4 in.
(
100mm)
4 in.
(
100mm)
1.4 in.
(35mm)
INSTALLATION INSTRUCTIONS
1. Do not remove thermostat. Prior to drilling anchor holes, cover thermostat with a
damp cloth to prevent dust from penetrating the sensor.
2. Center frame over existing thermostat. Mark and drill (4) anchor holes using a 1/4
in. (6.3mm) drill bit. Insert the (4) anchors and complete installation as shown.
NOTE: The (3) tabs on the frame must face upward (View A).
3. Insert the (3) slots on the cover over tabs on the top surface of frame. Rotate cover
downward onto the frame and turn key to lock.
CLEANING INSTRUCTIONS
To clean cover, remove from wall. Rinse with water to remove abrasive dust and
dirt. Wash with soap or mild detergent using a soft cloth (DO NOT SCRUB). Rinse
once more, then dry with a soft cloth or chamois. To remove grease or wet paint,
rub gently with a cloth wetted thoroughly with naphtha. Then wash and rinse.
DO NOT USE RAZOR BLADES.
All specifications and information shown were current as of publication, and are subject to change without notice.
INSTALLATION OF STI-9102 THERMOSTAT COVER
Electronic warranty form at www.sti-usa.com/wc14
