■ Minimum lot-to-lot spread for reliable operation
■ Very high switching speed
■ High ruggedness
■ Fully characterized at 125 °C
■ Integrated antiparallel collector-emitter diode
Applications
TO-220
BUL38D
3
2
1
■ Electronic transformers for halogen lamps
■ Switch mode power supplies
Description
The BUL38D is manufactured using high voltage
multi epitaxial planar technology for high switching
speeds and high voltage capability.
The device is designed for use in electronic
transformer for halogen lamps.
Table 1.Device summary
Order codeMarking
(1)
Figure 1.Internal schematic diagram
PackagePackaging
BUL38D
BUL38D A
or
TO-220Tube
BUL38D B
1. Product is pre-selected in DC current gain (group A and group B). STMicroelectronics reserves the right to ship either
groups according to production availability. Please contact your nearest STMicroelectronics sales office for delivery details.
June 2009Doc ID 7176 Rev 31/10
www.st.com
10
Electrical ratingsBUL38D
1 Electrical ratings
Table 2.Absolute maximum ratings
SymbolParameterValueUnit
V
V
V
CES
CEO
EBO
I
I
CM
I
I
BM
P
T
T
C
B
tot
stg
Collector-emitter voltage (VBE = 0)800V
Collector-emitter voltage (IB = 0)450V
Emitter-base voltage (IC = 0)9V
Collector current5A
Collector peak current (tP < 5 ms)10A
Base current2A
Base peak current (tP < 5 ms)4A
Total dissipation at Tc ≤ 25 °C80W
Storage temperature-65 to 150°C
Max. operating junction temperature150°C
J
Table 3.Thermal data
SymbolParameterValueUnit
R
R
thJC
thJA
Thermal resistance junction-case max1.56°C/W
Thermal resistance junction-ambient max62.5°C/W
2/10 Doc ID 7176 Rev 3
BUL38DElectrical characteristics
2 Electrical characteristics
(T
= 25°C unless otherwise specified)
case
Table 4.Electrical characteristics
SymbolParameterTest conditionsMin.Typ.Max.Unit
I
CES
I
CEO
V
CEO(sus)
V
EBO
V
CE(sat)
V
BE(sat)
h
FE
(1)(2)
t
s
t
f
t
s
t
f
t
s
t
f
Collector cut-off current
(VBE = 0)
Collector cut-off current
(IB =0)
Collector-emitter
(1)
sustaining voltage (IB = 0)
Emitter-base voltage
= 0)
(I
C
Collector-emitter
(1)
saturation voltage
Base-emitter saturation
(1)
voltage
DC current gain
Resistive load
Storage time
Fall tim e
Inductive load
Storage time
Fall tim e
Inductive load
Storage time
Fall tim e
V
= 800 V
CE
V
= 800 V Tc = 125 °C
CE
V
= 450 V250µA
CE
=100 mA450V
I
C
= 10 mA9V
I
E
= 1 A _ _ IB = 0.2 A
I
C
= 2 A _ IB = 0.4 A
I
C
= 3 A __ IB = 0.75 A
I
C
= 1 A _ _IB = 0.2 A
I
C
= 2 A _ IB = 0.4 A
I
C
I
= 10 mA V
C
= 0.5 A V
I
C
IC = 2 A V
Group A
Group B
= 150 V IC = 2.5 A
V
CC
I
B(on)
= 30 µs
t
P
= -I
B(off)
= 0.5 A
IC = 2 A I
V
V
I
V
V
= -5 V R
BE(off)
= 250 V L = 200 µH
CL
= 2 A I
C
= -5 V R
BE(off)
= 250 V L = 200 µH
CL
CE
CE
CE
B(on)
BB(off)
B(on)
BB(off)
= 5 V
= 5 V
= 5 V
= 0.4 A
=0
= 0.4 A
=0
10
13
22
12.2
100
1
55
1.3
100
500µAµA
0.5
0.7
1.1
1.1
1.2
60
23
32
0.8
1.8
100µsns
TC = 125 °C
V
V
V
V
V
µs
µs
µs
ns
V
1. Pulsed duration = 300 µs, duty cycle ≤ 1.5%.
2. The product is pre-selected in DC current gain (Group A and Group B). STMicroelectronics reserves the
right to ship either groups according to production availability. Please contact your nearest
STMicrolectronics sales office for delivery details.
Figure 6.DC current gain (VCE = 1.5 V) Figure 7.DC current gain (VCE = 5 V)
4/10 Doc ID 7176 Rev 3
BUL38DElectrical characteristics
Figure 8.Collector-emitter saturation
Figure 10. Inductive load storage timeFigure 11. Inductive load fall time
Voltage
Figure 9.Base-emitter saturation
voltage
Doc ID 7176 Rev 35/10
Electrical characteristicsBUL38D
2.2 Test circuits
Figure 12. Inductive load switching test circuit
1. Fast electronic switch
2. Non-inductive resistor
3. Fast recovery rectifier
Figure 13. Resistive load switching test circuit
1. Fast electronic switch
2. Non-inductive resistor
6/10 Doc ID 7176 Rev 3
BUL38DPackage mechanical data
3 Package mechanical data
In order to meet environmental requirements, ST offers these devices in different grades of
ECOPACK
specifications, grade definitions and product status are available at: www.st.com.
ECOPACK
®
packages, depending on their level of environmental compliance. ECOPACK®
®
is an ST trademark.
Doc ID 7176 Rev 37/10
Package mechanical dataBUL38D
TO-220 mechanical data
Dim
MinTypMaxMinTypMax
mminch
A4.404.600.1730.181
b0.610.880.0240.034
b11.141.700.0440.066
c0.480.700.0190.027
D15.2515.750.60.62
D11.270.050
E1010.400.3930.409
e2.402.700.0940.106
e14.955.150.1940.202
F1.231.320.0480.051
H16.206.600.2440.256
J12.402.720.0940.107
L13140.5110.551
L13.503.930.1370.154
L2016.400.645
L3028.901.137
∅P3.753.850.1470.151
Q2.652.950.1040.116
8/10 Doc ID 7176 Rev 3
BUL38DRevision history
4 Revision history
Table 5.Document revision history
DateRevisionChanges
16-Jun-20042Document migration, no content change.
23-Jun-20093Updated TO-220 mechanical data.
Doc ID 7176 Rev 39/10
