STL Virtue-1 Operation Manual And Instructions

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

STL Virtue-1® Linear Interior LED Dash Light

Operation Manual and Instructions

Congratulations, you are the owner of a STL Virtue-1® Linear Interior LED Dash Light! Your bar
is equipped with the latest technology and features at the best value found industry wide,
GUARANTEED. In addition to that, your purchase comes with the STL 3 Year Warranty against
any manufacture defects that may occur with your bar. So please read this document carefully
and call Customer Service at 800-757-2581 Monday - Friday 8:30 AM - 4:30 PM central time if
you need assistance. We are available and happy to help!

Warnings and Notices for Users and Installers

This document must be delivered to and read by the end user and installer as it serves to
provide you with the required information for proper and safe use of your STL product. Before
operating this or any STL products the user and installer must read this manual all the way
through. You will find important information in this manual that could prevent property damage
and/or serious injury to the user and installer.

STL products are intended to alert pedestrians and other operators of the presence of
personnel, the operation of emergency vehicles, an emergency site, and any warning needs. This
does not ensure that pedestrians or drivers will react, heed, or observe emergency warning
signals. Nor does the use of emergency signals grant or ensure you the right of way. It is your
responsibility to make sure you can proceed safely before driving against traffic, entering an
intersection, responding at a high rate of speed, or walking on or around traffic lanes.

Your STL emergency vehicle devices should be tested daily to insure the device and all its
functions are operating correctly. If you experience a malfunction contact STL's Customer
Service immediately for troubleshooting options, or a warranty or service claim. You must
ensure sure that the projection of the visual and audible signal is not blocked by vehicle
components (i.e.: open trunks, visors, compartment doors), vehicles, other obstructions, or
people.

This is professional grade equipment and is intended for strict use by authorized personnel only.
It is the user's responsibility to understand and obey all laws regarding emergency warning
devices. You must know and be familiar with all applicable city, state, and federal laws and
regulations prior to the use of emergency vehicle warning devices.

1 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

SpeedTech Lights, Inc. assumes no liability for any loss resulting from the use of this warning
device. Proper installation is vital to the performance of the warning devices and safe operation
of the emergency vehicle. Since the operator is under stressful environments the equipment
must be properly wired and mounted to ensure effectiveness and safety. Therefore controllers
must be properly installed and placed within convenient reach of the operator so eye contact
with the roadway is never lost.

The effectiveness of your STL equipment is highly dependent upon correct mounting and wiring.
Improper wiring and mounting of the warning device will reduce the output and performance of
the equipment. Emergency warning devices frequently require high electrical voltages and/or
currents. Properly protect and use caution around live electrical connections. Grounding or
shorting of electrical connections can cause high current arcing, which can cause severe
personal injury and/or serious vehicle damage, including fire.

Electromagnetic interference can be caused by many electronic devices used in emergency
vehicles. To ensure that this doesn't happen to you, lightbars should be mounted a minimum of
12" - 34" from the radio antenna and do not power your equipment from the same circuit or
share the same grounding circuit with radio communication equipment. After installation, test all
the vehicle's equipment together to ensure everything operates free of interference.

Driver and/or passenger airbags bags (SRS) will impact the way you mount your equipment. Any
equipment installed in the deployment area of the airbags will damage or dislodge the airbags
and sensors. This will also reduce the effectiveness of the airbags to protect the passengers and
therefore these areas must be avoided. Installers must make sure that this equipment along
with any parts, hardware, wiring, power supplies, and switch boxes do not interfere with the
airbags, SRS wiring, or sensors.

All STL equipment needs to be mounted and installed according to the vehicle manufacture's
instructions and securely attached to a part of the vehicle of sufficient strength to withstand the
forces applied by the equipment. This device should be permanently mounted within the zones
specified by the vehicle manufacturer. This especially applies to equipment mounted on the
exterior of the vehicle to avoid dislodging. Mounting units on the interior of the vehicle by a
method other than permanent mount is discouraged as it may become detached under
aggressive driving conditions such as sudden braking, collision, or swerving.

PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF
EMERGENCY WARNING DEVICES IS ESSENTIAL TO ENSURE THE SAFETY OF EMERGENCY
PERSONNEL AND THE PUBLIC.

2 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Important Points for Your Safety and Longevity of Your Light Bar

- Installers are required to have a good understanding of automotive electronic systems and procedures
for proper installation.

- Never stare directly into the LEDs as momentary blindness and/or eye damage may occur.

- Never take any lights through a car wash. Use only water to clean the outer body/lens of your
equipment.

- Never use a pressure washer to clean any STL products. Inspect and test your product daily to insure it
operates properly and is mounted correctly.

- Never cut wires or work on a unit while the unit is still connected to a power source.

