STI 34709 User Manual

Wireless Indoor PIR Motion Detector

Model STI-34701

Program sensor

before installation

Features

· APYROFLEX™ IR sensor and Highbar™ signal processing for superior
performance.

· 44 ft. range and 90 degree field of view (45 degrees to each side).

· Mountable on flat-wall or 45 degree corner.

· Cover tamper.

· Strong, reliable RF signal.

· 6-8 year battery life of CR123A battery.

· Low Battery indication.

We protect the things that protect you.

- 1 -

Programming Instructions

1. Remove cover by releasing snap closure located at the bottom center.

2. Put receiver in program mode (refer to receiver instructions for programming).

3. Remove Mylar tab from battery. Unit should immediately program into receiver, if not

press the tamper switch.

4. Motion sensitivity:

· Normal sensitivity: jumper on BOTH PINS

· High sensitivity: remove jumper

Mounting Instructions

1. Release holding tab and remove PCB (see internal view for tab location).

2. Remove screw knockouts for mounting.

3. Replace PCB. Make sure bug / insulation foam is installed.

4. Mount at 7.5ft (ideal height) with provided screws and optional anchors.

5. Replace cover. Unit immediately goes into 3 minute walk test. To reset walk test, remove

cover and reattach.

Walk Test LED

1. LED lights for 3 minutes when motion sensed (only during walk test).

2. Wireless transmissions are sent for each detection; so walk test can be used for receiver

test as well.

3. Motion stops (locks out) sensing for 20 seconds after LED flashes.

4. When complete, replace cover fixing screw.

Operation

1. Motion stops (locks out) transmitting wireless sensor alarms for 3 minutes after

sending an alarm transmission. This is to conserve battery life.

2. Walk Test LED does not activate in normal operating mode, only works during walk test.

3. Tamper: when cover is opened.

4. Supervisory: every hour.

- 2 -

Specications

· Mounting Hardware: #6 screw

· Mounting Height: 7.5ft (ideal height)

· Replacement battery: CR123A 1500mAH

· Temperature range: 0°F to 120°F

· Housing dimensions: 3.7” X 2.37” X 1.65”

Specifications subject to change without notice.

Side View

7.5 ft.

SENSITIVITY JUMPER

MOTION SENSOR

0

LOCK DOWN SHORT RANGE MIDDLE RANGE LONG RANGE

Top View

10 ft 20 ft 30 ft 40 ft

44 ft

0

44 ft

44 ft

BATTERY

+

MYLAR TAB

BUG FOAM

PCB HOLDING TAB

TAMPER AND WALK TEST SWITCH

WALK TEST LED

- 3 -
