Page 1
STIGA PARK
PRO 20
PRO 16
ROYAL
PRESIDENT
COMFORT
8211-0276-05
Page 2
19
PARK
18
1.
6
4
3
3.
2.
15
5
1
Page 3
PARK
7
4. President - Comfort
13
7
14
14
15
11
9
11
8
9
16
7
5. Royal
13
7
14
15
14
15
11
8
9
16
8
9
12
16
2
18
17
6. Pro 16 7. Pro 20
8.
9.
Page 4
PARK
10.
12.
14. Pro 16 - Pro 20
11. Briggs & Stratton Honda
13.Royal
15. President - Comfort
16. Royal
17. Pro 16 - Pro 20
Page 5
PARK
0.75 mm
18. Pro 20 Cat
20.
MAX
22.
19.
21.
23a. President - Comfort - Royal
23b. Pro 16 - Pro 20
24. President - Comfort - Royal
Page 6
ENGLISH
GB
GENERAL
This symbol indicates WARNING. Personal injury and/or damage to property
may result if the instructions are not
followed carefully.
You must read these instructions for
use and the accompanying pamphlet
“SAFETY INSTRUCTIONS” carefully, before starting up the machine.
SYMBOLS
The following symbols appear on the machine.
They are there to remind you of the care and attention required in use.
This is what the symbols mean:
Warning!
Read the instruction manual and the safety
manual before using the machine.
Warning!
Watch out for discarded objects. Keep onlookers away.
Warning!
Always wear hearing protectors.
Warning!
This machine is not designed to be driven
on public roads.
Warning!
The machine, equipped with original accessories, must not be driven in any direction on slopes with a gradient greater than
10º.
Warning!
Risk of crushing injuries. Keep hands and
feet well away from the articulated steering joint.
Warning!
Risk of burn injuries. Do not touch the silencer/catalytic converter.
CONTROLS AND
INSTRUMENTS
Items 1 - 19, see figures 1 - 7.
1. IMPLEMENT LIFTER
(President - Comfort - Royal - Pro16)
A pedal for raising front-mounted implement to
the transport position.
To lift up the implement, press the pedal down as
far as it will go. Then release the pedal, the implement lifter is now locked in the raised position.
To lower the implement, press the pedal down so
that the lock is released. Lower the implement lifter to the working position by slowly lifting your
foot from the pedal.
2. HYDRAULIC LIFTER (Pro20)
Hydraulic implement lifter for raising frontmounted implements to the transport position.
To raise the implement, press the rear
part of the switch. Release the switch
in the required position.
To lower the accessory, press the
front part of the switch. The switch
stays in the pressed position and the
implement lifter is lowered until it
reaches a floating position. This
means that the implement can follow
the contours of the ground.
The floating position, with the switch in the tilted
forward position, is recommended for normal use.
To secure the implement lifter, place the switch in
neutral.
NOTE! The hydraulic implement lifter must be
in floating position in order for the power takeoff to be connected.
3. SERVICE BRAKE
A pedal that acts on the machine’s braking system.
There are 3 positions:
1. Pedal released – service brake
not activated.
2. Pedal depressed halfway –
forward drive disengaged. Service brake not activated.
3. Pedal fully depressed – forward drive disengaged. Service
brake fully activated.
4. PARKING BRAKE
An inhibitor that can lock the brake pedal in the de-
Page 7
GB
ENGLISH
pressed position.
Depress the brake pedal fully. Move the
inhibitor to the right and then release the
brake pedal.
The parking brake is released by pressing the brake
pedal. The spring-loaded inhibitor slides to one
side.
Make sure that the parking brake is released when
operating the machine.
5. DRIVE PEDAL
A pedal that activates the variable transmission.
1. Depress the pedal with the
ball of your foot – the machine
moves forwards.
2. No load on the pedal – the machine is stationary.
3. Depress the pedal with your
heel – the machine reverses.
The drive pedal regulates the speed. The more
pressure applied, the faster the machine will move.
6. ADJUSTABLE STEERING WHEEL
The height of the steering wheel is infinitely adjustable. Undo the adjustment knob on the steering
column and raise or lower the steering wheel to the
desired position. Tighten.
Do not adjust the steering wheel during operation.
7. THROTTLE/CHOKE CONTROL
A control for setting the engine speed and to choke
the engine when starting from cold. (The latter
does not apply to Royal-Pro16-Pro20 which have
separate choke control – see item 8).