- Never install this product or route any wires through or in the deployment area of the airbag. Doing so
may cause serious personal injury as it will damage or reduce the effectiveness of the airbag by causing
the unit to become a projectile. Reference the owner's manual for your vehicle to find the airbag
deployment area. The User/Installer assumes all responsibility to determine proper mounting location,
based on providing ultimate safety to all passengers in the vehicle.

- If the product requires you to drill holes, the installer must ensure that the drilling process does not
damage any vehicle components or other vital parts. Check all sides of the mounting surface before
beginning to drill. Make sure to deburr all drilled holes and remove any metal remnants or shards to avoid
injury and wires from becoming spliced. Grommets are to be installed in all wire passage holes.

- In order for STL products to operate at optimum efficiency, a secure and good electrical connection to
the battery's Ground Post must be made. The recommended procedure requires the unit's ground wire be
connected directly to the NEGATIVE (-) battery post.

- Instruction manuals should be stored in a safe place for reference if you need to reinstall the unit or
perform maintenance. They can also be found at the main site under the product listing at
www.SpeedTechLights.com. If your product is no longer available on the website contact STL's Customer
Service at 800-757-2581 for assistance.

- If your product requires the use of a control box or remote device to turn on and control your
equipment make sure it is installed in a location that allows both the user and the vehicle to operate
safely in any driving condition.

- Never activate or control your equipment in hazardous driving conditions.

3 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

- FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS, WARNINGS, NOTICES, AND INSTRUCTIONS COULD
RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE THAT WILL VOID YOUR WARRANTY AND/OR CAUSE
SERIOUS INJURY TO YOU AND YOUR PASSENGER.

SUMMARY OF THE VIRTUE-1® LINEAR INTERIOR LED DASH LIGHT:

The Virtue-1® Linear Interior LED dash light includes powerful LINEAR optics and 6 3-watt MaxGen™
LEDs with 18 watts per module. This SpeedTech Lights LED dash light puts out an intense flash from
such a small package.

With 11 flash patterns plus a cigarette plug for powering the unit on/off and a pattern changer, its
memory functionality quickly recalls the last pattern used so you can quickly access your preferred
flash patterns with the push of a button.

With several bracket options, mounting this light bar is as simple as it can get with its compact design.
Don’t be fooled by the size of this LED Deck/Dash Lights. Whether in the front, rear or sides of the
vehicle, this little light is an attention getter.

Features:

 Powered by 12V
 Patented LED Eclipse®® Optic Technology - Linear Optics
 6 3-watt MaxGen™ LEDs
 11 available flash patterns
 Non-volatile memory recalls last flash pattern
 Lifespan of up to 100,000 hours
 Includes cigarette plug with On/Off switch and flash pattern toggle switch
 Variety of mounting bracket options available
 Optional removable windshield reflector
 Includes 10 feet of cable
 Dimensions: 5" L x 1.6" H x 2.2" D
 7 day money back guarantee*
 3 Year Warranty (optional 5 Year Warranty upgrade available)*

* See Terms and Conditions for details

4 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Wiring Diagram for power harness with three (3) colored leads: ALL CABLES SHOULD CONTACT TO +VDC
* Indicates a main power cable
Yellow Flash Pattern
*Red Positive
*Black Negative

How the Cigarette Lighter Plug Switch Operates Your STL Light bar

Left On/Off Switch

On Position: Turns on all the LED Modules in your light bar
Off Position: Turns off all the LED Modules in your light bar

Flash Pattern Button

Button cycles to the next flash pattern with each press. Non-Volatile memory recalls the last
flash pattern selected.

Unpacking your STL Product

Unpack your unit to identify all parts including but not limited to: light bar, switch box, brackets,
screws, bolts, wiring harness, fuses, etc.
Some parts may be in small bags.
Some products may be packaged inside boxes of other products.
Some parts such as Gutter Brackets, may be in the foam protection. Double check that no parts
are left within the foam protection or left in the box.

Pre-Installation and Testing

BENCH TEST all units prior to installation by connecting the Positive Cable (Red) and Negative
Cable (Black) to a power source to ensure all the features and parts of the light bar are
functional.

Test Check List:

o All LEDs and LED Modules fully functional
o Flash patterns
o Non-volatile memory
o No physical damage

If you have trouble call Customer Service at 800-757-2581 before proceeding.

