User manual
SPC58XXADPT64S rev. B evaluation board
Introduction
The SPC58XXADPT64S rev. B evaluation board supports STMicroelectronics SPC582BxxE1, SPC584BxxE1 and
SPC58xCxxE1 microcontrollers in eTQFP64 package.
Figure 1. SPC58XXADPT64S rev. B
UM2790
UM2790 - Rev 1 - February 2021
For further information contact your local STMicroelectronics sales office.
www.st.com
1 Overview
The SPC58XXADPT64S rev. B "mini module" is an evaluation board supporting STMicroelectronics
SPC582BxxE1, SPC584BxxE1 and SPC58xCxxE1 microcontrollers in eTQFP64 package with exposed pad
down.
The SPC58XXADPT64S rev. B "mini module" is designed to be connected onto the SPC58xxMB motherboard,
offering a mechanism for easy customer evaluation of the SPC582BxxE1, SPC584BxxE1 and SPC58xCxxE1
microcontrollers and to facilitate hardware and software development.
High density connectors provide the interface between the EVB and MCU daughter cards and help the
developers evaluate all device peripherals.
This user manual provides information on using SPC58XXADPT64S rev. B "mini module" board and its hardware
features.
The "mini module" may be used as a stand-alone unit granting access to the CPU, but no access to the I/O pins
as any motherboard peripherals.
The SPC58XXADPT64S rev. B "mini module" is designed to be easily configurable and to be used for
SPC582BxxE1, SPC584BxxE1 and SPC58xCxxE1.
The "mini module" is configured by default for SPC582BxxE1 and easily supports SPC584BxxE1 and
SPC58xCxxE1 by simply changing the following through-hole jumper JR19.
UM2790
Overview
Figure 2. Overview of SPC58XXADPT64S rev. B "mini module" - top
UM2790 - Rev 1
page 2/24
Figure 3. Overview of SPC58XXADPT64S rev. B "mini module" - bottom
UM2790
Package contents
1.1 Package contents
An SPC58XXADPT64S rev. B adapter package includes the following item:
• SPC58XXADPT64S rev. B "mini module"
1.2 Supported devices
The SPC58XXADPT64S rev. B "mini module" supports the following STMicroelectronics family of microcontrollers
in eTQFP64 package:
• SPC582BxxE1
• SPC584BxxE1
• SPC58xCxxE1
UM2790 - Rev 1
page 3/24
UM2790
License agreement
2 License agreement
The packaging of this evaluation board was sealed with a seal stating, " by breaking this seal, you agree to the
terms and conditions of the evaluation board license agreement, the terms and conditions of which are available
at https://www.st.com/resource/en/evaluation_board_terms_of_use/evaluationproductlicenseagreement.pdf ".
Upon breaking the seal, you and STMicroelectronics entered into the evaluation board license agreement, a
copy of which is also enclosed with the evaluation board for convenience.
Attention: This evaluation board only offers limited features for evaluating ST products. It has not been tested for use
with other products and is not suitable for any safety or other commercial or consumer application. This
evaluation board is otherwise provided “AS IS” and STMicroelectronics disclaims all warranties, express or
implied, including the implied warranties of merchantability and fitness for a particular purpose.
UM2790 - Rev 1
page 4/24
3 Handling precautions
Please take care to handle the package contents in a manner such as to prevent electrostatic discharge.
Before the EVB is used or power is applied, please fully read the following sections on how to correctly configure
the board. Failure to correctly configure the board may cause irreparable component, MCU or EVB damage.
UM2790
Handling precautions
UM2790 - Rev 1
page 5/24
4 Hardware description
4.1 Hardware features
The SPC58XXADPT64S rev. B "mini module" board has the following features:
• Connector for external power supplies input (5.0 V, 3.3 V, 1.25 V) used in stand-alone mode
• Reset button with driver and led indicator
• Socket for device in eTQFP64 package
• Debug ports:
– 14-pin header connector for JTAG port
– 10-pin header connector for SIPI interface
• 40 Mhz crystal main oscillator with jumpers to optionally disconnect it
• 8 Mhz oscillator with jumpers to optionally disconnect it
• Clock input through SMA connector to optionally disconnect it
• 2 X SAMTEC QSH series, 240 way connector to connect "mini module" to motherboard
UM2790
Hardware description
4.2 Hardware dimension and PCB component view
The "mini module" has the following dimensions:
• PCB area: 127 mm x 114.3 mm
• Top components height: 16 mm max
• Bottom components height: 3.5 mm max
• PCB thickness: 1.6 mm
UM2790 - Rev 1
page 6/24
5 Power and system configuration
5.1 Power supplies
When the "mini module" is plugged onto the motherboard, power is supplied directly by the motherboard. In this
setup, the external power supply input available on the "mini module" should NOT be used.
When the SPC58XXADPT64S rev.B "mini module" is used as a stand-alone board, external power supplies must
be used (5.0 V, 3.3 V, 1.25 V).