1. Choke – for starting a cold engine. The
choke is located in top of groove (does not
apply to Royal-Pro16-Pro20). Avoid operating the machine in this position, taking
care to move the control to full throttle
(see below) when the engine is warm.
2. Full throttle – when the machine is in
operation, full throttle should always be
used.
3. Idling.
8. CHOKE CONTROL
(Royal - Pro16 - Pro20)
A pull-type control to choke the engine when starting from cold.
1. Control fully pulled out – choke valve
in carburettor closed. For starting cold engine.
2. Control pushed in – choke valve open.
For starting warm engine and when operating the machine.
Never operate the machine with the choke
pulled out when the engine is warm.
9. IGNITION LOCK/SPOTLIGHT
Ignition lock used for starting/stopping the engine.
Also includes switch for spotlight (Senator does
not have a spotlight). Four positions:
1. Stop position – the engine is shortcircuited. The key can be removed.
2. Operating position – spotlight activated.
3. Operating position – spotlight not activated.
4. Start position – the electric start motor
is activated when the key is turned to the
spring-loaded start position. Once the engine has started, let the key return to operating position 3.
To turn on the spotlight, turn the key to position 2.
NOTE! If the key is turned from the stop position to operating position 2, the spotlight is activated. This uses up battery power. Do not leave
the machine with the key in position 2 (applies
to Pro16-Pro20).
10. POWER TAKE-OFF
A lever for engaging and disengaging the power
take-off for operating front-mounted accessories.
Two positions:
1. Lever in forward position – power takeoff disengaged.
Page 8
ENGLISH
GB
2. Lever in backward position - power
take-off engaged.
11. POWER TAKE-OFF (Pro20)
Switch for engaging/disengaging the electromagnetic power take-off for operating front-mounted
accessories. Two positions:
1. Press the front part of the switch – the
power take-off is engaged. The symbol
will light up.
2. Press the rear part of the switch – the
power take-off is disengaged.
12. DIFFERENTIAL INHIBITOR
(Pro16 - Pro20)
Lever for engaging the differential inhibitor. This
improves the towing capacity by locking the rear
wheels so that both wheels drive simultaneously.
Two positions:
1. Forward position – the differential inhibitor is not engaged. For normal operation.
2. Lever in backward position - differential inhibitor engaged. Works for both forward and reverse drive.
The differential inhibitor is of greatest use when
the rear wheels are unevenly loaded. For example
when turning sharp corners where the inner rear
wheel bears a lesser load.
When driving during the winter on slippery surfaces, the drive capacity is improved if snow chains
are not used.
When the differential inhibitor is engaged, the
steering is heavy. Avoid turning the steering
wheel!
13. HOUR COUNTER
Indicates the number of working hours. Only
works when the engine is running.
14. CRUISE CONTROL
(Royal - Pro16 - Pro20)
A switch for activating the cruise control. The
cruise control allows the drive pedal (5) to be
locked in the desired position.
1. Press down the drive pedal until the desired speed is obtained. Then press the
front part of the switch to activate the
cruise control. The symbol will light up.
2. Disengage the cruise control by braking
or pressing the rear part of the switch.
15. CUTTING HEIGHT ADJUSTMENT
(Royal - Pro16 - Pro20)
The machine is equipped with a control for using
the cutting deck with electrical cutting height adjustment (available as an accessory).
The switch is used to adjust the cutting
height in continuously variable positions.
The contact used for connecting the cutting deck is
mounted on the right side, in front of the front
wheel (fig. 2).
16. REAR RAKE (Pro20)
The machine is fitted with a control for electrical
adjustment of a rear rake (available as an accessory).
The switch is used to raise and lower the
rear rake.
Cables for connecting the rear rake are found at the
rear of the machine, to the left of the upper side of
the bumper. (Pro16 is prepared for a rear rake, cables routed).
17. SAND SPREADER (Pro20)
The machine has been designed for electrical adjustment of a sand spreader (available as an accessory).
The switch is used to start and stop the
12V
spreader.
The contact for connecting the sand spreader is
found at the rear of the machine, to the left of the
upper side of the bumper. (Pro16 is prepared for a
sand spreader, cables routed).
18. DISENGAGING LEVER
A lever for disengaging the variable transmission.
