
A A A
A A A
N - -
A A A
N N N
A A A
A A A
A A A
A A A
A A A
ES0431 - Rev 7
page 2/28
Function Section Limitation
OPAMP 2.7.1
TIM
LPTIM
RTC and TAMP
I2C
USART
SPI
FDCAN
USB
2.8.1
2.8.2 Consecutive compare event missed in specific conditions N N N
2.8.3
2.8.4 Output compare clear not working with external counter reset P P P
2.9.1
2.9.2 Device may remain stuck in LPTIM interrupt when clearing event flag P P P
2.9.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle P P P
2.10.1 Calendar initialization may fail in case of consecutive INIT mode entry A A A
2.10.2 Alarm flag may be repeatedly set when the core is stopped in debug N N N
2.10.3
2.10.4
2.10.5 Tamper flag not set on LSE failure detection N N N
2.11.1
2.11.2 Spurious bus error detection in master mode A A A
2.11.3 Spurious master transfer upon own slave address match P P P
2.11.4 OVR flag not set in underrun condition N N N
2.11.5 Transmission stalled after first byte transfer A A A
2.12.1 Anticipated end-of-transmission signaling in SPI slave mode A A A
2.12.2 Data corruption due to noisy receive line N N N
2.13.1 BSY bit may stay high when SPI is disabled A A A
2.13.2 BSY bit may stay high at the end of data transfer in slave mode A A A
2.14.1 Desynchronization under specific condition with edge filtering enabled A A A
2.14.2
2.15.1 ESOF interrupt timing desynchronized after resume signaling A A A
2.15.2 Incorrect CRC16 in the memory buffer N N N
OPAMP disturbed by fast-edge toggle on GPIO pin corresponding to
VINM0
One-pulse mode trigger not detected in master-slave reset + trigger
configuration
Compare event missed in center-aligned mode 1 and 2 with dithering
enabled
Device may remain stuck in LPTIM interrupt when entering Stop
mode
A tamper event fails to trigger timestamp or timestamp overflow
events during a few cycles after clearing TSF
REFCKON write protection associated to INIT KEY instead of CAL
KEY
Wrong data sampling when data setup time (tSU;DAT) is shorter than
one I2C kernel clock period
Tx FIFO messages inverted under specific buffer usage and priority
setting
STM32G431xx STM32G441xx
Summary of device errata
Status
Rev.ZRev.YRev.
X
P P P
P P P
N N N
A A A
N N N
A A A
P P P
A A A
ES0431 - Rev 7
page 3/28
STM32G431xx STM32G441xx
Description of device errata
2 Description of device errata
The following sections describe limitations of the applicable devices with Arm® core and provide workarounds if
available. They are grouped by device functions.
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
2.1 Core
Reference manual and errata notice for the Arm® Cortex®-M4 core revision r0p1 is available from http://
infocenter.arm.com.
2.1.1 Interrupted loads to SP can cause erroneous behavior
This limitation is registered under Arm ID number 752770 and classified into “Category B”. Its impact to the device
is minor.
Description
If an interrupt occurs during the data-phase of a single word load to the stack-pointer (SP/R13), erroneous
behavior can occur. In all cases, returning from the interrupt will result in the load instruction being executed an
additional time. For all instructions performing an update to the base register, the base register will be erroneously
updated on each execution, resulting in the stack-pointer being loaded from an incorrect memory location.
The affected instructions that can result in the load transaction being repeated are:
• LDR SP, [Rn],#imm
• LDR SP, [Rn,#imm]!
• LDR SP, [Rn,#imm]
• LDR SP, [Rn]
• LDR SP, [Rn,Rm]
The affected instructions that can result in the stack-pointer being loaded from an incorrect memory address are:
• LDR SP,[Rn],#imm
• LDR SP,[Rn,#imm]!
As compilers do not generate these particular instructions, the limitation is only likely to occur with hand-written
assembly code.
Workaround
Both issues may be worked around by replacing the direct load to the stack-pointer, with an intermediate load to a
general-purpose register followed by a move to the stack-pointer.
2.1.2 VDIV or VSQRT instructions might not complete correctly when very short ISRs are used
This limitation is registered under Arm ID number 776924 and classified into “Category B”. Its impact to the device
is limited.
ES0431 - Rev 7
Description
The VDIV and VSQRT instructions take 14 cycles to execute. When an interrupt is taken a VDIV or VSQRT
instruction is not terminated, and completes its execution while the interrupt stacking occurs. If lazy context save
of floating point state is enabled then the automatic stacking of the floating point context does not occur until a
floating point instruction is executed inside the interrupt service routine.
Lazy context save is enabled by default. When it is enabled, the minimum time for the first instruction in the
interrupt service routine to start executing is 12 cycles. In certain timing conditions, and if there is only one or two
instructions inside the interrupt service routine, then the VDIV or VSQRT instruction might not write its result to the
register bank or to the FPSCR.
page 4/28
STM32G431xx STM32G441xx
Core
The failure occurs when the following condition is met:
1. The floating point unit is enabled
2. Lazy context saving is not disabled
3. A VDIV or VSQRT is executed
4. The destination register for the VDIV or VSQRT is one of s0 - s15
5. An interrupt occurs and is taken
6. The interrupt service routine being executed does not contain a floating point instruction
7. Within 14 cycles after the VDIV or VSQRT is executed, an interrupt return is executed
A minimum of 12 of these 14 cycles are utilized for the context state stacking, which leaves 2 cycles for
instructions inside the interrupt service routine, or 2 wait states applied to the entire stacking sequence (which
means that it is not a constant wait state for every access).
In general, this means that if the memory system inserts wait states for stack transactions (that is, external
memory is used for stack data), then this erratum cannot be observed.
The effect of this erratum is that the VDIV or VQSRT instruction does not complete correctly and the register bank
and FPSCR are not updated, which means that these registers hold incorrect, out of date, data.
Workaround
A workaround is only required if the floating point unit is enabled. A workaround is not required if the stack is in
external memory.
There are two possible workarounds:
• Disable lazy context save of floating point state by clearing LSPEN to 0 (bit 30 of the FPCCR at address
0xE000EF34).
• Ensure that every interrupt service routine contains more than 2 instructions in addition to the exception
return instruction.
2.1.3 Store immediate overlapping exception return operation might vector to incorrect interrupt
This limitation is registered under Arm ID number 838869 and classified into “Category B (rare)”. Its impact to the
device is minor.
Description
The core includes a write buffer that permits execution to continue while a store is waiting on the bus. Under
specific timing conditions, during an exception return while this buffer is still in use by a store instruction, a late
change in selection of the next interrupt to be taken might result in there being a mismatch between the interrupt
acknowledged by the interrupt controller and the vector fetched by the processor.
