Features
■ Output current in excess of 1 A
■ Output voltages of 5; 6; 8; 9; 12; 15; 24 V
■ Thermal overload protection
■ Output transition SOA protection
■ 2 % Output voltage tolerance
■ Guaranteed in extended temperature range
Description
The L78xxAB L78xxAC series of three terminal
positive regulators are available in TO-220,
TO-220FP, and D
fixed output voltages, making it useful in a wide
range of applications. These regulators can
provide local on-card regulation, eliminating the
distribution problem associated with single point
regulation. Each type employs internal current
limiting, thermal shut-down and safe area
protection, making it essentially indestructible. If
adequate heat sinking is provided, they can
deliver over 1 A output current, although designed
primarily as fixed voltage regulators, these
devices can be used with external components to
obtain adjustable voltage and currents.
2
PAK packages and several
L78xxAB
L78xxAC
Precision 1 A regulators
TO-220
2
PAK
D
TO-220FP
Table 1. Device summary
Order codes
L7805AB L7809AC
L7805AC L7812AB
L7806AB L7812AC
L7806AC L7815AB
L7808AB L7815AC
L7808AC L7824AB
L7809AB L7824AC
July 2008 Rev 17 1/26
www.st.com
26
Contents L78xxAB - L78xxAC
Contents
1 Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Pin configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Test circuits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Application information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.1 Design consideration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7 Package mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8 Order codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2/26
L78xxAB - L78xxAC Diagram
1 Diagram
Figure 1. Block diagram
Figure 2. Schematic diagram
3/26
Pin configuration L78xxAB - L78xxAC
2 Pin configuration
Figure 3. Pin connections (top view)
TO-220
D
2
PAK
TO-220FP
4/26
L78xxAB - L78xxAC Maximum ratings
3 Maximum ratings
Table 2. Absolute maximum ratings
Symbol Parameter Value Unit
for V
= 5 to 18V 35
O
= 20, 24V 40
for V
O
for L7800AC 0 to 150
for L7800AB -40 to 125
V
°C
T
P
T
V
I
STG
OP
DC input voltage
I
Output current Internally limited mA
O
Power dissipation Internally limited mW
D
Storage temperature range -65 to 150 °C
Operating junction temperature range
Note: Absolute maximum ratings are those values beyond which damage to the device may occur.
Functional operation under these condition is not implied.
Table 3. Thermal data
Symbol Parameter TO-220 TO-220FP D2PAK U ni t
R
R
thJC
thJA
Thermal resistance junction-case 3 5 3 °C/W
Thermal resistance junction-ambient 50 60 62.5 °C/W
Figure 4. Application circuit
5/26
Test circuits L78xxAB - L78xxAC
4 Test circuits
Figure 5. DC parameter
Figure 6. Load regulation
Figure 7. Ripple rejection
6/26
L78xxAB - L78xxAC Electrical characteristics
5 Electrical characteristics
Table 4. Electrical characteristics of L7805A (VI = 10 V, IO = 1 A, TJ = 0 to 150 °C (L7805AC),
T
= -40 to 125 °C (L7805AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔVO(*) Load regulation
ΔI
SVR Supply voltage rejection V
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 4.9 5 5.1 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 17 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -1.1 mV/°C
O
O
= 7.5 to 20V
V
I
= 7.5 to 25V, IO = 500 mA 7 50 mV
V
I
= 8 to 12V 10 50 mV
V
I
V
= 8 to 12V, TJ = 25°C 2 25 mV
I
= 7.3 to 20V, TJ = 25°C 7 50 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 8 50 V
I
O
T
= 25°C 4.3 6 mA
J
4.8 5 5.2 V
6mA
V
= 8 to 25V, IO = 500 mA 0.8 mA
I
= 7.5 to 20V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 8 to 18V, f = 120Hz, IO = 500mA 68 dB
I
= 25°C, B =10Hz to 100kHz 10 µV/V
A
O
7/26
Electrical characteristics L78xxAB - L78xxAC
Table 5. Electrical characteristics of L7806A (VI = 11 V, IO = 1 A, TJ = 0 to 150 °C (L7806AC),
T
= -40 to 125 °C (L7806AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection V
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 5.88 6 6.12 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 17 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -0.8 mV/°C