Enables the machine to be moved by hand without
the help of the engine. Two positions:
Page 9
GB
ENGLISH
1. Lever moved back – transmission engaged for normal operation.
2. Lever moved forward – transmission disengaged. The machine can be moved by hand.
The machine may not be towed over long distances
or at high speeds. The transmission could be damaged.
19. FUEL GAUGE/FUEL CAP
Fuel cap with built-in fuel gauge that indicates how much fuel there is in the fuel
tank (applies to Royal-Pro16-Pro20).
Comfort and President have a fuel cap without a
fuel gauge.
The fuel tank holds approx. 11.5 litres.
AREAS OF USE
The machine may only be used for the following
tasks using the genuine STIGA accessories stated.
1. Mowing
Using cutting deck 13-2939 (92M), 13-2927/
13-2935 (107M), 13-2951/13-2952 (107 M
HD), 13-2915/13-2921 (121M), 13-2936/132937 (125 Combi Pro) or flail mower 13-1977.
2. Sweeping
Using brush unit 13-1933 or collector brush
unit 13-1939. Use of dust guard 13-1936 is recommended with the first option.
3. Snow clearance
Using snow blade 13-0918 or snow thrower 13-
1948. Snow chains 13-0936 (16“)/13-0937
(17“) and frame weights 13-0923 are recommended.
4. Grass clipping and leaf collection
Using towed collector 13-1978 (30") or 131950 (42").
5. Grass and leaf transport
Using dump cart 13-1979 (Standard), 13-1988
(Maxi) or 13-1992 (Combi).
6. Sand spreading
Using sand spreader 13-1975. Can also be used
for spreading salt. Snow chains 13-0936 (16“)
13-0937 (17“) and frame weights 13-0923 recommended.
7. Weeding on gravel paths
Using front mounted hoe 13-1944 and rearmounted rake 13-1969.
8. Lawn edge trimming
Using edge trimmer 13-0905.
9. Moss scarification
Using moss scarifier 13-1984.
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing hitch
from towed accessories must not exceed 500 N.
NOTE! Before using a trailer – contact your insurance company.
NOTE! This machine is not intended to be driven
on public roads.
STARTING AND OPERATION
ENGINE CASING
To inspect and maintain the engine and battery, remove the engine casing. Dismantling:
1. Unscrew the fuel cap/fuel gauge.
2. Pull up the rubber strap at the front edge of the
casing (fig. 8).
3. Carefully lift off the engine casing (fig. 9).
Assembly:
1. Place the casing over the lip on each side.
2. Make sure that the pins on the rear edge of the
casing go down into the respective holes (fig.
10).
3. Secure the front edge of the casing with the rubber strap (fig. 8).
4. Finally, screw in the fuel cap/fuel gauge.
The machine may not be operated unless the engine casing is mounted. Risk
of burns and crushing injuries.
FILLING THE FUEL TANK
Always use lead-free petrol. You must never use 2stroke petrol mixed with oil.
Page 10
ENGLISH
GB
NOTE! Bear in mind that ordinary lead-free petrol
is a perishable; do not purchase more petrol than
can be used within thirty days.
Environmental petrol can be used, i.e. alkylate petrol. This type of petrol has a composition that is
less harmful for people and nature.
Petrol is highly inflammable. Always
store fuel in containers that are made
especially for this purpose.
Only fill or top up with petrol outdoors,
and never smoke when filling or topping up. Fill with fuel before starting
the engine. Never remove the filler cap
or fill with petrol while the engine is
running or still warm.
Never completely fill the petrol tank. Leave an
empty space (= at least the entire filler tube plus 1
- 2 cm at the top of the tank) to allow the petrol to
expand when it warms up without overflowing
(fig. 28).
CHECKING THE ENGINE OIL LEVEL
(President - Comfort - Pro16 - Pro20)
On delivery, the crankcase is filled with SAE 30
oil.
Check the oil level every time before using to
ensure it is correct. The machine should be
standing on level ground.
Wipe clean around the oil dipstick. Unscrew and pull it up. Wipe off the dipstick.
Slide it down completely and tighten it.
Then unscrew it and pull it up again. Read off the
oil level. Top up with oil to the “FULL“ mark, if
the level comes below it (figs. 11).
CHECKING THE ENGINE OIL LEVEL
(Royal)
On delivery, the crankcase is filled with SAE
10W-40 oil.
