ADA
Compliant
Stopper Station Series
SS-2002F Push Buttons
Key-to-Reset
We protect the things that protect you.
Installation and Service Instructions
STOPPER STATION SERIES SS-2002F PUSH BUTTON
SAFETY NOTICE TO INSTALLERS AND USERS
This push button has been tested according to UL38 and UL2017. Manual fire alarm stations are
listed in UL category UNIU and non-fire alarm initiating devices are listed in UL category UEHX. It
is important to read, understand and follow all instructions provided with this product. It is the
installer’s responsibility to comply with NFPA72 and 101, NEC, mounting specifications according
to ADA and other applicable fire and electrical codes. After installation and testing are complete,
provide a copy of this manual to all personnel responsible for testing and maintenance of this
product. To avoid electrical shock, DO NOT attempt to install this product when power is on. For
outdoor usage, STI-6525 or STI-6535 Mini Weather Stopper Cover is required.
I. GENERAL
Product Dimensions See page 7
Switch Rating 2 Form C contacts
125/250 VAC, 10 A, 1/2 HP
30 VDC, 6 A
II. CONTENTS LIST
QTY. DESCRIPTION
1 Push Button Housing Assembly
1 18061 Reset Key
1 19001 Allen Head Screw #8-32 x 3/8 in.
1 19015 Allen Wrench 3/32 in.
4 19068 Screw 3.5mm x 13mm
2 19060 Screw #6-32 x 1 in.
1 19021 Ground Screw
4 19039 #6 x 1 1/4 in. SS SMS
4 19018 Plastic Screw Anchor
1 71100A Surface Backbox
III. INSTRUCTIONS
Housing Removal ...................................................................... Page 2
Backbox Preparation ................................................................ Page 3
Wire Connections ...................................................................... Page 4
Installation ................................................................................ Page 5
Key Reset Procedure.................................................................. Page 6
Product Dimensions .................................................................. Page 7
BUTTON AND SWITCH ASSEMBLY
10271 RED
SWITCH HOUSING
19015 WRENCH
(1) PROVIDED
19001 SCREW ALLEN HEAD
#8 - 32 X 3/8 in. (1) PROVIDED
HOUSING REMOVAL
REMOVE SCREW. PULL BOTTOM OF HOUSING OUT AND LIFT UP UNTIL
TABS ARE RELEASED FROM SLOTS IN BUTTON AND SWITCH ASSEMBLY.
- 2 -
BACKBOX PREPARATION
J
J
J
J
H
SWITCH BACKPLATE
MOUNTING HOLES
BOX MUST BE INSTALLED WITH
ARROWS POINTING UPWARD
THESE HOLES MUST BE
DRILLED OUT USING A
5/32 in. DRILL BIT
H
J
OUNTING HOLESM
T
CKPLA
ACH BWITS
H
J
ALLED WITHTT BE INSUSX MOB
TE
ALLED WITH
J
J
WS POINTING UPWOARR
ALLED WITHTT BE INSUSX MOB
5/32 in. DRILL BIT
DRILLED OUT USING A
T BEUSTHESE HOLES M
H
ARDWS POINTING UPW
ALLED WITH
5/32 in. DRILL BIT
DRILLED OUT USING A
T BE
DRILL POINT LOCATIONS PROVIDED
TOP AND BOTTO M FOR 1/2 in.
CONDUIT FITTINGS .
DRILL AS NEEDED
S NEEDEDDRILL A
ONDUIT FITC
OP AND BT
DRILL POINT L
S NEEDED
.TINGSONDUIT FIT
OR 1/2 in.M FOTTOOP AND B
VIDEDOTIONS PROCADRILL POINT L
(NOT INCLUDED WITH FLUSH MOUNT COVERS)
FIELD DRILLING FOR CONDUIT ENTRY IS
REQUIRED. LOCATIONS SHOWN ALSO
APPLY TO OPPOSITE, PARALLEL SIDE.
- 3 -
COM
NO
NC
INCORRECT METHOD OF
INSERTING MULTIPLE LEADS
(BOTH WIRES ON
ONE SIDE OF SCREW)
CORRECT METHOD OF
INSERTING MULTIPLE LEADS
(1 WIRE EACH
SIDE OF SCREW)
WIRE CONNECTIONS
STRIP
3/8 in. (9mm)
COM
NO
NC
GREEN, OR WHITE.