The following jumpers are used to configure the power supply:
Table 1. Supply related jumpers
Jumper Description Default Position
Jumper to enable the use of supply
J3
3.3V_SR
Jumper to enable the use of supply
J4
5.0V_SR
Jumper to enable the use of supply
J5
1.25V_SR
VDD_HV_ADR_S voltage configuration,
J6
select from 5.0V_LR (linear), 3.3V_SR
(switching) or 5.0V_SR (switching)
VDD_HV_ADV_S voltage configuration,
J7
select from 5.0V_LR (linear), 3.3V_SR
(switching) or 5.0V_SR (switching)
VDD_HV_IO_MAIN voltage configuration,
J8
select from 5.0V_SR or 3.3V_SR
VDD_HV_IO_FLEX voltage configuration,
J9
select from 5.0V_SR or 3.3V_SR (for
Chorus 4M with JR19 closed 2-3)
VDD_LV voltage configuration, select from
J16
1.25V_SR or from Ballast Circuit
Ballast supply voltage configuration, select
J18
from VDD_HV_IO_MAIN or from 5.0V_SR
VDD_HV_FLA voltage configuration,
JP1
connect or disconnect VDD_HV_FLA from
VDD_HV_IO_MAIN
1-2 (5.0V_LR)
1-2 (5.0V_LR)
1-2 (5.0V_SR)
1-2 (5.0V_SR)
1-2 (1.25V_SR)
1-2 (5.0V_SR)
Closed
Closed
Closed
Closed
UM2790
Power and system configuration
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - A3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D2
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D2
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - D3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - B3
Figure 4. SPC58XXADPT64S rev. B "mini module" -
top - A3
Figure 5. SPC58XXADPT64S rev. B "mini module" -
bottom - C3
UM2790 - Rev 1
page 7/24
5.2 Microcontrollers configuration
The SPC58XXADPT64S rev. B "mini module" is designed to be easily configurable and be used for
SPC582BxxE1, SPC584BxxE1 and SPC58xCxxE1.
The "mini module" is configured by default for SPC582BxxE1 and easily supports SPC584BxxE1 and
SPC58xCxxE1 by simply changing the following through-hole jumper JR19.
Table 2. Microcontroller configuration related jumpers
Jumper Description Default Position
Device pin 62 port configuration / function
configuration:
JR19
• 1-2 - PC12 for SPC582BxxE1
• 2-3 - VDD_HV_IO_FLEX for
SPC584BxxE1 and SPC58xCxxE1
5.3 Port configuration
The following jumpers need to configure the ports:
Closed 1-2
PC12 for
SPC582BxxE1
UM2790
Microcontrollers configuration
Figure 4. SPC58XXADPT64S rev. B "mini
module" - top - B3
Jumper Description Default Position
JP13 TESTMODE settings
Device pin 6 port configuration / function
JR14
configuration:
• 1-2 (PC1)
• 2-3 (ESR0)
Device pin 56 port configuration /
function configuration:
J29
• 1-2 (PH4) SPC582BxxE1
• 2-3 (BCTRL) SPC584BxxE1,
SPC58xCxxE
5.4 Debug interface configuration
The following jumpers need to configure the ports:
Table 4. Debug interface configuration related jumpers
Jumper Description Default Position
RSTIN connection
J13
• open (disconnect PORST)
• closed (connect PORST)
JTAG/LFAST LVDS pin 9 configuration
JP2
• open (disconnect ESR0)
• closed (connect ESR0)
Table 3. Ports related jumpers
Close (10 KΩ pull-
down)
Open
1-2 (PH4)
SPC582BxxE1
Closed (connect
PORST)
Open (disconnect
ESR0)
Figure 4. SPC58XXADPT64S rev. B "mini module" -
Figure 4. SPC58XXADPT64S rev. B "mini module" -
Figure 4. SPC58XXADPT64S rev. B "mini
module" - top - A2
Figure 4. SPC58XXADPT64S rev. B "mini
module" - top - C3
Figure 4. SPC58XXADPT64S rev. B "mini
module" - top - A3
top - B2
top - A3
UM2790 - Rev 1
page 8/24
5.5 System clock configuration
The "mini module" supports the usage of the crystal clock sources as well as the external clock source:
Table 5. Clock configuration jumpers
Jumper Description Default Position
40 MHz crystal clock source enable
J15
for pin EXTAL
40 MHz crystal clock source enable
J17
for pin XTAL
Enable 8 MHz oscillator power
J19
supply
External clock source from 8 MHz
J21
oscillator or SMA connector
1-2 (XT1 pin2)
1-2 (XT1 pin1)
Open
1-2
(8 MHz oscillator)
UM2790
System clock configuration
Figure 4. SPC58XXADPT64S rev. B "mini module" - top -
B2
Figure 4. SPC58XXADPT64S rev. B "mini module" - top -
B2
Figure 4. SPC58XXADPT64S rev. B "mini module" - top -
B1
Figure 4. SPC58XXADPT64S rev. B "mini module" - top -
D1
UM2790 - Rev 1
page 9/24
5.6 Reset circuit
The "mini module" supports different ways to reset the microcontroller.
