TABLE TENNIS TABLE
MODEL NO.
T8613
O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together. Leave locknuts slightly loose until you are instructed to
tighten them.
Please Do Not Return This Product To The Store!
Contact Escalade® Sports customer service department at:
Phone: 1-866-873-3528 Toll – Free !
Fax: 1-866-873-3533 Toll – Free !
E-mail: tabletennis@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at: www.escaladesports.com
ON-LINE TROUBLE SHOOTING TECHNICAL ASSISTANCE
ON-LINE PARTS REQUESTS FREQUENTLY ASKED QUESTIONS
®
ADDITIONAL ESCALADE
SPORTS PRODUCT INFORMATION
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
2L-5025-01
2009 Es calade
©
®®
Sports
Figure 1
READ AND FOLLOW ALL ASSEMBLY, OPERATING, AND
SAFETY INSTRUCTIONS CAREFULLY. AT LEAST TWO (2)
ADULTS ARE NEEDED TO PUT THIS TABLE TOGETHER!
1. Attach wood bottom board (#25) to caster rails
(#12) as shown in figure 1. Turn caster rail as shown
and attach board (#25) with four thumb screws
(#27). Tighten thumb screws securely.
12
12
25
27
27
2
AT LEAST TWO (2) ADULTS ARE NEEDED TO
COMPLETE THE REST OF THIS ASSEMBLY! WHEN
ASSEMBLING TOPS TO BASE, HANDLE TOP
ASSEMBLIES BY GRASPING ONLY THE TOPS
THEMSELVES. DO NOT GRASP METAL LEGS, USUPPORT, LINKAGE, OR HINGES. THESE PARTS
CAN MOVE AND COULD PINCH FINGERS OR
HANDS CAUSING SERIOUS INJURY! ASSEMBLE
Figure 2
AS SHOWN WITH LEGS FULLY CLOSED AND
TOPS IN A VERTICAL POSITION. DO NOT OPEN
LEGS AND TRY TO ASSEMBLE. TABLE TOPS ARE
HEAVY - DO NOT ATTEMP T TO ASSEMBLE
ALONE!
1
2.
Attach table top (#1) to base assembly that you just
put together as shown in figure 2. Pivot strut tubes up
as shown; then with at least one adult on each side of
table top (#1), lift top and align ends of U-support
tube with tops of strut tubes on caster rails (#12) as
shown in figure 2. Slide tubes together.
Strut
Tube
Strut
Tube
U-Support
Tube
DO NOT OPEN THE TABLE TO PLAYING POSITION
UNTIL BOTH TOPS ARE INSTALLED! DO NOT LEAVE
TABLE STANDING UNATT ENDED. IT COU LD BE
KNOCKED OVER CAUSING SERIOUS BODILY INJURY
OR PROPERTY DAMAGE.
Pivot Tubes Up
12
12
3
3. Attach hinges (#9) to strut tubes as shown in figure
3. With hinge positioned as shown, align hole in
hinge with hole in strut tube and attach with ¼-20 x
2" bolt #28, ¾” spacer #29 and hand knob #30.
Tighten knob securely. Repeat for other hinge.
CAUTION: Hinges must be positioned exactly
as shown or table will not operate correctly
and could be damaged.
4. With two adults, put other table half onto other strut
tubes following instructions in steps 2 and 3.
DO NOT OPEN THE TABLE TO PLAYING POSITION
UNTIL BOTH TOPS ARE INSTALLED! DO NOT LEAVE
TABLE STANDING UNATTENDED. IT COULD BE
KNOCKED OVER CAUSING SERIOUS BODILY INJURY
OR PROPERTY DAMAGE.
5. Attach Corner Protectors (#23) to table corners as
shown in Figure 3. Push snap tabs on Corner
Protectors into holes in rails.
aligned with holes before pushing
aligned with holes before pushingaligned with holes before pushing
Be sure tabs are
Be sure tabs areBe sure tabs are
. You could
break tabs if they are not aligned correctly.
Figure 3
CAUTION: Hinges must be positioned
exactly as shown or table will not operate
correctly and could be damaged.
30
28
9
29
14
23
23
9
28
29
Strut
Tube
30
30
28
9
4
29
OPENING AND CLOSING INSTRUCTIONS
EXERCISE CAUTION IN OPENI NG/CLOSIN G TABLE. SMALL CHILDREN, OR
CHILDREN NOT PROPERLY INSTRUCTED IN ITS USE , MUST NOT BE ALLOWED TO
OPEN/CLOSE TABLE. IMPROPER HANDLING AND MISUSE CAN RESULT IN SERIOUS
INJURY OR DAMAGE. DO NOT CLIMB, STAND, OR JUMP ON TABLE. MOISTURE
AND CONDENSATION WILL DAMAGE PLAYING SURFACE OF THIS TABLE. STORE
IN DRY, INDOOR PLACE.
TO OPEN:
1. Open legs on one table half and lock both leg hinges.
2. Standing at center of table, hold center of top edge with one
hand and U-Support with other hand. Pull U-Support outward
toward you to midway position. Continue to pull top of table
until leg rests on the floor. Do not leave table partially opened
at midway position. See Figure 4.
CAUTION:
6. Secure net posts to center of table and slide net down
over posts. See Figure 6.
NOTE: Net will be tight. It will be necessary to stretch
net. This will insure proper net tension.
Figure 4
3. Open legs of second table half and lock both hinges as with the
first half.
4. Lower second top as described in step 2.
5. Lock all four center hinges. See Figure 5.
PLAYBACK POSITION
Pull leg open and
Midway
Position
lock leg hinges
Center and leg
hinges locked
Safety
Clip
TO CLOSE:
1. Remove net and net posts from
table.
2. Unlock all four center hinges. See
Figure 5.
3. Lift one table half to midpoint until
the leg clips are engaged. Then
continue lifting until closed.
4. Unlock leg hinges on this half and
fold legs against top.
5. Raise other table half in the same
manner.
Figure 6
STORAGE
POSITION
Figure 7
Figure 5
Leg hinges
locked
Push to
lock hinge
PLAYING POSITION
Pull to
lock hinge
5
