ST Microelectronics SPBTLERF Datasheet
SPBTLE-RF
Bluetooth® V4.1 Smart module
Product preview
Features
Bluetooth Radio
-Bluetooth specification v4.1 compliant
-Master and slave Smart Bluetooth network processor module
-Embedded Bluetooth low energy protocol stack: GAP, GATT, SM, L2CAP, LL, RF-PHY
-Bluetooth low energy profiles provided separately
Preliminary module picture
11.5 mm x 13.5 mm x 2.0 mm
-Operating temperature range: -40°C to 85°C
Host Interface
-SPI, IRQ, and RESET
Antenna on board
CE, FCC, IC qualified
BQE certified
Jan 2015 - rev 0.1
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice. www.st.com
www.st.com
SPBTLE-RF
1 Description
The SPBTLE-RF is an easy to use Bluetooth® module, compliant with Bluetooth® v4.1. The module provides a complete RF platform in a tiny form factor.
The SPBTLE-RF enables wireless connectivity into electronic devices, not requiring any RF experience or expertise for integration into the final product. The SPBTLE-RF module, being a certified solution, optimizes the time to market of the final applications.
The module has been designed for maximum performance in a minimal space.
Optimized design allows the integration of a complete working Bluetooth® modem in the minimum possible size. Module interface is SPI serial interface.
2Applications
Watches
Fitness, wellness and sports
Consumer medical
Security/proximity
Remote control
Home and industrial automation
Assisted living
Mobile phone peripherals
PC peripherals
P a g e | 2 |
Rev 0.1 |
SPBTLE-RF
3 Block Diagram
Figure 1. HW block diagram
Battery or External Supply
BLUETOOTH L.E.. 2014 Module
|
|
|
SUPPLY FILTER |
|
|
|
|
|
|
||
INTERNAL 2.45 GHz |
Bead Ferrite |
|
|||
|
|
|
|||
RF antenna |
|
|
|
||
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
Host Controller |
SPI LINE |
|
interface |
|
|
|
|
|
|
|
|
RF |
|
|
BLUETOOTH |
|
|
|
||
|
BALUN |
|
|
|
|
|
|
BLUENRG |
|
|
+ Filter |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
32.768 kHz |
|
|
|
|
|
|
|
|
|
Crystal |
|
Internal / Ext. |
|
||
|
32 MHz |
|
32.768 kHz |
|
||
|
clock |
|
clock |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
External LPO (32.768 kHz)
OPTIONAL PIN FUNCTION
Rev 0.1 |
P a g e | 3 |
SPBTLE-RF
4 Software Architecture
Bluetooth Firmware implementation
Figure 2. SPBTLE-RF Application Block Diagaram
P a g e | 4 |
Rev 0.1 |
SPBTLE-RF
5 Hardware Specifications
General Conditions (VIN= 2.2V and 25°C)
5.1 Absolute Maximum Ratings |
|
|
|
|
|
|
|
|
|
|
||
Table 1. Absolute maximum rating |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rating |
|
Min |
|
Typical |
|
Max |
|
|
Unit |
|
|
|
Storage temperature range |
-40 |
|
- |
|
+85 |
|
|
°C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply voltage, VIN |
-0.3 |
|
- |
|
+ 3.9 |
|
|
Volts |
|
|
|
|
I/O pin Voltage |
-0.3 |
|
- |
|
+ 3.9 |
|
|
Volts |
|
|
|
|
(VIO five-volt tolerant pin) |
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RF saturation input power |
- |
|
8 |
|
- |
|
|
dBm |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.2 Recommended Operating Conditions |
|
|
|
|
|
|
|
|
|
|
||
Table 2. Recommended operating conditions |
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rating |
|
Min |
|
Typical |
|
Max |
|
|
Unit |
|
|
|
Operating Temperature Range |
|
-40 |
|
- |
|
85 |
|
|
°C |
|
|
|
Supply Voltage VIN |
|
2.0 |
|
3.3 |
|
3.6 |
|
|
Volts |
|
|
|
Signals & I/O Pin Voltage |
|
2.0 |
|
- |
|
3.6 |
|
|
Volts |
|
|
|
(according Supply Voltage) |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RF Frequency |
|
2402 |
|
- |
|
2480 |
|
|
MHz |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5.3 Pin assignement Figure 3. Pin connection
Rev 0.1 |
P a g e | 5 |
SPBTLE-RF
Table 3. Pin Assignement
|
Name |
|
|
Type |
|
|
Pin # |
|
|
Description |
|
|
ALT Function |
|
|
V max. Tolerant |
|
|
Initial State |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
SPI Interface |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SPI_IRQ |
|
O |
4 |
|
SPI IRQ(SLAVE has data for MASTER) |
|
|
|
|
Vin |
|
|
|
|
|||||
|
SPI_CLK |
|
I |
7 |
|
SPI CLOCK (Max. 8 MHz) |
|
|
|
|
Vin |
|
|
|
|
|||||
|
SPI_MISO |
|
O |
8 |
|
SPI MISO (MASTER in / SLAVE out) |
|
|
|
|
Vin |
|
|
|
|
|||||
|
SPI_MOSI |
|
I |
9 |
|
SPI MOSI (MASTER out SLAVE in) |
|
|
|
|
Vin |
|
|
|
|
|||||
|
SPI_CS |
|
I |
10 |
|
SPI “Chip Select” (SPI slave select) |
|
|
|
|
Vin |
|
|
|
|
|||||
|
Power and Ground |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
Vin |
|
|
|
5 |
|
|
Vin |
|
|
|
|
(2.0V + 3.6V max.) |
|
|
|
|
|||
|
GND |
|
|
|
6 |
|
|
GND |
|
|
|
|
|
|
|
|
|
|||
|
Reset |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
BT_RESET |
|
I |
11 |
|
Reset input (active low < 0.35 Vin) |
|
|
|
|
(2.0V + 3.6V max.). |
|
|
|
|
|||||
|
LPO |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EXT_LPCLK |
|
I |
1 |
|
Not connected / Optional pin function |
|
|
|
|
(2.0V + Vin max.). |
|
|
|
|
|||||
|
GPIO2 |
|
I/O |
2 |
|
|
Not connected |
|
|
|
|
|
|
|
|
|
||||
|
ANA TEST 0 |
|
I |
3 |
|
|
Not connected |
|
|
|
|
|
|
|
|
|
||||
P a g e | 6 |
Rev 0.1 |