To use and perform the reset driving there are different jumpers and switches:
Jumper Description Default Position
SW1 Reset push button Open Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D1
Connect the external reset to the reset
J22
driver for
ESR0 and PORST pins
J20 Connect the external reset to ESR0 pin Close Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D1
J25 Connect the external reset to PORST pin Close Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D2
5.7 Test points
The "mini module" has several test points. Below all test points description:
UM2790
Reset circuit
Table 6. Reset configuration jumpers
Close Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D1
Table 7. Test points
Test point Description Position
GT1 GND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A2
GT2 GND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - C4
GT3 GND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - C2
GT4 GND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A1
GT5 GND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D1
GT6 AGND test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - B2
GT7 VSS_OSC test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - B3
TP1 TCK test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A2
TP2 TMS/Txp test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A3
TP3 TDI/Txn test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A3
TP4 TDO/Rxp test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A3
TP5 JCOMP/Rxn test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A3
TP6 J23A, QSH connector, pin10 (PA5) test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A4
TP7 J23A, QSH connector, pin11 (PA6) test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A4
TP8 J23A, QSH connector, pin12 (PA7) test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - B4
TP9 J23A, QSH connector, pin13 (PA8) test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - B4
TP10 J23A, QSH connector, pin14 (PA9) test point Figure 4. SPC58XXADPT64S rev. B "mini module" - top - B4
5.8 Connectors
The "mini module" has the following connectors:
Connectors Description Position
J14 14-pin header connector for JTAG interface Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A3
UM2790 - Rev 1
Table 8. Connectors
page 10/24
Connectors Description Position
CN1
J12
J23, J24
J2
J26 SMA connector for external clock input ) Figure 4. SPC58XXADPT64S rev. B "mini module" - top - C2
10-pin header connector for JTAG/LFAST
LVDS interface
Fault collection and control unit (FCCU) pin,
for failure notification
2 X Samtec QSH series, 240 way connector
to connect "mini module" to motherboard
External power supplies input (5 V, 3.3 V,
1.25 V)
Figure 4. SPC58XXADPT64S rev. B "mini module" - top - A2
Figure 4. SPC58XXADPT64S rev. B "mini module" - top - C2
Figure 5. SPC58XXADPT64S rev. B "mini module" - bottom -
A1/A4
Figure 4. SPC58XXADPT64S rev. B "mini module" - top - D4
UM2790
Connectors
UM2790 - Rev 1
page 11/24
6 Layout overview
1
2
3
4
A
B
C
D
UM2790
Layout overview
Figure 4. SPC58XXADPT64S rev. B "mini module" - top
UM2790 - Rev 1
page 12/24
Figure 5. SPC58XXADPT64S rev. B "mini module" - bottom
1
2
3
4
A
B
C
D
UM2790
Layout overview
UM2790 - Rev 1
page 13/24
7 BOM
Item QTY Reference Manufacturer Code Value Part description
1 7
2 9
3 13
4 7
5 4
6 4
7 1 C51 47 pF DNP
8 1 C52 CCERSMD270-0603 27 pF Mult. cer. cap. 50V SMD 0603
9 2 C53, C55 10 pF DNP
10 2 C54, C57 DNM
11 1 C56 CCERSMD104-0603M 100 nF Mult. cer. cap. 50V SMD 0603
12 1 C58 CCERSMD270-0603M 27 pF Mult. cer. cap. 50V SMD 0603
13 1 CN1 SAM-TFM10502LDWT
14 1 DUT1 ZOCC64ETQFP
15 7
16 1 J2 AST-0250404 AST0250404
17 5
18 2 J6, J7 STRIP3PM + STRIP1PM
19 10
20 1 J12 STRIP2PM STRIP2PM Male strip 2 poles
21 1 J14 M.14.180 LP-3M N2514-6002RB
22 1 J19 STRIP2PM STRIP2PM Male strip 2 poles see mech part - open !
C4, C10, C28,
C31, C47, C48,
C59
C5, C8, C11, C13,
C15, C17, C19,
C29, C32
C6, C9, C22, C23,
C24, C25, C26,
C30, C33, C42,
C43, C44, C45
C7, C34, C36,
C38, C40, C49,
C50
C12, C14, C16,
C18
C35, C37, C39,
C41
GT1, GT2, GT3,
GT4, GT5, GT6,
GT7
J3, J4, J5, J13,
JP13
J8, J9, J15, J16,
J17, J18, J21, J29,
JR14, JR19
UM2790
Table 9. BOM
2.2 uF
CCERSMD104-0603M 100 nF Mult. cer. cap. 50V 0603
CCERSMD103-0603M 10 nF Mult. cer. cap. 50V 0603
CCERSMD225-0805M 2.2 uF
CCERSMD475-0805M 4.7 uF Mult. cer. cap. 16V 0805
CCERSMD473-0603M 47 nF Mult. cer. cap. 50V 0603
Samtec TFM-105-02-
L-D-WT
TEST2 TEST2 PCB test point - raised loops
STRIP2PM STRIP2PM
STRIP3PM +
STRIP1PM
STRIP3PM STRIP3PM
Mult. cer. cap. 16V 0805 - automotive
series - not mounted!
Mult. cer. cap. 16V 0805 - automotive
series
Mult. cer. cap. 50V SMD 0603 - not
mounted!
Mult. cer. cap. 50V SMD 0603 - not
mounted!
Mult. cer. cap. 50V SMD 0603 - not
mounted!
Samtec 5x2 TFM connector - 1.27 mm
pitch - with weld Tabs
CHORUS - device under test - TQFP64-
EP - SENSATA(WELLS) - 3010-064-
X-0G-ST
Conn 4 pin, 90°, AST board mount
screwless
Male strip 2 poles see mech part -
normally closed !!
Male strip 4 poles see mech part (close
pin 1 and 2)
Male strip 3 poles see mech part (close
pin 1 and 2)
3M conn flat male 14 pins, straight - pitch
2.54 mm
BOM
UM2790 - Rev 1
page 14/24
UM2790
Item QTY Reference Manufacturer Code Value Part description
23 3 J20, J22, J25 STRIP2PM STRIP2PM Male strip 2 poles see mech part - close !
