Estate Senator
13-2531-11
ESTATE
ESTATE SENATOR
• For those who prefer to gather-up grass clippings.
•Cutsthelawnmorethantwiceasfastasanormallawnmower.
The rear mounted grass box holds 250 litres and can be emptied
without the driver leaving the driving seat. A signal indicates when
the grass box is full and ready for emptying.
The Stiga Estate Senator is comfortable to drive, has a small turning circle and cuts close on both sides.
• 92 cm floating cutting deck with central cutting heigth adjustment. There are 7 cutting heigths from 30 - 80 mm.
• Reliable, 13.5 hp B riggs & Stratton Diamond I/C engine with
electric start. The petrol tank holds 5.5 litres. All controls are
located on an instrument panel. Removable starting key.
• Mechanical gearbox with five forward and reverse gears. Brake
pedal and parking hand brake.
• Accessories: tow-bar, deflector for cutting high grass without a
collection box and front weight.
Estate Senator (13-2531-11)
MOTOR
Brand Briggs & Stratton
Power 13,5hpI/CDiamond
Cylinders 1 - cyl.
Speed 2,2 - 9,7 km/h
Safety brake Yes
Battery 12 V /18 Ah
FUEL
Type of fuel Petrol
Tank volume 5,5 l
SPEED C O NTROL
Type of transmission Transaxle
Number of gears 5 + R
STEERING
Type of steering Front wheel steering
WHEELS
Type of wheels Lawn tyre tread
Wheel size Front 13'Rear18'''
Bearings Plain
Tyre pressure Front 1,5 bar. Rear 1,2 bar.
Driving Rearwheel drive
CUTTING SYSTEM
Type of cutting system Rear discharge
Cutting heights 30 - 80 mm in 7 steps
Cutting width 92 cm
Cutting height adjustment Central
CONTROLS
Electric starter Yes
Head light Yes
Gear lever Hand Control
MEASURES & WEIGH T
Weight 182 kg
Gross weight 224 kg
Package size W*H*L 99 x 105 x 190 cm
Type of package Carton on wooden pallet
Units on pallet 1
Largest measures W*H*L 96 x 109 x 219 cm
SEAT
Type of seat Comfort seat
Seat adjustable horizontally Yes
OTHER FACTS
CE-mark Yes
EAN bar code 731 332 130 145 3
Other GS-mark