The failure occurs when the following condition is met:
1. The handler for interrupt A is being executed.
2. Interrupt B, of the same or lower priority than interrupt A, is pending.
3. A store with immediate offset instruction is executed to a bufferable location.
– STR/STRH/STRB <Rt>, [<Rn>,#imm]
– STR/STRH/STRB <Rt>, [<Rn>,#imm]!
– STR/STRH/STRB <Rt>, [<Rn>],#imm
4. Any number of additional data-processing instructions can be executed.
5. A BX instruction is executed that causes an exception return.
6. The store data has wait states applied to it such that the data is accepted at least two cycles after the BX is
executed.
– Minimally, this is two cycles if the store and the BX instruction have no additional instructions between
them.
– The number of wait states required to observe this erratum needs to be increased by the number of
cycles between the store and the interrupt service routine exit instruction.
7. Before the bus accepts the buffered store data, another interrupt C is asserted which has the same or lower
priority as A, but a greater priority than B.
Example:
ES0431 - Rev 7
page 5/28
STM32G431xx STM32G441xx
System
The processor should execute interrupt handler C, and on completion of handler C should execute the handler
for B. If the conditions above are met, then this erratum results in the processor erroneously clearing the pending
state of interrupt C, and then executing the handler for B twice. The first time the handler for B is executed it
will be at interrupt C's priority level. If interrupt C is pended by a level-based interrupt which is cleared by C's
handler then interrupt C will be pended again once the handler for B has completed and the handler for C will be
executed.
As the STM32 interrupt C is level based, it eventually becomes pending again and is subsequently handled.
Workaround
For software not using the memory protection unit, this erratum can be worked around by setting DISDEFWBUF
in the Auxiliary Control Register.
In all other cases, the erratum can be avoided by ensuring a DSB occurs between the store and the BX
instruction. For exception handlers written in C, this can be achieved by inserting the appropriate set of intrinsics
or inline assembly just before the end of the interrupt function, for example:
ARMCC:
...
__schedule_barrier();
__asm{DSB};
__schedule_barrier();
}
GCC:
...
__asm volatile ("dsb 0xf":::"memory");
}
2.2
System
2.2.1 Full JTAG configuration without NJTRST pin cannot be used
Description
When using the JTAG debug port in Debug mode, the connection with the debugger is lost if the NJTRST pin
(PB4) is used as a GPIO. Only the 4-wire JTAG port configuration is impacted.
Workaround
Use the SWD debug port instead of the full 4-wire JTAG port.
2.2.2 FLASH_ECCR corrupted upon reset or power-down occurring during Flash memory program
or erase operation
Description
Reset or power-down occurring during a Flash memory location program or erase operation, followed by a read of
the same memory location, may lead to a corruption of the FLASH_ECCR register content.
Workaround
Under such condition, erase the page(s) corresponding to the Flash memory location.
2.2.3 Unstable LSI when it clocks RTC or CSS on LSE
Description
ES0431 - Rev 7
page 6/28
STM32G431xx STM32G441xx
The LSI clock can become unstable (duty cycle different from 50 %) and its maximum frequency can become
significantly higher than 32 kHz, when:
• LSI clocks the RTC, or it clocks the clock security system (CSS) on LSE (which holds when the LSECSSON
bit set), and
• the VDD power domain is reset while the backup domain is not reset, which happens:
– upon exiting Shutdown mode
– if V
– if V
Workaround
Apply one of the following measures:
• Clock the RTC with LSE or HSE/32, without using the CSS on LSE
• If LSI clocks the RTC or when the LSECSSON bit is set, reset the backup domain upon each VDD power up
(when the BORRSTF flag is set). If V
registers and anti-tampering configuration.
2.2.4 PCROP_RDP option bit production value not inline with the specification
is separate from VDD and VDD goes off then on
BAT
is tied to VDD (internally in the package for products not featuring the VBAT pin, or externally)
BAT
and a short (< 1 ms) VDD drop under VDD(min) occurs
is separate from VDD, also restore the RTC configuration, backup
BAT
DMA
Description
According to the specification, the PCROP_RDP option bit production value is “0”. In STM32G431 Rev Z devices,
with date code 947 and date codes less than 944, the PCROP_RDP option bit production value is “1”
Workaround
None
2.3
DMA
2.3.1 DMA disable failure and error flag omission upon simultaneous transfer error and global flag
clear
Description
Upon a data transfer error in a DMA channel x, both the specific TEIFx and the global GIFx flags are raised and
the channel x is normally automatically disabled. However, if in the same clock cycle the software clears the GIFx
flag (by setting the CGIFx bit of the DMA_IFCR register), the automatic channel disable fails and the TEIFx flag is
not raised.
This issue does not occur with ST's HAL software that does not use and clear the GIFx flag when the channel is
active.
Workaround
Do not clear GIFx flags when the channel is active. Instead, use HTIFx, TCIFx, and TEIFx specific event flags and
their corresponding clear bits.
2.4 DMAMUX
2.4.1 SOFx not asserted when writing into DMAMUX_CFR register
Description
The SOFx flag of the DMAMUX_CSR status register is not asserted if overrun from another DMAMUX channel
occurs when the software writes into the DMAMUX_CFR register.
ES0431 - Rev 7
page 7/28
STM32G431xx STM32G441xx
This can happen when multiple DMA channels operate in synchronization mode, and when overrun can occur
from more than one channel. As the SOFx flag clear requires a write into the DMAMUX_CFR register (to set
the corresponding CSOFx bit), overrun occurring from another DMAMUX channel operating during that write
operation fails to raise its corresponding SOFx flag.
Workaround
None. Avoid the use of synchronization mode for concurrent DMAMUX channels, if at least two of them potentially
generate synchronization overrun.
2.4.2 OFx not asserted for trigger event coinciding with last DMAMUX request
Description
In the DMAMUX request generator, a trigger event detected in a critical instant of the last-generated DMAMUX
request being served by the DMA controller does not assert the corresponding trigger overrun flag OFx. The
critical instant is the clock cycle at the very end of the trigger overrun condition.
Additionally, upon the following trigger event, one single DMA request is issued by the DMAMUX request
generator, regardless of the programmed number of DMA requests to generate.
The failure only occurs if the number of requests to generate is set to more than two (GNBREQ[4:0] > 00001).
Workaround
DMAMUX
Make the trigger period longer than the duration required for serving the programmed number of DMA requests,
so as to avoid the trigger overrun condition from occurring on the very last DMA data transfer.