O
O
= 8.6 to 21V
V
I
= 8.6 to 25V, IO = 500 mA 9 60 mV
V
I
= 9 to 13V 11 60 mV
V
I
V
= 9 to 13V, TJ = 25°C 3 30 mV
I
= 8.3 to 21V, TJ = 25°C 9 60 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.3 6 mA
J
5.76 6 6.24 V
6mA
V
= 9 to 25V, IO = 500 mA 0.8 mA
I
= 8.6 to 21V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 9 to 19V, f = 120Hz, IO = 500mA 65 dB
I
= 25°C, B =10Hz to 100kHz 10 µV/V
A
O
8/26
L78xxAB - L78xxAC Electrical characteristics
Table 6. Electrical characteristics of L7808A (VI = 14 V, IO = 1 A, TJ = 0 to 150 °C (L7808AC),
T
= -40 to 125 °C (L7808AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 7.84 8 8.16 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 18 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -0.8 mV/°C
O
O
= 10.6 to 23V
V
I
= 10.6 to 25V, IO = 500 mA 12 80 mV
V
I
= 11 to 17V 15 80 mV
V
I
V
= 11 to 17V, TJ = 25°C 5 40 mV
I
= 10.4 to 23V, TJ = 25°C 12 80 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.3 6 mA
J
7.7 8 8.3 V
6mA
V
= 11 to 25V, IO = 500 mA 0.8 mA
I
= 10.6 to 23V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 11.5 to 21.5V, f = 120Hz,
V
I
IO = 500mA
= 25°C, B =10Hz to 100kHz 10 µV/V
A
62 dB
O
9/26
Electrical characteristics L78xxAB - L78xxAC
Table 7. Electrical characteristics of L7809A (VI = 15 V, IO = 1 A, TJ = 0 to 150 °C (L7809AC),
T
= -40 to 125 °C (L7809AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 8.82 9 9.18 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 18 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -0.8 mV/°C
O
O
= 10.6 to 23V
V
I
= 10.6 to 25V, IO = 500 mA 12 90 mV
V
I
= 11 to 17V 15 90 mV
V
I
V
= 11 to 17V, TJ = 25°C 5 45 mV
I
= 10.4 to 23V, TJ = 25°C 12 90 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.3 6 mA
J
8.65 9 9.35 V
6mA
V
= 11 to 25V, IO = 500 mA 0.8 mA
I
= 10.6 to 23V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 11.5 to 21.5V, f = 120Hz,
V
I
IO = 500mA
= 25°C, B =10Hz to 100kHz 10 µV/V
A
61 dB
O
10/26
L78xxAB - L78xxAC Electrical characteristics
Table 8. Electrical characteristics of L7812A (VI = 19 V, IO = 1 A, TJ = 0 to 150 °C (L7812AC),
T
= -40 to 125 °C (L7812AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection V
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 11.75 12 12.25 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 18 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -1 mV/°C
O
O
= 14.8 to 27V
V
I
= 14.8 to 30V, IO = 500 mA 13 120 mV
V
I
= 16 to 12V 16 120 mV
V
I
V
= 16 to 12V, TJ = 25°C 6 60 mV
I
= 14.5 to 27V, TJ = 25°C 13 120 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.4 6 mA
J
11.5 12 12.5 V
6mA
V
= 15 to 30V, IO = 500 mA 0.8 mA
I
= 14.8 to 27V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 15 to 25V, f = 120Hz, IO = 500mA 60 dB
I
= 25°C, B =10Hz to 100kHz 10 µV/V
A
O
11/26
Electrical characteristics L78xxAB - L78xxAC
Table 9. Electrical characteristics of L7815A (VI = 23 V, IO = 1 A, TJ = 0 to 150 °C (L7815AC),
T
= -40 to 125 °C (L7815AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 14.7 15 15.3 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 19 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -1 mV/°C
O
O
= 17.9 to 30V
V
I
= 17.9 to 30V, IO = 500 mA 13 150 mV
V
I
= 20 to 26V 16 150 mV
V
I
V
= 20 to 26V, TJ = 25°C 6 75 mV
I
= 17.5 to 30V, TJ = 25°C 13 150 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.4 6 mA
J
14.4 15 15.6 V
6mA
V
= 17.5 to 30V, IO = 500 mA 0.8 mA
I
= 17.5 to 30V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 18.5 to 28.5V, f = 120Hz,
V
I
IO = 500mA
= 25°C, B =10Hz to 100kHz 10 µV/V
A
58 dB
O
12/26
L78xxAB - L78xxAC Electrical characteristics
Table 10. Electrical characteristics of L7824A (VI = 33 V, IO = 1 A, TJ = 0 to 150 °C (L7824AC),
T
= -40 to 125 °C (L7824AB), unless otherwise specified)
J
Symbol Parameter Test conditions Min. Typ. Max. Unit
V
V
ΔV
ΔV
ΔI
SVR Supply voltage rejection V
V
eN Output noise voltage T
R
I
I
ΔV
1. Load and line regulation are specified at constant junction temperature. Changes in VO due to heating effects must be
taken into account separately. Pulse testing with low duty cycle is used.