C
HOOSE RED, YELLOW, BLUE,
M
OLDED OF POLYCARBONATE.
SWITCH HOUSING
(
PROVIDED)
WRENCH.
S
CREW &
RETAINING
HOUSING
S
WITCH
A
SWITCH ASSEMBLY AND BACK PLATE
W
ITH MOLDED-IN STAINLESS STEEL INSERT
(ALL FASTENERS SHOWN PROVIDED)
THIS SIDE
CONTACT SET 2
THIS SIDE
CONTACT SET 1
COM
NC
NO
CONTACT
SET 1
CONTACT
SET 2
- 4 -
TYPICAL FLUSH MOUNT
SINGLE GANG
OUTLET BOX
19021 GROUND SCREW
BUTTON AND SWITCH ASSEMBLY
19060 #6 - 32 x 1 in.
SCREW (2) PROVIDED
2.375 in.
(60mm)
.75 in.
(19mm)
1.5 in.
(38mm)
.75 in.
(19mm)
INSTALLATION
19021 GROUND SCREW
BUTTON AND SWITCH ASSEMBLY
19060 SCREW #6-32 x 1 in.
(2) PROVIDED
19039 SCREW #6 x 1-1/4 in.
(4) PROVIDED
71100A-COLOR SURFACE BOX
19018 ANCHOR
(4) PROVIDED
DRILL (4) 3/16 in.
DIA HOLES
ALLEN HEAD
L
OCKING SCREW
AND WRENCH
AND WRENCH
O
CKING SCREWL
ADALLEN HE
AND WRENCH
O
CKING SCREW
AD
(4) PR
19018 ANCHOR
DIA HOLES
DRILL (4) 3/16 in.
VIDEDO(4) PR
19018 ANCHOR
XOCE BAOR SURFOLC-71100A
VIDEDO(4) PR
1/4 in.-19039 SCREW #6 x 1
SEMBLSCH AWITON AND STBUT
OUND SCREW19021 GR
Y
VIDEDO(2) PR
19060 SCREW #6
VIDED
32 x 1 in.-19060 SCREW #6
- 5 -
INSTALLATION NOTE
ADA mounting compliance
requires the operable part of
the initiating device shall not
be less than 1.1m (3 1/2 ft.) or
greater than 1.37m (4 1/2 ft.)
above finished floor service.
KEY RESET PROCEDURE
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY
(CONCAVE SIDE UP)
WITH 2 SLOTS
UNDER BUTTON
PART #18061
PUSH IN UNTIL BUTTON POPS UP.
SWITCH IS NOW RESET
ALIGN SLOT IN KEY
(CONCAVE SIDE UP)
WITH 2 SLOTS
UNDER BUTTON
KEY-TO-RESET SLOT
LOCATED UNDER BUTTON
PART #18061
A
VIEW IN DIRECTION OF ARROW A
- 6 -
19021 GROUND SCREW
DRILL (4)
5/32 in. DIA.
H
OLES
PUSH
NC
NO
COM
4.87 in.
(124mm)
1.62 in.
(41mm)
3.25 in.
(82mm)
1.25 in.
(32mm)
(
4) PROVIDED
19021 GROUND SCREW
19018 ANCHOR
(
4) PROVIDED
B
UTTON AND SWITCH ASSEMBLY
1
9068 SCREW
SELF TAPPING
(4) PROVIDED
1.62 in.
(41mm)
3.18 in.
(81mm)
1.56 in.
(40mm)
PRODUCT DIMENSIONS
MODELS
WITHOUT BACKBOX
WITH BACKBOX
MODELS
WARRANTY
Three year guarantee against breakage of polycarbonate in normal use
(one year on electro mechanical and electronic components).
Electronic warranty form at www.sti-usa.com/wc14.
2306 Airport Rd • Waterford, MI 48327
Printed in USA
© 2004
Phone: 248-673-9898 • Fax: 248-673-1246
800-888-4STI (4784) • www.sti-usa.com
Safety Technology International (Europe) Ltd.
Unit 49G Pipers Road • Park Farm Industrial Estate • Redditch
Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999
Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only)
E-mail: info@sti-europe.com • Web: www.sti-europe.com
06/05