24 2 J23, J24 SAM-QSH12001LDA
25 1 J26 BNC-SMA-FEM-180 BNC-SMA-FEM-180 Conn. RF SMA 180°
26 1 JP1
27 1 JP2 STRIP2PM STRIP2PM
28 1 LD1 LEDSMDGIAL-0805 Yellow Led Diode Yellow SMD 0805
29 1 LD2 LEDSMDRED-0805 Red Led diode red SMD 0805
30 1 OSC1 Q8MHZ-SMD-3953M 8 MHz Hybrid quartz osc SMD ECS 3953M
31 1 Q2 TRNJD2873-SMD NJD2873 NPN plastic Power transistor DPAK
32 1 R2 RESMD000-805-5 0R Resistor 1/10W 5% 0805
33 6
34 2 R6, R9 RESMD472-0603 4K7 Resistor 1/10W 1% 0603
35 2 R7, R11 10K DNP
36 1 R8 RESMD103-0603 10K Resistor 1/10W 1% 0603
37 1 R10 RESMD0R1-1206 0R1 Resistor 1/2W 1% 1206
38 2 R12, R18 RESMD103-0603 10K Resistor 1/10W 1% SMD 0603
39 1 R13 RESMD000-0603 0R Resistor 1/10W 1% SMD 0603
40 2 R16, R17 RESMD561-0603 560R Resistor 1/10W 1% SMD 0603
41 2 R19, R21 RESMD221-0603 220R Resistor 1/10W 1% SMD 0603
42 1 R20 RESMD472-0603 4K7 Resistor 1/10W 1% SMD 0603
43 1 R22 RESMD49R9-0603 49R9 Resistor 1/16W 1% 0603
44 1 R24 100R Resistor 1/10W 1% 0603 - not mounted!
45 2 R25, R26 DNM
46 1 SW1 PULSANTECS Pushbutton Pushbutton NO low profile for pcb
47 10
48 1 U1 74LVC125AMTR-SMD 74LVC125AMTR I.C. quad bus buffers SO14
49 1 U2 74V1G08-SMD 74V1G08STR
50 1 XT1 Q40MHZ-SMD-5032 40 MHz
R3, R5, R27, R28,
R29, R30
TP1, TP2, TP3,
TP4, TP5, TP6,
TP7, TP8, TP9,
TP10
RESMD000-0603 0R Resistor 1/10W 1% 0603
Samtec QSH-120-01-
L-D-A
TESTPOINT Test point SMD - not mounted!
Samtec 0.5 mm pitch high speed SMD
socket
Jumper SMD - close! - with a solder
drop !
Male strip 2 poles see mech part -
normally open !
Resistor 1/10W 1% SMD 0603 - not
mounted!
Resistor 1/16W 1% SMD 0603 - not
mounted!
I.C. single 2-input and gate - SMD
SOT23-5L
Quartz 40 MHz SMD NX5032GA XTAL
NDK
BOM
UM2790 - Rev 1
page 15/24
J3
default CLOSED
J4
default CLOSED
J5
default CLOSED
0603
100nF
50V
X7R
C5
VDD_HV_ADR_S
0603
10nF
50V
X7R
C6
AGND AGND
0603
100nF
50V
X7R
C8
VDD_HV_ADV_S
0603
10nF
50V
X7R
C9
AGND AGND
1-2 CLOSED
DEFAULT
2
1
3
J8
0603
100nF
50V
X7R
C29
0603
10nF
50V
X7R
C30
GND GND
0805
2.2uF
16V
X7R
C28
GND
N.M.
default CLOSE
JP1
0805
2.2uF
16V
X7R
C36
0603
47nF
50V
X7R
C37
0603
10nF
50V
X7R
C43
GND GND GND
0805
2.2uF
16V
X7R
C38
0603
47nF
50V
X7R
C39
0603
10nF
50V
X7R
C44
Pin 33
GND GND GND
0805
2.2uF
16V
X7R
C40
0603
47nF
50V
X7R
C41
0603
10nF
50V
X7R
C45
GND GND GND
Pin 27
0805
2.2uF
16V
X7R
C34
0603
47nF
50V
X7R
C35
0603
10nF
50V
X7R
C42
Pin 11
GND GND GND
Pin 47
VDD_LV
1-2 CLOSED
DEFAULT
2
1 3
J9
0603
100nF
50V
X7R
C32
0603
10nF
50V
X7R
C33
GND GND
VDD_HV_IO_F LEX
VDD_LV
AGND
N.M.
0805
2.2uF
16V
X7R
C4
0805
2.2uF
16V
X7R
C7
AGND
5.0V_SR3.3V_SR 1.25V_SR5.0V_LR
1-2 CLOSED
DEFAULT
1-2 CLOSED
DEFAULT
5.0V_SR
5.0V_SR
2
1
3
4
J7
2
1
3
4
J6
0805
2.2uF
16V
X7R
C31
GND
N.M.
Pin 57
0805
4.7uF
16V
X7R
C12
GND
0603
100nF
50V
X7R
C13
0603
10nF
50V
X7R
C23
GND GND
Pin 12
0805
4.7uF
16V
X7R
C14
GND
0603
100nF
50V
X7R
C15
0603
10nF
50V
X7R
C24
GND GND
Pin 28
0805
4.7uF
16V
X7R
C16
GND
0603
100nF
50V
X7R
C17
0603
10nF
50V
X7R
C25
GND GND
Pin 34
0603
100nF
50V
X7R
C11
0603
10nF
50V
X7R
C22
VSS_OSC VSS_OSCVSS_OSC
N.M.