Output voltage TJ = 25°C 23.5 24 24.5 V
O
= 5mA to 1A, PO ≤15W
I
Output voltage
O
(1)
Line regulation
O
(1)
Load regulation
O
I
Quiescent current
q
Quiescent current change
q
Dropout voltage IO = 1A, TJ = 25°C 2 V
d
Output resistance f =1kHz 20 mΩ
O
Short circuit current VI = 35V, TA = 25°C 0.2 A
sc
Short circuit peak current TJ = 25°C 2.2 A
scp
/ΔT Output voltage drift -1.5 mV/°C
O
O
= 27.3 to 38V
V
I
= 27 to 38V, IO = 500 mA 31 240 mV
V
I
= 30 to 36V 35 200 mV
V
I
V
= 30 to 36V, TJ = 25°C 14 120 mV
I
= 26.7 to 38V, TJ = 25°C 31 240 mV
V
I
= 5mA to 1A 25 100 mV
I
O
I
= 5mA to 1.5A, TJ = 25°C 30 100 V
O
= 250 to 750mA 10 50 V
I
O
T
= 25°C 4.6 6 mA
J
23 24 25 V
6mA
V
= 27.3 to 38V, IO = 500 mA 0.8 mA
I
= 27.3 to 38V, TJ = 25°C 0.8 mA
V
I
I
= 5mA to 1A 0.5 mA
O
= 28 to 38V, f = 120Hz, IO = 500mA 54 dB
I
= 25°C, B =10Hz to 100kHz 10 µV/V
A
O
13/26
Application information L78xxAB - L78xxAC
6 Application information
6.1 Design consideration
The L78xxA Series of fixed voltage regulators are designed with Thermal Overload
Protection that shuts down the circuit when subjected to an excessive power overload
condition, internal short-circuit protection that limits the maximum current the circuit will
pass, and output transistor safe-area compensation that reduces the output short-circuit
current as the voltage across the pass transistor is increased. In many low current
applications, compensation capacitors are not required. However, it is recommended that
the regulator input be bypassed with capacitor if the regulator is connected to the power
supply filter with long lengths, or if the output load capacitance is large. An input bypass
capacitor should be selected to provide good high frequency characteristics to insure stable
operation under all load conditions. A 0.33 µF or larger tantalum, mylar or other capacitor
having low internal impedance at high frequencies should be chosen. The bypass capacitor
should be mounted with the shortest possible leads directly across the regulators input
terminals. Normally good construction techniques should be used to minimize ground loops
and lead resistance drops since the regulator has no external sense lead.
The addition of an operational amplifier allows adjustment to higher or intermediate values
while retaining regulation characteristics. The minimum voltage obtained with the
arrangement is 2 V greater than the regulator voltage.
The circuit of figure 6 can be modified to provide supply protection against short circuit by
adding a short circuit sense resistor, RSC, and an additional PNP transistor. The current
sensing PNP must be able to handle the short circuit current of the three terminal regulator
Therefore a four ampere plastic power transistor is specified.
Figure 8. DC parameter
IO = VXX/R1+I
d
14/26
L78xxAB - L78xxAC Application information
Figure 9. DC parameter
VO = 7 to 20V
VI - VO ≥ 2V
Figure 10. DC parameter
V
I
REQ
REG
BEQ1
-(IQ1/βQ1)
+ Q1 (I
REG
V
BEQ1
______)
R1 = ______________
IO = I
R
Figure 11. DC parameter
1
15/26
Package mechanical data L78xxAB - L78xxAC
7 Package mechanical data
In order to meet environmental requirements, ST offers these devices in ECOPACK®
packages. These packages have a lead-free second level interconnect. The category of
second Level Interconnect is marked on the package and on the inner box label, in
compliance with JEDEC Standard JESD97. The maximum ratings related to soldering
conditions are also marked on the inner box label. ECOPACK is an ST trademark.
ECOPACK specifications are available at: www.st.com.