2.4.3 OFx not asserted when writing into DMAMUX_RGCFR register
Description
The OFx flag of the DMAMUX_RGSR status register is not asserted if an overrun from another DMAMUX request
generator channel occurs when the software writes into the DMAMUX_RGCFR register. This can happen when
multiple DMA channels operate with the DMAMUX request generator, and when an overrun can occur from more
than one request generator channel. As the OFx flag clear requires a write into the DMAMUX_RGCFR register
(to set the corresponding COFx bit), an overrun occurring in another DMAMUX channel operating with another
request generator channel during that write operation fails to raise the corresponding OFx flag.
Workaround
None. Avoid the use of request generator mode for concurrent DMAMUX channels, if at least two channels are
potentially generating a request generator overrun.
2.4.4 Wrong input DMA request routed upon specific DMAMUX_CxCR register write coinciding with
synchronization event
Description
If a write access into the DMAMUX_CxCR register having the SE bit at zero and SPOL[1:0] bitfield at a value
other than 00:
• sets the SE bit (enables synchronization),
• modifies the values of the DMAREQ_ID[5:0] and SYNC_ID[4:0] bitfields, and
• does not modify the SPOL[1:0] bitfield,
and if a synchronization event occurs on the previously selected synchronization input exactly two AHB clock
cycles before this DMAMUX_CxCR write, then the input DMA request selected by the DMAREQ_ID[5:0] value
before that write is routed.
ES0431 - Rev 7
page 8/28
STM32G431xx STM32G441xx
Workaround
Ensure that the SPOL[1:0] bitfield is at 00 whenever the SE bit is 0. When enabling synchronization by setting
the SE bit, always set the SPOL[1:0] bitfield to a value other than 00 with the same write operation into the
DMAMUX_CxCR register.
2.5 ADC
2.5.1 New context conversion initiated without waiting for trigger when writing new context in
ADC_JSQR with JQDIS = 0 and JQM = 0
Description
Once an injected conversion sequence is complete, the queue is consumed and the context changes according to
the new ADC_JSQR parameters stored in the queue. This new context is applied for the next injected sequence
of conversions.
However, the programming of the new context in ADC_JSQR (change of injected trigger selection and/or trigger
polarity) may launch the execution of this context without waiting for the trigger if:
• the queue of context is enabled (JQDIS cleared to 0 in ADC_CFGR), and
• the queue is never empty (JQM cleared to 0 in ADC_CFGR), and
• the injected conversion sequence is complete and no conversion from previous context is ongoing
ADC
Workaround
Apply one of the following measures:
• Ignore the first conversion.
• Use a queue of context with JQM = 1.
• Use a queue of context with JQM = 0, only change the conversion sequence but never the trigger selection
and the polarity.
2.5.2 Two consecutive context conversions fail when writing new context in ADC_JSQR just after
previous context completion with JQDIS = 0 and JQM = 0
Description
When an injected conversion sequence is complete and the queue is consumed, writing a new context in
ADC_JSQR just after the completion of the previous context and with a length longer that the previous context,
may cause both contexts to fail. The two contexts are considered as one single context. As an example, if the first
context contains element 1 and the second context elements 2 and 3, the first context is consumed followed by
elements 2 and 3 and element 1 is not executed.
This issue may happen if:
• the queue of context is enabled (JQDIS cleared to 0 in ADC_CFGR), and
• the queue is never empty (JQM cleared to 0 in ADC_CFGR), and
• the length of the new context is longer than the previous one
Workaround
If possible, synchronize the writing of the new context with the reception of the new trigger.
ES0431 - Rev 7
page 9/28
STM32G431xx STM32G441xx
2.5.3 Unexpected regular conversion when two consecutive injected conversions are performed in
Dual interleaved mode
Description
In Dual ADC mode, an unexpected regular conversion may start at the end of the second injected conversion
without a regular trigger being received, if the second injected conversion starts exactly at the same time than the
end of the first injected conversion. This issue may happen in the following conditions:
• two consecutive injected conversions performed in Interleaved simultaneous mode (DUAL[4:0] of
ADC_CCR = 0b00011), or
• two consecutive injected conversions from master or slave ADC performed in Interleaved mode
(DUAL[4:0]of ADC_CCR = 0b00111)
Workaround
• In Interleaved simultaneous injected mode: make sure the time between two injected conversion triggers is
longer than the injected conversion time.
• In Interleaved only mode: perform injected conversions from one single ADC (master or slave), making sure
the time between two injected triggers is longer than the injected conversion time.
2.5.4 ADC_AWDy_OUT reset by non-guarded channels
ADC
Description
ADC_AWDy_OUT is set when a guarded conversion of a regular or injected channel is outside the programmed
thresholds. It is reset after the end of the next guarded conversion that is inside the programmed thresholds.
However, the ADC_AWDy_OUT signal is also reset at the end of conversion of non-guarded channels, both
regular and injected.
Workaround
When ADC_AWDy_OUT is enabled, it is recommended to use only the ADC channels that are guarded by a
watchdog.
If ADC_AWDy_OUT is used with ADC channels that are not guarded by a watchdog, take only ADC_AWDy_OUT
rising edge into account.
2.5.5 End of 10/8/6-bit ADC conversion disturbing other ADCs
Description
The end-of-conversion event of an ADC instance set to 10-, 8-, or 6-bit resolution disturbs the reference voltage,
causing a conversion error to any other ADC instances with conversion in progress.
Workaround
Either set the ADCs to 12-bit resolution, or, with concurrent operation of multiple ADCs, avoid the end of
conversion of one ADC to occur during the conversion phase of another ADC. For example, set them all to
the same resolution and the same sampling duration, and start their sampling phase at the same time.
2.5.6 ADC input channel switching disturbs ongoing conversions
Description
A switch of the ADC input multiplexer to a different input channel disturbs all ADC instances with conversion in
progress, thus negatively impacting their DNL. As the device operates the multiplexer during the ADC conversion,
either to select the following input of a scan sequence or to open all multiplexer inputs (idle mode), this
disturbance source may affect all operating modes except continuous and except bulb sampling.
The DNL impact depends on the input channel and it increases with increasing number of concurrently converting
ADCs, the worst case (a few LSBs) being when all the ADCs on the device operate synchronously.
ES0431 - Rev 7
page 10/28
STM32G431xx STM32G441xx
Workaround
When using a single ADC input channel, activate bulb sampling. This prevents the opening of all multiplexer
inputs during the conversion cycle.
In scan conversion mode, set the input scan sequence such that two successive conversions are performed on
each input. Keep the result of the first and discard the second, as only the second is affected by the input channel
switch disturbance.
2.5.7 Wrong ADC result if conversion done late after calibration or previous conversion
Description
The result of an ADC conversion done more than 1 ms later than the previous ADC conversion or ADC calibration
might be incorrect.
Workaround
Perform two consecutive ADC conversions in single, scan or continuous mode. Reject the result of the first
conversion and only keep the result of the second.