Check the oil level every time before using to
ensure it is correct. The machine should be
standing on level ground.
Wipe clean around the oil dipstick. Unscrew and pull it up. Wipe off the dipstick.
Slide it down completely without tighten-
ing it.
Pull it up again and read off the oil level. Top up
with oil to the “UPPER” mark, if the oil level is be-
low it (fig. 11).
CHECKING THE TRANSMISSION
OIL LEVEL
The transmission is filled with SAE 10W-40 oil
when the machine is delivered from the factory,
Check the oil level every time before using to
ensure it is correct. The machine should be
standing on level ground.
Read off the oil level in the reservoir (fig. 23). It
should be between the “MAX” and “MIN” marks.
If necessary, top up with more oil. Use oil SAE
10W-40 (20W-50).
SAFETY SYSTEM
This machine is equipped with a safety system that
consists of:
- a switch at the brake pedal.
- a switch in the seat (Comfort, President) or the
seat bracket (other models).
- a switch at the power take-off engagement lever.
In order to start the machine, the following are necessary:
- brake pedal pressed down.
- driver sitting on seat.
- power take-off engagement lever in forward position (i.e. power take-off disengaged).
Always check the operation of the safety system before using the machine!
With the engine running and the driver sitting on
the seat, check as follows:
- press the drive pedal so that the machine starts
to move, release the drive pedal – the machine
must stop.
- press the drive pedal so that the machine starts
to move, engage the cruise control, lift your
weight off the seat – the machine must stop (applies to Royal, Pro16, Pro20).
- press the drive pedal so that the machine starts
to move, engage the cruise control, press the
brake pedal – the machine must stop (applies to
Royal, Pro16, Pro20).
- engage the power take-off, lift your weight off
the seat – the engine must stop (applies to Comfort, President, Royal, Pro16).
- engage the power take-off, lift your weight off
the seat – the power take-off must be disengaged (applies to Pro20).
Page 11
GB
ENGLISH
Do not use the machine if the safety system is not working! Take the machine
to a service workshop for inspection!
STARTING ENGINE
1. Open the fuel cock (fig. 12).
2. Make sure that the spark plug cable is properly
in place.
3. Check to make sure that the power take-off is
disengaged.
4. Do not keep your foot on the drive pedal.
5a. Comfort-President:
Starting cold engine – put the throttle control in the
choke position. Starting warm engine – put the
throttle control at full throttle (approx. 1 cm behind
the choke position).
5b. Royal-Pro16-Pro20:
Put the throttle control at full throttle. Starting cold
engine – pull the choke control out fully. Starting
warm engine – do not touch the choke control.
6. Depress the brake pedal fully.
7. Turn the ignition key and start the engine.
8a. Comfort-President:
Once the engine has started, move the throttle control gradually to full throttle if the choke has been
used.
8b. Royal-Pro16-Pro20:
Once the engine has started, push the choke control
in gradually if it has been used.
9. When starting from cold, do not make the machine work under load immediately, but let the engine run for a few minutes first. This will allow the
oil to warm up.
When in use, always operate the engine at full
throttle.
STOPPING
Disengage the power take-off. Apply the parking
brake.
Allow the engine to idle 1 - 2 mins. Stop the engine
by turning off the starter key.
Shut off the petrol cock. This is particularly important if the machine is to be transported on a trailer
for example.
If the machine is left unattended, remove the spark plug cable from the
spark plug. Also remove the starter key.
The engine may be very warm immediately after it is shut off. Do not touch the
silencer, cylinder or cooling fins. This
can cause burn injuries.
CATALYTIC CONVERTER
(Pro20 Cat)
The catalytic converter gets very hot during operation. The heat remains for a long time after the engine has been stopped. Be aware of the fire risk.
Do not park in close proximity to inflammable objects. Do not cover the
machine until the catalytic converter
has cooled down.
STEERING AID (Pro20)
Built-in function in order to facilitate steering. The
operator only has to turn the steering wheel gently.
A hydraulic torque amplifier creates the remaining
force.
As opposed to normal servo steering (e.g. in a car),
the steering aid has a limited capacity. This means
that it has some characteristics that might be considered negative:
- at a low engine rpm or in situations where extra
steering force is needed, steering can be considered to be “jumpy”.