16/26
L78xxAB - L78xxAC Package mechanical data
TO-220 mechanical data
Dim.
A 4.40 4.60 0.173 0.181
C1.23 1.32 0.048 0.051
D 2.40 2.72 0.094 0.107
D1 1.27 0.050
E0.49 0.70 0.019 0.027
F 0.61 0.88 0.024 0.034
F1 1.14 1.70 0.044 0.067
F2 1.14 1.70 0.044 0.067
G4.95 5.15 0.194 0.203
G1 2.4 2.7 0.094 0.106
H2 10.0 10.40 0.393 0.409
L2 16.4 0.645
L4 13.0 14.0 0.511 0.551
L5 2.65 2.95 0.104 0.116
L6 15.25 15.75 0.600 0.620
L7 6.2 6.6 0.244 0.260
L93.5 3.93 0.137 0.154
DIA. 3.75 3.85 0.147 0.151
Min. Typ. Max. Min. Typ. Max.
mm. inch.
P011C
17/26
Package mechanical data L78xxAB - L78xxAC
H
TO-220FP mechanical data
Dim.
Min. Typ Max. Min. Typ. Max.
A 4.40 4.60 0.173 0.181
B 2.5 2.7 0.098 0.106
D 2.5 2.75 0.098 0.108
E 0.45 0.70 0.017 0.027
F 0.75 1 0.0300.039
F1 1.15 1.50 0.045 0.059
F2 1.15 1.50 0.045 0.059
G4.95 5.2 0.194 0.204
G1 2.4 2.7 0.094 0.106
H 10.0 10.40 0.393 0.409
L2 16 0.630
L3 28.6 30.6 1.126 1.204
L4 9.8 10.6 0.3850.417
L5 2.93.6 0.114 0.142
L6 15.9 16.4 0.626 0.645
L7 99.3 0.354 0.366
DIA. 33.2 0.118 0.126
mm. inch.
18/26
7012510A-
L78xxAB - L78xxAC Package mechanical data
Figure 12. Drawing dimension D2PAK (type STD-ST)
0079457/L
19/26
Package mechanical data L78xxAB - L78xxAC
Figure 13. Drawing dimension D2PAK (type WOOSEOK-Subcon.)
20/26
0079457/L
L78xxAB - L78xxAC Package mechanical data
Table 11. D
Dim.
A 4.40 4.60 4.30 4.70
A1 0.03 0.23 0 0.20
b 0.70 0.93 0.70 0.90
b2 1.14 1.70 1.17 1.37
c 0.45 0.60 0.45 0.50 0.60
c2 1.23 1.36 1.25 1.30 1.40
D 8.95 9.35 9 9.20 9.40
D1 7.50 7.50
E 10 10.40 9.80 10.20
E1 8.50 7.50
e2.54 2.54
e1 4.88 5.28 5.08
H 15 15.85 15 15.30 15.60
J1 2.49 2.69 2.20 2.60
L 2.29 2.79 1.79 2.79
2
PAK mechanical data
Type STD-ST Type WOOSEOK-Subcon.
mm. mm.
Min. Typ. Max. Min. Typ. Max.
L1 1.27 1.40 1 1.40
L2 1.30 1.75 1.20 1.60
R 0.4 0.30
V2 0° 8° 0° 3°
Note: The D2PAK package coming from the subcontractor Wooseok is fully compatible with the
ST's package suggested footprint.
21/26
Package mechanical data L78xxAB - L78xxAC
Figure 14. D2PAK footprint recommended data
Table 12. Footprint data
Dim. mm. inch.
A 12.20 0.480
B9.750.384
C 16.90 0.665
D3.500.138
E1.600.063
F2.540.100
G5.080.200
Values
22/26
L78xxAB - L78xxAC Package mechanical data
Tape & reel D2PAK-P2PAK-D2PAK/A-P2PAK/A mechanical data
Dim.
Min. Typ. Max. Min. Typ. Max.
A180 7.086
C 12.8 13.0 13.2 0.504 0.512 0.519
D 20.2 0.795
N60 2.362
T 14.4 0.567
Ao 10.50 10.6 10.70 0.413 0.417 0.421
Bo 15.70 15.80 15.90 0.618 0.622 0.626
Ko 4.804.90 5.00 0.189 0.193 0.197
Po 3.9 4.0 4.1 0.153 0.157 0.161
P 11.9 12.0 12.1 0.468 0.472 0.476
mm. inch.