0805
2.2uF
16V
X7R
C10
Pin 38
0805
4.7uF
16V
X7R
C18
GND
0603
100nF
50V
X7R
C19
0603
10nF
50V
X7R
C26
GND GND
Pin 49
VDD_HV_IO_MA IN
VDD_HV_IO_MAIN
0R
1/10W
0805
R2
5.0V_SR3.3V_SR1.25V_SR
GND
GND
GT1
TEST2
GT2
TEST2
GT3
TEST2
GT4
TEST2
GT5
TEST2
RING -HE ADED FOR PROBE HOOK
AGND
GT6
TEST2
0R
1/10W
0603
R5
VSS_OSC GND
0R
1/10W
0603
R3
AGND GND
VSS_OSC
GT7
TEST2
AGND
VSS_OSC
GND
VDD_HV_IO_FLEX
1-2 CLOSED
DEFAULT
2
13
J16
NJD2873
Q2
Thermal plane
0805
2.2uF
16V
X7R
C49
0805
2.2uF
16V
X7R
C50
0805
2.2uF
16V
X7R
C59
N.M.
0805
2.2uF
16V
X7R
C47
N.M.
0805
2.2uF
16V
X7R
C48
N.M.
GND
GND
for power 2W/3W
1-2 CLOSED
GNDGND
0R1
1/2W
1206
R10
2
1
3
J18
VDD_HV_IO_M AIN
5.0V_SR
DEFAULT
BCTRL
BCTRL
1
2
3
4
AST 0250404
J2
VDD_HV_ADV_S
22
VDD_HV_JT AG_OSC
38
VDD_HV_IO_W0
12
VDD_HV_IO0_S0
28
VDD_HV_IO0_E0
34
VDD_HV_ADR_S
20
ADC
OSC & JTAG (3.3V or 5V)
I/O (3.3v - 5V)
VSS_HV_ADR_S
19
VSS_HV_ADV_S
21
VSS_HV_OSC
35
MCU CORE LOGIC (1.25V)
Power Pins
VDD_HV_FLA
57
VDD_LV_W3
11
EPAD
65
VDD_LV_S0
27
VDD_L V_E5
33
VDD_LV_E3
47
FLASH DECOUPLING
Power Bar
DUT1A
VDD_HV_IO0_N0
49
SPC58xCxxE1 /
SPC584BxxE1 /
SPC582BxxE1
UM2790 - Rev 1
8 Schematics
Figure 6. Power and decoupling
page 16/24
Schematics
UM2790
4K 7
1/10W
060 3
R9
VDD_HV_IO_M AIN
ESR0
E SR0 PC1
PI[0..15 ]
PI[0..15 ]
PI1
PI2
PI3
PI4
PI6
PI7
PH[0..15 ]
PH[0..15 ]
PG[0..15 ]
PG[0..15 ]
PG10
PG11
PG12
PF[0..15 ]
PF[0..15 ]
PF2
PF3
PE[0..15 ]
PE[0..15 ]
PE 2
PE 3
PE10
PE11
EXTA L
XTA L
PORS T
JP13
default CL OSE D
10K DNP
1/10W
0603
R7
10K
1/10W
0603
R8
GND
VDD_HV_IO_M AIN
NOT MOUNTED
PD[0..15]
PD[0..15]
PD0
PD5
PD11
PD12
PD13
PD14
PD15
PC[0..15]
PC[0..15 ]
PC1
PC2
PC3
PC4
STRIP 2P M
J12
FCCU_F1 LABEL ON PCB
FCCU_F0 LABEL ON PCB
JCOMP/Rxn
TDO/Rxp
TDIT/ xn
TMS T/xp
TCK
TP5TP4TP3TP2TP1
RST IN
PORST
PC13
PC14
PC15
4K7
1/10W
0603
R6
VDD_HV_IO_M AIN
PB[0..15]
PB[0..15 ]
PB 8
PB 9
PB10
PB 1 1
2
13
JR14
1-2 CLOSE D
DEFAUL T
PA[1 ]
51
PA[2 ]
50
TCK / PA[6]
43
TMS / PA[7 ]
40
TDI / PA[8 ]
39
TDO / PA[9]
41
PA[10 ]
52
PA[11 ]
53
PB[8 ]
32
PB[9 ]
31
PB[10 ]
30
PB[11] / FCCU_F0
29
PD[0 ]
58
PD[5 ]
48
PD[11 ]
26
PD[12 ]
8
PD[13 ]
9
PF[2 ]
64
PF[3 ]
63
PG[10]
23
PG[11]
24
PG[12]
25
PE[2 ]
7
PE[3 ]
10
PE[10 ]
54
PE[11 ]
55
PORS T
45
TEST MODE
44
XTA L
37
EXTA L
36
SPC58xCxxE1 / SPC584BxxE1 / SPC582BxxE1 Port Pins
PC[13 ]
61
PC[14 ]
60
PC[15 ]
59
PC[2] / FCCU_F1
5
PC[3]
4
PC[4]
3
PD[14 ]
1
PD[15 ]
2
PH[4 ]
56
PC[1 ]
6
JCOMP / PA[5 ]
42
PI[7 ]
18
PI[6 ]
17
PI[4 ]
16
PI[3 ]
15
PI[2 ]
14
PI[1 ]
13
PC[12]/VDD_HV_IO_FLEX
62
PM[14 ]
46
DUT1B
PA[0..15]
PA[0..15 ]
PA1
PA2
PA10
PA11
default CLOSED
J13
1-2 CLOSE D
DEFAUL T
2
1 3
JR19
PC12
VDD_HV_IO_FLEX
PIN62
Jumper s etting
2-3 : Chorus 4M
1-2 : Chorus 1M
PM14
BCTRL
1-2 CLOSE DDEFAULT
2
13
J29
BCTRL
PH4
UM2790 - Rev 1
Figure 7. Signals
page 17/24
Schematics
UM2790
EXTAL
XTAL
EVB-EXTAL
ESR0
RSTIN
RST-MCU
OSC-MOD
EVB-EXTAL
EXTAL-SMA
RST-SW
VCC
GND
2 3
14
1
7
74LVC125AMTR
U1A
I2
5O26
OE2
4
74LVC125AMTR
U1B
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
3.3V_SR
VDD_HV_IO_MAIN
XTAL
EXTAL
ESR0
RSTIN
RST-SW
GND
GND
GND
GND
GND
GND
GND
GND
(MCU Crystal Input)
(MCU Crystal Output)
1-2 CL OSED
DEFAULT
1-2 CL OSED
DEFAULT
default OPEN
1-2 CLOSED
DEFAULT
GND
default CLOSED
default CLOSED
default CLOSED
REMOVE XTAL jumper when driving EXTAL from
Oscillator Module or External Source (PLL Enabled)
Connect XTAL jumper to GND when driving EXTAL from
Oscillator Module or External Source (PLL Bypass Mode)
Note - External 3.3V
regulator MUST be
enabled when using
oscillator module
Note - Internal
Pull-Up on Pin 1
SMA style
Connector
USER RESET LED
External Clock Input
MCU RESET LED
RESET
SO14
I3
9O38
OE
3
10
74LVC125AMTR
U1C
SO14
SO14
NOT MOUNTED
NOT MOUNTED
2
13
STRIP3PM
J17
0R
1/10W
0603
R13
1 2
40MHz
NX5032GA
XT1
0603
10pF DNP
50V
COG/NP0
C53
0603
10pF DNP
50V
