Stiga PARK PRESTIGE 4WD, 13-6185-14 Specifications
March 13, 2008
www.stiga.com
Park Prestige 4WD
13-6185-14
PARK
PARK PRESTIGE 4WD
Articulated steering is the secret. You sit above the pivot point
och watch over the cutting deck ahead. It is easy to turn and easy
to navigate around bushes, trees and fences. The back wheels follow the track of those up front. Test drive and experience the
incredible feeling of freedom! Combined with 4WD you can stop
and go without slipping even on slippery slopes and snowcovered
driveways.
The front mounted deck is easy to use, clean and maintain. There
is a full range of Combi decks with Multiclip and rear discharge
between 95 cm to 110 cm to choose from. The Multiclip system
cuts and fertilises the lawn at the same time. No need for raking
or emptying a collector.
This fron t mo wer comes with a lot of features. Hydr ostatic speed
control, high comfort seat adjustable with one hand grip, adjustable steering wheel, hour meter, headlight, electric cutting height
adjustment and mechanical servo steering. The cutting deck can
be angled into cleaning position without removing the V-belt.
Choose from a ling list of implements. You can easily change from
a cutting deck, sweeper or edge cutter to a snow blade or snow
thrower. Equipped with the patented quick connection for accessories.
Park Prestige 4WD (13-6185-14)
ENGINE
Brand Kohler Courage
Power 18 hp SV540
Cylinders 1 cyl
FUEL
Type of fuel Petrol
Tank volume 12 l
SPEED CONTROL
Type of transmission Hydrostatic KTM 7
Number of gears Infinitely variable 0-10 km/h + R
STEERING
Type of steering Genuine articulated steering
Servo assisted steering Mechanical
Adjustable steering wheel Yes
Articulated steering through chain/chain Yes
WHEELS
Type of wheels Stiga special lawn tyre tread
Wheel size Front and rear 16 inches, wide
Tyre pressure Front 0,6 bar. Rear 0,4 bar
Driving Four wheel drive
CUTTING INFORMATION
Type of cutting system Front cutting Combi deck
Cutting heights 25-85 mm in 10 steps
Cutting width 95-110 cm
Cutting height adjustment Electric with 95 Combi El, 105 Combi El and 110 Combi Pro
El
VIBRATIONS & SOUND LEVELS
Synchronized belt On 95-105 Combi
Free rotating blades On 110 Combi Pro
CONTROLS
Deck connection Quick connection
Deck lift Foot controlled
Electric starter Yes
Head light Yes
Hour meter Yes
Gear lever Foot pedal
Choke Separate
COLOUR & MATERIA L
Colour Yellow / Grey
Material of chassis Steel
MEASURES & WEIGHT
Weight 218 kg excl. cut ting deck
Gross weight 258 kg excl. cutting deck
Package size WxHxL 92x101x202 cm
Largest measures WxHxL 130x125x245 cm with deck
SEAT
Type of seat Comfort seat with high back support
Seat adjustable horizontally One hand grip
OTHER FACTS
CE-mark Yes
Instructions for use 8211-0003-80
EAN bar code 7 313 321 303 624