23/26
Order codes L78xxAB - L78xxAC
8 Order codes
Table 13. Order codes
Packaging
Part number
TO-220 TO-220FP D
L7805AB L7805ABV L7805ABP L7805ABD2T-TR 5 V
L7805AC L7805ACV L7805ACP L7805ACD2T-TR 5 V
L7806AB L7806ABV L7806ABD2T-TR 6 V
L7806AC L7806ACV L7806ACD2T-TR 6 V
L7808AB L7808ABV L7808ABD2T-TR 8 V
L7808AC L7808ACV L7808ACD2T-TR 8 V
L7809AB L7809ABV L7809ABD2T-TR 9 V
L7809AC L7809ACV L7809ACD2T-TR 9 V
L7812AB L7812ABV L7812ABD2T-TR 12 V
L7812AC L7812ACV L7812ACD2T-TR 12 V
L7815AB L7815ABV L7815ABD2T-TR 15 V
L7815AC L7815ACV L7815ACD2T-TR 15 V
2
PAK
Output voltage
L7824AB L7824ABV L7824ABD2T-TR 24 V
L7824AC L7824ACV 24 V
24/26
L78xxAB - L78xxAC Revision history
9 Revision history
Table 14. Document revision history
Date Revision Changes
21-Jun-2004 9 Document updating.
04-Aug-2006 10 Order codes updated and new template.
2
19-Jan-2007 11 D
07-Mar-2007 12 Update figure D
01-Jun-2007 13 Order codes updated.
25-Jul-2007 14 Add Ta b le 1 in cover page.
11-Dec-2007 15 Modified: Ta b le 1 3 .
20-Feb-2008 16 Modified: Table 13 on page 24.
15-Jul-2008 17 Modified: Table 1 on page 1 and Table 13 on page 24.
PAK mechanical data has been updated and add footprint data.
2
PAK in cover page.
25/26
L78xxAB - L78xxAC
Please Read Carefully:
Information in this document is provided solely in connection with ST products. STMicroelectronics NV and its subsidiaries (“ST”) reserve the
right to make changes, corrections, modifications or improvements, to this document, and the products and services described herein at any
time, without notice.
All ST products are sold pursuant to ST’s terms and conditions of sale.
Purchasers are solely responsible for the choice, selection and use of the ST products and services described herein, and ST assumes no
liability whatsoever relating to the choice, selection or use of the ST products and services described herein.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this
document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products
or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such
third party products or services or any intellectual property contained therein.
UNLESS OTHERWISE SET FORTH IN ST’S TERMS AND CONDITIONS OF SALE ST DISCLAIMS ANY EXPRESS OR IMPLIED
WARRANTY WITH RESPECT TO THE USE AND/OR SALE OF ST PRODUCTS INCLUDING WITHOUT LIMITATION IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE (AND THEIR EQUIVALENTS UNDER THE LAWS
OF ANY JURISDICTION), OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
UNLESS EXPRESSLY APPROVED IN WRITING BY AN AUTHORIZED ST REPRESENTATIVE, ST PRODUCTS ARE NOT
RECOMMENDED, AUTHORIZED OR WARRANTED FOR USE IN MILITARY, AIR CRAFT, SPACE, LIFE SAVING, OR LIFE SUSTAINING
APPLICATIONS, NOR IN PRODUCTS OR SYSTEMS WHERE FAILURE OR MALFUNCTION MAY RESULT IN PERSONAL INJURY,
DEATH, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE. ST PRODUCTS WHICH ARE NOT SPECIFIED AS "AUTOMOTIVE
GRADE" MAY ONLY BE USED IN AUTOMOTIVE APPLICATIONS AT USER’S OWN RISK.
Resale of ST products with provisions different from the statements and/or technical features set forth in this document shall immediately void
any warranty granted by ST for the ST product or service described herein and shall not create or extend in any manner whatsoever, any
liability of ST.
ST and the ST logo are trademarks or registered trademarks of ST in various countries.
Information in this document supersedes and replaces all information previously supplied.
The ST logo is a registered trademark of STMicroelectronics. All other names are the property of their respective owners.
© 2008 STMicroelectronics - All rights reserved
STMicroelectronics group of companies
Australia - Belgium - Brazil - Canada - China - Czech Republic - Finland - France - Germany - Hong Kong - India - Israel - Italy - Japan -
Malaysia - Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - United States of America
www.st.com
26/26
Loading...