COG/NP0
C55
0603
100nF
50V
X7R
C56
STRIP2PM
J19
2
13
STRIP3PM
J21
49R9
1/16W
0603
1%
R22
EN
1
GND2OUT
3
+Vs
4
8MHz
7x5
OSC1
10K
1/10W
0603
R18
560R
1/10W
0603
R16
4K7
1/10W
0603
R20
STRIP2PM
J22
Yellow
0805
LD1
STRIP2PM
J20
STRIP2PM
J25
220R
1/10W
0603
R19
220R
1/10W
0603
R21
560R
1/10W
0603
R17
Red
0805
LD2
2
1 3
STRIP3PM
J15
1
2
BNC-SMA-FEM-180
J26
ENABLE
GND
VCC
1
2
4
53
74V1G08STR
SOT23-5L
U2
RSTIN
TDI
TDO
TCK
JCOMP
TMS
GND
GND
GND
NOT MOUNTED
Jtag interface
TDI, TDO, TCK, TMS & JCOMP are not connected todaughter card.
PORST, ESR0, are connected to daughtercard
JTAG Connector
NOT MOUNTED
GND
1 2
3 4
5 6
7 8
9 10
11 12
13 14
N2514-6002RB
J14
10K
1/10W
0603
R12
10K DNP
1/10W
0603
R11
0603
27pF
50V
COG/NP0
C52
0603
47pF DNP
50V
COG/NP0
C51
Pushbutton
SW1
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
VSS_OSC
JCOMP/Rxn
TCK
TDI/Txn
TDO/Rxp
TMS/Txp
GND
GND
GND
GND
DNM
1/16W
0603
R26
DNM
1/16W
0603
R25
0603
DNM
X7R
C54
0603
DNM
X7R
C57
0603
27pF
50V
COG/NP0
C58
JTAG/LFast LVDS INTERFACE
10 Pin Version
NOT MOUNTED !!!
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
RSTIN
di ffe re n tia l si gn a ls
0R
1/10W
0603
R30
0R
1/10W
0603
R29
0R
1/10W
0603
R28
0R
1/10W
0603
R27
JCOMP TMS TDI TDO
100R
1/10W 0603
R24
default OPEN
JP2
ESR0
1 2
3 4
5 6
7 8
9 10
GND
12
GND
11
SAMTEC TFM-105-02-L-D-WT
CN1
GND
GND
UM2790 - Rev 1
Figure 8. JTAG, JTAG/LFast LVDS INTERFACE, reset and crystal
page 18/24
Schematics
UM2790
PA8
PG10
PG12
5.0V_SR
PE2
PE10
1.25V_SR
PC2
PC4
5.0V_SR
PC14
3.3V_SR
1.25V_SR
PA2
PA10
5.0V_SR
1.25V_SR
3.3V_SR
1.25V_SR
5.0V_SR
PA9
PG11
5.0V_SR
PE11
1.25V_SR
PE3
PC1
PC3
PC13
PC15
3.3V_SR
1.25V_SR
PA1
PA11
5.0V_SR
5.0V_SR
1.25V_SR
3.3V_SR
5.0V_SR
1.25V_SR
VDD_HV_IO_MAIN
5.0V_LR
5.0V_LR
3.3V_SR
3.3V_SR
5.0V_SR
5.0V_SR
1.25V_SR
1.25V_SR
VDD_HV_IO_MAIN
VDD_HV_IO_MAIN
5.0V_LR
5.0V_LR
VDD_HV_IO_MAIN
3.3V_SR
3.3V_SR
5.0V_SR
5.0V_SR
1.25V_SR
1.25V_SR
PF2
PG10
PG11
PG12
PH4
PC1
PC13
PC14
PC15
PA1
PA2
PA10
PA11
PB8
PB9
PB10
PB11
PD0
PD5
PD11
PD12
PD13
PD14
PD15
PE2
PE3
PE10
PE11
1.25V_SR
5.0V_LR
3.3V_SR
5.0V_SR
VDD_HV_IO_MAIN
1.25V_SR
5.0V_SR
3.3V_SR
1.25V_SR
3.3V_SR
1.25V_SR
1.25V_SR
3.3V_SR
PF3
5.0V_SR
PD5
PD11
PD13
PD15
3.3V_SR
PB9
PB11
3.3V_SR
PH4
1.25V_SR
3.3V_SR
PF2
5.0V_SR
PD0
PD12
PD14
1.25V_SR
PB8
PB10
1.25V_SR
5.0V_SR
3.3V_SR
1.25V_SR
3.3V_SR
5.0V_LR
1.25V_SR
1.25V_SR
5.0V_SR
5.0V_SR
3.3V_SR
3.3V_SR
VDD_HV_IO_MAIN
5.0V_LR
VDD_HV_IO_MAIN
5.0V_LR
1.25V_SR
1.25V_SR
5.0V_SR
5.0V_SR
3.3V_SR
3.3V_SR
VDD_HV_IO_MAIN
5.0V_LR
VDD_HV_IO_MAIN
RST-SW
3.3V_SR1.25V_SR 5.0V_LR5.0V_SR VDD_HV_IO_M AIN
RST-SW
PortE
GND
GND
GND
TP6
PA[0..15] PB[0..15]
PC[0..15]
PD[0..15]
PE[0..15]
PF[0..15]
PG[0..15] PH[0..15]
PA[0..15] PB[0..15] PC[0..15]
PD[0..15]
PE[0..15]
PF[0..15]
PG[0..15] PH[0..15]
PortA PortB PortC PortD PortF PortG PortH
1
1
3
3
5
5
7
7
9
9
11
11
13
13
15
15
17
17
19
19
21
21
23
23
25
25
27
27
29
29
31
31
33
33
35
35
37
37
39
39
41
41
43
43
45
45
47
47
49
49
51
51
53
53
55
55
57
57
59
59
61
61
63
63
65
65
67
67
69
69
71
71
73
73
75
75
77
77
79
79
81
81
83
83
85
85
87
87
89
89
91
91
93
93
95
95
97
97
99
99
101
101
103
103
105
105
107
107
109
109
111
111
113
113
115
115
117
117
119
119
2
2
4
4
6
6
8
8
10
10
12
12
14
14
16
16
18
18
20
20
22
22
24
24
26
26
28
28
30
30
32
32
34
34
36
36
38
38
40
40
42
42
44
44
46
46
48
48
50
50
52
52
54
54
56
56
58
58
60
60
62
62
64
64
66
66
68
68
70
70
72
72
74
74
76
76
78
78
80
80
82
82
84
84
86
86
88
88
90
90
92
92
94
94
96
96
98
98
100
100
102
102
104
104
106
106
108
108
110
110
112
112
114
114
116
116
118
118
120
120
SAMTEC QSH-120-01-L-D-A
J23A
SH1
SH1
SH2
SH2
SH3
SH3
SH4
SH4
SH5
SH5
SH6
SH6
SH7
SH7
SH8
SH8
SH9
SH9
121
121
123
123
125
125
127
127
129
129
131
131
133
133
135
135
137
137
139
139
141
141
143
143
145
145
147
147
149
149
151
151
153
153
155
155
157
157
159
159
161