2.5.8 ADC channel 0 converted instead of the required ADC channel
ADC
Description
The following ADC conversions unduly convert the ADC internal channel 0 instead of the required channel, and
as a consequence, they return zero as conversion result:
1. an injected conversion triggered while regular conversion is on-going
2. the master ADC first injected conversion and the slave ADC first regular conversion (after resume) when
dual simultaneous or interleaved dual ADC is used
3. the first regular/injected conversion after a regular or injected software STOP (setting ADSTP or JADSTP bit
respectively)
4. the first regular or injected conversion following the DMA end of transfer, after the completion of a regular
sequence read by the DMA in one-shot mode
Workaround
Apply one of the following measures:
• Depending on the case, insert a dummy conversion:
– at the beginning of the injected sequence (not applicable in injected discontinuous mode,
JDISCEN = 1) in the case 1
– after the ADC slave resumes regular conversions in dual simultaneous or interleaved dual ADC mode
(not applicable in injected discontinuous mode, JDISCEN = 1) in the case 2
– after stopping the ADC by software in the case 3
– after DMA end-of-transfer in the case 4
• Avoid collisions between injected and regular conversions by using triggered regular conversions or by
launching regular conversion at the end of injected sequence in the cases 1 and 2.
• After a regular or injected software STOP, disable the ADC with ADDIS = 1 and enable it again with
ADEN = 1. This introduces a hardware dummy conversion (the cases 3 and 4).
ES0431 - Rev 7
page 11/28
2.6 COMP
2.6.1 Comparator previously not fully tested in production
Description
STM32G431xx STM32G441xx
COMP
The comparator is not fully tested. As a consequence, the V
parameter may be out of specification. The
offset
following specification substitutes the one in the datasheet for these parts:
Symbol Parameter Conditions Min Typ Max Unit
V
offset
Comparator offset error
Full V
voltage range, full
DDA
temperature range
-20 -15/+2 3 mV
Workaround
None.
2.7 OPAMP
2.7.1 OPAMP disturbed by fast-edge toggle on GPIO pin corresponding to VINM0
Description
In non-inverting PGA OPAMP mode, fast-edge toggle on the GPIO pin corresponding to VINM0 OPAMP input
disturbs the operational amplifier inverting input. The disturbance on the OPAMP output is then multiplied
depending on the gain set.
Note: The disturbance is not observed in the OPAMP external gain and follower modes.
Note: The VINM0 input corresponds to the GPIO pin PA3 for OPAMP1, PA5 for OPAMP2, and PB2 for OPAMP3.
Workaround
Apply one of the following measures:
• Prevent fast-edge toggle on VINM0, by using the corresponding GPIO as slow-edge analog signal input, as
a static output, or by grounding it.
• If the OPAMP output is sampled by an ADC, synchronize that sampling with the fast-edge VINM0 signal
such as to move the ADC sampling away from the VINM0 signal edges.
2.8 TIM
2.8.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration
Description
The failure occurs when several timers configured in one-pulse mode are cascaded, and the master timer is
configured in combined reset + trigger mode with the MSM bit set:
OPM = 1 in TIMx_CR1, SMS[3:0] = 1000 and MSM = 1 in TIMx_SMCR.
The MSM delays the reaction of the master timer to the trigger event, so as to have the slave timers cycleaccurately synchronized.
If the trigger arrives when the counter value is equal to the period value set in the TIMx_ARR register, the
one-pulse mode of the master timer does not work and no pulse is generated on the output.
ES0431 - Rev 7
page 12/28
STM32G431xx STM32G441xx
Workaround
None. However, unless a cycle-level synchronization is mandatory, it is advised to keep the MSM bit reset, in
which case the problem is not present. The MSM = 0 configuration also allows decreasing the timer latency to
external trigger events.
2.8.2 Consecutive compare event missed in specific conditions
Description
Every match of the counter (CNT) value with the compare register (CCR) value is expected to trigger a compare
event. However, if such matches occur in two consecutive counter clock cycles (as consequence of the CCR
value change between the two cycles), the second compare event is missed for the following CCR value
changes:
in edge-aligned mode, from ARR to 0:
•
– first compare event: CNT = CCR = ARR
– second (missed) compare event: CNT = CCR = 0
•
in center-aligned mode while up-counting, from ARR-1 to ARR (possibly a new ARR value if the period is
also changed) at the crest (that is, when TIMx_RCR = 0):
– first compare event: CNT = CCR = (ARR-1)
– second (missed) compare event: CNT = CCR = ARR
•
in center-aligned mode while down-counting, from 1 to 0 at the valley (that is, when TIMx_RCR = 0):
– first compare event: CNT = CCR = 1
– second (missed) compare event: CNT = CCR = 0
This typically corresponds to an abrupt change of compare value aiming at creating a timer clock single-cyclewide pulse in toggle mode.
As a consequence:
• In toggle mode, the output only toggles once per counter period (squared waveform), whereas it is expected
to toggle twice within two consecutive counter cycles (and so exhibit a short pulse per counter period).
• In center mode, the compare interrupt flag does note rise and the interrupt is not generated.
Note: The timer output operates as expected in modes other than the toggle mode.
TIM
Workaround
None.
2.8.3 Compare event missed in center-aligned mode 1 and 2 with dithering enabled
Description
With dithering enabled, the compare event is not generated and the output in toggle mode is incorrect in:
• center-aligned mode 1, with the CCR value between ARR-16 and ARR
• center-aligned mode 2, with the CCR value lower than 16
Note: These CCR values correspond to a waveform with extreme duty cycles: close to 0%, with the pulse width being
one timer clock cycle, or close to 100%, with the pulse width being the PWM period minus one timer clock cycle.
The timer output operates as expected if configured in other than toggle mode.
The center-aligned mode 3 is exempt of this failure.
Workaround
None.
ES0431 - Rev 7
page 13/28
STM32G431xx STM32G441xx
2.8.4 Output compare clear not working with external counter reset
Description
The output compare clear event (ocref_clr) is not correctly generated when the timer is configured in the following
slave modes: Reset mode, Combined reset + trigger mode, and Combined gated + reset mode.
The PWM output remains inactive during one extra PWM cycle if the following sequence occurs:
1. The output is cleared by the ocref_clr event.
2. The timer reset occurs before the programmed compare event.
Workaround
Apply one of the following measures:
• Use BKIN (or BKIN2 if available) input for clearing the output, selecting the Automatic output enable mode
(AOE = 1).
• Mask the timer reset during the PWM ON time to prevent it from occurring before the compare event (for
example with a spare timer compare channel open-drain output connected with the reset signal, pulling the
timer reset line down).
2.9 LPTIM
LPTIM
2.9.1 Device may remain stuck in LPTIM interrupt when entering Stop mode
Description
This limitation occurs when disabling the low-power timer (LPTIM).