5 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Instructions for Mounting, Wiring and Programming

IMPORTANT! To ensure proper installation installers are required to have a good understanding
of automotive electronic, systems and procedures for proper installation. When you are drilling
into the vehicle's surfaces, ensure that the area is free of any electrical wires, vehicle upholstery,
fuel lines, etc. that could be damaged. All wiring passing through drilled holes should use
grommets and silicone sealant to prevent wire or moisture damage when passing through
compartment walls.
WARNING! Larger wires and secure or tight connections will ensure longer service life for your
product. It is highly recommended that soldered connections have heat shrink used to protect
the connection. Special attention should be given to the location and method of splicing wires
to make electrical connections to protect these splices from lost power or connection and
corrosion. Insulation displacement connectors are not to be used. To reduce voltage drop,
minimize the number of splices in the wires. The current carrying capacity of wires and fuses will
be significantly reduced under high ambient temperature (e.g. under the hood). Use SXL type
wire in the engine compartment where higher heat resistance is required according to SAE J-

1128. All wires should be in accordance with the minimum wire size and other recommendations
made by the manufacturer and be protected from hot surfaces and moving parts. Grommets,
cable ties, looms, and other installation hardware should be used to anchor and protect all
wiring. Fuses should be properly sized and located as close to the power take off points as
possible to protect the wiring and device. To protect against short circuits, a fuse is included by
STL for all products. Do NOT use a fuse with a higher amp rating than the initial fuse included.
Do NOT use Circuit Breaks with STL Products. Ground terminations should only be made directly
to the battery.

Mounting
Suction Cup:

 Slide mounting screws down the track in the back of the bar.
 Line up the screws to the appropriate holes in the bracket.
 Secure the bracket using the included nuts.

Surface Mount End Caps:

 Remove end cap from the bar.
 Replace with the surface mount end cap.

6 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Wiring: Connecting Wires to the Battery

 WARNING! If you are supplying your own wiring that connects to the positive or

negative terminal of the battery, fuse sizes must be sized according to STL's
provided fuse to be considered fused properly to the battery in order to carry the
load.

 Route the power cables by opening the wiring shield and running the cables through it

towards your vehicle's firewall.

 Follow the factory wiring harness through the firewall.
 If it is necessary to drill a hole in the firewall for the power cables, be sure no

components will be damaged from drilling. As with all holes that are drilled, file the
edges down smooth and insert a grommet to protect the cables.

 Route the cable along the factory wiring harness towards the battery.
 Wire your power cables (Red with In Line Fuse (STL Supplied) and Black cable) to your

battery to power up your light bar.

 You will want to ensure your grounding cable is taken directly to the negative terminal of

your battery to avoid any electrical feedback which may disrupt your light bar system.

 DO NOT allow the positive (Red wire) and negative (Black wire) to touch one another.

This may cause injury to you and damage your equipment by causing a short in the unit
that is not covered under the STL warranty.

Wiring: Cigarette Lighter Plug

 If you are using the Cigarette Lighter Plug follow the guidelines for Wiring to get the

cables into the vehicle and plug the Cigarette Lighter Plug into your Cigarette outlet.

Wiring: Connecting Wires to Control Box

 This unit will feature a power harness with three (3) colored leads with a connector that

plugs into the Cigarette Lighter Plug.

 When not utilizing the Cigarette Lighter Plug reference the Wiring Diagram for

power harness with three (3) colored leads

 Now that you have pulled the cable into the vehicle attach the connector back to your

light bar's wire harness in the CORRECT positions using a pin pusher and plug it into
your Cigarette Lighter Plug. If you do not know the correct position of each wire in the
connector call customer service at 800-757-2581 before proceeding.

 If you are using your own switch box or the STL IntelliSiren, wire the cables accordingly

into your control panel by referencing the wiring diagram and instruction manual of your
control panel.

7 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Programming Flash Patterns

 All STL LED products are equipped with a non-volatile memory which will recall the last

flash pattern when the light bar is turned on.

 Set your flash pattern by pushing the Flash Pattern button on your Cigarette Lighter Plug

to cycle through the various patterns until you find the appropriate pattern.

 If you are not using the Cigarette Lighter Plug you will follow the wiring diagram to

identify the Flash Pattern wire to manually run through and select the desired flash
pattern.

Maintenance

While STL's light bars are very durable, there are some things you need to keep in mind and
practice to preserve the longevity and function of your bar.

 Never take any STL Light bars through a car wash, such as a pressure washer, automatic

car wash, brushes that will scratch your equipment or similar car washes or equipment
where chemicals, high pressure water, and materials may scratch or damage your
equipment.

 Use Water (H20) with a soft cloth to clean your light bar and lenses.

 Yellowing of clear lenses may occur overtime. Lenses can be purchased by calling STL

Customer Service at 800-757-2581.

Parts List

Mounting Brackets

Warning LED Modules

Printed Circuit Board

Cable Harness

Cigarette Plug with Power and Flash Switches

Trouble Shooting

All Manufacture Defects are covered under the STL Warranty accordingly. Warranty is void with

disassembly or rewiring of STL Products or Improper Wiring or Installation. If you are unsure

how to trouble shoot your light bar for any reason or if the trouble shooting does not fix your

issue, call Customer Service immediately for assistance at 800-757-2581.