- the machine should always be moving when the
steering is used. Avoid turning the steering
wheel when the machine is standing completely
still and the accessory is in the lowered working
position.
The steering is adapted in order to produce better
results at a normal working speed. This produces
major benefits.
Even when the engine is not running, the steering
works. However, it is harder to turn in this case, if
the machine is to be manoeuvred manually.
DRIVING TIPS
Make sure that there is the correct quantity of oil in
the engine when driving on slopes (oil level on
“FULL”).
Page 12
ENGLISH
GB
Be careful when driving on slopes. No
sudden starting or stopping when moving up or down a slope. Never drive
across a slope. Move from the top down,
and from the bottom to the top.
The machine, equipped with original
accessories, may not be driven on slopes
greater than 10º in any direction.
Reduce the speed on slopes and when
making sharp turns to prevent the machine from tipping over or you losing
control of the machine.
Do not turn the steering wheel to full
lock when driving in top gear and at full
throttle. The machine can easily topple
over.
Keep hands and fingers well away from
articulated steering joint and seat
bracket. Risk of crushing injuries. Never operate the machine without the engine casing.
SERVICE AND MAINTENANCE
SERVICE PROGRAM
In order to keep the machine in good condition, as
regards reliability and operational safety as well as
from an environmental perspective, STIGA’s service program should be followed.
The contents of this program can be found in the
attached service log.
We recommend that an authorised workshop carries out every service. This guarantees that the
work is performed by trained personnel and with
genuine spare parts.
At every service, the service log should be
stamped. A “fully stamped” service log is a valuable document that improves the machine’s secondhand value.
PREPARATIONS
Unless otherwise stated, all service and maintenance must be carried out on a stationary machine
when the engine is not running.
Prevent the machine from rolling by always applying the parking brake.
Prevent unintentional starting of the
engine by always stopping the engine,
disconnecting the spark plug cable
from the spark plug and earthing it.
Disconnect the negative cable from the
battery.
CLEANING
To reduce the risk of fire, keep the engine, silencer/catalytic converter, battery and fuel tank free from grass,
leaves and oil.
To reduce the risk of fire, regularly
check the machine for oil and/or fuel
leakage.
When washing the machine with water under high
pressure, do not point the jet directly at the transmission.
Do not point jets of water directly at the engine.
Use a brush or compressed air in order to clean it.
ENGINE OIL
(President - Comfort - Pro16 - Pro20)
Change the oil for the first time after 5 hours running, and then after every 50 hours running or once
a season. Change oil when the engine is warm.
Always use a good grade of oil (service grade SF,
SG or SH).
Change the oil more often (after 25 hours of operation or at least once a season) if the engine has to
operate under demanding conditions or if the ambient temperature is high.
The engine oil may be very hot if it is
drained off directly after the engine is
shut off. So allow the engine to cool a
few minutes before draining the oil.
1. Oil drain pipe (metal):
Unscrew the oil drain plug at the end of the pipe.
Collect the oil in a collection vessel. Then take
the oil to a recycling station. Do not allow oil to
get on the V-belts.
2. Screw in the oil drain plug. Make sure that the
fibre gasket and the O-ring inside the plug are not
damaged and that they are in the correct place.
3. Remove the dipstick and fill up with new oil.
Oil capacity:
Comfort, President - 1.4 l
Page 13
GB
ENGLISH
Pro16, Pro20 - 1.7 l (incl. oil filter)
Oil type, summer (> 4ºC): SAE-30
(SAE 10W-30 can also be used. However, oil consumption may increase somewhat if 10W-30 is
used. Therefore, check the oil level more regularly
if you use this type of oil).
Oil type, winter (< 4ºC): SAE 5W-30
(if this oil is not available, use SAE 10W-30).
Use oil without any additives.
Do not fill with too much oil. This can cause the
engine to overheat.
After filling up the oil, start the engine and idle for
30 seconds. Stop the engine. Wait for 30 seconds
and then check the oil level.
Check to see if there is any oil leakage. If necessary, fill up the oil up to the “FULL“ mark.
ENGINE OIL (Royal)
Change the oil for the first time after 20 hours of
operation (or during the first month), and then after
every 100 hours of operation or once every 6
months.
Change oil when the engine is warm. Always use
a good grade of oil (service grade SF, SG or SH).