When the user application clears the ENABLE bit in the LPTIM_CR register within a small time window around
one LPTIM interrupt occurrence, then the LPTIM interrupt signal used to wake up the device from Stop mode may
be frozen in active state. Consequently, when trying to enter Stop mode, this limitation prevents the device from
entering low-power mode and the firmware remains stuck in the LPTIM interrupt routine.
This limitation applies to all Stop modes and to all instances of the LPTIM. Note that the occurrence of this issue
is very low.
Workaround
In order to disable a low power timer (LPTIMx) peripheral, do not clear its ENABLE bit in its respective LPTIM_CR
register. Instead, reset the whole LPTIMx peripheral via the RCC controller by setting and resetting its respective
LPTIMxRST bit in RCC_APByRSTRz register.
2.9.2 Device may remain stuck in LPTIM interrupt when clearing event flag
Description
This limitation occurs when the LPTIM is configured in interrupt mode (at least one interrupt is enabled) and
the software clears any flag in LPTIM_ISR register by writing its corresponding bit in LPTIM_ICR register. If the
interrupt status flag corresponding to a disabled interrupt is cleared simultaneously with a new event detection,
the set and clear commands might reach the APB domain at the same time, leading to an asynchronous interrupt
signal permanently stuck high.
This issue can occur either during an interrupt subroutine execution (where the flag clearing is usually done), or
outside an interrupt subroutine.
Consequently, the firmware remains stuck in the LPTIM interrupt routine, and the device cannot enter Stop mode.
ES0431 - Rev 7
page 14/28
STM32G431xx STM32G441xx
RTC and TAMP
Workaround
To avoid this issue, it is strongly advised to follow the recommendations listed below:
• Clear the flag only when its corresponding interrupt is enabled in the interrupt enable register.
• If for specific reasons, it is required to clear some flags that have corresponding interrupt lines disabled in
the interrupt enable register, it is recommended to clear them during the current subroutine prior to those
which have corresponding interrupt line enabled in the interrupt enable register.
• Flags must not be cleared outside the interrupt subroutine.
Note: The proper clear sequence is already implemented in the HAL_LPTIM_IRQHandler in the STM32Cube.
2.9.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle
Description
The compare match event (CMPM), auto reload match event (ARRM), PWM output level and interrupts are
updated with a delay of one kernel clock cycle.
Consequently, it is not possible to generate PWM with a duty cycle of 0% or 100%.
The following waveform gives the example of PWM output mode and the effect of the delay:
LPTIM_ARR 0x0A
LPTIM_CMP 0x06
LPTIM_CNT
PWM output
0x05 0x06 0x07 0x08 0x09 0x0A 0x00 0x01 0x02
CMPM = 1
ARRM = 1
Workaround
Set the compare value to the desired value minus 1. For instance in order to generate a compare match when
LPTM_CNT = 0x08, set the compare value to 0x07.
2.10
RTC and TAMP
2.10.1 Calendar initialization may fail in case of consecutive INIT mode entry
Description
ES0431 - Rev 7
If the INIT bit of the RTC_ICSR register is set between one and two RTCCLK cycles after being cleared, the
INITF flag is set immediately instead of waiting for synchronization delay (which should be between one and two
RTCCLK cycles), and the initialization of registers may fail. Depending on the INIT bit clearing and setting instants
versus the RTCCLK edges, it can happen that, after being immediately set, the INITF flag is cleared during one
RTCCLK period then set again. As writes to calendar registers are ignored when INITF is low, a write occurring
during this critical period might result in the corruption of one or more calendar registers.
page 15/28
STM32G431xx STM32G441xx
RTC and TAMP
Workaround
After existing the initialization mode, clear the BYPSHAD bit (if set) then wait for RSF to rise, before entering the
initialization mode again.
Note: It is recommended to write all registers in a single initialization session to avoid accumulating synchronization
delays.
2.10.2 Alarm flag may be repeatedly set when the core is stopped in debug
Description
When the core is stopped in debug mode, the clock is supplied to subsecond RTC alarm downcounter even
though the device is configured to stop the RTC in debug.
As a consequence, when the subsecond counter is used for alarm condition (the MASKSS[3:0] bitfield of the
RTC_ALRMASSR and/or RTC_ALRMBSSR register set to a non-zero value) and the alarm condition is met just
before entering a breakpoint or printf, the ALRAF and/or ALRBF flag of the RTC_SR register is repeatedly set by
hardware during the breakpoint or printf, which makes any tentative to clear the flag(s) ineffective.
Workaround
None.
2.10.3 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles
after clearing TSF
Description
With the timestamp on tamper event enabled (TAMPTS bit of the RTC_CR register set), a tamper event is ignored
if it occurs:
• within four APB clock cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, while
the TSF flag is not yet effectively cleared (it fails to set the TSOVF flag)
• within two ck_apre cycles after setting the CTSF bit of the RTC_SCR register to clear the TSF flag, when the
TSF flag is effectively cleared (it fails to set the TSF flag and timestamp the calendar registers)
Workaround
None.
2.10.4 REFCKON write protection associated to INIT KEY instead of CAL KEY
Description
The write protection of the REFCKON bit is unlocked if the key sequence is written in RTC_WPR with the
privilege and security rights set by the INITPRIV and INITSEC bits, instead of being set by the CALPRIV and
CALSEC bits.
Workaround
Unlock the INIT KEY before writing REFCKON.
2.10.5 Tamper flag not set on LSE failure detection
Description
With the timestamp on tamper event enabled (the TAMPTS bit of the RTC_CR register set), the LSE failure
detection (LSE clock stopped) event connected to the internal tamper 3 fails to raise the ITAMP3F and ITAMP3MF
flags, although it duly erases or blocks (depending on the internal tamper 3 configuration) the backup registers
and other device secrets, and the RTC and TAMP peripherals resume normally upon the LSE restart.
ES0431 - Rev 7
page 16/28
STM32G431xx STM32G441xx
Note: As expected in this particular case, the TSF and TSMF flags remain low as long as LSE is stopped as they
require running RTCCLK clock to operate.
Workaround
None.
2.11 I2C
I2C
2.11.1 Wrong data sampling when data setup time (t
Description
The I2C-bus specification and user manual specify a minimum data setup time (t
• 250 ns in Standard mode
• 100 ns in Fast mode
• 50 ns in Fast mode Plus
The device does not correctly sample the I2C-bus SDA line when t
(I2C-bus peripheral clock) period: the previous SDA value is sampled instead of the current one. This can result in
a wrong receipt of slave address, data byte, or acknowledge bit.