161
163
163
165
165
167
167
169
169
171
171
173
173
175
175
177
177
179
179
181
181
183
183
185
185
187
187
189
189
191
191
193
193
195
195
197
197
199
199
201
201
203
203
205
205
207
207
209
209
211
211
213
213
215
215
217
217
219
219
221
221
223
223
225
225
227
227
229
229
231
231
233
233
235
235
237
237
239
239
SH16
SH16
SH15
SH15
SH14
SH14
SH13
SH13
SH12
SH12
SH11
SH11
SH10
SH10
122
122
124
124
126
126
128
128
130
130
132
132
134
134
136
136
138
138
140
140
142
142
144
144
146
146
148
148
150
150
152
152
154
154
156
156
158
158
160
160
162
162
164
164
166
166
168
168
170
170
172
172
174
174
176
176
178
178
180
180
182
182
184
184
186
186
188
188
190
190
192
192
194
194
196
196
198
198
200
200
202
202
204
204
206
206
208
208
210
210
212
212
214
214
216
216
218
218
220
220
222
222
224
224
226
226
228
228
230
230
232
232
234
234
236
236
238
238
240
240
SAMTEC QSH-120-01-L-D-A
J23B
1
1
3
3
5
5
7
7
9
9
11
11
13
13
15
15
17
17
19
19
21
21
23
23
25
25
27
27
29
29
31
31
33
33
35
35
37
37
39
39
41
41
43
43
45
45
47
47
49
49
51
51
53
53
55
55
57
57
59
59
61
61
63
63
65
65
67
67
69
69
71
71
73
73
75
75
77
77
79
79
81
81
83
83
85
85
87
87
89
89
91
91
93
93
95
95
97
97
99
99
101
101
103
103
105
105
107
107
109
109
111
111
113
113
115
115
117
117
119
119
2
2
4
4
6
6
8
8
10
10
12
12
14
14
16
16
18
18
20
20
22
22
24
24
26
26
28
28
30
30
32
32
34
34
36
36
38
38
40
40
42
42
44
44
46
46
48
48
50
50
52
52
54
54
56
56
58
58
60
60
62
62
64
64
66
66
68
68
70
70
72
72
74
74
76
76
78
78
80
80
82
82
84
84
86
86
88
88
90
90
92
92
94
94
96
96
98
98
100
100
102
102
104
104
106
106
108
108
110
110
112
112
114
114
116
116
118
118
120
120
SAMTEC QSH-120-01-L-D-A
J24A
SH1
SH1
SH2
SH2
SH3
SH3
SH4
SH4
SH5
SH5
SH6
SH6
SH7
SH7
SH8
SH8
SH9
SH9
121
121
123
123
125
125
127
127
129
129
131
131
133
133
135
135
137
137
139
139
141
141
143
143
145
145
147
147
149
149
151
151
153
153
155
155
157
157
159
159
161
161
163
163
165
165
167
167
169
169
171
171
173
173
175
175
177
177
179
179
181
181
183
183
185
185
187
187
189
189
191
191
193
193
195
195
197
197
199
199
201
201
203
203
205
205
207
207
209
209
211
211
213
213
215
215
217
217
219
219
221
221
223
223
225
225
227
227
229
229
231
231
233
233
235
235
237
237
239
239
SH16
SH16
SH15
SH15
SH14
SH14
SH13
SH13
SH12
SH12
SH11
SH11
SH10
SH10
122
122
124
124
126
126
128
128
130
130
132
132
134
134
136
136
138
138
140
140
142
142
144
144
146
146
148
148
150
150
152
152
154
154
156
156
158
158
160
160
162
162
164
164
166
166
168
168
170
170
172
172
174
174
176
176
178
178
180
180
182
182
184
184
186
186
188
188
190
190
192
192
194
194
196
196
198
198
200
200
202
202
204
204
206
206
208
208
210
210
212
212
214
214
216
216
218
218
220
220
222
222
224
224
226
226
228
228
230
230
232
232
234
234
236
236
238
238
240
240
SAMTEC QSH-120-01-L-D-A
J24B
PA5
PA7PA6
VDD_HV_IO_FLEX
VDD_HV_IO_FLEXVDD_HV_IO_FLEX
PI3
VDD_HV_IO_FLEX
VDD_HV_IO_FLEX
TP7 TP8
TP10TP9
PC2
PC3
PC4
PF3
PI[0..15]
PI[0..15]
PortI
PI1
PI2
PI3
PI4
PI6
PI7
PI1
PI2
PI4
PI7PI6
PC12
PC12
PM14
UM2790 - Rev 1
Figure 9. Motherboard connectors
page 19/24
Schematics
UM2790
Revision history
Date Version Changes
17-Feb-2021 1 Initial release.
UM2790
Table 10. Document revision history
UM2790 - Rev 1
page 20/24
UM2790
Contents
Contents
1 Overview ..........................................................................2
1.1 Package Contents..............................................................3
1.2 Supported Devices .............................................................3
2 License agreement ................................................................4
3 Handling precautions ..............................................................5
4 Hardware description ..............................................................6