The engine oil may be very hot if it is
drained off directly after the engine is
shut off. So allow the engine to cool a
few minutes before draining the oil.
Unscrew the oil drain plug at the end of the pipe
(fig. 13).
Collect the oil in a collection vessel. Then take
the oil to a recycling station. Do not allow oil to
get on the V-belts.
Screw in the oil drain plug. Make sure that the fibre
gasket and the O-ring inside the plug are not damaged and that they are in the correct place.
Remove the dipstick and fill up with new oil up to
the “UPPER” mark.
Oil capacity:
Royal - 0.9 l (= oil quantity at change. In total the
engine holds 1.15 l).
Oil type for all seasons: SAE 10W-40.
For extremely low temperatures (< -20° C), use
SAE 5W-30.
Use oil without any additives.
Do not fill with too much oil. This can cause the
engine to overheat.
OIL FILTER – ENGINE
(Pro16 - Pro20)
Replace the oil filter after every 100 hours of operation or once a season.
Before screwing the new filter, oil the filter gasket
with engine oil.
Screw the filter by hand, until the filter gasket
touches the filter attachment. Then tighten ½ to ¾
of a full turn (fig. 14).
Start the engine and idle to see if any leakage occurs. Stop the engine. Check the oil level. If necessary, fill up the oil up to the “FULL” mark.
AIR FILTER - ENGINE
Comfort - President - Pro16 - Pro20:
Clean the foam pre-filter every 3 months or after
every 25 hours of operation, whichever comes
first.
Clean the paper filter insert once a year or after
every 100 hours of operation, whichever comes
first.
Royal:
Clean the air filter every 3 months or after every 50
hours of operation, whichever comes first.
Clean the paper filter insert once a year or after
every 200 hours of operation, whichever comes
first.
All models:
Note! Both filters should be cleaned more often if
the machine operates on dusty ground.
1. Remove the protective cover of the air filter (fig.
15 - 17).
2. Dismantle the paper filter insert and the foam
pre-filter. Make sure that no dirt gets into the carburettor. Clean the air filter housing.
3a. Pro 16, Pro 20:
Wash the pre-filter in liquid detergent and water.
Squeeze dry. Pour a little oil on the filter and
squeeze in the oil.
3b. President, Comfort:
Replace the pre-filter once a year or after every 25
hours of operation, whichever comes first.
4. Clean the paper filter insert as follows: Knock it
lightly against a flat surface. If the filter is very
Page 14
ENGLISH
GB
dirty, change it.
5. Assemble in the reverse order.
Petroleum-based solvents such as kerosene may
not be used for cleaning the paper filter insert.
These solvents can destroy the filter.
Do not use compressed air for cleaning the paper
filter insert. The paper filter insert must not be
oiled.
AIR FILTER – CATALYTIC
CONVERTER (Pro20 Cat)
Clean the catalytic converter’s air filter every 3
months or after every 25 hours of operation,
whichever comes first.
1. Remove the cover by pressing in the locking
mechanism with a screwdriver etc. (fig. 18).
2. Remove the foam filter and wash it in liquid detergent and water. Squeeze dry. Do not oil the filter.
3. Replace the filter and snap the cover into place.
SPARK PLUG
Only use a Briggs & Stratton sparking tester to
check the spark in the sparking plug(s) (fig. 19).
Clean the spark plug after every 100 hours of operation or once a season. For replacing a spark plug,
a spark plug sleeve A and a torsion pin B are provided in the accessories bag.
The engine manufacturer recommends:
Royal: NGK BPR5ES or DENSO W16EPR-U
President-Comfort-Pro16-Pro20: Champion
RC12YC
Correct spark gap: 0.75 mm.
COOLING AIR INTAKE - ENGINE
The engine is air-cooled. A blocked cooling system can damage the engine. The engine should be
cleaned at least once a year or every 100 hours of
operation.
Remove the fan casing. Clean the cooling fins on
the cylinder, the fan and the rotating protective
grille. Clean more frequently if mowing dry grass.
BATTERY
The battery is a valve-regulated battery with 12 V
nominal voltage. The battery is completely maintenance free. You don’t have to check or top up the
electrolyte level.
On delivery, the battery is in the accessories box.
The battery must be fully charged before being used for the first time. The
battery should always be stored fully
charged. If the battery is stored while
totally flat it could sustain permanent
damage.