Workaround
Increase the I2C kernel clock frequency to get I2C kernel clock period within the transmitter minimum data setup
time. Alternatively, increase transmitter’s minimum data setup time. If the transmitter setup time minimum value
corresponds to the minimum value provided in the I2C-bus standard, the minimum I2CCLK frequencies are as
follows:
• In Standard mode, if the transmitter minimum setup time is 250 ns, the I2CCLK frequency must be at least
4 MHz.
• In Fast mode, if the transmitter minimum setup time is 100 ns, the I2CCLK frequency must be at least
10 MHz.
• In Fast-mode Plus, if the transmitter minimum setup time is 50 ns, the I2CCLK frequency must be at least
20 MHz.
) is shorter than one I2C kernel clock period
SU;DAT
) as:
SU;DAT
is smaller than one I2C kernel clock
SU;DAT
2.11.2 Spurious bus error detection in master mode
Description
In master mode, a bus error can be detected spuriously, with the consequence of setting the BERR flag of the
I2C_SR register and generating bus error interrupt if such interrupt is enabled. Detection of bus error has no effect
on the I2C-bus transfer in master mode and any such transfer continues normally.
Workaround
If a bus error interrupt is generated in master mode, the BERR flag must be cleared by software. No other action
is required and the ongoing transfer can be handled normally.
ES0431 - Rev 7
page 17/28
2.11.3 Spurious master transfer upon own slave address match
Description
When the device is configured to operate at the same time as master and slave (in a multi- master I2C-bus
application), a spurious master transfer may occur under the following condition:
• Another master on the bus is in process of sending the slave address of the device (the bus is busy).
• The device initiates a master transfer by bit set before the slave address match event (the ADDR flag set in
the I2C_ISR register) occurs.
• After the ADDR flag is set:
– the device does not write I2C_CR2 before clearing the ADDR flag, or
– the device writes I2C_CR2 earlier than three I2C kernel clock cycles before clearing the ADDR flag
In these circumstances, even though the START bit is automatically cleared by the circuitry handling the ADDR
flag, the device spuriously proceeds to the master transfer as soon as the bus becomes free. The transfer
configuration depends on the content of the I2C_CR2 register when the master transfer starts. Moreover, if the
I2C_CR2 is written less than three kernel clocks before the ADDR flag is cleared, the I2C peripheral may fall into
an unpredictable state.
Workaround
Upon the address match event (ADDR flag set), apply the following sequence.
Normal mode (SBC = 0):
1. Set the ADDRCF bit.
2. Before Stop condition occurs on the bus, write I2C_CR2 with the START bit low.
Slave byte control mode (SBC = 1):
1. Write I2C_CR2 with the slave transfer configuration and the START bit low.
2. Wait for longer than three I2C kernel clock cycles.
3. Set the ADDRCF bit.
4. Before Stop condition occurs on the bus, write I2C_CR2 again with its current value.
The time for the software application to write the I2C_CR2 register before the Stop condition is limited, as the
clock stretching (if enabled), is aborted when clearing the ADDR flag.
Polling the BUSY flag before requesting the master transfer is not a reliable workaround as the bus may become
busy between the BUSY flag check and the write into the I2C_CR2 register with the START bit set.
STM32G431xx STM32G441xx
I2C
2.11.4 OVR flag not set in underrun condition
Description
In slave transmission with clock stretching disabled (NOSTRETCH = 1 in the I2C_CR1 register), an underrun
condition occurs if the current byte transmission is completed on the I2C bus, and the next data is not yet written
in the TXDATA[7:0] bitfield. In this condition, the device is expected to set the OVR flag of the I2C_ISR register
and send 0xFF on the bus.
However, if the I2C_TXDR is written within the interval between two I2C kernel clock cycles before and three APB
clock cycles after the start of the next data transmission, the OVR flag is not set, although the transmitted value is
0xFF.
Workaround
None.
ES0431 - Rev 7
page 18/28
2.11.5 Transmission stalled after first byte transfer
Description
When the first byte to transmit is not prepared in the TXDATA register, two bytes are required successively,
through TXIS status flag setting or through a DMA request. If the first of the two bytes is written in the I2C_TXDR
register in less than two I2C kernel clock cycles after the TXIS/DMA request, and the ratio between APB clock
and I2C kernel clock frequencies is between 1.5 and 3, the second byte written in the I2C_TXDR is not internally
detected. This causes a state in which the I2C peripheral is stalled in master mode or in slave mode, with clock
stretching enabled (NOSTRETCH = 0). This state can only be released by disabling the peripheral (PE = 0) or by
resetting it.
Workaround
Apply one of the following measures:
• Write the first data in I2C_TXDR before the transmission starts.
• Set the APB clock frequency so that its ratio with respect to the I2C kernel clock frequency is lower than 1.5
or higher than 3.
2.12 USART
STM32G431xx STM32G441xx
USART
2.12.1 Anticipated end-of-transmission signaling in SPI slave mode
Description
In SPI slave mode, at low USART baud rate with respect to the USART kernel and APB clock frequencies, the
transmission complete flag TC of the USARTx_ISR register may unduly be set before the last bit is shifted on the
transmit line.
This leads to data corruption if, based on this anticipated end-of-transmission signaling, the application disables
the peripheral before the last bit is transmitted.
Workaround
Upon the TC flag rise, wait until the clock line remains idle for more than the half of the communication clock
cycle. Then only consider the transmission as ended.
2.12.2 Data corruption due to noisy receive line
Description
In UART mode with oversampling by 8 or 16 and with 1 or 2 stop bits, the received data may be corrupted if a
glitch to zero shorter than the half-bit occurs on the receive line within the second half of the stop bit.
Workaround
None.
2.13
SPI
2.13.1 BSY bit may stay high when SPI is disabled
Description
The BSY flag may remain high upon disabling the SPI while operating in:
• master transmit mode and the TXE flag is low (data register full).
• master receive-only mode (simplex receive or half-duplex bidirectional receive phase) and an SCK strobing
edge has not occurred since the transition of the RXNE flag from low to high.
• slave mode and NSS signal is removed during the communication.
ES0431 - Rev 7
page 19/28
STM32G431xx STM32G441xx
Workaround
When the SPI operates in:
• master transmit mode, disable the SPI when TXE = 1 and BSY = 0.
• master receive-only mode, ignore the BSY flag.
• slave mode, do not remove the NSS signal during the communication.
2.13.2 BSY bit may stay high at the end of data transfer in slave mode
Description
BSY flag may sporadically remain high at the end of a data transfer in slave mode. This occurs upon coincidence
of internal CPU clock and external SCK clock provided by master.
In such an event, if the software only relies on BSY flag to detect the end of SPI slave data transaction (for
example to enter low-power mode or to change data line direction in half-duplex bidirectional mode), the detection
fails.