4.1 Hardware features..............................................................6
4.2 Hardware dimension and PCB component view .....................................6
5 Power and system configuration ...................................................7
5.1 Power supplies ................................................................7
5.2 Microcontrollers configuration ....................................................8
5.3 Port configuration ..............................................................8
5.4 Debug interface configuration ....................................................8
5.5 System clock configuration ......................................................9
5.6 Reset circuit ..................................................................10
5.7 Test points ...................................................................10
5.8 Connectors...................................................................10
6 Layout overview ..................................................................12
7 BOM..............................................................................14
8 Schematics .......................................................................16
Revision history .......................................................................20
UM2790 - Rev 1
page 21/24
UM2790
List of tables
List of tables
Table 1. Supply related jumpers ................................................................7
Table 2. Microcontroller configuration related jumpers .................................................8
Table 3. Ports related jumpers .................................................................8
Table 4. Debug interface configuration related jumpers ................................................8
Table 5. Clock configuration jumpers ............................................................9
Table 6. Reset configuration jumpers ........................................................... 10
Table 7. Test points ....................................................................... 10
Table 8. Connectors ....................................................................... 10
Table 9. BOM ...........................................................................14
Table 10. Document revision history ............................................................. 20
UM2790 - Rev 1
page 22/24
UM2790
List of figures
List of figures
Figure 1. SPC58XXADPT64S rev. B ............................................................1
Figure 2. Overview of SPC58XXADPT64S rev. B "mini module" - top ..................................... 2
Figure 3. Overview of SPC58XXADPT64S rev. B "mini module" - bottom ................................... 3
Figure 4. SPC58XXADPT64S rev. B "mini module" - top .............................................12
Figure 5. SPC58XXADPT64S rev. B "mini module" - bottom .......................................... 13
Figure 6. Power and decoupling .............................................................. 16
Figure 7. Signals ........................................................................ 17
Figure 8. JTAG, JTAG/LFast LVDS INTERFACE, reset and crystal ...................................... 18
Figure 9. Motherboard connectors ............................................................ 19
UM2790 - Rev 1
page 23/24
UM2790
IMPORTANT NOTICE – PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and improvements to ST
products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST
products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of
Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other product or service
names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2021 STMicroelectronics – All rights reserved
UM2790 - Rev 1
page 24/24
Loading...