If the machine is not going to be used for an extended period (more than 1 month), the battery
should be charged, disconnected and then stored in
a cool, safe place. Charge the battery completely
before reinstalling.
The battery can be charged in two ways:
1. Via a battery charger (recommended). This must
be a charger with constant voltage. The battery
can be damaged if a standard type battery
charger (for acid batteries) is used.
Stiga recommends battery charger with item no.
1136-0602-01 which may be ordered by an authorised dealer.
2. You can also allow the engine to charge the battery. In this case it is very important, above all
when starting the machine for the first time and
when it has not been used for a long time, to allow the engine to run continuously for at least
45 minutes.
Do not short circuit the battery’s terminals. Sparks occur which can result in
fire. Do not wear metal jewellery which
can come into contact with the battery
terminals.
In the event of damage to the battery
casing, cover, terminals or interference
to the strip covering the valves, the battery should be replaced.
If the battery terminals are coated with oxide, they
should be cleaned. Clean the battery terminals with
a wire brush and grease them.
LUBRICATION
The machine’s articulated steering joint has four
grease nipples that should be lubricated with universal grease after every 25 hours of operation (fig.
20).
Note: The fourth grease nipple is not shown on the
picture. It is located on the underside, on the flexible axle’s front bearing.
Page 15
GB
ENGLISH
Comfort-President-Royal:
Lubricate the steering chain with chain spray a
couple of times per season.
Pro16-Pro20:
Lubricate the steering chains with chain spray a
couple of times per season. If the steering chains
are really dirty, dismantle them, wash them and
then grease them once more.
Comfort-President-Royal:
The front wheel hub has grease nipples that should
be lubricated after every 50 hours of operation (fig.
24).
Apply universal grease to all the plastic bearings a
couple of times per season.
Apply a coating of engine oil to the tension arm
joints a couple of times each season.
Apply a few drops of engine oil to both ends of the
throttle control cables a couple of times a season.
The hydrostatic transmission is filled with oil
(10W-40) on delivery from the factory. Unless it is
opened (only to be performed by a specialist), and
provided no leakage occurs, no topping up with oil
should normally be carried out. Transmission oil
does not normally need to be changed.
STEERING CABLES
(President - Comfort - Royal)
The steering cables should be adjusted for the first
time after the machine has been in operation for 2
- 3 hours, and then after every 25 hours of operation.
Put the machine in the straight-ahead position.
Tension the steering cables by tightening the nuts
that are located on the underside of the articulated
steering joint (fig. 21). The screws in the ends of
the cables should be held firmly during adjustment
so that the cables are not twisted. Use an adjustable
wrench or similar for this purpose, inserting it in
the key handles in the ends of the screws. Tension
until all play is removed.
Adjust both the nuts the same amount to ensure
that the alignment of the steering wheel is not
changed.
Once the adjustment is complete, turn the steering
wheel as far as it will go in either direction. Check
that the chain does not come into contact with the
pulley, and that the cables do not become entangled with the steering pinions.
Do not tension the steering cables too hard. Otherwise the steering will be heavy and wear and tear
on the cables will increase.
STEERING CHAINS (Pro16 - Pro20)
The steering chains should be adjusted for the first
time after the machine has been in operation for 2
- 3 hours, and then after every 50 hours of opera-
tion.
Put the machine in the straight-ahead position.
Tension the steering chains by tightening up the
nuts that are located on the underside of the articulated steering joint (fig. 21). Tension until all play
is removed.
Adjust both the nuts the same amount to ensure
that the alignment of the steering wheel is not
changed.
Do not over-tighten the steering chains. This will
cause the steering to become heavy and will increase wear on the steering chains.
PATENT - DESIGN
REGISTRATION
This machine or parts thereof is covered by the following patent and design registration:
9900627-2 (SE), SE00/00250 (PCT), 9901091-0
(SE), SE00/00577 (PCT), 9901730-3 (SE), SE00/
00895 (PCT), 9401745-6 (SE), SE95/00525
(PCT), 595 7497 (US), 95920332.4 (EPC).
99 1095 (SE), 499 11 740.9 (DE), M1990 000734
(IT), 577 251-253 (FR), 115325 (US).
GGP reserves the right to make alterations to the product
without prior notification.
Page 16
www.stiga.com
GGP Sweden AB · Box 1006 · SE-573 28 TRANÅS
Loading...