As a conclusion, the BSY flag is unreliable for detecting the end of data transactions.
Workaround
Depending on SPI operating mode, use the following means for detecting the end of transaction:
• When NSS hardware management is applied and NSS signal is provided by master, use NSS flag.
• In SPI receiving mode, use the corresponding RXNE event flag.
• In SPI transmit-only mode, use the BSY flag in conjunction with a timeout expiry event. Set the timeout such
as to exceed the expected duration of the last data frame and start it upon TXE event that occurs with the
second bit of the last data frame. The end of the transaction corresponds to either the BSY flag becoming
low or the timeout expiry, whichever happens first.
Prefer one of the first two measures to the third as they are simpler and less constraining.
Alternatively, apply the following sequence to ensure reliable operation of the BSY flag in SPI transmit mode:
1. Write last data to data register.
2. Poll the TXE flag until it becomes high, which occurs with the second bit of the data frame transfer.
3. Disable SPI by clearing the SPE bit mandatorily before the end of the frame transfer.
4. Poll the BSY bit until it becomes low, which signals the end of transfer.
Note: The alternative method can only be used with relatively fast CPU speeds versus relatively slow SPI clocks
or/and long last data frames. The faster is the software execution, the shorter can be the duration of the last data
frame.
FDCAN
2.14
FDCAN
2.14.1 Desynchronization under specific condition with edge filtering enabled
Description
FDCAN may desynchronize and incorrectly receive the first bit of the frame if:
• the edge filtering is enabled (the EFBI bit of the FDCAN_CCCR register is set), and
• the end of the integration phase coincides with a falling edge detected on the FDCAN_Rx input pin
If this occurs, the CRC detects that the first bit of the received frame is incorrect, flags the received frame as faulty
and responds with an error frame.
Note: This issue does not affect the reception of standard frames.
Workaround
Disable edge filtering or wait for frame retransmission.
ES0431 - Rev 7
page 20/28
STM32G431xx STM32G441xx
2.14.2 Tx FIFO messages inverted under specific buffer usage and priority setting
Description
Two consecutive messages from the Tx FIFO may be inverted in the transmit sequence if:
• FDCAN uses both a dedicated Tx buffer and a Tx FIFO (the TFQM bit of the FDCAN_TXBC register is
cleared), and
• the messages contained in the Tx buffer have a higher internal CAN priority than the messages in the Tx
FIFO.
Workaround
Apply one of the following measures:
• Ensure that only one Tx FIFO element is pending for transmission at any time:
The Tx FIFO elements may be filled at any time with messages to be transmitted, but their transmission
requests are handled separately. Each time a Tx FIFO transmission has completed and the Tx FIFO gets
empty (TFE bit of FDACN_IR set to 1) the next Tx FIFO element is requested.
• Use only a Tx FIFO:
Send both messages from a Tx FIFO, including the message with the higher priority. This message has to
wait until the preceding messages in the Tx FIFO have been sent.
• Use two dedicated Tx buffers (for example, use Tx buffer 4 and 5 instead of the Tx FIFO). The following
pseudo-code replaces the function in charge of filling the Tx FIFO:
USB
Write message to Tx Buffer 4
Transmit Loop:
Request Tx Buffer 4 - write AR4 bit in FDCAN_TXBAR
Write message to Tx Buffer 5
Wait until transmission of Tx Buffer 4 complete (IR bit in FDCAN_IR),
read TO4 bit in FDCAN_TXBTO
Request Tx Buffer 5 - write AR5 bit of FDCAN_TXBAR
Write message to Tx Buffer 4
Wait until transmission of Tx Buffer 5 complete (IR bit in FDCAN_IR),
read TO5 bit in FDCAN_TXBTO
2.15
USB
2.15.1 ESOF interrupt timing desynchronized after resume signaling
Description
Upon signaling resume, the device is expected to allow full 3 ms of time to the host or hub for sending the
initial SOF (start of frame) packet, without triggering SUSP interrupt. However, the device only allows two full
milliseconds and unduly triggers SUSP interrupt if it receives the initial packet within the third millisecond.
Workaround
When the device initiates resume (remote wakeup), mask the SUSP interrupt by setting the SUSPM bit for 3 ms,
then unmask it by clearing SUSPM.
2.15.2 Incorrect CRC16 in the memory buffer
Description
Memory buffer locations are written starting from the address contained in the ADDRn_RX for a number of bytes
corresponding to the received data packet length, CRC16 inclusive (that is, data payload length plus two bytes),
or up to the last allocated memory location defined by BL_SIZE and NUM_BLOCK, whichever comes first. In the
former case, the CRC16 checksum is written wrongly, with its least significant byte going to both memory buffer
byte locations expected to receive the least and the most significant bytes of the checksum.
ES0431 - Rev 7
page 21/28
STM32G431xx STM32G441xx
Although the checksum written in the memory buffer is wrong, the underlying CRC checking mechanism in the
USB peripheral is fully functional.
Workaround
Ignore the CRC16 data in the memory buffer.
USB
ES0431 - Rev 7
page 22/28
Revision history
STM32G431xx STM32G441xx
Table 4. Document revision history
Date Version Changes
19-Apr-2019 1 Initial release.
Added in Section 2 Description of device errata and in Table 3. Summary of
device limitations:
• erratum FLASH_ECCR corrupted upon reset or power-down occurring
during Flash memory program or erase operation
• erratum OVR flag not set in underrun condition
17-Dec-2019 2
22-Jun-2020 3
28-Jul-2020
31-Aug-2020 5
05-Nov-2020 6
4
• Transmission stalled after first byte transfer
• silicon revision Y
Removed:
‑
• erratum First double
power-down while programming
• erratum Data cache might be corrupted during Flash memory readwhile-write operation
Added in Section 2 Description of device errata and in Table 3. Summary of
device limitations:
• erratum ADC channel 0 converted instead of the required ADC channel
• erratum Consecutive compare event missed in specific conditions
• erratum Compare event missed in center-aligned mode 1 and 2 with
dithering enabled
• erratum Output compare clear not working with external counter reset
• erratum A tamper event fails to trigger timestamp or timestamp overflow
events during a few cycles after clearing TSF
• erratum REFCKON write protection associated to INIT KEY instead of
CAL KEY
• erratum Tamper flag not set on LSE failure detection
• erratum Anticipated end-of-transmission signaling in SPI slave mode
• erratum Data corruption due to noisy receive line
• erratum ESOF interrupt timing desynchronized after resume signaling
• erratum Incorrect CRC16 in the memory buffer
• erratum Desynchronization under specific condition with edge filtering
enabled
• erratum Tx FIFO messages inverted under specific buffer usage and
priority setting
Added in Section 2 Description of device errata and in Table 3. Summary of
device limitations:
• erratum Comparator previously not fully tested in production
• erratum VREF+ output voltage disturbed by some GPIOs toggling
Added in Section 2 Description of device errata and in Table 3. Summary of
device limitations: PCROP_RDP option bit production value not inline with the
specification
Removed : VREF+ output voltage disturbed by some GPIOs toggling
Updated:
• Document's scope and all tables in the document to add revision X
information.