8 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

Problem

Warning LED
module has one
or all diodes out

No recall of flash

pattern

Scenarios

Are all the LED

Diodes out?

No

Yes

Is the units power

cables run to the
correct locations:
Positive (red) and

Negative (black),

directly to the

battery?

Possible Cause

If at least one LED diode is
out, the LED Module needs
to be replaced.

Defective PCB
or LED module or cables
disconnected from
Connector or LED.

Trouble Shooting

Call Customer Service to make a warranty claim for a new
LED

1. Make sure the product is disconnected from power.

2. Unscrew the two screws that secure the LED module for
the light bar.

3. Pull the LED out gently and slowly.

4. You will see red and black wires that lead to a connector.

5. Confirm that the wires with pins are in the connectors
(Both male and female connectors) have not come out of
the connectors.

6. If so: use a pin pusher to place the wires back into the
connector.
a. Ensure the wings of the pin are opened to ensure a
proper connection.
b. If closed use tweezers to pull away from the base.
c. A click will be heard when placing the pin back into the
connector.
d. Make sure the pin is seated in the center of its pin
position to ensure proper connection

7. If not: continue reading:

1. Follow steps 1 - 4 to unplug a working module in the
same manner.

2. Plug in the defective module into the working modules
position.
a. If the LED module comes on. You need a new PCB
b. If the LED module does not come on. You need a new
LED module

9 (c) 2016 SpeedTech Lights, Inc.

Pressing buttons

on the Switch

Box but light bar

doesn't respond

at all or for

specific function

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

No

Yes

Does the STL Logo

on the Grand

Control Box light up

when on?

No

Yes

Improper Grounding.

Improper Grounding.

Broken Cigarette Plug

Broken Fuse

Disconnected Connector

Damaged Cable

TEST THE POSSIBLE
CAUSES FOR "No"

Wires in the wrong
location

If grounded incorrectly, an electrical feedback could be the
culprit. Electrical feedback can cause the PCB not to
recognize the command that it is being told to do.
Move the ground to proper location and see if this fixes the
issue.

A New PCB may be required.

If grounded incorrectly, an electrical feedback could be the
culprit. Electrical feedback can cause the PCB not to
recognize the command that it is being told to do.
Move the ground to proper location and see if this fixes the
issue.

Inspect to cigarette plug to make sure there is no damage
or pulled wires from the plug. If so you will need to replace
the Cigarette Plug

If the cigarette plug is not damaged unscrew the cap of the
cigarette plug to gain access to the fuse. Check to see if the
fuse is broken. If do you will need to replace the Fuse.

Check that the connector is fully recessed in the switch box.
If you have an extension cable with connectors check that
the connection has not disconnected.

Check the full length of your wiring to make sure there are
no spliced wired in the cable harness.

TEST THE POSSIBLE CAUSES FOR "No"

You may have a wire that is not in the correct position. If
you are using an extension cable with connectors or no

10 (c) 2016 SpeedTech Lights, Inc.

218 Trademark Dr • Buda • Texas •78610

Phone [phone] • Fax [phone] • Email [e-mail]

connector, make sure that the wires are corresponding

correctly. In other words, simply make sure the colors are
matching one another and that you do not have a Green
connected to a Yellow. Green should be connected to
Green.

Stay Safe and Continue Lighting the Way® with SpeedTech Lights®

We know that Trust is Earned®! Thank you for giving STL the opportunity to earn your business
and trust. Visit www.SpeedTechLights.com for any additional information and services regarding
STL Warranty, Return Policy, Videos, or any other Customer Service needs you deem necessary.
Shop with Confidence® with SpeedTech Lights!

(c) 2016 SpeedTech Lights, Inc.
All rights reserved. No part of this Operations Manual and Instructions may be reproduced, distributed, transmitted, or otherwise
shared in any form or by any means, including but not limited to photocopying, recording, electronic delivery, .pdf reproduction, or
any other means of reproducing all or any part hereof without the express prior written consent of the SpeedTech Lights, Inc., except
for non-commercial purposes as permitted by United States copyright law. Customers of SpeedTech Lights, Inc., may download and
print this Operations Manual and Instructions for use with products sold to the customer by SpeedTech Lights, Inc. However, no part
of the Operations Manual and Instructions may be otherwise or subsequently reproduced, downloaded, disseminated, published, or
transferred, in any form or by any means, except with the prior written consent of SpeedTech Lights, Inc.

11 (c) 2016 SpeedTech Lights, Inc.