• erratum DMA disable failure and error flag omission upon simultaneous
transfer error and global flag clear
word of Flash memory corrupted upon reset or
ES0431 - Rev 7
page 23/28
STM32G431xx STM32G441xx
Date Version Changes
Added:
• erratum New context conversion initiated without waiting for trigger
when writing new context in ADC_JSQR with JQDIS = 0 and JQM = 0
• erratum Two consecutive context conversions fail when writing new
context in ADC_JSQR just after previous context completion with
JQDIS = 0 and JQM = 0
• erratum Unexpected regular conversion when two consecutive injected
conversions are performed in Dual interleaved mode
• erratum ADC_AWDy_OUT reset by non-guarded channels
• erratum LPTIM events and PWM output are delayed by 1 kernel clock
cycle
16-Apr-2021 7
Added erratum OPAMP disturbed by fast-edge toggle on GPIO pin
corresponding to VINM0
ES0431 - Rev 7
page 24/28
STM32G431xx STM32G441xx
Contents
Contents
1 Summary of device errata..........................................................2
2 Description of device errata........................................................4
2.1 Core .........................................................................4
2.1.1 Interrupted loads to SP can cause erroneous behavior............................4
2.1.2 VDIV or VSQRT instructions might not complete correctly when very short ISRs are used. 4
2.1.3 Store immediate overlapping exception return operation might vector to incorrect interrupt 5
2.2 System .......................................................................6
2.2.1 Full JTAG configuration without NJTRST pin cannot be used .......................6
2.2.2 FLASH_ECCR corrupted upon reset or power-down occurring during Flash memory
program or erase operation.................................................6
2.2.3 Unstable LSI when it clocks RTC or CSS on LSE ................................6
2.2.4 PCROP_RDP option bit production value not inline with the specification..............7
2.3 DMA .........................................................................7
2.3.1 DMA disable failure and error flag omission upon simultaneous transfer error and global
flag clear ...............................................................7
2.4 DMAMUX .....................................................................7
2.4.1 SOFx not asserted when writing into DMAMUX_CFR register ......................7
2.4.2 OFx not asserted for trigger event coinciding with last DMAMUX request..............8
2.4.3 OFx not asserted when writing into DMAMUX_RGCFR register .....................8
2.4.4 Wrong input DMA request routed upon specific DMAMUX_CxCR register write coinciding
with synchronization event .................................................8
2.5 ADC .........................................................................9
2.5.1 New context conversion initiated without waiting for trigger when writing new context in
ADC_JSQR with JQDIS = 0 and JQM = 0......................................9
2.5.2 Two consecutive context conversions fail when writing new context in ADC_JSQR just after
previous context completion with JQDIS = 0 and JQM = 0 .........................9
2.5.3 Unexpected regular conversion when two consecutive injected conversions are performed
in Dual interleaved mode .................................................10
ES0431 - Rev 7
2.5.4 ADC_AWDy_OUT reset by non-guarded channels ..............................10
2.5.5 End of 10/8/6-bit ADC conversion disturbing other ADCs .........................10
2.5.6 ADC input channel switching disturbs ongoing conversions .......................10
2.5.7 Wrong ADC result if conversion done late after calibration or previous conversion ......11
2.5.8 ADC channel 0 converted instead of the required ADC channel ....................11
page 25/28
STM32G431xx STM32G441xx
Contents
2.6 COMP.......................................................................12
2.6.1 Comparator previously not fully tested in production .............................12
2.7 OPAMP......................................................................12
2.7.1 OPAMP disturbed by fast-edge toggle on GPIO pin corresponding to VINM0 ..........12
2.8 TIM .........................................................................12
2.8.1 One-pulse mode trigger not detected in master-slave reset + trigger configuration ......12
2.8.2 Consecutive compare event missed in specific conditions ........................13
2.8.3 Compare event missed in center-aligned mode 1 and 2 with dithering enabled ........13
2.8.4 Output compare clear not working with external counter reset .....................14
2.9 LPTIM.......................................................................14
2.9.1 Device may remain stuck in LPTIM interrupt when entering Stop mode ..............14
2.9.2 Device may remain stuck in LPTIM interrupt when clearing event flag ...............14
2.9.3 LPTIM events and PWM output are delayed by 1 kernel clock cycle.................15
2.10 RTC and TAMP ...............................................................15
2.10.1 Calendar initialization may fail in case of consecutive INIT mode entry...............15
2.10.2 Alarm flag may be repeatedly set when the core is stopped in debug ................16
2.10.3 A tamper event fails to trigger timestamp or timestamp overflow events during a few cycles
after clearing TSF .......................................................16
2.10.4 REFCKON write protection associated to INIT KEY instead of CAL KEY .............16
2.10.5 Tamper flag not set on LSE failure detection ...................................16
2.11 I2C .........................................................................17
2.11.1 Wrong data sampling when data setup time (t
period ................................................................17
2.11.2 Spurious bus error detection in master mode ..................................17
2.11.3 Spurious master transfer upon own slave address match .........................18
2.11.4 OVR flag not set in underrun condition .......................................18
2.11.5 Transmission stalled after first byte transfer ...................................19
) is shorter than one I2C kernel clock
SU;DAT
2.12 USART ......................................................................19
2.12.1 Anticipated end-of-transmission signaling in SPI slave mode ......................19
2.12.2 Data corruption due to noisy receive line......................................19
2.13 SPI .........................................................................19
2.13.1 BSY bit may stay high when SPI is disabled ...................................19
2.13.2 BSY bit may stay high at the end of data transfer in slave mode....................20
ES0431 - Rev 7
page 26/28
STM32G431xx STM32G441xx
Contents
2.14 FDCAN ......................................................................20
2.14.1 Desynchronization under specific condition with edge filtering enabled...............20
2.14.2 Tx FIFO messages inverted under specific buffer usage and priority setting...........21
2.15 USB.........................................................................21
2.15.1 ESOF interrupt timing desynchronized after resume signaling .....................21
2.15.2 Incorrect CRC16 in the memory buffer .......................................21
Revision history .......................................................................23
ES0431 - Rev 7
page 27/28
STM32G431xx STM32G441xx
IMPORTANT NOTICE – PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and improvements to ST
products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST
products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of
Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service
names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2021 STMicroelectronics – All rights reserved
ES0431 - Rev 7
page 28/28
Loading...
